Ricoh FT4015 PARTS CATALOG FT4018PC



PARTS CATALOG

First Edition September 1997

Ricoh Company,LTD.

PARTS CATALOG

INTRODUCTION

This chapter i nst r uct s you the numbers and n am es of parts on this ma chi ne.

INDEX to PARTS CATALOG

GRAND KINGFISHER (A245)



PARTS CATALOG

INTRODUCTION

This chapter ins tr ucts you the numbers and names of parts on th i s m achine.

INDEX to PARTS CATALOG

LOCATION OF UNIT ........................................................... 2

1.EXTERIOR (A245) ........................................................... 6

2.PLATEN COVER (A245).................................................. 8

3.OPERATION PANEL (A245)............................................ 10

4.PAPER TRAY (A245)............... .................. .................. .... 12

5.BY-PASS FEED TABLE (A245)....................................... 14

6.PAPER FEED SECTION 1 (A245)................................... 16

7.PAPER FEED SECTION 2 (A245)................................... 18

8.PAPER REGISTRATION (A245) ..................................... 20

9.OPTICS SECTION 1 (A245) ............................................ 22

10.OPTICS SECTION 2 (A245) ........................................... 24

11.OPTICS SECTION 3 (A245) ........................................... 26

12.TONER BOTTLE HOLDER UNIT (A245)........................ 28

13.IMAGING UNIT - 1 (A245)............................................... 30

14.IMAGING UNIT - 2 (A245)............................................... 32

15.LOWER OPTICS SECTION (A245)................................ 34

16.FUSING UNIT (A245)...................................................... 36

17.TRANSFER AND EXIT SECTION (A245)....................... 38

18.DRIVE SECTION 1 (A245).............................................. 40

19.DRIVE SECTION 2 (A245).............................................. 42

20.ELECTRICAL SECTION 1 (A245)................................... 44

21.ELECTRICAL SECTION 2 (A245)................................... 46

22.FRAME SECTION (A245) ............................................... 48

23.MAIN CONTROL BOARD (A245) ................................... 50

24.DECAL AND DOCUMENT (A245) .................................. 54

25.SPECIAL TOOLS (A245)... ... ................................. ......... 56

PARTS INDEX ..................................................................... 59

September ,30 ’97

LOCATION OF UNIT

1.EXTERIOR (A245)

See Page 7

4.PAPER TRAY (A245)

2.PLATEN COVER (A245)

See Page 9

5.BY-PASS FEED TABLE (A245)

3.OPERATION PANEL (A245)

See Page 11

6.PAPER FEED SECTION 1 (A245)

See Page 13

See Page 15

2

See Page 17

LOCATION OF UNIT

7.PAPER FEED SECTION 2 (A245)

See Page 19

10.OPTICS SECTION 2 (A245)

8.PAPER REGISTRATION (A245)

See Page 21

11.OPTICS SECTION 3 (A245)

9.OPTICS SECTION 1 (A245)

See Page 23

12.TONER BOTTLE HOLDER UNIT (A245)

See Page 25

See Page 27

3

See Page 29

LOCATION OF UNIT

13.IMAGING UNIT - 1 (A245)

See Page 31

16.FUSING UNIT (A245)

14.IMAGING UNIT - 2 (A245)

See Page 33

17.TRANSFER AND EXIT SECTION (A245)

15.LOWER OPTICS SECTION (A245)

See Page 35

18.DRIVE SECTION 1 (A245)

See Page 37

See Page 39

4

See Page 41

LOCATION OF UNIT

19.DRIVE SECTION 2 (A245)

See Page 43

22.FRAME SECTION (A 245)

20.ELECTRICAL SECTIO N 1 (A245)

See Page 45

21.ELECTRICAL SECTION 2 (A245)

See Page 47

See Page 49

5

1.EXTERIOR (A245)

6

1.EXTERIOR (A245)

Index
No.

