Ricoh FT 4422 Part Catalog



2)#/(&4

PARTS CATALOG

First Edition O ct ober 1995

2)#/(#/-0!.9,4$

PARTS CATALOG

INTRODUCTION

This chapter instructs you the numbers and names of parts on this machine.

INDEX to PARTS CATALOG

FT4422 (A173)
DF57 (A318)
CS110 (A490)

&4!

PARTS CATALOG

INTRODUCTION

This chapter instructs you the numbers and names of parts on this machine.

INDEX t o PARTS CATALOG

Location of Unit .................................................................. 3

1.EXTE RI O R (A173) ............... ...... ...... ...... ...... ...... ...... ...... .. 6

2.PLATE N C O VE R (A173) ...... ...... ...... ...... ...... ...... ...... ...... .. 8

3.OPTICS 1 (A173) ............................................................. 10

4.OPTICS 2 (A173) ............................................................. 12

5.OPTICS 3 (A173) ............................................................. 14

6.OPTICS 4 (A173) ............................................................. 16

7.BY-PASS FEED SECTION (A173) .................................. 18

8.PAPER TRAY (A173) ....................................................... 20

9.PAPER REGISTRATION 1 (A 173) .................................. 22

10.PAPER REGISTRATION 2 (A173) ................................. 24

11.PAPER FEED SECTION (A173) ..................................... 26

12.TONER HOPPER UNIT (A173) ...................................... 28

13.DEVELOPMEMNT UNIT (A173) ..................................... 30

14.CHARGE C OR O N A U NIT (A173) ............ ...... ...... ...... ..... 32

15.DRUM UNIT 8A173) ....................................................... 34

16.CLEANING U NI T (A173) ........... ...... ...... ...... ...... ...... ...... .. 36

17.TRANSFER UNIT (A173)................................................ 38

18.FUSI N G UN IT (A173) ........... ...... ...... ...... ...... ...... ...... ...... 40

19.PAPER EXIT SECTION (A 173) ........... ...... ...... ...... ...... ... 42

20.DRI VE SECTION ( A 173) ......... ...... ...... ...... ...... ...... ...... ... 44

21.ELECT RICAL SECTION 1 ( A 173) ................... ...... ...... ... 46

22.ELECT RICAL SECTION 2 ( A 173) ................... ...... ...... ... 48

23.FRAME S EC TI O N (A173) ........... ...... ...... ...... ...... ...... ...... 50

24.MAIN CONTROL BOARD (A173) ................................... 52

25.DECAL AND DDCUMENT (A173) ................ ...... ...... ...... 56

26.SPECIAL TOOLS (A173) ...... ...... ...... ...... ...... ...... ...... ...... 58

PARTS INDEX ..................................................................... 61

Octo ber, 31’95

Location of Unit

1. EXTE RI O R (A173)

4. OPTI C S 2 (A173)

See Page 6

2. PLATEN COVER (A173)

See Page 8

5. OPTICS 3 (A173)

3. OPTICS 1 (A173)

See Page 10

6. OPTI C S 4 (A173)

See Page 12

See Page 14

2

See Page 16

Location of Unit

7. BY-PASS FEED SECTION (A 173)

See Page 18

10. PAPER REGISTRATION 2 (A173)

8. PAPER TRAY (A173)

See Page 20

11. PAPER FEED SECTION (A173)

9. PAPER REGISTRATION 1 (A173)

See Page 22

12. TONER HOPPER UNIT (A173)

See Page 24

See Page 26

3

See Page 28

Location of Unit

13. DEVELOPMEMNT UNIT (A173)

See Page 30

16. CLEAN I N G UNI T ( A173)

14. CHA RG E CORO N A U NI T (A173)

See Page 32

17. TRANSFER UNIT (A 173)

15. DRUM UNIT 8A173)

See Page 34

18. FUSING UNI T (A173)

See Page 36

See Page 36

4

See Page 40

Location of Unit

19. PAPER EXIT SECTION (A173)

See Page 42

22. ELECTRICAL SECTION 2 ( A 173)

20. DRIVE SECTION ( A173)

See Page 44

23. FRAME SECTION (A173)

21. ELECTRICAL SECTION 1 ( A 173)

See Page 46

See Page 48

See Page 50

5

1. EXTERIOR (A173)

6

1. EXTERIOR (A173)

Index
No.

1 A128 1263 Left Cover (RIC) 1
1 A128 6362 Left Cover (NRG) 1
2 A173 4465 Copy Tray Slide (RIC) 1
2 A173 6406 Copy Tray Slide (NRG) 1
3 A048 4470 Copy Tray - Guide (RIC) 1
3 A048 6407 Copy Tray - Guide (NRG) 1
4 A173 4440 Copy Tray (RIC) 1
4 A173 6237 Copy Tray (NRG) 1
5 A128 1980 Exposure Glass 1
6 A173 1616 Scale (RIC) 1
6 A173 6241 Scale (NRG) 1
7 A173 1236 Upper Cover (RIC) 1
7 A173 6231 Upper Cover (NRG) 1
8 A110 1313 Rear Cover (RIC) 1
8 A110 6313 Rear Cover (NRG ) 1
9 A173 1277 Right Cover (RIC) 1
9 A173 6229 Right Cover (NRG) 1
10 A173 1320 Front Low er Cover 1
11 A173 1334 Front C over (RIC) 1
11 A173 6247 Front C over (NR G ) 1
12 A173 1233 Front D oor (RIC ) 1
12 A173 6201 Front D oor (NRG ) 1
13 A128 1845 Stepped Screw - M5 2
14 A173 1385 Oper at ion S heet 1
15 AG07 1008 Door Catch - Latch 1
16 A173 1235 Left Lower Cover (R IC) 1
16 A173 6227 Left Lower Cover (N R G) 1
17 A173 1397 Cap - Left Lower Cover (RIC) 2
17 A173 6376 Cap - Left Lower Cover (NRG ) 2
18 A110 5813 Left Operat ion Panel Bracket 1
19 A173 5812 Right Bracket - Operation Panel 1
20 A173 5651 Oper at ion P anel Ass’y (RIC) 1
20 A173 6292 Oper at ion P anel Ass’y (NRG) 1
21 A110 1381 Filter C over 1
22 A054 6330 Decal - Key-top Cover (NSA) 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

22 A054 6335 Decal - Key-top Cover (GES) 1
23 A128 6350 Model Name Plate - GER 1
23 A173 6365 Model Name Plate - NSA - A4 1
23 A173 6366 Model Name Plate - GES 1

101 0353 0060F Philips Truss Head Scr ew - M3x6
102 0443 0060W Hexagon Head Tapping Screw - M3x6
103 0413 0082W Tapping Screw - M3x8
104 0951 3006Z Philips Screw With Flat Washer - M3
105 0344 0060F Philips Truss Head Screw - M4x6

Part No.

Description

Q’ty Per
Assembly

7

2. PLATEN COVER (A173)

8

2. PLATEN COVER (A173)

Index
No.

1 A077 9523 Platen Cover Sheet - 10sheets/Set 1
2 A077 1357 Platen Cover Pad 1
3 A173 1855 Original Holder (RIC) 1
3 A173 6434 Original Holder (NRG) 1
4 5216 1374 Hinge Shaft - Platen Cover 2
5 A173 1770 Platen Cover Hinge (RIC) 1
5 A173 6358 Platen Cover Hinge (NRG) 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0720 0025E Retaining Ring - M2.5
102 0344 0100D P hil ips Truss Head Screw - M4x10
103 0951 3012W Philips Screw Wit h Fl at Washer-M3x1

Part No.

Description

Q’ty Per
Assembly

9

3. O PTICS 1 (A173)

10

3. O PTICS 1 (A173)

Index
No.

1 AC03 0019 2nd & 3rd Mirror 1
2 A128 1715 2nd Scanner Brcket 1
3 A006 1721 Front Spring Plate 4
4 AB03 2024 Pulley - Scanner Wire 2
5 A110 1724 Rear Spring Plate 4
6 A128 1729 2nd Mirror 1
7 A069 1883 Shoe - Scanner 3
8 AW02 0075 Photointerrupter 1
9 A173 1786 Sensor Bracket 1
10 A027 1705 Mirror Guide 1
11 A128 1817 Mirror Spring 1
12 A128 1815 5th Mirror 1
13 AC03 0026 Mirror - L224 1
14 A128 1761 Mirror Bracket 1
15 A048 1782 Mirror Shutter 1
16 A048 1764 Rack Gear - Mirror Drive 1
17 AB01 7129 Gear - 20z And 72z 1
18 AB01 0075 Gear - 48t 1
19 A173 1768 Motor Base 1
20 A173 5219 Mirror Drive Motor 1
21 AG07 0004 Magnetic Catch 1
22 A128 1816 6th Mirror 1
23 A128 1793 6th Mirror Bracket 1
24 A006 1722 Spring Plate 2
25 A048 1801 Mirror Seal 1
26 A128 1797 Front 6th Mirror Bracket 1
27 A075 1766 Adjusting Cam 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0720 0050E R et aini ng Ri ng - M5
102 0951 4008W Philips Screw With Flat Washer-M4x8
103 0313 0140W Philips Pan Head Screw - M3x14
104 0413 0082W Tapping Screw - M3x8
105 0443 0060W Hexagon Head Tapping Screw - M3x6
106 0353 0060F Philips Truss Head Scr ew - M3x6
107 0720 0040E R et aini ng Ri ng - M4
108 0805 0077 Retaining R i ng - M3

Part No.

Description

Q’ty Per
Assembly

11

4. O PTICS 2 (A173)

12

4. O PTICS 2 (A173)

Index
No.

1 A173 1753 Shielding Seal 1
2 A128 1754 Shielding Plate 1
3 A173 1750 Lens Bracket 1
4 AA15 0074 Seal - 12x272 1
5 A173 1752 Shielding Sheet 1
6 AC02 0082 Lens - F8/180 1
7 AA05 0046 Lens Drive Wire 1
8 A048 1755 Lens Shutter 1
9 5215 1812 Lens Drive Pulley 1
10 A128 1757 Lens Motor Bracket 1
11 A173 5221 Lens Drive Motor 1
12 AW02 0075 Photointerrupter 1
13 A173 1784 Lens Sensor Bracket 1
14 A069 1772 Guide Plate 1
15 A048 1789 Lens Cover 1
16 5215 1806 Pulley 1
17 AA14 3264 Pulley Shaft 1
18 A173 1771 ADS Cover 1
19 A173 5120 Optical Control Board 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0413 0082W Tapping Screw - M3x8
102 0951 3006W Philips Screw With Flat Washer-M3x6
103 0951 3008W Philips Screw With Flat Washer-M3x8
104 0951 4008W Philips Screw With Flat Washer-M4x8
105 0443 0060W Hexagon Head Tapping Screw - M3x6
106 0720 0040E R et aini ng Ri ng - M4
107 0413 0060W Tappi ng Scr ew - M3x6

Part No.

Description

Q’ty Per
Assembly

13

5. O PTICS 3 (A173)

14

5. O PTICS 3 (A173)

Index
No.

1 A075 1870 Scanner Motor Pulley 1
2 A173 1660 Scanner Motor Bracket 1
3 AA08 2029 Bushing - 6x13x5 2
4 A077 5231 Scanne Drive Motor - DC30V 60W 1
5 A048 1737 Front Wire Pulley 2
6 A173 1733 Rear Left Pulley 1
7 AA05 0044 Scanner Drive Wire - 1458mm 1
8 A006 1744 Wire Support Plate 2
9 A128 1818 Tension Spring 2
10 A048 1721 Spring Plate A 2
11 A173 1731 Front Right Pulley 1
12 A006 1745 Wire Adjusting Pl ate 1
13 AA05 0045 Scanner Drive Wire - 1011mm 1
14 A128 1728 1st Mirror 1
15 A110 1705 1st Mirror Support Plate 1
16 A173 5917 Exposure Lamp - 181V 310W 1
16 A173 5916 Exposure Lamp - 181V 310W 1
17 A110 1861 Reflector 1
18 A085 1670 Exposure Adjusting Plate 4
19 A128 5876 Clamp 1
20 A096 1873 Scanner Shoe Pin 4
21 A006 1707 Rear Wire Clamp 1
22 A085 1668 Terminal Supporter 2
23 A085 1672 Front Lamp Terminal 2
24 A110 1669 Lam p Hol der Spring 2
25 A173 5403 Clamp 2
26 A173 5282 Exposure Lamp Harness 1
27 A048 1721 Spring Plate A 2
28 A069 1883 Shoe - Scanner 4
29 A006 1708 Front Wire Clamp 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0720 0050E R et aini ng Ri ng - M5
102 0807 4127 Wave Washer
103 0951 3008W Philips Screw With Flat Washer-M3x8
104 0443 0060W Hexagon Head Tapping Screw - M3x6
105 0951 4008W Philips Screw With Flat Washer-M4x8
106 0313 0120W Philips Pan Head Screw - M3x12
107 0951 3012W Philips Screw With Flat Washer-M3x1
108 0951 3006W Philips Screw With Fl at Washer-M3x6

Part No.

