SAMSUNG 797DF Service Manual Part List

7 Electrical Parts List
!!!
!
❈ You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
7-1-1 LE17IS Main PCB Parts
Level Loc. No. Code No. Description Specification Remarks
0 LE17ISBB/EDC 1 ST-LE17ISBB/EDC - 1 SDI,HIGH-CON(DF-T) -
3 BH94-00976C - ASSY PCB MAIN-ST LE17IS SNA 4 2306-000147 C414 C-FILM,LEAD-PPF 1uF,5%,250V,BK,26x24x15,22.5mm SA 4 2306-000263 C452 C-FILM,LEAD-PPF 770nF,5%,250V,BK,26x21.5x13.5, SA 4 2301-001195 C601 C-FILM,LEAD-PPF 150nF,10%,275VAC,BK,26x16.5x7, SA 4 2301-001195 C602 C-FILM,LEAD-PPF 150nF,10%,275VAC,BK,26x16.5x7, SA 4 2401-003619 C605 C-AL 270uF,20%,450V,GP,BK,25.4x50mm,10 SA 4 BH63-00134A CIS1 SHIELD-BOTTOM LE17KS,SECC,T1.0 SNA 4 BH63-00124A CIS2 SHIELD-IC LE17KS,SPTE,T0.2 SNA 4 BH63-00143A CIS3 COVER-PCB R LE17KS,ABS PC,IV16 SNA 4 BH63-00144A CIS4 COVER-PCB L LE17KS,ABS PC,IV16 SNA 4 BH68-00001A CIS40 LABEL-MARK CDT ART-PAPER100G,-,WHT,BLK,-,ALL,CDT SNA 4 0204-002426 CIS6 FLUX DF-201TVS,MIX,0.820,FLUX13%,14KG,- SNA 4 0204-002420 CIS7 SOLVENT 1M-1000,C3H70H,96,-,- SNA 4 3711-003895 CN201 CONNECTOR-HEADER BOX,13P,1R,2mm,STRAIGHT,SN SA 4 3711-003843 CN202 CONNECTOR-HEADER BOX,8P,1R,2mm,STRAIGHT,SN SA 4 3711-004484 CN203 CONNECTOR-HEADER BOX,5P,1R,2mm,STRAIGHT,SN SA 4 3711-000197 CN321 CONNECTOR-HEADER 1WALL,3P,1R,2.5mm,STRAIGHT,SN SA 4 3711-005055 CN401 CONNECTOR-HEADER 1WALL,4P,1R,10MM/8.0MM,STRAIGHT,SN-PB,WHT SA 4 3721-001053 CN601 PLUG-AC POWER 3P,-,-,NI SNA 4 3301-000130 CORE_1 CORE-FERRITE AC,23.5x9.4x12.6mm,1500,2800G SNA 4 3301-001264 CORE_2 CORE-FERRITE AC,18.2X9.7X28.2MM,1500,2800GAUSS SNA 4 0402-001441 D403 DIODE-RECTIFIER -,40V,3A,DO-201AD,BK SA 4 0402-001295 D505 DIODE-RECTIFIER GUR460L-5700,600V,4A,DO-201AD,BK SA 4 0402-001295 D507 DIODE-RECTIFIER GUR460L-5700,600V,4A,DO-201AD,BK SA 4 0402-001227 D601 DIODE-BRIDGE D3SBA60,600V,2.3A,SIP-4,BK SA 4 0402-000005 D626 DIODE-RECTIFIER 31DF4,400V,3A,DO-201AD,BK SA 4 6003-000122 FBT+H/S SCREW-TAPTITE BH,+,B,M4,L12,ZPC(YEL),SWRCH18 SNA 4 3601-001303 FH1 FUSE-RADIAL LEAD 250V,4A,TIME-LAG,CERAMIC,5X20MM SA 4 6502-000127 HS601_CLAMP1 CABLE CLAMP DAWH-18NB,ID15,-,NYLON66,NTR SNA 4 6502-001058 HS601_CLMAP2 CABLE CLAMP DAWH-50N,ID16.6,-,NYLON6/6,NTR SNA 4 3704-001071 IC201_SOCKET SOCKET-IC 42P,DIP,SN,1.778mm SA 4 1204-002259 IC401 IC-DEF. PROCESSOR 4 1203-003240 IC621 IC-POSI.FIXED REG. L78M05,IPAK,3P,6.5x6.1mm,PLASTIC,4.75/5.25V,-,0to+150C,0.5A,-,ST SA 4 1203-000165 IC622 IC-POSI.ADJUST REG. 78R12,TO-220,4P,-,PLASTIC,11.7/12.3V,1.5W,-20TO+80C,1A,-,ST SA 4 BH27-00134A L411 COIL CHOKE 4 BH27-00150A L441 COIL LINEARITY 4 BH27-00061A L601 COIL FILTER -,33.0mH,0.1ohm,72Ts,28.*28,-,BK,SQE-2828,3A,-,- SA 4 6003-001023 M/PCB+SH/BTM SCREW-TAPTITE RWH,+,B,M3,L10,ZPC(YEL),SWRCH1 SNA 4 0505-001689 Q401 FET-SILICON IRFU210B,N,200V,2.7A,1.5OHM,2.5W,I-PAK SA 4 0505-001689 Q561 FET-SILICON IRFU210B,N,200V,2.7A,1.5OHM,2.5W,I-PAK SA 4 2005-001163 R409 R-WIRE WOUND,NON 0.68ohm,1%,3W,AA,TP,5.5x15mm SA 4 2003-000695 R414 R-METAL OXIDE(S) 430ohm,5%,3W,AA,TP,6x16mm SA 4 3501-001111 RL601 RELAY-POWER 12VDC,250MW,5000MA,1FORMA,15MS,5MS SA 4 6003-000133 SH/BTM+AC/SOCK SCREW-TAPTITE BH,+,S,M4,L8,ZPC(YEL),SWRCH18A,- SNA 4 BH39-00453A SIGNAL_CABLE CBF SIGNAL 4 BH26-00090B T401 TRANS HORIZ.DRIVE 4 BH26-00158A T411 TRANS-H PULSE 4 BH26-00084A T501 TRANS FBT 4 BH26-00086A T561 TRANS-FOCUS 4 BH26-00172B T601 TRANS SWITCHING EER3942,LE17IS,90~264V,PL3,PM2A,ER-3942,290uH,49uH ­4 BH26-00163A T602 TRANS 4 1404-001264 TH601 THERMISTOR-PTC 4.5OHM,+30/-20%,220V,290VAC,21A,-,TR SA 4 1404-001020 TH602 THERMISTOR-NTC 8ohm,15%,-,17mW/C,BK SA
STV9118,SDIP,32P,27.94x8.89mm,PLASTIC,13.2V,-,0to+70C,ST,IC-DEF. PROCESSOR
100UH,CDTMO,100UH,10%,0.2OHM,5.0A,AR8X25,60.5TS,18X40MM,11MM,USTC0.12X20,TR,-10C HL-1527C,5.2uH,YL8115X27.5,11mm,18x17x55mm,15©™x6.5t°æ0.5t,22T/1000T,BK,20%,0.0
LE19IS,15P/06P,08P,20276-N1,1830mm,UL20276,BLACK,D-SUB/MALE,AWG28/30,30V,ATT. TY EI-1916,AN19J,7P,35.0MH,185TS/13TS/95TS,73.0UH,7.5/0.05OHM,PL3,EI-1916,170UH MAX EI-2820,AN19IS,10P,500uH,,,0.35uH,,,1.00/0.030,,PL3,DMR30,EI-2820,300uH,23*29.5* FQM19A005,PS17NO,122UH,SM19C,FUR3757SU,113.2MOHM,80,14P,-10~+60,BK,27KV EE1916,5P,2.0MH MIN,290MH MIN,0.85OHM/32.0OHM,EE1916(PL3,SL-2),EE19*16,23.0UH MA
UU-1116,CU17K,5,18mH min,18mH min,2.7ohm MAX,10 ~ 55,FERRITE,UU-1116 SB-5S
SNA
SA
SNA
SNA
SA SA SA SA
SA
4 BH96-00285B HS490 ASSY HEAT SINK P BH62-00055A,SPRING,J6920,DTV1500HFP,2SK2761,OIL SILICON SNA
4 BH97-00505C MICOM ASSY MICOM LE19IS SA 5 0903-001194 IC201 IC-MICROCONTROLLER 5 BH82-00020J CIS A/S MICOM LE19IS SNA
3P863,8Bit,SDIP,42P,600MIL,12MHz,ST,CMOS,PLASTIC,5V,-,-40to+85C,1040BYTE,48KBYTE
SNA
LE17IS/LE19IS/LE19IT 7-1
7 ElectricalPartsList
!