1 A245 1270 Front Cover Ass‘y (RIC) 1
1 A219 6070 Front Cover Ass‘y (NRG) 1
1 A245 6470 Front Cover Ass’y (SVN) 1
1 A245 6270 Front Cover Ass’y (INF) 1
2 A153 1285 Emblem (RIC/NRG) 1
2 A156 6413 Emblem (SVN) 1
2 A153 6423 Support Cover (INF) 1
3 C225 2867 Decal - Cover - Panel (NSA) 1
3 C225 2866 Decal - key Top Cover (REX) 1
3 A153 6409 Decal - key Top Cover (GES) 1
4 A153 1354 Hinge Pin 2
5 A219 1284 Operation Guide Sheet 1
6 A190 1282 Magnet Catch 1
7 A190 1287 Front Lower Cover 1
8 A190 1337 Inner Cover 1
9 AG07 0004 Magnetic Catch 2
10 G020 2677 Support - Paper Tray - Left 1
11 A245 1450 Operation Panel Ass‘y - LT (RI C / N RG ) 1
11 A245 1451 Operation Panel Ass’y - A4 1
11 A245 1452 Operation Panel Ass’y -LT ( SVN ) 1
12 A190 1260 Upper Cover 1
13 AC01 2042 Exposure Glass 1
14 A190 1655 Scale - A4 1
15 AA14 3070 Shoulder Screw - M2x2 2
16 A245 1305 Left Lower Cover 1
17 A190 1300 Left Upper Cover 1
18 A126 4460 Slide Copy Tray 1
19 A126 4470 Copy Tray Guide 1
20 A126 4400 Copy Tray 1
21 A245 6182 Model Name Plate - GES 1
21 A245 6184 Model Name Plate - NSA 1
21 A245 6186 Model Name Plate - REX 1
21 A219 6186 Model Name Plate - GENERIC 1
22 A245 1330 Rear Cover 1
23 A190 1290 Rear Right Cover 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

24 A190 1297 Right Lower Cover 1
25 A190 1295 Front Right Cover 1
26 A190 1283 Magnet Catch 1

101 0452 3008Z Bind Tapping Scr ew - M3x8
102 0353 0060B Philips Pan Head Screw - M3x6
103 0434 0102W Tapping Screw - M 4x10
104 0451 3014B Tapping Screw - M3-14
105 0452 3010Z Bind Tapping Scr ew - 3x10
106 0451 3006B Tapping Screw - M3x6

Part No.

Description

Q’ty Per
Assembly

7

2.PLATEN COVER (A245)

8

2.PLATEN COVER (A245)

Index
No.

1 A219 1391 Platen Cover 1
2 AA14 3424 Knob Screw - M4x8 2
3 A190 1856 Platen Cover Bracket 1
4 A193 1246 Platen Cover Hinge Ass‘y 1

5 AA16 2067 Platen Cover Pad 1

6 5448 2804 Platen Cover Sheet 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0414 0142B Binding Self Tapping Screw - M4x14

Part No.

Description

Q’ty Per
Assembly

9

3.OPERATION PANEL (A245)

10

3.OPERATION PANEL (A245)

Index
No.

* A245 1450 Operation Panel Ass‘y - LT (RIC/NRG) 1
* A245 1451 Operation Panel Ass’y - A4 1
* A245 1452 Operation Panel Ass’y - LT (SVN) 1
1 A219 1461 Operation Panel Cover 1
2 A245 1461 Indication Sheet - LT (RIC/NRG) 1
2 A245 1462 Indication Sheet - A4 1
2 A245 1463 Indication Sheet - LT (SVN) 1
3 A219 1463 Operation Panel Sheet 1
3 A219 1476 Operation Panel Sheet - LT (SVN) 1
4 A190 1452 Keytop - Start (RIC/NRG) 1
4 A219 1471 Keytop - Start (SVN) 1
5 A190 1453 Keytop - Clear/Stop (RIC/NRG) 1
5 A219 1472 Keytop - Clear/Stop (SVN) 1
6 A190 1454 Keytop - Clear Mode (RIC/NRG) 1
6 A219 1473 Keytop - Clear Mode (SVN) 1
7 A190 1455 Keytop - 10keys (RIC/NRG) 1
7 A219 1474 Keytop - 10keys (SVN) 1
8 A219 1464 Operation Panel Board 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

Part No.

Description

Q’ty Per
Assembly

11

4.PAPER TRAY (A245)

12

4.PAPER TRAY (A245)

Index
No.

