Rockwell Automation PowerFlex 22-WIM-N1, PowerFlex 22-WIM-N4S User Manual

User Manual

DSI Wireless
Interface Module

22-WIM-N1
22-WIM-N4S

FRN 1.xxx

Important User Information

Solid state equipment has operational characteristics differing from those of
electromechanical equipment. Safety Guidelines for the Application, Installation and
Maintenance of Solid State Controls (Publication SGI-1.1 available from your local
Rockwell Automation sales office or online at http://www.rockwellautomation.com/
literature) describes some important differences between solid state equipment and
hard-wired electromechanical devices. Because of this difference, and also because
of the wide variety of uses for solid state equipment, all persons responsible for
applying this equipment must satisfy themselves that each intended application of
this equipment is acceptable.

In no event will Rockwell Automation, Inc. be responsible or liable for indirect or
consequential damages resulting from the use or application of this equipment.

The examples and diagrams in this manual are included solely for illustrative
purposes. Because of the many variables and requirements associated with any
particular installation, Rockwell Automation, Inc. cannot assume responsibility or
liability for actual use based on the examples and diagrams.

No patent liability is assumed by Rockwell Automation, Inc. with respect to use of
information, circuits, equipment, or software described in this manual.

Reproduction of the contents of this manual, in whole or in part, without written
permission of Rockwell Automation, Inc. is prohibited.

Throughout this manual, when necessary we use notes to make you aware of safety
considerations.

Important: Identifies information that is critical for successful application and

understanding of the product.

Allen-Bradley, PowerFlex, Pocket DriveExplorer for Pocket PC, DriveExplorer, and DriveExecutive are either registered

trademarks or trademarks of Rockwell Automation, Inc.

The Bluetooth

®

word mark and logos are owned by the Bluetooth SIG, Inc.

DeviceNet is a trademark of the Open DeviceNet Vendor Association.

ControlNet is a trademark of ControlNet International Ltd.

Windows and Microsoft are registered trademarks of Microsoft Corp.

WARNING: Identifies information about practices or circumstances
that can cause an explosion in a hazardous environment, which may
lead to personal injury or death, property damage, or economic loss.

ATTENTION: Identifies information about practices or circumstances
that can lead to personal injury or death, property damage, or economic
loss. Attentions help you, identify a hazard, avoid the hazard, and
recognize the consequences.

Shock Hazard labels may be located on or inside the equipment (e.g.,
drive or motor) to alert people that dangerous voltage may be present.

Burn Hazard labels may be located on or inside the equipment (e.g.,
drive or motor) to alert people that surfaces may be at dangerous
temperatures.

Summary of Changes

The information below summarizes the changes made to this manual
since its last release (July 2005):

The information below summarizes the changes made to this manual
since its last release (March 2005):

Description of Change Page(s)

In Chapter 3 in the “Using Pocket DriveExplorer for Pocket PC” section, added
the new subsection “Assigning a Name for the WIM.”

3-8

In Chapter 3 in the “Using DriveExplorer/DriveExplorer Lite” section, added the
new subsection “Assigning a Name for the WIM.”

3-14

In Chapter 3 in the “Using DriveExecutive” section, added the new subsection
“Assigning a Name for the WIM.”

3-23

Description of Change Page(s)

In Chapter 1:

• In section “Equipment Shipped with the WIM,” added categories and items

for 22-WIM-N1 and 22-WIM-N4S.

• In Step 3 of the Quick Start table:

– Corrected Comm Flt Action parameter number from “02” to “07.”
– Corrected Security Mode parameter number from “03” to “05.”
– Corrected Security PIN parameter number from “04” to “06.”
– Added “Use the RTU Master mode to …” and a reference to Appendix D.

1-3

1-5

In Chapter 3 in subsection “To reset a PIN number when misplaced or
forgotten,” added information to retrieve a stored PIN number.

3-26

soc-ii Summary of Changes

Table of Contents

Preface About This Manual

Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-1

Rockwell Automation Support. . . . . . . . . . . . . . . . . . . . . . . . P-2

Conventions Used in This Manual . . . . . . . . . . . . . . . . . . . . . P-3

Third-Party Bluetooth Support. . . . . . . . . . . . . . . . . . . . . . . . P-3

Chapter 1 Getting Started

Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Compatible Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Required Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Chapter 2 Installing the WIM

Installing the NEMA 1 WIM (22-WIM-N1) . . . . . . . . . . . . 2-1

Installing the NEMA 4 WIM (22-WIM-N4S) . . . . . . . . . . . 2-2

Removing the NEMA 1 WIM (22-WIM-N1) . . . . . . . . . . . . 2-4

Chapter 3 Configuring the WIM

Configuration Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Using Pocket DriveExplorer for Pocket PC. . . . . . . . . . . . . . 3-2

Using DriveExplorer/DriveExplorer Lite. . . . . . . . . . . . . . . 3-10

Using DriveExecutive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16

Setting the Fault Action . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24

Enabling and Setting the Security Mode . . . . . . . . . . . . . . . 3-25

Resetting the WIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-26

Chapter 4 Troubleshooting

Understanding the Status Indicator . . . . . . . . . . . . . . . . . . . . 4-1

Viewing WIM Diagnostic Items . . . . . . . . . . . . . . . . . . . . . . 4-3

Viewing and Clearing Events . . . . . . . . . . . . . . . . . . . . . . . . 4-4

Viewing and Clearing DF1 Communication Statistics . . . . . 4-5

Appendix A Specifications

Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Mechanical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

ii Table of Contents

Appendix B WIM Parameters

About Parameter Numbers. . . . . . . . . . . . . . . . . . . . . . . . . . . B-1

Parameter List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1

Appendix C Wireless Flash Updating DSI Peripherals

Using Pocket DriveExplorer for Pocket PC . . . . . . . . . . . . . C-1

Using DriveExplorer/DriveExplorer Lite . . . . . . . . . . . . . . . C-6

Using DriveExecutive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-11

Appendix D Using RTU Master Mode

Establishing Wireless Connection . . . . . . . . . . . . . . . . . . . . D-1

Configuring the Drive Parameters . . . . . . . . . . . . . . . . . . . . D-2

Configuring the WIM for RTU Master Mode . . . . . . . . . . . D-4

System Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-6

Accessing the Drives on RTU Master Network. . . . . . . . . . D-8

Glossary

Index

Preface

About This Manual

Documentation can be obtained online at

http://www.rockwellautomation.com/literature.

Topic Page

Related Documentation

P-1

Rockwell Automation Support P-2

Conventions Used in This Manual P-3

Third-Party Bluetooth Support P-3

Related Documentation

For: Refer to: Publication

Pocket DriveExplorer™
for Pocket PC

http://www.ab.com/drives/driveexplorer, and
Pocket DriveExplorer for Pocket PC online help
(installed with the software)

—

DriveExplorer™ http://www.ab.com/drives/driveexplorer, and

DriveExplorer online help (installed with the software)

—

DriveTools™ SP (includes
DriveExecutive™)

http://www.ab.com/drives/drivetools, and
DriveExecutive online help (installed with the software)

—

HIM HIM Quick Reference 22HIM-QR001…

PowerFlex

®

4 Drive PowerFlex 4 User Manual

PowerFlex 4 Quick Start

22A-UM001…
22A-QS001…

PowerFlex

®

40 Drive PowerFlex 40 User Manual

PowerFlex 40 Quick Start

22B-UM001…
22B-QS001…

PowerFlex

®

400 Drive PowerFlex 400 User Manual 22C-UM001…

RSLinx™
or RSLinx Lite

Getting Results with RSLinx Guide,
and online help (installed with the software)

LINX-GR001…

Bluetooth

®

wireless

technology

http://www.Bluetooth.org or
http://www.Bluetooth.com

—

P-2 About This Manual

Rockwell Automation, Inc. offers support services worldwide, with over
75 sales/support offices, over 500 authorized distributors, and over 250
authorized systems integrators located through the United States alone.
In addition, Rockwell Automation, Inc. representatives are in every
major country in the world.

Local Product Support

Contact your local Rockwell Automation, Inc. representative for:

• Sales and order support

• Product technical training

• Warranty support

• Support service agreements

Technical Product Assistance

If you need to contact Rockwell Automation, Inc. for technical
assistance, please review the information in Chapter 4

, Troubleshooting,
first. If you still have problems, then access the Allen-Bradley Technical
Support web site at www.ab.com/support/abdrives.

Rockwell Automation Support

About This Manual P-3

The following conventions are used throughout this manual:

• Parameter names are shown in the format Parameter xx - [*]. The xx

represents the parameter number, and the * represents the parameter
name — for example Parameter 01 - [Adapter Cfg].

• Menu commands are shown in bold type face and follow the format

Menu > Command. For example, if you read “Select File > Open,”
you should click the File menu and then click the Open command.

• The firmware release is displayed as FRN X.xxx. The “FRN”

signifies Firmware Release Number. The “X” is the major release
number. The “xxx” is the minor update number.

• Pocket DriveExplorer for Pocket PC (version 1.01), My Bluetooth

Places software (version 1.4.2), DriveExplorer Lite (version 4.04),
and DriveExecutive (version 3.01) were used for the screen pictures in
this manual. Different versions of the software may differ in
appearance and procedures.

• This manual provides information about the 22-WIM-N* Wireless

Interface Module (WIM) and using it with PowerFlex 4-Class drives.
The module can be used with other products that support DSI.

Since the WIM requires a Pocket PC, laptop PC or desktop PC equipped
with Bluetooth wireless technology, you may need to install a
third-party, vendor-specific Bluetooth driver. If this driver fails to
establish wireless communication with the WIM, refer to its
documentation for assistance. Furthermore, troubleshooting help may be
available on the vendor web site.

Conventions Used in This Manual

Third-Party Bluetooth Support

P-4 About This Manual

Notes:

Chapter 1

Getting Started

The 22-WIM-N* Wireless Interface Module (WIM) provides a wireless
communications interface between a Pocket PC, laptop computer or
desktop computer equipped with Bluetooth wireless technology and any
Allen-Bradley product supporting DSI. The WIM uses the full-duplex
DF1 protocol

.

Figure 1.1 Components of the WIM

Topic Page

Components

1-1

Features

1-2

Compatible Products 1-2

Required Equipment 1-3

Safety Precautions 1-4

Quick Start 1-5

Status Indicator 1-6

Components

Contains FCC ID: SNT-2XWIMNX
IC: 5450A-2XWIMNX

This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received,
including interference that may cause undesired operation

➊

(NEMA 1 WIM shown)

Item Part Description

➊

Status
Indicator

LED that indicates WIM
operation, when data is being
received from the Bluetooth
wireless technology enabled
Pocket PC or computer, and
when data is being sent to
the Pocket PC or computer.
Refer to Status Indicator

on
page 1-6 and Chapter 4,
Troubleshooting for more

information.

1-2 Getting Started

Features of the WIM include the following:

• A status indicator (LED) that reports the operating status of the

module.

• Connectivity to products implementing DSI, such as PowerFlex

4-Class drives and peripherals. When used with a product, the WIM
will autobaud to the DSI data rate that is used by the product.

• The WIM receives power from the drive. An outside power source is

not needed.

• An RTU Master operating mode for use on an RTU Master network to

monitor, configure, and control up to 32 PowerFlex 4-Class drives
using wireless communication and Allen-Bradley drive software
tools.

• The following tools can be used to configure the WIM:

– Pocket DriveExplorer for Pocket PC (version 1.01 or higher)
– DriveExplorer (version 4.04 or higher)
– DriveExecutive (version 3.01 or higher)
– PowerFlex 4-Class HIM

• The WIM can be used with compatible Allen-Bradley software tools

through wireless communication to flash upgrade itself and other DSI
peripherals (PowerFlex 4-Class HIMs and communication adapters)
to take full advantage of new firmware features as they become
available.