!
Level Loc. No. CodeNo. Description Specification Remarks
4 BH97-00508C - ASSY AUTO-(MAIN)ST LE17IS SNA 5 3301-000011 BD201 BEAD-AXIAL ,3.5x1.0x5.7mm,,BK,,, SA 5 3301-000011 BD202 BEAD-AXIAL ,3.5x1.0x5.7mm,,BK,,, SA 5 3301-000011 BD203 BEAD-AXIAL ,3.5x1.0x5.7mm,,BK,,, SA 5 3301-000011 BD402 BEAD-AXIAL ,3.5x1.0x5.7mm,,BK,,, SA 5 3301-000011 BD411 BEAD-AXIAL ,3.5x1.0x5.7mm,,BK,,, SA 5 3301-000011 BD412 BEAD-AXIAL ,3.5x1.0x5.7mm,,BK,,, SA 5 3301-000011 BD431 BEAD-AXIAL ,3.5x1.0x5.7mm,,BK,,, SA 5 3301-000011 BD501 BEAD-AXIAL ,3.5x1.0x5.7mm,,BK,,, SA 5 3301-001450 BD601 BEAD-AXIAL 45ohm,3.5x0.6x5.7mm,50mA,TP,,, SNA 5 2201-000119 C201 C-CERAMIC,DISC 100NF,+80-20%,50V,Y5V,TP,8X3MM,5 SA 5 2401-000050 C202 C-AL 10uF,20%,16V,GP,TP,5x11,2.5 SA 5 2201-000389 C203 C-CERAMIC,DISC 0.022NF,5%,50V,C0G,TP,5X3MM,5 SA 5 2201-000389 C204 C-CERAMIC,DISC 0.022NF,5%,50V,C0G,TP,5X3MM,5 SA 5 2201-000144 C205 C-CERAMIC,DISC 0.1NF,5%,50V,C0G,TP,8.5X3MM,5 SA 5 2201-000017 C206 C-CERAMIC,DISC 1NF,10%,50V,Y5P,TP,5X3.5MM,5 SA 5 2201-000374 C207 C-CERAMIC,DISC 0.22NF,5%,50V,C0G,TP,10.5X3MM,5 SA 5 2401-000603 C208 C-AL 1UF,20%,50V,GP,TP,5X11,2 SA 5 2401-000603 C209 C-AL 1UF,20%,50V,GP,TP,5X11,2 SA 5 2401-000603 C210 C-AL 1UF,20%,50V,GP,TP,5X11,2 SA 5 2401-000603 C211 C-AL 1UF,20%,50V,GP,TP,5X11,2 SA 5 2201-000389 C212 C-CERAMIC,DISC 0.022NF,5%,50V,C0G,TP,5X3MM,5 SA 5 2401-002075 C260 C-AL 4.7uF,20%,50V,GP,TP,5x11,5 SA 5 2401-002463 C301 C-AL 470uF,20%,16V,GP,TP,8x11.5,5 SA 5 2301-000174 C302 C-FILM,LEAD-PEF 15nF,5%,100V,TP,7.2x4.0x7.5mm, SA 5 2301-000148 C303 C-FILM,LEAD-PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm SA 5 2401-000852 C304 C-AL 220uF,20%,35V,GP,TP,8x11.5mm,5 SA 5 2305-000004 C305 C-FILM,LEAD-PEF 220nF,10%,100V,TP,12.7x16,5mm SA 5 2301-000010 C306 C-FILM,LEAD-PEF 100nF,5%,100V,TP,11.5x12.5mm,5 SA 5 2401-002463 C307 C-AL 470uF,20%,16V,GP,TP,8x11.5,5 SA 5 2401-001914 C309 C-AL 1uF,20%,50V,BP,TP,5x11,5 SA 5 2301-000148 C310 C-FILM,LEAD-PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm SA 5 2301-000188 C312 C-FILM,LEAD-PEF 1nF,5%,100V,TP,10.5x12.5x6.5,5 SA 5 2201-000119 C321 C-CERAMIC,DISC 100NF,+80-20%,50V,Y5V,TP,8X3MM,5 SA 5 2401-000025 C322 C-AL 100uF,20%,16V,GP,TP,6.3x11,5 SA 5 2301-000168 C331 C-FILM,LEAD-PEF 150nF,5%,100V,TP,11.5x19mm,7.5 SA 5 2305-000237 C332 C-FILM,LEAD-PEF 1uF,5%,63V,TP,7.5x15.5mm,5mm SA 5 2401-000031 C333 C-AL 47uF,20%,16V,GP,TP,5x11,5 SA 5 2401-000050 C401 C-AL 10uF,20%,16V,GP,TP,5x11,2.5 SA 5 2401-001218 C402 C-AL 4.7uF,20%,100V,WT,TP,5x11,5 SA 5 2301-000010 C403 C-FILM,LEAD-PEF 100nF,5%,100V,TP,11.5x12.5mm,5 SA 5 2301-000020 C404 C-FILM,LEAD-PEF 27nF,5%,100V,TP,7.3x4x12.5mm,5 SA 5 2301-001441 C405 C-FILM,LEAD-PPF 2nF,3%,1.6kV,TP,20x2.5x11mm,7.5 SA 5 2309-000106 C406 C-FILM,LEAD-OTHER 2.2nF,5%,1.6KV,TP,23x16x9,7.5m SA 5 2401-003826 C411 C-AL 220UF,20%,63V,LR,TP,10X25MM,5 SA 5 2201-000285 C412 C-CERAMIC,DISC 1NF,10%,1KV,Y5P,TP,8X5MM,5 SA 5 2201-000012 C413 C-CERAMIC,DISC 0.22NF,10%,1KV,Y5P,TP,6.3X5MM,5 SA 5 2201-000003 C415 C-CERAMIC,DISC 0.068NF,10%,2KV,SL,TP,7X5MM,5 SA 5 2201-000732 C417 C-CERAMIC,DISC 0.68NF,10%,1KV,Y5P,TP,7X4MM,5 SA 5 2401-002463 C431 C-AL 470uF,20%,16V,GP,TP,8x11.5,5 SA 5 2305-000665 C432 C-FILM,LEAD-PEF 100nF,5%,63V,TP,7.5x4.0x5.0mm, SA 5 2301-000148 C433 C-FILM,LEAD-PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm SA 5 2202-000573 C434 C-CERAMIC,MLC-RADIAL 0.82NF,5%,50V,C0G,TP,5.1X3.2X5.1MM,5 SA 5 2301-000020 C435 C-FILM,LEAD-PEF 27nF,5%,100V,TP,7.3x4x12.5mm,5 SA 5 2401-002075 C436 C-AL 4.7uF,20%,50V,GP,TP,5x11,5 SA 5 2401-000603 C437 C-AL 1UF,20%,50V,GP,TP,5X11,2 SA 5 2401-000031 C438 C-AL 47uF,20%,16V,GP,TP,5x11,5 SA 5 2301-000188 C439 C-FILM,LEAD-PEF 1nF,5%,100V,TP,10.5x12.5x6.5,5 SA 5 2301-000004 C440 C-FILM,LEAD-PEF 2.2nF,5%,100V,TP,5.5X10X2.9,5m SA 5 2301-000106 C441 C-FILM,LEAD-PEF 1.5nF,0.05,100V,TP,10.5*12.5*6 SA 5 2301-000016 C442 C-FILM,LEAD-PEF 22nF,5%,100V,TP,7.2x4.5x9.0mm, SA 5 2301-000168 C443 C-FILM,LEAD-PEF 150nF,5%,100V,TP,11.5x19mm,7.5 SA 5 2301-000188 C444 C-FILM,LEAD-PEF 1nF,5%,100V,TP,10.5x12.5x6.5,5 SA 5 2301-001249 C451 C-FILM,LEAD-PPF 68nF,5%,400V,TP,19x7x15mm,7.5 SA 5 2306-000197 C453 C-FILM,LEAD-PPF 390nF,5%,250V,TP,20*19*12,7.5m SA 5 2306-000131 C454 C-FILM,LEAD-PPF 150nF,5%,250V,TP,19x16x7.5,7.5 SA 5 2301-001249 C455 C-FILM,LEAD-PPF 68nF,5%,400V,TP,19x7x15mm,7.5 SA 5 2301-001067 C456 C-FILM,LEAD-PPF 82nF,5%,400V,TP,19x15.5x7,7.5 SA
7-2 LE17IS/LE19IS/LE19IT
7 ElectricalPartsList
Level Loc. No. Code No. Description Specification Remarks
5 2301-001249 C457 C-FILM,LEAD-PPF 68nF,5%,400V,TP,19x7x15mm,7.5 SA 5 2201-000291 C458 C-CERAMIC,DISC 1NF,10%,500V,Y5P,TP,7.5X3.5MM,5 SA 5 2401-000603 C459 C-AL 1UF,20%,50V,GP,TP,5X11,2 SA 5 2202-000654 C460 C-CERAMIC,MLC-RADIAL 100nF,10%,50V,X7R,TP,5.1x6.6x3.2mm,5 SA 5 2301-000294 C501 C-FILM,LEAD-PEF 56nF,5%,100V,TP,9.5x12.5mm,5mm SA 5 2301-000013 C502 C-FILM,LEAD-PEF 4.7nF,5%,100V,TP,10.5x12.5x6.5 SA 5 2301-000312 C503 C-FILM,LEAD-PEF 8.2nF,5%,100V,TP,6x12.5mm,5mm SA 5 2401-000025 C504 C-AL 100uF,20%,16V,GP,TP,6.3x11,5 SA 5 2201-000163 C505 C-CERAMIC,DISC 10NF,+80-20%,50V,Y5V,TP,7X3MM,2.5 SA 5 2305-000237 C506 C-FILM,LEAD-PEF 1uF,5%,63V,TP,7.5x15.5mm,5mm SA 5 2202-000654 C507 C-CERAMIC,MLC-RADIAL 100nF,10%,50V,X7R,TP,5.1x6.6x3.2mm,5 SA 5 2401-000025 C508 C-AL 100uF,20%,16V,GP,TP,6.3x11,5 SA 5 2401-000025 C509 C-AL 100uF,20%,16V,GP,TP,6.3x11,5 SA 5 2305-000412 C510 C-FILM,LEAD-PEF 470nF,5%,63V,TP,-,5mm SA 5 2303-000102 C511 C-FILM,LEAD-PEF 1.2nF,5%,1.6KV,TP,23*16*7.5,7. SA 5 2201-000012 C512 C-CERAMIC,DISC 0.22NF,10%,1KV,Y5P,TP,6.3X5MM,5 SA 5 2401-000058 C513 C-AL 220uF,20%,100V,GP,TP,12.5x25,5 SA 5 2401-000031 C521 C-AL 47uF,20%,16V,GP,TP,5x11,5 SA 5 2202-002009 C530 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2401-000638 C531 C-AL 2.2uF,20%,350V,WT,TP,10x12.5mm SA 5 2401-001576 C532 C-AL 47uF,20%,50V,GP,TP,8x11.5,5 SA 5 2401-002267 C533 C-AL 2.2uF,20%,250V,GP,TP,8x11.5,5 SA 5 2301-000213 C534 C-FILM,LEAD-PEF 220nF,5%,250V,TP,21.5x11,7.5 SA 5 2301-001480 C535 C-FILM,LEAD-PEF 2000NF,5%,100V,TP,17X16.5X9.5,7.5 SA 5 2401-001026 C536 C-AL 3.3UF,20%,50V,GP,TP,5X11,5 SA 5 2401-002300 C537 C-AL 47uF,20%,50V,GP,TP,6.3x11,5 SA 5 2305-000428 C541 C-FILM,LEAD-PEF 47nF,5%,250V,TP,11x9x4.5,5mm SA 5 2401-000480 C551 C-AL 10uF,20%,50V,GP,TP,5x11,5 SA 5 2201-000129 C552 C-CERAMIC,DISC 0.1NF,10%,1KV,Y5P,TP,7X4MM,5 SA 5 2201-000285 C561 C-CERAMIC,DISC 1NF,10%,1KV,Y5P,TP,8X5MM,5 SA 5 2201-000285 C562 C-CERAMIC,DISC 1NF,10%,1KV,Y5P,TP,8X5MM,5 SA 5 2306-001011 C563 C-FILM,LEAD-PPF 56nF,5%,250V,TP,19x7.5x14.5,7. SA 5 2301-000016 C564 C-FILM,LEAD-PEF 22nF,5%,100V,TP,7.2x4.5x9.0mm, SA 5 2301-000174 C565 C-FILM,LEAD-PEF 15nF,5%,100V,TP,7.2x4.0x7.5mm, SA 5 2201-000023 C603 C-CERAMIC,DISC 2.2NF,20%,250V,Y5U,TP,11X7MM,5 SA 5 2201-000023 C604 C-CERAMIC,DISC 2.2NF,20%,250V,Y5U,TP,11X7MM,5 SA 5 2401-000970 C606 C-AL 