RocketFish RF-WHD200 User Manual
4-Port WirelessHD Kit
RF-WHD200
User Guide
Rocketfish RF-WHD200
4-Port WirelessHD Kit
Contents
Safety information .......................................................... 3
Features............................................................................... 4
Setting up the HDWireless Kit..................................... 9
Using the WirelessHD Kit ............................................13
Specifications..................................................................19
Legal notices ...................................................................21
One year warranty.........................................................23
Introduction
Thank you for purchasing this high-quality Rocketfish system, which
represents the state of the art in 60 GHz wireless transceiver design,
and gives you complete freedom while enjoying your music or
movies without the limitations of cables.
The system has a maximum transmission range of up to 32.8 feet
(10 meters) line-of-sight (within the same room), and can be used
with your HDMI-compatible home theater components, gaming
systems, or computer. Please note that the 60 GHz frequency will not
penetrate walls, so this product is not to be used to transmit AV
signals from one room to another.
This User Guide explains how to correctly install, operate, and get the
best performance from your WirelessHD kit. Read this guide carefully
before installing your system, and save it for future reference.
2
Safety information
The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
Warni ng: To reduce the risk of fire or electric shock, do not expose the included
devices to rain or moisture.
Caution: To reduce the risk of electric shock, do not disassemble any component of the
kit. There are no user-serviceable parts inside. Refer servicing to qualified service
personnel.
• Read these instructions.
• Keep these instructions.
•Heed all warnings.
• Follow all instructions.
• Do not use the included devices near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong is provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement
of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
3RF-WHD200
• Only use attachments or accessories specified by the manufacturer.
• Unplug the included devices during lightning storms or when unused
for long periods of time.
• Refer all servicing to qualified service personnel. Servicing is required
when a component of the kit has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
• The included devices shall not be exposed to dripping or splashing and
no objects with liquids such as vases, shall be placed on the apparatus.
• The AC power adapter is used as the disconnect device. This disconnect
device shall remain readily operable.
• Read the rating labels on the bottom of the base station and wireless
speaker for power input and other safety information.
Features
Package contents
The box should contain:
• 60 GHz WirelessHD transmitter
• 60 GHz WirelessHD receiver
• Mounting bracket for receiver
•HDMI cables (2)
• AC power adapter (2)
•Remote control
•Quick Setup Guide
•User Guide
4
Transmitter front/top panel
Item Description
1 HDMI 4—When the indicator is on this HDMI port is in use.
2 HDMI 3—When the indicator is on this HDMI port is in use.
3 HDMI 2—When the indicator is on this HDMI port is in use.
4 HDMI 1—When the indicator is on this HDMI port is in use.
5
Power and link status indicator ( )
• Blinking—The power is on and the receiver is searching for the transmitter or is in sleep
mode.
• On—The transmitter and receiver are linked.
• Off—The power is off.
5RF-WHD200
Receiver front/top panel
Item Description
1
Power and link status indicator ( )
• Blinking—The power is on and the receiver is searching for the transmitter or is in sleep mode.
• On—The transmitter and receiver are linked.
•Off—The power is off.
Transmitter back panel
1
Item Description
1 DC IN jack—Connect the power adapter labeled “transmitter” to this jack.
2 Power switch—Turns the transmitter on or off.
3 HDMI/WVAN switch— A quick press (<1 second) toggles the HDMI switch input to select the next HDMI input.
A long press (>3 seconds) toggles WirelessHD output between one or more WirelessHD receivers in the same
room.
4-7 HDMI input—Connect up to four HDMI source devices to the HDMI inputs using high-speed HDMI cables.
6
Receiver back and side panels
Right side view
Item Description
1 HDMI jack—Connect this port to an HDMI input on the TV or projector, using a high-speed HDMI cable.
2 DC IN jack—Connect the power adapter labeled “Receiver” to this jack.
3 Power switch—Turns the receiver on or off.
4 Cable routing clips - Insert HDMI cable into these clips for receiver placement stability.
Left side viewBack view
7RF-WHD200
Remote control
Note: Remote control design subject to change.
Item Description
1 SLEEP button -Press to put the WirelessHD receiver and transmitter into sleep mode; or to "wake"
them up from sleep mode if they do not automatically do so on their own (this functionality varies by
brand and model of connected components). Be sure to point the remote toward each one separately.
2-5 HDMI 1-4 - Press to select the HDMI port for the signal source of your choice.
8
Note: Remove the plastic film from the remote control before using it for the first time.
Make sure you point the remote control at the WirelessHD transmitter.
Wireless HD Transceiver
Plastic film
HDMI 4HDMI 3
HDMI 1
HDMI 2
SLEEP