* A245 2551 Paper Tray Ass’y - LT 1
* A245 2552 Paper Tray Ass’y - A4 1
1 G020 2647 Paper Tray Cover 1
2 G020 2668 Sheet - Paper Set 1
3 A190 2692 Decal - Paper Tray Operation 1
4 G020 2593 Paper Size Sensor - LT 1
4 G020 2595 Paper Size Sensor - A4 1
5 G020 2663 Paper Size Actuator 1
6 G020 2648 Holder - Paper Size Detector 1
7 G020 2592 Release Lever - Bottom Plate 1
8 G020 2599 Spring - Release Lever 1
9 A190 2812 Stopper Cover 1
10 A190 2810 Cassette Stopper 1
11 G020 2567 Rear Side Fence 1
12 G020 2558 Rear Corner Separator 1
13 A157 2769 Rear Stopper Spring 2
14 A190 2642 Rear Lever Stopper 1
15 G020 2557 Tray Bottom Plate 1

16 G020 2645 Friction Pad 1

17 G020 2656 Pressure Spring - Bottom Pl at e 2
18 G020 2658 Grounding Plate - Bottom Plate 1
19 AB01 3868 Gear - 16Z 1
20 G020 2644 End Fence 1
21 G020 2573 Front Paper Separator 1
22 A190 2561 Side Fence Rack 1
23 G020 2664 Front Stopper Lever 1
24 A190 2560 Front Side Fence 1
25 A190 2690 Decal - 1st Paper Tray 1
25 A190 2691 Decal - 2nd Paper Tray 1
26 G020 2661 Bottom Plate Ass’y 1
27 A193 2660 Paper Separator Cushion 2
28 A219 2696 Decal - Size Selection 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0450 3008B Tapping Screw - M3x8
102 0452 3008B Tapping Screw - M3x8
103 0413 0082W Tapping Screw - M 3x8
104 0451 3006B Tapping Screw - M3x6

Part No.

Description

Q’ty Per
Assembly

13

5.BY-PASS FEED TABLE (A245)

14

5.BY-PASS FEED TABLE (A245)

Index
No.

* A190 2700 By-pass Feed Unit 1
1 G020 2735 Guide - By-pass Feed Ta ble 2
2 A190 2707 Side Fence Rack 2
3 A190 2701 By-pass Feed Cover 1
4 A190 2708 Decal - By-pass Feed 1
5 G020 2786 Shaft - By-pass Release L ever 1
6 G020 2784 Lever - By-pass Feed Tabl e 1
7 5447 2681 Snap Ring 1
8 G020 2702 Pressure Spring - By-pass Feed 1
9 A190 2698 Support Cover - By-pass Feed 1
10 A190 2782 Bottom Plate Stay 1
11 A190 2705 Right Side Fence 1
12 G011 3305 Gear - 16T 1
13 A190 2702 Paper Guide 1
14 A190 2704 Bottom Plate - By-pass Feed 1
15 A190 2706 Left Side Fence 1
16 5215 2713 Bottom Plate Pad 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0453 3006Z Tapping Screw - M 3x6
102 0451 3006B Tapping Screw - M3x6

Part No.

Description

Q’ty Per
Assembly

15

6.PAPER FEED SECTION 1 (A245)

16

6.PAPER FEED SECTION 1 (A245)

Index
No.

1 A190 1139 Magnetic Clutch - Vertical 1
2 A219 3360 Toner Bottle Holder Guide - Ass’y 1

3 A190 3361 Toner Bottle Holder Guide 1
4 G020 2785 Cover - Feed Roller Shaft 1
5 A190 2771 Resist Sensor 1
6 A190 3363 Guide Seal - Toner Supply Unit 1
7 G020 2753 Bracket - Registration Senso r 1
8 A190 2772 Paper End Sensor 1
9 G020 2787 Cover - By-pass Paper End Sensor 1
10 A190 5344 Relay Harness - By-pa ss Feed 1
11 G020 2723 By-pass Feed Sha ft 1
12 G020 2587 Bushing - Paper Feed 1

13 G020 2721 By-pass Feed R o l l er 1

14 A190 2564 Relay Roller 1
15 G020 2586 Rear Pin - Paper Feed R ol ler 1
16 G020 2585 Front Pin - Paper Feed R ol l er 1
17 G020 2570 Shaft - Paper Feed Ro ll er 1
18 G020 2565 Paper Guide 4

19 G020 2555 Paper Feed Roller 2

20 A219 3364 Mylar Seal - 8x429 1
21 A219 3365 Mylar Seal - 8x400 1
22 G020 2554 Paper Feed Roller Ass’y 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0805 3480 Bushing - 6mm
102 0720 0040E Retaining Ring - M4
103 0451 3006B Tapping Screw - M3x6
104 0450 3008B Tapping Screw - M3x8

Part No.

