Sagem MY901C User Manual

252889386_my900C-my901C_en.book Page 1 Vendredi, 30. mars 2007 9:47 09

ENGLISH

252889386_my900C-my901C_en.book Page 2 Vendredi, 30. mars 2007 9:47 09

252889386_my900C-my901C_en.book Page 3 Vendredi, 30. mars 2007 9:47 09

You have just purchased a SAGEM phone, we congratulate you; it is recommended that you read this handbook carefully in order to use your phone efficiently and in the best conditions. Your phone can be used internationally in the various networks (3G, GSM 900 MHz and DCS 1800 MHz as well as EDEGE for my901C model) depending on the roaming arrangements with your operator. This phone is approved to meet European standards.

SAGEM is a trademark of Sagem Communication SAFRAN group. T9® Text Input is a trademark of ©Tegic Communications Inc. Java™ and all Java™ based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. The WAP navigator and some message softwares (i-mode) are under licence Openwave. The WAP navigator and the softwares included are the exclusive property of Openwave. For this reason, it is forbidden to modify, translate, disassemble or even decompile all or part of these softwares. Wellphone™ and SmartCom™ are registered trademarks owned by SmartCom SARL France. The Bluetooth Windows is a trademark of Microsoft Corporation. miniSD™ is a trademark of SD Card Association.

word mark and logos are owned by the Bluetooth® SIG, Inc.

252889386_my900C-my901C_en.book Page 4 Vendredi, 30. mars 2007 9:47 09

Description ................................................................................................................................... 7

Installing the SIM card and the battery .................................................................................................. 9

Inserting the memory card ................................................................................................................... 10

Idle screen and external screen................................................................................................ 11

The icons ............................................................................................................................................. 11

Quick start .................................................................................................................................. 12

Information on the SIM card ................................................................................................................ 12

Getting started ..................................................................................................................................... 13

Help ..................................................................................................................................................... 13

Switching ON/OFF............................................................................................................................... 13

Network................................................................................................................................................ 14

First call ............................................................................................................................................... 14

Receiving a call.................................................................................................................................... 15

Video call ............................................................................................................................................. 15

Using your phone....................................................................................................................... 16

Improving antenna performance.......................................................................................................... 16

Increase the battery life of your phone ................................................................................................ 16

Charging the battery ............................................................................................................................ 17

Call history.................................................................................................................................. 18

Phonebook.................................................................................................................................. 19

Using the phonebook........................................................................................................................... 19

Storing a new contact .......................................................................................................................... 19

Contact options.................................................................................................................................... 19

Call groups........................................................................................................................................... 21

4 Contents

252889386_my900C-my901C_en.book Page 5 Vendredi, 30. mars 2007 9:47 09

Messages .................................................................................................................................... 22

Creating a text message or an e-mail .................................................................................................. 22

Saving the message ............................................................................................................................ 23

Sending the message ..........................................................................................................................23

Receiving messages............................................................................................................................ 23

Creating and sending a voice message............................................................................................... 24

Messages menu................................................................................................................................... 24

Photo and video ......................................................................................................................... 26

Taking a photo .....................................................................................................................................26

Taking a video...................................................................................................................................... 27

Multimedia .................................................................................................................................. 28

Music player ............................................................................................................................... 29

WAP............................................................................................................................................. 31

Logging on ...........................................................................................................................................31

Downloading objects............................................................................................................................ 31

Logging off ...........................................................................................................................................32

GPRS/EDGE........................................................................................................................................ 32

Games ......................................................................................................................................... 33

Applications (Organiser and tools) .......................................................................................... 34

Calendar .............................................................................................................................................. 34

ToDo ....................................................................................................................................................34

Clock .................................................................................................................................................... 35

Calculator and converter...................................................................................................................... 35

Local information.................................................................................................................................. 36

Modem Status...................................................................................................................................... 36

Services ...............................................................................................................................................36

My Applications.................................................................................................................................... 36

Dictaphone........................................................................................................................................... 36

Contents 5

252889386_my900C-my901C_en.book Page 6 Vendredi, 30. mars 2007 9:47 09

Connectivity................................................................................................................................ 37

Settings ....................................................................................................................................... 40

® ................................................................................................................................................................................37

Bluetooth

USB mode ........................................................................................................................................... 39

Synchronize ......................................................................................................................................... 39

Profiles................................................................................................................................................. 40

Display ................................................................................................................................................. 40

Languages ........................................................................................................................................... 40