DSI is based on the Modbus RTU serial communication protocol. The
WIM can be used with Allen-Bradley Component Class (PowerFlex
4-Class) drives and other products that support DSI. At the time of
publication, compatible products include all the following types of:

Features

Compatible Products

• PowerFlex 4 drives

• PowerFlex 40 drives

• PowerFlex 40P drives

• PowerFlex 400 drives

Getting Started 1-3

Equipment Shipped with the WIM

When you unpack the WIM, verify that the package includes:

22-WIM-N1

22-WIM-N4S

User-Supplied Equipment

To configure the WIM, you must use one of the following:

Required Equipment

❑ One Wireless Interface Module

❑ This manual

❑ One Wireless Interface Module

❑ One 22-HIM-H30 Cable

❑ This manual

❑ Pocket DriveExplorer for Pocket PC software (version 1.01 or

higher) running on a Pocket PC equipped with Bluetooth wireless
technology

❑ DriveExplorer software (version 4.04 or higher) running on a laptop

or desktop computer equipped with Bluetooth wireless technology

❑ DriveExecutive stand-alone software (version 3.01 or higher) or

bundled with the DriveTools SP suite (version 1.01 or higher)
running on a laptop or desktop computer equipped with Bluetooth
wireless technology

❑ PowerFlex 4-Class HIM (22-HIM-*)

1-4 Getting Started

Please read the following safety precautions carefully.

Safety Precautions

!

ATTENTION: Risk of injury or death exists from machine motion

when using wireless communications and software to Start/Stop/Jog,
configure or otherwise communicate with a drive.

Using the control bar feature in Pocket DriveExplorer for Pocket PC,
DriveExplorer or DriveExecutive with wireless communications may
present safety hazards due to potential loss of the wireless connection.
For example, if the wireless connection is interrupted after a start or jog
command is initiated from the control bar, the drive cannot be stopped
using the control bar until the wireless connection is restored. For this
reason, it is required to always use an additional hard-wired stop circuit
to disable the drive.

!

ATTENTION: Risk of injury or equipment damage exists. Only

personnel familiar with drive and power products and the associated
machinery should plan or implement the installation, start-up,
configuration, and subsequent maintenance of the product using a
WIM. Failure to comply may result in injury and/or equipment damage.

!

ATTENTION: Risk of injury or equipment damage exists.
Parameter 02 - [Comm Flt Action] lets you determine the action of

the WIM and connected drive if DF1 serial communications are
disrupted. By default, this parameter faults the drive. You can set this
parameter so that the drive continues to run. Precautions should be
taken to ensure that the setting of this parameter does not create a risk
of injury or equipment damage. When commissioning the drive, verify
that your system responds correctly to various situations (for example, a
communication disruption or a faulted controller).

Getting Started 1-5

This section is designed to help experienced users quickly start using the
WIM. If you are unsure how to complete a step, refer to the referenced
chapter.

Figure 1.2 NEMA 1 WIM (22-WIM-N1) Installed in a HIM Bezel (22-HIM-B1)

Quick Start

Step Action Refer to…

1 Review the safety precautions for the WIM. Throughout this

manual

2 Install the WIM.

To install the NEMA 1 WIM (22-WIM-N1) in a remote-mounted
HIM bezel (22-HIM-B1), first install the bezel (see HIM Bezel
Installation Instructions Publication No. 22HIM-IN002…). Make
sure the HIM bezel is connected to the drive port using the 2 m
(6.6 ft.) bezel cable. Then place the WIM in the bezel cradle.
Apply power to the drive.

For the NEMA 4 WIM (22-WIM-N4S), see Installing the NEMA

4 WIM (22-WIM-N4S) on page 2-2 for installation instructions.

Chapter

2,
Installing the
WIM

3 Configure the WIM parameters.

The WIM is provided ready for use. It is only necessary to
configure the WIM if you want to:

• Change the default setting (0 = Fault) for Parameter 07 -

[Comm Flt Action]

• Enable the WIM security mode using Parameters 05 -

[Security Mode] and 06 - [Security PIN]

• Use the RTU Master mode to monitor, configure, and

control up to 32 PowerFlex 4-Class drives on a network

Chapter 3,
Configuring the
WIM

Appendix D,
Using RTU
Master Mode

PowerFlex 4/40/400 Drives
(with 22-COMM-* Adapter)

DeviceNet/ControlNet Network

HIM Bezel with

Installed WIM

Contains FCC ID: SNT-2XWIMNX
IC: 5450A-2XWIMNX

This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received,
including interference that may cause undesired operation

Pocket PC,

Laptop or Desktop

Computer

1-6 Getting Started

The WIM reports its operating status using a tri-color status indicator
(Figure 1.3).

Figure 1.3 Status Indications of the WIM

Status indications under normal operation are described below:

If any other conditions occur, refer to Chapter 4, Troubleshooting.

Status Indicator

Item Status Indication Description

➊

Solid Blue The WIM is receiving data from the Bluetooth wireless

technology enabled Pocket PC or computer, or transmitting
data to the Pocket PC or computer.

Flashing Green The WIM is operating, but has not established wireless

communication with the Bluetooth wireless technology
enabled Pocket PC or computer.

Contains FCC ID: SNT-2XWIMNX
IC: 5450A-2XWIMNX

This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received,
including interference that may cause undesired operation

➊

(NEMA 1 WIM shown)

Chapter 2

Installing the WIM

Chapter 2 provides instructions for installing and removing the WIM.

The WIM is offered in two styles: a NEMA 1 module (22-WIM-N1) and
a NEMA 4 module (22-WIM-N4S). Each style is installed differently.

The NEMA 1 WIM (22-WIM-N1) is installed in a HIM bezel
(22-HIM-B1) that is mounted in a remote location.

1. If the HIM bezel is not mounted, refer to the HIM Bezel Installation

Instructions Publication No. 22HIM-IN002… for mounting details.

2. Route the bezel cable to the drive. Connect the bezel cable to the DSI

port on the bottom of the drive.

3. Install the WIM into the HIM bezel cradle (Figure 2.1

).

Figure 2.1 Installing the WIM in a HIM Bezel

Topic Page

Installing the NEMA 1 WIM (22-WIM-N1)

2-1

Installing the NEMA 4 WIM (22-WIM-N4S) 2-2

Removing the NEMA 1 WIM (22-WIM-N1) 2-4

Installing the NEMA 1 WIM (22-WIM-N1)

22-WIM-N1

(Wireless Interface Module)

22-HIM-B1

Bezel

PowerFlex 4/40/400 Drive

with Installed HIM

2 m (6.6 ft.)

Bezel Cable

Contains FCC ID: SNT-2XWIMNX
IC: 5450A-2XWIMNX

This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received,
including interference that may cause undesired operation

2-2 Installing the WIM

4. The status LED on the WIM momentarily flashes red on powerup

and then flashes green to indicate it is ready to establish wireless
communication with the Pocket PC or computer.

5. Establish wireless communication between the WIM and the Pocket

PC or computer. For this procedure, refer to the respective section in
Chapter 3 that corresponds to the drive software tool you are using:

• Using Pocket DriveExplorer for Pocket PC

on page 3-2

• Using DriveExplorer/DriveExplorer Lite on page 3-10

• Using DriveExecutive on page 3-16

When communication is achieved, the WIM status LED will turn
solid blue.

The NEMA 4 WIM (22-WIM-N4S) is designed for remote installation.
Refer to Figure 2.2

for overall WIM dimensions. Choose an appropriate
location to mount the NEMA 4 WIM. A cable distance greater than 3 m
(10 ft.) is not CE compliant. Maximum cable length should not exceed
10 m (33 ft.).

Figure 2.2 NEMA 4 WIM Dimensions

1. Drill the required hole pattern in the panel. See Figure 2.3 for

dimensions.

Installing the NEMA 4 WIM (22-WIM-N4S)

93,0

(3.66)

25,0

(0.98)

2.0 m

mm
(in.)

180,0
(7.08)

Contains FCC ID: SNT-2XWIMNX
IC: 5450A-2XWIMNX

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received,
including interference that may cause undesired operation

Installing the WIM 2-3

Figure 2.3 Hole Pattern for Mounting NEMA 4 WIM

2. Peel the protective film from the gasketed surface on the back of the

WIM (Figure 2.4).

3. Insert the supplied 2 m (6.6 ft.) WIM cable into the mating socket on

the back of the WIM.

4. Install the supplied O-ring into the cable routing hole on the panel to

protect the cable. Then route the WIM cable through the cable
routing hole on the panel.

5. Align the six threaded studs of the WIM with the panel clearance

holes, and place the WIM against the panel.

6. Tighten the nuts onto the six threaded studs of the WIM extending

behind the panel. Recommended torque is 0.68 N-m (6.0 lb.-in.).

7. Route the WIM cable to the drive. Connect the WIM cable to the DSI

port on the bottom of the drive.

8. Apply power to the drive. The status LED on the WIM momentarily

flashes red on powerup and then flashes green to indicate it is ready
to establish wireless communication with the Pocket PC or computer.

67,0

(2.63)

60,0

(2.36)

77,0

(3.03)

77,0

(3.03)

53,5

(2.11)

∅

19,1

(0.75)

∅

4,8

(0.19)

2-4 Installing the WIM

9. Establish wireless communication between the WIM and the Pocket

PC or computer. For this procedure, refer to the respective section in
Chapter 3 that corresponds to the drive software tool you are using:

• Using Pocket DriveExplorer for Pocket PC

on page 3-2

• Using DriveExplorer/DriveExplorer Lite on page 3-10

• Using DriveExecutive on page 3-16

When communication is achieved, the WIM status LED will turn
solid blue.

Figure 2.4 Mounting NEMA 4 WIM onto Panel

The drive can remain powered when removing a WIM.

Remove the WIM from the remote-mounted HIM bezel.

➌

➋

➍

➎

➏

0.68 N-m

(6.0 lb.-in.)

Removing the NEMA 1 WIM (22-WIM-N1)

!

ATTENTION: Risk of injury or equipment damage exists. If the HIM

bezel cable (for a bezel-mounted WIM) is disconnected from Port 2 on
the bottom of the drive, the drive may fault. Determine how the drive
will respond before disconnecting the cable.

Chapter 3

Configuring the WIM

Chapter 3 provides information about configuring the WIM.

For a list of parameters, refer to Appendix B, WIM Parameters. For
definitions of terms in this chapter, refer to the Glossary.

The WIM stores parameters and other information in its own
Non-Volatile Storage (NVS). You must, therefore, access the WIM to
view and edit its parameters. The following table lists tools that you can
use to access the WIM and edit its parameters.

Topic Page

Configuration Tools

3-1

Using Pocket DriveExplorer for Pocket PC 3-2

Using DriveExplorer/DriveExplorer Lite 3-10

Using DriveExecutive 3-16

Setting the Fault Action 3-24

Enabling and Setting the Security Mode 3-25

Resetting the WIM 3-26

TIP: The WIM is provided ready for use. It is only necessary to
configure the WIM if you want to:

• Change the default setting (0 = Fault) for Parameter 07 - [Comm Flt

Action].

• Enable the security mode using Parameters 05 - [Security Mode]

and 06 - [Security PIN].

• Use the RTU Master mode to monitor, configure, and control up to 32

PowerFlex 4-Class drives on a network. (See Appendix

D for details.)

Configuration Tools

Device Type Tool Refer to…

Pocket PC Pocket DriveExplorer for Pocket PC (version 1.01 or higher) Page 3-2

Laptop or
Desktop
Computer

DriveExplorer software (version 4.04 or higher) Page 3-10

DriveExecutive software (version 3.01 or higher) Page 3-16

PowerFlex HIM —

3-2 Configuring the WIM

With Pocket DriveExplorer for Pocket PC software running on a Pocket
PC equipped with Bluetooth wireless technology, you can edit parameters
in the WIM, connected drive, and any of the attached peripherals.

If you are unsure how to use Pocket DriveExplorer for Pocket PC, refer
to the online help (select Help > Help Topics).

Establishing Wireless Communication Between the WIM and
Pocket PC

1. Launch Pocket DriveExplorer for Pocket PC from the Today Screen

to create a new connection using the Connection Manager
(Figure 3.1

).