Description

Q’ty Per
Assembly

15

6. O PTICS 4 (A173)

16

6. O PTICS 4 (A173)

Index
No.

1 A173 1776 Scale Bracket 1
2 A128 5872 Wire Sadle 1
3 A128 1713 Upper Seal 2
4 A110 1829 Front Side Plate 1
5 A173 5402 Clip 2
6 A173 1788 Sensor Bracket 1
7 AW02 0075 Photointerrupter 1
8 A128 1842 Right Stay - Exposure Gl ass 1
9 A128 1713 Upper Seal 1
10 A128 1835 Platen Cover Left Bracket 1
11 A128 5876 Clamp 4
12 A128 5875 Clamp 3
13 A128 1834 Platen Cover Right Bracket 1
14 A110 1817 Scanner Slide Rail 2
15 A128 1719 Fan Motor Bracket 1
16 A173 5400 Fan Motor - 24V 1
17 A128 1823 Optics Right Stay 1
18 A048 1839 Left Guide Bracket 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0413 0060W Tapping Screw - M3x6
102 0443 0060W Hexagon Head Tapping Screw - M3x6
103 0960 3030W Philips Flange Scr ew M3 X 30

Part No.

Description

Q’ty Per
Assembly

17

7. BY-PAS S FE ED S EC TION (A173)

18

7. BY-PAS S FE ED S EC TION (A173)

Index
No.

1 A173 2852 By-pass Feed Unit 1
2 A173 2856 Rear Side Fence (RIC) 1
2 A173 6356 Rear Side Fence (NRG) 1
3 A128 2681 Front Side Fence (RIC) 1
3 A128 6351 Front Side Fence (NRG ) 1
4 A173 2874 Spring Plate 1
5 A173 2876 By-Pass Feed Bottom Guide (RIC) 1
5 A173 6354 By-Pass Feed Bottom Guide (NRG) 1
6 A173 2871 By-Pass Feed Guide 1
7 A173 2946 By-Pass Feed Table (RIC) 1
7 A173 6346 By-Pass Feed Table (NRG) 1
8 A048 2928 Cam - Manual Feed Table 1
9 A128 2698 Side Fence Gear 2
10 A128 2775 Gear 1
11 A006 2699 Spacer - 5.1x20mm 1
12 A048 2938 Paper Guide - Manual Feed Table (RIC) 1
12 A048 6356 Paper Guide - Manual Feed Table (NRG ) 1
13 A128 2945 Cover - Manual Feed Table - RIC 1
14 A048 2951 Front Guide Hol der 2
15 AA14 3288 Stepped Screw 1
16 AW50 0012 Push Switch 1
17 A128 2956 Small Cassett e Cover (R IC) 1
17 A128 6058 Small Cassett e Cover (N R G) 1
18 A128 2716 Front Side Fence 1
19 A128 2727 Rear Side Fence 1
20 AA00 2010 Decal - Paper Level 1
21 A173 2911 Bottom Plate 1
22 A128 2713 Bottom Plate Pad 1
23 A128 2964 Actuator - A4 1
23 A128 2962 Actuator - A4R 1
23 A173 2798 Actuator - B5R 1
24 A128 2743 Rear Fence 1
25 A173 2791 Small Cassett e (RIC ) 1
25 A173 6364 Small Cassett e (NRG ) 1
26 AA00 2009 Decal - A4 (RIC) 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

26 AA00 2008 Decal - A4R (RIC) 1
26 AA00 2026 Decal - B5 1
26 A048 6285 Decal - A4 (NR G ) 1
26 A048 6286 Decal - A4R (NRG) 1

101 0443 0060W Hexagon Head Tapping Screw - M3x6
102 0344 0060F Philips Truss Head Scr ew - M4x6
103 0413 0062W Tapping Screw - M3x6
104 0805 0073 Retaining Ring - M5
105 0965 4010W Tapping Screw With Flatw asher - M4x10
106 0414 0082F Philips Truss Head Screw - M4x8

Part No.

Description

Q’ty Per
Assembly

19

8. PAPER T RAY (A 173)

20

8. PAPER T RAY (A 173)

Index
No.

1 AF01 1030 Bottom Plate - Papper Tray 1
2 AF01 3001 Bottom Plate Pad 2
3 A173 2843 Decal - Paper Feed (RIC ) 1
3 A173 2848 Decal - Paper Feed (RIC - TWN) 1
3 A173 6387 Decal - Paper Feed (NRG ) 1
4 A110 2833 Leaf Spring - End Fence 1
5 A110 2832 End Fence - Paper Tray 1
6 AF01 6068 Front S ide Fence - Paper Tray 1
7 A048 2817 Side Fence Stopper 1
8 AA06 3081 Spring - Side Fence Stopper 1
9 A110 2870 Front Corner Separator 1
10 A110 2789 Rear Side Fence - Paper Tray 1
11 AA00 1172 Decal - Paper Volume 1
12 AA14 3288 Stepped Screw 2
13 A110 2871 Rear Coner Separator 1
14 A110 2877 Corner Separator Seal 2
15 A110 2843 Registration Adjustment Plate 1
16 A048 2835 Side Fence Gear 2
17 AB01 3492 Gear - 16z 1
18 AA06 3497 Pressure Spring 2
19 A173 2811 Paper Tray Cover (RI C) 1
19 A173 6312 Paper Tray Cover (NR G) 1
20 AA06 3205 Spring 1
21 A077 2822 Pl at e Rel ease Slider 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0414 0102F Tapping Screw - M4x10
102 0413 0082F Bind Tapping Screw - M3x8
103 0965 3008W Tapping Screw With Flat Washer-M3x8
104 0805 0073 Retaining Ring - M5
105 0720 0030E Retaini ng R ing - M3

Part No.

Description

Q’ty Per
Assembly

21

9. PAPER R EGISTRATION 1 ( A 173)

22

9. PAPER R EGISTRATION 1 ( A 173)

Index
No.

1 A173 2745 Upper Paper Feed Guide 1
2 5215 2621 Snap Ring - M6 1
3 A173 2777 Paper Feed Roller 1
4 5215 2620 Feed Roller 1
5 5215 2618 Feed Roller Hub 1
6 5215 2622 Upper Feed Shaft Bracket 1
7 5053 0223 Bushing - 8mm 2
8 A173 2774 1st Paper Feed Shaft 1
9 A173 2741 Paper End Actuator 1
10 5215 2600 Upper Feed Guide Plate 1
11 A173 2746 By-Pass Feed Guide 1
12 A173 2753 Release Shaft 1
13 A173 2758 Rear Release Arm 1
14 5205 3103 Bushing - 6mm 2
15 A173 2756 Shaft Bracket 2
16 A173 2725 Sensor Actuattor 1
17 A173 2718 Bottom Plate Spr ing 1
18 A173 2737 Rear Cassette Holder (RI C) 1
18 A173 6340 Rear Cassette Holder (NRG ) 1
19 A024 2653 Upper Lift Arm 1
20 A173 2735 1st Entrance Guide 1
21 A173 2734 Upper Bracket - Paper Feed 1
22 A173 2761 Paper Size Sensor Bracket 1
23 AW50 0010 Push Switch 1
24 A069 2820 Friction Pad Ass’y 1
25 A173 2720 Release Spring 1
26 A173 2740 Pressure Spring 1
27 A173 2715 Pad Lever 1
28 A173 2743 Friction Pad Bracket 1
29 A173 2771 Spacer 1
30 AA14 3064 Philips Pan Head Screw - M3x10 1
31 A173 2716 Release Lever Spring 1
32 A173 2714 Release Lever 1
33 A173 2713 Release Shaft 1
34 A173 2736 Front Cassette Holder (RI C ) 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

34 A173 6339 Front C assette Holder (NRG) 1
35 A128 5876 Clamp 1
36 5443 2668 Bushing - 4x6x7mm 1
37 A173 5257 Right Harness 1
38 A173 2757 Front R elease A rm 1

101 0434 0060W Tapping Screw - M4x6
102 0443 0060W Hexagon Head Tapping Screw - M3x6
103 0720 0060E R et aini ng Ri ng - M6
104 0720 0030E R et aini ng Ri ng - M3
105 0720 0025E R et aini ng Ri ng - M2.5
106 0323 0060W Philips Sunken Head Screw - M3x6
107 0413 0082W Tapping Screw - M3x8
108 0434 0080W Tappi ng Scr ew - M4x8

Part No.

Description

Q’ty Per
Assembly

23

10. PAPER R EGISTRATIO N 2 (A173)

24

10. PAPER R EGISTRATIO N 2 (A173)

Index
No.

1 A173 3025 Development Rail 1
2 AF02 1039 Upper Registration Roller 1
3 A048 2573 Registration Lower Guide 1
4 AW02 0024 Photointerruptor 1
5 5215 2600 Upper Feed Guide Plate 1
6 A128 2658 Pressure Spring 1
7 A173 2668 Seal - 9.5x75 1
8 A173 2662 Middle Guide Pl ate - Registration 1
9 A048 3913 Upper Transfer Guide 1
10 A173 2611 Lower Registration R oll er 1
11 AA06 0254 Spring - Upper Transfer G uide 1
12 A128 2751 Registration Roller Knob 1
13 A048 3898 Lower Transfer Guide 1
14 AA08 0094 Front Registr at ion Roller Bushing 2
15 A128 2663 Front Spring - Registration Roller 2
16 A128 2768 Stepped Screw - M3x5 2
17 5053 0223 Bushing - 8mm 2
18 A128 5876 Clamp 1
19 AG05 1071 Knob - Regi str at ion Guide P lat e 1
20 AA02 0001 Drawer Tray Magnet 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0443 0060W Hexagon Head Tapping Screw - M3x6
102 0951 4006W Philips Screw With Flat Washer-M4x6
103 0720 0060E R et aini ng Ri ng - M6
104 0705 0050Z Toothed Washer - M5
105 0720 0040E R et aini ng Ri ng - M4
106 0313 0040W Philips Pan Head Screw - M3x4
107 0131 0300E Philips Pan Head Screw - M3x30

Part No.

Description

Q’ty Per
Assembly

25

11. PAPER FEED SECTION (A173)

26

11. PAPER FEED SECTION (A173)

Index
No.

1 AB01 1067 Gear - 100z 1
2 AB01 3428 Gear - 35z 1
3 A173 1124 Development Drive Shaft 1
5 A157 2772 Paper Stripper Shaft 1
6 A157 2773 Feed Roller Holder 1
7 A173 1155 Paper End Actuator 1
8 A173 2623 2nd Drive Roller 1
9 A173 2725 Sensor Actuattor 1
10 A173 2633 Clutch Stopper 1
11 AW50 0012 Push Switch 1
12 A173 2816 Paper Sensor Bracket 1
13 A048 2861 Paper End Sensor Bracket 1
14 AW02 0075 Photointerrupter 1
15 A173 1195 Release Spring 1
16 A048 2862 Paper End Sensor Bracket 1
17 5053 0223 Bushing - 8mm 2
18 A173 5055 Magnetic Clutch 1
19 5447 2681 Snap Ring 1
20 A173 2632 I dle Gear - 28/14Z 1
21 A173 2622 Clutch Stopper Bracket 1
22 A173 2919 Bushing - 8mm 1
23 A173 2607 Paper Drive Shaft 1
24 A173 2635 Idle Gear 1
25 AA14 5209 Shaft - Drive Gear 1
26 AB01 3421 Gear - 18z 1
27 A173 2621 Feed Roller Bushing 1
28 A157 2774 Feed Roller 2
29 AF03 1027 Paper Feed Roller 2

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0720 0060E R et aini ng Ri ng - M6
102 0720 0025E R et aini ng Ri ng - M2.5
103 0720 0030E R et aini ng Ri ng - M3
104 0443 0060W Hexagon Head Tapping Screw - M3x6
105 0443 0080W Hexagon Head Tapping Screw - M3x8
106 0805 3386 Bushing - 8mm
107 0413 0082B Tapping Screw - M3x8

Part No.

Description

Q’ty Per
Assembly

27

12. TONER HOPPER UNIT (A173)

28

12. TONER HOPPER UNIT (A173)

Index
No.

