LU 252744938B ITD81 HD EN.book Page 1 Mercre di, 7. juin 2006 6:31 18

DIGITAL TERMINAL

TERRESTRIAL RECEPTION MPEG2 – MPEG4

ITD81

HD TV

USER MANUAL

LU 252744938B ITD81 HD EN.book Page I Mercredi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

CONGRATULATIONS!

This is a new generation of Sagem Communication receiver dedicated to Digital Terrestrial Television.

Once you have connected your receiver, you will be able to enjoy all the services.

You can update your receiver if new functions or services become available.

The Sagem Communication Receiver follows a continuous development strategy. Therefore, we reserve the right to make changes and improvements to the product described in this user manual without any prior notice.

This product complies with EMC directive 89/336/EEC.

CE marking:

The CE marking certifies that the product complies with the essential requirements of the Directive 1999/5/CE of the European Parliament and Council concerning radio equipment and telecommunication equipment for the health and safety of users and concerning magnetic interference.

The CE declaration of conformity can be viewed in the support section of the Sagem Communication site www.sagem.com, or it can be obtained from the following address:

Sagem Communication - Customer relations department

95800 Cergy Saint-Christophe - France

4 rue du Petit Albi

Your Set Top Box is supplied with default code 1234.

I

LU 252744938B ITD81 HD EN.book Page 1 Mercre di, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

Contents

1. DESCRIPTION ...................................................................................................................................................... 2

1.1. Front panel ................................................................................................................................................. 2

1.2. Rear panel .................................................................................................................................................. 2

1.3. Remote control ............................................................................................................................................ 3

2. RECOMMENDATIONS .......................................................................................................................................... 4

3. ENVIRONNEMENT AND SAFETY ........................................................................................................................ 5

4. CONNECTIONS .................................................................................................................................................... 6

4.1. Connection to a high-definition television .................................................................................................... 6

4.2. Aerial connections ....................................................................................................................................... 7

4.2.1. DTT-compatible wireless aerial ........................................................................................................ 7

4.2.2. Non-DTT-compatible wireless aerial ................................................................................................ 8

4.3. Connection to a home cinema amplifier ...................................................................................................... 9

4.4. Connection to a hi-fi unit .............................................................................................................................. 9

5. FIRST INSTALLATION ....................................................................................................................................... 10

5.1. Choice of menu language and Country ..................................................................................................... 10

5.2. Installation of DTT channels ...................................................................................................................... 10

6. CHOICE OF LANGUAGES AND COUNTRIES ................................................................................................. 11

7. TERMINAL SETTINGS ........................................................................................................................................ 12

7.1. DTT channel search .................................................................................................................................. 12

7.1.1. Memorisation of DTT channels ....................................................................................................... 12

7.1.2. Reception level indication ............................................................................................................... 12

7.2. Picture adjustment ..................................................................................................................................... 13

7.2.1. HD outputs ...................................................................................................................................... 13

7.2.2. SD output ........................................................................................................................................ 13

7.3. Audio settings ............................................................................................................................................ 14

7.4. Default settings .......................................................................................................................................... 15

8. USER SETTINGS ................................................................................................................................................ 16

8.1. Changing the parental pin code ................................................................................................................ 16

8.2. Parental control options ............................................................................................................................. 16

8.3. User preferences ....................................................................................................................................... 17

8.4. User List .................................................................................................................................................... 17

9. USING THE INFO BANNER ................................................................................................................................ 18

10. SOFTWARE UPDATE ......................................................................................................................................... 19

11. TECHNICAL CHARACTERISTICS ..................................................................................................................... 20

12. GUARANTEE ...................................................................................................................................................... 22

13. ENVIRONMENT .................................................................................................................................................. 23

1

LU 252744938B ITD81 HD EN.book Page 2 Mercre di, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

1. DESCRIPTION

Using the high definition digital terminal, you can receive the free DTT (Digital Terrestrial Television) channels ( HD and SD).

The free DTT (Digital Terrestrial Television) channels.

THE PACKAGE CONTAINING YOUR TERMINAL ALSO CONTAINS:

• 1 remote control and 2 batteries.