22uF,20%,50V,WT,TP,5x11,5 SA 5 2202-002009 C607 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2201-000325 C608 C-CERAMIC,DISC 2.2NF,10%,500V,Y5P,TP,9.5X4MM,5 SA 5 2201-000129 C609 C-CERAMIC,DISC 0.1NF,10%,1KV,Y5P,TP,7X4MM,5 SA 5 2201-000017 C610 C-CERAMIC,DISC 1NF,10%,50V,Y5P,TP,5X3.5MM,5 SA 5 2401-000611 C611 C-AL 1uF,20%,50V,WT,TP,5x11,5 SA 5 2305-000149 C613 C-FILM,LEAD-PEF 100nF,5%,100V,TP,12x12.5x6.5,5 SA 5 2301-000284 C614 C-FILM,LEAD-PEF 47nF,5%,100V,TP,8.5x12.5mm,5mm SA 5 2401-001585 C615 C-AL 47uF,20%,50V,WT,TP,8x11.5,5 SA 5 2202-002009 C616 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2201-000023 C617 C-CERAMIC,DISC 2.2NF,20%,250V,Y5U,TP,11X7MM,5 SA 5 2401-000015 C618 C-AL 33uF,20%,50V,WT,-,6.3x11mm,2.5 SA 5 2201-000291 C619 C-CERAMIC,DISC 1NF,10%,500V,Y5P,TP,7.5X3.5MM,5 SA 5 2305-000178 C621 C-FILM,LEAD-PEF 10nF,5%,100V,TP,-,5mm SA 5 2401-000039 C622 C-AL 1000uF,20%,16V,GP,TP,10x16,5 SA 5 2401-000025 C623 C-AL 100uF,20%,16V,GP,TP,6.3x11,5 SA 5 2401-000010 C624 C-AL 220uF,20%,16V,GP,-,6.3x11mm,2. SA 5 2401-000010 C625 C-AL 220uF,20%,16V,GP,-,6.3x11mm,2. SA 5 2401-000010 C626 C-AL 220uF,20%,16V,GP,-,6.3x11mm,2. SA 5 2401-000039 C627 C-AL 1000uF,20%,16V,GP,TP,10x16,5 SA 5 2401-000058 C628 C-AL 220uF,20%,100V,GP,TP,12.5x25,5 SA 5 2401-003826 C629 C-AL 220UF,20%,63V,LR,TP,10X25MM,5 SA 5 2201-000732 C630 C-CERAMIC,DISC 0.68NF,10%,1KV,Y5P,TP,7X4MM,5 SA 5 2401-000039 C631 C-AL 1000uF,20%,16V,GP,TP,10x16,5 SA 5 2401-000058 C633 C-AL 220uF,20%,100V,GP,TP,12.5x25,5 SA 5 2201-000017 C634 C-CERAMIC,DISC 1NF,10%,50V,Y5P,TP,5X3.5MM,5 SA 5 0203-001600 CIS10 TAPE-PAPER #53128,0.15,5.5,2000M,BEIGE SNA 5 0203-001599 CIS9 TAPE-KRAFT #53110,0.1,6,2000M,BRN SNA 5 BH71-40300A CN420 PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN SNA 5 BH71-40300A CN421 PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN SNA 5 3711-000217 CN602 CONNECTOR-HEADER 1WALL,2P,1R,7.92MM,STRAIGHT,SN,NTR SA 5 0401-000005 D201 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000005 D251 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA
LE17IS/LE19IS/LE19IT 7-3
7 ElectricalPartsList
Level Loc. No. Code No. Description Specification Remarks
5 0401-000005 D252 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0402-000274 D301 DIODE-RECTIFIER UF4004,400V,1A,DO-41,TP SA 5 0401-000005 D401 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000005 D402 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0402-001118 D411 DIODE-RECTIFIER UF1G,400V,1.2A,DO-204AC,TP SA 5 0402-000274 D412 DIODE-RECTIFIER UF4004,400V,1A,DO-41,TP SA 5 0401-000004 D441 DIODE-SWITCHING 1SS244,220V,200MA,DO-34,TP SA 5 0402-000274 D451 DIODE-RECTIFIER UF4004,400V,1A,DO-41,TP SA 5 0401-000005 D501 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000005 D502 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000005 D504 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000005 D506 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000005 D508 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000005 D509 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0402-000274 D510 DIODE-RECTIFIER UF4004,400V,1A,DO-41,TP SA 5 0402-000012 D531 DIODE-RECTIFIER UF4007,1KV,1A,DO-41,TP SA 5 0402-000274 D532 DIODE-RECTIFIER UF4004,400V,1A,DO-41,TP SA 5 0402-000017 D533 DIODE-RECTIFIER RGP02-12,1.2KV,0.5A,DO-204AL,TP SA 5 0401-000005 D541 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0402-001114 D542 DIODE-RECTIFIER 1N4936GP,400V,1A,DO-201AD,TP SA 5 0402-000546 D543 DIODE-RECTIFIER TVR10G,400V,1.0A,DO-41,TP SA 5 0401-000005 D544 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000005 D551 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0402-000012 D603 DIODE-RECTIFIER UF4007,1KV,1A,DO-41,TP SA 5 0402-000012 D604 DIODE-RECTIFIER UF4007,1KV,1A,DO-41,TP SA 5 0402-000546 D605 DIODE-RECTIFIER TVR10G,400V,1.0A,DO-41,TP SA 5 0402-000546 D606 DIODE-RECTIFIER TVR10G,400V,1.0A,DO-41,TP SA 5 0401-000005 D607 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000005 D608 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000005 D621 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0402-001194 D622 DIODE-RECTIFIER UG2D,200V,2A,-,TP SA 5 0402-000274 D623 DIODE-RECTIFIER UF4004,400V,1A,DO-41,TP SA 5 0402-000274 D624 DIODE-RECTIFIER UF4004,400V,1A,DO-41,TP SA 5 0402-001194 D627 DIODE-RECTIFIER UG2D,200V,2A,-,TP SA 5 0402-001118 D628 DIODE-RECTIFIER UF1G,400V,1.2A,DO-204AC,TP SA 5 6042-000001 EY301 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000001 EY302 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000001 EY401 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000001 EY402 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000001 EY403 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY404 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY405 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY411 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY415 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000001 EY422 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000001 EY423 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY454 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY455 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY501 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY502 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY503 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY504 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY505 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY506 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY507 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000001 EY601 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000001 EY602 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000001 EY603 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000001 EY604 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000001 EY605 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000001 EY606 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY607 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY608 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY621 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY622 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY623 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 BH71-40300A GT401 PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN SNA 5 BH71-40300A GT402 PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN SNA 5 BH71-40300A GT601 PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN SNA
7-4 LE17IS/LE19IS/LE19IT
7 ElectricalPartsList
Level Loc. No. Code No. Description Specification Remarks