1 A152 7662 Joint 1
2 A110 3336 Agitator Lever 1
3 AB01 3442 Gear - Toner Supply 1
4 AB01 3443 Gear - Idler - Toner Supply 1
5 AB01 3444 Gear - Agitat or 1
6 5215 3295 Hopper Filter 1
7 AA15 1481 Shield - Toner Hopper - Rear Upper 1
8 AA15 1606 Seal -44x14x3 1
9 AA15 1480 Shield - Toner Hopper - Front U pper 1
10 A048 7670 Slitter 1
11 A110 3340 Plate Nut 1
12 AA15 1482 Shield - Toner Hopper - Upper 1
13 AA15 0197 Shield - Toner Hopper - Right 1
14 AA15 0198 Shield - Toner Hopper - Lower 1
15 AA15 1485 Shield - Rear Upper - Toner Hopper 1
16 A173 3403 Auger Shaft 1
17 AA15 1476 Sponge - Toner Supply 1
18 AA15 1489 Seal - 2x5x37.5 1
19 A128 3014 Tonner Supply Roller 1
20 A048 7669 Plate - Toner Supply Roller 1
21 AA15 0331 Seal - Toner Supply Unit 1
22 AA15 1483 Shield - Toner Hopper - Lower 1
23 A048 7654 Lower Casing - Toner Supply Unit 1
24 AA15 1487 Shield - Rear Lower - Toner Hopper 1
25 AA15 1486 Shield - Front Lower - Toner Hopper 1
26 5215 3303 Seal - Toner Supply Roller 2
27 AA15 1479 Shield - Case - Toner Hopper - Rear 1
28 AA15 0196 Shield - Toner Hopper - Left 1
29 AA06 0267 Spring - Toner End A dt uator Lever 1
30 AA15 1484 Shield - Front Upper - Toner Hopper 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0728 0040E G rip Ri ng - 4mm
102 0720 0030E R et aini ng Ri ng - M3
103 0805 0077 Retaining Ring - M3
104 0413 0082W Tapping Screw - M3x8
105 0951 3006W Philips Screw With Fl at Washer-M3x6

Part No.

Description

Q’ty Per
Assembly

29

13. DEVEL OPMEM NT UNIT (A173)

30

13. DEVEL OPMEM NT UNIT (A173)

Index
No.

1 AD03 1266 Development Roller 1
2 AD03 6021 Mixing Vanes 1
3 AA15 2231 Development Filter 1
4 AA15 1604 Seal - 16x9x3 1
5 A048 7600 Case - Upper - Development 1
6 A048 7631 Retainer - Ball Bearing 1
7 AB01 3437 Gear - 19t 1
8 AB01 3439 Gear - 23z 1
9 AD03 7023 Mixing Auger 1
10 A173 3402 Paddle Roller 1
11 AA15 1186 Front Side Plate Seal 1
12 5205 3103 Bushing - 6mm 1
13 A173 3401 Mixing Auger 1
14 AB01 3858 Gear - 15z 1
15 AA15 2136 Shield - Development Roller 1
16 AA15 1605 Seal - 323x4x3 1
17 A128 3310 Lower Casing 1
18 AB01 3440 Gear - Roller - Agitate,Mix 1
19 A048 7612 Development Roller Knob 1
20 AB01 3441 Gear - 20z 1
21 A048 7632 Cover - Gear 1
22 5205 3103 Bushing - 6mm 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0720 0040E R et aini ng Ri ng - M4
102 0414 0102F Tapping Screw - M4x10
103 0951 3008W Philips Screw With Flat Washer-M3x8
104 0313 0050W Philips Pan Head Screw - M3x5
105 0727 0090E R et aini ng Ri ng C - M9
106 0805 3415 Ball Bearing - 9x20x6
107 0434 0060W Tapping Screw - M4x6
108 0805 0073 Retaining R i ng - M5

Part No.

Description

Q’ty Per
Assembly

31

14. CHARGE CORO NA UNIT (A173)

32

14. CHARGE CORO NA UNIT (A173)

Index
No.

1 A006 2055 Charge Corona Cleaner 1
2 A048 2008 Charge Corona Unit 1
3 A006 2117 Front Cover - Charge Corona 1
4 A006 2114 Grid Anchor 1
5 AD02 3059 Left Main Corona Unit Casing 1
6 A006 2118 Rear Cover - Charge Corona 1
7 5442 2108 Corona Wire Spring 1
8 A048 9001 Charge Corona Wire - 10pcs/Set 1
9 A006 2111 Charge Corona Grid 1
10 A030 6231 Corona Wire Ring 1
11 AA06 0141 Spring - Charge Corona Gri d 2
12 A048 2091 Front End Block 1
13 5442 2069 Plastic Screw - Main Corona 1
14 AD02 3060 Right Main Corona Unit Casing 1
15 AA06 0255 Spring - Rear Charge Corona Gri d 2
16 A006 2118 Rear Cover - Charge Corona 1
17 5442 2110 Plug - Corona Unit 1
18 A006 2123 Cleaner Stay 1
19 A006 2122 Cleaner Stopper 1
20 A008 2087 Corona Cleaner Pad 2
21 A006 2121 Cleaner Holder 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0413 0082W Tapping Screw - M3x8
102 0413 0062W Tapping Screw - M3x6
103 0951 4006W Philips Screw With Flat Washer-M4x6
104 0971 3006a Philips Pol ycarbonate Screw - M3x6

Part No.

Description

Q’ty Per
Assembly

33

15. DRUM UNIT 8A173)

34

15. DRUM UNIT 8A173)

Index
No.

1 A128 2271 Left Drum Stay 1
2 A128 2275 Front Transport Guide 1
3 A048 2276 Ring - Transport Bracket 1
4 A075 2258 Pick-Up Pawl Shaft 2
5 A048 2273 Pick-Off Pawl Bracket 1
6 AA06 3106 Spring - Pick-Up Pawl 2
7 A006 2270 Pick-Off Pawl 2
8 A128 2278 Sensor Holder 1
9 A128 5222 Id Sensor Board 1
10 A075 2268 Upper Left Drum Stay 1
11 A128 2281 Rear Drum Side Plate 1
12 A075 2269 Right Drum Stay 1
13 A069 9510 Drum 1
14 A128 2262 Drum Support Plate 1
15 A128 2258 Drum Holder 1
16 A173 2103 Stepped Screw 1
17 A173 2101 Bushing - 8x22x7 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0413 0060W Tapping Screw - M3x6
102 0313 0040W Philips Pan Head Screw - M3x4
103 0314 0100W Philips Pan Head Screw - M4x10
104 0314 0200B Philips Pan Head Screw - M4x20
106 0805 3104 Bushing - 8x22x7
107 0951 3004B Philps Screw Wit h Fl at Washer -M3x4

Part No.

Description

Q’ty Per
Assembly

35

16. CL EANING UN IT (A173)

36

16. CL EANING UN IT (A173)

Index
No.

1 A128 3558 Upper Cleaning Case 1
2 AA00 0059 Caution Decal - Engl ish 1
3 A005 3585 Sensor Feeler - Toner Over Flow 1
4 A005 3587 Feeler Supporter 1
5 A005 3586 Rubber Seal - Toner Collection 1
6 A006 3584 Toner Collection Hosing 1
7 A128 3581 Front Case Cleaning 1
8 A128 3569 Pressuer Seal 1
9 A128 3582 Upper Lower Seal 1
10 A128 3568 Pressure Spring 2
11 A128 3583 Front Seal-C leaning 1
12 A128 3589 Rear Seal-Cleaning 1
13 A128 3572 Cleaning Lower Seal 2
14 A006 3589 Cleaning Entrance Seal 1
15 A128 3588 Shield - Drum 2
16 A128 3591 Seal - 5x5 2
17 AB01 7160 Gear - 17z And 35z 1
18 AB01 1084 Gear - 17z 1
19 AA08 0030 Bushing - 5x13x7 2
20 A128 3715 Lens Fixing Pin 1
21 A128 3580 Toner Collection Shaft 1
22 AA15 1109 Seal - 5x16x5 2
23 A128 3590 Seal - 9.5 2
24 5446 3648 Stepped Screw - M4 1
25 A128 3571 Blade Holder 1
26 A128 3552 Cleaning Blade 1
27 A128 3578 Rear Holder S eal 1
28 A128 3573 Front Holder S eal 1
29 A128 3563 Blade Release Lever 1
30 A173 3185 Lower Cleaning Case 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0951 3008B Philips Screw With Flat Washer-M3x8
102 0413 0062W Tapping Screw - M3x6
103 0313 0060W Philips Pan Head Screw - M3x6
104 0720 0040E Retaining Ring - M4
105 0951 3006W Philips Screw With Flat Washer-M3x6
106 0413 0082W Tapping Screw - M3x8
107 0951 3004B Philps Screw Wit h Fl at Washer -M3x4

Part No.

Description

Q’ty Per
Assembly

37

17. TRANSFER UNIT (A173)

38

17. TRANSFER UNIT (A173)

Index
No.

1 A048 3881 T&S Corona Guide 1
2 A048 3883 Cover - T/S Corona - Front 1
3 5442 2108 Corona Wire Spring 2
4 A048 9003 Separation Corona Wire - 10pcs/Set 1
5 A048 9002 Transfer Corona Wi r e - 10pcs/Set 1
6 A173 3082 Guide Plate 1
7 A173 3081 T/S Corona Unit Casing 1
8 AD02 2180 Rear End B lock - T&S C or ona 1
9 AA06 3036 Terminal Spring 2
10 A048 3887 Cover - T/S Corona - Rear 1
11 AD02 2179 Front E nd Bl ock - T&S Cor ona 1
12 A048 3888 T&S Corona Guide Plate 1
13 A173 3859 Spring Plate 1
14 A048 3857 Spring Plate 2
15 A173 3880 Spring Plate 1
16 A173 3901 Transfer Guide Plate 1
17 A048 3860 Transport Bracket Holder 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0443 0060W Hexagon Head Tapping Screw - M3x6
102 0413 0082W Tapping Screw - M3x8
103 0951 3005W Philips Screw With Flat Washer-M3x5
104 0413 0060W Tappi ng Scr ew - M3x6

Part No.

Description

Q’ty Per
Assembly

39

18. FU SIN G UNI T (A173)

40

18. FU SIN G UNI T (A173)

Index
No.

1 A128 4155 Fusing Cover 1
2 A173 4224 Upper Fusing Stay 1
3 A128 5435 Thermofuse 1
5 A173 5052 Thermistor 1
6 A173 1081 Drive Release Bracket 1
7 A173 1085 Cleaning Drive Gear 1
8 A048 4105 Rear Heater H older 1
9 AB01 3417 Gear - 30z 1
10 AB01 3418 Gear - 24z 1
11 A128 4314 Pressure Spring 1
12 A017 4085 Pressure Lever 1
13 A173 4223 Lower Guide Plate 1
14 AB01 3201 Gear - 40t 1
15 AE03 0003 Ball Bearing - 30x42x7 1
16 A048 4084 Collar - Hot Roller 1
17 AE01 1035 Hot Roller 1
18 A173 4079 Lower Entrance Guide 1
19 AE02 0016 Pressure Roller 1
20 A173 4081 Lower Guide Plate 1
21 AE03 1002 Bushing - 8x14x7 1
22 AX44 0067 Fusing Lamp - 220V 780W 1
22 AX44 0066 Fusing Lamp - 115V 780W 115% 1
23 AG05 0046 Fusing Knob 1
24 A075 4100 Front Heater Hol der 1
25 A128 5875 Clamp 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0951 3006W Philips Screw With Flat Washer-M3x6
102 0951 3008W Philips Screw With Flat Washer-M3x8
103 0443 0060W Hexagon Head Tapping Screw - M3x6
104 0720 0040E Retaining Ring - M4
105 0720 0060E Retaini ng R ing - M6

Part No.

Description

Q’ty Per
Assembly

41

19. PAPER EXIT SE C TIO N (A173)

42

19. PAPER EXIT SE C TIO N (A173)

Index
No.

1 A173 4475 Decal - Exit 1
2 5203 4179 Cauti on Decal - High Temperatur e 1
3 A173 4415 Exit Cover (RIC) 1
3 A173 6372 Exit Cover (NRG) 1
4 A173 4470 Feeler 1
5 AA06 6210 Spring - Feeler 1
6 A173 4215 Gear - 16z 1
7 A173 4231 Upper Exit Guide 2
8 A173 4425 Grip Cover (RIC) 1
8 A173 6375 Grip Cover (NRG) 1
9 AG07 0004 Magnetic Catch 2
10 A173 4028 Release Spring 2
11 A173 4467 Exit Roller Holder 2
12 AF04 0031 Upper Exit Roller 2
13 A173 4213 Release Plate 1
14 AA14 3423 Shaft - Release Plate 2
15 AA14 0485 Shaft - Hot Roller Stripper 1
16 AA06 0513 Spring - Hot R oller Stripper 2
17 A006 9002 Hot Roller S tripper (5pcs/ Set ) 2
18 A173 4225 Lower Exit Roller 1
19 A173 4227 Front Exit Holder 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0720 0040E Retaining Ring - M4
102 0720 0030E Retaining Ring - M3
103 0805 3385 Bushing - 6mm
104 0413 0082W Tapping Screw - M3x8
105 0965 3008W Tappi ng Scr ew With Flat Washer-M3x8

Part No.