• 1 mains unit.

• 1 Scart cable.

1.1. Front panel

1

234 5

1. P+/P-

• Change channel.

2. ®

• Wake up the terminal (press and release)

• Reinitialize terminal (press and hold for 5 sec.).

1.2. Rear panel

689

IN

OUT

DTT

6. DTT AERIAL INPUT

7. ANALOGUE VIDEO CONNECTORS Y Pb Pr

8. DIGITAL AUDIO CONNECTOR

9. SCART CONNECTOR (to TV)

10. MAINS SUPPLY UNIT CONNECTOR

3. TERMINAL STATUS INDICATOR

4. DISPLAY DIAL

• The current time when the terminal is on standby.

• The programme number when it is turned on.

5. SUBSCRIBER CARD READER

7

Y

DIGITAL

Pb

LEFT

RIGHT

Pr

HDMI

AUDIOVIDEO

TV

VCR

12V DC IN

1014 13 12 11

11. SCART CONNECTOR (to VCR or DVD writer)

12. ANALOG AUDIO CONNECTORS (to hi-fi unit)

13. HDMI DIGITAL AUDIO VIDEO CONNECTOR

14. DTT AERIAL OUTPUT

2

LU 252744938B ITD81 HD EN.book Page 3 Mercre di, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

1.3. Remote control

*

Used to switch from TV mode to terminal mode and AUX scart mode.

*

Access radio mode *.

*

Access teletext mode.

V+/V-

Volume adjustment.

MENU

Access terminal customization screens:

• PIN Code management

• Selection of favourite channels

• Terminal setting

• Storing channels

INFO BANNER

Information on current/followin g programme.

OK

Confirms a selection

EXIT

Exit from an application (

BANNER or MENU for example).

1234...

Access a particular channel

INFO

ON/OFF

Put terminal on standby:

• Normal (press and release)

• Sleep (press and hold for 5sec.)

To wake up the terminal from sleep mode, press the terminal front panel.

Button not assigned

Favourite channels

Access favourite channels.

P+/P-

Change channel.

Mute

Switches sound on or off.

GUIDE

*

Access to programme guide.

Navigation arrows

MENU, you use them to

• In the navigate between the various screens.

INFO BANNER, you use

• In the them to see what programmes are on other channels later on.

RETURN

Return to the last screen or channel visited.

® button on the

SAT/DTT**

* not available ** not available: DTT receiver only

HD

Change resolution mode if HD option enabled.

3

LU 252744938B ITD81 HD EN.book Page 4 Mercre di, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

2. RECOMMENDATIONS

X WHERE TO PUT YOUR TERMINAL?

• The terminal must be connected to an easily-accessible mains socket.

• Choose a location away from radiators or other heat sources.

• Leave free space around the terminal for ventilation and ensure that curtains, other appliances or cupboards cannot prevent air circulating around the ventilation slots.

• Avoid exposing the terminal to very strong light (sun, spotlights, etc.).

X INSERTING BATTERIES INTO THE REMOTE CONTROL

• Remove the cover on the back of the remote control. Insert the two round AAA 1.5 batteries supplied (press and raise the cover using a coin for example).

X SAFETY INSTRUCTIONS

• To avoid short-circuits (fire or electrocution hazard) do not expose your terminal to dampness. Do not place any object containing liquid (vase for example) on the appliance. The terminal must not be splashed with liquid. If necessary, disconnect your terminal and consult your supplier.

• Avoid reconnecting the terminal after it has been subjected to large changes in temperature.

X WARNING

DANGEROUS VOLTAGE INSIDE – DO NOT OPEN THE TERMINAL!

• Any attempt to open the terminal may render you liable to legal action.

• Take care not to allow liquids or metal objects to enter the terminal through the ventilation slots. You will be liable for any repair or replacement costs.

• If liquid is upset onto the terminal, unplug it immediately from the mains.

X This "HD TV" Television Receiver complies with the "HD TV" Minimum Requirements. The "HD TV" Logo is a

trademark of EICTA.

