Samlex SEC-1212, SEC-1223, SEC-1223BBM, SEC-1235, SEC-1235M Features

FEATURE SHEET

Samlex Base Station Power Supplies

Samlex SEC Series AC to DC Power Supplies have been proven reliable in the eld for over 20 years.
These switch mode designed supplies are highly efcient, compact and lightweight. Safety certied
to stringent UL standards in both Canada and the USA (120V Models), Samlex backs all of its Power
Supplies by an industry leading no hassle 3 Year Limited Warranty.

SEC-1212 SEC-1223 SEC-1223BBM

SEC-1235

Power Supply
Modular Connector Cable

SEC-PSPP

MODEL

SEC-1212 120 VAC 13.8 VDC 10A 14A

SEC-1223 120 VAC 13.8 VDC 23A 25A

SEC-1223BBM 120 VAC 13.8 VDC 23A 25A

SEC-1235 120 VAC 13.8 VDC 30A 35A

SEC-1235M 120 VAC 13.8 VDC 30A 35A

SEC-1212CE 230 VAC 13.8 VDC 10A 14A

SEC-1223CE 230 VAC 13.8 VDC 23A 25A

SEC-1223BBM-CE 230 VAC 13.8 VDC 23A 25A

SEC-PSPP Power Supply Modular Connector Cable

INPUT

VOLTAGE

OUTPUT

VOLTAGE

OUTPUT

CURRENT

CONTINUOUS

NEW

OUTPUT

CURRENT

PEAK

SEC-1235M

PRODUCT FEATURES

- Switch Mode Design

- High Reliability & High Efciency

- Produces clean, consistent power,
highly ltered to suppress RFI

- Immediate Delivery

- Optional Radio Cabinet Enclosures

- Optional 2U 19” Rack Plates

3 YEAR LIMITED WARRANTY

Industry Proven Reliability

41600-0121

samlexamerica.com

COMPLETE RADIO CABINET OFFERING REFERENCE SHEET

Cabinet Only Cabinet & SEC-1212 Cabinet & SEC-1223

Harris (M/A Com) Radio Models

M7300, M5300, XG-75M 12400-H – SEC-1223-M7300

M7100 12170-H – SEC-1223-M7100

HDM150 12440-H – SEC-1223-HYT

XG-25M, XG-75M, XG-100M, M7300, M5300 12480-H – SEC-1223-XG

Hytera Radio Models

MD78X Series 12440-H – SEC-1223-HYT

Icom Radio Models

IC‐A110, IC‐F1010/F2010, IC‐F1610/F2610 12110-I SEC-1212-IC1 SEC-1223-IC1

IC‐F310, 320, 410, 420, 510, 520, 610, 620 12120-I SEC-1212-IC2 SEC-1223-IC2

IC‐F110S/F210S, IC‐F110/F210, IC‐F121S/F221S, IC‐F121/F221, F5121, F6121, F5011, F6011,
F6021, IC-2820H, ID-880H-05

IC‐F5061/IC‐F6061, IC-F5063/IC-F6063, A120 12333-I – SEC-1223-IC4

IC-F5400D/F6400D/7500

Kenwood Radio Models

TK-880 TK-760(G), TK-760H, TK-762G, TK-840, TK-860G, TK-862G, TK-780, TK-840, TK-940,
TK-980, TK-981, TK-863G

TK‐6110 12270-K – SEC-1223-TK4

NX-3720, NX-3820, NX-5700, NX-5800, NX-5900, TK-730, TK-5830, TK-5930, TK-7160H, TK-8160H,
VM5000

TK-7160, TK-8160

TK-7102, TK-7180, TK-8180, TK-7360, TK-8360, TK-7302, TK-8302, NX-700, NX-800, NX-740,
NX-840, NX-720, NX-820, NX-920, NX-900, NX-901, TK-D740, TK-D840,TM-281A, TK-8102
(these models also  t with 12450-K)

Motorola Radio Models

SM50, SM120, M1225, GTX, CM200, CM300, CM200D, CM300D, PM400, XPR2500, DM1600 12060-M SEC-1212-SM SEC-1223-SM

CDM750, CDM1250, CDM1550 12220-M SEC-1212-CDM SEC-1223-CDM

MOTOTRBO XPR4550, XPR4350, XPR4380, XPR6150, DGM6100 12337-M SEC-1212-MOTOTRBO SEC-1223-MOTOTRBO

MOTOTRBO XPR5000 Series, DGM 5000, 5500, 8000, 8500, DM4000 12430-M SEC-1212-MT-XPR5000 SEC-1223-MT-XPR5000

XTL 1500, XTL 2500 Mid Power, XTL 5000 Mid Power, APX 6500 with 05 Control Head Mid Power 12345-M SEC-1212-XTL-MID SEC-1223-XTL-MID

Tait Radio Models

TM 9300, TM 9400 12491-T – SEC-1223-TM

Vertex Radio Models

VX2000, VX2500, VX3000, VX3200 12070-V SEC-1212-VX SEC-1223-VX

VX4000, VX5000, VX5500/6000 Low Band 12210-V SEC-1212-VX2 SEC-1223-VX2

VX4100/4200 Series 12260-V SEC-1212-VX3 SEC-1223-VX3

VX2200, VX2100, EVX-5300/5400, VX4500, VX4600 12280-V SEC-1212-VX4 SEC-1223-VX4

VXD7200 12337-M SEC-1212-MOTOTRBO SEC-1223-MOTOTRBO

Yaesu Radio Models

FT-2900 12333-I – –

NOTE: Radios not included. If your desired radio is not listed, contact Samlex.

12200-I SEC-1212-IC3 SEC-1223-IC3

12540-I – –

12090-K SEC-1212-TK2 SEC-1223-TK2

12450-K – SEC-1223-NX

12250-K SEC-1212-TK3 SEC-1223-TK3

41600-1219

Samlex is always looking to expand our radio cabinet offering to accommodate new and popular
radios. Let us know if you are getting requests for a Radio Cabinet we don’t currently offer!

Innovative Power Conversion Products Since 1991 | www.samlexamerica.com