Description

Q’ty Per
Assembly

43

20. DR IVE SECT ION ( A 173)

44

20. DR IVE SECT ION ( A 173)

Index
No.

1 A173 1112 Toner Supply Bracket 1
2 A173 1113 Toner Supply Shaft 1
3 AB01 3429 Gear - 26z 1
4 A173 5057 Magnetic Clutch 1
5 A173 1122 Development Drive Bracket 1
6 A173 1121 Development Doctor Bracket 1
7 5053 0223 Bushing - 8mm 1
8 A128 5875 Clamp 2
9 A173 5055 Magnetic Clutch 3
10 A173 2616 I dle Gear - 40z 1
11 A173 2747 Paper End Sensor Bracket 1
12 AW02 0075 Photointerrupter 1
13 A173 2615 Gear - 33/44z 1
14 A173 1138 Timing Belt 1
15 A173 2627 Support Plate 1
16 A173 2622 Clutch Stopper Bracket 1
17 A110 3350 Development Connector 1
18 A128 5306 P. Sensor Harness 1
19 A173 1093 Drum Drive Bracket 1
20 A128 5872 Wire Sadle 1
21 A173 1097 I dle Gear - 30z 2
22 A173 1188 Tightener Spring 1
23 A173 1068 Tightener 1
24 A173 1139 Stepped Screw - M5 1
25 A173 1132 Pulley - 18z 1
26 A173 1133 Gear - 24z 1
27 A173 5035 Main Motor - DC220V 25W 1
27 A173 5037 Main Motor - DC115V 25W 1
28 A173 5856 Transformer Bracket 1
29 A128 5875 Clamp 1
30 A048 5856 Power Pack Bracket 1
31 A173 1098 I dle Gear - 36Z 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0720 0060E Retaining Ring - M6
102 0443 0060W Hexagon Head Tapping Screw - M3x6
103 0951 3010W Philipsscrew With Flat Washer-M3x10
104 0805 3384 Bushing - 5mm
105 0805 3386 Bushing - 8mm
106 0633 0120E Spring Pin - M3x12

Part No.

Description

Q’ty Per
Assembly

45

21. ELEC TRICA L SECTION 1 ( A173)

46

21. ELEC TRICA L SECTION 1 ( A173)

Index
No.

1 A173 1146 Exit Sensor Bracket 1
2 AW02 0075 Photointerrupter 1
3 AX64 0054 Fan Motor - DC 2.4W (Large) 1
4 A173 1141 Duct Bracket 1
5 A173 1185 Ozone Filter - 78x88 2
6 A173 3595 Upper Cleaning Stay 1
7 AD02 1108 T/S Corona Receptacle 1
8 A173 5814 Safety Switch Lever 1
9 5203 1686 Screw - Slid Rail 2
10 AD02 1015 Receptacle Housi ng 1
11 A128 5830 Decal - Left Cover 1
12 A173 5813 Safety Switch Bracket 1
13 A173 5316 AC Harness 1
14 A173 5036 Erase Lamp 1
15 A173 5235 Eraser 1
16 A048 5820 Eraser bracket 1
17 AD02 1013 Chage Corona Receptacle 1
18 AW50 0012 Push Switch 1
19 A054 1182 Bracket - Sensor Cover 1
20 A048 2675 Cam - Lower Right Cover 1
21 AG07 0004 Magnetic Catch 2
22 A173 5801 Total Counter Bracket 1
23 AX31 0024 Total Counter 1
24 A173 2637 Stepped Screw - M6 1
25 A173 2636 Right Lower Cover (R IC) 1
25 A173 2638 Right Lower Cover (N R G) 1
26 A128 5875 Clamp 1
27 A048 2674 Guide - Auxiliary 4
28 AF02 2042 Middle Pressure Roller 4
29 A048 2679 Spring Plate 8
30 5442 2107 Spring 2
31 A173 5406 Fan Motor - DC 2.4W (Small) 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0443 0060W Hexagon Head Tapping Screw - M3x6
102 0313 0300W Philips Pan Head Screw - M3x30
103 0443 0080W Hexagon Head Tapping Screw - M3x8
104 0313 0050W Philips Pan Head Screw - M3x5
105 0951 4008W Philips Screw With Flat Washer-M4x8
106 0951 3020W Philips Screw With Flatwasher-M3x20
107 0802 5085 Tapping Screw - M4x8
108 1204 1576 Main Switch
109 1204 2334 Safety Switch - FA1L-AA20
110 0951 3006W Philips Screw With Fl at Washer-M3x6

Part No.

Description

Q’ty Per
Assembly

47

22. ELEC TRICA L SECTION 2 ( A173)

48

22. ELEC TRICA L SECTION 2 ( A173)

Index
No.

1 A173 5161 Main Control Board 1
2 A173 5262 Left Harness 1
3 A173 5857 Main Cont r ol Board B racket 2
4 AZ32 0069 Power P ack - CBG 1
5 A128 5873 Clamp 6
6 A173 5039 Power Pack - TD 1
7 A128 5340 Power Pack Harness 1
8 A173 5821 AC Control Board Bracket 1
9 A173 5620 AC/DC Power Unit - 230V 1
9 A173 5621 AC/DC Power Unit - 115V 1
10 A173 5313 Heater Harness 1
11 A173 5260 Paper Tray Harness 1
12 A173 5258 Right Harness 1
13 A173 5275 Scanner Right Harness 1
14 A173 5276 Optics Harness 1
15 A173 1148 Suppor Plate Bracket 1
16 A173 5026 Power Supply Cord - 230V 1
16 A173 5471 Power Supply Cord - 230V 1
17 A111 5850 Power Supply Cord Bracket 1
18 A173 5404 Clamp 3
19 A128 5876 Clamp 2

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0443 0060W Hexagon Head Tapping Screw - M3x6
102 0951 4006W Philips Screw With Flat Washer-M4x6
103 0315 0080M Philips Pan Head Screw - M5x8
104 0705 0050Z Toot hed Washer - M5
105 1107 0797 Fuse - 16A 250V (115V)
105 1107 0784 Fuse - 6.3A 250V (230V)

Part No.

Description

Q’ty Per
Assembly

49

23. FR AME SECTION (A173)

50

23. FR AME SECTION (A173)

Index
No.

1 A048 2056 Cleaning Rail 1
2 A110 2052 Charge Corona Guide 1
3 A048 2053 Left Charge Corona Rail 1
4 A110 2054 Right Charge Cor ona R ail 1
5 A128 5876 Clamp 1
6 A173 3832 Support Plate 1
7 A173 3960 Transfer Lever 1
8 A173 3955 Transfer Release Br acket 1
9 A173 5050 Anti-Condensation Heater - 230V 18W 1
9 A173 5051 Anti-Condensation Heater - 230V18W 1
10 A173 1179 Copy Tray Rail 1
11 A173 1177 Right Paper Gui de 1
12 A173 1183 Left Guide Plate 1
13 A173 1181 Tray Positioning Plate 2
14 5216 1186 Rubber Foot 4
15 AA15 0364 Seal - 110 X 25 1
16 A173 2617 Lower Paper Feed Stay 1
17 A110 1195 Release Spring 1
18 5442 1702 Small Screw - M3 1
19 A110 1191 Release Plate Bracket 1
20 A110 1312 Rear Cover Bracket 2
21 A048 1301 Key Counter Bracket 1
22 A173 5250 Front Harness 1
23 A128 1130 Sealding Seal - 5th Mirror 1
24 AA15 1526 Seal - 5th Mirror 1
25 A006 2130 Spring Plate - Charge Corona 2
26 A128 5872 Wire Sadle 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0443 0060W Hexagon Head Tapping Screw - M3x6
102 0414 0102F Tapping Screw - M4x10
103 0413 0082W Tapping Screw - M3x8
104 0951 3010W Ph ilipsscr ew With Flat Washer-M3x10

Part No.

Description

Q’ty Per
Assembly

51

24.MAIN CONTROL BOARD (A173)

52

24.MAIN CONTROL BOARD (A173)

53

24.MAIN CONTROL BOARD (A173)

54

24.MAIN CONTROL BOARD (A173)

Index
No.

*A173 5161 Main Contr ol Board 1
1 A173 5107 IC - UVEPROM 1M 8X 150NS 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 1102 2179 Connector - PIC - FS4 - T
102 1102 4201 ConneCtor - 2P
103 1102 4202 Connector - 3P
104 1102 4204 CT Header - 5P
105 1102 4205 CT Header - 6P
106 1102 4207 Connector - 8P
107 1102 4210 Connector - 11P
108 1102 4211 CT Header - 12P
109 1102 4619 Connector - 2P
110 1102 4628 Connector - 11P
111 1102 4631 CTConnector - 2P
112 1102 5007 CT Header - 14P
113 1103 1169 Connector - 6P
114 1103 1770 Connector - 4P
115 1103 1776 Pin Header - 1OP
116 1401 0869 Transistor - Array - TD 62003F
117 1407 1535 lC - TD62308AP
118 1407 2055 lC - T062304F
119 1407 2230 IC - T06F62303F
120 1407 3381 IC - 74HC4066A
121 1407 3533 IC - 74HC241A
122 1407 4136 IC - UPD7831
123 1407 4315 IC - TE7751
124 1408 0598 IC - MB3773PF
125 1503 0071 0sicillator - 12Mhz
126 1905 0009 IC - 1M X8 150NS
127 1407 4286 IC - MK48Z52B - 15
128 1408 0398 IC - NJ2903M
129 1407 2187 IC - SN74LS07NS
130 1407 2080 lC - SN74LS21NS
131 1407 2412 IC - SN74LS32M
132 1407 2413 IC - SN74LSI38M
133 1407 4234 IC - SN74LS373M
134 1407 3322 IC - MC74HC04AF
135 1400 0369 Transistor - 2SA1213Y

Part No.

Description

Q’ty Per
Assembly

Index
No.

136 1402 0277 Zener Diode - 1Z12
137 1402 0476 Diode - ISS184
138 1602 0987 Capacitor&Coil - 270PF 100V
139 1607 0491 Capacitor - BL03RN2 - R6
140 1204 1372 Locking Support
141 1104 0598 lC - Socket
142 1102 5305 Connector - 6P

143 1630 2101 Resistor - 100 Ω 1/8W
144 1630 2102 Resistor - 1K Ω 1/8W ±5%
145 1630 2103 Resistor - 10K Ω 1/8W
146 1630 2104 Resistor - 100K Ω 1/8W ±5%
147 1630 2106 Resistor - 10M Ω 1/8W
148 1630 2123 Resistor - 12K Ω 1/8W ±5%
149 1630 2152 Resistor - 1.5K Ω 1/8W ±5%
150 1630 2154 Resistor - 150K Ω ±5%1/8W
151 1630 2204 Resistor - 200K Ω ±5%1/8W
152 1630 2222 Resistor - 2.2K Ω I/8W
153 1630 2223 Resistor - 22K Ω 1/8W ±5%
154 1630 2243 Resistor - 24K Ω 1/8W ±5%
155 1630 2272 Resistor - 2.7 Ω ±5%1/8W
156 1630 2273 Resistor - 27K Ω 1/8W 5%
157 1630 2301 Resistor - 300 Ω 1/8W 5%
158 1630 2302 Resistor - 3K Ω I/8W 5%
159 1630 2394 Resistor - 390K Ω 1/8W ±5%
160 1630 2472 Resistor - 4.7K Ω 1/8W ±5%
161 1630 2473 Resistor - 47K Ω 1/8W ±5%
162 1630 2513 Resistor - 151 Ω 1/8W ±5%
163 1630 2561 Resistor - 560 Ω ±5%1/8W
164 1630 2622 Resistor - 6.2K Ω 1/8W 5%
165 1630 2681 Resistor - 680 Ω 1/8W ±5%
166 1630 2824 Resistor - 820 Ω 1/8W ±5%
167 1632 1001 Resistor - IK Ω ±1% 1/8W
168 1632 1002 Resistor - 10.OK Ω 1/8W ±1%

Part No.

Description

Q’ty Per
Assembly

Index
No.

169 1632 1301 Resistor - 1.3K Ω ±1% 1/8W
170 1632 3901 Resistor - 3.9K Ω 1/8W ±1%
171 1605 0343 Capacitor - 30PF ±5% 50V

172 1605 0596 Capacitor - 100PF
173 1605 0636 Capacitor - 0.1µF
174 1606 1139 Capacitor - 0.01µF ±20%

175 1606 1455 Capacitor - 470PF 25V
176 1640 2101 Capacitor - 100µF ±20% 25V
177 1640 2470 Capacitor - 47µF ±20% 25V
178 1640 5109 Capacitor - 1µF ±20% 50V
179 1604 5478 Capacitor - 0.47µF ±20% 50V
180 1102 4629 Connector - 12P

181 1402 0478 Diode - 1SS226TE85L
182 1104 0239 LSI Socket - 24P

Part No.

