RuggedSwitch™ User Guide
RUGGEDSWITCH™ USER GUIDE
FOR USE WITH RS8000, RS1600, AND RS900 PRODUCTS
RUGGEDSWITCH™ OPERATING SYSTEM V1.5
Version 1.5.1 – Aug. 3, 2004
RuggedCom
64 Jardin Drive, Unit 3G
Concord, Ontario
Canada L4K 3P3
Voice: (905) 760-7799
1-(888) 264-0006
Fax: (905) 760-9909
Support@RuggedCom.com
http://www.RuggedCom.com
Disclaimer
RuggedCom Inc. makes no warranty of any kind with regard to this
material.
RuggedCom shall not be liable for errors contained herein or for
consequential damages in connection with the furnishing, performance, or
use of this material.
Warranty
Five (5) years from date of purchase, return to factory. For warranty
details, visit www.ruggedcom.com or contact your customer service
representative
COPYRIGHT © Dec 2002 RuggedCom Inc.
ALL RIGHTS RESERVED
This document contains proprietary information, which is protected by
copyright. All rights are reserved.
No part of this document may be photocopied, reproduced or translated
to another language without the prior written consent of RuggedCom Inc.
.
2
RuggedCom
ABOUT THIS USER GUIDE
This guide is concerned with aiding the user in the configuration and operation of the
RuggedSwitch™ using the RuggedCom User Interface. Specifically, this guide details
aspects of:
• Accessing the User Interface
• Security (passwords)
• Configuring the switch
• Status determination
• Performance measurement
• Uploading and downloading files
• Dealing with alarms
This guide is intended solely for the purpose of familiarizing the reader with the ways
that the RuggedSwitch™ can be used to support Ethernet switching applications.
About this User Guide
Applicable Firmware Revision
This guide is applicable to RuggedSwitch™ Operating System (ROS) software
revision 1.5.x.
Who Should Use This User Guide
This guide is to be used by network technical support personnel who are familiar with
the operation of networks. Others who might find the book useful are network and
system planners, system programmers and line technicians.
How To Use This User Guide
The index of this guide has been prepared with:
• Entries to each of the “Features” sections of the manual,
• Entries to each of the “Troubleshooting” sections of the manual (located at
the end of each chapter),
• Entries to each of the Menus, organized by name.
RuggedCom
It is recommended that you use this guide along with the following applicable
documents.
RuggedSwitch™ RS8000 Family Installation Guide
RuggedSwitch™ RS1600 Family Installation Guide
RuggedSwitch™ RS900 Family Installation Guide
1
RuggedSwitch™ User Guide
Rugged MediaConverter™ Installation Guide
RuggedCom Fiber Guide
White paper: Rapid Spanning Tree in Industrial Networks
Document Conventions
This publication uses the following conventions:
Note: Means reader take note. Notes contain helpful suggestions or references to materials not
contained in this guide.
Quick Start Recommendations
The following description is included to aid those users experienced with switches
that may wish to attempt to configure the switch without fully reading the guide.
Commands strings have been provided with
1. Locate/mount the chassis in its final resting place.
2. Attach a PC running terminal emulation software to the RS232 port and apply
power to the chassis (default baud rate, data bits, parity - “57600 8 n”, no
hardware/software flow control). Set the terminal type to VT100. Gain access to
the UI (Type <CR>, the default password string is set to “admin”, see Chapter 1).
3. Configure the switch’s IP address (Administration, Configure IP Services, IP
Address) and Subnet Mask (Administration, Configure IP Services, Subnet).
If instead you wish the switch to load the address via DHCP, set the address type
to dynamic (Administration, Configure IP Services, IP Address Type). See
Chapter 1 for more details.
their full path from the root menu.
2
4. You may wish to change the default guest, operator and administration passwords
(Administration, Configure IP Services, Configure Passwords). See Chapter 1
for more details.
5. The ports are already set up with sensible defaults and autoselects where possible.
You may want to hard configure specific settings such as speed, duplex, flow
control and far end fault detection. Broadcast filtering is activated. See Chapter 3
for more details.
6. RSTP is enabled for the bridge by default and can be disabled if desired
(Spanning Tree, Configure Bridge RSTP Parameters, State). RSTP may also
be forced to support only legacy STP (Spanning Tree, Configure Bridge RSTP
Parameters, Version Support). Note that the switch deals with legacy STP
pathcosts by default and can be set to deal with larger path costs (Spanning Tree,
Configure Bridge RSTP Parameters, Cost Style). RSTP may also be set
enabled/disabled on a per port basis (Spanning Tree, Configure Port RSTP
Parameters, Enable). You may also want to identify controllers and IEDs by
setting the Edge parameter to True for those ports (Spanning Tree, Configure
Port RSTP Parameters, Edge). See Chapter 6 for more details.
RuggedCom
About this User Guide
7. At this point the switch will raise links, learn addresses and forward traffic. By
default link alarms and SNMP linkUp/linkDown traps (See Chapter 1) are raised
for all ports. The Port Configuration and Status, View Port Status command
will indicate the current state of the ports in real time. The Ethernet Statistics,
View Ethernet Statistics command will provide a useful indication of traffic on
the switch. The Spanning Tree, View Port RSTP Statistics command will
provide an indication of which ports have been blocked to prevent traffic loops.
8. By default the switch has VLAN 1 configured on all ports (VLAN 1 is always
present for management purposes). IGMP is disabled for VLAN 1 by default and
can be enabled by the Virtual LANs, Configure Static VLANs, IGMP
command.
9. If remote SNMP management or traps are desired, configure the appropriate
manage station (Administration, Configure SNMP Management Stations).
10. Ports that are not in use should be disabled (Port Configuration and Status,
Configure Port Parameters Command) to improve security, increase
performance, reduce power consumption and cause the switch to run cooler.
11. Further concerns such as configuring static MAC addresses, port security, VLANs
and IGMP as well as ensuring robustness, measuring and optimizing performance
are dealt with by reading the guide fully.
For Users Migrating From Revisions ROS 1.2 and Earlier..
1. The “operator” access level has been created. The ability to configure, view and
operate product features has been aligned with the guest, operator and
administration access levels. All passwords are now stored in the configuration
file in an encrypted form.
2. The TFTP Server feature is now configurable. It may be configured to be
disabled, to only allow files to be retrieved or to provide full access.
3. The CLI shell provides a TFTP client command that can be used to upload and
download files from TFTP servers.
4. Port Mirroring has been moved from the Diagnostics menu to the Port
Configuration and Status menu.
5. The system log may now be viewed and cleared from the Diagnostics menu.
RuggedCom
3
RuggedSwitch™ User Guide
