DipSlide Incubator EM4
KK43.1
Lightweight, small incubator specially designed for DipSlides. With transparent, easily removable cover for
quick insertion and removal of DipSlides. Easy to operate, even for inexperienced users. A stand insert and
a thermometer are also supplied. Also usable without a stand for incubation of Petri dishes and contact
plates.
Technical Data
Capacity
4 l
Inner dimensions W x H x D
180 x 125 x 180 mm
Outer dimensions W x H x D
230 x 180 x 230 mm
Capacity
23 DipSlides
Temperature range
Room temperature to 44 °C
Weight
1,5 kg
Power supply
220 V, 25 W
Operation
- Plug the main plug into a 230 V~ socket
- Ideal room temperature: approx. 20 °C
- The temperature of the case is set to 36 °C ± 1 °C
- This temperature can be corrected with the screw on the side of the incubator
- Do not exceed 45 °C
- When the incubator heats up, the red LED lights up
- A control lamp (red LED) confirms the correct function of the incubator
- Clean with a cloth if necessary
- Only use the unit dry! Do not fill with water!
Delivery content
- Screwable cover fastener/plate
- Frame for 23 DipSlides/tubes plus thermometer
- Control thermometer
DipSlide Incubator EM4
KK43.1 1 unit
Instructions for use