Description

Q’ty Per
Assembly

55

25. DECAL AND DDCUMENT (A173)

56

25. DECAL AND DDCUMENT (A173)

Index
No.

1 5203 4179 Caution Decal - High Temperature
2 A173 1388 Decal - Symbol (RIC) 1
2 A173 6386 Decal - Symbol (NRG) 1
3 A173 2843 Decal - Paper Feed (RIC) 1
3 A173 2848 Decal - Paper Feed (RIC- TWN) 1
3 A173 6387 Decal - Paper Feed (NRG) 1
4 A173 4475 Decal - Exit 1
5 AA00 0059 Caut ion D ecal - Engl ish 1
6 AA00 0401 Decal - High Temperature 1
7 AA00 1172 Decal - Paper Volume 1
7 AA00 1172 Decal - Paper Volume 1
8 AA00 2008 Decal - A4R (RIC) 1
8 AA00 2009 Decal - A4 (RIC) 1
8 AA00 2026 Decal - B5 (RIC) 1
8 A048 6285 Decal - A4R (NRG) 1
8 A048 6286 Decal - A4 (NRG) 1
8 A121 6832 Decal - B5 (NRG) 1
9 A173 2822 Decal - By-Pass Feed 1
10 A173 8608 Operat i ng Inst r uct ions - Engli sh (R IC) 1
10 A173 8698 Operat i ng Inst r uct ions - Engli sh (N R G ) 1
10 A173 8609 Operating I nstr uct ions - TWN 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

Part No.

Description

Q’ty Per
Assembly

57

26. SPECIAL TOOLS (A173)

58

26. SPECIAL TOOLS (A173)

Index
No.

1 A006 9105 Drum Shoe Shaft 1
2 A006 9103 Omega Clamp 1
3 A006 9104 Asjusting S canner Pin (4pcs/set) 1
4 A008 9502 Silicone Grease - G40M 1
5 5203 9501 Grease 501 1
6 5442 9106 Drum Shoe 1
7 5447 9104 Shoe Adaptor 1
8 5420 9507 Digital Multimeter - Brckman 1
9 5447 9078 Heat Resist ing G r ease MT-78 1
10 5420 9516 Test Chart - OS - A3 (10pcs/set) 1
11 5420 9502 Test Chart - OS - A3 (100pcs/set) 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

Part No.

Description

Q’ty Per
Assembly

59

PARTS INDEX

Part No.

Description

Page and
Index No.

Part No.

Descri p t ion

Page and
Index No

A173 1068 Tightener 45- 23
A173 1081 Drive Release Bracket 41- 6
A173 1085 Cleaning Drive Gear 41- 7
A173 1093 Drum Drive Bracket 45- 19
A173 1097 I dle Gear - 30z 45- 21
A173 1098 I dle Gear - 36Z 45- 31
A173 1112 Toner Supply Bracket 45- 1
A173 1113 Toner Supply Shaft 45- 2
A173 1121 Development Doctor Bracket 45- 6
A173 1122 Development Drive Bracket 45- 5
A173 1124 Development Drive Shaft 27- 3
A173 1132 Pulley - 18z 45- 25
A173 1133 Gear - 24z 45- 26
A173 1138 Timing Belt 45- 14
A173 1139 Stepped Screw - M5 45- 24
A173 1141 Duct Bracket 47- 4
A173 1146 Exit Sensor Bracket 47- 1
A173 1148 Suppor Plate Br acket 49- 15
A173 1155 Paper End Actuator 27- 7
A173 1177 Right Paper Guide 51- 11
A173 1179 Copy Tray Rail 51- 10
A173 1181 Tray Positioni ng Plate 51- 13
A173 1183 Left Guide Plate 51- 12
A173 1185 Ozone Filter - 78x88 47- 5
A173 1188 Tightener Spring 45- 22
A173 1195 Release Spr ing 27- 15
A173 1233 Front Door (RI C) 7- 12
A173 1235 Left Lower C over (RIC) 7- 16
A173 1236 Upper Cover (RIC) 7- 7
A173 1277 Right Cover (RIC) 7- 9
A173 1320 Front Lower Cover 7- 10
A173 1334 Front Cover (R IC) 7- 11
A173 1385 Operation Sheet 7- 14
A173 1388 Decal - Symbol (RIC) 57- 2
A173 1397 Cap - Left Lower Cover (RIC ) 7- 17

A173 1616 Scale (RIC) 7- 6
A173 1660 Scanner Motor Bracket 15- 2
A173 1731 Front Right Pulley 15- 11
A173 1733 Rear Left Pulley 15- 6
A173 1750 Lens Bracket 13- 3
A173 1752 Shielding Sheet 13- 5
A173 1753 Shielding Seal 13- 1
A173 1768 Motor Base 11- 19
A173 1770 Platen Cover Hinge (RIC) 9- 5
A173 1771 ADS Cover 13- 18
A173 1776 Scale Bracket 17- 1
A173 1784 Lens Sensor Bracket 13- 13
A173 1786 Sensor Bracket 11- 9
A173 1788 Sensor Bracket 17- 6
A173 1855 Original Holder (RIC) 9- 3
A173 2101 Bushing - 8x22x7 35- 17
A173 2103 Stepped Screw 35- 16
A173 2607 Paper Drive Shaft 27- 23
A173 2611 Lower Registration Roll er 25- 10
A173 2615 Gear - 33/44z 45- 13
A173 2616 I dle Gear - 40z 45- 10
A173 2617 Lower Paper Feed Stay 51- 16
A173 2621 Feed Roller Bushing 27- 27
A173 2622 Clutch Stopper Bracket 27- 21
A173 2622 Clutch Stopper Bracket 45- 16
A173 2623 2nd Drive Roller 27- 8
A173 2627 Support Plat e 45- 15
A173 2632 I dle Gear - 28/14Z 27- 20
A173 2633 Clutch Stopper 27- 10
A173 2635 Idle Gear 27- 24
A173 2636 Right Lower Cover (RIC) 47- 25
A173 2637 Stepped Screw - M6 47- 24
A173 2638 Right Lower Cover (NR G) 47- 25
A173 2662 Middle Guide Plate - Registration 25- 8
A173 2668 Seal - 9.5x75 25- 7

62

Part No.

Description

Page and
Index No.

Part No.

Descri p t ion

Page and
Index No

A173 2713 Release Shaf t 23- 33
A173 2714 Release Lever 23- 32
A173 2715 Pad Lever 23- 27
A173 2716 Release Lever Spring 23- 31
A173 2718 Bottom Plate Spring 23- 17
A173 2720 Release Spr ing 23- 25
A173 2725 Sensor Actuattor 23- 16
A173 2725 Sensor Actuattor 27- 9
A173 2734 Upper Bracket - Paper Feed 23- 21
A173 2735 1st Entrance Guide 23- 20
A173 2736 Front Casset te Holder (RI C ) 23- 34
A173 2737 Rear C assette Holder (RIC) 23- 18
A173 2740 Pressure Spring 23- 26
A173 2741 Paper End Actuator 23- 9
A173 2743 Friction Pad Bracket 23- 28
A173 2745 Upper Paper Feed Guide 23- 1
A173 2746 By-Pass Feed Guide 23- 11
A173 2747 Paper End Sensor Bracket 45- 11
A173 2753 Release Shaf t 23- 12
A173 2756 Shaft Bracket 23- 15
A173 2757 Front Rel ease Arm 23- 38
A173 2758 Rear R elease A rm 23- 13
A173 2761 Paper Size Sensor B racket 23- 22
A173 2771 Spacer 23- 29
A173 2774 1st Paper Feed Shaft 23- 8
A173 2777 Paper Feed Roller 23- 3
A173 2791 Small Cassette (RIC ) 19- 25
A173 2798 Actuator - B5R 19- 23
A173 2811 Paper Tray Cover (RIC) 21- 19
A173 2816 Paper Sensor Bracket 27- 12
A173 2822 Decal - By-Pass Feed 57- 9
A173 2843 Decal - Paper Feed (RIC) 21- 3
A173 2843 Decal - Paper Feed (RIC) 57- 3
A173 2848 Decal - Paper Feed (RIC- TWN ) 21- 3
A173 2848 Decal - Paper Feed (RIC- TWN ) 57- 3

A173 2852 By-pass Feed Uni t 19- 1
A173 2856 Rear S ide Fence (RIC) 19- 2
A173 2871 By-Pass Feed Guide 19- 6
A173 2874 Spring Plate 19- 4
A173 2876 By-Pass Feed Bottom Guide (RIC) 19- 5
A173 2911 Bottom Plate 19- 21
A173 2919 Bushing - 8mm 27- 22
A173 2946 By-Pass Feed Table (RIC) 19- 7
A173 3025 Development Rail 25- 1
A173 3081 T/S Corona Unit Casing 39- 7
A173 3082 Guide Plate 39- 6
A173 3185 Lower Cleaning Case 37- 30
A173 3401 Mixing Auger 31- 13
A173 3402 Paddle Roller 31- 10
A173 3403 Auger Shaft 29- 16
A173 3595 Upper Cleaning Stay 47- 6
A173 3832 Support Plate 51- 6
A173 3859 Spring Plate 39- 13
A173 3880 Spring Plate 39- 15
A173 3901 Transfer Guide Plate 39- 16
A173 3955 Transfer Release Bracket 51- 8
A173 3960 Transfer Lever 51- 7
A173 4028 Release Spr ing 43- 10
A173 4079 Lower Entr ance Gui de 41- 18
A173 4081 Lower Guide Plate 41- 20
A173 4213 Release Plate 43- 13
A173 4215 Gear - 16z 43- 6
A173 4223 Lower Guide Plate 41- 13
A173 4224 Upper Fusing Stay 41- 2
A173 4225 Lower Exit Roller 43- 18
A173 4227 Front Exit Hol der 43- 19
A173 4231 Upper Exit Guide 43- 7
A173 4415 Exit Cover (RIC) 43- 3
A173 4425 Grip Cover (RIC) 43- 8
A173 4440 Copy Tray (RIC) 7- 4

63

Part No.

Description

Page and
Index No.

Part No.

Descri p t ion

Page and
Index No

A173 4465 Copy Tray Slide (RIC) 7- 2
A173 4467 Exit Roller Holder 43- 11
A173 4470 Feeler 43- 4
A173 4475 Decal - Exit 43- 1
A173 4475 Decal - Exit 57- 4
A173 5026 Power Supply Cord - 230V 49- 16
A173 5035 Main Motor - DC220V 25W 45- 27
A173 5036 Erase Lamp 47- 14
A173 5037 Main Motor - DC115V 25W 45- 27
A173 5039 Power Pack - TD 49- 6
A173 5050 Anti-Condensat ion H eater - 230V 18W 51- 9
A173 5051 Anti-Condensat ion H eater - 230V18W 51- 9
A173 5052 Thermistor 41- 5
A173 5055 Magnetic Clutch 27- 18
A173 5055 Magnetic Clutch 45- 9
A173 5057 Magnetic Clutch 45- 4
A173 5107 IC - UVEPROM 1M 8X 150NS 55- 1
A173 5120 Optical Control Board 13- 19
A173 5161 Main Control Board 49- 1
A173 5161 Main Contr ol Board 55-
A173 5219 Mirror Drive Motor 11- 20
A173 5221 Lens Drive Motor 13- 11
A173 5235 Eraser 47- 15
A173 5250 Front Har ness 51- 22
A173 5257 Right Harness 23- 37
A173 5258 Right Harness 49- 12
A173 5260 Paper Tray Harness 49- 11
A173 5262 Left Harness 49- 2
A173 5275 Scanner Right Harness 49- 13
A173 5276 Optics Harness 49- 14
A173 5282 Exposure Lamp Har ness 15- 26
A173 5313 Heater H ar ness 49- 10
A173 5316 AC Harness 47- 13
A173 5400 Fan Motor - 24V 17- 16
A173 5402 Clip 17- 5

A173 5403 Clamp 15- 25
A173 5404 Clamp 49- 18
A173 5406 Fan Motor - DC 2.4W (Small) 47- 31
A173 5471 Power Supply Cord - 230V 49- 16
A173 5620 AC/DC Pow er Uni t - 230V 49- 9
A173 5621 AC/DC Pow er Uni t - 115V 49- 9
A173 5651 Operat i on Panel Ass’y (RIC) 7- 20
A173 5801 Total C ounter Bracket 47- 22
A173 5812 Right Bracket - Operation Panel 7- 19
A173 5813 Safet y Sw itch Bracket 47- 12
A173 5814 Safety Switch Lever 47- 8
A173 5821 AC Control Board Bracket 49- 8
A173 5856 Transformer Bracket 45- 28
A173 5857 Main Contr ol Board B racket 49- 3
A173 5916 Exposure Lamp - 181V 310W 15- 16
A173 5917 Exposure Lamp - 181V 310W 15- 16
A173 6201 Front Door (NR G) 7- 12
A173 6227 Left Lower C over (NR G ) 7- 16
A173 6229 Right Cover (NRG) 7- 9

*

A173 6231 Upper Cover (NRG) 7- 7
A173 6237 Copy Tray (NRG) 7- 4
A173 6241 Scale (NRG) 7- 6
A173 6247 Front Cover (N RG ) 7- 11
A173 6292 Operat i on Panel Ass’y (NRG) 7- 20
A173 6312 Paper Tray Cover (NRG) 21- 19
A173 6339 Front Casset te Holder (NR G ) 23- 34
A173 6340 Rear C assette Holder (NRG) 23- 18
A173 6346 By-Pass Feed Table (NRG) 19- 7
A173 6354 By-Pass Feed Bottom Guide (NRG) 19- 5
A173 6356 Rear S ide Fence (NR G ) 19- 2
A173 6358 Platen Cover Hinge (NRG) 9- 5
A173 6364 Small Cassette (NRG ) 19- 25
A173 6365 Model Name Plate - NSA - A4 7- 23
A173 6366 Model Name Plate - GES 7- 23
A173 6372 Exit Cover (NRG) 43- 3

64

Part No.

