Page 1

BD-E5900

Blu-ray

user manual

imagine the possibilities

Thank you for purchasing this Samsung product. To receive more complete service, please register your product at

www.samsung.com/register

™

Disc Player

Page 2

Safety Information

Warning

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lighting flash and Arrowhead within the triangle is a warning sign alerting you of dangerous voltage inside the product.

WARNING

• To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

FCC NOTE (for U.S.A)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on.

The user is encouraged to try to correct the interference by one or more of the following measures.

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment

and receiver.

• Connect this equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

• This class B digital product meets all requirements of the Canadian Interference Causing Equipment Regulations.

Note to CATV system installer

This reminder is provided to call CATV system installer's attention to Article 820-40 of the National Electrical Code (Section 54 of Canadian Electrical Code, Part I) that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The explanation point within the triangle is a warning sign alerting you of important instructions accompanying the product.

CLASS 1 LASER PRODUCT

This Compact Disc player is classified as a CLASS 1 LASER product. Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

Complies with 21CFR 1040.10 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.

DANGER :

• VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID DIRECT EXPOSURE TO BEAM. (FDA 21 CFR)

CAUTION :

• CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO THE BEAM. (IEC 60825-1)

• THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVER AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT PRODUCTO LÁSER CLASE 1

| NOTE |

\If the Region number of a Blu-ray Disc/DVDs does not

correspond to the Region number of this player, the player cannot play the disc.

2 English

Page 3

Precautions

Important Safety Instructions

Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install

in accordance with the manufacturer's instructions.

8. Do not install near any heat sources such

as radiators, heat registers, stoves, or other apparatus (including AV receivers) that produce heat.

9. Do not defeat the safety purpose of the

polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on

or pinched particularly at plugs, convenience receptacles, and the point where it exits the apparatus.

11. Only use attachments/accessories specified

by the manufacturer.

12. Use only with the cart,

stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms

or when unused for long periods of time.

14. Refer all servicing to qualified service

personnel. Servicing is required when the apparatus has been damaged in any way, such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Disc Storage & Management

• Holding Discs

- Fingerprints or scratches on a disc may reduce sound and picture quality or cause skipping

- Avoid touching the surface of a disc where data has been recorded.

- Hold the disc by the edges so that fingerprints will not get on the surface.

- Do not stick paper or tape on the disc.

• Cleaning Discs

- If you get fingerprints or dirt on a disc, clean it with a mild detergent diluted in water and wipe with a soft cloth.

- When cleaning, wipe gently from the inside to the outside of the disc.

• Disc Storage `Do not keep in direct sunlight. `Keep in a cool ventilated area. `Keep in a clean protection jacket and store

vertically.

Handling Cautions

• Do not expose this apparatus to dripping or

splashing. Do not put objects filled with liquids, such as vases on the apparatus.

• To turn this apparatus off completely, you must

pull the power plug out of the wall socket. Consequently, the power plug must be easily and readily accessible at all times.

01 Safety Information

English 3

Page 4

Safety Information

• Do not plug multiple electric devices into the same wall socket. Overloading a socket can cause it to overheat, resulting in a fire.

• Maintenance of Cabinet.

- Before connecting other components to this player, be sure to turn them off.

- If you move your player suddenly from a cold place to a warm place, condensation may occur on the operating parts and lens and cause abnormal disc playback. If this occurs, unplug the player, wait for two hours, and then connect the plug to the power outlet. Then, insert the disc, and try to play back again.

• If the product makes an abnormal noise or produces a burning smell or smoke, turn off the power switch immediately and disconnect the power plug from the wall outlet. Then, contact the nearest customer service center for technical assistance. Do not use the product. Using the product as it is may cause a fire or an electric shock.

Using the 3D function

IMPORTANT HEALTH AND SAFETY INFORMATION FOR 3D PICTURES. Read and understand the following safety information before using the 3D function.

• Some viewers may experience discomfort while viewing 3D TV such as dizziness, nausea, and headaches. If you experience any such symptom, stop viewing 3D TV, remove the 3D Active Glasses, and rest.

• Watching 3D images for an extended period of time may cause eye strain. If you feel eye strain, stop viewing 3D TV, remove your 3D Active Glasses, and rest.

• A responsible adult should frequently check on children who are using the 3D function. If there are any reports of tired eyes, headaches, dizziness, or nausea, have the child stop viewing 3D TV and rest.

• Do not use the 3D Active Glasses for other purposes (Such as general eyeglasses, sunglasses, protective goggles, etc.)

• Do not use the 3D function or 3D Active Glasses while walking or moving around. Using the 3D function or 3D Active Glasses while moving around may cause you to bump into objects, trip, and/or fall, and cause serious injury.

• If you want to enjoy 3D content, connect a 3D device (3D compliant AV receiver or TV) to the player's HDMI OUT port using a high-speed HDMI cable. Put on 3D glasses before playing the 3D content.

• The player outputs 3D signals only through HDMI cable connected to the HDMI OUT port.

• As the video resolution in 3D play mode is fixed according to the resolution of the original 3D video, you can not change the resolution to your preference.

• Some functions such as BD Wise, screen size adjustment, and resolution adjustment may not operate properly in 3D play mode.

• You must use a high-speed HDMI cable for proper output of the 3D signal.

• Stay at least three times the width of the screen from the TV when watching 3D images. For example, if you have a 46-inch screen, stay 138 inches (11.5 feet) from the screen.

• Place the 3D video screen at eye level for the best 3D picture.

• When the player is connected to some 3D devices, the 3D effect may not function properly.

• This player does not convert 2D content into 3D.

• "Blu-ray 3D" and "Blu-ray 3D" logo are trademarks of the Blu-ray Disc Association.

Copyright

manual may be reproduced or copied without the prior written permission of Samsung Electronics Co.,Ltd.

4 English

Page 5

Contents

SAFETY INFORMATION

2 Warning

3 Precautions

3 Important Safety Instructions

3 Disc Storage & Management

3 Handling Cautions

4 Using the 3D function

4 Copyright

GETTING STARTED

7 Disc and Format Compatibility

7 Disc types and contents your player can

play

7 Disc types your player cannot play

8 Region Code

8 Logos of Discs the player can play

9 Supported Formats

11 Accessories

12 Front Panel

12 Rear Panel

13 Remote Control

13 Tour of the Remote Control

CONNECTIONS

14 Connecting to a TV

15 Connecting to an Audio System

15 Method 1 Connecting to an HDMI

supported AV receiver

15 Method 2 Connecting to an AV receiver

with Dolby Digital or DTS decoder

16 Connecting to a Network Router

16 Wired Network

16 Wireless Network

SETTINGS

17 The Initial Settings Procedure

17 The Home Screen

18 Accessing the Settings Screen

18 Buttons on the Remote Control Used for

the Settings Menu

19 Settings Menu Functions

24 Networks and the Internet

24 Configuring Your Network Connection

26 Wi-Fi Direct

27 Soft AP

28 AllShare Settings

28 Upgrading Software

28 By Online

29 By USB

29 By Disc

29 By Downloaded

30 Standby Mode Upgrade

MEDIA PLAY

31 Playing Commercial Video Discs

31 The AllShare Play Screen

31 Accessing the AllShare Play Screen

31 The AllShare Play Screen at a Glance

31 Playing Files on a USB Device or USB

Compatible Mobile Phone

32 Playing Commercial Audio Discs

32 Music Screen Controls

33 Playing a Disc with User Recorded

Content

33 Using the AllShare Network Function

33 To Download the AllShare Software

34 Playing Content Located on Your PC or

DLNA Device through the Blu-ray Disc Player

34 Controlling the Playback of Content

Located on Your PC with Your Smart Phone

Contents

English 5

Page 6

Contents

35 Controlling Video Playback

35 Buttons on the Remote Control used for

Video Playback

35 Using the Tools Menu

37 Controlling Music Playback

37 Buttons on the Remote Control used for

Music Playback

37 Using the Tools Menu

38 Repeating Tracks on an Audio CD

38 Shuffling Tracks on an Audio CD

38 Creating a Playlist from a CD

38 Ripping

39 Playing Photo Contents

39 Using the Tools Menu

40 Using the Tools Menu when a file is

highlighted

NETWORK SERVICES

42 Using Smart Hub

42 Smart Hub at a Glance

43 Using the Web Browser

44 BD-LIVE™

44 Using Disc to Digital

APPENDIX

45 Compliance and Compatibility Notice

46 Copy Protection

46 Network Service Disclaimer

47 License

48 Additional Information

48 Note

50 Resolution according to the contents type

51 Digital Output Selection

52 Troubleshooting

54 Repairs

55 Specifications

6 English

Page 7

Getting Started

Disc and Format Compatibility

Disc types and contents your player can play

Media Disc Type Details

Blu-ray Disc

3D Blu-ray Disc

VIDEO

MUSIC


| NOTE |

\The player may not play certain CD-RW/-R and DVD-R because of the disc type or recording conditions.

\If a DVD-RW/-R has not been recorded properly in DVD video format, it will not be playable.

\Your player will not play content that has been recorded on a DVD-R at a bit-rate that exceeds 10 Mbps.

\Your player will not play content that has been recorded on a BD-R or USB device at a bitrate that exceeds 25 Mbps.

\Playback may not work for some types of discs, or when you use specific functions, such as angle change and aspect ratio

adjustment. Information about the discs is written in detail on the disc box. Please refer to this if necessary.

\When you play a BD-J title, loading may take longer than a normal title or some functions may perform slowly.

DVD-VIDEO

DVD-RW

DVD-R

DVD+RW

DVD+R

CD-RW/-R,

DVD-RW/-R,

BD-RE/-R

CD-RW/-R,

DVD-RW/-R,

BD-RE/-R

BD-ROM or BD-RE/-R recorded in the BD-RE format.

DVD-VIDEO, recorded DVD+RW/DVD-RW(V)/DVD-R/+R that have been recorded and finalized, or a USB storage media containing MKV, MP4 contents.

Music recorded on CD-RW/-R, DVD-RW/-R, BD-RE/-R or a USB storage media containing MP3 or WMA contents.

Photos recorded on CD-RW/-R, DVD-RW/-R, BD-RE/-R or a USB storage media containing JPEG contents.

02 Getting Started

Disc types your player cannot play

• HD DVD

• DVD-ROM/PD/

MV, etc

• DVD-RAM

• Super Audio CD

(except CD layer)

• DVD-RW(VR mode)

• CVD/CD-ROM/CDV/

CD-G/CD-I/LD (CD-Gs play audio only, not graphics.)

• 3.9 GB DVD-R for Authoring.

English 7

Page 8

Getting Started

Region Code

Both players and discs are coded by region. These regional codes must match for a disc to play. If the codes do not match, the disc will not play. The Region Number for this player is displayed on the rear panel of the player.

Disc Type

Blu-ray Disc

DVD-VIDEO

Region

Code

North America, Central America, South America, Korea, Japan,

Taiwan, Hong Kong and South East Asia.

Europe, Greenland, French territories, Middle East, Africa,

Australia and New Zealand.

India, China, Russia, Central and

South Asia.

The U.S., U.S. territories and

Canada

Europe, Japan, the Middle East,

Egypt, South Africa, Greenland

Taiwan, Korea, the Philippines,

Indonesia, Hong Kong

Mexico, South America, Central America, Australia,

New Zealand, Pacific Islands, Caribbean

Russia, Eastern Europe, India, most of Africa, North Korea,

Mongolia

Area

Logos of Discs the player can play

Blu-ray Disc 3D Blu-ray Disc

BD-LIVE

NTSC broadcast system in

U.S.A, Canada, Korea, Japan

8 English

China

Page 9

Supported Formats

Video File Support

02 Getting Started

File Extension Container Video Codec Resolution

*.avi

*.mkv

*.asf *.wmv *.mp4

*.3gp

*.vro

*.mpg

*.mpeg

*.ts *.tp

*.trp

`Limitations

- Even when a file is encoded by a supported codec listed above, the file might not be played if its content is defective or corrupted.

- Normal playback is not guaranteed if the file's container information is wrong or the file itself is corrupted.

- Files having higher bit or frame rates than standard may stutter when played back.

- The seek (skip) function is not available if the file's index table is damaged.

- When you playback a file remotely through a network connection, video playback may stutter depending on the network speed.

- Some USB/Digital camera devices may not be compatible with the player.

`Video decoder

- Supports up to H.264 Level 4.1

- Does not support GMC 2 or higher

`Audio decoder

- Supports WMA 7, 8, 9 and STD

- Does not support WMA 9 PRO multi-channel or lossless audio if the number of channels is more than 2.

