Rohde&Schwarz RT-ZP03S User Manual

®

R&S

RT-ZP03S
Probe
User Manual

(B2í×2)

1802957302
Version 04

This document describes the following R&S®RT-ZP03S models:

●

R&S®RT-ZP03S (1803.1001.02)

© 2022 Rohde & Schwarz GmbH & Co. KG

Mühldorfstr. 15, 81671 München, Germany

Phone: [phone] - 0

Email: [e-mail]

Internet: www.rohde-schwarz.com

Subject to change – data without tolerance limits is not binding.

R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.

Trade names are trademarks of the owners.

1802.9573.02 | Version 04 | R&S®RT-ZP03S

Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol, e.g.
R&S®RT-ZP03S is indicated as R&S RT-ZP03S.

R&S®RT-ZP03S

Safety and regulatory information

1 Safety and regulatory information

The product documentation helps you use the R&S RT-ZP03S safely and effi­ciently. Follow the instructions provided here and throughout the manual.

Use the product only for its intended use and within its performance limits. If the
probe assembly is used in a manner not specified by the manufacturer, the pro­tection provided by it may be impaired.

Operating site

Only use the product indoors, and keep it dry. The product has no casing and is
sensitive to moisture and humidity.

Do not use the probe in explosive atmospheres.

The product is suitable for pollution degree 2 environments where nonconductive
contamination can occur. Occasionally a temporary conductivity that is caused by
condensation must be expected. Temporary condensation occurs only when the
product is out of service.

Using the probe

Take the following measures for your safety:

●

If any part of the product is damaged or broken, stop using the product. Check
the probe cable regularly for wear. Touching a worn cable during measure­ments can cause injuries.

●

Before connecting the probe to a circuit under test, make sure that the probe
is connected to a grounded measurement instrument.

●

Do not connect a probe to any voltage that exceeds the maximum permissible
input voltage specified in the data sheet.

●

Do not use the probe for measurements on mains circuit.

●

The probe is not rated for any measurement category. Do not use the probes
in circuits with measurement category II, III or IV.

●

With increasing frequency, the voltage on the probe tip should not be higher
than illustrated in the derating curve.

●

Always connect the probe lead to earth ground.

3User Manual 1802.9573.02 ─ 04