Description

Page and
Index No.

Part No.

Descri p t ion

Page and
Index No

A173 6375 Grip Cover (NRG) 43- 8
A173 6376 Cap - Left Lower Cover (NRG ) 7- 17
A173 6386 Decal - Symbol (NRG) 57- 2
A173 6387 Decal - Paper Feed (NRG) 21- 3
A173 6387 Decal - Paper Feed (NRG) 57- 3
A173 6406 Copy Tray Slide (NRG) 7- 2
A173 6434 Original Holder (NRG) 9- 3
A173 8608 Operat i ng Inst r uct ions - Engli sh (R IC) 57- 10
A173 8609 Operat i ng Inst r uct ions - TWN 57- 10
A173 8698 Operat i ng Inst r uct ions - Engli sh (N R G ) 57- 10

AA00 0059 Cauti on Decal - English 37- 2
AA00 0059 Cauti on Decal - English 57- 5
AA00 0401 Decal - High Temperature 57- 6
AA00 1172 Decal - Paper Volume 21- 11
AA00 1172 Decal - Paper Volume 57- 7
AA00 1172 Decal - Paper Volume 57- 7
AA00 2008 Decal - A4R (RIC) 19- 26
AA00 2008 Decal - A4R (RIC) 57- 8
AA00 2009 Decal - A4 (RIC) 19- 26
AA00 2009 Decal - A4 (RIC) 57- 8
AA00 2010 Decal - Paper Level 19- 20
AA00 2026 Decal - B5 19- 26
AA00 2026 Decal - B5 (RIC) 57- 8
AA02 0001 Drawer Tray Magnet 25- 20
AA05 0044 Scanner D rive Wire - 1458mm 15- 7
AA05 0045 Scanner D rive Wire - 1011mm 15- 13
AA05 0046 Lens Drive Wire 13- 7
AA06 0141 Spring - Charge Corona Grid 33- 11
AA06 0254 Spring - Upper Transfer Guide 25- 11
AA06 0255 Spring - Rear Charge Corona Grid 33- 15
AA06 0267 Spring - Toner End Adt uator Lever 29- 29
AA06 0513 Spring - Hot Rol ler Stripper 43- 16
AA06 3036 Terminal Spring 39- 9
AA06 3081 Spring - Side Fence Stopper 21- 8
AA06 3106 Spring - Pick-Up P aw l 35- 6
AA06 3205 Spring 21- 20
AA06 3497 Pressure Spring 21- 18
AA06 6210 Spring - Feeler 43- 5
AA08 0030 Bushing - 5x13x7 37- 19
AA08 0094 Front Regi str at ion Roller Bushing 25- 14
AA08 2029 Bushing - 6x13x5 15- 3
AA14 0485 Shaft - Hot Roller Stripper 43- 15
AA14 3064 Philips Pan Head Screw - M3x10 23- 30
AA14 3264 Pulley Shaft 13- 17
AA14 3288 Stepped Screw 19- 15

65

Part No.

Description

Page and
Index No.

Part No.

Descri p t ion

Page and
Index No

AA14 3288 Stepped Screw 21- 12
AA14 3423 Shaft - Release Plate 43- 14
AA14 5209 Shaft - Drive Gear 27- 25
AA15 0074 Seal - 12x272 13- 4
AA15 0196 Shield - Toner Hopper - Left 29- 28
AA15 0197 Shield - Toner Hopper - Right 29- 13
AA15 0198 Shield - Toner Hopper - Lower 29- 14
AA15 0331 Seal - Toner S upply Unit 29- 21
AA15 0364 Seal - 110 X 25 51- 15
AA15 1109 Seal - 5x16x5 37- 22
AA15 1186 Front Side Plate Seal 31- 11
AA15 1476 Sponge - Toner Supply 29- 17
AA15 1479 Shield - Case - Toner H opper - Rear 29- 27
AA15 1480 Shield - Toner Hopper - Fr ont U pper 29- 9
AA15 1481 Shield - Toner Hopper - Rear U pper 29- 7
AA15 1482 Shield - Toner Hopper - Upper 29- 12
AA15 1483 Shield - Toner Hopper - Lower 29- 22
AA15 1484 Shield - Fr ont Upper - Toner Hopper 29- 30
AA15 1485 Shield - Rear Upper - Toner Hopper 29- 15
AA15 1486 Shield - Fr ont Lower - Toner Hopper 29- 25
AA15 1487 Shield - Rear Lower - Toner Hopper 29- 24
AA15 1489 Seal - 2x5x37.5 29- 18
AA15 1526 Seal - 5th Mirror 51- 24
AA15 1604 Seal - 16x9x3 31- 4
AA15 1605 Seal - 323x4x3 31- 16
AA15 1606 Seal -44x14x3 29- 8
AA15 2136 Shield - Devel opment Roller 31- 15
AA15 2231 Development Filter 31- 3
AB01 0075 Gear - 48t 11- 18
AB01 1067 Gear - 100z 27- 1
AB01 1084 Gear - 17z 37- 18
AB01 3201 Gear - 40t 41- 14
AB01 3417 Gear - 30z 41- 9
AB01 3418 Gear - 24z 41- 10
AB01 3421 Gear - 18z 27- 26

AB01 3428 Gear - 35z 27- 2
AB01 3429 Gear - 26z 45- 3
AB01 3437 Gear - 19t 31- 7
AB01 3439 Gear - 23z 31- 8
AB01 3440 Gear - Rolle r - Agi tate,Mix 31- 18
AB01 3441 Gear - 20z 31- 20
AB01 3442 Gear - Toner Supply 29- 3
AB01 3443 Gear - Idler - Toner Supply 29- 4
AB01 3444 Gear - Agit ator 29- 5
AB01 3492 Gear - 16z 21- 17
AB01 3858 Gear - 15z 31- 14
AB01 7129 Gear - 20z And 72z 11- 17
AB01 7160 Gear - 17z And 35z 37- 17
AB03 2024 Pulley - Scanner Wire 11- 4
AC02 0082 Lens - F8/180 13- 6
AC03 0019 2nd & 3rd Mirror 11- 1
AC03 0026 Mirr or - L224 11- 13
AD02 1013 Chage Corona Receptacle 47- 17
AD02 1015 Receptacle Housing 47- 10
AD02 1108 T/S Corona Receptacle 47- 7
AD02 2179 Front End Bl ock - T&S C orona 39- 11
AD02 2180 Rear End Block - T&S Cor ona 39- 8
AD02 3059 Left Main Corona Unit Casing 33- 5
AD02 3060 Right Mai n Cor ona Unit Casing 33- 14
AD03 1266 Development Roller 31- 1
AD03 6021 Mixing Vanes 31- 2
AD03 7023 Mixing Auger 31- 9
AE01 1035 Hot Roller 41- 17
AE02 0016 Pressure Roller 41- 19
AE03 0003 Ball Bearing - 30x42x7 41- 15
AE03 1002 Bushing - 8x14x7 41- 21
AF01 1030 Bottom Plate - Papper Tray 21- 1
AF01 3001 Bottom Plate Pad 21- 2
AF01 6068 Front Side Fence - Paper Tray 21- 6
AF02 1039 Upper Registration R ol ler 25- 2

66

Part No.

Description

Page and
Index No.

Part No.

Descri p t ion

Page and
Index No

AF02 2042 Middle Pressure Roller 47- 28
AF03 1027 Paper Feed Roller 27- 29
AF04 0031 Upper Exit Roller 43- 12
AG05 0046 Fusing Knob 41- 23
AG05 1071 Knob - Regi str at ion Guide P lat e 25- 19
AG07 0004 Magnetic Catch 11- 21
AG07 0004 Magnetic Catch 43- 9
AG07 0004 Magnetic Catch 47- 21
AG07 1008 Door Catch - Latch 7- 15
AW02 0024 Photointerruptor 25- 4
AW02 0075 Photointerrupter 11- 8
AW02 0075 Photointerrupter 13- 12
AW02 0075 Photointerrupter 17- 7
AW02 0075 Photointerrupter 27- 14
AW02 0075 Photointerrupter 45- 12
AW02 0075 Photointerrupter 47- 2
AW50 0010 Push Switch 23- 23
AW50 0012 Push Switch 19- 16
AW50 0012 Push Switch 27- 11
AW50 0012 Push Switch 47- 18
AX31 0024 Total C ounter 47- 23
AX44 0066 Fusing Lamp - 115V 780W 115% 41- 22
AX44 0067 Fusing Lamp - 220V 780W 41- 22
AX64 0054 Fan Motor - DC 2.4W (Large) 47- 3
AZ32 0069 Power Pack - CBG 49- 4

A005 3585 Sensor Feeler - Toner O ver Fl ow 37- 3
A005 3586 Rubber Seal - Toner Collection 37- 5
A005 3587 Feeler Supporter 37- 4
A006 1707 Rear Wir e C lamp 15- 21
A006 1708 Front Wir e Clamp 15- 29
A006 1721 Front Spr ing Plate 11- 3
A006 1722 Spring Plate 11- 24
A006 1744 Wire Suppor t Plat e 15- 8
A006 1745 Wire Adj usti ng Pl at e 15- 12
A006 2055 Charge Corona Cleaner 33- 1
A006 2111 Charge Corona Grid 33- 9
A006 2114 Grid Anchor 33- 4
A006 2117 Front Cover - Charge C or ona 33- 3
A006 2118 Rear C over - Charge Cor ona 33- 6
A006 2118 Rear C over - Charge Cor ona 33- 16
A006 2121 Cleaner Holder 33- 21
A006 2122 Cleaner Stopper 33- 19
A006 2123 Cleaner Stay 33- 18
A006 2130 Spring Plate - Char ge Corona 51- 25
A006 2270 Pick-Off Pawl 35- 7
A006 2699 Spacer - 5.1x20mm 19- 11
A006 3584 Toner Collection Hosing 37- 6
A006 3589 Cleaning Entrance Seal 37- 14
A006 9002 Hot Roller Stripper (5pcs/ Set ) 43- 17
A006 9103 Omega Clamp 59- 2
A006 9104 Asjusti ng Scanner Pin (4pcs/set) 59- 3
A006 9105 Drum Shoe Shaft 59- 1
A008 2087 Corona Cleaner Pad 33- 20
A008 9502 Silicone Grease - G40M 59- 4
A017 4085 Pressure Lever 41- 12
A024 2653 Upper Lift Arm 23- 19
A027 1705 Mirror Guide 11- 10
A030 6231 Corona Wire Ring 33- 10
A048 1301 Key Counter Bracket 51- 21
A048 1721 Spring Plate A 15- 10

67

Part No.

Description

Page and
Index No.

Part No.