Memory Card ....................................................................................................................................... 41

Video telephony ................................................................................................................................... 41

Browser settings .................................................................................................................................. 41

Networks.............................................................................................................................................. 41

Calls..................................................................................................................................................... 41

Security................................................................................................................................................ 43

Date and Time ..................................................................................................................................... 45

Shortcuts.............................................................................................................................................. 45

Memory................................................................................................................................................ 45

Technical features ...................................................................................................................... 46

Care and safety information...................................................................................................... 48

SAR ..................................................................................................................................................... 48

Advice for limiting exposure to radiofrequency (RF) fields .................................................................. 48

Safety................................................................................................................................................... 49

Environment......................................................................................................................................... 50

End User Licence Agreement (EULA), for the software ......................................................... 51

Java™.......................................................................................................................................... 55

Warranty...................................................................................................................................... 58

Troubleshooting ......................................................................................................................... 61

Customer care ............................................................................................................................ 63

Index ............................................................................................................................................ 64

6 Contents

252889386_my900C-my901C_en.book Page 7 Vendredi, 30. mars 2007 9:47 09

Description

Red key

Lens for videocall or shooting in photo and video

∗

(*) In this manual, when a function is chosen by pressing on this key, square brackets are used (e.g.: [

Description 7

: Short press: Switch on. Long press: Switchoff. Short press (in a call context): Reject a call - hang up. Short press (in menus): Return to idle screen

Green key

: Long press (in a call cont ext): Activate/Deactivate hands-free mode ( not use the phone in hands-free mode near to your ear, or you may suffer hearing loss) Short press (in call context): Call - receiving a call Short press (in idle screen): displaying the call log

Right programmable key:

In idle screen: Access to certain functions (shortcuts) In menus: Access to the selecti on shown on screen in the tab (*)

Left programmable key:

In idle screen: Access to certain functions (shortcuts) In menus: Access to the selecti on shown on screen in the tab (*)

Videocall. The navigator allows you:

- to navigate in the vario us functions pressing the relevant part (up, down, right,

left)

- to confirm your selection pressing the central part (OK)

Note

: in this manual, "press OK" means press this key. In idle screen, pressing the navigator displays the main menus icons Pressing the navigator followed by one of th e numeric keys numbered from 1 to 9, you can display a menu directly.

When composing a message:

Long press: switches from on e input mode to another (ABC/T9) Short press: Upper case/lower case/figures

Long press (in idle screen): Silent mode Long press (in call reception mode): Stops ring tone Short press (in ring tone setting mode): Acti vate / deactivate ring tone Short press: Stops sound in video or message playing, or in a game

(Function available depending on model)

Save

WARNING:

]).

252889386_my900C-my901C_en.book Page 8 Vendredi, 30. mars 2007 9:47 09

Lens for videocall or high shooting in photo and video.

Left key:

- to validate a

selection,

- Music player mode:

play or pause music.

Right key:

- to cancel a

selection,

- to stop and quit the

music player mode.

Key used for:

- displaying the profile

activated,

- setting the volume,

- stopping the ring tone

(first press), refusing a call (second press).

: flap keypad

Long press locking.

Navigator:

- to scroll the various profiles

(after activation of a profile with the lateral key),

- Music player mode: change

to the next or last piece of music.

Flap

Opening the flap allows you to take a call (if it is activated in the menu

8 Description

Settings/Calls/Active flip

), closing the flap ends a call.

252889386_my900C-my901C_en.book Page 9 Vendredi, 30. mars 2007 9:47 09

Installing the SIM card and the battery

WARNING

Depending on the model, network configuration and associated subscription cards, certain functions may not be available. Your phone is identified by its IMEI number. Write this number down, and do not keep it with your phone, because you may

be asked for it in the event of your phone being stolen, in order to prevent it from being used, even with a different SIM card. In order to display the IMEI on your phone's screen, type: *#06#.

The SIM card is inserted under the phone's battery. Ensure that the phone is switched off and the charger disconnected.

1 Turn the phone back and press the lock button to remove the back cover. 2 Take out battery if already installed. 3 Slide the SIM card, with cut corner as shown on the phone, into the card holder with fold face down. 4 Place the battery by positioning first the top of it, as shown on the battery.

5 Place the back cover, clicking in first the upper part then the lower part.

3214

Description 9

252889386_my900C-my901C_en.book Page 10 Vendredi, 30. mars 2007 9:47 09

Inserting the memory card

- Remove the back cover and insert the memory card into the slot located above the charger connector pushing it until it

clicks into place.