Figure 3.1 Connection Manager Screen

Using Pocket DriveExplorer for Pocket PC

!

ATTENTION: Risk of injury or death exists from machine motion

when using wireless communications and software to Start/Stop/Jog,
configure or otherwise communicate with a drive.

Using the control bar feature in Pocket DriveExplorer for Pocket PC
(version 2.01 or higher) with wireless communications may present
safety hazards due to potential loss of the wireless connection. For
example, if the wireless connection is interrupted after a start or jog
command is initiated from the control bar, the drive cannot be stopped
using the control bar until the wireless connection is restored. For this
reason, it is required to always use an additional hard-wired stop circuit
to disable the drive.

Configuring the WIM 3-3

2. Select Connect > New from the menu list. The New Connection

Wizard (Figure 3.2

) appears.

Figure 3.2 New Connection Wizard Screen

3. Select the “Bluetooth” radio button and tap Next ->. The “Where is

your destination?” screen (Figure 3.3

) appears.

Figure 3.3 “Where is your destination?” Screen

4. Select one of the radio button choices:

• Local - point-to-point: Choose “Local” if you want to connect

only to a local drive using the WIM. Selecting “Local” and
tapping Next -> displays the “Local Connection” screen
(Figure 3.4

) which requests you to name the connection for later

reuse.

• Remote - routed over a network: Choose “Remote” if you want

to connect to a local drive using the WIM and then route through it
to a remote device on DeviceNet™ (via 22- COMM-D adapter),
ControlNet™ (via 22-COMM-C adapter) or EtherNet/IP (via

3-4 Configuring the WIM

22-COMM-E adapter). Also choose “Remote” when you intend to
operate the WIM in RTU Master mode. See Appendix D

for
details. If you select “Remote,” disregard Steps 5 through 9 and
instead, go directly to Step 10 on Page 3-6 and perform sub-steps
A through H.

Figure 3.4 Local Connection Screen

5. Enter a name and tap Next ->. The “Connection Summary” screen

(Figure 3.5) appears.

Figure 3.5 Connection Summary Screen

6. You can save the connection information and connect immediately,

or save the connection for connecting later.

After making a selection, the “Location for saved connection” screen
(Figure 3.6

) appears, enabling you to navigate to a desired location

on the Pocket PC to store connections.

Configuring the WIM 3-5

Figure 3.6 “Location for saved connection” Screen

7. Ta p OK to save the connection file and begin the connection process.

The “Searching for Bluetooth Connections” screen
(Figure 3.7

) appears, asking you to select a detected Bluetooth

device.

Figure 3.7 Searching for Bluetooth Connections Screen

8. Select the Bluetooth device from this screen and tap OK. This screen

only appears the first time you connect to this Bluetooth device. Its
address is saved to the connection file. The next time you open the
connection, if this same device is within range, Pocket DriveExplorer
for Pocket PC will immediately connect.

The connection process then begins (Figure 3.8

).

3-6 Configuring the WIM

Figure 3.8 Opening Connection Screen

9. The status bar will update and then when connection is complete, the

StatusMonitor application will launch and show the “StatusMonitor”
screen (Figure 3.9

) for the drive.

Figure 3.9 Drive StatusMonitor Screen

You can then select other devices from the Port menu, or other
functions from the Tasks menu.

10. If you will be routing to one or more remote networked drives, you

will need to perform sub-steps A through H in this step. This
requires that you are able to connect to the Bluetooth card/module
(cannot be done offline) because Pocket DriveExplorer for Pocket
PC must interrogate the device and determine what kinds of network
adapters are present.

For an example illustrating remote connection, we are using two
PowerFlex 40 drives with 22-COMM-D DeviceNet adapters
connected to each other using standard DeviceNet cabling.

Configuring the WIM 3-7

A. With the “Where is your destination?” screen (Figure 3.10)

displayed and “Remote” selected, tap Next -> to display the
“Searching for Bluetooth Devices:” screen (Figure 3.11

) that lists

the detected Bluetooth devices.

B. Select the Bluetooth device to which you want Pocket

DriveExplorer for Pocket PC to connect to, and tap OK.

C. With the Remote Configuration screen (Figure 3.12) displayed,

enter a name (for this example, Drive 1) for the drive. Then set its
node address (for this example, “1”) to match the node address of
the 22-COMM-D DeviceNet adapter in Drive 1.

Figure 3.12 Drive 1 Remote Configuration Screen

D. Ta p Next -> to display the Connection Summary screen

(Figure 3.13

) which shows information about this drive being

connected to the network. Then tap Save and Connect Now to

Figure 3.10 “Where is your

destination?” Screen

Figure 3.11 Bluetooth Browser

Screen

3-8 Configuring the WIM

display the “Location for saved connection” screen (Figure 3.14).

E. Use the default name shown or enter a desired name (for this

example, Drive 1). Use the default directory shown or select a
different path to which the connection is saved on the Pocket PC.
Then tap OK. The StatusMonitor screen for the drive appears.

F. From the Drive 1 StatusMonitor screen, select Connect > New…

from the menu list. The New Connection Wizard screen appears.
Then select the “Bluetooth” radio button and tap Next ->.

G. Repeat sub-steps A through E for each remaining drive on the

network.

H. From the last drive’s StatusMonitor screen, select Connect > and

the drive to which you want to connect to (for example, Drive

1.dfc). This establishes connection to that drive and displays its
StatusMonitor screen.

Note: Using the “Remote” connection option for the WIM
establishes a point-to-point connection. Therefore, you can only
connect to one networked drive at a time.

Assigning a Name for the WIM (optional)

The WIM can be assigned a custom name (up to 16 alpha-numeric
characters) that represents its associated drive’s application function,
such as Pump 1 or Conveyor A. After successfully establishing a custom
WIM name, it replaces the default drive name (for example, PowerFlex
40 3P 460V 1.0HP) that appears in the “Searching for Bluetooth
Devices” screen and will now be recognized on the network.

Figure 3.13 Connection Summary

Screen

Figure 3.14 “Location for saved

connection” Screen

Configuring the WIM 3-9

1. From the drive StatusMonitor screen (Figure 3.9), tap the Port menu

and select the drive port to which the WIM is connected. For this
example, Port 1 is selected (Figure 3.15

) because the WIM is
installed in the drive’s bottom RJ-45 port. The WIM StatusMonitor
screen (Figure 3.16

) appears.

2. On the WIM StatusMonitor screen (Figure 3.16

), tap the stylus on
the white area above the “22-WIM-Nx” catalog number to display
the User Text entry screen (Figure 3.17

). In the text box, enter the
desired name for the WIM (for example, Pump 1 shown in

Figure 3.18) and tap OK. The WIM StatusMonitor screen reappears

with the entered name.

3. For the entered name to be recognized on the network, either reset

the WIM or power cycle the drive. Then re-establish wireless
communication between the WIM and Pocket PC.

Figure 3.15 Port Selection Screen Figure 3.16 WIM StatusMonitor Screen

Figure 3.17 User Text Entry Screen Figure 3.18 Pump 1 Screen

3-10 Configuring the WIM

With DriveExplorer software running on a computer equipped with
Bluetooth wireless technology, you can edit parameters in the WIM,
connected drive, and any of the attached peripherals. DriveExplorer Lite,
a free, limited-feature version of DriveExplorer, can be downloaded
from http://www.ab.com/drives/driveexplorer.

If you are unsure how to use DriveExplorer or DriveExplorer Lite, refer
to the online help (select Help > Help Topics).

Establishing Wireless Communication Between the WIM and
Computer

Bluetooth wireless technology enabled cards/modules installed in a
computer are typically provided with a software program to establish
communication with other wireless devices. The following example
procedure describes how to establish communication using the software
program “My Bluetooth Places” (version 1.4.2), which was included
with a specific brand Bluetooth wireless technology module. Different
versions of this software and different programs may differ in
appearance and procedures.

1. Launch the “My Bluetooth Places” program. The program window

(Figure 3.19

) will appear.

Using DriveExplorer/DriveExplorer Lite

!

ATTENTION: Risk of injury or death exists from machine motion

when using wireless communications and software to Start/Stop/Jog,
configure or otherwise communicate with a drive.

Using the control bar feature in DriveExplorer (version 2.01 or higher)
with wireless communications may present safety hazards due to
potential loss of the wireless connection. For example, if the wireless
connection is interrupted after a start or jog command is initiated from
the control bar, the drive cannot be stopped using the control bar until
the wireless connection is restored. For this reason, it is required to
always use an additional hard-wired stop circuit to disable the drive.

Configuring the WIM 3-11

Figure 3.19 My Bluetooth Places Program Window

2. In the “My Bluetooth Places” program window, double-click the

“Find Bluetooth Devices” icon, which starts a search to find the
device to which you want to connect. The “Entire Bluetooth
Neighborhood” window (Figure 3.20

) appears, displaying icons of
all Bluetooth wireless technology enabled devices detected by the
computer card or module that are within its reception range.

Important: Wait for the search to complete before proceeding.

Figure 3.20 Entire Bluetooth Neighborhood Window

3-12 Configuring the WIM

3. In the “Entire Bluetooth Neighborhood” window, double-click on the

device icon to which you want to establish wireless communication
(for this example, the “PowerFlex 40” icon). The “PowerFlex 40”
connection window (Figure 3.21

) will appear.

Figure 3.21 PowerFlex 40 Connection Window

4. In the “PowerFlex 40” connection window, double-click the “COM1

on PowerFlex…” icon to initiate the wireless communication
connection. A pop-up dialog box (Figure 3.22

) appears, indicating

the specific COM port to use for the connection (COM8 for this
example). Click OK.

Important: Always note the COM port shown in the dialog box

because this same specific port must be selected in the
DriveExplorer/DriveExplorer Lite Configure
Communication window (Step 6).

Figure 3.22 COM8 Dialog Box

Configuring the WIM 3-13

The “PowerFlex 40” connection window (Figure 3.23) re-appears,
but this time with the “COM1 on PowerFlex…” icon lit up in green,
indicating that a wireless communication connection now exists.

Figure 3.23 PowerFlex 40 Connection Window with Lit Green Icon

5. Launch DriveExplorer or DriveExplorer Lite to access parameters in

the WIM, connected drive, and any connected peripherals. Then
select Explore > Configure Communication. The Configure
Communication screen (Figure 3.24

) will appear.

Figure 3.24 DriveExplorer/DriveExplorer Lite Configure Communication

Screen

6. Select the same COM port established by the Bluetooth wireless

technology enabled computer (noted in Step 4). For this example,
COM8 is used. There is no need to set the baud rate or change any
other settings. Then click OK.

3-14 Configuring the WIM

7. In the DriveExplorer or DriveExplorer Lite window, select Explore
> Connect > Serial Point-to-Point to display the DriveExplorer

menu tree window. In the left pane, click the + signs to expand the
tree. For this example, click on “22-WIM-Nx DF1 Wireless Module”
to display the WIM parameters in the right pane (Figure 3.25

).

Double-click a parameter to edit it.

Figure 3.25 DriveExplorer/DriveExplorer Lite Menu Tree Window

Assigning a Name for the WIM (optional)

The WIM can be assigned a custom name (up to 16 alpha-numeric
characters) that represents its associated drive’s application function,
such as Pump 1 or Conveyor A. After successfully establishing a custom
WIM name, it replaces the default drive name (for example, PowerFlex
40 3P 460V 1.0HP) that appears in the “Entire Bluetooth Neighborhood”
screen and will now be recognized on the network.

1. With the DriveExplorer/DriveExplorer Lite Menu Tree window
(Figure 3.25

) displayed and the “22-WIM-Nx DF1 Wireless

Module” selected, select Explore > Device Properties… to display
the WIM’s properties screen (Figure 3.26).

Figure 3.26 WIM Properties Screen

Configuring the WIM 3-15

2. In the text box, enter the desired name (for example, Pump 1) and
click Apply. Then click Close to close the WIM properties screen.