4

LU 252744938B ITD81 HD EN.book Page 5 Mercre di, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

3. ENVIRONNEMENT AND SAFETY

X EUROPEAN DIRECTIVE ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)

In the context of sustainable development, the reduction of wastes to be eliminated by reusing, recycling, composting and energy recovery is strongly advised. In order to comply with this directive which is applicable to EEEs sold after 13/08/2005, your receiver will be taken back free of charge and recycled by the distributor of the EEE within the limits of the quantity and types of equipment bought from them. These appliances which contain substances potentially dangerous to human health and the environment will be recycled.

X DIRECTIVE ON THE RESTRICTION OF USE OF CERTAIN HAZARDOUS SUBSTANCES IN

ELECTRONIC EQUIPMENT (RoHS)

Your receiver along with the batteries supplied comply with the directive relating to the RoHS – dangerous materials such as lead, mercury or cadmium are not used. This avoids environmental hazards and any risks to the health of personnel at the recycling centres. The batteries of the remote control can be removed simply.

Note : When the batteries of the remote control are worn out, please dispose of them at a collection point and

not with household waste.

X MEANING OF LOGOS PRESENT ON THE PRODUCT OR ITS PACKAGING

The deleted dustbin sign means that at the end of its life, the product is subject to selective collection and must not be thrown away in unsorted general household waste.

The looped arrow sign means that the packaging may be recycled and must not be disposed of with household waste.

The green logo means that a financial contribution has been made to the national association for the retrieval and recycling of packaging (Eco emballage in France).

The logo with three arrows shown on the plastic parts means that they may be recycled and that they must not be disposed of with household waste.

X SAFETY

REMINDER FOR TERMINAL CONNECTIONS (PAGE 2 OF THIS MANUAL) Connectors coded 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16: Very low safety voltage

X ELECTRICAL CONSUMPTION OF THE TERMINAL

To reduce the consumption of your terminal, you are recommended to place it in standby mode when not in use. We recommend you to turn off the terminal or unplug it from the mains if you will not be using it for a prolonged period of time.

5

LU 252744938B ITD81 HD EN.book Page 6 Mercre di, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

4. CONNECTIONS

4.1. Connection to a high-definition television

To take advantage of HD high-quality definition, you must connect the HDMI connection of your digital terminal to the HDMI or DVI connector (protected by HDCP) on your television (cable not supplied).

Digital terminal

High definition television

VCR or DVD writer

Your VCR/DVD writer is connected to your television and the terminal using the scart connectors.

Note : If your television is fitted with a DVI connector (protected by HDCP), refer to page 9 of this manual to

carry out the audio connections.

6

LU 252744938B ITD81 HD EN.book Page 7 Mercre di, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

4.2. Aerial connections

To make sure that your terminal can receive all the free DTT channels, you must check first of all that your house is covered by DTT and that your wireless installation is compatible.

TO FIND OUT IF YOU ARE COVERED BY DTT: contact your distributor.

4.2.1. DTT-compatible wireless aerial

• Connect your aerial by plugging in the terrestrial aerial cable to the DTT INPUT connector. Afterwards, connect the DTT OUTPUT connector to the aerial input of your VCR/DVD writer.

• Then connect the mains unit between the 12V connector of the terminal and a mains socket near to the appliance and easily accessible.

• Finally, connect your other appliances as indicated below.

Note : If your VCR/DVD writer has multiple scart connectors, choose the TV or EXT1 connector.

Digital terminal

7

DTTcompatible aerial

VCR or DVD writer

LU 252744938B ITD81 HD EN.book Page 8 Mercre di, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

4.2.2. Non-DTT-compatible wireless aerial

If your wireless aerial is not compatible and you live near a transmitter, you can buy a "FULL BAND" internal aerial from a specialist shop, local audiovisual shop or superstore. If you live a long way from a transmitter, you will need a new external aerial which may be installed by an installer.

• Connect your aerial by plugging in your internal aerial cable to the DTT INPUT connector. You do not change your current aerial connection which stays connected to your TV.

• Then connect the mains unit between the 12V connector of the terminal and a mains socket near to the appliance and easily accessible.