- To remove the card, first make sure that no application is accessing the card, then slightly push the top edge of the card

to release it and pull it out of the slot.

WARNING

The memory card is very fragile. Take care when you insert or remove the memory card. The memory card may suffer damage if withdrawn during a read or write operation. Ensure that no application accesses

the card during its withdrawal. Some memory cards must be formatted with a PC before first use with the phone. Only the memory cards with a maximum of 1 Go size can be used with this phone model.

10 Description

252889386_my900C-my901C_en.book Page 11 Vendredi, 30. mars 2007 9:47 09

Idle screen and external screen

On the external screen, time, incoming calls and various icons (battery, messages, the profile activated, etc.) are displayed. On the main screen, date and time, the network provider name, various messages about calls (that can be deleted by

pressing ) are displayed.

The icons

Battery (if it flashes red, the battery must be charged immediately)

Silent mode (the ringtone is off)

Only emergency call is possible

Signal strength level (between 0 and 5 bars)

Message received (read your message), flashing: memory full (delete some messages)

GPRS connection

WAP connection

Connection to the 3G network

Grey: EDGE network unavailable

Black: EDGE connection Flashing: connection on hand

Alarm

Memory card inserted (idle screen)

Memory card inserted (external screen).

Idle screen and external screen 11

252889386_my900C-my901C_en.book Page 12 Vendredi, 30. mars 2007 9:47 09

Quick start

Information on the SIM card

To use your phone, you need a card called SIM or USIM card. It contains personal information that you can modify:

- Secret codes (PIN(s): Personal Identification Numbers), these codes allow

you to protect access to your SIM card and phone

- Phonebook

- Messages

- How special services work.

WARNING

This card must be handled and stored with care in order not to be damaged. If you should lose your SIM card, contact your network provider immediately. Please keep your SIM card out of reach of young children.

12 Quick start

252889386_my900C-my901C_en.book Page 13 Vendredi, 30. mars 2007 9:47 09

Getting started

When you switch on your phone for the first time, follow instructions displayed on the screen. If access to the SIM card is protected, the device prompts you to enter the PIN number: Enter the code

for security reasons. After pressing [ If there are contacts saved in your SIM card, you are invited, if you wish, to copy them in the phone contacts memory.

between 4 and 8 digits given to you when the SIM card was issued. These digits do not appear on the screen

], the phone activates your SIM card settings.

Warning

If a wrong PIN number is entered three times in succession, your SIM card is blocked. You must then:

- Enter the PUK (Personal Unblocking Key) code provided by your operator, and validate.

- Enter your PIN number and validate.

- Enter your PIN number again and validate.

After 5 or 10 failed attempts (depending on the type of SIM card), the SIM card is definitely locked. You must then contact your operator to obtain a new card.

Help

Among the various phone menus, a

Note

: displaying help pages is done with the WAP browser but does not need a WAP connection.

Help

menu displays explanation pages for using the functions concerned.

Switching ON/OFF

When your phone is off, a short press on will turn it ON. When the phone is ON, if your are browsing inside the menus, a short press on will come back to the idle screen. When

you are in the idle screen, a long press on will switch OFF the phone.

Quick start 13

252889386_my900C-my901C_en.book Page 14 Vendredi, 30. mars 2007 9:47 09

Network

Once ON, the phone is searching for a network on which it can make calls. If it finds one, it displays the name of the network on the screen.

Note

: if it finds a 3G network, the 3G icon is displayed on the screen.

You are then ready to send or receive a call.

If the network’s name appears, calls are possible on your operator's network. If the letter R and a network name are displayed, calls are possible on a roaming network provider. If the letter E is displayed without any network name, only the emergency services are accessible (ambulance, police, fire brigade). If the network icon flashes, the phone is in permanent search mode. There is no network available. The signal strength indicator received allows you to display the quality of reception. If it indicates less than three bars, search for better reception in order to call in good conditions.

First call

Dial the number you want to ring. Press . You can adjust the sound level (volume) using the navigator upwards or downwards. At the end of the conversation press to hang up.

International call

Press 0 (hold down) to display « + », then dial the country code without waiting for the dial tone, then the number of the called party.

Emergency services

Depending on the network you can obtain the emergency service with or without SIM card. It is enough to be in an area served by a network. To obtain the international emergency service, dial

14 Quick start

112

then press .