3. For the entered name to be recognized on the network, either reset
the WIM or power cycle the drive. Then re-establish wireless
communication between the WIM and the desktop or laptop
computer.

TIP: When using DriveExplorer version 5.01 or higher, you can also
name the WIM with this alternate method:

A. With the DriveExplorer/DriveExplorer Lite Menu Tree window

(Figure 3.25

) displayed, select the “22-WIM-Nx Wireless Module”
in the tree view to display the WIM Product Window (Figure 3.27) in
the right pane.

Figure 3.27 WIM Product Window

B. Click the gray “22-WIM-Nx” title header in the WIM Product

Window to display the WIM name text entry box (Figure 3.28).

Figure 3.28 WIM Name Text Entry Box

C. Enter the desired name (for example, Pump 1) and click Apply.

3-16 Configuring the WIM

With DriveExecutive software running on a computer equipped with
Bluetooth wireless technology, you can edit parameters in the WIM,
connected drive, and any of the attached peripherals.

If you are unsure how to use DriveExecutive, refer to the online help
(select Help > Help Topics).

Establishing Wireless Communication Between the WIM and
Computer

Bluetooth wireless technology enabled cards/modules installed in a
computer are typically provided with a software program to establish
communication with other wireless devices. The following example
procedure describes how to establish communication using the software
program “My Bluetooth Places” (version 1.4.2), which was included
with a specific brand Bluetooth wireless technology module. Different
versions of this software and different programs may differ in
appearance and procedures.

1. Launch the “My Bluetooth Places” program. The program window

(Figure 3.29

) will appear.

Using DriveExecutive

!

ATTENTION: Risk of injury or death exists from machine motion

when using wireless communications and software to Start/Stop/Jog,
configure or otherwise communicate with a drive.

Using the control bar feature in DriveExecutive (version 4.01 or higher)
with wireless communications may present safety hazards due to
potential loss of the wireless connection. For example, if the wireless
connection is interrupted after a start or jog command is initiated from
the control bar, the drive cannot be stopped using the control bar until
the wireless connection is restored. For this reason, it is required to
always use an additional hard-wired stop circuit to disable the drive.

Configuring the WIM 3-17

Figure 3.29 My Bluetooth Places Program Window

2. In the “My Bluetooth Places” program window, double-click the

“Find Bluetooth Devices” icon, which starts a search to find the
device to which you want to connect. The “Entire Bluetooth
Neighborhood” window (Figure 3.30

) appears, displaying icons of
all Bluetooth wireless technology enabled devices detected by the
computer card or module that are within its reception range.

Important: Wait for the search to complete before proceeding.

Figure 3.30 Entire Bluetooth Neighborhood Window

3-18 Configuring the WIM

3. In the “Entire Bluetooth Neighborhood” window, double-click on the

device icon to which you want to establish wireless communication
(for this example, the “PowerFlex 40” icon). The “PowerFlex 40”
connection window (Figure 3.31

) will appear.

Figure 3.31 PowerFlex 40 Connection Window

4. In the “PowerFlex 40” connection window, double-click the “COM1

on PowerFlex…” icon to initiate the wireless communication
connection. A pop-up dialog box (Figure 3.32) appears, indicating
the specific COM port to use for the connection (COM8 for this
example). Click OK.

Important: Always note the COM port shown in the dialog box

because this same specific port must be selected in the
RSLinx Configure RS-232 DF1 Devices window
(Step 6).

Figure 3.32 COM8 Dialog Box

Configuring the WIM 3-19

The “PowerFlex 40” connection window (Figure 3.33) re-appears,
but this time with the “COM1 on PowerFlex…” icon lit up in green,
indicating that a wireless communication connection now exists.

Figure 3.33 PowerFlex 40 Connection Window with Lit Green Icon

5. Launch RSLinx to create a driver to represent the connection on

COM8 (communication port assigned in Step 4 on Page 3-18

.

6. Select Communication > Configure Drivers… to display the

Configure Drivers screen. From the Available Driver Types
pull-down list, select “RS-232 DF1 devices” as shown in
(Figure 3.34

).

Figure 3.34 Configure Drivers Screen

3-20 Configuring the WIM

7. After the driver is selected, click the Add New… button. The Add

New RSLinx Driver screen will appear. Create a name for the new
driver or use the default name, and click OK.

8. The Configure RS-232 DF1 Devices window (Figure 3.35

) appears.

Figure 3.35 Configure RS-232 DF1 Devices Window

Use the following settings:

Then click OK.

9. The Configure Drivers window (Figure 3.36

) will re-appear. Verify

that the status of the newly created driver is “Running.” Then click
Close.

Configuration Field Setting

Comm Port Select the same COM port established by the Bluetooth

wireless technology enabled computer (noted in Step 4). For
this example, COM8 is used.

Device 1770-KF2/1785-KE/SCANport

Baud Rate Any setting

Station Number 00

Parity None

Error Checking Any setting

Stop Bits 1

Protocol Full Duplex

Configuring the WIM 3-21

Figure 3.36 Configure Drivers Window

10. Select Communications > RSWho to display the browse window.

Then expand the menu tree in the left pane to display either the
“Unrecognized Device” icon (which represents the drive) or the
“DSI” icon to verify that the driver is communicating with the
device. The screen should look similar to Figure 3.37

.

Figure 3.37 RSLinx Browse Window

11. Launch DriveExecutive to access parameters in the WIM, connected

drive, and any connected peripherals.

12. In the DriveExecutive window, select Drive > Connect to Drive…

to display the Connect to Drive menu tree window. Then expand the
menu tree in the left pane to display either the “Unrecognized
Device” icon (which represents the drive) or the “DSI” icon. The
screen should look similar to Figure 3.38

.

3-22 Configuring the WIM

Figure 3.38 Connect to Drive Window

13. Then click OK. DriveExecutive will begin updating drive

information such as parameter names, diagnostics, etc. and store
them in a DriveExecutive directory established for this purpose.

14. In the left pane of the DriveExecutive menu tree window, click the +

signs to expand the tree. For this example, click on “22-WIM-Nx”
and click “Linear List” to display the WIM parameters in the right
pane (Figure 3.39

). To edit a parameter, double-click it or use the

Value column pull-down menu.

Figure 3.39 DriveExecutive Menu Tree Window

Configuring the WIM 3-23

Assigning a Name for the WIM (optional)

The WIM can be assigned a custom name (up to 16 alpha-numeric
characters) that represents its associated drive’s application function,
such as Pump 1 or Conveyor A. After successfully establishing a custom
WIM name, it replaces the default drive name (for example, PowerFlex
40 3P 460V 1.0HP) that appears in the “Entire Bluetooth Neighborhood”
screen and will now be recognized on the network.

1. With the DriveExecutive Menu Tree window (Figure 3.39

) displayed

and the “22-WIM-Nx DF1” selected, select Peripheral >
Properties… to display the WIM’s Properties screen (Figure 3.40

).

Figure 3.40 WIM Properties Screen

2. In the text box, enter the desired name (for example, Pump 1) and
click OK.

3. For the entered name to be recognized on the network, either reset
the WIM or power cycle the drive. Then re-establish wireless
communication between the WIM and the desktop or laptop
computer.

3-24 Configuring the WIM

By default, when communications are disrupted (for example, loss of
wireless communication), the WIM and connected drive respond by
faulting. You can configure a different response to communication
disruptions using Parameter 07 - [Comm Flt Action].

To change the fault action

Set the value of Parameter 07 - [Comm Flt Action] to the desired
response:

Changes to this parameter take effect immediately. A reset is not
required.

Setting the Fault Action

!

ATTENTION: Risk of injury or equipment damage exists.
Parameter 07 - [Comm Flt Action] lets you determine the action of

the WIM and connected drive if communications are disrupted. By
default, this parameter faults the drive. You can set this parameter so
that the drive continues to run. Precautions should be taken to ensure
that the setting of this parameter does not create a risk of injury or
equipment damage. When commissioning the drive, verify that your
system responds correctly to various situations (for example, disruption
of wireless communication).

Value Action Description

0 Fault The drive will fault.

1 Stop The drive will stop and not fault.

2 Zero data The drive is sent 0 for output data after a communications

disruption. This does not command a stop.

3 Hold last The drive continues in its present state after a communications

disruption.

Configuring the WIM 3-25

The WIM has a security mode to prevent access to its configuration
settings. You can enable the security mode using Parameter 05 -

[Security Mode], and set a desired PIN number using Parameter 06 ­[Security PIN].

To enable the WIM security mode

1. Set Parameter 05 - [Security Mode] to “PIN Required.”

2. Reset the WIM (see Resetting the WIM

on page 3-26).

To set a PIN number

1. Set Parameter 06 - [Security PIN] to a desired 4-digit number
(0000-9999). The default is “0000.”

For your convenience, please write down your assigned PIN number
and store it in a safe place:

PIN Number = ___ ___ ___ ___

2. Reset the WIM (see Resetting the WIM

on page 3-26).

To use the WIM when security mode is enabled

When establishing a wireless connection to the WIM for the first time,
entry of the PIN number will be requested. However, PIN number entry
will not be requested for any subsequent connection when using the
same device (Pocket PC, desktop computer or laptop computer). If you
do not secure your Pocket PC or computer against unauthorized use, the
WIM security feature will not provide its intended protection.

Enabling and Setting the Security Mode

Value Description

0 PIN Not Required (Default)

1 PIN Required

3-26 Configuring the WIM

To reset a PIN number when misplaced or forgotten

If you misplaced or forget the assigned PIN number, you will not be able
to connect to the WIM using drive software. To reset the PIN number,
you will need to access the WIM through a different DSI peripheral (for
example, 22-HIM). Using that peripheral, select Parameter 05 -

[Security Mode] and set it to “0” (PIN Not Required). Then select
Parameter 06 - [Security PIN] to view the stored PIN number.

When using the WIM in RTU Master mode, DSI peripherals are not
supported. In this case, call Drives Technical Support for assistance. (See

Page P-2

for contact information.)

Changes to some WIM parameters require that you reset the WIM before
the new settings take effect. You can reset the WIM by cycling power to
the drive or by using Parameter 08 - [Reset Module].

Set Parameter 08 - [Reset Module] to Reset Module.

After you enter 1 = Reset Module, the WIM will be immediately reset.

Important: This will break the wireless connection, so you will need to

re-establish the connection.

When you enter 2 = Set Defaults, the WIM will set all WIM parameters
to their factory-default settings. After performing a Set Defaults, enter
1 = Reset Module so that the new values take effect. The value of this
parameter will be restored to 0 = Ready after performing the reset or
setting the defaults.

Resetting the WIM

Value Description

0 Ready (Default)

1 Reset Module

2 Set Defaults

Chapter 4

Troubleshooting

Chapter 4 provides information to troubleshoot the WIM.

The WIM reports its operating status using a status indicator
(Figure 4.1

).

Figure 4.1 Status Indications of the WIM

Status Indications

Topic Page

Understanding the Status Indicator

4-1

Viewing WIM Diagnostic Items 4-3

Viewing and Clearing Events 4-4

Viewing and Clearing DF1 Communication Statistics 4-5

Understanding the Status Indicator

Status Cause Corrective Action

Off WIM is not powered. • Securely place WIM in bezel, or

securely connect bezel or WIM cable to
the drive.

• Apply power to the drive.

Contains FCC ID: SNT-2XWIMNX
IC: 5450A-2XWIMNX

This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received,
including interference that may cause undesired operation

➊

(NEMA 1 WIM shown)

4-2 Troubleshooting

Flashing
Green

WIM is communicating with
drive, but not transmitting or
receiving wireless signals.

This is normal behavior for a WIM when it is
operational, but not communicating with a
wireless device.

Establish wireless communication with the
Bluetooth wireless technology enabled
Pocket PC or computer. For this procedure,
refer to the respective section in Chapter 3
that corresponds to the drive software tool
you are using:

• Using Pocket DriveExplorer for Pocket

PC on page 3-2

• Using DriveExplorer/DriveExplorer

Lite on page 3-10

• Using DriveExecutive on page 3-16

Flashing
Green/Red

WIM is in boot mode, or WIM
may have a corrupted flash
file.