5 BH71-40300A GT602 PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN SNA 5 1103-001150 IC241 IC-EEPROM 24C081,1Kx8,DIP,8P,9.2x6.4mm,2.7/5.5V,-25to+70C SA 5 1203-000610 IC501 IC-PWM CONTROLLER 494,DIP,16P,300MIL,PLASTIC,40V,1W,0TO+70C,250MA,4.75/5.25V,ST SA 5 BH39-40305U JP_DHH CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP1 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP10 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP11 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP12 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP13 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP14 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP15 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP16 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP17 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP18 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP19 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP20 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP21 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP22 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP23 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP24 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP25 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP26 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP27 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP28 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP29 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP3 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP30 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP31 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP32 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP33 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP34 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP35 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP36 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP37 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP38 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP39 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP4 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP40 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP41 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP42 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP43 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP44 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP45 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP46 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP47 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP48 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP49 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP5 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP50 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP51 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP52 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP53 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP54 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP57 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP58 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP60 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP61 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP62 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP63 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP64 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP65 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP66 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP67 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP68 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP69 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP7 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP70 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP71 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP72 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA
LE17IS/LE19IS/LE19IT 7-5
7 ElectricalPartsList
Level Loc. No. Code No. Description Specification Remarks
5 BH39-40305U JP73 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP74 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP75 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP76 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP77 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP78 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP79 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP8 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP80 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP82 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP83 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP9 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 2701-000189 L218 INDUCTOR-AXIAL 0.47UH,10%,2534 SA 5 2701-000116 L501 INDUCTOR-AXIAL 10UH,10%,4298 SA 5 BH41-00270A MP1.0 PCB MAIN LE19IS,FR-1,1,1.0,1.6T,247*247,LE19,MAIN SNA 5 0501-000122 Q321 TR-SMALL SIGNAL 2N3904,NPN,625mW,TO-92,TP,100-300 SA 5 0501-000581 Q322 TR-SMALL SIGNAL 2N3906,PNP,625mW,TO-92,TP,100-300 SA 5 0501-000586 Q323 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120-240 SA 5 0501-000586 Q403 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120-240 SA 5 0501-000303 Q404 TR-SMALL SIGNAL KSA733,PNP,250mW,TO-92,TP,120-240 SA 5 0501-000586 Q411 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120-240 SA 5 0501-000303 Q412 TR-SMALL SIGNAL KSA733,PNP,250mW,TO-92,TP,120-240 SA 5 0501-000586 Q455 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120-240 SA 5 0501-000586 Q456 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120-240 SA 5 0501-000586 Q457 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120-240 SA 5 0501-000586 Q458 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120-240 SA 5 0501-000404 Q459 TR-SMALL SIGNAL KSD1616-Y,NPN,750mW,TO-92,TP,135-270 SA 5 0501-000122 Q502 TR-SMALL SIGNAL 2N3904,NPN,625mW,TO-92,TP,100-300 SA 5 0501-000581 Q503 TR-SMALL SIGNAL 2N3906,PNP,625mW,TO-92,TP,100-300 SA 5 0501-000122 Q523 TR-SMALL SIGNAL 2N3904,NPN,625mW,TO-92,TP,100-300 SA 5 0501-000586 Q541 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120-240 SA 5 0501-000143 Q542 TR-SMALL SIGNAL 2N6520,PNP,625mW,TO-92,TP,30-200 SA 5 0501-000413 Q551 TR-SMALL SIGNAL KSP44,NPN,625mW,TO-92,TP,50-200 SA 5 0501-000122 Q601 TR-SMALL SIGNAL 2N3904,NPN,625mW,TO-92,TP,100-300 SA 5 0501-000404 Q604 TR-SMALL SIGNAL KSD1616-Y,NPN,750mW,TO-92,TP,135-270 SA 5 0501-000010 Q621 TR-SMALL SIGNAL KSC1008,NPN,800mW,TO-92,TP,120-240 SA 5 0501-000586 Q622 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120-240 SA 5 0501-000586 Q624 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120-240 SA 5 0501-000321 Q625 TR-SMALL SIGNAL KSB1116-Y,PNP,750mW,TO-92,TP,135-270 SA 5 2001-000429 R201 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000290 R202 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000734 