- Does not support WMA sampling rate of 22050Hz mono.

AVI MKV ASF MP4 3GP VRO VOB

PS TS

MPEG4 SP/ASP

H.264 BP/

MP/HP

Window

Media Video v9

MPEG2

MPEG1 352x288

1920x1080

Frame rate

(fps)

6~30

24/25/30

24/25/3 20

Bitrate (Mbps) Audio Codec

Dolby Digital

LPCM

AAC

HE-AAC

WMA

Dolby Digital Plus

MP3 DTS

English 9

Page 10

Getting Started

`Comments

- MPEG4 : Supports up to GMC 1-Warping Point.

- H.264 : Supports up to BP/MP/HP Level 4.1.

- WMV : Supports V9, VC1 SP/MP/AP L3.

- MPEG1 : Does not support D-picture.

- MPEG2 : Supports up to Hight Profile High Level.

| NOTE |

\Some MKV and MP4 format discs may not play,

depending on their video resolution and frame rate.

Music File Support

File

Extension

*.mp3

*.wma

Container

MP3

WMA

Audio

Codec

Support Range

MP3 -

* Sampling rates (in kHz) - 8, 11, 16, 22, 32, 44.1, 48

WMA

* Bitrates - All bit rates in the range 5kbps to 384kbps

Notes on the USB connection

• Your player supports USB storage media, MP3 players, digital cameras, and USB card readers.

• Some USB/digital camera devices may not be compatible with the player.

• Your player supports the FAT16, FAT32, and NTFS files systems.

• Connect USB devices directly to the player's USB port. Connecting through a USB cable may cause compatibility problems.

• Inserting more than one memory device into a multi-card reader may cause the reader to operate improperly.

• The player does not support the PTP protocol.

• Do not disconnect a USB device during a

"loading" process.

• The bigger the image resolution, the longer the image takes to display.

• This player cannot play MP3 files with DRM (Digital Rights Management) downloaded from commercial sites.

• Your player only supports video that is under 30fps (frame rate).

• Your player only supports USB Mass Storage Class (MSC) devices such as thumb drives and USB HDD. (HUB is not supported.)

• Certain USB HDD Devices, multi-card readers and thumb drives may not be compatible with this player.

• If some USB devices require excessive power, they may be limited by the circuit safety device.

• If playback from a USB HDD is unstable, provide additional power by plugging the HDD into a wall socket. If the problem continues, contact the USB HDD manufacturer.

• You must remove the USB storage device safely. (by performing the "Safely Remove USB" function to prevent possible damage to the USB memory.) Press the HOME button to move to the home screen, press the YELLOW (C) button, and then press the v button.

• SAMSUNG is not responsible for any data file damage or data loss.

• Your player does not support compression file, sparse file and encryption file of NTFS.

- Before disconnecting a USB device, please use USB Safety Removal.

- If you don't use USB Safety Removal, your data on USB device can be corrupted or lost

- You can repair or format a USB device on your Desktop PC. (MS-Windows OS only)

10 English

Page 11

AVCHD (Advanced Video Codec High Definition)

• This player can play back AVCHD format discs. These discs are normally recorded and used in camcorders.

• The AVCHD format is a high definition digital video camera format.

• The MPEG-4 AVC/H.264 format compresses images with greater efficiency than the conventional

image compressing format.

• Some AVCHD discs use the "x.v.Color" format. This player can play back AVCHD discs that use "x.v.Color" format.

• "x.v.Color" is a trademark of Sony Corporation.

• "AVCHD" and the AVCHD logo are trademarks of Matsushita Electronic Industrial Co., Ltd. and Sony

Corporation.

| NOTE |

\Some AVCHD format discs may not play, depending on the recording conditions.

AVCHD format discs need to be finalized.

\"x.v.Color" offers a wider color range than normal DVD camcorder discs.

Accessories

Check for the supplied accessories shown below.

02 Getting Started

Batteries for Remote Control (AAA Size)

(BN43-00004A)

Quick Guide

(AK68-02232C)

User Manual

(AK68-02228A)

SOURCE

VOL VOL

– +

VOL

–

SAMSUNG TV

DISC MENU

TITLE MENU

POPUP

HOME SMART

HOME

HUB

INFOTOOLS

RETURN

EXIT

A B C D

AUDIO SUBTITLE FULL

PANDORA

SCREEN

PANDORA

DIGITAL

SUBTITLE

INPUT

Remote Control (AK59-00145A)

English 11

Page 12

Getting Started

Front Panel

OPEN/CLOSE BUTTON PLAY/PAUSE BUTTON

POWER BUTTON

DISPLAY USB HOST

REMOTE CONTROL SENSOR

DISC TRAY

| NOTE |

\To upgrade the player's software through the USB Host jack, you must use a USB memory stick.

\When the player displays the Blu-ray Disc menu, you cannot start the movie by pressing the Play button on the player or the

remote. To play the movie, you must select Play Movie or Start in the disc menu, and then press the v button.

Rear Panel

12 English

LAN

HDMI OUT DIGITAL AUDIO OUT

Page 13

Remote Control

Tour of the Remote Control

02 Getting Started

After setup, allows you to set the input

(This button is only available in samsung TV.)

Press to open and close the disc tray.

Press numeric buttons to operate options.

Press to skip backwards or forwards.

Press to move to the home screen.

These buttons are used both for menus

on the player and also several Blu-ray Disc

Use to access various audio functions on a

source on your TV.

Turn the player on and off.

Use to enter the disc menu.

Press to stop a disc.

Press to use Netflix.

Press to use the Tools menu.

Return to the previous menu.

functions.

disc.

Press to use Pandora.

SOURCE

VOL VOL

– +

VOL

SAMSUNG TV

SUBTITLE

TITLE MENU

POPUP

HUB

INFOTOOLS

EXIT

SCREEN

INPUT

DISC MENU

HOME SMART

HOME

RETURN

A B C D

AUDIO SUBTITLE FULL

PANDORA

DIGITAL

Turn the TV on and off. (This button is only available in samsung TV.)

–

TV volume adjustment. (This button is only available in samsung TV.)

Use to enter the Popup menu/Title menu.

Press to search backwards or forwards.

Press to pause a disc.

Press to play a disc.

Press to use Smart Hub.

Use to display the playback information.

Use to select menu items and change menu values.

Press to exit the menu.

Press to use full screen function.

Press to switch the Blu-ray Disc/DVD's subtitle language.

Installing batteries

| NOTE |

\If the remote does not operate properly:

- Check the polarity +/– of the batteries.

- Check if the batteries are drained.

- Check if the remote sensor is blocked by obstacles.

- Check if there is any fluorescent lighting nearby.

| CAUTION |

\Dispose of batteries according to local environmental

regulations. Do not put them in the household trash.

English 13

Page 14

Connections

Connecting to a TV

Connect an HDMI cable (not supplied) from the HDMI OUT jack on the back of the product to the HDMI IN jack on your TV.

- Do not connect the power cord to the wall outlet until you have made all the other connections.

- When you change the connections, turn off all devices before you start.

Audio Video

| NOTE |

\If you use an HDMI-to-DVI cable to connect to your display device, you must also connect the Digital Audio Out on the player

to an audio system to hear audio.

\An HDMI cable outputs digital video and audio, so you don't need to connect an audio cable.

\Depending on your TV, certain HDMI output resolutions may not work. Please refer to the user manual of your TV.

\When you connect the player to your TV using the HDMI cable or to a new TV, and then turn it on for the first time, the player

automatically sets the HDMI output resolution to the highest supported by the TV.

\A long HDMI cable may cause screen noise. If this occurs, set HDMI Deep Color to Off in the menu.

\To view video in the HDMI 720p, 1080i, or 1080p output mode, you must use a High speed (category 2) HDMI cable.

\HDMI outputs only a pure digital signal to the TV.

If your TV does not support HDCP (High-bandwidth Digital Content Protection), random noise appears on the screen.

14 English

Page 15

Connecting to an Audio System

You can connect the Blu-ray player to an the audio system using the method illustrated below.

- Do not connect the power cord to the wall outlet until you have made all the other connections.

- When you change the connections, turn off all devices before you start.

Method 1 Connecting to an HDMI supported AV receiver

• Connect an HDMI cable (not supplied) from the HDMI OUT jack on the back of the product to the HDMI IN jack on your receiver.

• Best quality (Recommended)

Method 2 Connecting to an AV receiver with Dolby Digital or DTS decoder

• Using a digital Coaxial cable (not supplied), connect the Coaxial Digital Audio Out jack on the product to the Digital Coaxial In jack of the receiver.

• Good quality

• You will hear sound only through the front two speakers with Digital Output set to PCM.

Method 2Method 1

AudioAudio

03 Connections

English 15

Page 16

Connections

Connecting to a Network Router

You can connect your player to your network router using one of the methods illustrated below.

To use the AllShare network functionality, you must connect your PC to your network as shown in the illustrations. The connection can be wired or wireless.

Wired Network

Broadband modem

(with integrated router)

Broadband

Router

Broadband

modem

| NOTE |

\Internet access to Samsung's software update server

may not be allowed, depending on the router you use or your ISP's policy. For more information, contact your ISP (Internet Service Provider).

\DSL users, please use a router to make a network

connection.

service

Broadband service

Wireless Network

Wireless Router

Broadband

service

| NOTE |

\If your wireless router supports DHCP, this player can use

a DHCP or static IP address to connect to the wireless network.

\Set your wireless router to Infrastructure mode. Ad-hoc

mode is not supported.

\The player supports only the following wireless security

key protocols:

- WEP (OPEN/SHARED), WPA-PSK (TKIP/AES),

WPA2-PSK (TKIP/AES)

\Select a channel on the wireless router that is not

currently being used. If the channel set for the wireless router is currently being used by another device nearby, it will result in interference and communication failure.

\If you select the Pure High-throughput (Greenfield)

802.11n mode and set the Encryption type on your router or router to WEP, TKIP or TKIP-AES (WPS2Mixed), the player will not support a connection in compliance with new Wi-Fi certification specifications.

\Wireless LAN, by its nature, may cause interference,

depending on the operating conditions (router performance, distance, obstacles, interference by other radio devices, etc).

16 English

Page 17

Settings

The Initial Settings Procedure

• The Home screen will not appear if you do not configure the initial settings.

• The OSD (On Screen Display) may change in this player after you upgrade the software version.

• The access steps may differ depending on the menu you selected.

The Initial Settings Procedure lets you set the OSD and menu languages, configure the connection to your home network, choose the aspect ratio output (screen size and format) that is correct for your TV, and apply an upgrade to your player's software, if one is available. For complete Initial Settings instructions, see the Quick Start Guide.

| NOTE |

\If you skip Network Setup during the Initial Settings

procedure, you can configure your network settings later. See "Configuring Your Network Connection" on pages 24~26 for instructions.

If you want to display the Initial Settings screen again and make changes, select Settings > System > Initial Settings in the Home screen or select the Reset option. (See pages 21 or 23)

\If you want to use an Anynet+(HDMI-CEC) function,

please follow the instructions below.

1) Connect the player to an Anynet+(HDMI-CEC)compliant Samsung TV using HDMI Cable.

2) Set the Anynet+(HDMI-CEC) feature to On in both the TV and the player.

3) Set the TV to the Initial Settings Procedure.

The Home Screen

Settings

Set various functions to suit your personal preferences.

Smart Hub

Smart Hub : Starts Smart Hub. From Smart Hub,

you can access YouTube, games, and other apps.

AllShare Play : Play videos, photos or music

content from Disc, USB, PC or mobile devices.

Disc to Digital : Access you movie collection via cloud storage anytime, any place without your DVD

disc.

Settings : Set various functions to suit your

personal preferences.

`Selecting an Option on the Home Screen

1. To select an option on the Home screen,

move the cursor using the ◄► buttons until it highlights the option of your choice, and then press the v button.

| NOTE |

If you leave the player in the stop mode for more than 5 minutes without using it, a screen saver will appear on your TV. If the player is left in the screen saver mode for

more than 20 minutes, the power will automatically turn off.

AllShare Play Disc to Digital

04 Settings

English 17

Page 18

Settings

HOME

VOL

–

SOURCE

DISC MENU

HOME SMART

TITLE MENU

VOL VOL

POPUP

SAMSUNG TV

HUB

– +

INFOTOOLS

RETURN

EXIT

Accessing the Settings Screen

1. Select Settings on the Home screen, and

then press v button. The Settings screen appears.

