Ricoh VT1730 User Manual

PRIPORT VT1730
Operating Instructions
- Machine Exterior

Machine Exterior

MAJOR COMPONENTS

MAJOR COMPONENTS
TOP COVER
AI -=x\ \
/
TAPE DISPENSER (option)
This feeds out strips of paper which separate the printing groups on the paper delive~ table.
ADF UNIT
The Automatic Document
Feeder (ADF) feeds the
original to the printing
\
positiyn automati=lly.
this
15.
PAPER DELIVERY TABLE
Completed prints are delivered here. See page 17.
OPERATION PANEL
Operator controls and indicators are located here. See page 2.
MAJOR COMPONENTS
Operation Panel
= Keys -

Operation Panel

IMAGE MODE KEY
Press to select the Line mode or Photo mode in aocordanoe with the type and quality of the original. See page 35. \
SPEED KEY
Press to adjust the rotation speed of the machine in accordance with the type of image and printing paper. See page 27 and 28.
--
El
1
c
+
0(
4
0(
7
0(
/
IMAGE DENSITY
KEY
Press to make
prints darker or
lighter. See page 27.
/ \
/
AUTO CYCLE KEY
Use to automatically process masters and make prints. See page 30.
\
RESET KEY
Press to reset Press to shift the error indicators.
IMAGE POSITION KEY
image forwards or backwards on the print paper. See page 24.
Operation Panel
MAJOR COMPONENTS
MEMORY/CLASS KEY
Press to select group printing. See page 31 and 33. \
NUMBER KEYS
Press to enter the numb~r of prints.
\
STOP KEY
Press to stop the machine. The machine will continue printing when the Print Startkey is pressed. If you stop making a master, the “~+ A“ indicators will blink and the machine will not continue making the master when the Master Making key is
\ I
MASTER
~MAKING KEY
Press to make a master.
m
/
ENTER KEY
Press to input information into
the memory.
CLEAR KEY
Press to change Press to start printing.
the number that is set in the munter.
\
PROOF KEY
Press to make trial prints or extra prints.
PRINT START KEY

INSTALLATION REQUIREMENTS Machine Environment Environments To Avoid

INSTALLATION REQUIREMENTS

Machine Environment

The installation location should be carefully chosen because environmental conditions greatly affect the performance of the machine.
Optimum environmental conditions
ClTemperature: 10-30 ‘C, 50 -86‘F ClHumidity: 20-90 % RH IJ On a strong and level base (for example, a sturdy desk). ClThe machine must be level within 5 mm, 1/5” both front to rear and left to right.

Environments To Avoid

D Locations exposed to direct sunlight or strong light (more than 1,500 Iux). D Locations directly exposed to cool air from an air conditioner or to heat from a heater.
(Sudden temperature changes from low to high or vice versa may cause condensation
within the machine.) ~ Dusty areas. ClAreas with corrosive gases.

Power Connation Access To The Machine

INSTALLATION REQUIREMENTS

Power Connection

0 Securely connect the power cord to a dedimted 120V,60HZ power source which
supplies more than 2.4A.
IJ Make
sure the plug is firmly inserted into the outlet.
~ Avoid multiwiring. ClDo not pinch the
power cord.
D Make sure that the wall outlet is near the machine and easily accessible.
~ Voltage must not fluctuate more than 10
?40.
Access To The Machine
Place the machine near a power source, providing clearan= as shown below.
Paper Delivery
More than 60 cm, 23.7”
Table
‘More than
60 cm, 23.7”
&
A
>
More than 70 CM, 27.6”
I
5
.

SUPPLYING THE MASTER ROLL, INK, AND TAPE

.

SupplyingThe Master Roll

SUPPLYING THE MASTER ROLL, INK,
AND TAPE
Supplying The Master Roll
Caution:
Caution:
1. Insert both spools into a new master
2.
Caution: When you open or close the top
When you open the top cover, make sure that there are no originals on the top
cover.
If you drop something, such as a clip, inside the machine, remove it before continuing. If you cannot find what yOLJhave dropped or if you are unable to remove it from the machine, contact your service representative.
roll.
Open the top cover.
cover, be careful not to pinch your fingers between the top cover and
the back cover.
Caution: When you open or close the top
cover, or hands against the switch actuator of the top cover.
3. Position the new master roll as shown
in the illustration.
6
be careful not to hit yourhead
. .
Lift the pressure release Ieverin the
.,
4. direction of the arrow to release the
feed roller pressure.
Insert the leading edge of the master
5. roll under the feed roller.
Return the pressure release lever to its
6. original position.
Turn on the main switch.
7.
O The main switch is located at the left side
of the operation panel.
Press the master cut button to cut the
8. leading edge of the master roll.
Caution: When the master cut button is
pressed, the master roll will rotate.
Do not touch the master roll.
SUPPLYING THE MASTER ROLL, INK, AND TAPE
9.
Remove the cut-off portion of the master roll.
~ Removethecut-offmasterpaper
completelyto preventmastermisfeed.
If the masterisslackafterrotating,move
CJ
the pressurereleaseleverseveraltimes
to take upthe slack.
10. Close the top cover,
Supplying The Master Roll

Supplying Ink

1, Open the ink cover.
2. Press down the release lever (green tab [A]). The ink pack holder slides out
part way.
r=
3. Pull out the ink pack holder as shown.
Caution: Take your finger off the release lever
while puliing out the ink pack holder. You may be injured by the edge of
the ho/der.
Remove the cap of the new ink pack.
O Donotremove the seal from the spout of
the ink pack.
I
5. Install a ink pack as shown in the figure.
5. Slide in the ink pack holder.
6.
Press the
setting lever (green tab [B])
until it clicks.
IJ Ifthe setting lever is not pressed properly,
ink will not be supplied from the ink pack
to the machine.
7. Close the ink cover.
r
,
“ngTape For The Tape Dispenser (O@ion)
.,
Suppiyl
SUPPLYING THE MASTER ROLL, INK, AND TAPE

