Samson CL2 User Manual

CL2
P R O F E S S I O N A L     M I C R O P H O N E S
Condenser Microphone
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Operating the CL2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 4
CL2 Polar Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Operating the CL2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Changing the Capsule and Pick-up Pattern . . . . . . . . . . . . . . . . . . . . . . . . .5
P-Popping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Operating the CL2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
CL2 Applications Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Wiring Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Copyright 2006 Samson Technologies Corp. Printed October, 2006 v1.1 Samson Technologies Corp. 45 Gilpin Avenue Hauppauge, New York 11788-8816 Phone: 1-800-3-SAMSON (1-800-372-6766) Fax: 631-784-2201 www.samsontech.com

Introduction

Thank you for purchasing the CL2 Condenser Microphone, stereo matched pair kit from Samson Audio. Ideal for a variety of miking applications from vocals to instruments, ensembles to soloist, to just about any sound source that needs to be amplified or recorded, the CL2 condenser microphone brings a high level of accuracy and audio performance. The CL2 is a pencil style, externally biased, true capacitor (condenser) pressure gradient micro­phone that excels in both live performance and recording applications. For added versatility, the CL2 matched pair kit comes with interchangeable omni and cardioid capsules featuring three micron, gold-sputtered diaphragms and precision-tuned back plates. Equipped with a linear frequency response for superior reproduction, the microphone has also been designed to withstand high sound pressure level capabilities of 141 dB in cardioid and 138 db in omni. The microphone also features a built-in selectable High Pass Filter and 10dB pad. Plus, the CL2 matched pair kit includes a complete set of useful accessories for each microphone. Two 360 degree suspension mounts, two micro-perforated stainless steel pop filters, two windscreens, two microphone clips and a twin mic holder for stereo miking, fit neatly in the included alumi­num carry case protecting the microphones while in storage, in the studio or on the road with the band.
Should your microphone ever require servicing, a Return Authorization num­ber (RA) must be obtained before shipping your unit to Samson. Without this number, the unit will not be accepted. Please call Samson at 1-800-3SAMSON (1-800-372-6766) for a Return Authorization number prior to shipping your unit. Please retain the original packing materials and if possible return the unit in the original carton and packing materials.
1
1

Features

CL2 Features
The Samson CL2 matched pair kit has been produced using state-of-the-art micro­phone technology and is engineered to the finest detail. Here are some of its main features:
• Extended range linear frequency response for optimum reproduction and excep­tionally clear, crisp sound with great transient response. The pair of CL2 micro­phones of been matched within 1.5 dB.
• Ultra sensitive, low mass capsules featuring three micron, gold-sputtered dia­phragms capture up all of the nuances of any performance.
• The CL2 matched pair kit comes with interchangeable capsules for each micro phone allowing you to configure the microphones for different response patterns. The Cardioid polar pattern rejects signals not originating directly in front of the mic capsule minimizing feedback problems and providing increased separa­tion. The Omni polar pattern picks sounds for all directions producing a natural response that’s free from proximity effect.
• High SPL capability of 141 db (cardioid) and 138 db (omni), lending itself to a wide range of miking situations like brass percussion.
• Special shock-mounted mic holder is included to minimize noise and provide additional protection.
• The CL2 matched pair kit comes with two micro-perforated pop filters that help eliminate annoying "p-popping".
• The included foam wind screen can be fitted to greatly reduce turbulent noise when used in an outdoor environment.
• Lightweight and compact, the CL2 can be mounted on any standard microphone stand using the included shock-mount or mic clip.
• The CL2 matched pair kit also comes with a twin mic mount for stereo miking applications.
• Rugged brass case construction ensures reliable performance in even the most demanding environments.
• Gold plated XLR Connector provide long-lasting reliable connections.
• Included foam-lined impact resistant aluminum carrying case for convenience when transporting two CL2 microphones to or from studios to venues.
-
2