3D Settings

Display

TV Aspect Ratio 16:9 Original

Smart Hub Screen Size Size 3

Audio

BD Wise On

Resolution Auto

Network

Movie Frame (24Fs) Auto

System

HDMI Color Format Auto

HDMI Deep Color Auto

Support

Progressive Mode Auto

2. To access the menus, sub-menus, and

options on the Settings screen, please refer to the remote control illustration below.

Buttons on the Remote Control Used for the Settings Menu

Detailed Function Information

Each Settings function, menu item, and individual option is explained in detail on-screen. To view an explanation, use the ▲▼◄► buttons to select the function, menu item, or option. The explanation will usually appear on the right side of the screen. A short description of each Settings function starts on the next page. Additional information on some of the functions is also in the Appendix of this manual.

2 4

HOME Button : Press to move to the Home screen.

RETURN Button : Return to the previous menu.

• Press ▲▼◄► to move the cursor or select an

• Press the v button to activate the currently

EXIT Button : Press to exit the current menu.

18 English

(Enter) / DIRECTION Buttons :

item.

selected item or confirm a setting.

Page 19

Settings Menu Functions

Display

3D Settings

TV Aspect Ratio

Smart Hub Screen Size

BD Wise

Resolution

Movie Frame (24Fs)

HDMI Color Format

HDMI Deep Color

Progressive Mode Lets you improve picture quality when viewing DVDs.

Select whether to play a Blu-ray Disc with 3D contents in 3D Mode.

•

If you move to the Home or Smart Hub Home screen while in 3D mode, the player will switch to 2D automatically.

Lets you adjust the output of the player to the screen size and screen format of your TV.

Lets you select the optimal size for the Smart Hub Screen.

BD Wise is Samsung's latest inter-connectivity feature. When you connect a Samsung player and a Samsung TV with BD Wise to each other via HDMI, and BD Wise is on in both the player and TV, the player outputs video at the video resolution and frame rate of the Blu-ray Disc/DVD.

Set the output resolution of the HDMI video signal to Auto, 1080p, 1080i, 720p or 480p. The number indicates the number of lines of video per frame. The i and p indicate interlaced and progressive scan, respectively. Generally, the higher quality.

If the player is connected to a 24Fs compatible TV, setting the Movie Frame (24Fs) feature to Auto lets the player adjust its HDMI output to 24 frames per second automatically for improved picture quality.

•

You can enjoy the Movie Frame (24Fs) feature only on a TV supporting this frame rate.

•

Movie Frame is only available when the player is in the HDMI 1080i or 1080p output resolution modes.

Lets you set the color space format for the HDMI output so that it matches the capabilities of the connected device (TV, monitor, etc). The screen goes black momentarily after you have selected a format.

Lets you set the product to output HDMI video with Deep Color. Deep Color provides more accurate color reproduction with greater color depth.

04 Settings

English 19

Page 20

Settings

Audio

Network

Digital Output

PCM Downsampling

Dynamic Range Control

Downmixing Mode

Network Settings

Network Status Lets you check the current network and Internet status.

Lets you select the digital audio output format that is suitable for your TV or AV Receiver. For more details, see the digital output selection table on page 51.

Lets you choose to have 96Khz PCM signals downsampled to 48Khz before they are outputted to an amplifier. Choose On if your amplifier or receiver is not compatible with a 96Khz signal.

Lets you apply dynamic range control to Dolby Digital, Dolby Digital Plus, and Dolby TrueHD audio.

Auto : Automatically controls the dynamic range of

Dolby TrueHD audio, based on information in the Dolby TrueHD soundtrack. Also turns dynamic range control on for Dolby Digital and Dolby Digital Plus.

Off : Leaves the dynamic range uncompressed,

letting you hear the original sound.

On : Turns dynamic range control on for all three

Dolby formats. Quieter sounds are made louder and the volume of loud sounds is reduced.

Lets you select the multi-channel downmix method that is compatible with your stereo system. You can choose to have the player downmix to normal stereo or to surround compatible stereo.

Configure the network connection so you can enjoy various features such as Internet services or AllShare Wi-Fi functionality, and perform software upgrades.

20 English

Wi-Fi Direct

Lets you connect a Wi-Fi Direct device to the player using a peer-to-pear network, without the need for a wireless router Note that if you set wireless network, it may be disconnected while you're using Wi-Fi Direct.

| NOTE |

\A text file, such as file with a .TXT or .DOC extension is not

play when using the Wifi Direct function.

Page 21

Network

Soft AP

AllShare Settings

Device Name

BD-Live Settings

Lets you connect other types of Wi-Fi devices to the player wirelessly. Requires that you create a security key which you must enter into the other Wi-Fi devices when you are connecting them to the network.

Lists network connected AllShare devices and lets you control whether each device (a smartphone, a tablet, etc.) can share content with or control the player.

Lets you input a name for the player that will identify it on your networks.

Set various BD-Live function. BD-Live allows you to access extra features available on some Blu-ray Discs if you are connected to the Internet.

BD-Live Internet Connection : Lets you fully allow,

partly allow, or prohibit a BD-Live Internet connection.

BD Data Management : Manage BD data

downloaded from a BD-Live service or Blu-ray Disc.

04 Settings

System

Initial Settings

Quick Start

Lets you re-run the Initial Settings procedure. See the Quick Start Guide for details.

Lets you set the player to turn on quickly by decreasing the boot time.

| NOTE |

\If this function set to On, Standby power consumption will be

increased.

English 21

Page 22

Settings

System

Anynet+ (HDMI-CEC)

Device Manager

Language

Anynet+ is a convenient function that offers linked operations with other Samsung players that have the Anynet+ feature and lets you control those products with one Samsung TV remote. To operate this function, you must connect this player to an Anynet+ Samsung TV using an HDMI cable.

You can connect a wireless USB keyboard or mouse to the USB port on the front of the player.

Keyboard Settings : Lets you configure a wireless

USB keyboard connected to the player.

| NOTE |

\You can use the keyboard only when a QWERTY keyboard

screen or window appears in the Web Browser.



Mouse Settings : Lets you configure a wireless USB mouse connected to the player. You can use the mouse in the player's menu in the same way you use a mouse on your PC.

`To use a mouse with the player's menu:

Connect the USB mouse to the player.

Click the primary button you selected in Mouse Settings. The Simple Menu appears.

Click the menu options you want.

| NOTE |

\Depending on the model of the USB HID keyboard and mouse

may not be compatible with your product.

\Some HID keyboard keys may not work.

\Wired USB keyboards are not supported.

\Some applications may not be supported.

\If a wireless HID Keyboard does not operate because of

interference, move the keyboard closer to the player.

You can select the language you prefer for the Onscreen menu, disc menu, subtitles, etc.

•

The language you select for the disc menu, disc audio, or subtitles will only appear if it is supported on the disc.

22 English

Page 23

System

Security

General

The default PIN is 0000. Enter the default PIN to access the security function if you haven't created your own PIN. After you have accessed the security function for the first time, change the PIN using the Change PIN function.

BD Parental Rating : Prevents playback of Blu-ray

Discs with a rating equal to or above a specific age rating you enter unless the PIN is entered.

DVD Parental Rating : Prevents playback of DVDs

with a rating above a specific numerical rating you select unless the PIN is entered.

Change PIN : Change the 4-digit PIN used to access

security functions.

`If you forget your PIN:

Remove any disc or USB storage device.

Press and hold the p button on the front panel for 5 seconds or more. All settings will revert to the factory settings.

You can change the options listed below to match your preferences.

Time Zone : Select the time zone in which you live. Menu Transparency : Adjust the transparency of the

menu box.

04 Settings

Support

Software Upgrade

Contact Samsung

Remote Management

Reset

For more information about the Software Upgrade function, see "Upgrading Software" on pages 28~30.

Provides contact information for assistance with your player.

When activated, lets Samsung Call Center agents diagnose and fix problems with the product remotely. Requires an active Internet connection.

| NOTE |

\Remote Management service might not be available in some

countries.

\Contact your nearest service center for your PIN code and tell

the code to the person in charge. It enables remote diagnosis of the product and required measures.

Resets all settings to their default settings except for the network and Smart Hub settings. The default security PIN is 0000.

English 23

Page 24

Settings

Networks and the Internet

When you connect this player to a network, you can use network based applications and functions such as Smart Hub and BD-LIVE, and upgrade the player's software through the network connection. For more information about accessing and using Internet services, see the Network Services chapter of this manual on pages 42~44. Instructions for configuring the network connection start below.

Configuring Your Network Connection

Before you begin, contact your ISP to find out if your IP address is static or dynamic. If it is dynamic, and you have a wired or wireless network, we recommend using the Automatic configuration procedures described below.

If you are connecting to a wired network, connect the player to your router using a LAN cable before you start the configuration procedure. If you are connecting to a wireless network, disconnect any wired network connection before you begin. To begin configuring your network connection, follow these steps:

1. In the Home screen, select Settings, and

then press the v button.

2. Select Network, and then press the v

button.

3. Select Network Settings, and then press the

button.

4. Go to the instructions for Wired networks

starting below or the instructions for Wireless networks starting on page 25.

Wired Network

Wired - Automatic

After following Steps 1 to 3 above:

1. Select Start in the Network Settings screen,

and then press the v button. The player detects the wired connection, verifies the network connection and then connects to the network.

Wired - Manual

If you have a static IP address or the Automatic procedure does not work, you'll need to set the Network Settings values manually.

After following Steps 1 to 3 above:

1. Select Start in the Network Settings screen,

and then press the v button. The Network Status screen appears. The player attempts to verify the network connection and fails.

Network Settings

Wired network connection failed.

IP auto setting failed. Try the following to set your IP address automatically. Or set your IP address manually by selecting 'IP Settings'.

- Ensure DHCP server is enabled on router and unplug and re-plug-in the router.

- Contact your Internet Service Provider for more information.

MAC Address XX:XX:XX:XX:XX:XX IP Address 0.0.0.0 Subnet Mask 0.0.0.0 Gateway 0.0.0.0 DNS Server 0.0.0.0

IP Settings

Retry

2. Select IP Settings on the right of the screen,

and press the v button. The IP Settings screen appears.

3. Select the IP Mode field, and then set it to

Manual.

4. Use the number keypad on your remote to

enter the Network values. Use the ▲▼◄► buttons on the remote to move from entry field to entry field.

| NOTE |

\You can get these values from your Internet provider. You

can also view these values on most Windows computers. For instructions, see "Getting the Network Settings Values." on page 25.

5. When done, highlight OK, and then press

button. The player verifies the network

connection and then connects to the network.

24 English

Page 25

< Getting the Network Settings Values >

You can view your Network Settings values on most Windows computers. To view the Network Settings values, follow these steps:

• Windows XP

1. Right click the Network icon on the bottom

right of the Windows desktop.

2. In the pop-up menu, click Status.

3. On the dialog that appears, click the Support

tab.

4. On the Support tab, click the Details button.

The Network settings are displayed.

• Windows 7

1. Click the Network icon on the bottom right of

the Windows desktop.

2. In the pop-up menu, click Network and

Sharing Center.

3. On the dialog that appears, click the Local

Area Connection or Wireless Network Connection depending on your network connection.

4. On the Support tab, click the Details button.

The Network settings are displayed.

| NOTE |

\Depending on your Windows version, the information may

differ.

Wireless Network

You can setup a wireless network connection in three ways:

- Wireless Automatic

- Wireless Manual

- WPS(PBC)

When you configure the wireless network connection, any wireless network devices currently connected through the player or, if applicable, the player's current wired connection, will be disconnected.

Wireless (General) - Automatic

After followng Steps 1 to 3 in "Configuring Your Network Connection" on page 24.

1. Select Start in the Network Settings screen,

and then press the v button. The player searches for and then displays a list of the available networks.

Network Settings

Select your wireless router from the list.

iptime23

ELT

JSY

KT_WLAN_C361

Mirhenge_edu

SO070VOIP

Refresh

WPS(PBC)

Cancel

2. Select the desired network, and then press

the v button.

3. Select Next, and then press the v button

again.

4. On the Security screen, enter your network's

Security Code or Pass Phrase. Enter numbers directly using the number buttons on your remote control. Enter letters by selecting a letter with an arrow button, and then pressing v button.

5. When done, select Next at the right of the

screen. The player verifies the network connection and then connects to the network.

| NOTE |

\You should be able to find the Security Code or Pass

Phrase on one of the set up screens you used to set up your router or modem.

Wireless (General) - Manual

If you have a static IP address or the Automatic procedure does not work, you'll need to set the Network Settings values manually.

After folloiwng Steps 1 to 3 in "Configuring Your Network Connection" on page 24.

04 Settings

English 25

Page 26

Settings

1. Select Start in the Network Settings screen,

and then press the v button. The player searches for and then displays a list of the available networks.