R203 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000734 R204 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R205 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R206 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000800 R207 R-CARBON 5.1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000739 R208 R-CARBON 4.7MOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000734 R209 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000734 R210 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000734 R211 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000734 R212 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R213 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R214 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R215 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000006 R216 R-CARBON 2.4KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000006 R217 R-CARBON 2.4KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000793 R218 R-CARBON 47OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R219 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000734 R220 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000734 R221 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R222 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R223 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000290 R224 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000290 R227 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000435 R228 R-CARBON 1MOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000435 R229 R-CARBON 1MOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R230 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000554 R231 R-CARBON 270OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000869 R232 R-CARBON 56OHM,5%,1/8W,AA,TP,1.8X3.2MM SA
7-6 LE17IS/LE19IS/LE19IT
7 Electrical Parts List
Level Loc. No. Code No. Description Specification Remarks
5 2001-000869 R233 R-CARBON 56OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R234 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R235 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R236 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R241 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R242 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R243 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000734 R244 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000977 R301 R-CARBON 8.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2004-000216 R302 R-METAL 10Kohm,1%,1/4W,AA,TP,2.4x6.4mm SA 5 2004-000616 R304 R-METAL 24Kohm,1%,1/4W,AA,TP,2.4x6.4mm SA 5 2001-001078 R305 R-CARBON(S) 15KOHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2004-001005 R306 R-METAL 5.1Kohm,1%,1/4W,AA,TP,2.4x6.4m SA 5 2004-004038 R307 R-METAL 4.3Kohm,1%,1/4W,AA,TP,2.4x6.4m SA 5 2004-004231 R308 R-METAL(S) 2.4OHM,1%,1/2W,AA,TP,3.3X9MM SA 5 2004-001391 R309 R-METAL(S) 2.2ohm,1%,1/2W,AA,TP,2.4x6.4mm SA 5 2001-000037 R310 R-CARBON(S) 330OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000290 R311 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-001053 R312 R-CARBON(S) 1.5OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000977 R313 R-CARBON 8.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000734 R321 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000331 R322 R-CARBON 12KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000302 R323 R-CARBON 10OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000864 R324 R-CARBON 56KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000042 R325 R-CARBON 1KOHM,5%,1/4W,AA,TP,2.4X6.4MM SA 5 2001-000281 R326 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-001079 R327 R-CARBON(S) 15OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-001079 R328 R-CARBON(S) 15OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000319 R401 R-CARBON 120KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000221 R402 R-CARBON 1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000221 R403 R-CARBON 1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000490 R404 R-CARBON 200OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000739 R405 R-CARBON 4.7MOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000052 R406 R-CARBON(S) 3.3KOHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-001078 R407 R-CARBON(S) 15KOHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2003-000505 R408 R-METAL OXIDE(S) 150ohm,5%,3W,AA,TP,6x16mm SA 5 2003-000763 R410 R-METAL OXIDE(S) 6.8ohm,5%,3W,AA,TP,6x16mm SA 5 2003-000468 R411 R-METAL OXIDE(S) 10ohm,5%,1W,AA,TP,3.3x9mm SA 5 2001-000008 R412 R-CARBON 15KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2003-000005 R413 R-METAL OXIDE(S) 1ohm,5%,2W,AA,TP,4x12mm SA 5 2001-000107 R415 R-CARBON(S) 150KOHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2004-001118 R431 R-METAL 5Kohm,1%,1/4W,AA,TP,2.4x6.4mm SA 5 2001-000449 R432 R-CARBON 2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2004-004367 R433 R-METAL 90Kohm,1%,1/4W,AA,TP,6.2x2.6mm SA 5 2001-000449 R434 R-CARBON 2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000010 R435 R-CARBON 68KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000356 R436 R-CARBON 150KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2004-001230 R437 R-METAL 75Kohm,1%,1/4W,AA,TP,2.4x6.4mm SA 5 2004-000657 R438 R-METAL 27Kohm,1%,1/4W,AA,TP,2.4x6.4mm SA 5 2004-000412 R439 R-METAL 18Kohm,1%,1/4W,AA,TP,2.4x6.4mm SA 5 2001-000890 R440 R-CARBON 6.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000577 R441 R-CARBON 2KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000009 R442 R-CARBON 20KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000290 R451 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000290 R452 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000290 R453 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000290 R454 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000411 R455 R-CARBON 18KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000411 R456 R-CARBON 18KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000411 R457 R-CARBON 18KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000411 R458 R-CARBON 18KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R459 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R460 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R461 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R462 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2003-000450 R463 R-METAL OXIDE(S) 100Kohm,5%,3W,AA,TP,6x16mm SA 5 2003-000541 R464 R-METAL OXIDE(S) 1Kohm,5%,3W,AA,TP,6x16mm SA 5 2003-000671 R465 R-METAL OXIDE(S) 390ohm,5%,2W,AA,TP,4x12mm SA 5 2001-000290 R467 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA
LE17IS/LE19IS/LE19IT 7-7
7 Electrical Parts List
!