Descri p t ion

Page and
Index No

A048 1721 Spring Plate A 15- 27
A048 1737 Front Wir e Pul ley 15- 5
A048 1755 Lens Shutter 13- 8
A048 1764 Rack Gear - Mirror Drive 11- 16
A048 1782 Mirror Shutter 11- 15
A048 1789 Lens Cover 13- 15
A048 1801 Mirror Seal 11- 25
A048 1839 Left Guide Bracket 17- 18
A048 2008 Charge Corona Unit 33- 2
A048 2053 Left Charge C or ona Rai l 51- 3
A048 2056 Cleaning Rail 51- 1
A048 2091 Front End Bl ock 33- 12
A048 2273 Pick-Off Pawl Bracket 35- 5
A048 2276 Ring - Transport Bracket 35- 3
A048 2573 Registr at ion Lower Guide 25- 3
A048 2674 Guide - Auxiliary 47- 27
A048 2675 Cam - Lower Right Cover 47- 20
A048 2679 Spring Plate 47- 29
A048 2817 Side Fence Stopper 21- 7
A048 2835 Side Fence Gear 21- 16
A048 2861 Paper End Sensor Bracket 27- 13
A048 2862 Paper End Sensor Bracket 27- 16
A048 2928 Cam - Manual Feed Table 19- 8
A048 2938 Paper Guide - Manual Feed Table ( RIC) 19- 12
A048 2951 Front Gui de H older 19- 14
A048 3857 Spring Plate 39- 14
A048 3860 Transpor t Bracket H ol der 39- 17
A048 3881 T&S Corona Guide 39- 1
A048 3883 Cover - T/S Corona - Front 39- 2
A048 3887 Cover - T/S Corona - Rear 39- 10
A048 3888 T&S Cor ona Guide Plate 39- 12
A048 3898 Lower Transfer Guide 25- 13
A048 3913 Upper Transfer Guide 25- 9
A048 4084 Collar - Hot Roller 41- 16
A048 4105 Rear H eat er H ol der 41- 8

A048 4470 Copy Tray - Guide (RIC) 7- 3
A048 5820 Eraser bracket 47- 16
A048 5856 Power Pack Bracket 45- 30
A048 6285 Decal - A4 (NRG) 19- 26
A048 6285 Decal - A4R (NRG) 57- 8
A048 6286 Decal - A4R (NRG) 19- 26
A048 6286 Decal - A4 (NRG) 57- 8
A048 6356 Paper Guide - Manual Feed Table ( NR G ) 19- 12
A048 6407 Copy Tray - Guide (NRG) 7- 3
A048 7600 Case - Upper - Development 31- 5
A048 7612 Development Roller Knob 31- 19
A048 7631 Retai ner - Ball Bearing 31- 6
A048 7632 Cover - Gear 31- 21
A048 7654 Lower Casing - Toner Supply Unit 29- 23
A048 7669 Plate - Toner Supply Rol ler 29- 20
A048 7670 Slitter 29- 10
A048 9001 Charge Corona Wire - 10pcs/Set 33- 8
A048 9002 Transfer Corona Wir e - 10pcs/Set 39- 5
A048 9003 Separation Corona Wire - 10pcs/Set 39- 4
A054 1182 Bracket - Sensor Cover 47- 19
A054 6330 Decal - Key-top Cover (NSA) 7- 22
A054 6335 Decal - Key-top Cover (GES) 7- 22
A069 1772 Guide P lat e 13- 14
A069 1883 Shoe - Scanner 11- 7
A069 1883 Shoe - Scanner 15- 28
A069 2820 Friction Pad Ass’y 23- 24
A069 9510 Drum 35- 13
A075 1766 Adjusti ng Cam 11- 27
A075 1870 Scanner Motor Pulley 15- 1
A075 2258 Pick-Up Pawl Shaft 35- 4
A075 2268 Upper Left Drum Stay 35- 10
A075 2269 Right Drum Stay 35- 12
A075 4100 Front Heat er Ho lder 41- 24
A077 1357 Platen Cover Pad 9- 2
A077 2822 Pl at e Rel ease Slider 21- 21

68

Part No.

Description

Page and
Index No.

Part No.

Descri p t ion

Page and
Index No

A077 5231 Scanne Drive Motor - DC 30V 60W 15- 4
A077 9523 Platen Cover Sheet - 10sheets/Set 9- 1
A085 1668 Terminal S uppor ter 15- 22
A085 1670 Exposure Adj usting Plate 15- 18
A085 1672 Front Lamp Terminal 15- 23
A096 1873 Scanner Shoe Pin 15- 20
A110 1191 Release Plate Bracket 51- 19
A110 1195 Release Spr ing 51- 17
A110 1312 Rear C over Bracket 51- 20
A110 1313 Rear Cover (RIC) 7- 8
A110 1381 Filter Cover 7- 21
A110 1669 Lamp Hol der Spring 15- 24
A110 1705 1st Mirror Support Plate 15- 15
A110 1724 Rear S pr ing Plate 11- 5
A110 1817 Scanner Slide Rail 17- 14
A110 1829 Front Side Plate 17- 4
A110 1861 Reflector 15- 17
A110 2052 Charge Corona Guide 51- 2
A110 2054 Right Charge Corona R ail 51- 4
A110 2789 Rear S ide Fence - Paper Tray 21- 10
A110 2832 End Fence - Paper Tray 21- 5
A110 2833 Leaf Spring - End Fence 21- 4
A110 2843 Registr at ion Adjustment Plat e 21- 15
A110 2870 Front Cor ner S eparator 21- 9
A110 2871 Rear C oner Separat or 21- 13
A110 2877 Corner S eparator Seal 21- 14
A110 3336 Agitator Lever 29- 2
A110 3340 Plate Nut 29- 11
A110 3350 Development Connector 45- 17
A110 5813 Left Operat ion Panel Bracket 7- 18
A110 6313 Rear Cover (NRG) 7- 8
A111 5850 Power Supply Cord Bracket 49- 17
A121 6832 Decal - B5 (NRG) 57- 8
A128 1130 Sealding Seal - 5th Mirror 51- 23
A128 1263 Left Cover (RIC) 7- 1

A128 1713 Upper Seal 17- 3
A128 1713 Upper Seal 17- 9
A128 1715 2nd Scanner Brcket 11- 2
A128 1719 Fan Motor Bracket 17- 15
A128 1728 1st Mirror 15- 14
A128 1729 2nd Mirror 11- 6
A128 1754 Shielding Plate 13- 2
A128 1757 Lens Motor Bracket 13- 10
A128 1761 Mirror Bracket 11- 14
A128 1793 6th Mirror Bracket 11- 23
A128 1797 Front 6th Mirror Bracket 11- 26
A128 1815 5th Mirror 11- 12
A128 1816 6th Mirror 11- 22
A128 1817 Mirror Spring 11- 11
A128 1818 Tension Spring 15- 9
A128 1823 Optics Right Stay 17- 17
A128 1834 Platen Cover Right Bracket 17- 13
A128 1835 Platen Cover Left Bracket 17- 10
A128 1842 Right Stay - Exposure Glass 17- 8
A128 1845 Stepped Screw - M5 7- 13
A128 1980 Exposure Glass 7- 5
A128 2258 Drum Holder 35- 15
A128 2262 Drum Support Plate 35- 14
A128 2271 Left Drum Stay 35- 1
A128 2275 Front Transport Guide 35- 2
A128 2278 Sensor Holder 35- 8
A128 2281 Rear D rum Side Plate 35- 11
A128 2658 Pressure Spring 25- 6
A128 2663 Front Spr ing - Registration Roller 25- 15
A128 2681 Front Side Fence (RIC) 19- 3
A128 2698 Side Fence Gear 19- 9
A128 2713 Bottom Plate Pad 19- 22
A128 2716 Front Side Fence 19- 18
A128 2727 Rear S ide Fence 19- 19
A128 2743 Rear Fence 19- 24

69

Part No.

Description

Page and
Index No.

Part No.

Descri p t ion

Page and
Index No

A128 2751 Registr at ion Roller Knob 25- 12
A128 2768 Stepped Screw - M3x5 25- 16
A128 2775 Gear 19- 10
A128 2945 Cover - Manual Feed Table - RI C 19- 13
A128 2956 Small Cassette Cover (R IC) 19- 17
A128 2962 Actuator - A4R 19- 23
A128 2964 Actuator - A4 19- 23
A128 3014 Tonner Supply Roller 29- 19
A128 3310 Lower Casing 31- 17
A128 3552 Cleaning Blade 37- 26
A128 3558 Upper Cleaning Case 37- 1
A128 3563 Blade Release Lever 37- 29
A128 3568 Pressure Spring 37- 10
A128 3569 Pressuer Seal 37- 8
A128 3571 Blade Holder 37- 25
A128 3572 Cleaning Lower Seal 37- 13
A128 3573 Front Hol der Seal 37- 28
A128 3578 Rear H older S eal 37- 27
A128 3580 Toner Collection Shaft 37- 21
A128 3581 Front Case Cleaning 37- 7
A128 3582 Upper Lower Seal 37- 9
A128 3583 Front Seal -C leaning 37- 11
A128 3588 Shield - Dr um 37- 15
A128 3589 Rear S eal- C leaning 37- 12
A128 3590 Seal - 9.5 37- 23
A128 3591 Seal - 5x5 37- 16
A128 3715 Lens Fixing Pi n 37- 20
A128 4155 Fusing Cover 41- 1
A128 4314 Pressure Spring 41- 11
A128 5222 Id Sensor Board 35- 9
A128 5306 P. Sensor Har ness 45- 18
A128 5340 Power Pack Harness 49- 7
A128 5435 Thermofuse 41- 3
A128 5830 Decal - Left Cover 47- 11
A128 5872 Wire Sadle 17- 2

A128 5872 Wire Sadl e 45- 20
A128 5872 Wire Sadl e 51- 26
A128 5873 Clamp 49- 5
A128 5875 Clamp 17- 12
A128 5875 Clamp 41- 25
A128 5875 Clamp 45- 8
A128 5875 Clamp 45- 29
A128 5875 Clamp 47- 26
A128 5876 Clamp 15- 19
A128 5876 Clamp 17- 11
A128 5876 Clamp 23- 35
A128 5876 Clamp 25- 18
A128 5876 Clamp 49- 19
A128 5876 Clamp 51- 5
A128 6058 Small Cassette Cover (N R G) 19- 17
A128 6350 Model Name Plate - GER 7- 23
A128 6351 Front Side Fence (NR G ) 19- 3
A128 6362 Left Cover (NRG) 7- 1
A152 7662 Joint 29- 1
A157 2772 Paper Stripper Shaft 27- 5
A157 2773 Feed Roller Holder 27- 6
A157 2774 Feed Roller 27- 28
5053 0223 Bushing - 8mm 23- 7
5053 0223 Bushing - 8mm 25- 17
5053 0223 Bushing - 8mm 27- 17
5053 0223 Bushing - 8mm 45- 7
5203 1686 Screw - Slid Rail 47- 9
5203 4179 Cauti on Decal - High Temperatur e 43- 2
5203 4179 Cauti on Decal - High Temperatur e 57- 1
5203 9501 Grease 501 59- 5
5205 3103 Bushing - 6mm 23- 14
5205 3103 Bushing - 6mm 31- 12
5205 3103 Bushing - 6mm 31- 22
5215 1806 Pulley 13- 16
5215 1812 Lens Drive Pulley 13- 9

70

Part No.

Description

Page and
Index No.

Part No.

Descri p t ion

Page and
Index No

5215 2600 Upper Feed Guide Plate 23- 10
5215 2600 Upper Feed Guide Plate 25- 5
5215 2618 Feed Roller Hub 23- 5
5215 2620 Feed Roller 23- 4
5215 2621 Snap Ring - M6 23- 2
5215 2622 Upper Feed Shaft Bracket 23- 6
5215 3295 Hopper Filter 29- 6
5215 3303 Seal - Toner Supply Roller 29- 26
5216 1186 Rubber Foot 51- 14
5216 1374 Hinge Shaft - Platen Cover 9- 4
5420 9502 Test Chart - OS - A3 (100pcs/set) 59- 11
5420 9507 Digital Multimeter - Brckman 59- 8
5420 9516 Test Chart - OS - A3 (10pcs/set) 59- 10
5442 1702 Small Screw - M3 51- 18
5442 2069 Pl asti c Scr ew - Main Corona 33- 13
5442 2107 Spring 47- 30
5442 2108 Corona Wire Spring 33- 7
5442 2108 Corona Wire Spring 39- 3
5442 2110 Plug - Corona Unit 33- 17
5442 9106 Drum Shoe 59- 6
5443 2668 Bushing - 4x6x7mm 23- 36
5446 3648 Stepped Screw - M4 37- 24
5447 2681 Snap Ring 27- 19
5447 9078 Heat R esist ing G r ease MT-78 59- 9
5447 9104 Shoe Adaptor 59- 7

0131 0300E Philips Pan Head Screw - M3x30 25-107
0313 0040W Philips Pan Head Screw - M3x4 25-106
0313 0040W Philips Pan Head Screw - M3x4 35-102
0313 0050W Philips Pan Head Screw - M3x5 31-104
0313 0050W Philips Pan Head Screw - M3x5 47-104
0313 0060W Philips Pan Head Screw - M3x6 37-103
0313 0120W Philips Pan Head Screw - M3x12 15-106
0313 0140W Philips Pan Head Screw - M3x14 11-103
0313 0300W Philips Pan Head Screw - M3x30 47-102
0314 0100W Philips Pan Head Screw - M4x10 35-103
0314 0200B Philips Pan Head Screw - M4x20 35-104
0315 0080M Philips Pan Head Screw - M5x8 49-103
0323 0060W Philips Sunken Head Screw - M3x6 23-106
0344 0060F Philips Truss Head Screw - M4x6 7-105
0344 0060F Philips Truss Head Screw - M4x6 19-102
0344 0100D Philips Truss Head Screw - M4x10 9-102
0353 0060F Philips Truss Head Screw - M3x6 7-101
0353 0060F Philips Truss Head Screw - M3x6 11-106
0413 0060W Tapping Screw - M3x6 13-107
0413 0060W Tapping Screw - M3x6 17-101
0413 0060W Tapping Screw - M3x6 35-101
0413 0060W Tapping Screw - M3x6 39-104
0413 0062W Tapping Screw - M3x6 19-103
0413 0062W Tapping Screw - M3x6 33-102
0413 0062W Tapping Screw - M3x6 37-102
0413 0082B Tapping Screw - M3x8 27-107
0413 0082F Bind Tapping Screw - M3x8 21-102
0413 0082W Tapping Screw - M3x8 7-103
0413 0082W Tapping Screw - M3x8 11-104
0413 0082W Tapping Screw - M3x8 13-101
0413 0082W Tapping Screw - M3x8 23-107
0413 0082W Tapping Screw - M3x8 29-104
0413 0082W Tapping Screw - M3x8 33-101
0413 0082W Tapping Screw - M3x8 37-106
0413 0082W Tapping Screw - M3x8 39-102

71

Part No.

