Roberts Radio CD9949 User Manual

CD9949

Stereo CD Radio

Cassette Recorder with

ROBERTS

Sound for Generations

Symphony

Please read this manual before use

book mar

Contents .................................................................................... 1

Controls ..................................................................................... 2

Battery Operation...................................................................... 3

Mains Operation ........................................................................ 3

Operating the radio................................................................... 4

Presetting stations .................................................................... 5

Recalling a preset station ........................................................ 6

Inserting a CD ........................................................................... 7

Playing a CD ............................................................................. 7

CD bookmark ........................................................................... 8

Selecting a track ....................................................................... 9

Search function ......................................................................... 9

Repeat play ............................................................................... 9

Listening to cassette tapes .................................................... 10

Recording from the radio ....................................................... 11

Recording from CD ................................................................ 12

Recording from the internal microphone............................. 12

Recording from an external microphone ............................. 13

Preventing accidental erasure .............................................. 14

Cleaning tape heads.............................................................. 14

Headphones ............................................................................ 15

Specification............................................................................ 16

Circuit features ........................................................................ 16

Mains supply............................................................................ 17

Guarantee................................................................................ 18

CLASS 1

LASER PRODUCT

Warning

CLASS 1 LASER PRODUCT means that the laser's construction makes

it inherently safe so that the legally prescribed maximum permissible radiation values can never be exceeded

Caution: Using any equipment or devices other than those described

and specified in these operating instructions, or tampering with the unit in any way, can result in dangerous exposure to radiation.

Controls

5 4 3

1. Preset buttons

2. Internal microphone

3. External mic socket

4. Headphone socket

5. Function switch

6. Volume control

7. Tone control

8. FM mono/stereo switch

9. Mains socket

10. Telescopic aerial

11. Battery compartment

12. Tuning tone volume

13. Waveband switch

18192021222324

14. CD track up/down buttons

15. CD Play/Pause button

16. CD Stop button

17. CD repeat button

14 15

18. Tuning up/down buttons

19. Record key

20. Play key

21. Rewind key

22. Fast forward key

23. LCD display

24. Stop key

Battery operation

1. Remove the Battery cover on the rear of your CD radio cassette by pushing the catches in the direction shown.

2. Insert eight LR14 (C size) batteries into the compartment. Take care to ensure all batteries are inserted with the correct polarity as shown inside the battery compartment. Replace the battery cover.

3. Reduced power, distortion, and a ‘stuttering’ sound are all signs that the batteries may need replacing.

We would recommend for economy that your CD9949 is used on the mains whenever possible with battery operation for occasional or stand-by use only.

Mains operation

1. Place your CD radio cassette on a flat surface.

2. Plug the mains lead into the Socket located on the rear of your CD radio cassette. Ensure that the plug is pushed fully into the socket.

3. Plug the other end into a wall socket and switch on.

4. Do not allow this unit to be exposed to moisture (e.g. dripping or splashing). Do not leave your radio where excessive heat could cause damage such as in a parked car where the heat from the sun can build up even though the outside temperature may not seem too high.

Note: The unit remains connected to the mains even when it is switched off. The unit is only isolated from the mains if the mains plug is removed from the wall socket.

Operating the radio

1. Slide Function switch to the Radio position.

Radio

Off

Tape

2. Slide Waveband switch to select the required wave band . For the FM waveband fully extend the Telescopic aerial angle and rotate, if necessary, to obtain best reception.

3. Press and hold down either the Tuning up or Tuning down buttons for more than 0.5 sec to commence scan tuning. An audible tone will be heard indicating that the radio is tuning. The tone will increase in pitch for tuning up and decrease in pitch for tuning down.

4. Your radio will scan the selected waveband, sound a beep tone and stop automatically when it finds a station of sufficient strength.

5. To recommence scan tuning, press and hold down either the Tuning up or Tuning down buttons for more than 0.5 sec.

6. When the waveband end is reached the radio will beep and continue tuning from the opposite waveband end.

7. Adjust the Volume and Tone controls to the desired settings.

8. To switch off your radio slide the Function switch to the Off/Tape position.

Note: On FM if a station being received is weak some hiss may be audible. To reduce the hiss slide the FM Stereo/Mono switch (on rear) to the mono position. The stereo indicator will be removed from the display.

If you need any further advice, please call our Technical Helpline on :020 8758 0338 (Mon-Fri)

TUNING

Min

VOLUME

Max

Min

Tone

Max

Presetting stations

MHz

You may preset up to 15 different stations, 5 on FM, 5 on MW and 5 on LW.

1. Slide Function switch to the Radio position to switch on.

2. Slide Waveband switch to select the required wave band

3. Tune into a station as previously described on page 4.

4. Press and hold down the required Preset button until the radio beeps (greater than 2 seconds) The preset number will appear in the display and the station will be stored under the chosen preset button.

5. Repeat this procedure for the remaining presets.

6. Stations stored in preset memories may be overwritten by following the above procedure.

Radio

Off

Tape