Description

Q’ty Per
Assembly

17

7.PAPER FEED SECTION 2 (A245)

18

7.PAPER FEED SECTION 2 (A245)

Index
No.

1 G020 2587 Bushing - Paper Feed 1
2 A190 2902 Switch Lever 1
3 A245 5310 DC Harness 1
4 A190 2900 Switch Bracket 1
5 A190 2564 Relay Roller 1
6 G020 2585 Front Pin - Paper Feed Roller 1
7 G020 2586 Rear Pin - Paper Feed Roller 1
8 G020 2570 Shaft - Paper Feed Roller 1
9 G020 2565 Paper Guide 4

10 G020 2555 Paper Feed Roller 2

11 A190 1139 Magnetic Clutch - Vertical 1
12 A190 2611 Paper Guide Plate 1
13 G020 2613 Virtical Relay Gu i de 1
14 AF02 0283 Pressure Roller 4
15 G020 2577 Spring Plate - Driven Roller 8
16 G020 2630 Magnetic Cat ch 1
17 G020 2576 Guide - Vertical Tr ansport 1
18 A190 2905 Cushion 1
19 G020 2554 Paper Feed Roller Ass’y 1

20 A245 2610 Lower Paper Guide 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0805 3480 Bushing - 6mm
102 0720 0040E Retaining Ring - M4
103 0720 0030E Retaining Ring - M3
104 0451 3014B Tapping Screw - M3-14
105 0451 3006B Tapping Screw - M3x6
106 1204 235 6 Micro Switch - AM51612A531
107 0453 3008 B Bind Tapping Screw - M3X8

Part No.

Description

Q’ty Per
Assembly

19

8.PAPER REGISTRATION (A245)

20

8.PAPER REGISTRATION (A245)

Index
No.

1 G020 3888 Pin - Transfer Guide 1
2 A190 2780 Front Bushing 1
3 5447 2681 Snap Ring 2
4 G020 2743 Tension Spring 2
5 A190 2711 Friction Pad Stay 1
6 G020 2745 Lower Guide Plate - Regi st 1
7 A190 2783 Resist Roller Knob 1
8 A190 2740 Lower Registration Roller 1
9 A190 2781 Rear Bushing 1
10 G020 2712 Holder - By-pas s Feed Friction Pad 1
11 G020 2741 Upper Regist r ation Roller 1
12 G020 2765 Knob - Lower Transport Guide 1
13 G020 2745 Lower Guide Pl at e - Regist 1
14 AA06 0331 Release Spring 1
15 5053 0223 Bushing - 8mm 2
16 G020 2754 Upper Paper Guide 1
17 A190 2717 Friction Pad Guide 1

18 G020 2716 Friction Pad 1

19 A190 2714 Friction Pad Holder Ass‘y 1
20 G020 2713 Pressure Spring 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0451 3006B Tapping Screw - M3x6

Part No.

Description

Q’ty Per
Assembly

21

9.OPTICS SECTION 1 (A245)

22

9.OPTICS SECTION 1 (A245)

Index
No.

1 A190 1660 Scanner Guide Rail 1
2 A111 1753 Seal - 0.1x18x49 1
3 AC06 3001 White Reference Plate 1
4 AW02 0075 Photointerrupter 1
5 A190 1651 Left Scale Support Plate 1
6 A190 1652 Exposure Glass Seal 4
7 AW10 0033 Thermistor 1
8 A190 1815 2nd/3rd Mirror 2
9 A077 1690 Spring Plate - Mirror 4
10 A190 1691 2nd Scanner Frame 1
11 A069 1883 Shoe - Scanner 1
12 A190 1694 Shoe Bracket 1
13 A190 1824 2nd Scanner Support Plate 1
14 A190 1751 Harness Guide Pulley Ass‘y 1