• Finally, connect your other appliances as indicated below.

Note : If your VCR/DVD writer has multiple scart connectors, choose the TV or EXT1 connector.

Digital terminal

VCR or DVD writer

Non-DTTcompatible aerial

DTT-compatible internal aerial

8

LU 252744938B ITD81 HD EN.book Page 9 Mercre di, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

4.3. Connection to a home cinema amplifier

To take advantage of quality DOLBY DIGITAL sound available on some channels, we advise you to connect your terminal to your HOME CINEMA amplifier fitted with a coaxial input. Connect the DIGITAL AUDIO output to the input of your HOME CINEMA amplifier (coaxial cable not supplied).

Digital terminal

4.4. Connection to a hi-fi unit

To take advantage of the terminal's laser quality sound, just connect the right and left audio outputs of the terminal to the auxiliary input of your hi-fi system (cable not supplied).

Tip: Connected this way, you can listen to radio channels with the TV turned off.

Home Cinema Amplifier

Digital terminal

HI-FI unit

9

LU 252744938B ITD81 HD EN.book Page 10 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

5. FIRST INSTALLATION

• Switch on your TV.

• The welcome screen appears. If it has still not appeared after 30 seconds, switch your TV to the auxiliary inputs (HDMI, YUV, Scart) until the welcome screen does appear.

5.1. Choice of menu language and Country

WELCOME

OSD LANGUAGE SWEDISH

DTT CHANNEL

With your box you can access to the free digital terrestrial television channels. To accede, press OK key of your remote. If not select "to not install DTT"

SEARCH

TO NOT INSTALL DTT TO INSTALL DTT

• Choose your menu language.

• Choose the country in which the terminal is to be used

If you want to install the free DTT channels straight away, select "TO INSTALL DTT", otherwise select "TO NOT INSTALL DTT".

Note: If you are unable to receive the DTT signal, choose "Cancel" to cancel the DTT channels installation procedure and refer to section 7.2 to adjust your antenna and carry out another memorisation operation.

DTT CHANNEL

PROCESSING CHANNEL : 35

SEARCH

Your terminal is now ready to work. However, you should refer to chapter 7 "Terminal settings" for a configuration better suited to your needs, and to chapter 8 "User settings", depending on your preferences.

10

LU 252744938B ITD81 HD EN.book Page 11 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

6. CHOICE OF LANGUAGES AND COUNTRIES

Press the MENU key to access the settings.

MAIN MENU

LANGUAGES/COUNTRY

USER SETTINGS

BOX SETTINGS

CONDITIONNAL ACCESS

EXIT

Select the "Languages/country" line.

OSD LANGUAGES

COUNTRY

AUDIO TRACK

SUBTITLING

TELETEXT LANGUAGE

LANGUAGES/COUNTRY

ENGLISH

SWEDEN

SWEDISH

DANISH

EXIT

Choose your preferred settings.

Note: your choice of audio language and subtitles will be applied at each channel change, provided that they are broadcast.

11

LU 252744938B ITD81 HD EN.book Page 12 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

7. TERMINAL SETTINGS

7.1. DTT channel search

7.1.1. Memorisation of DTT channels

CHANNEL SEARCH

DTT CHANNEL SEARCH

DTT SIGNAL INFORMATIONS

DTT CHANNEL

PROCESSING CHANNEL : 35

SEARCH

• Select the "DTT channel search" line by OK.

BACK

• The search begins automatically. If no channel is found, adjust your dish using the following level control screen.

7.1.2. Reception level indication

checked DTT channel DTT Transmitter signal strength cber vber not received packet tps presence aci cci presence long echos

27

frequency: 522,17

none Yes No No No

DTT SIGNAL DIAGNOSTIC

-63 dBm 1,16e-04 0

The "diagnostic" screens can help you adjust your dish more accurately.

12

LU 252744938B ITD81 HD EN.book Page 13 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

7.2. Picture adjustment

7.2.1. HD outputs

If you have connected your terminal to an "HD ready" flat screen with a YUV, HDMI or DVI input, you should set "HD outputs activation" to "Yes".