252889386_my900C-my901C_en.book Page 15 Vendredi, 30. mars 2007 9:47 09

Receiving a call

When you receive a call, the number of your caller is displayed when it is presented by the network. Press to answer, and speak. To refuse the call, press . To stop the ring tone or the vibrate, without refusing the call, press

Hands-free mode

During a call, press to switch into hands-free mode.

WARNING:

in this mode do not bring the phone up to your ear.

When on a call, pressing [

Options

] allows you to have access to different functions.

Video call

If you want to make a video call, dial the number then press the VIDEOCALL key (or select, pressing [

call

option).

You can also select the number in the phonebook and press the VIDEOCALL key (or [

Notes

- The recipient must also have a phone with this function.

- Videotelephony only operates on the 3G network, check the 3G icon is displayed on the idle screen before making a video

call.

Receiving a video call

- Press the VIDEOCALL key.

You can select to activate or not the camera:

- press

or to activate the camera

- press if you do no want to activate the camera.

A prompt asks you if you want to confirm the activation of the loudspeaker.

Quick start 15

Options]/Video call

Options

], the

Video

252889386_my900C-my901C_en.book Page 16 Vendredi, 30. mars 2007 9:47 09

Using your phone

Improving antenna performance

The antenna is integrated in your phone, under the back cover at the top. Avoid putting your fingers on this area when the phone is switched ON. If your fingers obstruct the antenna, the phone may have to operate with a higher power level than usual; decreasing its efficiency quickly. It could also affect the

quality of your communications.

Increase the battery life of your phone

- Don't press the keys when not necessary: each keypress activates the backlight, and uses much power.

- Don't obstruct the antenna with your fingers.

- Activation of Bluetooth® function reduces the phone battery life. We advise you to deactivate it when not in use.

16 Using your phone

252889386_my900C-my901C_en.book Page 17 Vendredi, 30. mars 2007 9:47 09

Charging the battery

Your phone is powered by a rechargeable battery. A new battery must be charged for 4 hours at least before being used for the first time. It reaches its optimum capacity after a few cycles of use.

When your battery has been discharged, the empty battery icon flashes. In this case recharge your battery for at least 15 minutes before making any calls in order not to be cut off quickly.

To recharge the battery:

Connect the charger to a socket. Plug the end of the cable into the bottom connector of the phone. The phone is then charging up. The battery icon scrolls up and down to indicate that it is charging. When the battery is fully charged, the charging stops on its own. Disconnect the cable. When charging, the battery may warm up, this is normal.

WARNING

If the battery has entirely discharged, the phone cannot start. Plug the phone to the charger. The phone will switch on after a few minutes of charge. You can use the phone again when the

WARNING

There is danger of explosion if the battery is placed in an incorrectly way or if it is exposed to fire. Do not short circuit it. The battery does not have any part that you can change. Do not try to open the battery casing. Use only the appropriate chargers and batteries as shown in the phone manufacturer's catalogue. The use of other types of chargers or batteries may be dangerous or invalidate the warranty. Used batteries must be disposed of in the appropriate places. We advise you to take the battery out if you plan not to use the phone for extended periods. You are strongly advised not to connect your phone to the charger if it doesn’t contain a battery. The charger is a safety step-down transformer, it is forbidden to modify, alter or replace it by another component (power supply plug, etc).

Using your phone 17

Start

option is displayed on the screen.

252889386_my900C-my901C_en.book Page 18 Vendredi, 30. mars 2007 9:47 09

Call history

This menu allows you to access the call log divided into four lists that you can display by the navigator: all calls, outgoing calls, incoming calls and missed calls.

Various options are proposed: store a number in your phonebook, call, send a message, etc. You can also make a call to a number by pressing the key. Fast access to the list of calls from the idle screen: press the key

18 Call history

252889386_my900C-my901C_en.book Page 19 Vendredi, 30. mars 2007 9:47 09

Phonebook

Using the phonebook

Enter the

Phonebook

The icon displayed next to a contact’s name shows in which phonebook the contacts is stored.

contact stored in the SIM card

contact stored in the phone

You can search for a contact quiclky by typing the first letters. You can display it by pressing

menu, the contacts list is displayed if you already get some (otherwise, go to

Storing a new contact

- Display the

- Enter the first name and press OK.

- Enter the last name and press

- Enter the number and press OK.

- Press [

Phonebook

Note:

you can fill other fields if you store the contact in the phone memory (email, address, ringtone, photo, etc.).

Save

] to store it.