Description

Page and
Index No.

Part No.

Descri p t ion

Page and
Index No

0413 0082W Tapping Screw - M3x8 43-104
0413 0082W Tapping Screw - M3x8 51-103
0414 0082F Philips Truss Head Screw - M4x8 19-106
0414 0102F Tapping Screw - M4x10 21-101
0414 0102F Tapping Screw - M4x10 31-102
0414 0102F Tapping Screw - M4x10 51-102
0434 0060W Tapping Screw - M4x6 23-101
0434 0060W Tapping Screw - M4x6 31-107
0434 0080W Tapping Screw - M4x8 23-108
0443 0060W Hexagon Head Tapping Screw - M3x6 7-102
0443 0060W Hexagon Head Tapping Screw - M3x6 11-105
0443 0060W Hexagon Head Tapping Screw - M3x6 13-105
0443 0060W Hexagon Head Tapping Screw - M3x6 15-104
0443 0060W Hexagon Head Tapping Screw - M3x6 17-102
0443 0060W Hexagon Head Tapping Screw - M3x6 19-101
0443 0060W Hexagon Head Tapping Screw - M3x6 23-102
0443 0060W Hexagon Head Tapping Screw - M3x6 25-101
0443 0060W Hexagon Head Tapping Screw - M3x6 27-104
0443 0060W Hexagon Head Tapping Screw - M3x6 39-101
0443 0060W Hexagon Head Tapping Screw - M3x6 41-103
0443 0060W Hexagon Head Tapping Screw - M3x6 45-102
0443 0060W Hexagon Head Tapping Screw - M3x6 47-101
0443 0060W Hexagon Head Tapping Screw - M3x6 49-101
0443 0060W Hexagon Head Tapping Screw - M3x6 51-101
0443 0080W Hexagon Head Tapping Screw - M3x8 27-105
0443 0080W Hexagon Head Tapping Screw - M3x8 47-103
0633 0120E Spring Pin - M3x12 45-106
0705 0050Z Toothed Washer - M5 25-104
0705 0050Z Toothed Washer - M5 49-104
0720 0025E Retaining Ri ng - M2.5 9-101
0720 0025E Retaining Ri ng - M2.5 23-105
0720 0025E Retaining Ri ng - M2.5 27-102
0720 0030E Retaining Ri ng - M3 21-105
0720 0030E Retaining Ri ng - M3 23-104
0720 0030E Retaining Ri ng - M3 27-103

0720 0030E Retaining Ri ng - M3 29-102
0720 0030E Retaining Ri ng - M3 43-102
0720 0040E Retaining Ri ng - M4 11-107
0720 0040E Retaining Ri ng - M4 13-106
0720 0040E Retaining Ri ng - M4 25-105
0720 0040E Retaining Ri ng - M4 31-101
0720 0040E Retaining Ri ng - M4 37-104
0720 0040E Retaining Ri ng - M4 41-104
0720 0040E Retaining Ri ng - M4 43-101
0720 0050E Retaining Ri ng - M5 11-101
0720 0050E Retaining Ri ng - M5 15-101
0720 0060E Retaining Ri ng - M6 23-103
0720 0060E Retaining Ri ng - M6 25-103
0720 0060E Retaining Ri ng - M6 27-101
0720 0060E Retaining Ri ng - M6 41-105
0720 0060E Retaining Ri ng - M6 45-101
0727 0090E Retaining Ri ng C - M9 31-105
0728 0040E Grip Ring - 4mm 29-101
0802 5085 Tapping Scr ew - M4x8 47-107
0805 0073 Retai ning R ing - M5 19-104
0805 0073 Retai ning R ing - M5 21-104
0805 0073 Retai ning R ing - M5 31-108
0805 0077 Retai ning R ing - M3 11-108
0805 0077 Retai ning R ing - M3 29-103
0805 3104 Bushing - 8x22x7 35-106
0805 3384 Bushing - 5mm 45-104
0805 3385 Bushing - 6mm 43-103
0805 3386 Bushing - 8mm 27-106
0805 3386 Bushing - 8mm 45-105
0805 3415 Ball Bearing - 9x20x6 31-106
0807 4127 Wave Washer 15-102
0951 3004B Philps Screw With Flat Washer -M3x4 35-107
0951 3004B Philps Screw With Flat Washer -M3x4 37-107
0951 3005W Philips Screw With Flat Washer-M3x5 39-103
0951 3006W Philips Screw With Flat Washer-M3x6 13-102

72

Part No.

Description

Page and
Index No.

Part No.

Descri p t ion

Page and
Index No

0951 3006W Philips Screw With Flat Washer-M3x6 15-108
0951 3006W Philips Screw With Flat Washer-M3x6 29-105
0951 3006W Philips Screw With Flat Washer-M3x6 37-105
0951 3006W Philips Screw With Flat Washer-M3x6 41-101
0951 3006W Philips Screw With Flat Washer-M3x6 47-110
0951 3006Z Philips Screw With Fl at Washer - M3 7-104
0951 3008B Philips Screw With Flat Washer-M3x8 37-101
0951 3008W Philips Screw With Flat Washer-M3x8 13-103
0951 3008W Philips Screw With Flat Washer-M3x8 15-103
0951 3008W Philips Screw With Flat Washer-M3x8 31-103
0951 3008W Philips Screw With Flat Washer-M3x8 41-102
0951 3010W Philipsscrew With Flat Washer-M3x10 45-103
0951 3010W Philipsscrew With Flat Washer-M3x10 51-104
0951 3012W Philips Screw With Flat Washer-M3x1 9-103
0951 3012W Philips Screw With Flat Washer-M3x1 15-107
0951 3020W Philips Screw With Flatwasher-M3x20 47-106
0951 4006W Philips Screw With Flat Washer-M4x6 25-102
0951 4006W Philips Screw With Flat Washer-M4x6 33-103
0951 4006W Philips Screw With Flat Washer-M4x6 49-102
0951 4008W Philips Screw With Flat Washer-M4x8 11-102
0951 4008W Philips Screw With Flat Washer-M4x8 13-104
0951 4008W Philips Screw With Flat Washer-M4x8 15-105
0951 4008W Philips Screw With Flat Washer-M4x8 47-105
0960 3030W Philips Flange Screw M3 X 30 17-103
0965 3008W Tapping Screw With Flat Washer-M3x8 21-103
0965 3008W Tapping Screw With Flat Washer-M3x8 43-105
0965 4010W Tapping Screw With Flat w asher- M4x10 19-105
0971 3006a Philips Polycarbonate Screw - M3x6 33-104
1102 2179 Connector - PIC - FS4 - T 55-101
1102 4201 ConneCtor - 2P 55-102
1102 4202 Connector - 3P 55-103
1102 4204 CT Header - 5P 55-104
1102 4205 CT Header - 6P 55-105
1102 4207 Connector - 8P 55-106
1102 4210 Connector - 11P 55-107

1102 4211 CT Header - 12P 55-108
1102 4619 Connector - 2P 55-109
1102 4628 Connector - 11P 55-110
1102 4629 Connector - 12P 55-180
1102 4631 CTConnector - 2P 55-111
1102 5007 CT Header - 14P 55-112
1102 5305 Connector - 6P 55-142
1103 1169 Connector - 6P 55-113
1103 1770 Connector - 4P 55-114
1103 1776 Pi n Header - 1OP 55-115
1104 0239 LSI Socket - 24P 55-182
1104 0598 l C - Socket 55-141
1107 0784 Fuse - 6.3A 250V (230V) 49-105
1107 0797 Fuse - 16A 250V (115V) 49-105
1204 1372 Locking Support 55-140
1204 1576 M ain Switch 47-108
1204 2334 Safety Switch - FA1L-AA20 47-109
1400 0369 Transistor - 2SA1213Y 55-135
1401 0869 Transistor - Array - TD62003F 55-116
1402 0277 Zener Diode - 1Z12 55-136
1402 0476 Diode - ISS184 55-137
1402 0478 Diode - 1SS226TE85L 55-181
1407 1535 l C - TD62308AP 55-117
1407 2055 l C - T062304F 55-118
1407 2080 l C - SN74LS21NS 55-130
1407 2187 I C - SN74LS07NS 55-129
1407 2230 I C - T06F62303F 55-119
1407 2412 I C - SN74LS32M 55-131
1407 2413 I C - SN74LSI38M 55-132
1407 3322 I C - MC74HC04AF 55-134
1407 3381 I C - 74HC4066A 55-120
1407 3533 I C - 74HC241A 55-121
1407 4136 I C - UPD7831 55-122
1407 4234 I C - SN74LS373M 55-133
1407 4286 IC - MK48Z52B - 15 55-127

73

Part No.

Description

Page and
Index No.

Part No.

Descri p t ion

Page and
Index No

1407 4315 I C - TE7751 55-123
1408 0398 I C - NJ2903M 55-128
1408 0598 I C - MB3773PF 55-124
1503 0071 0sicillat or - 12Mhz 55-125
1602 0987 Capacitor&Coil - 270PF 100V 55-138

1604 5478 Capacitor - 0.47µF ±20% 50V 55-179
1605 0343 Capacitor - 30PF ±5% 50V 55-171

1605 0596 Capacitor - 100PF 55-172
1605 0636 Capacitor - 0.1µF 55-173
1606 1139 Capacitor - 0.01µF ±20% 55-174

1606 1455 Capacitor - 470PF 25V 55-175
1607 0491 Capacitor - BL03RN2 - R6 55-139

1630 2101 Resistor - 100 Ω 1/8W 55-143
1630 2102 Resistor - 1K Ω 1/8W ±5% 55-144
1630 2103 Resistor - 10K Ω 1/8W 55-145
1630 2104 Resistor - 100K Ω 1/8W ±5% 55-146
1630 2106 Resistor - 10M Ω 1/8W 55-147
1630 2123 Resistor - 12K Ω 1/8W ±5% 55-148
1630 2152 Resistor - 1.5K Ω 1/8W ±5% 55-149
1630 2154 Resistor - 150K Ω ±5%1/8W 55-150
1630 2204 Resistor - 200K Ω ±5%1/8W 55-151
1630 2222 Resistor - 2.2K Ω I/8W 55-152
1630 2223 Resistor - 22K Ω 1/8W ±5% 55-153
1630 2243 Resistor - 24K Ω 1/8W ±5% 55-154
1630 2272 Resistor - 2.7 Ω ±5%1/8W 55-155
1630 2273 Resistor - 27K Ω 1/8W 5% 55-156
1630 2301 Resistor - 300 Ω 1/8W 5% 55-157
1630 2302 Resistor - 3K Ω I/8W 5% 55-158
1630 2394 Resistor - 390K Ω 1/8W ±5% 55-159
1630 2472 Resistor - 4.7K Ω 1/8W ±5% 55-160
1630 2473 Resistor - 47K Ω 1/8W ±5% 55-161
1630 2513 Resistor - 151 Ω 1/8W ±5% 55-162
1630 2561 Resistor - 560 Ω ±5%1/8W 55-163

1630 2622 Resistor - 6.2K Ω 1/8W 5% 55-164
1630 2681 Resistor - 680 Ω 1/8W ±5% 55-165
1630 2824 Resistor - 820 Ω 1/8W ±5% 55-166
1632 1001 Resistor - IK Ω ±1% 1/8W 55-167
1632 1002 Resistor - 10.OK Ω 1/8W ±1% 55-168
1632 1301 Resistor - 1.3K Ω ±1% 1/8W 55-169
1632 3901 Resistor - 3.9K Ω 1/8W ±1% 55-170
1640 2101 Capacitor - 100µF ±20% 25V 55-176
1640 2470 Capacitor - 47µF ±20% 25V 55-177
1640 5109 Capacitor - 1µF ±20% 50V 55-178

1905 0009 I C - 1M X8 150NS 55-126

74