VIDEO SETTINGS

HD outputs activation

HD outputs resolution

TV screen format

video resizing

AUX scart

7.2.2. SD output

If you have not connected your terminal to an "HD ready" flat screen, but to a standard 16/9 or 4/3 television, you should set the "HD outputs activation" option to "No". The YUV and HDMI outputs on your terminal will then output no video signal.

HD outputs activation

TV screen format

video resizing

TV scart

AUX scart PAL S-VIDEO

Yes No

1080i 720p

4/3 16/9

letter box pan & scan

PAL S-VIDEO

CANCELDEFAULT VALUES OK

VIDEO SETTINGS

Yes No

4/3 16/9

letter box pan & scan

PAL RGB

CANCELDEFAULT VALUES OK

• Select the required resolution: 1080i or 720p.

• "Make sure that the chosen screen format is 16/9.

• Choose the AUX scart video standard (PAL or S-Video).

• Note that the video output on the AUX scart is not in HD quality but in SD and the 16/9 format of the HD video will be delivered in 4/3 letter box format.

• "If the terminal's HD outputs are used (YUV or HDMI) the TV scart only outputs PAL video (RGB cut).

• Choose the format of your standard TV: 4/3 or 16/9.

• If you have a 4/3 TV, select the "Letter box" option in other words a 16/9 picture in a 4/3 screen, or the "pan and scan" option, in other words the centre of a 16/9 image in a 4/3 screen.

• Choose the TV scart video: PAL or RGB (better quality).

• Choose the AUX scart video: PAL or S-video (better quality).

13

LU 252744938B ITD81 HD EN.book Page 14 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

7.3. Audio settings

Access this screen from the MENU key, then "Terminal settings" and "Audio settings".

• To adjust the terminal's volume setting, position the cursor on "-" or "+" to lower or raise the volume and press the OK key.

• If you have HOME CINEMA equipment, set "Dolby AC3" to "Yes".

• If you are using the HDMI or DIGITAL AUDIO connector, set "Dolby AC3" to "YES".

• You can memorise the settings by pressing the "OK" button.

AUDIO SETTINGS

Digital audio output level

MIN MAX

-+

DOLBY AC3 on digital output output

Dolby digital adjusting

Yes No

MIN MAX

-+

CANCELDEFAULT VALUES OK

14

LU 252744938B ITD81 HD EN.book Page 15 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

7.4. Default settings

FACTORY DEFAULT RESET

To enter the reset menu, please enter your parental pin code

* * * *

CANCEL

FACTORY DEFAULT RESET

Your box will be reset to factory condition

This operation will take a few minutes.

Do you confirm the reset ?

In Terminal Settings, choose FACTORY DEFAULT RESET.

As mentioned on the screen opposite, all

!

the channels and settings will be lost if you confirm this choice.

You must enter the parental pin code in order to set this configuration.

OK

CANCEL

CONFIRM

15

LU 252744938B ITD81 HD EN.book Page 16 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

8. USER SETTINGS

8.1. Changing the parental pin code

CHANGE MY PARENTAL CONTROL PIN CODE

Enter your new parental pin code :

Please confirm your parent pin code by entering it again :

8.2. Parental control options

PARENTAL CONTROL OPTIONS

DTT Channels locking :

DTT channels list

Press MENU to access the various configurations. Select "User settings" then "Parental pin code". Enter your code to access the menu opposite then type in and reconfirm your new code.

Note: The decoder is delivered with default pin code 1234.

OKCANCEL

You can lock access to the wished DTT channels. Select the type of channel.

1 channel1 X 2 channel2 3 channel3 4 channel4 5 channel5 6 channel6 7 channel7 8 channel8

OKCANCEL

DTT LOCKED CHANNELS

Then check the channels you want to lock. You will be asked for your parental code when you reach the locked channel.

NEXT<< >>PAGE 1/3

16

LU 252744938B ITD81 HD EN.book Page 17 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

8.3. User preferences

USER PREFERENCES

Zapping banner time out :

LOW MEDIUM HIGH

8.4. User List

USER LIST MANAGER

User list: YES NO

Favourite DTT channels selection

DTT channels list

On this screen you can choose the zapping banner display time.