Reflash WIM firmware. If issue persists,
return WIM to factory for repair/
replacement.

Solid Blue WIM is communicating with

drive, or is in process of flash
updating (WIM or DSI
peripheral).

No action required.

Solid Red Internal communication error.

WIM diagnostic and
initialization sequence did
not complete.

• Power cycle the drive.

• Check cables and their connections.

• If issue persists, return WIM to factory

for repair/replacement.

Flashing
Red

WIM is not communicating
with drive.

• Power cycle the drive.

• Check cables and their connections.

• If issue persists, return WIM to factory

for repair/replacement.

WIM is a slave device and
the DSI master stopped
communicating or was
removed.

• Power cycle the drive.

• Check cables and their connections.

• Check and/or replace 22-COMM-*

adapter installed in drive.

• If issue persists, return WIM to factory

for repair/replacement.

Status Cause Corrective Action

Troubleshooting 4-3

WIM Diagnostic Items can be viewed with the following tools:

• For Pocket PCs, use Pocket DriveExplorer for Pocket PC software
(version 1.01 or higher).

• For laptop or desktop computers, use DriveExplorer software
(version 4.04 or higher), DriveExecutive software (version 3.01 or
higher)

• An LCD PowerFlex 4-Class HIM.

If you encounter unexpected communications problems, diagnostic
items can help you or Rockwell Automation personnel troubleshoot the
problem.

Viewing WIM Diagnostic Items

No. Name Description

1 Field Flash Cnt The number of times the WIM has been field flashed.

2 Adapter Events The number of events in the event queue.

3 Reference The present value of the Reference being transmitted to the

drive by the WIM.

4 Logic Command The present value of the Logic Command being transmitted

to the drive by the WIM.

5 Logic Status The present value of the Logic Status being received from

the drive by the WIM.

6 Feedback The present value of the Feedback being received from the

drive by the WIM.

7 Clear DSI Counts Clears all DSI counters to zero.

8 DSI Packets Sent

(1)

(1)

The number of DSI packets may differ due to other DSI peripherals connected to the drive.

The number of DSI packets sent by the WIM that are in the
correct format.

9 DSI Packets Rcvd

(1)

The number of DSI packets received by the WIM that are in
the correct format.

10 DSI Bad Packets The number of DSI packets detected by the WIM that have

CRC errors.

11 DSI Retries The number of DSI messages re-sent because no

response was received.

4-4 Troubleshooting

The WIM maintains an event queue that reports the history of its actions.
You can view the event queue with the following tools:

• For Pocket PCs, use Pocket DriveExplorer for Pocket PC software

(version 1.01 or higher).

• For laptop or desktop computers, use DriveExplorer software

(version 4.04 or higher), DriveExecutive software (version 3.01 or
higher)

• An LCD PowerFlex 4-Class HIM.

To view the event queue

1. Access the event queue using a configuration tool.

2. Scroll through events in the event queue.

Events

Many events in the Event queue occur under normal operation. If you
encounter unexpected communications problems, the events may help
you or Allen-Bradley personnel troubleshoot the problem. The following
events may appear in the event queue:

Viewing and Clearing Events

Code Event Description

F0 No Event No event present in the WIM event queue.

F1 Adapter Reset The WIM was reset by the user.

F2 Slave Detected A slave was detected to be present by the master.

F3 Slave Removed A slave was detected to be removed by the master.

F4 Host Timeout A timeout condition occurred on Msg to Host.

F5 Slave Timeout A timeout condition occurred on Msg to Slave.

F6 Master Timeout A timeout condition occurred on Msg to Master.

F7 Serial Timeout A timeout occurred on the Serial 232 side (with control

enabled).

F8 Control Enabled The WIM has sent a “Soft Control Enable” command to

the drive.

F9 Control Disabled The WIM has sent a “Soft Control Disable” command to

the drive.

F10 EEPROM Sum Flt The startup sequence detected corrupt EEPROM

storage in the WIM.

Troubleshooting 4-5

To clear the event queue

1. Access the event queue using a configuration tool.

2. Set the value of 1 > Clr Event Queue to Enable, and then press
Enter to clear the event queue.

If you encounter unexpected communications problems or are creating
an application that uses DF1 data, you can view the communications
statistics in the WIM. Parameter 10 - [DF1 Packets Sent] and
Parameter 11 - [DF1 Packets Rcvd] store this data.

To view and clear DF1 data, you must access the main menu in the WIM
firmware.

To view DF1 data

1. Access the parameters in the WIM using a configuration tool.

2. Scroll through the DF1 Parameters 10 and 11, which contain DF1

data. For a description of each parameter, refer to Appendix B

, WIM

Parameters.

To clear DF1 data

1. Access the parameters in the WIM using a configuration tool.

2. Set the value of Parameter 09 - [Clear DF1 Counts] to “1 = Clear
Counts,” and then press Enter to clear the DF1 data.

Viewing and Clearing DF1 Communication Statistics

4-6 Troubleshooting

Notes:

Appendix A

Specifications

Appendix A provides the specifications for the WIM.

Topic Page

Communications

A-1

Electrical A-1

Mechanical A-1

Environmental A-2

Regulatory Compliance A-2

Communications

Radio

Transceiver

Frequency
Power
Range

National Semiconductor LMX9820A Bluetooth Serial Port

Module, V1.1 Bluetooth Compliant Component

2.402 to 2.480 GHz Frequency Hopping

2.5mW Maximum RF Output
Class II – 10 m (32.8 ft.) anticipated* range

(*will vary due to environmental conditions)

Drive

Protocol
Data Rate

Drive Serial Interface (DSI)

19.2 kbps

Electrical

Consumption 170mA at +5V DC

The WIM draws the required power from the connected
product. An external power source is not required.

Mechanical

Dimensions

Height
Width
Depth

NEMA 1 WIM (22-WIM-N1) NEMA 4 WIM (22-WIM-N4S)

116.0 mm (4.57 in.) 180.0 mm (7.08 in.)

70.0 mm (2.75 in.) 93.0 mm (3.66 in.)

16.0 mm (0.63 in.) 25.0 mm (0.98 in.)

Weight 85g (3.0 oz.) 161g (5.7 oz.)

A-2 Specifications

NOTE: This is a product of category C2 according to IEC 61800-3. In a
domestic environment this product may cause radio interference in
which case supplementary mitigation measures may be required.

FCC Statement of Conditions

Compliance Statement (Part 15.19)

This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including

interference that may cause undesired operation.

Environmental

Temperature

Operating
Storage

0 to 50° C (32 to 122° F)

-40 to 85° C (-40 to 185° F)

Relative Humidity 5 to 95% non-condensing

Atmosphere Important: The WIM must not be installed in an area where

the ambient atmosphere contains volatile or corrosive gas,
vapors or dust. If the WIM is not going to be installed for a
period of time, it must be stored in an area where it will not be
exposed to a corrosive atmosphere.

Vibration

Operating
Non-Operating

2.5G @5Hz-2KHz
5 G @5Hz-2KHz

Shock

Operating
Non-Operating

30 G peak acceleration, 11 (±1) ms pulse width
50 G peak acceleration, 11 (±1) ms pulse width

Regulatory Compliance

UL
cUL
CE
CTick
FCC ID
IC

UL508C
CAN / CSA C22.2 No. 14-M91
EN50178 and EN61800-3
AS / NZS 2064, Group 1, Class A
SNT-2XWIMNX
5450A-2XWIMNX

Specifications A-3

Warning (Part 15.21)

Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
equipment.

RF Exposure (OET Bulletin 65)

To comply with FCC RF exposure requirements for mobile transmitting
devices, this transmitter should only be used or installed at locations
where there is at least 20 cm (7.9 inches) separation distance between the
antenna and all persons.

Industry Canada Statement

The term “IC” before the certification/registration number only signifies
that the Industry Canada technical specifications were met.

A-4 Specifications

Notes:

Appendix B

WIM Parameters

Appendix B presents information about the WIM parameters.

The parameters in the WIM are numbered consecutively. You can use the
following configuration tools to access the parameters in the WIM.

Topic Page

About Parameter Numbers

B-1

Parameter List B-1

About Parameter Numbers

Configuration Tool Numbering Scheme

• Pocket DriveExplorer for Pocket PC

• DriveExplorer

• DriveExecutive

• HIM

The adapter parameters begin with parameter

01. For example, Parameter 01 - [Adapter
Cfg] is parameter 01 as indicated by this
manual.

Parameter List

No. Name and Description Details

01 [Adapter Cfg]

Sets the operating mode of the WIM.

Default: 0 = Auto
Values: 0 = Auto

1 = Master
2 = Slave

3 = RTU Master
Type: Read/Write
Reset Required: Yes

02 [Adapter Type]

Displays the present operating mode of the WIM.

Default: 0 = Master
Value: 0 = Master

1 = Slave

2 = RTU Master
Type: Read Only

03 [Drive Addr Cfg]

Sets the node address of the WIM for use with the WIM
operating mode set with Parameter 01 - [Adapter
Cfg]. In Auto, Master or Slave mode, the WIM node
address can be any valid value. In RTU Master mode,
the WIM node address must match the address of any
drive on the network. Each network drive address, set
using drive parameter 104 - [Comm Node Addr], must
be unique.

Default: 1
Minimum: 1
Maximum: 247
Type: Read/Write
Reset Required: Yes

B-2 WIM Parameters

04 [Drive Addr Act]

Displays the node address of the drive that the WIM is
communicating with when the WIM is set to RTU
Master mode using Parameter 01 - [Adapter Cfg].

Default: 1
Minimum: 1
Maximum 247
Type: Read Only

05 [Security Mode]

Enables/disables the security mode for the WIM, which
prevents accessing its parameters and the connected
drive for configuration.

Default: 0
Values: 0 = PIN Not Req’d

1 = PIN Required
Type: Read/Write
Reset Required: Yes

06 [Security PIN]

Sets the PIN number to access WIM parameters for
configuration when Parameter 05 - [Security Mode] is
set to 1 = PIN Required. See Page 3-25

for details.

Default: 0
Minimum: 0
Maximum: 9999
Type: Read/Write
Reset Required: Yes

07 [Comm Flt Action]

Sets the action that the WIM and drive will take if the
WIM detects that DF1 serial communications are
disrupted. This setting is effective only if control I/O is
transmitted through the WIM.

Default: 0 = Fault
Values: 0 = Fault

1 = Stop

2 = Zero Data

3 = Hold Last
Type: Read/Write
Reset Required: No

08 [Reset Module]

No action if set to “Ready.” Resets the WIM if set to
“Reset Module.” Restores the WIM to its factory default
settings if set to “Set Defaults.” This parameter is a
command. It will be set to “0 = Ready” after the
command has been performed.

Default: 0 = Ready
Values: 0 = Ready

1 = Reset Module

2 = Set Defaults
Type: Read/Write
Reset Required: No

09 [Clear DF1 Counts]

No action if set to “Ready.” Resets the DF1 statistical
parameters 10 and 11 to 0 if set to “1 = Clear Counts.”
This parameter is a command. It will be reset to
“0 = Ready” after a “Clear Counts” command has been
performed.

Default: 0 = Ready
Values: 0 = Ready

1 = Clear Counts
Type: Read/Write
Reset Required: No

10 [DF1 Packets Sent]

Displays the number of DF1 packets sent by the WIM.
The value of this parameter is normally approximately
equal to the Parameter 11 - [DFI Packets Rcvd] value.

Default: 0
Minimum: 0
Maximum: 65535
Type: Read Only

11 [DF1 Packets Rcvd]

Displays the number of DF1 packets received by the
WIM. The value of this parameter is normally
approximately equal to the Parameter 10 - [DFI
Packets Sent] value.

Default: 0
Minimum: 0
Maximum: 65535
Type: Read Only

No. Name and Description Details

!