2. Select the desired network, and then press

the v button.

3. Select Next, and then press the v button

again.

4. On the Security screen, enter your network's

Security Code or Pass Phrase. Enter numbers directly using the number buttons on your remote control. Enter letters by selecting a letter with the ▲▼◄► buttons, and then pressing the v button.

5. When done, select Next at the right of the

screen, and then press the v button.

6. The Network Status screen appears.

The player attempts to verify the network connection and fails.

7. Select IP Settings on the right of the screen,

and press the v button. The IP Settings screen appears.

8. Select the IP Mode field, and then set it to

Manual.

9. Use the number keypad on your remote to

enter the Network values. Use the ▲▼◄► buttons on the remote to move from entry field to entry field.

| NOTE |

\You can get these values from your Internet provider. You

can also view these values on most Windows computers. For instructions, see "Getting the Network Settings Values." on page 25.

10. When done, highlight OK, and then press v

button. The Network Status screen appears. The product verifies the network connection and then connects to the network. When it is done, highlight OK, and then press v button.

WPS(PBC)

After followng Steps 1 to 3 in "Configuring Your Network Connection" on page 24.

1. Select Start in the Network Settings screen,

and then press the v button. The player searches for and then displays a list of the available networks.

2. Press the WPS(PBC) button on your router

within two minutes. Your player automatically acquires all the network settings values it needs and connects to your network. The Network Status screen appears. The player connects to the network after the network connection is verified.

Wi-Fi Direct

The Wi-Fi Direct function allows you to connect Wi-Fi Direct devices to the player and each other using a peer-to-peer network, without a wireless router.

| NOTE |

\Some Wi-Fi Direct devices may not support the AllShare

function if connected via Wi-Fi Direct. If this is the case, it is advisable to change the network connection method between devices.

1. Turn on the Wi-Fi direct device and activate

its Wi-Fi Direct function.

2. In the Home screen, select Settings, and

then press the v button.

3. Select Network, and then press the v

button.

4. Select Wi-Fi Direct, and then press the v

button. The Wi-Fi Direct devices that you can connect appear.

Display

Audio

Network

System

Support

Wi-Fi Direct

Refresh

' Return

Device Name : [BD]E5900

Select your Wi-Fi Direct device to connect to.

AndroidXXXXXXX Disconnected

26 English

Page 27

5. You have three ways to complete the Wi-Fi

connection:

• Through the Wi-Fi device.

• Through the player using PBC.

• Through the player using a PIN.

Each is covered below.

Through the Wi-Fi Device

1. On the Wi-Fi device, follow the procedure on

the device for connecting to another Wi-Fi Direct device. See the device's user manual for instructions.

2. When you have completed the procedure,

you should see a pop-up on your TV screen saying that a device that supports Wi-Fi Direct has requested to connect. Select OK, and then press the v button to accept.

3. The Connecting pop-up appears, followed

by the Connected pop-up. When it closes, you should see the device listed on the Wi-Fi Direct screen as connected.

Through the Player Using PBC

1. Select the Wi-Fi Direct device you want to

connect to this player, and then press the v button. The PBC/PIN pop up appears.

2. Select PBC, and then press the v button.

The PBC pop-up appears.

3. Press the PBC button on the Wi-Fi Direct

device within 2 minutes.

4. The Connecting pop-up appears, followed

by the Connected pop-up. When it closes, you should see the device listed on the Wi-Fi Direct screen as connected.

Through the Player Using a PIN

1. Select the Wi-Fi Direct device you want to

connect to this player, and then press the v button. The PBC/PIN pop up appears.

2. Select PIN, and then press the v button.

The PIN pop-up appears.

3. Note the PIN code in the pop-up, and then

enter it into the appropriate field in the Wi-Fi Direct device you want to connect.

4. The Connecting pop-up appears, followed

by the Connected pop-up. When it closes, you should see the device listed on the Wi-Fi Direct screen as connected.

| NOTE |

\The wired or wireless network connection will be

disconnected when you use the Wi-Fi Direct function.

\A text file, such as file with a .TXT or .DOC extension is

not play when using the Wifi Direct function.

Soft AP

Soft AP is short for Software enabled Access Point. Soft AP lets you connect other Wi-Fi devices to your network through the player and lets you can enjoy various features such as AllShare network functionality or network remote control. It requires that you create a security key which you must enter into the other Wi-Fi devices when you are connecting them to the network.

1. In the Home screen, select Settings, and

then press the v button.

2. Select Network, and then press the v

button.

3. Select Soft AP, and then press the v

button.

4. Select On or Off, and then press the v

button.

< To Set the Soft AP Security Key >

1. On the Soft AP screen, select Security Key,

and then press the v button. The Security Key screen appears.

2. On the Security key screen, enter a security

key. Enter numbers directly using the number buttons on your remote control. Enter letters by selecting a letter with the ▲▼◄► buttons, and then pressing the v button.

3. When done, use the the ▲▼◄► buttons to move to Done at the bottom of the screen, and then press the v button.

When you connect a Wi-Fi device through the connection procedure on the device, you must enter the security key you created here into the appropriate field.

04 Settings

English 27

Page 28

Settings

AllShare Settings

The AllShare Settings screen lists your network connected AllShare devices and their IP addresses. Through this screen, you can allow a device to access the player, deny access, or delete the device from the AllShare list.

1. In the Home screen, select Settings, and

then press the v button.

2. Select Network, and then press the v

button.

3. Select AllShare Settngs, and then press the

button.

4. Select a device, and then press the v

button. The AllShare Settings pop-up appears.

5. Select Allow, Deny, or Delete from the list,

and then press the v button.

The AllShare Settings screen only displays devices if you have established networked connections to AllShare devices. For more information about AllShare networked devices, see page 31.

Upgrading Software

The Software Upgrade menu allows you to upgrade the player's software for performance improvements or additional services.

• Never turn the player off or back on manually during the update process.

1. In the Home screen, select the Settings, and

then press the v button.

2. Select Support, and then press the v

button.

3. Select Software Upgrade, and then press

the v button.

4. Select one of the following methods:

• By Online

• By USB

• By Disc

• By Downloaded

• Standby Mode Upgrade

5. Press the v button.

| NOTE |

\The upgrade is complete when the player turns off, and

then turns on again by itself.

\Samsung Electronics shall takes no legal responsibility

for player malfunction caused by an unstable Internet connection or consumer negligence during a software upgrade.

\If you want to cancel the upgrade while the upgrade

software is downloading, press the v button.

\When the system upgrade is progressing, "UP" is

displayed on the front panel.

By Online

Your player must be connected to the Internet to use the By Online function.

1. Select By Online, and then press the v

button. The Connecting to Server message appears.

2. If there is a download available, the Download

pop-up appears with a progress bar and the download starts.

3. When the download is complete, the

Upgrade Query window appears with three choices: Upgrade Now, Upgrade Later, or Don't Upgrade.

4. If you select Upgrade Now, the player

upgrades the software, turns off, and then turns on automatically.

5. If you do not make a selection in one minute

or select Upgrade Later, the player stores the new upgrade software. You can upgrade the software later using the By Downloaded function.

6. If you select Don't Upgrade, the player

cancels the upgrade.

28 English

Page 29

By USB

1. Visit www.samsung.com.

2. Click SUPPORT on the top right of the page.

3. Enter the product's model number into the search field, and then click Find Product.

4. Click Get downloads in the center of the

page below the Downloads header.

5. Click Firmware in the center of the page.

6. Click the ZIP icon in the File column on the

right side of the page.

7. Click OK in the pop-up that appears to download and save the firmware file to your PC.

8. Unzip the zip archive to your computer. You should have a single folder with the same name as the zip file.

9. Copy the folder to a USB flash drive.

10. Make sure no disc is inserted in the player,

and then insert the USB flash drive into the USB port of the player.

11. In the player's menu, go to Settings > Support > Software Upgrade.

12. Select By USB.

| NOTE |

\There should be no disc in the player when you upgrade

the software using the USB Host jack.

\When the software upgrade is done, check the software

details in the software Upgrade menu.

\Do not turn off the player during the software upgrade.

It may cause the player to malfunction.

\Software upgrades using the USB Host jack must be

performed with a USB flash memory stick only.

By Disc

1. Follow Steps 1 through 7 in By USB.

2. Unzip the zip archive to your computer. You

should have a single folder with the same name as the zip file.

3. Write the folder onto a disc. We recommend

a CD-R or DVD-R.

4. Finalize the disc before you remove it from

your computer.

5. Insert the disc into the player.

6. In the player's menu, go to Settings >

Support > Software upgrade.

7. Select By Disc.

| NOTE |

\When the system upgrade is done, check the software

details in the software Upgrade menu.

\Do not turn off the player during the Software Upgrade.

It may cause the player malfunction.

By Downloaded

The By Downloaded option lets you upgrade using a file the player downloaded earlier but you decided not to install immediately or a file downloaded by the player in Standby Mode.

1. If upgrade software has been downloaded,

you will see the software version number to the right of By Downloaded.

2. Select By Downloaded, and then press the

button.

3. The player displays a message asking if you want to upgrade. Select Yes. The player begins the upgrade.

4. When the update is complete, the player turns off automatically, and t hen turns on.

| NOTE |

\When the system upgrade is done, check the software

details in the software Upgrade menu.

\Do not turn off the player during the software Upgrade.

It may cause the player to malfunction.

04 Settings

English 29

Page 30

Settings

Standby Mode Upgrade

You can set the Standby Mode Upgrade function so that the player downloads new upgrade software when it is in Standby mode. In Standby mode, the player is off, but its Internet connection is active. This allows the player to download upgrade software automatically, when you are not using it.

1. Press the ▲▼ buttons to select Standby Mode Upgrade, and then press the v

button.

2. Select On or Off. If you select On, the player will automatically download new upgrade software when it is in Standby mode with the power off. If it downloads new upgrade software, the player will ask you if you want to install it when you turn the player on.

| NOTE |

\To use Standby Mode Upgrade function, your player must

be connected to the Internet.

30 English

Page 31

Media Play

Your Blu-ray Disc Player can play content located on Blu-ray/DVD/CD discs, USB devices, PCs, and DLNA compatible cell phones. To play content located on your PC or on a DLNA compatible cell phone, you must connect your PC and the player to your network and download and install the AllShare network software on your PC.

Playing Commercial Video Discs

1. Press the 8 button to open the disc tray.

2. Push a disc gently into the disc tray with the

disc’s label facing up.

3. Press the

button to close the disc tray.

Playback starts automatically.

4. If playback does not start automatically, press

the

button on the remote or see “The

AllShare Play Screen” below.

The AllShare Play Screen

For all media, except for commercail video discs, the AllShare Play Main Screen or one of its subscreens is your primary means of accessing and selecting content to view or play. For example, if you connect a USB device to the player, the player will display the content located on the USB device on the AllShare Play USB screen.

| NOTE |

\You can use the AllShare Play Screen to access a

commercial video disc. For example, when you stop a movie, but leave the disc in the player, you can start it again using the AllShare Play Screen. However, unlike other media, when you insert a commercial video disc, it bypasses the AllShare Play Screen and starts playing automatically.

Accessing the AllShare Play Screen

To access the AllShare Play Main screen, select AllShare Play on the Home screen, and then press the v button.

The AllShare Play Screen at a Glance

AllShare Play

/ Videos /

Disc

My list

Videos

Photos

Music

USB

DLNA

No Disc inserted.

There is no device connected.

My List : Lists recently played or viewed files. If the

device or media containing files listed in My List is

inserted into or connected to the player, you can use My List to play or view those files.

Contents Type : Lets you select the type of content

to view or play: Videos, Photos, or Music.

Device Type : Lets you select the device or media

where the content is located.

Displays the colored buttons on your remote that

you can press to access or perform functions.

| NOTE |

\The video files played via DLNA will be listed in My List

only when the network connection has been established.

\Blu-ray/DVD/CD disk contents will not be listed in My List.

The AllShare Play screen will only display files of the Content Type you selected. For example, if you select Music, you will only be able to see music files. If you open folders labeled Photos or Videos, no files will be displayed. To view other types of files, select a different Content Type.

Playing Files on a USB Device or USB Compatible Mobile Phone

There are two methods you can use to play or view multimedia files located on a USB device or USB compatible mobile phone through your player.

English 31

05 Media Play

Page 32

Media Play

Method 1

1. Turn the player on.

2. Connect the USB device or mobile phone to

the USB port on the front panel of the player. The New Device Connected pop-up appears.

AllShare Play

New device connected.

