Sagem FAST 2604, FAST 2644 User Manual
SAGEM F@stTM 2604/2644
Quick Installation Guide
252987009-A_GIR_2604-2644 (gb).i1 1 22/05/2008 13:35:25
Contents
1 CONTENTS OF THE PACK .................................................2
2 CONNECTION .....................................................................
3
2.1 CONNECTING YOUR ROUTER ..............................................................3
2.2 CONNECTING ADDITIONAL TELEPHONES ..........................................3
3 INSTALLATION FROM THE CD-ROM ................................ 4
3.1 INSTALLATION BY WI-FI INTERFACE .................................................... 5
3.2 INSTALLATION USING THE ETHERNET PORT ..................................... 8
3.3 INSTALLATION OF AN ADDITIONAL COMPUTER .................................9
4 TROUBLESHOOTING .......................................................10
4.1 STATUS OF THE LEDS ON THE LEFT OF THE ...................................10
FRONT PANEL .......................................................................................10
4.2 STATUS OF THE LEDS ON THE RIGHT OF THE ................................. 10
FRONT PANEL .......................................................................................10
4.3 ROUTER SUPERVISION .......................................................................11
4.4 «DIAGNOSTICS» TOOL ........................................................................ 12
5 SAFETY INSTRUCTIONS .................................................14
5 SAFETY INSTRUCTIONS (CONTD.) ................................
15
252987009-A_GIR_2604-2644 (gb).i2 2 22/05/2008 13:35:25
SAGEM F@st™ 2604/2644
1
Sagem Communications thanks you for choosing from the SAGEM F@stTM 2604/2644 Routers’
range and hopes that it will provide you with full satisfaction.
SAGEM F@st
TM
2604 and SAGEM F@st
TM
2644 products adapt the ADSL function respectively on
POTS (ITU G.992.1/3/5 - Appendix A) and on ISDN (ITU G.992.1/3/5 - Appendix B).
SAGEM F@st
TM
2604 and SAGEM F@st
TM
2644 equipment includes four Ethernet interfaces
(ETH1 to ETH4).
In addition, this router allows access to all the services provided by your Internet Access Provider, as
shown in the diagram below.
List of symbols used in this guide
Warns you about an action or a serious omission.
Provides you with important information you must take into account.
Presentation
252987009-A_GIR_2604-2644 (gb).i3 3 22/05/2008 13:35:26
SAGEM F@st™ 2604/2644
2
1 CONTENTS OF THE PACK
Before you begin installation make sure that the pack contains the following elements:
Contents of the pack
252987009-A_GIR_2604-2644 (gb).i4 4 22/05/2008 13:35:26
SAGEM F@st™ 2604/2644
3
Make sure that the router is not connected to your computer before you start the installation from the CD-ROM.
2 CONNECTION
2.1 CONNECTING YOUR ROUTER
2.2 CONNECTING ADDITIONAL TELEPHONES
Connect the elements as shown in the diagram below.
Connection
Connect the router as shown in the diagram below.
Note: A «UK» mains adapter can be provided
optionally as required.
L
i
n
e
c
a
b
l
e
252987009-A_GIR_2604-2644 (gb).i5 5 22/05/2008 13:35:27
SAGEM F@st™ 2604/2644
4
3 INSTALLATION FROM THE CD-ROM
Make sure that the router is not connected to your computer before you start the installation from the CD-ROM.
The installation procedure described below was undertaken in Windows VistaTM.
Installation in other Windows® (98, ME, 2000 and XP) can be slightly different.
insert the CD-ROM into the rele-
vant drive; the screen opposite will
appear:
click on Next to display the
precautions to be taken during
installation.
Installation from the CD-ROM
click on Next; the screen opposite
will appear allowing you to select
the type of installation (rst installation or installation of an additional
computer).
252987009-A_GIR_2604-2644 (gb).i6 6 22/05/2008 13:35:28