Supplying Tape For The Tape Dispenser (Option)

~ Make sure that the main switch is turned on
Open the cover of the tape dispenser.
1.
Put the roll in the dispenser.
2.
Feed the leading edge of the roll into
3*
the dispensing slot until it stops.
and the tape power switch is off.
Turn on the power switch of the tape
4. dispenser.
11
SUPPLYING THE MASTER ROLL, INK, AND TAPE
5. Press the manual cut button to trim off the leading edge of the tape.
Supplying Tape For The Tape D~penser (Option)
12

Cautions For Printing Paper

OPERATION

Cautions For Printing Paper
Only use printing paper that meets the following specifications:
Size: Max.: 216 mm x 356 mm, 8.5” x 14.0”
Min.: 90 mm x 140 mm, 3.5” x 5.5”
Weight: 70 g/rep -200 g/rep, 18.6 lb -53.2 lb
Print Area: 210 mm x 349.6 mm, 8.3” x 13.8” or less
Cautions:
IJ Avoid using the following kinds of paper:
OPERATION
Roughly-cutpaper
=
= paper of dmerent thicknesses in the same stack
= Buckledor curled paper
- Shortgrained paper
paperof low stiffness
e
= Dusty paper
IJ Correct curls in the paper before setting it in the machine. When ou cannot correct
the paper around the drum or stares may appear.
D Store paper where it will not curl or absorb moisture. Use paper smn after it is
unpacked.
ClAvoid using the top and bottom sheets of a new paper pack to prevent paper misfeeds
(multiple feeding).
ClWhen thick paper is used, the paper tends not to be delivered properly if it is curled
or if the printing speed is at the lowest setting.
~ Only use paper where the leading edge has two right angle comers, as shown below.
curl, stack the paper with the curl face down. Othemise t e paper may wrap
x
t
n
13
OPERATION

Cautions When UsingThe Document Feeder

Cautions When Using The Document Feeder
Only use originals that meet the following specifications:
Size:
Max.: 216 mm x 356 mm, 8.5” x 14.0” Min.: 90 mm x 140 mm, 3.5” x 5.5”
Weight: 64 g/mz -104.7 g/mz, 17.0 lb -27.9
lb
Cautions:
IJ Remove paper clips or staples from the originals. IJ If you use paste-up originals, make sure the pasted parts are adhered firml to the
base sheet. If the thickness of the paste-up original is more than 0.1 mm, 1250”, a
shadow may be printed on the paper. fJ Correct curled or bent originals to prevent misfeeds. ~ If you use curled orfolded originals, the image on the prints will be distorted, especially
for straight lines. The machine oannot correct curls or folds in originals. IJ If there is a large solid fill ima e on the leading edge of the ori inal, paper misfeeds
8 \tend to occur. In that case, shi the image position backward wit the Image Position
key (See page 24). ~ For the following types of originals, make a copy and use the copy as an original.
C3carbon mated originals = Bent or damaged originals
Y
= Originals with glue on them = Originals with binding holes
~ The first 5 mm, 1/5” of the leading ed e and the last 1 mm, 1/25” of the trailing ed e
3 !cannot be printed. Make sure the lea in edge margin is at least 5 mm, 1/5” and t e
trailing edge margin is at least 1 mm, 1/ 5“.
Original
*
8
5 mm
1/5”
1 mm, 1/25”
14

Preparation For Printing

.,
Preparation For Printing
ClWhen you load thick and small paper, see page 16.
Loading paper
Open the paper feed table carefully.
1.
Adjust the paper feed side plates to
2. match the paper size.
OPERATION
Press down the feed roller pressure
3.
lever.
15
OPERATION
.. ..
4. Place the paper on the paper feed table.
Make sure every sheet in the stack is set
~
evenly. This helpsprevent paperskewing.
CJ Make sure the leading edge of the staok
is infull contact with the front board.
0 500 sheets of paper can be loaded at a
time. If you load more than 500 sheets, paper may not be fed properly.
~ Do not stack paper over the paper feed
side plates.
5. Lift the feed roller pressure lever.
Caution: Be careful not to catch your finger
between the /ever and the side
paneL
Preparation For Printing
6. Make sure that the paper feed side plates contact the paper gently.
O The paper feed side plates should be
parallel to the sides of the paper stack, othenvise the paper might not be fed correctly.
Printing on thick and small paper
Set the side pads before adjusting the
paper feed side plates to match the paper size.
Thick and small paper:
Heavier than 150 g/mz, 39.9 lb Smaller than 210 x 150 mm,
X 5.9”
8.3”
r I
l-m- 11 LI
J
-
,L3 II
III
16
Preparation For Printing
Setting up the paper delivery table
Open the paper delivery table.
1.
Move the paper delivery end plate to
2. match the print paper size.
OPERATION
3. Move the paper delivery side plates to
match the print paper size.
17
OPERATION
Adjust the paper delivery rollers to
4. match the paper size,
Preparation For Printhq
D Ifyoupositionthepaperdeliveryrollerson
the printarea, each rollerwill make a line
onthe paper.
Cl You should leave marginsof more than
5 mm, 1/5”onthe rightand leftsidesofthe paper because the rollers track those areas.
O The paper delivery rollers may not feed
properly and a misfeed may occur if the printcontains a large solidfill image. In such cases, leave margins of approximately 10 mm, 2/5 on bothedges and movethe rollersfurtheraway fromthe edges.
Caution: Do not touch the paper delivery
rollers while the machine is operating, or the machine will be damaged.
lb
I
c
I
-&55iih
)+ II