15 A190 1821 Harness Guide Pulley 1
16 A190 1688 Bushing 2
17 A190 1692 2nd Scanner Support Plate 1
18 A190 1689 Clamp 1
19 A245 1700 1st Scanner Unit - 120V 1
19 A245 1701 1st Scanner Unit - 230V 1
20 A190 1725 Bushing 1
21 A219 1194 ADF Bracket 1
22 A190 1814 Scanner Guide Rod 1
23 A190 1654 Right Bracket - Exposure Glass 1
24 A184 1672 Thermofuse - 128 1
25 A219 1197 Rear Bracket - ADF 2
26 A245 1740 1st Scanner Cushion 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 1105 0310 Wire Clamp
102 0451 3006B Tapping Screw - M3x6
103 0353 0060B Philips Pan Head Screw - M3x6
104 0720 0040E Retaining Ring - M4
105 0453 3006Z Tapping Screw - M3x6

Part No.

Description

Q’ty Per
Assembly

23

10.OPTICS SECTION 2 (A245)

Option

24

10.OPTICS SECTION 2 (A245)

Index
No.

1 A190 1816 Timing Belt - L1110P2M 1
2 A190 1666 Pulley Bracket 1
3 A190 1819 1st Scanner Spring 1
4 AX40 0052 Anti-Condensation Heater - 1 15V 18W 1
(Option)
4 AX40 0053 Anti-Condensation Heater - 2 40V 18W 1
(Option)
5 A190 1812 Blue Filter 1
6 A190 1682 Lens Caridge 1
7 A190 1698 Shielding Plate 1
8 AC02 0077 Lens - F8/180 1
9 A19 0 1683 Shading P late 1
10 A190 1684 Shielding Plate 1
11 A111 1753 Seal - 0.1x18x49 1
12 A190 1693 Lens Cover 1
13 A190 1813 Timing Belt - L824P2M 1
14 A190 1663 Lens Guide Rail 1
15 A190 1818 2nd Scanner Spring 1
16 A190 1664 Pulley Bracket 1
17 A190 1685 Lens Cover Bracket 1
18 A190 1669 Lens Support Bracket 1
19 A184 5205 Scanner Motor - DC24V 96W 1
20 A190 1696 Motor Bracket 1
21 A190 1820 Lens Holder Spring 1
22 A190 1803 Timing Puley - 22Z/44Z 1
23 A190 1817 Timing Belt - L754P2M 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0451 3006B Tapping Screw - M3x6
102 0450 3010B Tapping Screw - M3x10
103 0701 0030B Flat Washer - M3
104 0720 0060E Retaining Ring - M6
105 0450 3006B Tapping Screw - M3x6

Part No.

Description

Q’ty Per
Assembly

25

11.OPTICS SECTION 3 (A245)

26

11.OPTICS SECTION 3 (A245)

Index
No.

1 A190 1672 Lens Drive Motor Ass‘y DC24V 81.6W 1
2 A190 1671 Mirror Drive Motor Ass‘y DC24V 81.6W 1
3 A152 5120 Optics Control Board 1
4 A077 1745 Cover - ADS Sensor 1
5 AW02 0075 Photointerrupter 2
6 A190 1811 4th/5th Mirror 2
7 A190 1676 Rod Bracket 1
8 A190 1802 Timing Pulley - 30Z 1
9 A190 1810 Mirror Guide Rod 1
10 A190 1679 Mirror Sensor Shuter 1
11 A190 1678 3rd Scanner Brakcet 1
12 A153 1906 Adjust Shoe 1
13 AA06 3523 Adjust Spring 1
14 A077 1690 Spring Plate - Mirror 6
15 A190 1809 6th Mirror 1
16 A190 5343 Scanner H.P Harness 1
17 AB01 7361 Gear - 24Z/56Z 1
18 A190 1827 Rack Gear 1
19 A190 1825 3rd Scanner Support Plate 1
20 AB01 7129 Gear - 20Z AND 72Z 1
21 A077 1746 Mirror Adjusting Screw 1
22 A190 1675 6th Mirror Bracket - Rear 1
23 AA06 3180 Adjust Spring 1
24 A190 1674 6th Mirror Bracket - Front 1
25 A190 1831 Shield heater Rear 1
26 AA15 0234 Mylar Seal - Base 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0450 3006B Tapping Screw - M3x6
102 0353 0060B Philips Pan Head Screw - M3x6
103 0451 3006B Tapping Screw - M3x6
104 1105 0328 Harness Clamp - ES-0505
105 0720 0040E Retaining Ring - M4
106 0951 3006B Philips Screw With Flat Washer-M3x6
107 1105 0008 Nylon Clamp - 2n

Part No.