, press [

Options

Add new contact

then

Mobile

SIM

Contact options

To display the various options, select a contact and press [

View contact

It allows you to display the contact's information (phone number, email, photo, etc.).

Edit

It allows you to edit and/or modify a contact.

Voice call

It allows you to call the contact selected.

Phonebook 19

Options

Storing a new contact

252889386_my900C-my901C_en.book Page 20 Vendredi, 30. mars 2007 9:47 09

Video call

It allows you to make a video call.

Create message

It allows you to send a written or voice message or a postcard to the contact selected.

Send vCard

It allows you to send contact details by message or Bluetooth®.

Delete

It allows you to delete the contact selected.

My Details

You can enter the details corresponding to your own number.

Set as Business Card

The details of a contact stored in the phone memory can be saved in a business card.

Manage

Assign Speed Dial

Copy to mobile Move to mobile

Copy to SIM

number will be copied.

Move to SIM

Duplicate

Copy all Delete all

Memory

: it allows you to assign a short number to a contact. : it allows you to copy a contact stored in the SIM card to the phone memory. : It allows you to move the contact selected stored in the SIM card to the phone memory.

: It allows you to copy a contact from the phone memory to the SIM card. Only the name and the first phone

: It allows you to move a contact from the phone memory to the SIM card.

: it allows you to copy contact details to add a new one.

: it allows you to copy all the contacts from one memory to the other.

: it allows you to delete all the contacts.

: it shows the number of contacts stored in each memory and the available memory space.

Add to group

It allows you to add a contact to a group or to create a new group.

20 Phonebook

252889386_my900C-my901C_en.book Page 21 Vendredi, 30. mars 2007 9:47 09

Contact Settings

Prompt to save

activate or deactivate a request to store the number in the phonebook.

View Contacts

switches on.

Sort contacts by

: after an incoming or outgoing call with a number not stored in the phonebook, this option allows you to

: it allows you to select the default phonebook (SIM, phone, SIM and phone) displayed when the phone

: This menu allows you to select the way to sort contacts in the phonebook (by name or first name).

Emergency number

This menu lists various services numbers and emergency numbers.

Synchronize

You can synchronize your contacts stored in the phone memory with those of your computer electronic mails. Use the Wellphone software (provided on an optional CD or available from www.wellphone.com) and configure your USB connection in your phone or activate Bluetooth

Synchronization parameters

You can directly enter the contacts database settings.

Call groups

A call group allows you to group contacts: this group can be used to send messages easily to all the group contacts.

- In the phonebook, select the

- Press [

Add group

- Enter a name and press OK.

- Then the phone displays the contacts list to make your choice.

Phonebook 21

Call groups

] (if there is no group already created) or [

tab.

Options

] then

Add group

252889386_my900C-my901C_en.book Page 22 Vendredi, 30. mars 2007 9:47 09

Messages

The Messaging menu contains the following message types: text messages (SMS, MMS), voice messages and e-mail. MMS is a Multimedia Message Service, which allows you to enclose photos, audio files, and others rich contents to your messages; these messages can even be composed of several slides. MMS are differently charged to SMS are. Please contact your network provider to get more information on their cost and the service availability.

Creating a text message or an e-mail

- Select

Messages/Create New

- Select

Message

Note

: The [

There are two input modes. To switch from one mode to another (ABC mode/T9 mode), make a long press on into upper case/lower case/figures make a short press on

Also you can make your choice by selecting [

ABC mode

press twice the

• abc: lower case text

• ABC: upper case text

• Abc: first letter of the word in upper case

123 mode

T9 mode

• abc T9: lower case text

• ABC T9: upper case text

• Abc T9: first letter of the word in upper case

Using T9 Mode

The Easy Message T9® mode helps you to easily write your messages. The language used is the one selected on the display of the phone (if the language selected is not compatible with the Easy Message T9 Press once the key corresponding to the letter chosen and compose the word by continuing to press the keys corresponding to the various letters without paying attention to the display: the word is highlighted. The same sequence of keys pressed can correspond to several words, existing on the dictionary. If the word that appears is not the word you expected, press the navigator downwards or upwards to scroll through the words corresponding to this key sequence.

22 Messages

Options

] key allows you to select various options for typing the text.

: it allows you to type letters: press on one key several times to make the letter wanted appear (for example:

key to display B).

: it allows you to type figures

(see below for using it)

, the English language will be automatically selected).

E-mail

∗

∗.

Options]/Input mode

To switch

+ 50 hidden pages