!!!
!
Level Loc. No. Code No. Description Specification Remarks
5 2003-000514 R468 R-METAL OXIDE(S) 15ohm,5%,2W,AA,TP,4x12mm SA 5 BH39-40305U R469 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 2001-000241 R501 R-CARBON 1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000290 R502 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000812 R503 R-CARBON 5.6KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000689 R504 R-CARBON 390KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000786 R505 R-CARBON 47KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000734 R506 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000331 R507 R-CARBON 12KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R509 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000241 R510 R-CARBON 1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-001153 R511 R-CARBON(S) 47OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-001144 R512 R-CARBON(S) 4.7KOHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2005-001172 R513 R-WIRE WOUND,NON 0.6ohm,5%,3W,AA,TP,5.5x15mm SA 5 2003-000432 R515 R-METAL OXIDE(S) 1.5Kohm,5%,3W,AA,TP,6x16mm SA 5 2004-001005 R516 R-METAL 5.1Kohm,1%,1/4W,AA,TP,2.4x6.4m SA 5 2001-000878 R520 R-CARBON 6.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000800 R521 R-CARBON 5.1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2004-001136 R522 R-METAL 6.8Kohm,1%,1/4W,AA,TP,2.4x6.4m SA 5 2001-000734 R523 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2004-001298 R526 R-METAL 82Kohm,2%,1/4W,AA,TP,2.4x6.4mm SA 5 2001-000429 R530 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000073 R531 R-CARBON 33KOHM,5%,1/4W,AA,TP,2.4X6.4MM SA 5 2004-000781 R532 R-METAL 330Kohm,1%,1/4W,AA,TP,2.4x6.4m SA 5 2004-000560 R533 R-METAL 220Kohm,1%,1/4W,AA,TP,2.4x6.4m SA 5 2001-000800 R534 R-CARBON 5.1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2004-000252 R535 R-METAL 11Kohm,1%,1/4W,AA,TP,2.4x6.4mm SA 5 2001-000591 R541 R-CARBON 3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R542 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2002-001091 R543 R-COMPOSITION 270KOHM,5%,1/2W,AA,TP,3X9MM SA 5 2002-001062 R544 R-COMPOSITION 150Kohm,2%,1/2W,AA,TP,3.9x9mm SA 5 2002-000121 R545 R-COMPOSITION 1Mohm,10%,1/2W,AA,TP,3.5x9.5mm SA 5 2001-000734 R550 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R551 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000331 R553 R-CARBON 12KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R554 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R555 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2002-001079 R556 R-COMPOSITION 470Kohm,5%,1/2W,AA,TP,4x10mm SA 5 2002-001079 R557 R-COMPOSITION 470Kohm,5%,1/2W,AA,TP,4x10mm SA 5 2001-000114 R558 R-CARBON(S) 180KOHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000114 R559 R-CARBON(S) 180KOHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2003-000514 R561 R-METAL OXIDE(S) 15ohm,5%,2W,AA,TP,4x12mm SA 5 2001-000221 R562 R-CARBON 1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-001129 R601 R-CARBON(S) 330KOHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-001129 R602 R-CARBON(S) 330KOHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2003-000738 R603 R-METAL OXIDE(S) 56Kohm,5%,2W,AA,TP,4x12mm SA 5 2003-000014 R604 R-METAL OXIDE(S) 10Kohm,5%,3W,AA,TP,6x16mm SA 5 2002-001103 R605 R-COMPOSITION 300Kohm,5%,1/2W,AA,TP,3.7x10.0mm SA 5 2002-001103 R606 R-COMPOSITION 300Kohm,5%,1/2W,AA,TP,3.7x10.0mm SA 5 2001-001116 R607 R-CARBON(S) 27OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000734 R608 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000780 R609 R-CARBON 470OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000281 R610 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 BH39-40305U R611 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 2001-000023 R621 R-CARBON 47OHM,5%,1/4W,AA,TP,2.4X6.4MM SA 5 2001-000027 R622 R-CARBON 100OHM,5%,1/4W,AA,TP,2.4X6.4MM SA 5 2001-000613 R623 R-CARBON 3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000857 R624 R-CARBON 560OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000290 R626 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000290 R627 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000472 R628 R-CARBON 2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000786 R629 R-CARBON 47KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2003-000473 R631 R-METAL OXIDE(S) 10ohm,5%,3W,AA,TP,6x16mm SA 5 2001-001108 R632 R-CARBON(S) 22KOHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000613 R634 R-CARBON 3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 4715-001055 SK531 SURGE ABSORBER 1kV,+50-10%,-,-,RADIAL SNA 5 6042-000002 TP501 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 2801-000006 X201 CRYSTAL-UNIT 12MHz,50ppm,28-AAM,S,35ohm,BK SA 5 0403-001327 ZD201 DIODE-ZENER MTZJ18A,16.22-17.06V,500MW,DO-34,TP SA
7-8 LE17IS/LE19IS/LE19IT
7 Electrical Parts List
Level Loc. No. Code No. Description Specification Remarks
5 0403-001068 ZD202 DIODE-ZENER UZ4.7BSA,4.44-4.68V,500MW,DO-34,TP SA 5 0403-000361 ZD221 DIODE-ZENER UZ6.2BSB,5.96-6.27V,500MW,DO-34,TP SA 5 0403-000361 ZD222 DIODE-ZENER UZ6.2BSB,5.96-6.27V,500MW,DO-34,TP SA 5 0403-000361 ZD223 DIODE-ZENER UZ6.2BSB,5.96-6.27V,500MW,DO-34,TP SA 5 0403-000361 ZD224 DIODE-ZENER UZ6.2BSB,5.96-6.27V,500MW,DO-34,TP SA 5 0403-000361 ZD225 DIODE-ZENER UZ6.2BSB,5.96-6.27V,500MW,DO-34,TP SA 5 0403-000361 ZD501 DIODE-ZENER UZ6.2BSB,5.96-6.27V,500MW,DO-34,TP SA 5 0403-001167 ZD541 DIODE-ZENER MTZJ30D,29.02-30.51V,500MW,DO-34,TP SA 5 BH39-40305U ZD542 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 0403-001068 ZD543 DIODE-ZENER UZ4.7BSA,4.44-4.68V,500MW,DO-34,TP SA 5 0403-001221 ZD601 DIODE-ZENER UZ39BSB,35.36-37.19V,500MW,DO-34,TP SA 5 0403-000361 ZD602 DIODE-ZENER UZ6.2BSB,5.96-6.27V,500MW,DO-34,TP SA
