Sage SGR200 operation manual

the Adjusta Grill

BGR200

™

EN

QUICK GUIDE

DE

KURZANLEITUNG

CONTENTS

2 We recommend safety rst
4 Getting to know your new appliance
5 Operating your new appliance
7 Care & Cleaning

SAGE®
RECOMMENDS
SAFETY FIRST

At Sage® we are very safety
conscious. We design and
manufacture appliances with
your safety foremost in mind.
In addition, we ask that you
exercise a degree of care
when using any electrical
appliance and adhere to the
following precautions.

IMPORTANT
SAFEGUARDS

READ ALL INSTRUCTIONS
BEFORE FIRST USE AND SAVE
FOR FUTURE REFERENCE

• The full information
book is available at
sageappliances.com

• Before using the rst time
ensure your electricity supply
is the same as shown on
the label on the underside
of the appliance.

• Remove and safely discard
any packaging materials

before rst use.

• The appliance is for household
use only. Do not use the
appliance for anything other
than its intended use. Do not
use in moving vehicles or boats.
Do not use outdoors. Misuse
may cause injury.

• Fully unwind the power cord
before operating.

• Position the appliance on
a stable, heat resistant, level,
dry surface away from the edge
and do not operate on or near
a heat source such as a hot
plate, oven or gas hob.

• Do not let the power cord
hang over the edge of a bench
or table, touch hot surfaces
or become knotted.

• Position the appliance at least
20cm from walls or heat / steam
sensitive materials and provide
adequate space above and on
all sides for air circulation.

• Ensure the power cord does not
become trapped between the
upper and lower hot plates of the
appliance during use or storage.

• Do not leave the appliance
unattended when in use.

The appliance is marked

with a HOT surface
symbol. The lid and other

surfaces will be hot
when the appliance is operating
and for some time after use.
To prevent burns always use

2

WE RECOMMEND SAFETY FIRST

EN

insulated oven mitts or
use handles or knobs
where appropriate.

• Always ensure the appliance
is turned OFF, unplugged at
the power outlet and has been
allowed to cool before cleaning,
moving or storing.

• Do not use the appliance if the
power cord, plug, or appliance
becomes damaged in any way.
If damaged or maintenance
other than cleaning is
required, please contact
Sage Customer Service or
go to sageappliances.com

• Any maintenance other
than cleaning should be
performed by an authorised

®

Sage

service centre.

• Children shall not play with
the appliance.

• The appliance can be used by
children aged 8 or older and
persons with reduced physical,
sensory or mental capabilities
or a lack of experience and
knowledge, only if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards

involved. Cleaning of the
appliance should not be carried
out by children unless they are
8 year or older and supervised.

• The appliance and it’s
cord should be kept out
of reach of children aged
8 years and younger.

• The installation of a residual
current safety switch is
recommended to provide
additional safety when using
all electrical appliances.
Safety switches with a rated
operating current not more
than 30mA are recommended.
Consult an electrician for
professional advice.

The symbol shown

indicates that this appliance
should not be disposed of

in normal household waste.
It should be taken to a local
authority waste collection centre
designated for this purpose or
to a dealer providing this service.
For more information, please

contact your local council oce.

Do not immerse the power
plug, cord or appliance

in water or any liquid.

SAVE THESE INSTRUCTIONS

3

GETTING TO KNOW YOUR NEW APPLIANCE

B

C

GA H

I

J

K

D F

A. 2200 watt element
B. Floating hinged top plate
C. Durable non-stick cooking plates
D. Angle adjust non-slip feet
E. Convenient cord storage in base
F. Variable temperature control dial

Rating Information

220–240V~ 50–60Hz 1850–2200W

4

E

G. POWER and READY lights
H. Adjustable grilling height control clip

with 7 settings
I. Locking storage clip
J. Heavy duty die cast arms
K. Removable drip tray

OPERATING YOUR NEW APPLIANCE

EN

BEFORE FIRST USE

Remove and safely discard any packaging
material or promotional labels before using your

grill for the rst time. Check that the cooking

plates are clean and free of dust. If necessary,
wipe over with a soft damp cloth. Dry thoroughly.

NOTE

When using the grill for the rst time you
may notice a ne smoke haze. This is

caused by the heating of some of the
components. There is no need for concern.

The grill can be used as a grill for searing meats
and vegetables or as a sandwich press for
toasting breads and focaccias. It also features
an adjustable height control feature which

allows you to x the top plate to a range of

positions above the bottom plate.

TO USE AS A GRILL

1. Insert the power plug into a 220-240V

power outlet and turn the power ON.
The red POWER light will illuminate.

2. Turn the variable temperature control

to SEAR for fast heat up. Allow the
grill to pre-heat with the top cooking
plate in the closed position until the
green READY light illuminates.

3. When the grill has preheated, place

the foods to be cooked onto the bottom
cooking plate. Always place foods towards
the rear of the bottom cooking plate.

NOTE

The grill can be used to cook foods in the
open or closed position.

4. Close the top cooking plate. The top

cooking plate has a oating hinge that

is designed to evenly press down on food.

The top plate must be fully lowered to

achieve grill marks on the selected foods.

5. Grilling times will depend on the food

being cooked.

6. Once food is cooked, use the handle

to open the grill and raise the top cooking

plate. Remove food with the help of a plastic

or wooden spatula. Never use metal tongs

or a knife as these can cause damage

to the non-stick coating.

TO USE AS A SANDWICH PRESS

1. Insert the power plug into a 220-240V

power outlet and turn the power ON.

The red POWER light will illuminate.

2. Turn the variable temperature control

to SANDWICH setting. Allow the grill to

preheat with the top cooking plate in the

closed position until the green READY

light illuminates.

3. When the sandwich press has pre-heated,

place the sandwich onto the bottom cooking

plate. Always place sandwiches towards

the rear of the bottom cooking plate.

4. Close the top cooking plate. The top plate

must be fully lowered to cook sandwiches.

5. Once the sandwich is cooked, use the

handle to open the grill and raise the

top cooking plate. Remove sandwich with

the help of a plastic or wooden spatula.

Never use metal tongs or a knife as these

can cause damage to the non-stick coating.

5