Play videos, photos, or music content from Disc, USB, PC or mobile

Smart Hub Disc to Digital

Videos

Photos

Music

devices.

m80

" Enter ' Return

Settings

Safely Remove USB

| NOTE |

If the pop-up does not appear, go to Method 2.

3. Use the ▲▼ buttons to select Videos, Photos, or Music, and then press the v button. The AllShare Play screen appears listing the content of the device or phone. Depending on how the contents is arranged, you will see either folders, individual files, or both.

4. Select a file to view or play, and then press the v button.

5. Press the RETURN button to exit a folder or to return to the Home screen.

Method 2

1. Turn the player on.

2. Connect the USB device or mobile phone to

the USB port on the front panel of the player.

3. Select AllShare Play on the Home screen, and then press the v button.

4. On the left side, select Videos, Photos, or Music, and then press the v button.

5. On the right side, select USB, and then press the v button. The AllShare Play screen appears listing the contents of the device or phone. Depending on how the contents are arranged, you will see either folders, individual files, or both.

6. If necessary, use the the ▲▼◄► buttons

to select a folder, and then press the v button.

7. Use the ▲▼◄► buttons to select a file to

view or play, and then press the v button.

8. Press the RETURN button to exit a folder or

to return to Home screen.

| NOTE |

\To remove the USB storage device, you must use the

“Safely Remove USB” function to prevent possible damage to the USB memory. Press the HOME button to move to the Home screen, press the YELLOW (C) button, and then press the v button.

\If you insert a disc when playing a USB device or phone,

the device mode changes to "Disc" automatically.

\If your mobile phone is DLNA compatible, you can play

contents without connecting a USB cable. See "Using the AllShare Network Function" on pages 33~34.

Playing Commercial Audio Discs

1. Place a pre-recorded, commercial audio disc

into the disc tray with the disc’s label facing up, and then close the tray. The AllShare Music screen appears listing the tracks. Playback of the first track starts automatically.

2. To play a particular track, use the ▲▼ buttons

on the remote to select the track, and then press the v button.

Music Screen Controls

AllShare Play

TRACK 001 TRACK 002 TRACK 003 TRACK 004 TRACK 005 TRACK 006 TRACK 007 TRACK 008 TRACK 009 TRACK 010

/ Music /

Audio CD

02:38

03:17

05:21

05:34

02:54



03:44

TRACK 001

04:07

03:42

03:15

03:16

bc Page Move / Tools ' Return

1/14

00:03 / 02:38

32 English

Page 33

Pause a track.

Play a track.

Repeat one track or all tracks.

Play tracks in random order.

To access the controls, play a track, and then use the ◄► buttons to move to the control of your choice.

| NOTE |

The Music Screen controls are only accessible when a track is playing.

\All controls do not appear at the same time.

\For more information about playing music, go to

Controlling Music Playback on pages 37~39.

5. If you selected Photos, the AllShare Photos

screen appears listing the photos on the disc. Use the ▲▼◄► buttons to select the photo you want to view, and and then press the v button.

6. If you selected Videos, the AllShare Videos

screen appears listing the video files on the disc. Use the ▲▼◄► buttons to select the video you want to watch, and and then press the v button.

| NOTE |

For all folders, - Music, Photo, and Video - you can also push the TOOLS button on your remote, and then select Play Folder to play or view all the files in the folder automatically. Select the folder first before pushing the TOOLS button.

05 Media Play

Playing a Disc with User Recorded Content

You can play mulitmedia files you have recorded on DVD or CD discs.

1. Place a user recorded disc into the disc

tray with the disc’s label facing up, and then close the tray. The Device Connected pop-up appears.

2. Use the ▲▼ buttons to select the type of

content you want to view or play - Videos, Photos, or Music - and then press the v button.

| NOTE |

Even though the player will display folders for all content types, it will only display files of the Content Type you selected in Step 2. For example, if you selected music, you will only be able to see music files. You can change this selection on the AllShare Play main screen.

3. Use the ◄► buttons to select the folder

containing the content type you chose in Step 2, and then press the v button.

4. If you selected Music, the Allshare Music

screen appears listing the music files on the disc. Use the ▲▼ buttons to select the file you want to play, and then press the v button.

Using the AllShare Network Function

AllShare lets you play Videos, Photos, or Music located on your PC or your DLNA compatible device through the player using a wireless network connection.

To Download the AllShare Software

To use AllShare with your PC or DLNA device, you must install AllShare software on your PC.

You can download the PC software and get detailed instructions for using AllShare from the Samsung.com website.

1. Go to www.samsung.com.

2. Click Support at the top of the page.

3. On the Support page, enter the model

number of your player into the Model Number field, and then press the v button.

4. On the page that appears, click Get

downloads on the left side under Downloads. The Download Center appears.

5. On the Download Center page, click the

Software tab.

6. On the software tab, click the File icon on the

right side of the AllShare line.

English 33

Page 34

Media Play

7. In the pop-up that appears, click Save File.

8. Find the AllShare install file on your disk, and

then double click the file.

9. In the pop-up that appears, click Run, and then follow the directions that appear on your screen.

Download the AllShare Installation/Instruction manual from the same Software Tab by clicking the corresponding PDF file symbol in the File column on the right. The file, in PDF format, will download and open. You can view and/or save the file.

Playing Content Located on Your PC or DLNA Device through the Blu-ray Disc Player

PC Blu-ray Disc Player

Play back PC's files

AllShare Connection

1. Connect the Blu-ray Disc Player, your PC, and/or your DLNA compatible cell phone to the same wireless network.

2. Follow the directions in the AllShare software Installation/Instruction manual to set up devices and files for playing or viewing.

3. Select AllShare Play in the player's Home screen, and then press the v button. The AllShare Play screen appears.

4. Select the connected DLNA compatible device or your PC, and then press the v button. A screen listing the available files appears.

5. Select the file you want to play or view, and then press the v button.

Controlling the Playback of Content Located on Your PC with Your Smart Phone

AllShare

Connection

Smart Phone

(Only available with Samsung phones supporting AllShare functionality.)

1. Connect the Blu-ray Disc Player, your PC,

and your DLNA compatible cell phone to the same wireless network.

2. Follow the directions in the AllShare software

Installation/Instruction manual to set up devices and files for playing or viewing.

3. On your computer, using the AllShare

software, confirm your phone is connected.

4. On the phone, select the file you want to view

or play, and then select the Blu-ray player as the playback device.

5. On the phone, start playback.

Blu-ray Disc Player

Play back PC's files

Control PC's files to Blu-ray Disc Player

34 English

Page 35

Controlling Video Playback

VOL

–

SOURCE

DISC MENU

TITLE MENU

VOL VOL

POPUP

SAMSUNG TV

– +

You can control the playback of video content located on a DVD, USB, mobile device or PC. Depending on the disc or contents, some of the functions described in this manual may not be available.

Buttons on the Remote Control used for Video Playback



Using the disc menu, title menu, popup menu, and title list

05 Media Play



Playback related buttons

The player does not play sound in Search, Slow or Step mode.

• To return to normal speed playback, press the button.

6 5 7

button

Starts playback.

Stops playback.

Pauses playback.

During playback, press the 3 or 4

Fast Motion Play

button. Each time you press the 3 or 4 button, the playback speed will change.

Slow Motion Play

Step Motion Play

In pause mode, press the 4 button. Each time you press the 4 button, the playback speed will change.

In pause mode, press the 7 button. Each time you press the 7 button, a new frame appears.

During playback, press the 1 or 2

Skip Motion Play

button. Each time you press 1 or 2 button, the disc moves to the previous or next chapter or file.

DISC MENU button

During playback, press this button to display the Disc menu.

During playback, press this button to

TITLE MENU button

display the Title menu.

• If your disc has a playlist, press the

GREEN (B) button to go to the playlist.

POPUP MENU button

During playback, press this button to display the Popup menu.

Using the Tools Menu

During playback, press the TOOLS button.

Play from the Beginning

Movie Note

Scene Search

Select to return to the beginning of the movie, and then press the v button.

Movie Note provides information such as director, cast, synopsis, etc.

| NOTE |

\Movie Note is available if the disc

includes Movie Note information and connected to a network.

You can use the Scene Search function during playback to view or start a movie from the scene of your choice.

| NOTE |

\If the index information in the file

is damaged or the file does not support indexing, you will not be able to use the Scene Search function.

\If you play the AllShare Play after

connect to a computer with the network, the Scene Search may not be supported.

English 35

Page 36

Media Play

Title Search

Chapter Search

Time Search

Repeat Mode

If there is more than one movie on the disc or device, select to start a different title.

1. Select Title Search, and then press

the v button.

2. Use the ▲▼ buttons to select

a title, and then press the v button.

Select to play the chapter of your choice.

1. Select Chapter Search, and then

press the v button.

2. Use the ▲▼ buttons to select a

chapter, and then press the v button.

Select to play the movie from a selected time point.

1. Select Time Search, and then

press the v button.

2. Using the number buttons, enter

the time point you want to go to, and then press the v button.

| NOTE |

\You can also use the ◄► buttons

to advance or rewind the movie. The movie advances or rewinds one minute each tme you press the ◄ ► buttons.

Select to repeat a title, chapter, or specific section.

- Off : Select to return to normal

playback.

- Title : Choose to repeat a selected

title.

- Chapter : Choose to repeat a

specific chapter.

- Repeat A-B : Choose to repeat a

specific section.

Repeat Mode

Full Screen

Picture Mode

Audio

Subtitle

Angle

1. Press the ▲▼ buttons to select

repeat A-B, and then press the

button.

2. Press the v button at the point

where you want repeat play to start (A). Let the movie play.

3. Press the v button at the point

where you want repeat play to stop (B).

| NOTE |

\You must set point (B) at least 5

seconds of playing time after point (A).

Select to change the full screen size.

Select to set the picture mode.

- Dynamic : Increases sharpness and

brightness.

- Standard : Choose this setting for

most viewing applications.

- Movie : The best setting for

watching movies.

- User : Lets you adjust the sharpness

and noise reduction function respectively.

| NOTE |

\When you use the BD wise function,

this menu will not appear.

Select to set the desired audio language.

Select to set the desired subtitle language.

- You can also operate this function

by pressing the SUBTITLE button on the remote control.

Select to view a scene from another angle. The Angle option displays the number of angles available to view. When a Blu-ray Disc/DVD contains multiple angles of a particular scene, you can change angle.

36 English

Page 37

BONUSVIEW

VOL

–

SOURCE

DISC MENU

TITLE MENU

VOL VOL

POPUP

SAMSUNG TV

– +

HOME

VOL

–

SOURCE

DISC MENU

HOME SMART

TITLE MENU

VOL VOL

POPUP

A B C D

SAMSUNG TV

HUB

– +

INFOTOOLS

RETURN

EXIT

Video

BONUSVIEW Audio

Go to Videos List

Information

| NOTE |

\Depending on the disc or storage device, the Tools menu

may differ. See pages 39~41 for addtional options.

\Video files with high bitrates of 20Mbps or more strain

the player's capabilities and may stop playing during playback.

Controlling Music Playback

You can control the playback of music content located on a DVD, USB, mobile device or PC.

Buttons on the Remote Control used for Music Playback

Select to set the desired bonusview option.

Select to go to the list of videos on the current media.

Select to view video file information.

5 6

NUMBER buttons : Press the number of a track. The selected track is played.

button : Stops a track.

Skip : During playback, press the GREEN (B) or YELLOW (C) button to move to the previous or next

page of the playlist.

Fast Play (Audio CD (CD-DA) only)

During playback, press the 3 or 4 button.

Each time you press the 3 or 4 button, the playback speed will change.

button : Pauses a track.

button : Plays the currently selected track.

Using the Tools Menu

During playback, press the TOOLS button.

View

Folder view

Title

Artist

Album

Genre

Selection Play

Go to Playlist

Rip

Information

| NOTE |

\Depending on the disc or storage device, the Tools menu

may differ. See pages 39~41 for addtional options.

See pages 39~41.

The Ripping function converts CD audio to the mp3 format and saves the converted files on a USB device connected to the player. See Ripping on pages 38~39.

Select to see the (Contents) information: File size, date created, etc.

English 37

05 Media Play

Page 38

Media Play

Repeating Tracks on an Audio CD

You can set the product to repeat tracks on an audio CD (CD-DA/MP3).

1. During playback, use the ► button to select

in the lower right corner of the screen,

and then press the v button.

2. Use the ▲▼ to select the repeat mode you

want - Off, One Song, or All - and then press the v button.