ATTENTION: Risk of injury or equipment damage exists. Parameter 07 ­[Comm Flt Action] lets you determine the action of the WIM and connected

drive if communications are disrupted. By default, this parameter faults the drive.
You can set this parameter so that the drive continues to run. Precautions
should be taken to ensure that the setting of this parameter does not create a
risk of injury or equipment damage. When commissioning the drive, verify that
your system responds correctly to various situations (for example, a disconnect
cable).

!

ATTENTION: Risk of injury or equipment damage exists.The drive will fault
when you remove or reset the WIM. Determine how the drive will respond before
removing or resetting the WIM.

Appendix C

Wireless Flash Updating DSI
Peripherals

Appendix C provides information about using the WIM with compatible
Allen-Bradley software tools through wireless communication to flash
update itself and other DSI peripherals, such as PowerFlex 4-Class HIMs
and communication adapters, to take full advantage of new firmware
features as they become available.

Note: You cannot flash update a PowerFlex 4-Class drive using the
WIM. Instead, you must use the AK-U9-FLSH1 PowerFlex 4-Class
Flash Update Kit, which includes the flash module with cable, a
1203-SFC cable, and instructions.

Important: Using a hard-wired cable connection is the preferred

method to flash update a DSI peripheral. However, if the
application circumstances dictate that a flash update using
wireless communication is necessary, then follow the
procedure for the respective software tool in this appendix.

This wireless flash update procedure uses a 22-COMM-D
communication adapter as the example DSI peripheral being flashed.
When flashing other DSI peripherals, screens associated with that device
will be different than those shown in this procedure.

1. Visit the following Allen-Bradley web site to obtain the appropriate

firmware update for the DSI peripheral:

http://www.ab.com/support/abdrives/webupdate/

At this web site, click on the device to access all of its firmware
updates. Then select Firmware Updates > Application Firmware
Updates (or vx.xxx Flash Kit) > vx.xxx Flash Kit.

Topic Page

Using Pocket DriveExplorer for Pocket PC

C-1

Using DriveExplorer/DriveExplorer Lite C-6

Using DriveExecutive C-11

Using Pocket DriveExplorer for Pocket PC

C-2 Wireless Flash Updating DSI Peripherals

2. Click on the appropriate flash kit version to open the File Download

screen (Figure C.1

).

Figure C.1 File Download Screen

Important: The Pocket PC must be docked with the desktop or

laptop computer during the synchronization process.

Click Open to launch the firmware installation tool. Then click
Next > to launch the ControlFLASH wizard to install the device’s
firmware update on the desktop or laptop computer. Follow the
instructions on the ControlFLASH wizard screens.

Important: In the last screen, the ControlFLASH Setup Complete

screen (Figure C.2

), uncheck both boxes and click

Finish.

Figure C.2 ControlFLASH Setup Complete Screen

Wireless Flash Updating DSI Peripherals C-3

3. With the PDE Flash File Xfer (Transfer) Utility installed on your

desktop or laptop PC, launch this program (Figure C.3

).

Figure C.3 Flash File Transfer Utility Screen

4. In the Select Available Product window (Figure C.4), select the

product to list available updates on the desktop or laptop PC (for this
example, 20-COMM-D via 22-SCM-232 or 22-WIM). In the Select
Available Update window, select the firmware version to be transferred
to the Pocket PC for flash updating (for this example, 1.007.01 Full).

Figure C.4 Flash File Firmware Version Screen

Then click Transfer. Click OK after the files were successfully
transferred. Then click Exit to close the utility program.

C-4 Wireless Flash Updating DSI Peripherals

5. Establish wireless communication between the WIM and Pocket PC.

For this procedure, refer to Using Pocket DriveExplorer for Pocket

PC on page 3-2.

6. With the StatusMonitor screen (Figure C.5) for the drive displayed,
select Port > and then the appropriate port number (for this example,
Port 1) to display the StatusMonitor screen (Figure C.6

) for the

peripheral device being flashed (for this example, the 22-COMM-D).

7. Select Tasks > Flash Update to open the DeviceFlash screen
(Figure C.7

). In the Available Updates list, select the appropriate

firmware version (for this example, 1.007.01 Full). Then tap Next ->
to continue. The DeviceFlash update warning screen (Figure C.8)
appears.

Figure C.5 Port Selection Screen

Figure C.6 StatusMonitor Screen for

22-COMM-D

Figure C.7 DeviceFlash Screen

Figure C.8 DeviceFlash Update

Warning Screen

Wireless Flash Updating DSI Peripherals C-5

8. Ta p Flash to start the flash update (Figure C.9). When the flash

update is complete, Pocket DriveExplorer for Pocket PC will reset
the DSI peripheral (Figure C.10

).

Note: The WIM status indicator changes from solid blue to flashing
red, and then to flashing green after the reset process is complete.

9. Ta p Close to exit the flash update process (Figure C.11

).

Figure C.11 DeviceFlash Completed Screen

The WIM status indicator changes from flashing green to solid blue,
and the StatusMonitor screen will reappear. Verify that the Product
Revision number matches the firmware version that was flashed to
the peripheral device.

Figure C.9 Flash Update Progress

Screen

Figure C.10 Device Reset Screen

C-6 Wireless Flash Updating DSI Peripherals

This wireless flash update procedure uses a 22-COMM-D
communication adapter as the example DSI peripheral being flashed.
When flashing other DSI peripherals, screens associated with that device
will be different than those shown in this procedure.

1. Visit the following Allen-Bradley web site to obtain the appropriate
firmware update for the device:

http://www.ab.com/support/abdrives/webupdate/

At this web site, click on the device to access all of its firmware
updates. Then select Firmware Updates > Application Firmware

Updates (or vx.xxx Flash Kit) > vx.xxx Flash Kit.

2. Click on the appropriate flash kit version to open the File Download

screen (Figure C.12

).

Figure C.12 File Download Screen

Click Open to launch the firmware installation tool. Then click
Next > to launch the ControlFLASH wizard to install the device’s

firmware update on the desktop or laptop computer. Follow the
instructions on the ControlFLASH wizard screens.

Important: In the last screen, the ControlFLASH Setup Complete

screen (Figure C.13

), uncheck both boxes and click

Finish.

Using DriveExplorer/DriveExplorer Lite

Wireless Flash Updating DSI Peripherals C-7

Figure C.13 ControlFLASH Setup Complete Screen

3. Establish wireless communication between the WIM and the desktop

or laptop computer. For this procedure, refer to Using DriveExplorer/

DriveExplorer Lite on page 3-10.

4. With the DriveExplorer linear list screen (Figure C.14) displayed,

click on the device to be flash updated (for this example, a
22-COMM-D communication adapter).

Figure C.14 DriveExplorer Linear List Screen

5. Select Explore > Device Properties… to display the device’s
information screen. Then click the Details tab to show a screen
(Figure C.15

) with the device’s firmware revision information.

C-8 Wireless Flash Updating DSI Peripherals

Figure C.15 Details Tab Screen

6. In the Details tab screen, click the Flash Update… button to open

the Select Flash Update screen (Figure C.16).

Figure C.16 Select Flash Update Screen

In the Available Flash Updates window on this screen, select the
desired firmware version from the list (for this example, 1.007.01
Full). Then click Next > to continue. The Confirm Flash Update
warning screen (Figure C.17

) appears.

Wireless Flash Updating DSI Peripherals C-9

Figure C.17 Confirm Flash Update Warning Screen

7. Click FLASH to start the flash update (Figure C.18).

Figure C.18 Executing Flash Update Progress Screen

Note: Near the end of the flash update process, the WIM status
indicator changes from solid blue to flashing red, and then to
flashing green.

8. When the flash update is completed, the message window in the
Executing Flash Update screen changes to indicate that flash update
was completed (Figure C.19

).

C-10 Wireless Flash Updating DSI Peripherals

Figure C.19 Executing Flash Update Completed Screen

Click Close to exit the Flash Update Completed screen. The Device
Firmware Changed dialog box (Figure C.20

) will appear.

Figure C.20 Device Firmware Changed Dialog Box

9. Depending on the device being flash updated, do one of the following:

– When flashing a peripheral (not the WIM), click Ye s .

DriveExplorer will re-establish the wireless connection to the
device. Then power cycle the drive to initialize the device with
the WIM.

– When flashing the WIM, click No. The wireless connection to

the WIM breaks after the flash update, requiring a manual
reconnection. Use the Bluetooth Manager to re-establish the
wireless connection to the WIM. After wireless communication
is re-established, DriveExplorer will automatically reconnect to
the WIM.

10. With the DriveExplorer linear list screen (Figure C.14

) displayed,

select the device (for this example, a 22-COMM-D communication
adapter). Then select Explore > Device Properties… to verify that
the Revision number shown on the General tab screen matches the
firmware version flashed into the device.

Wireless Flash Updating DSI Peripherals C-11

This wireless flash update procedure uses a 22-COMM-D
communication adapter as the example device being flashed. When
flashing other DSI peripherals, screens associated with that device will
be different than those shown in this procedure.

1. Visit the following Allen-Bradley web site to obtain the appropriate
firmware update for the device:

http://www.ab.com/support/abdrives/webupdate/

At this web site, click on the device to access all of its firmware
updates. Then select Firmware Updates > Application Firmware

Update (or vx.xxx Flash Kit) > vx.xxx Flash Kit.

2. Click on the appropriate flash kit version to open the File Download

screen (Figure C.21

).

Figure C.21 File Download Screen

Click Open to launch the firmware installation tool. Then click
Next > to launch the ControlFLASH wizard to install the device’s

firmware update on the desktop or laptop computer. Follow the
instructions on the ControlFLASH wizard screens.

Important: In the last screen, the ControlFLASH Setup Complete

screen (Figure C.22

), uncheck both boxes and click

Finish.

Using DriveExecutive

C-12 Wireless Flash Updating DSI Peripherals

Figure C.22 ControlFLASH Setup Complete Screen

3. Establish wireless communication between the WIM and the desktop

or laptop computer. For this procedure, refer to Using

DriveExecutive on page C-11.

4. With the DriveExecutive linear list screen (Figure C.23) displayed,

right-click on the device to be flash updated (for this example, a
22-COMM-D communication adapter).

Figure C.23 DriveExecutive Linear List Screen

5. Select Properties… to display the device’s general information
screen. Then click the Component Details tab to show its related
screen (Figure C.24

).

Wireless Flash Updating DSI Peripherals C-13

Figure C.24 Component Details Tab Screen

6. In the Component Details tab screen, click the Flash Update button

to open the Select Device to Update screen (Figure C.25), which
shows the device’s firmware revision information.

Figure C.25 Select Device to Update Screen

Click on the device to be flashed (for this example, a 22-COMM-D
communication adapter), and then click Next > to continue. The
Select Flash Update screen (Figure C.26

) appears.

C-14 Wireless Flash Updating DSI Peripherals

Figure C.26 Select Flash Update Screen

7. Select the desired firmware version from the Available Flash
Updates list (for this example, 1.007.01 Full). Then click Next > to
continue. The Confirm Flash Update warning screen (Figure C.27

)

appears.

Figure C.27 Confirm Flash Update Warning Screen

8. Click FLASH to start the flash update. The Executing Flash Update
screen (Figure C.28) appears.

Wireless Flash Updating DSI Peripherals C-15

Figure C.28 Executing Flash Update Progress Screen

Note: Near the end of the flash update process, the WIM status
indicator changes from solid blue to flashing red, and then to
flashing green.

9. When the flash update is completed, the message window in the

Executing Flash Update screen changes to indicate that flash update
was completed (Figure C.29

).

Figure C.29 Executing Flash Update Completed Screen

Click Close to exit the Flash Update Completed screen. The Select
Device to Update screen (Figure C.25) reappears along with the
Windows in-process icon (typically, the hourglass icon). When
flashing a peripheral, wait for this icon to disappear (approximately
30 seconds). When flashing the WIM, the icon remains displayed
until after the wireless connection is re-established (Step 11).

C-16 Wireless Flash Updating DSI Peripherals

10. Power cycle the drive to initialize the device with the WIM.

11. Use the Bluetooth Manager to re-establish the wireless connection to

the device.