OKCANCEL

With this screen you can create a list of DTT favourites. Set "User list" to YES. Select the type of list (DTT).

1 channel1 X 2 channel2 3 channel3 4 channel4 5 channel5 6 channel6 7 channel7 8 channel8

OKCANCEL

FAVOURITE DTT LIST

Indicate the required channels. You can switch to the user favourites list by pressing key .

NEXT<< >>PAGE 1/3

17

LU 252744938B ITD81 HD EN.book Page 18 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

9. USING THE INFO BANNER

PRESS OK FOR MORE

Bla Bla bla bla

WATCH

SUMMARY

OPTIONS

SUMMARY

1/3

BACK

17:49

2 C MORE HD SAT MOVIE - IMPOSSIBLE DREAM

16H42 18H56

17:49

2 C MORE HD SAT MOVIE - IMPOSSIBLE DREAM

16H42 18H56

17:49

1 CHANNEL 1 DTH MOVIE - IMPOSSIBLE DREAM FROM 16H42 TO 18H54

used to look for programmes in progress on another channel without leaving the current channel.

on another channel without leaving the current

channel.

More information enables you to:

• watch the selected channel

• see the summary of the channel selected.

AUDIO TRACK

ENGLISH

SUBTITLES

NONE

PREFER

BACK

USER LIST

ACTIVATE

DISPLAYED CHANNEL

ADD

LANGUAGE

BACK

17:49

1 CHANNEL 1 DTH MOVIE - IMPOSSIBLE DREAM FROM 16H42 TO 18H54

17:49

1 CHANNEL 1 DTH MOVIE - IMPOSSIBLE DREAM FROM 16H42 TO 18H54

From the INFO BANNER, you can also choose a different audio language and subtitling than those chosen in the settings menus.

From the INFO BANNER you can also activate or add a channel to your user list.

18

LU 252744938B ITD81 HD EN.book Page 19 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

10. SOFTWARE UPDATE

The decoder software can be updated over the air.

When a new software version is available, the decoder automatically proposes an update.

DOWNLOAD PROCESS

In order to improve the set top box functionnalities, a software download is necessary.

During the download, the screen will be black. Do not switch off your box during this time.

To receive the update press OK otherwise cancel

Press "OK" to start the update (recommended). Your decoder will then be unavailable for a few minutes. During this period, the TV screen is black and the front panel display shows a scrolling "00 - -", "01 - - ", "02 - -", "03 - -", "04 - -", indicating that updating is in progress.

If a problem occurs during the update, the decoder stops and displays an error message on the front panel Pressing any key on the remote control will abort the update process and return the decoder to normal use.

1

CONFIRMCANCEL

2

.

1 The update prompt appears when you exit standby. So that you can take advantage of this important function, we

recommend that you set your decoder to standby when not in use.

2 Refer to appendix A for the list of errors.

19

LU 252744938B ITD81 HD EN.book Page 20 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

11. TECHNICAL CHARACTERISTICS

Transmission standards

DVB-T, MPEG-2, MEPG-4

TERRESTRIAL FRONT END

TERRESTRIAL RF INPUT Input freq. range: UHF 470-862 MHz (8 MHz BW) - VHF 174-222 MHz (7/8 MHz BW) Loop through output frequency Range: 47- 862 MHz COFDM bandwidth: 7MHz & 8MHz RF input level: -90 to -20 dB m RF impedance: 75 Ohm Tuning step: 166.66KHz TERRESTRIAL DEMODULATOR DVBT COFDM mode: 2k /8k, SFN supported Modulation: QPSK, 16-QAM, 64-QAM

VIDEO DECODER

MPEG2 standard MPEG-2 MP@HL for 50Hz Input rates (max) 80 Mbit/s at ship input MPEG-4 PART 10/H.264 MPEG-4 AVC HP@L4 (HD) for 50Hz Input rates (max): 20 Mbit/s for HP@L4 MPEG-4 AVC HP@L3 (SD) Input rates (max): 10 Mbit/s for HP@L3