AllShare Play

TRACK 001 TRACK 002 TRACK 003 TRACK 004 TRACK 005 TRACK 006 TRACK 007 TRACK 008 TRACK 009 TRACK 010

/ Music /

Audio CD

02:38

03:17

05:21

05:34

02:54



03:44

TRACK 001

04:07

03:42

03:15

03:16

bc Page Move / Tools ' Return

1/14

00:03 / 02:38

Shuffling Tracks on an Audio CD

You can set the product to play tracks on an audio CD (CD-DA/MP3) at random.

1. During playback, use the ► button to select

in the lower right corner of the screen,

and then press the v button.

2. Use the ▲▼ to set the Shuffle mode On or Off, and then press the v button.

Creating a Playlist from a CD

1. With the Playback screen displayed, press the TOOLS button. The Tools menu appears.

2. Use the ▲▼ buttons to select Selection Play, and then press the v button. The

Selection Play screen appears.

3. Use the ▲▼ buttons to select a track, and then press the v button. A check appears to the left of the track.

4. Repeat Step 3 to select and check additional tracks.

5. To remove a track from the list, move to the

track, and then press the v button again. The check on the track is removed.

6. When done, press the ► button to select Play, and then press the v button. The

Music Playback screen reappears listing only the tracks you checked. The selected tracks play automatically.

| NOTE |

\You can create a playlist with up to 99 tracks on Audio

CDs (CD-DA).

\If you have created a playlist, Selection Play is replaced

by Edit Playlist on the Tools menu.

\On the Selection Play screen, you can also choose Select

All, Deselect All, and Cancel.

- Use Select All to select all tracks. This cancels your

individual track selections. When you press the RETURN button on your remote or select 6 button, and then press the v button, all tracks will appear on the Music Playback screen, and the product will begin to play all tracks from Track 001.

- Use Deselect All to deselect all selected tracks at once.

Then, select individual tracks or use Select All to select all the tracks, and then press the RETURN button on your remote or select 6 button, and then press the v button. If you do not use Select All or select individual tracks, the Playlist will not change.

- Cancel cancels any changes you made on the Play

Select screen. When you return to the Playback screen, the Playlist will be unchanged.

Ripping

1. Insert a USB device into the USB jack on the

front of the product.

2. With the Playback screen displayed, press the TOOLS button. The Tools menu appears.

3. Use the ▲▼ buttons to select Rip, and then press the v button. The Rip screen appears.

4. Use the ▲▼ buttons to select a track, and then press the v button. A check appears to the left of the track.

5. Repeat Step 3 to select and check additional tracks.

38 English

Page 39

6. To remove a track from the list, move to the

track, and then press the v button again. The check on the track is removed.

7. When done, press the ► button to select

Rip, and then press the v button. The Rip pop-up appears.

8. Press the v button to begin the ripping

process. The Ripping Completion Bar popup appears.

9. When ripping is complete, the “Ripping is

completed.” message appears. Press the v button.

10. Press the RETURN button to go back to the

Playback screen.

| NOTE |

\This function is not available with DTS Audio CD.

\This function may not be supported by some discs.

\This function will be encoded to the .mp3 format at

192kbps.

Playing Photo Contents

You can play photo contents located on a DVD, USB, mobile device or PC.

Using the Tools Menu

During playback, press the TOOLS button.

Go to Photos List

Start Slide Show

Slide Show Speed

Slide Show Effect

Background Music On

Background Music Setting

Select to go to the list of photos on the current media.

Select to start the slide show.

Select to set a slide show's speed.

Select to set a slide show's special effects.

Select to listen to music while viewing a slide show.

Select to set the background music setting.

Select to set the picture settings.

- Dynamic : Choose to increase

Sharpness.

- Standard : Choose for most viewing

applications.

- Movie : This is the best setting for

Picture Mode

Zoom

Rotate

Selection Play

Information

| NOTE |

\Depending on the disc or storage device, the Tools menu

may differ. All options may not be displayed.

\To enable the background music function, the photo file

must be in the same storage media as the music file. However, the sound quality can be affected by the bitrate of the MP3 file, the size of the photo, and the encoding method.

\You can't enlarge the subtitle and PG graphic in the full

screen mode.

watching movies.

- User : Lets you adjust the sharpness

and noise reduction function respectively.

| NOTE |

\When you use the BD wise function,

this menu will not appear.

Select to enlarge the current picture. (Enlarge up to 4 times)

Select to rotate the picture. (This will rotate the picture either clockwise or counter clockwise.)

See pages 39~41.

Shows the picture information.

05 Media Play

English 39

Page 40

Media Play

Using the Tools Menu when a file is highlighted

When a file is highlighted, press the TOOLS button.

Select to access the sort options: Artist,

View

Folder view

Title

Artist

Album

Genre

Latest Date

Earliest Date

Monthly

Genre, Monthly, Latest Date, etc. The sort options that appear depend on the storage and media type.

Appears in the View function screen. Select to display the folders on the storage device.

Appears on the View function screen. Select to sort all photo or video files on a storage device by title.

Appears on the View function screen. Select Artist to sort and then display all music tracks on a storage device by artist.

Appears on the View function screen. Select Album to sort and then display all music tracks on a storage device by album.

Appears on the View function screen. Select Genre to sort and then display all music tracks on a storage device by genre.

Appears on the View function screen. Select to sort and then display all photo or video files on a storage device from the latest to earliest date.

Appears on the View function screen. Select to sort and then display all photo or video files on a storage device from the earliest to latest date.

Appears on the View function screen. Select to sort all photo or video files on a storage device by the month created.

Selection play

Send

Selection Play lets you select specific music, video, and photo files to play. It works essentially the same for all media. The example below is for photos.

1. On the selection screen, use the

▲▼◄► buttons to select a photo you want to view, and and then press the v button. A check mark appears to the left of the picture.

2. Repeat Step 1 for each photo you

want to view.

3. To de-select a photo, highlight it,

and then press the v button.

4. When done, use the ◄► buttons to select Play, and then press the v button. A slide show containing the photos you selected begins.

5. To pause the slide show, press the

button once. To restart the

slide show, press the v button again.

6. To stop the slide show, press the RETURN button.

| NOTE |

\After the slide show begins, you can

control the slide show by pressing the TOOLS button and displaying the Slide Show menu. See "Using the Tools Menu" page 39.

Select Send to upload selected files to Picasa, Facebook, Cloud Storage, or Family Story.

To use Send, you need to establish an account with the on-line site, and then log in using the Log In function.

40 English

Page 41

Send

Add to Playlist

1. Use the ▲▼◄► buttons to

select a file, and then press the

button.

2. Repeat for each track or file you

want to upload.

| NOTE |

\You can also move to Select All on

the right, and then press the button to select all tracks or files.

3. Select Send on the right side, and

then press the v button.

4. Use the ▲▼ buttons to select the

on line site you want to upload the files or tracks to, and then press the v button.

The Log In/Out function lets you log in to your online Samsung account.

Select to create a playlist or add files or tracks to a playlist.

1. Use the ▲▼◄► buttons to

highlight a track or file, and then press the v button.

2. Repeat for each track or file you

want to add.

3. Select Add to Playlist on the right,

and then press the v button.

4. On the screen that appears,

perform one of the following actions:

• Select the Playlist to which you want to add the tracks or files and then press v button.

• Select Create New, and then press the v button. On the keyboard pop-up that appears, create a name for the new playlist. Enter numbers using the numbers on the remote. Enter letters by using the ▲▼◄► buttons to move the cursor, and then pressing the v button. When finished, move to Done at the bottom of the screen, and then press the v button.

Depending on the screen you are

Delete (Playlist)

Edit Playlist

Play Current Group

Go to Playlist

Encoding

Information

| NOTE |

\Depending on the disc or storage device, the Tools menu

may differ. All options may not be displayed.

viewing, select Delete to erase a file from erasable media (such as a USB device) or to delete a playlist.

Select Edit Playlist to remove files or tracks from an existing playlist. The storage device containing the playlist must be inserted into or attached to the player.

1. Use the ▲▼◄► buttons to

select a file, and then press the

button.

2. Repeat for each track or file you

want to remove.

| NOTE |

\You can also move to Select All on

the right, and then press the button to select all tracks or files.

3. Select Remove on the right side,

and then press the v button.

After you have sorted by Artist, Genre, Album,Title, Latest Date, Earliest Date, or Monthly, select a group that is the result of the sort (for example, all pictures taken in August), and then select Play Current Group to play or view the files in that group only.

Select to go to the Playlist section of the Main AllShare screen.

Encoding - which changes by language or by geographical area - modifies how the player sorts, arranges, and presents files or tracks, displays dates, etc. Select Encoding to change the encoding to match your language or geographical area.

Displays media file and content information.

05 Media Play

English 41

Page 42

Network Services

You can enjoy various network services such as Smart Hub or BD-LIVE by connecting the player to your network.

To use network services, you must first:

1. Connect the player to the network.

(See page 16)

2. Configure the network settings.

(See pages 24~26)

Using Smart Hub

Using Smart Hub, you can download movies, videos, and music from the Internet, and access various for pay or free-of-charge applications and view them on your TV. Application content includes news, sports, weather forecasts, stock market quotes, maps, photos, and games.

For instructions that explain how to use Smart Hub, follow these steps:

1. Go to www.samsung.com.

2. Click Support at the top of the page.

3. On the Support page, enter the model

number of your player into the Model Number field, and then press the Enter button.

4. On the page that appears, click Get

downloads on the left side under Downloads. The Download Center appears.

5. On the Download Center page, click the

Manuals tab.

6. On the Manuals tab, click the file icon to the

right of Smart Hub Users Manual. The manual downloads.

| NOTE |

\The web location of the Smart Hub manual is subject to

change without notice.

\If the home page is updated or revised, the content

mentioned in the user manual may differ from the actual menus.

Smart Hub at a Glance

1 2 483

Samsung Apps Your Video Family Story Fitness Kids

Contents 1

xxxxxxxx

Your Video : Provides recommendations for videos

based on your tastes.

Search : Provides an integrated search of your

video providers and connected AllShare devices.

Recommended : Displays recommended contents

managed by Samsung.

Commercial : Displays the Smart Hub Guide, an introduction to the player, and new application

introductions.

Family Story : Effortless way to access family content.

• Provides access to family photos, messages, and events, anytime and anywhere.

Fitness : Gateway to the Unified Self-Care Service.

• Presents fitness videos from various content

partners with feedback on calories burned after every workout.

Kids : Kids service gives kids an easy and safe way to enjoy their favorite content.

• Provides a wide variety of fun and safe content for children.

Navigation Help : Displays the remote control buttons you can use to navigate in Smart Hub.

• RED (A) : To log in to Smart Hub.

• GREEN (B) : To display the background screen.

• Tools : To display the settings window.

• Return : To return to the previous menu.

5 6 7

Contents 3

Contents 2

xxxxxxxx

Contents 4

xxxxxxxx

42 English

Page 43

My Applications : Displays your personal gallery of applications which you can add to, modify, and

delete.

Samsung Apps : Open Samsung Apps to download various for pay or free-of-charge application

services.

Using the Web Browser

You can access the internet using the Web Browser application which is installed in the Smart Hub screen by default.

1. Select Smart Hub on the Home screen, and

then press the v button.

2. Select the Web Browser application in Smart

Hub, and then press the v button.

| NOTE |

\When you run the Web Browser with the player connected

by HDMI to a BD Wise compatible TV - and BD Wise is on

- the browser is maximized to fill the screen and the TV's resolution is set to the optimal resolution automatically.

\The Web Browser is not compatible with Java

applications.

\If you attempt to download a file, and the file can not be

saved, an error message will appear.

\E-commerce, for purchasing proudcts online, is not

supported.

\ActiveX is not supported.

\Access may be blocked to some websites or to web

browsers operated by certain businesses.

Web Browser at a Glance

http://www.samsung.com

b Control Panel c Pointer Browsing Scroll up/down / Tools ' Return

Control Panel : Displays the various Web Browser

functions.

: Moves to the previous page.

•

: Moves to the last page before going back.

: Reloads the current page so that it is

•

refreshed on the screen.

•

: Moves to the Home screen of the Web

Browser.

•

: Allows you to zoom in or out of the screen at

various percentages.

•

: Allows you to bookmark specific pages so

that you can move to them easily.

•

: Allows you to view the history of your visited

pages by date, name, or frequency.

http://www.samsung.com

•

page address manually or select a page from the visited page list to move to that page.

•

: Allows you to switch easily between

multiple, currently open Web Browser windows.

•

: Allows you to search for information by

entering words.

•

: Lets you share the current site with your

family group by sending a message.

•

: Allows you to configure all settings for using

the Web Browser.

