Important Information about the Sagemcom F@ST 2705 WS:

Operational working:

F@ST2705 WS must be used in a temperature controlled place. It is compliant to ETS 300 019-1-3 Class T

3.2 standard:

1.

Temperature : 0°C to +45°C

2. Solar Radiation : 700w / m

3. Relative humidity : 5 to 85 % without condensation

4. No Airflow

Installation and Safe Usage Instructions:

1. Place the ADSL gateway on a flat surface.

2.

Connect the manufacturer supplied AC to DC power adapter. The F@ST 2705 router requires the use

of a 12VDC, 500 mA power adapter. Only use a manufacturer supplied and approved power adapter.

3. Connect the F@ST 2705 to the AC Mains in accordance with the installation instructions in this booklet,

and the markings on the identification label (voltage, current, and frequency of electricity network).

4. Connect the Ethernet cable (provided) to one of the RJ45 ports on the ADSL Router labeled "LAN1",

"LAN2", "LAN3", or "LAN4". Then connect the other end of the Ethernet Cable to the Ethernet port of a

computer. Repeat as necessary for the other available Ethernet ports.

5. For a ADSL configuration, connect the provided DSL Cable to the port on the ADSL Router labeled

"DSL". Connect the other end of the DSL Cable to a standard Phone Jack.

CAUTION: To reduce the risk of fire, always and only use a UL Listed or CSA Certified

Telecommunication Line Cord (DSL cable) with a minimum wire gauge of 26AWG (0.4 mm dia.

minimum, or 0.129 mm² minimum) or larger (e.g., 24AWG).

Wall Mount Installation

This device can be mounted on a wall using the two mounting brackets on the bottom of the device,it is

recommended to use two round or pan head screws (not included)

1. Install two screws horizontally apart on a wall using the measurement shown in Figure 1. The screws

should protrude from the wall in order to fit the device between the head of the screw and the wall. If the

screws are installed in drywall. Use hollow wall anchors to ensure that the unit does not pull away from

the wall due to prolonged strain from the cable and power connectors.

2. Remove the device from the product package.

3. Mount the device on the wall.

Refer to Figures 1 and 2 for more details.

Figure 1: Distance (horizontal) Between Brackets for Screws Figure 2: Recommended Screw Size

1

When using this device, basic safety precautions should always be followed to reduce the risk of fire, electric shock,

and injury to persons including the following:

1. Do not use this product near water and avoid contact with moisture. For example, do not use near a bathtub, wash bowl,

kitchen sink, laundry tub, in a wet basement, or near a swimming pool. Care should be taken so that liquids are not spilled on

this equipment.

2. This equipment is for indoor use only, do not place or install in an outdoor location.

3. The devices connected to the telephone interfaces must be kept indoor use only.

4. Never insert objects into the vents of this equipment as this can result in the risk of electrical shock or fire.

5. This equipment should only be operated from the type of power supply (Voltage and Current) indicated on the marking

label.

6. Do not overload wall outlets or extension cords. Doing so can result in the risk of fire or electrical shock.

7. Avoid blocking any vent openings or exhaust exits on this equipment. Do not place equipment in a built-in installation such

as a cabinet that may impede the flow of air through the ventilation openings.

8. The equipment should be situated away from heat sources such as radiators, heat registers, stoves, or other heat

producing appliances and equipment.

9. Care should be taken to ensure that the power cord is routed, so it is not likely to be walked on or pinched by items placed

upon or next to it.

10. Unplug this equipment before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning only.

11. This equipment is not user serviceable and is to be serviced by qualified personnel only. Do not disassemble this

equipment. If service is required, disconnect all power and phones lines from the equipment and consult qualified service

personnel.

12. To disconnect this equipment from AC power, unplug the power supply from the AC wall socket.

13. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric

shock from lightning.

14. Do not use the telephone to report a gas leak in the vicinity of the leak.

15. Make sure the power socket to which you connect the power cord is easily accessible and as close as possible to the

equipment so that the appliance can be unplugged quickly in case of a problem.

Save these Instructions!