4 BH99-00030F HS422 ASSY HEAT/SINK HS TR,SCREW+NUT,IRFS630B(4),OIL SILICON SNA 5 0205-001154 CIS OIL-SILICON G746,-,- SNA 5 0505-001716 CIS FET-SILICON IRFS630B,N,200V,9A,0.4OHM,38W,TO-220F SA 5 6006-001008 CIS SCREW-ASS’Y MACH WSP,BH,+,M3,L10,ZPC(YEL),SWRCH SNA 5 6021-000118 CIS NUT-HEXAGON 1C,M3,ZPC(YEL),SM20C SNA 5 BH62-00044A CIS HEAT SINK-TR AQ19FS,A1050S,T2.0,20,55,-,-,- SNA
4 BH99-10019H HS411 ASSY HEAT/SINK H/S TR,SCREW+NUT,IRF634A,-,-,OIL SILICON,-,- SNA 5 0205-001154 CIS OIL-SILICON G746,-,- SNA 5 0505-001181 CIS FET-SILICON IRF634A,N,250V,8.1A,450mohm,74 SA 5 6006-001008 CIS SCREW-ASS’Y MACH WSP,BH,+,M3,L10,ZPC(YEL),SWRCH SNA 5 6021-000118 CIS NUT-HEXAGON 1C,M3,ZPC(YEL),SM20C SNA 5 BH62-30024B CIS HEAT SINK-IC SPC-1,T1,SN COATING,- SNA
4 BP96-00065B HS301 ASSY HEAT SINK P BH62-00003B,SCREW,STV9325,OIL SILICON SNA 5 0205-001154 H/S OIL-SILICON G746,-,- SNA 5 1204-002262 H/S IC-VERTICAL DEF. 5 6003-000334 H/S SCREW-TAPTITE RH,+,2S,M3,L6,ZPC(YEL),SWRCH18 SNA 5 BH62-00003B H/S HEAT SINK-VERT A1050S,T1.0,T1.0,-,DA,DB SNA
4 BP96-00075D HS601 ASSY HEAT SINK P BH62-00052A,SPRING,8SA0965,SILICON RUBBER SNA 5 BH13-00049A H/S IC HYBRID FS8S0965RCB(DP906C),LE19IS,5,-25 to 85,TO-220(FORMING),35,ST SA 5 BH61-00004A H/S SPRING ETC-TR CDA,CDB,SUS304,-,-,-,-,-,T0.5,-,-,- SNA 5 BH62-00052A H/S HEAT SINK-POWER M782,A1050S,T1.0,W25,L55,-,BH62,- SNA 5 BH62-20001B H/S TUBE-RUBBER CSQ4357,W25*L20*T0.45,-,-,-,- SNA
STV9325,HEPTAWATT,7P,15.45x10.22mm,PLASTIC,35V,-,-40to+150C,ST,IC-VERTICAL DEF.
SNA
7-1-2 LE17IS Video PCB Parts
Level Loc. No. Code No. Description Specification Remarks
3 BH94-00978A - ASSY PCB VIDEO-ST LE19IS SNA 4 6003-001023 - SCREW-TAPTITE RWH,+,B,M3,L10,ZPC(YEL),SWRCH1 SNA 4 BH39-00386A CIS CBF-GROUND ASS’Y 4 BH63-00131A CIS1 SHIELD-VIDEO LE17KS,SPTE,T0.2 SNA 4 0204-002426 CIS3 FLUX DF-201TVS,MIX,0.820,FLUX13%,14KG,- SNA 4 0204-002420 CIS4 SOLVENT 1M-1000,C3H70H,96,-,- SNA 4 BH68-00001A CIS40 LABEL-MARK CDT ART-PAPER100G,-,WHT,BLK,-,ALL,CDT SNA 4 3711-004236 CN101 CONNECTOR-HEADER BOX,6P,1R,2MM,STRAIGHT,SN SNA 4 BH39-00015A CN102 CBF-HARNESS 4 BH13-00050A IC102 IC HYBRID NT6813K-30031,NT6813K-30031,24P,-55 to +150,240mA,-0.5 to 6V,ST SA 4 3704-001203 SK101 SOCKET-CRT 9P,29PI,22.5PI,NI+SN,- SNA
MS17JO,8*0.16*16TA,1P/2P,80MM,35750-1010,EARTH PLATE CLIP,BK,8*0.16*16TA
13P/14P,200MM,WHT/BLK/RED/BLU,UL1007,AWG26,SMH200-13/YBNH200-14
SA
SA
4 BH96-00283B HS106 ASSY HEAT SINK P BH62-00054A,SCREW,LM2463,OIL SILICON SNA 5 0205-001154 H/S OIL-SILICON G746,-,- SNA 5 1201-002116 H/S IC-VIDEO AMP 5 6003-000334 H/S SCREW-TAPTITE RH,+,2S,M3,L6,ZPC(YEL),SWRCH18 SNA 5 BH62-00054A H/S HEAT SINK-PS LEO,A1050S,2.0,112,25 SNA
4 BH97-00510A - ASSY AUTO-(VIDEO)ST LE19IS SNA 5 3301-001450 BD101 BEAD-AXIAL 45ohm,3.5x0.6x5.7mm,50mA,TP,,, SNA
LM2463,TO-220,11P,17.5x20.01mm,-,-20,PLASTIC,100V,-,0to70C,-,-,-,-,-,ST
SA
LE17IS/LE19IS/LE19IT 7-9
7 Electrical Parts List
Level Loc. No. Code No. Description Specification Remarks
5 3301-001450 BD102 BEAD-AXIAL 45ohm,3.5x0.6x5.7mm,50mA,TP,,, SNA 5 3301-001450 BD104 BEAD-AXIAL 45ohm,3.5x0.6x5.7mm,50mA,TP,,, SNA 5 3301-001660 BD105 BEAD-RADIAL 100OHM,3.5X9.0X0.8,50MA,TP,K-150,0OHM SA 5 3301-001450 BD106 BEAD-AXIAL 45ohm,3.5x0.6x5.7mm,50mA,TP,,, SNA 5 2202-002009 C101 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2401-000025 C103 C-AL 100uF,20%,16V,GP,TP,6.3x11,5 SA 5 2401-000603 C104 C-AL 1UF,20%,50V,GP,TP,5X11,2 SA 5 2201-000019 C106 C-CERAMIC,DISC 10nF,+80-20%,500V,Y5V,TP,13.5x4mm,5 SA 5 2401-003036 C111 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm SA 5 2202-002009 C112 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2401-003036 C113 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm SA 5 2201-000119 C114 C-CERAMIC,DISC 100NF,+80-20%,50V,Y5V,TP,8X3MM,5 SA 5 2401-003036 C115 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm SA 5 2202-002009 C116 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2301-000148 C117 C-FILM,LEAD-PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm SA 5 2201-000483 C118 C-CERAMIC,DISC 0.033NF,5%,50V,C0G,TP,5X3.5MM,5 SA 5 2401-003036 C119 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm SA 5 2202-002009 C120 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2401-003036 C121 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm SA 5 2202-002009 C122 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2301-000010 C123 C-FILM,LEAD-PEF 100nF,5%,100V,TP,11.5x12.5mm,5 SA 5 2401-000049 C124 C-AL 47uF,20%,100V,WT,TP,10x16,5 SA 5 2202-002009 C125 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2201-000119 C126 C-CERAMIC,DISC 100NF,+80-20%,50V,Y5V,TP,8X3MM,5 SA 5 2201-000119 C131 C-CERAMIC,DISC 100NF,+80-20%,50V,Y5V,TP,8X3MM,5 SA 5 2201-000019 C132 C-CERAMIC,DISC 10nF,+80-20%,500V,Y5V,TP,13.5x4mm,5 SA 5 2201-000154 C133 C-CERAMIC,DISC 10NF,+80-20%,2KV,Y5P,TP,20X5MM,7.5 SA 5 2202-000286 C134 C-CERAMIC,MLC-AXIAL 56pF,5%,50V,SL,TP,1.9x3.5,- SA 5 2202-000286 C135 C-CERAMIC,MLC-AXIAL 56pF,5%,50V,SL,TP,1.9x3.5,- SA 5 2202-002009 CB01 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2202-002009 CB02 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2301-000010 CB03 C-FILM,LEAD-PEF 100nF,5%,100V,TP,11.5x12.5mm,5 SA 5 2401-003911 CB04 C-AL 1uF,20%,160V,BP,TP,6.3x11mm,5 SA 5 2202-002009 CG01 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2202-002009 CG02 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2301-000010 CG03 C-FILM,LEAD-PEF 100nF,5%,100V,TP,11.5x12.5mm,5 SA 5 2401-003911 CG04 C-AL 1uF,20%,160V,BP,TP,6.3x11mm,5 SA 5 6502-000001 CIS CABLE CLAMP DAWH-5NB,D15,L35,NYLON66,NTR SNA 5 0203-001599 CIS6 TAPE-KRAFT #53110,0.1,6,2000M,BRN SNA 5 0203-001600 CIS7 TAPE-PAPER #53128,0.15,5.5,2000M,BEIGE SNA 5 BH71-40300A CN_G2 PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN