R&S
RT-ZF7A
SMA Adaptor
Manual
(B1Z32)
1801420302
Version 02
This manual describes the R&S RT-ZF7A SMA Adaptor (1801.4126.02).
© 2021 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: +49 89 41 29 - 0
Email: info@rohde-schwarz.com
Internet: www.rohde-schwarz.com
Subject to change – data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1801.4203.02 | Version 02 | R&S®RT-ZF7A
Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol, e.g.
R&S®RT-ZF7A is indicated as R&S RT-ZF7A.
R&S®RT-ZF7A
Safety information
1 Safety information
The product documentation helps you to use the product safely and efficiently.
Keep the product documentation nearby and offer it to other users.
Safety information warns you about the potential dangers and gives instructions
how to prevent personal injuries or damage caused by dangerous situations.
Throughout the documentation, safety instructions are provided when you need to
take care during setup or operation.
Intended use
The equipment under test (EUT) is a signal quality test and development board,
indented to be used at laboratory or test and measurement areas. These areas
are used for analysis, testing and servicing and where equipment is operated by
trained personnel.
Operating site
Only use the product indoors, and keep it dry. The product has no casing and is
sensitive to moisture and humidity.
The product is suitable for pollution degree 2 environments where nonconductive
contamination can occur. For more information on environmental conditions such
as ambient temperature, see the specifications.
Disposal
In line with EN 50419, the product cannot be disposed of in the normal
household waste. Even disposal via the municipal collection points for
waste electrical and electronic equipment is not permitted.
Rohde & Schwarz has developed a disposal concept for the ecofriendly disposal
or recycling of waste material. Rohde & Schwarz fully assumes its obligation as a
producer to take back and dispose of electrical and electronic waste. Contact
your local service representative to dispose of the product.
3Manual 1801.4203.02 ─ 02
R&S®RT-ZF7A
Product description
2 Product description
The R&S RT-ZF7A SMA adaptor is used to connect twisted-pair cables to SMA
ones.
It is used in combination with, for example:
●
R&S RT-ZF7 Automotive Ethernet T&D Fixture
●
R&S RT-ZF8 Automotive Ethernet Compliance Fixture
For data, see the "R&S RT-ZFxx Oscilloscope Test Fixtures - Specifications" at
www.rohde-schwarz.com/brochure-datasheet/rto.
2.1 Deliveries
The R&S RT-ZF7A delivery package contains the following items:
●
R&S RT-ZF7A SMA adaptor
●
Manual
3 Contacting customer support
Technical support – where and when you need it
For quick, expert help with any Rohde & Schwarz product, contact our customer
support center. A team of highly qualified engineers provides support and works
with you to find a solution to your query on any aspect of the operation, programming or applications of Rohde & Schwarz products.
Contact information
Contact our customer support center at www.rohde-schwarz.com/support, or fol-
low this QR code:
4Manual 1801.4203.02 ─ 02
R&S®RT-ZF7A
Figure 3-1: QR code to the Rohde & Schwarz support page
Contacting customer support
5Manual 1801.4203.02 ─ 02