Description

Q’ty Per
Assembly

27

12.TONER BOTTLE HOLDER UNIT (A245)

28

12.TONER BOTTLE HOLDER UNIT (A245)

Index
No.

* A219 3030 Toner Supply Unit - 115V (RIC-NA) 1
* A219 3034 Toner Supply Unit - 230V (RIC-EU) 1
* A219 3036 Toner Supply Unit (Others) 1
1 A219 3311 Toner Collection Cover 1
2 A219 3342 Lower Seal - Tonner Collecti on C over 1
3 G020 3345 Right Seal 1
4 G020 3313 Spring 1
5 A219 3317 Toner Adding Shutter 1
6 A219 3312 Toner Adding Gate 1
7 A184 3422 Toner Slider 1
8 A219 3339 Toner Bottle Holder Lever 1
9 A219 3314 Toner Supply Unit Case (RIC-NA) 1
9 A219 3411 Toner Supply Unit Case (RIC-EU) 1
9 A219 3416 Toner Supply Unit Case (Others) 1
10 A219 3384 Spring Plate 1
11 A184 3411 Chuck Spring 1
12 G020 3334 Slide r Ass‘y 1

13 G020 3326 Cushion 1
14 A219 3322 Toner Bottle Cover 1
15 A219 3325 Mylar Blade 2
16 A184 3421 Chuck Shaft 1
17 A184 3420 Bottle Chuck 1
18 A219 3381 Roller 1
19 A219 3382 Upper Cover 1
20 A219 3383 Lower Cover 1
21 A219 3319 Sheet - Toner Supply Shutter 1
22 A219 3341 Cushion - Toner Collection Cover 2
23 A219 3385 Sheet - Roller Cover 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0452 3006B Tapping Screw - M3x6

Part No.

Description

Q’ty Per
Assembly

29

13.IMAGING UNIT - 1 (A245)

30

13.IMAGING UNIT - 1 (A245)

Index
No.

* A219 2205 Imaging Unit 1
1 A190 2280 Front Side Plate 1
2 A190 2011 Charge Corona Unit 1

3 A190 2060 Charge Corona Gr i d 1
4 A190 2065 Charge Corona Wire 1

5 A190 2085 Front Endblock Cover 1
6 A219 3132 Development Cover 1
7 A190 2062 Spring Plate - Charge Corona Grid 1
8 A190 2075 Cleaning Shaft 1
9 A190 2116 Rear Shielding Plate 1
10 A190 2105 Corona Wire Terminal 1
11 A190 2086 Rear Endblock Cover 1

12 A190 2070 Corona Wire Cleaner Ass‘y 1

13 A190 2320 Knob Screw 1
14 A184 3863 Corona Wire Spring 1
15 A190 3094 Development Entrance Seal 1
16 A190 3152 Gear - 18Z 1
17 A190 3155 Idle Gear - 17Z 2
18 A190 3166 Rear Seal 1
19 A190 3167 Front Seal 1
20 G020 2327 Pressure Spring 1
21 A190 3171 Imaging Unit Shutter 1
22 A190 3165 Long Seal 1
23 A190 3162 Imaging Unit Upper C ase 1
24 A190 2290 Rear Side Plate 1
25 A190 3156 Cam Gear 1
26 A190 3050 Development Roller Ass‘y 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0353 0060B Philips Pan Head Screw - M3x6
102 0452 3006B Tapping Screw - M3x6

Part No.

Description

Q’ty Per
Assembly

31

14.IMAGING UNIT - 2 (A245)

32

14.IMAGING UNIT - 2 (A245)

Index
No.