AUDIO DECODER

MPEG-1/MPEG2 layer I MPEG-1/MPEG2 Layer II (Musicam Audio)(2.0) DOLBY AC3 Loop through Audio decoder, sampling rates 32, 44.1 or 48kHz

OUTPUT RESOLUTION / FORMAT

HD

: 1280x720 @ 50Hz progressive, or 1920x1080 @ 50Hz interlaced - Aspect ratio 16/9

SD

: Aspect Ratio: 4:3 and 16:9 Conversion: Pan and Scan, Letter box Scaling: SD > HD

SD INPUT / OUTPUT

TV SCART RGB out, CVBS, Audio R/L AUX SCART CVBS, S-video, RGB in, Audio R/L

HD OUTPUT

RCA Y, Pb, Pr, audio R/L HDMI with HDCP

AUDIO OUTPUT

HiFi audio output mono stereo in case of MPEG1 la yer II,

Electrical S/PDIF two channel PCM in case of MPEG1layerII, Originally received beatstrea m in case of AC3

CONDITIONAL ACCESS*

1 x ISO/IEC 7816 Smart Card Reader

FRONT PANEL

4 digits amber colour display Indicator: 1 dual colour led IR sensor: 38 KHz 3 buttons 1 smart card reader

REAR PANEL

1 x IEC169-2 female (terrestrial in) 1 x IEC169-2 male (terrestrial out) 2 x SCART (TV, AUX) 1 x HDMI 6 x RCA (YPrPb, Stereo L/R, S/PDIF)

POWER SUPPLY

Mains supply voltage 220-240 V ~50 Hz Power Consumption max: 25W

*not available, free to air DTT only.

20

LU 252744938B ITD81 HD EN.book Page 21 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

APPENDIX A

List of possible error messages when updating the software

Er00 : the software currently in the decoder is identical to the software available on the satellite. Decoder

updating is not necessary. Select CANCEL on the prompt screen.

Er02, ER05, Er10, Er11 : the signal quality does not enable the software to be correctly acquired.

Check the signal strength and quality, with the help of the diagnostic screens. If the signal is correct, try updating again. If this fails once more, postpone updating by selecting CANCEL on the prompt screen.

INFO BANNERFor the other error messages, contact your operator or installation contractor.

21

LU 252744938B ITD81 HD EN.book Page 22 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

12. GUARANTEE

In order to apply the guarantee, you should contact your dealer

or Sagem Communication helpdesk at 08 05 11 18 05.

Proof of purchase will be required. Should any malfunctioning arise,

the dealer or Sagem Communication helpdesk will advise you what to do.

If you bought your equipment from Sagem Communication directly, the following shall apply:

1) Sagem Communication undertakes to remedy by repair, free of charge for labour and replacement parts, any defects in the equipment during a period of twelve (12) months from the date of original delivery of the equipment, where those defects are a result of faulty workmanship.

During this twelve-month guarantee period, the defective equipment will be repaired free of charge; the customer must however return the defective equipment in its original package with all accessories at his/ her own expense, to the address given by Sagem Communication After Sales Department, the phone number of which can be found on the delivery slip. Unless the customer has concluded with Sagem Communication a maintenance contract for the equipment which specifically provides for repairs to be carried out at the customer's residence, the repairs will not be carried out on the equipment at the customer's residence.

The following sentence applies to purchases of equipment for the customer's trade, business or profession. Except as otherwise expressly provided in this Document and to the extent permitted by law, Sagem Communication makes no representations or warranties, express or implied, statuette or otherwise, and to such extent, all terms and conditions implied by law are hereby excluded.

This guarantee does not affect the Customer's statutory rights.