: Allows you to enter a

06 Network Services

English 43

Page 44

Network Services

Navigation Help : Displays the remote control buttons you can use to navigate in Web Browser.

• GREEN (B) : To display the Control Panel.

• YELLOW (C) : To switch the pointer.

( )

•

• Tools : To display Tools window.

• Return : To return to the previous menu.

: Scroll Up/Scroll Down the page.

BD-LIVE™

Once the player is connected to your network, you can enjoy various movie-related service contents available on BD-LIVE compliant discs.

1. Attach a USB memory stick to the USB jack

on the front of the player, and then check its remaining memory. The memory device must have at least 1GB of free space to accommodate the BD-LIVE services.

2. Select Settings on the Home screen, and

then press the v button.

3. Select Network, and then press the v

button.

4. Select BD Live Settings, and then press the

button.

5. Select BD Data Management, and then

press the v button.

6. Select Select Device, and then press the

button.

7. Select USB, and then press the v button.

8. Insert a Blu-ray Disc that supports BD-LIVE.

9. Select an item from the list of BD-LIVE service

contents provided by the disc manufacturer.

| NOTE |

\The way you use BD-LIVE and the provided contents may

differ, depending on the disc manufacturer.

Using Disc to Digital

Access your movie collection via cloud storage anytime, any place without your DVD disc.

Go to www.samsungsupport.com for more detailed information.

| NOTE |

\Samsung may add additional applications for this feature

in the future.

44 English

Page 45

Appendix

Compliance and Compatibility Notice

NOT ALL discs are compatible

• Subject to the restrictions described below and those noted throughout this Manual, including the Disc Type and Characteristics section of this user manual, disc types that can be played are: pre-recorded commercial BD-ROM, DVD-VIDEO, and Audio CD (CD-DA); BD-RE/-R, DVD-RW/-R; and CD-RW/-R.

• Discs other than the above cannot and/or is not intended to be played by this player. And some of the above discs may not play due to one or more reasons provided below.

• Samsung cannot assure that this player will play every disc bearing the BD-ROM, BD-RE/-R, DVD-VIDEO, DVD-RW/-R, DVD+RW/+R and CD-RW/-R logos, and this player may not respond to all operating commands or operate all features of every disc. These and other disc compatibility and player operation issues with new and existing format discs are possible because:

- Blu-ray is a new and evolving format and this player may not operate all features of Blu-ray Discs because some features may be optional, additional features may have been added to the Blu-ray Disc format after the production of this player, and certain available features may be subject to delayed availability;

- not all new and existing disc format versions are supported by this player;

- new and existing disc formats may be revised, changed, updated, improved and/or supplemented;

- some discs are produced in a manner that allows specific or limited operation and feature during playback;

- some features may be optional, additional features may have been added after the production of this player or certain available features may be subject to delayed availability;

- some discs bearing the BD-ROM, BD-RE/-R, DVD-VIDEO, DVD-RW/-R, DVD+RW/+R and CD-RW/-R logos may still be non-standardized discs;

- some discs may not be played depending on their physical state or recording conditions;

- problems and errors can occur during the creation of Blu-ray Disc, DVD software and/or the manufacture of discs;

- this player operates differently than a standard DVD player or other AV equipment; and/or

- for reasons noted throughout this user manual and for other reason(s) discovered and posted by SAMSUNG customer care center.

• If you encounter disc compatibility or player operation problems, please contact SAMSUNG customer care center. You may also contact SAMSUNG customer care center for possible updates on this player.

• For additional information on playback restrictions and disc compatibility, refer to the Precautions, Before Reading the user manual, Disc Types and Characteristics, and Before Playing sections of this user manual.

• For Blu-ray Disc Player progressive scan output : CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN CASE OF PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE 'STANDARD DEFINITION' OUTPUT. IF THERE ARE QUESTIONS REGARDING OUR TV SET COMPATIBILITY WITH THIS PRODUCT, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER.

07 Appendix

English 45

Page 46

Appendix

Copy Protection

• Because AACS (Advanced Access Content System) is approved as content protection system for Blu-ray Disc format, similar to use of CSS (Content Scramble System) for DVD format, certain restrictions are imposed on playback, analog signal output, etc., of AACS protected contents. The operation of this product and restrictions on this product may vary depending on your time of purchase as those restrictions may be adopted and/or changed by AACS after the production of this product. Furthermore, BD-ROM Mark and BD+ are additionally used as content protection system for Blu-ray Disc format, which imposes certain restrictions including playback restrictions for BD-ROM Mark and/or BD+ protected contents. To obtain additional information on AACS, BD-ROM Mark, BD+, or this product, please contact SAMSUNG customer care center.

• Many Blu-ray Disc/DVDs are encoded with copy protection. Because of this, you should only connect your Player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy-protected Blu-ray Disc/DVDs.

• Under the U.S. Copyright laws and Copyright laws of other countries, unauthorized recording, use, display, distribution, or revision of television programs, videotapes, Blu-ray Discs, DVDs, and other materials may subject you to civil and/or criminal liability.

• Cinavia Notice : This product uses Cinavia technology to limit the use of unauthorized copies of some commercially-produced film and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be interrupted. More information about Cinavia technology is provided at the Cinavia Online Consumer Information Center at http://www.cinavia.com. To request additional information about Cinavia by mail, send a postcard with your mailing address to: Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, USA. This product incorporates proprietary technology under license from Verance Corporation and is protected by U.S. Patent 7,369,677 and other U.S. and worldwide patents issued and pending as well as copyright and trade secret protection for certain aspects of such technology. Cinavia is a trademark of Verance Corporation. Copyright 2004-2010 Verance Corporation. All rights reserved by Verance. Reverse engineering or disassembly is prohibited.

Network Service Disclaimer

All content and services accessible through this device belong to third parties and are protected by copyright, patent, trademark and/or other intellectual property laws. Such content and services are provided solely for your personal noncommercial use. You may not use any content or services in a manner that has not been authorized by the content owner or service provider. Without limiting the foregoing, unless expressly authorized by the applicable content owner or service provider, you may not modify, copy, republish, upload, post, transmit, translate, sell, create derivative works, exploit, or distribute in any manner or medium any content or services displayed through this device.

46 English

Page 47

THIRD PARTY CONTENT AND SERVICES ARE PROVIDED "AS IS." SAMSUNG DOES NOT WARRANT CONTENT OR SERVICES SO PROVIDED, EITHER EXPRESSLY OR IMPLIEDLY, FOR ANY PURPOSE. SAMSUNG EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. SAMSUNG DOES NOT GUARANTEE THE ACCURACY, VALIDITY, TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY CONTENT OR SERVICE MADE AVAILABLE THROUGH THIS DEVICE AND UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL SAMSUNG BE LIABLE, WHETHER IN CONTRACT OR TORT, FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY FEES, EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR IN CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR AS A RESULT OF THE USE OF ANY CONTENT OR SERVICE BY YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Third party services may be terminated or interrupted at any time, and Samsung makes no representation or warranty that any content or service will remain available for any period of time. Content and services are transmitted by third parties by means of networks and transmission facilities over which Samsung has no control. Without limiting the generality of this disclaimer, Samsung expressly disclaims any responsibility or liability for any interruption or suspension of any content or service made available through this device.

Samsung is neither responsible nor liable for customer service related to the content and services. Any question or request for service relating to the content or services should be made directly to the respective content and service providers.

License

• Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.

• Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, & DTS and the Symbol together are registered trademarks & DTS 2.0+Digital Out is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

• The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

• Oracle and Java are registered trademarks of Oracle and/or its affiliates. Other names may be trademarks of their respective owners.

07 Appendix

• Open Source License Notice

- In the case of using open source software, Open Source Licenses are available on the product menu.

• Blu-ray Disc™, Blu-ray™ and the logos are trademarks of the Blu-ray Disc Association.

English 47

Page 48

Appendix

Additional Information

Note

3D Settings

• For some 3D discs, to stop a movie during 3D playback, press the 5 button once. The movie stops and the 3D mode option is de-activated. To change a 3D option selection when you are playing a 3D movie, press the 5 button once. The Blu-ray menu appears. Press the 5 button again, then select 3D Settings in the Blu-ray menu.

• Depending on the content and the position of the picture on your TV screen, you may see vertical black bars on the left side, right side, or both sides.

TV Aspect Ratio

• Depending on the disc type, some aspect ratios may not be available.

• If you select an aspect ratio and option that is different than the aspect ratio of your TV screen,

the picture might appear to be distorted.

• If you select the 16:9 Original, your TV may display 4:3 Pillarbox (black bars on sides of picture).

BD Wise (Samsung Players only)

• When BD Wise is on, the Resolution setting automatically defaults to BD Wise and BD Wise appears in the Resolution menu.

• If the player is connected to a device that does not support BD Wise, you can not use the BD Wise function.

Settings

• For proper operation of BD Wise, set the BD Wise option of both the player and the TV to On.

Digital Output

• Be sure to select the correct Digital Output or you will hear no sound or just loud noise.

• If the HDMI device (AV receiver, TV) is not compatible with compressed formats (Dolby Digital,

DTS), the audio signal outputs as PCM.

• Regular DVDs do not have BONUSVIEW audio and Navigation Sound Effects.

• Some Blu-ray Discs do not have BONUSVIEW audio and Navigation Sound Effects.

• This Digital Output setup does not affect the HDMI audio output to your TV.

It affects the coaxial and HDMI audio output when your player is connected to an AV receiver.

• If you play MPEG audio soundtracks, the audio signal outputs as PCM regardless of your Digital Output selections (PCM or Bitstream).

PCM Downsampling

• Even when PCM Downsampling is set to Off, some discs will only output downsampled audio through the coaxial digital outputs.

• HDMI

- If your TV is not compatible with compressed multi-channel formats (Dolby Digital, DTS), the

player may output PCM 2ch downmixed audio even though you selected Bitstream (either Reencoded or Unprocessed) in the setup menu.

- If your TV is not compatible with PCM sampling rates over 48kHz, the player may output

48kHz.

48 English

Page 49

Settings

Media Play

BD-LIVE Internet Connection

• What is a valid certificate? When the player uses BD-LIVE to send the disc data and a request to the server to certify the disc, the server uses the transmitted data to check if the disc is valid and sends the certificate back to the player.

• The Internet connection may be restricted while you are using BD-LIVE contents.

BD Data Management

• In the external memory mode, disc playback may be stopped if you disconnect the USB device in the middle of playback.

• Only those USB devices formatted in the FAT file system (DOS 8.3 volume label) are supported. We recommend you use USB devices that support USB 2.0 protocol with 4 MB/sec or faster read/write speed.

• The Resume Play function may not work after you format the storage device.

• The total memory available to BD Data Management may differ, depending on conditions.

Anynet+ (HDMI-CEC)

• Depending on your TV, certain HDMI output resolutions may not work. Please refer to the user manual of your TV.

• This function is not available if the HDMI cable does not support CEC.

• If your Samsung TV has an Anynet+ logo, then it supports the Anynet+ function.

Selecting the Audio Language

• The ◄► indicator will not appear on the screen if the BONUSVIEW section does not contain any BONUSVIEW audio settings.

• The languages available through the Audio Language function depend on the languages that are encoded on the disc. This function or certain languages may not be available.

• Some Blu-ray Discs may allow you to select either the PCM or Dolby Digital audio soundtrack in English.

Selecting the Subtitle Language

• Depending on the Blu-ray Disc / DVD, you may be able to change the subtitle language in the Disc Menu. Press the DISC MENU button.

• This function depends on the selection of subtitles that are encoded on the disc and may not be available on all Blu-ray Discs/DVDs.

• Information about the main feature BONUSVIEW mode will also appear if the Blu-ray Disc has a BONUSVIEW section.

• This function changes both the primary and secondary subtitles at the same time.

• The total number of primary and secondary subtitles are displayed respectively.

• If you press the SUBTITLE button on the remote control, the subtitle bar appears.

Press the RETURN button to remove the subtitle bar.

07 Appendix

English 49

Page 50

Appendix

Resolution according to the contents type

Contents Type

Setup

BD Wise Resolution of Blu-ray Disc 1080@60F 480i

Auto Max. Resolution of TV input Max. Resolution of TV input Max. Resolution of TV input

1080p@60F

(Movie Frame : Off)

Movie Frame : Auto (24Fs) 1080@24F 1080@24F -

1080i 1080i 1080i 1080i

720p 720p 720p 720p

480p 480p 480p 480p

| NOTE |

\If the TV you connected to the player does not support Movie Frame or the resolution you selected, the message "If no

pictures are shown after selecting 'Yes', please wait for 15 seconds to return to the previous resolution. Do you want to change the resolution?" appears. If you select Yes, the TV's screen will go blank for 15 seconds, and then the resolution will

revert to the previous resolution automatically.