12. On the Select Device to Update screen, verify that the Revision
number shown now matches the firmware version flashed into the
device.

13. Click Cancel to close the Select Device to Update screen. Then click
Cancel again to close the device’s general information screen. The

DriveExecutive online window is now ready for use.

Appendix D

Using RTU Master Mode

Appendix D provides information about using the WIM in RTU Master
mode.

With the WIM in RTU Master mode, you can monitor, configure, and
control up to 32 PowerFlex 4-Class drives using Allen-Bradley drive
software tools.

Important: All PowerFlex 40 and PowerFlex 400 drives on an RTU

Master network must have an open internal Port 1. Thus, a
22-COMM-* adapter cannot be connected to this port via
the Internal Interface ribbon cable.

When a drive faults in an RTU Master network, all other drives remain
operational and unaffected.

Establish wireless communication between the WIM and the computer.
For this procedure, refer to the respective section in Chapter 3 that
corresponds to the drive software tool you are using:

• Using Pocket DriveExplorer for Pocket PC

on page 3-2

• Using DriveExplorer/DriveExplorer Lite on page 3-10

• Using DriveExecutive on page 3-16

Important: When using DriveExplorer to connect to drives on an RTU

Master network, use only DriveExplorer Full since
DriveExplorer Lite does not support multi-drive
connectivity.

Topic Page

Establishing Wireless Connection

D-1

Configuring the Drive Parameters D-2

Configuring the WIM for RTU Master Mode D-4

System Wiring D-6

Accessing the Drives on RTU Master Network D-8

TIP: A total of 247 drives can be supported on the RTU Master network
when RS-485 repeaters are installed.

Establishing Wireless Connection

D-2 Using RTU Master Mode

When setting drive parameters for the following functions to enable
operation on an RTU Master network, use each drive’s integral HIM or
use the WIM. When using the WIM, electrically connect the WIM to the
drive, establish wireless connection with the drive, and use a drive
software tool to set its parameters. Then electrically connect the WIM to
the next drive and repeat the process until the parameters in all of the
drives have been set.

Setting Comm Data Rates

For each drive to be networked (including Drive 1 connected to the
WIM), set drive parameter 103 - [Comm Data Rate] to “4” (19.2K).

Setting Drive Addresses

1. For Drive 1 connected to the WIM, set drive parameter 104 - [Comm
Node Addr] to match the WIM node address (default = 1) set with

Parameter 3 - [Drive Addr Cfg].

Important: When setting a WIM node address, do not use a value

higher than “77” octal (or 63 decimal when using
DriveExecutive).

2. For each remaining drive to be networked, set drive parameter 104 ­[Comm Node Addr] to a unique address.

Setting Comm Loss Action

For each drive to be networked (including Drive 1 connected to the
WIM), set drive parameter 105 - [Comm Loss Action] to either “1”
(Coast to Stop) or “2” (Stop).

Power Cycle All Drives

Power cycle each drive so that all new settings established in this section
will take effect.

Configuring the Drive Parameters

Using RTU Master Mode D-3

For your convenience, use the listing below to note the settings for each
drive to be networked.

Network
Drive
Number

Address Setting for
Parameter 104 - [Drive Addr Cfg]

Comm Fault Setting for
Parameter 105 - [Comm Loss Action]

1
2
3
4
5
6
7
8

9

10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32

D-4 Using RTU Master Mode

Using Pocket DriveExplorer for Pocket PC

1. On the drive StatusMonitor screen (Figure D.1), select Port > Port 1
to display the WIM StatusMonitor screen (Figure D.2).

2. Select Tasks > Parameter (Linear) to display the WIM parameter
list screen (Figure D.3). Then tap WIM Parameter 01 - [Adapter

Cfg] to display the Adapter Cfg parameter screen (Figure D.4).

3. Select RTU Master from the pull-down menu, and tap Apply to

confirm the change. Then tap OK (at top right of screen) to return to
the WIM parameter list screen.

Configuring the WIM for RTU Master Mode

Figure D.1 Port 1 Selection Screen Figure D.2 WIM StatusMonitor Screen

Figure D.3 WIM Parameter List

Screen

Figure D.4 Adapter Cfg Parameter

Screen

Using RTU Master Mode D-5

4. Remove power from the drive to which the wireless connection has

been made. Then electrically connect all drives to create the RTU
Master network. Refer to System Wiring

on page D-6 for network

wiring details.

Using DriveExplorer

1. On the DriveExplorer WIM Linear List screen (Figure D.5),
double-click WIM Parameter 01 - [Adapter Cfg] and set its value
to “3 = RTU Master.”

Figure D.5 DriveExplorer WIM Linear List Screen

2. Remove power from the drive to which the wireless connection has
been made. Then electrically connect all drives to create the RTU
Master network. Refer to System Wiring on page D-6 for network
wiring details.

Using DriveExecutive

1. In the Value column of the DriveExecutive WIM Linear List screen
(Figure D.6), click on the WIM Parameter 01 - [Adapter Cfg]
pull-down list and set its value to “3 = RTU Master.”

D-6 Using RTU Master Mode

Figure D.6 DriveExecutive WIM Linear List Screen

2. Remove power from the drive to which the wireless connection has

been made. Then electrically connect all drives to create the RTU
Master network. Refer to System Wiring

on page D-6 for network

wiring details.

When wiring an RTU Master network, refer to Figure D.7

. Connect the
first PowerFlex 4-Class drive (Drive 1) on the network to the WIM using
an AK-U0-RJ45-SC1 splitter cable. Connect its male end into Port 2 on
the bottom of the drive. The WIM must be connected to the Master port
(identified by the letter “M” at the port) of the splitter cable.

Important: Only one splitter cable can be used on the network, and it

must be used to connect the WIM to the first drive.

Using a 22-RJ45CBL-Cxx Communications Cable, or an appropriate
twisted pair cable and an AK-U0-RJ45-TB2P terminal block connector
(Figure D.8

), insert the connector into the splitter cable Slave port
(identified by the letter “S” at the port). Then insert the connector on the
cable’s other end into Port 2 on the bottom of the second drive (Drive 2).

For all subsequent PowerFlex 4-Class drives (up to 32 drives total on the
RTU Master network), daisy-chain them together using the same type of
cable and terminal block adapters connected into Port 2 on the bottom of
each respective drive.

System Wiring

Using RTU Master Mode D-7

Figure D.7 Wiring Example for RTU Master Network

The AK-U0-RJ45-TB2P two-position terminal block connector
(Figure D.8

) can be used to conveniently daisy-chain the PowerFlex
4-Class drives from Drive 1, which is connected to the WIM. Two
terminating resistors are also included with terminal block connectors in
the AK-U0-RJ45-TB2P kit.

Figure D.8 AK-U0-RJ45-TB2P Terminal Block Connector

Figure D.9 shows a wiring diagram for using the AK-U0-RJ45-TB2P

terminal block connectors.

Figure D.9 AK-U0-RJ45-TB2P Connector Wiring Diagram

Drive 1

(PowerFlex 4/40/400)

Drive 2 Drive 32

Up to 32 PowerFlex 4/40/400

Drives on RTU Master Network

AK-U0-RJ45-TB2P

Connector with

Terminating Resistor

AK-U0-RJ45-TB2P

Connector

RS-485

. . .

AK-U0-RJ45-SC1
Splitter Cable

AK-U0-RJ45-TB2P

Connector with

Terminating Resistor

HIM Bezel with

Installed WIM

Contains FCC ID: SNT-2XWIMNX
IC: 5450A-2XWIMNX

This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received,
including interference that may cause undesired operation

Pocket PC,

Laptop or

Desktop

Computer

Master Port Slave Port

To Slave Port on

Splitter Cable

(connected to Drive 1)

To Drive 2 To Drive 32

120

Ω

¼ Watt

Resistor

120

Ω

¼ Watt

Resistor

. . .

. . .

D-8 Using RTU Master Mode

Using one of the Allen-Bradley drive software tools enables you to
monitor, configure, and control any of the drives on the RTU Master
network. You can also monitor and configure the WIM.

Using Pocket DriveExplorer for Pocket PC

1. Re-establish wireless communication between the WIM and the

computer. Launch Pocket DriveExplorer for Pocket PC. The
ConnectionMgr screen (Figure D.10) appears. Select Connect >
New to display the New Connection Wizard screen (Figure D.11

).

2. Select the “Bluetooth” radio button and click Next -> to display the

“Where is your destination?” screen (Figure D.12

).

Figure D.12 “Where is your destination?” Screen

Accessing the Drives on RTU Master Network

Figure D.10 ConnectionMgr

Screen

Figure D.11 New Connection Wizard

Screen

Using RTU Master Mode D-9

3. Select the “Remote” radio button and click Next -> to display the

Bluetooth Browser screen (Figure D.13

).

Figure D.13 Bluetooth Browser Screen

4. Select the drive to which the WIM is connected (for this example,

PowerFlex 40 3P 460V 1.0HP), and click OK to display the Remote
Configuration screen (Figure D.14

). Enter a name (for this example,
“Drive 1”) for the drive. Then set its node address (for this example,
“1”) to match the node address set with drive parameter 104 ­[Comm Node Addr].

Figure D.14 Remote Configuration Screen

D-10 Using RTU Master Mode

5. Click Next -> to display the Connection Summary screen

(Figure D.15

) which shows information about this drive being

connected to the network. Then click Save and Connect Now to
display the “Location for saved connection” screen (Figure D.16).

6. Use the default name shown or enter a desired name (for this

example, Drive 1). Use the default directory shown or select a
different path to which the connection is saved on the Pocket PC.
Then click OK. The StatusMonitor screen for the drive appears.

7. Repeat Steps 1 through 6 for each remaining drive on the network.

8. After connections for all drives on the network have been created and

saved, you can now select any drive to access its information. With
any drive StatusMonitor screen (Figure D.17

) displayed, select

Connect > and then the desired drive file name (for this example,
Drive 2.dfc) to display its StatusMonitor screen (Figure D.18

). Then

select Tasks > Parameter (Linear) to access its parameter list.

Figure D.15 Connection Summary

Screen

Figure D.16 “Location for saved

connection” Screen

Figure D.17 Drive Selection

Screen

Figure D.18 Drive 2 StatusMonitor

Screen

Using RTU Master Mode D-11

Using DriveExplorer (Full Version Only)

1. Re-establish wireless communication between the WIM and the

computer. Launch DriveExplorer. The application window
(Figure D.19

) will appear.

Figure D.19 DriveExplorer Full Application Window

2. Select Explore > Connect > Serial to Network… to display the

Network Connection - Node Selection screen (Figure D.20).

Figure D.20 Network Connection - Node Selection Screen

3. Select the “Multiple” radio button. Then enter the node address for

the first network drive (for this example, “1”), and the node address
for the last network drive (for this example, “3”) to view all drives
simultaneously in the DriveExplorer online window. Click Connect
to display the DriveExplorer network menu tree (Figure D.21

).

TIP: If the network drive node address is valid, “Online” is shown next
to the selected address. If a node address is not valid, “Offline” will
appear.

D-12 Using RTU Master Mode

Figure D.21 DriveExplorer Network Menu Tree

4. Click on each node in the menu tree to create its database and

identity. Then expand each node to display the connected drive and
WIM representation (Figure D.22

).

Figure D.22 DriveExplorer Expanded Network Menu Tree

TIP: WIM representation appears for each drive in the menu tree even
though there is only one WIM on the network. To access the WIM
parameters, click any WIM shown in the menu tree.

Using RTU Master Mode D-13

Using DriveExecutive

1. Re-establish wireless communication between the WIM and the

computer. Launch DriveExecutive. In the application window, select
Drive > Connect to Drive… to display the Connect to Drive
window. Then expand the menu tree in the left pane to display either
the “Unrecognized Device” icons (which represent the drives) or the
“DSI” icons. The window should look similar to Figure D.23

.

Figure D.23 Connect to Drive Window

2. Select the drive to which you want to connect to (for this example,
the node address 01 drive) and click OK. DriveExecutive will upload
the drive information and display its online window (Figure D.24

).