SNA 5 BH71-40300A CN_GND PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN SNA 5 2202-002009 CR01 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2202-002009 CR02 C-CERAMIC,MLC-AXIAL 100NF,+80-20%,50V,Y5V,TP,2.3X3.0MM,- SA 5 2301-000010 CR03 C-FILM,LEAD-PEF 100nF,5%,100V,TP,11.5x12.5mm,5 SA 5 2401-003911 CR04 C-AL 1uF,20%,160V,BP,TP,6.3x11mm,5 SA 5 0401-000005 DB01 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000005 DB02 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000004 DB03 DIODE-SWITCHING 1SS244,220V,200MA,DO-34,TP SA 5 0401-000004 DB04 DIODE-SWITCHING 1SS244,220V,200MA,DO-34,TP SA 5 0401-000004 DB05 DIODE-SWITCHING 1SS244,220V,200MA,DO-34,TP SA 5 0401-000005 DG01 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000005 DG02 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000004 DG03 DIODE-SWITCHING 1SS244,220V,200MA,DO-34,TP SA 5 0401-000004 DG04 DIODE-SWITCHING 1SS244,220V,200MA,DO-34,TP SA 5 0401-000004 DG05 DIODE-SWITCHING 1SS244,220V,200MA,DO-34,TP SA 5 0401-000005 DR01 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000005 DR02 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP SA 5 0401-000004 DR03 DIODE-SWITCHING 1SS244,220V,200MA,DO-34,TP SA 5 0401-000004 DR04 DIODE-SWITCHING 1SS244,220V,200MA,DO-34,TP SA 5 0401-000004 DR05 DIODE-SWITCHING 1SS244,220V,200MA,DO-34,TP SA 5 6042-000001 EY1 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000001 EY2 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY3 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY4 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 6042-000002 EY5 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H SNA 5 BH13-00022A IC104 IC HYBRID-BIAS CLAMP LM2480NA,PN15H/17L,8P,0to+70C,DIP,3mA,85V,ST SA 5 BH39-40305U JP101 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP102 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA
7-10 LE17IS/LE19IS/LE19IT
7 Electrical Parts List
Level Loc. No. Code No. Description Specification Remarks
5 BH39-40305U JP103 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP104 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 BH39-40305U JP105 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. SA 5 2701-001062 LB01 INDUCTOR-AXIAL 0.12UH,10%,3070 SA 5 2701-001092 LB02 INDUCTOR-AXIAL 0.07uH,10%,2360 SA 5 2701-001062 LG01 INDUCTOR-AXIAL 0.12UH,10%,3070 SA 5 2701-001092 LG02 INDUCTOR-AXIAL 0.07uH,10%,2360 SA 5 2701-001062 LR01 INDUCTOR-AXIAL 0.12UH,10%,3070 SA 5 2701-001092 LR02 INDUCTOR-AXIAL 0.07uH,10%,2360 SA 5 BH41-00271A MP1.0 PCB-VIDEO LE19IS,FR-1,1,1.0,1.6T,82.3*123.5,LE19,6,VIDEO SNA 5 2001-000577 R102 R-CARBON 2KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R103 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R105 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R106 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000016 R107 R-CARBON(S) 1OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000435 R111 R-CARBON 1MOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000812 R112 R-CARBON 5.6KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R113 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 R114 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-001138 R131 R-CARBON(S) 390OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000037 R132 R-CARBON(S) 330OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000947 R134 R-CARBON 7.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000084 R135 R-CARBON 100Kohm,5%,1/4W,AA,TP,2.4x6.4mm SA 5 2001-000969 RB01 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000969 RB02 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 RB03 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-001187 RB05 R-CARBON(S) 75OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000429 RB06 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-001129 RB07 R-CARBON(S) 330KOHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000022 RB08 R-CARBON(S) 33OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000969 RG01 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000969 RG02 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 RG03 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-001199 RG05 R-CARBON(S) 91OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000429 RG06 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-001129 RG07 R-CARBON(S) 330KOHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000022 RG08 R-CARBON(S) 33OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000969 RR01 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000969 RR02 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-000429 RR03 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-001187 RR05 R-CARBON(S) 75OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000429 RR06 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM SA 5 2001-001129 RR07 R-CARBON(S) 330KOHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 2001-000022 RR08 R-CARBON(S) 33OHM,5%,1/2W,AA,TP,2.4X6.4MM SA 5 1405-001064 SK104 SURGE ABSORBER 400V,20%,-,-,AXIAL SA 5 4715-001065 SK105 SURGE ABSORBER 200V,20%,-,-,RADIAL SNA 5 4715-001055 SK108 SURGE ABSORBER 1kV,+50-10%,-,-,RADIAL SNA 5 4715-001065 SKB01 SURGE ABSORBER 200V,20%,-,-,RADIAL SNA 5 4715-000102 SKG01 SURGE ABSORBER 200V,20%,1000A,-,RADIAL SNA 5 4715-000102 SKR01 SURGE ABSORBER 200V,20%,1000A,-,RADIAL SNA 5 0403-001068 ZD105 DIODE-ZENER UZ4.7BSA,4.44-4.68V,500MW,DO-34,TP SA
7-1-3 LE17IS Others
Level Loc. No. Code No. Description Specification Remarks
2 BH90-00592A - ASSY COVER REAR LE17JS,EDC SNA 3 BH63-00130A C/R COVER-REAR LE17KS,ABS HB,IV16 SNA
2 BH90-00598A - ASSY STAND LE17JS/LE15VS,EDC SNA
3 BH96-00272A STD ASSY STAND P LE17KS,ABS HB IV16 SNA 4 6902-000109 STD BAG PE HDPE,T0.015,L430,W350,TRP,28,2,PE MARK SNA
LE17IS/LE19IS/LE19IT 7-11