2) Exclusions from Guarantee

SAGEM shall have no liability under the guarantee in respect of: damage, defects breakdown or malfunction due to:

- failure to properly follow the installation process and instructions for use, or

- an external cause to the equipment (including but not limited to, lightening, fire, shock or water damage of

any nature), or

- modifications made without the written approval of Sagem Communication, or

- a failure or neglect to maintain the equipment or inappropriate maintenance, or

- unsuitable operating conditions, particularly of temperature and humidity, or

- repair or maintenance of the equipment by persons not authorised by Sagem Communication, or

- the removal and/or destruction of the label positioned on the fixation screw of the lower plastic cover,

wear and tear from normal daily use of the equipment and its accessories, damage due to insufficient or bad packaging of equipment when returned to Sagem Communication, supply of new versions of software, work on any equipment or software modified or added without the prior written consent of Sagem Communication, malfunctions not resulting from the Equipment or from software installed in user workstations for the purpose of use of the equipment, communication problems related to an unsuitable environment, including:

- problems related to access and/or connection to the Internet such as interruptions by access networks or

malfunction of the line used by the subscriber or his correspondent,

- transmission faults (for example poor geographical coverage by radio transmitters, interference or poor line

quality),

- the local network fault (wiring, servers, workstations) or the failure of the transmission network, the normal

servicing (as defined in the user guide supplied with the equipment) as well as malfunctioning due to servicing not being carried out, servicing costs are in any event always borne by the customer.

ATTENTION

22

LU 252744938B ITD81 HD EN.book Page 23 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

13. ENVIRONMENT

Preservation of the environment as part of a sustainable development logic is an essential concern of the manufacturer. The desire of the manufacturer is to operate systems observing the environment and consequently it has decided to integrate environmental performances in the life cycle of its products, from manufacturing to commissioning, use and elimination.

PACKAGING

The presence of the logo (green dot) means that a contribution is paid to an approved national organisation to improve packaging recovery and recycling infrastructures.

To facilitate recycling, please respect the sorting rules set up locally for this kind of waste.

BATTERIES

If your product contains batteries, they must be disposed of at appropriate collection points.

THE PRODUCT

The crossed-out waste bin stuck on the product means that the product belongs to the family of electrical and electronic equipment.

In this respect, the European regulations ask you to dispose of it selectively:

x At sales points in the event of the purchase of similar equipment. x At the collection points made available to you locally (drop-off

centre, selective collection, etc.).

In this way you can participate in the re-use and upgrading of Electrical and Electronic Equipment Waste, which can have an effect on the environment and human health.

23

LU 252744938B ITD81 HD EN.book Page 24 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

Preservation of the environment as part of a sustainable development logic is an essential concern of the manufacturer. The desire of the manufacturer is to operate systems observing the environment and consequently it has decided to integrate environmental performances in the life cycle of its products, from manufacturing to commissioning, use and elimination.

PACKAGING

The presence of the logo (green dot) means that a contribution is paid to an approved national organisation to improve packaging recovery and recycling infrastructures.

To facilitate recycling, please respect the sorting rules set up locally for this kind of waste.

BATTERIES

If your product contains batteries, they must be disposed of at appropriate collection points.

THE PRODUCT

The crossed-out waste bin stuck on the product means that the product belongs to the family of electrical and electronic equipment.

In this respect, the European regulations ask you to dispose of it selectively:

x At sales points in the event of the purchase of similar equipment. x At the collection points made available to you locally (drop-off

centre, selective collection, etc.).

In this way you can participate in the re-use and upgrading of Electrical and Electronic Equipment Waste, which can have an effect on the environment and human health.

24

LU 252744938B ITD81 HD EN.book Page 25 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

Notes :

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

25

LU 252744938B ITD81 HD EN.book Page 26 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

Notes :

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

26

LU 252744938B ITD81 HD EN.book Page 27 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

Notes :

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

27

LU 252744938B ITD81 HD EN.book Page 28 Merc redi, 7. juin 2006 6:31 18

DIGITAL TERMINAL USER MANUAL

Notes :

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

28

LU 252744938B ITD81 HD EN.book Page 29 Merc redi, 7. juin 2006 6:31 18

User manual

DATA SUBJECT TO CHANGE WITHOUT NOTICE

*252744938B*

Sagem Communication

Société anonyme au capital de 300 272 000 € - 480 108 158 RCS PARIS

27, rue Leblanc - 75512 PARIS CEDEX 15 - FRANCE

www.sagem.com

Sagem ITD81 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