\If the screen stays blank after you have changed the resolution, remove all discs, and then press and hold the

on the front of the player for more than 5 seconds. All settings are restored to the factory default. Run the Initial Settings procedure again. Then, go to Settings > Display > Resolution in the Menu, and select the correct resolution for your TV.

\When you run the Initial Settings procedure, re-select the language and aspect ratio (screen size and format) only. Resetting

does not affect your network settings, so you should be able to skip Network Setup and Software Upgrade.

\When the factory default settings are restored, all stored user BD data will be deleted.

\The Blu-ray Disc must have the 24 frame feature for the player to use the Movie Frame (24Fs) mode.

Blu-ray Disc

1080@60F 1080@60F 1080@60F

E-contents/

Digital contents

DVD

button

50 English

Page 51

Digital Output Selection

Setup PCM

Connection

PCM Up to 7.1ch PCM 2ch PCM PCM 2ch Re-encoded DTS

Dolby Digital PCM 2ch PCM 2ch Dolby Digital Dolby Digital Re-encoded DTS

Dolby Digital

Plus

Audio Stream

on Blu-ray

Disc

Audio Stream

on DVD

Definition for Blu-ray Disc

* If Source Stream is 2ch, "Re-encoded Dolby D" Settings are not applied.

Blu-ray Discs may include three audio streams :

- Main Feature Audio : The audio soundtrack of the main feature.

- BONUSVIEW audio : An additional soundtrack such as the director or actor's commentary.

- Navigation Sound Effects : When you choose some menu navigation, Navigation Sound Effects may sound. Navigation Sound Effects are different on each Blu-ray Disc.

Dolby TrueHD PCM 2ch PCM 2ch Dolby TrueHD Dolby Digital Re-encoded DTS

DTS PCM 2ch PCM 2ch DTS DTS Re-encoded DTS

DTS-HD High

Resolution

Audio

DTS-HD

Master Audio

PCM PCM 2ch PCM 2ch PCM 2ch PCM 2ch PCM 2ch PCM 2ch

Dolby Digital PCM 2ch PCM 2ch Dolby Digital Dolby Digital Dolby Digital Dolby Digital

DTS PCM 2ch PCM 2ch DTS DTS DTS DTS

Any

HDMI

Receiver

PCM 2ch PCM 2ch

Decodes main feature

audio and BONUSVIEW

audio stream together

into PCM audio and add

Navigation Sound Effects.

Coaxial

Bitstream

(Unprocessed)

HDMI

Receiver

Dolby Digital

Plus

DTS-HD High

Resolution

Audio

DTS-HD

Master Audio

Outputs only main feature audio stream so that your

AV receiver can decode the

You will not hear

BONUSVIEW audio and

Navigation Sound Effects.

Coaxial

Dolby Digital Re-encoded DTS

DTS Re-encoded DTS

audio bitstream.

Bitstream

(Re-encoded

DTS)

HDMI Receiver

or Coaxial

Decodes main

feature audio

and BONUSVIEW

audio stream

together into

PCM audio and

add Navigation

Sound Effects,

then re-encodes

the PCM

audio into DTS

bitstream

Bitstream

(Re-encoded

Dolby D)

HDMI supported

AV receiver or

Coaxial

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Decodes main

feature audio and

BONUSVIEW audio

stream together

into PCM audio

and add Navigation

Sound Effects,

then re-encodes

the PCM audio

into Dolby Digital

bitstream

07 Appendix

English 51

Page 52

Appendix

Troubleshooting

Before requesting service, please try the following solutions.

PROBLEM SOLUTION

No operation can be performed with the remote control.

The disc does not play. • Ensure that the disc is installed with the label side facing up.

The disc Menu does not appear. • Ensure that the disc has disc menus.

The prohibition message appears on the screen.

Play mode differs from the Setup Menu selection.

The screen ratio cannot be changed. • The Screen Ratio is fixed on your Blu-ray Disc/DVD.

No audio. • Make sure you have selected the correct Digital Output in the Audio Options

The screen is blank. • If the HDMI output is set to a resolution your TV cannot support (for

• Check the batteries in the remote control. They may need replacing.

• Operate the remote control at a distance of no more than 20 feet from the

player.

• Remove the batteries and hold down one or more buttons for several minutes to drain the microprocessor inside the remote control to reset it. Reinstall the batteries and try to operate the remote control again.

• Check the region number of the Blu-ray Disc/DVD.

• This message appears when an invalid button is pressed.

• The Blu-ray Disc/DVD's software doesn't support the feature (e.g., angles).

• You've requested a title or chapter number or search time that is out of

range.

• Some of the functions selected in the Setup Menu may not work properly if the disc is not encoded with the corresponding function.

• This is not a problem with the player.

Menu.

example, 1080p), you may not see a picture on your TV.

• Press the

• When the factory default settings are restored, all stored user BD data will

inside. All settings will revert to the factory settings.

be deleted.

button (on front panel) for more than 5 seconds with no disc

Forgot password • Press the

52 English

inside. All settings including the password will revert to the factory settings. Don't use this unless absolutely necessary.

• When the factory default settings are restored, all stored user BD data will be deleted.

button (on front panel) for more than 5 seconds with no disc

Page 53

PROBLEM SOLUTION

If you experience other problems. • Go to the contents and find the section of the user manual that contains the

explanations regarding the current problem, and follow the procedure once again.

• If the problem still cannot be solved, please contact your nearest Samsung authorized service center.

The picture is noisy or distorted • Make sure that the disc is not dirty or scratched.

• Clean the disc.

No HDMI output. • Check the connection between the TV and the HDMI jack of the player.

• Check if your TV supports 480p, 720p, 1080i or 1080p HDMI input resolution.

07 Appendix

Abnormal HDMI output screen. • If random noise appears on the screen, it means that TV does not support

AllShare function

I can see folders shared through AllShare, but I cannot see the files.

The video plays intermittently. • Check if the network is stable.

The AllShare connection between the player and the PC is unstable.

HDCP (High-bandwidth Digital Content Protection).

• AllShare only shows Video, Photo, and Music files. Other types of files are not displayed.

• Check if the network cable is properly connected and if the network is not overloaded.

• The wireless connection between the DLNA compatible device and the player is unstable. Check the connection.

• IP addresses within the same subnetwork should be unique. If they are not, IP interference can cause this phenomenon.

• Check if you have a firewall enabled. If so, disable the firewall function.

English 53

Page 54

Appendix

PROBLEM SOLUTION

BD-LIVE

I cannot connect to the BD-LIVE server. • Test whether the network connection is successful using the Network

Status function. (See page 20)

• Check whether a USB memory device is connected to the player.

• The memory device must have at least 1GB of free space to accommodate

the BD-LIVE service. You can check the available size in BD Data Management. (See page 21)

• See if the BD-LIVE Internet Connection option is set to Allow(All).

• If all above fails, contact the contents provider or update to the player to the

latest firmware.

When using the BD-LIVE service, an error occurs.

| NOTE |

\When the factory default settings are restored, all stored user BD data will be deleted.

• The memory device must have at least 1GB of free space to accommodate the BD-LIVE service. You can check the available size in BD Data Management. (See page 21)

Repairs

If you contact us to repair your player, an administration fee may be charged if either:

1. An engineer is called out to your home at your request and there is no defect in the product.

2. You bring the unit to a repair center and there is no defect in the product.

We will provide you with the amount of the administration fee before we make a home visit or begin any work on your player. We recommend you read this manually thoroughly, search for a solution on line at www.samsung.com, or contact Samsung Customer Care at 1-800-SAMSUNG (726-7864) before seeking to repair your player.

54 English

Page 55

Specifications

Power Requirements AC 120V, 60Hz Power Consumption 17W

General

USB

HDMI

Audio Output Digital Audio Output Coaxial

Network

• Network speeds equal to or below 10Mbps are not supported.

• Design and specifications are subject to change without prior notice.

• Weight and dimensions are approximate.

• Dispose unwanted electronics through an approved recycler.

To find the nearest recycling location, go to our website: www.samsung.com/recyclingdirect or call, (877) 278 - 0799.

Weight 2.5 Ibs Dimensions 14.2 (W) X 7.7 (D) X 1.5 (H) inches Operating Temperature Range +41°F to +95°F Operating Humidity Range 10 % to 75 % Type A USB 2.0 DC output 5V 500mA Max.

Video

Audio PCM, Bitstream

Ethernet 100BASE - TX Terminal Wireless LAN Built-in

Security

WPS(PBC) Supported

2D : 1080p, 1080i, 720p, 480p 3D : 1080p, 720p

WEP (OPEN/SHARED) WPA-PSK (TKIP/AES) WPA2-PSK (TKIP/AES)

07 Appendix

English 55

Page 56

LIMITED WARRANTY TO ORIGINAL PURCHASER

This SAMSUNG brand product, as supplied and distributed by SAMSUNG and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of:

One (1) Year Parts and Labor*

(*90 Days Parts and Labor for Commercial Use)

This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States. To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG's authorized service center. Transportation of the product to and from the service center is the responsibility of the purchaser.

SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer.

SAMSUNG's obligations with respect to software products distributed by SAMSUNG under the SAMSUNG brand name are set forth in the applicable end user license agreement. Non-SAMSUNG hardware and software products, if provided, are on an "AS IS" basis. Non-SAMSUNG manufacturers, suppliers, publishers, and service providers may provide their own warranties.

This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, and except to the extent otherwise expressly provided for in this statement, noncommercial use of this product, and shall not apply to the following, including, but not limited to: damage which occurs in shipment; delivery and installation; applications and uses for which this product was not intended; altered product or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect, fire, water, lightning or other acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied and authorized by SAMSUNG, or which damage this product or result in service problems; incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to follow operating instructions, cleaning, maintenance and environmental instructions that are covered and prescribed in the instruction book; product removal or reinstallation; reception problems and distortion related to noise, echo, interference or other signal transmission and delivery problems. SAMSUNG does not warrant uninterrupted or error-free operation of the product.

THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER'S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.

Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

To obtain warranty service, please contact SAMSUNG customer care center.

Page 57

QUESTIONS OR COMMENTS?

COUNTRY CALL OR VISIT US ONLINE AT WRITE

IN THE US

1-800-SAMSUNG

(726-7864)

www.samsung.com

Samsung Electronics America, Inc.

85 Challenger Road Ridgefield Park,

NJ 07660-2112

AK68-02228A-00

Samsung BD-E5900-ZA User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Safety Information

Warning

Precautions

Important Safety Instructions

Disc Storage & Management

Handling Cautions

Using the 3D function

Copyright

Getting Started

Disc and Format Compatibility

Disc types and contents your player can play

Disc types your player cannot play

Region Code

Logos of Discs the player can play

Supported Formats

Accessories

Front Panel

Rear Panel

Remote Control

Tour of the Remote Control

Connections

Connecting to a TV

Connecting to an Audio System

Method 1 Connecting to an HDMI supported AV receiver

Method 2 Connecting to an AV receiver with Dolby Digital or DTS decoder

Connecting to a Network Router

Wired Network

Wireless Network

Settings

The Initial Settings Procedure

The Home Screen

Accessing the Settings Screen

Buttons on the Remote Control Used for the Settings Menu

Settings Menu Functions

Networks and the Internet

Configuring Your Network Connection

Wi-Fi Direct

Soft AP

AllShare Settings

Upgrading Software

By Online

By USB

By Disc

By Downloaded

Standby Mode Upgrade

Media Play

Playing Commercial Video Discs

The AllShare Play Screen

Accessing the AllShare Play Screen

The AllShare Play Screen at a Glance

Playing Files on a USB Device or USB Compatible Mobile Phone

Playing Commercial Audio Discs

Music Screen Controls

Playing a Disc with User Recorded Content

Using the AllShare Network Function

To Download the AllShare Software

Playing Content Located on Your PC or DLNA Device through the Blu-ray Disc Player

Controlling the Playback of Content Located on Your PC with Your Smart Phone

Controlling Video Playback

Buttons on the Remote Control used for Video Playback

Using the Tools Menu

Controlling Music Playback

Buttons on the Remote Control used for Music Playback

Using the Tools Menu

Repeating Tracks on an Audio CD

Shuffling Tracks on an Audio CD

Creating a Playlist from a CD

Ripping

Playing Photo Contents

Using the Tools Menu

Using the Tools Menu when a file is highlighted

Network Services

Using Smart Hub

Smart Hub at a Glance

Using the Web Browser

BD-LIVE™