TIP: If the drive information does not exist on the computer or is
different than existing information on the computer, DriveExecutive will
automatically create a database file for the drive before displaying its
online window.

D-14 Using RTU Master Mode

Figure D.24 Drive 1 Online Linear List Window

3. Repeat Steps 1 and 2 for each remaining drive on the network.

Figure D.25 shows online windows for each of the drives in this

example RTU Master network.

Figure D.25 Drives 1 - 3 Online Linear List Windows

Glossary

A Application Code

Code that runs in the WIM after the boot code calls it. It performs the
normal operations of the system.

B BCC (Block Check Character)

An error detection scheme where the 2’s complement of the 8-bit sum
(modulo-256 arithmetic sum) of all data bytes in a transmission block. It
provides a means of checking the accuracy of each message
transmission.

Bluetooth Wireless Technology

Bluetooth wireless technology enables cable-free connection of devices
that would normally be physically linked by wires, such as a drive
connected to a computer.

Boot Code

Code that runs when the WIM first receives power. It checks basic
operations and then calls the application code.

C ControlFLASH

ControlFLASH is an Allen-Bradley software tool that lets users
electronically update firmware on printed circuit boards. The tool takes
advantage of the growing use of flash memory (electronic erasable
chips) across industrial control products.

CRC (Cyclic Redundancy Check)

An error detection scheme where all of the characters in a message are
treated as a string of bits representing a binary number. This number is
divided by a predetermined binary number (a polynomial) and the
remainder is appended to the message as a CRC character. A similar
operation occurs at the receiving end to prove transmission integrity.

D DF1 Protocol

A peer-to-peer link layer protocol that combines features of ANSI
X3.28-1976 specification subcategories D1 (data transparency) and F1
(two-way simultaneous transmission with embedded responses).

G-2 Glossary

DSI (Drive Serial Interface)

DSI is based on the Modbus RTU serial communication protocol and is
used by various Allen-Bradley drives and power products, such as
PowerFlex 4, PowerFlex 40, PowerFlex 40P, and PowerFlex 400 drives.

DSI Peripheral

A device that provides an interface between DSI and a network or user.
Peripheral devices are also referred to as “adapters” or “modules.” The
WIM and PowerFlex 4-Class HIMs (22-HIM-xxx) are examples of DSI
peripherals.

DSI Product

A device that uses the DSI communications interface to communicate
with one or more peripheral devices. For example, a motor drive such as
a PowerFlex 4-Class drive is a DSI product. In this manual, a DSI
product is also referred to as “drive” or “host.”

DriveExplorer Software

DriveExplorer software is a tool for monitoring and configuring
Allen-Bradley products and adapters. It can be run on computers running
various Microsoft Windows operating systems. DriveExplorer (version

3.xx or higher) can be used to configure the WIM and PowerFlex drives.
Information about DriveExplorer and a free Lite version can be accessed
at http://www.ab.com/drives/driveexplorer

.

DriveTools SP Software

A software suite designed for running on various Microsoft Windows
operating systems. This software suite provides a family of tools,
including DriveExecutive, that you can use to program, monitor, control,
troubleshoot, and maintain Allen-Bradley products. DriveTools SP
(version 1.01 or higher) can be used with PowerFlex drives. Information
about DriveTools SP can be accessed at http://www.ab.com/drives/

drivetools.

E EDS (Electronic Data Sheet) Files

EDS files are simple text files that are used by network configuration
tools such as RSNetWorx for DeviceNet to describe products so that you
can easily commission them on a network. EDS files describe a product
device type, revision, and configurable parameters. EDS files for many
Allen-Bradley products can be found at http://www.ab.com/networks/

eds.

Glossary G-3

F Flash Update

The process of updating firmware in a device. The WIM can be flash
updated using the Allen-Bradley software tool ControlFLASH in
combination with an Allen-Bradley drive-configuration software tool,
such as Pocket DriveExplorer for Pocket PC, DriveExplorer or
DriveExecutive.

H HIM (Human Interface Module)

A device that can be used to configure and control a PowerFlex 4-Class
drive. PowerFlex 4-Class HIMs (22-HIM-xxx) can also be used to
configure connected peripherals such as the WIM.

Hold Last

When communications are disrupted (for example, a cable is
disconnected), the WIM and PowerFlex drive can respond by holding
last. Hold last results in the drive receiving the last data received via the
DF1 connection before the disruption. If the drive was running and using
the Reference from the converter, it will continue to run at the same
Reference.

N NVS (Non-Volatile Storage)

NVS is the permanent memory of a device. Devices such as the WIM
and drive store parameters and other information in NVS so that they are
not lost when the device loses power. NVS is sometimes called
“EEPROM.”

P PCCC (Programmable Controller Communications Commands)

PCCC is the protocol used by some controllers to communicate with
devices on a network. Some software products (for example,
DriveExplorer and DriveExecutive) also use PCCC to communicate.

Pocket DriveExplorer for Pocket PC Software

Pocket DriveExplorer for Pocket PC software is a Pocket PC tool for
monitoring and configuring Allen-Bradley products and adapters. It can
be run on a Pocket PC running Microsoft Windows Mobile 2003 (or
higher) operating system. Pocket DriveExplorer for Pocket PC (version

1.xx or higher) can be used to configure the WIM and PowerFlex drives.

Information about Pocket DriveExplorer for Pocket PC can be accessed
at http://www.ab.com/drives/driveexplorer

.

G-4 Glossary

PowerFlex 4-Class (Component-Class) Drives

The Allen-Bradley PowerFlex 4-Class family of AC drives includes the
PowerFlex 4, PowerFlex 40, PowerFlex 40P, and PowerFlex 400. These
drives can be used for applications ranging from 0.2 kW (0.25 HP) to 7.5
kW (10 HP).

S Status Indicator

A status indicator is an LED that is used to report the status of a device.
The WIM has one status indicator that emits blue, green, or red
indications.

W WIM (Wireless Interface Module)

The WIM provides a wireless communications interface between any
Allen-Bradley DSI drive and a computer or Pocket PC with an RS-232
port. The WIM uses a full-duplex RS-232 DF1 protocol. The WIM may
also be referred to as “22-WIM-N*,” “DSI peripheral,” or “module.”

Z Zero Data

When communications are disrupted (for example, a cable is
disconnected), the converter and drive can respond with zero data. Zero
data results in the drive receiving zero as values for Logic Command,
Reference, and Datalink data. If the drive was running and using the
Reference from the converter, it will stay running but at zero Reference.

Index

A

accessing parameters, 3-1

Adapter Cfg parameter, B-1

Adapter Type parameter, B-1

application code, G-1

assigning name for WIM (optional)

using DriveExecutive, 3-23

using DriveExplorer, 3-14

using Pocket DriveExplorer for

Pocket PC, 3-8

attentions, 1-4

B

BCC (Block Check Character), G-1

Bluetooth wireless technology, G-1

boot code, G-1

C

Clear DF1 Counts parameter, B-2

clearing DF1 data, 4-5

clearing events, 4-5

Comm Flt Action parameter, B-2

communications specifications, A-1

compatible products, 1-2

components, 1-1

configuration tools for parameters,

3-1

ControlFLASH, G-1

CRC (Cyclic Redundancy Check),

G-1

D

DF1 Packets Rcvd parameter, B-2

DF1 Packets Sent parameter, B-2

DF1 protocol, G-1

diagnostic items, 4-3

dimensions, A-1

Drive Addr Act parameter, B-2

Drive Addr Cfg parameter, B-1

DriveExecutive

using to establish wireless

connection, 3-16

web site, see DriveTools SP

DriveExplorer

definition, G-2

free Lite version, G-2

using to establish wireless

connection, 3-10

web site, G-2

drives, see DSI products

DriveTools SP

definition, G-2

web site, G-2

DSI

compatible products, 1-2

definition, G-2

peripheral definition, G-2

product definition, G-2

E

EDS (Electronic Data Sheet) Files

definition, G-2

web site, G-2

EEPROM, see Non-Volatile Storage

(NVS)

equipment

required, 1-3

supplied, 1-3

event queue

clearing events, 4-5

list of events, 4-4

viewing events, 4-4

Index-2

F

fault action, 3-24

fault queue, see event queue

firmware

parameters in, 3-1

release, P-3

flash update, G-3

flash updating DSI peripherals

wirelessly

using DriveExecutive, C-11

using DriveExplorer, C-6

using Pocket DriveExplorer for

Pocket PC, C-1

H

HIM (Human Interface Module), G-3

hold last

definition, G-3

setting, 3-24

I

installing the WIM

NEMA 1, 2-1

NEMA 4, 2-2

L

LED, see status indicator

M

manual

conventions, P-3

related documentation, P-1

web site, P-1

mechanical specifications, A-1

N

naming the WIM (optional)

using DriveExecutive, 3-23

using DriveExplorer, 3-14

using Pocket DriveExplorer for

Pocket PC, 3-8

Non-Volatile Storage (NVS), G-3

P

parameters

accessing, 3-1

configuration tools for, 3-1

convention, P-3

list of, B-1–B-2

numbers of, B-1

PCCC (Programmable Controller

Communications

Commands), G-3

Pocket DriveExplorer for Pocket PC

definition, G-3

using to establish wireless

connection, 3-2

web site, G-3

power consumption, A-1

power cycle, 3-26

PowerFlex drives, G-4

products, see DSI products

Q

quick start, 1-5

R

radio

frequency, A-1

power, A-1

range, A-1

transceiver, A-1

regulatory compliance, A-2

Index-3

related documentation, P-1

removing the WIM, 2-4

Reset Module parameter, B-2

resetting the WIM, 3-26

RSLinx, P-1

RTU Master mode, D-1

S

safety precautions, 1-4

Security Mode parameter, B-2

Security PIN parameter, B-2

specifications, A-1

status indicator

definition, G-4

locating, 1-6

troubleshooting with, 4-1

understanding, 4-1

T

technical support, P-2

tools, see equipment

troubleshooting, 4-1

U

update, see flash update

using RTU Master mode, D-1

V

viewing

DF1 data, 4-5

diagnostic items, 4-3

W

web site

DriveExecutive, G-2

DriveExplorer, G-2

DriveTools SP, G-2

Pocket DriveExplorer for Pocket

PC, G-3

technical manuals/

documentation, P-1

WIM

assigning a name (optional)

using DriveExecutive, 3-23

using DriveExplorer, 3-14

using Pocket DriveExplorer for

Pocket PC, 3-8

components, 1-1

configuration tools for parameters,

3-1

diagnostic items, 4-3

event queue, 4-4

features, 1-2

illustration, 1-1

installing, 2-1, 2-2

parameters, B-1–B-2

removing, 2-4

resetting, 3-26

wireless flash updating DSI

peripherals

using DriveExecutive, C-11

using DriveExplorer, C-6

using Pocket DriveExplorer for

Pocket PC, C-1

Z

zero data

definition, G-4

setting, 3-24

Index-4

Index-5

Index-6

www.rockwellautomation.com

A

mericas: Rockwell Automation, 1201 South Second Street, Milwaukee, WI 53204-2496 USA, Tel: [phone], Fax: [phone]

Europe/Middle East/Africa: Rockwell Automation, Vorstlaan/Boulevard du Souverain 36, 1170 Brussels, Belgium, Tel: [phone], Fax: [phone]

A

sia Pacific: Rockwell Automation, Level 14, Core F, Cyberport 3, 100 Cyberport Road, Hong Kong, Tel: [phone], Fax: [phone]

Power, Control and Information Solutions Headquarters

U.S. Allen-Bradley Drives Technical Support
Tel: [phone], Fax: [phone], Email: [e-mail], Online: www.ab.com/support/abdrives

Publication 22WIM-UM001C-EN-P – November, 2006 P/N 353372-P03

Supersedes 22WIM-UM001B-EN-P – July, 2005 Copyright © 2006 Rockwell Automation, Inc. All rights reserved. Printed in USA.