1 A190 3564 Toner Cap 1
2 A184 3611 Toner Recycle Belt 1
3 A190 3563 Toner Recycle Roller 2
4 A190 3569 Recycle Roller Bushing 1
5 A190 3112 1st Agitator 1
6 A190 3153 Transfer Auger Gear 2
7 A190 3116 2nd Agitator 1
8 A190 3125 Busing 4
9 A190 3183 Harness Holder 1
10 A190 3560 Toner Collection Coil 1
11 A048 2276 Ring - Transport Bracket 5
12 G020 2355 Transport Guide Shaft 5
13 G020 3565 Grounding Plate 1
14 A190 3570 Cleaning Entrance Seal 1
15 A184 2455 Toner Density Sensor 1

16 A219 9510 OPC Drum 1

17 A190 5346 Development Unit Harness 1
18 A190 3568 Rear Bushing 1
19 G020 3571 Toner Corre ct i on G ear - 14/24Z 1

20 A190 3550 Cleaning Blade 1

21 A190 2330 Toner Recycle Cover 1
22 A190 3128 Seal 6mm 4
23 A190 3192 Lower Seal - 3 x 6 x 396 1
24 G020 1923 CS Ring - M2.4 2
25 A190 3193 Seal - 5x55 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0353 0060B Philips Pan Head Screw - M3x6
102 0452 3006B Tapping Screw - M3x6

Part No.

Description

Q’ty Per
Assembly

33

15.LOWER OPTICS SECTION (A245)

34

15.LOWER OPTICS SECTION (A245)

Index
No.

1 A190 1042 Front Lever Bracket 1
2 A190 1041 Front Door Switch Lever 1
3 5206 2684 Shoulder Screw - M3 4
4 AA06 3489 Spring - 45mm 1
5 A190 1164 Safety Switch Lever 1
6 A190 1160 Safety Switch Bracket 1
7 A190 1152 Guide Rail 1
8 A190 1151 Duct Cover 1
9 A190 1153 Duct 1
10 A190 1163 Drive Release Wire 1
11 A190 1131 Drive Gear Joint Brac ket 1
12 G020 1157 Gear - 28Z 1
13 A190 1132 Gear - 32Z 1
14 A190 1138 Spacer 1
15 A190 1136 Gear Shaft 1
16 A190 1134 Support Bracket 1
17 A422 1082 Pick-up Spring 1
18 A190 1043 Fusing Switch Lever 1
19 A190 1342 Front Lever Support Plate 1
20 A190 1345 Release Spring - Front Lever 1
21 A190 2020 Quenching Lamp U ni t 1
22 A190 1341 Front Door Lever 1
23 A190 1162 Safety Switch Arm 1
24 A190 1040 Front Safety Switch Arm 1
25 A190 2030 Erase Lamp Unit 1
26 AA14 3716 Stepped Screw 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0451 3006B Tapping Screw - M3x6
102 0720 0030E Retaining Ring - M3
103 1204 2334 Interlock Switch - Fa1l
104 1105 0199 Clamp

Part No.

Description

Q’ty Per
Assembly

35

16.FUSING UNIT (A245)

36

16.FUSING UNIT (A245)

Index
No.

* A245 4023 Fusing Unit - 120V 1
* A245 4024 Fusing Unit - 230V 1
1 A190 4089 Stripper Pawl Bracket 1
2 A190 4053 Fusing Unit Knob 1
3 A190 4092 Stripper Pawl Spring 5

4 A184 4072 Stripper Pawl 5

5 A184 4105 Left Retaining Ring - 31 1
6 A190 4385 Antistatic Brush 1
7 A153 4087 Thermistor Holder 1
8 A190 4119 Thermistor 1
9 A190 4073 Fusing Stay 1
10 A219 4123 Thermofuse - 169°C 1

11 A190 4070 Fusing Unit Cover 1
12 A219 4117 Fusing Lamp - 115V 850W 1
12 A245 4120 Fusing Lamp - 230V 760W 1
13 A184 4081 Right Retaining Ring - 31 1
14 A190 4086 Hot Roller Bushing 2

15 A245 4100 Hot Roller 1

16 G020 4177 Gear - 40Z 1
17 G020 4175 Bushing - Pressure Roller 2

18 A245 4103 Pressure Roller 1

19 A245 4109 Pressure Spring 2
20 A245 4108 Pressure Roller Lever 2
21 A190 4129 Connector Bracket 1
22 A190 4121 Rear Heater Bracket 1
23 A190 4071 Fusing Entrance Guide 1
24 A190 4386 Antistatic Brush 1
25 A190 4120 Front Heater Bracket 1
26 A190 4076 Fusing Frame 1
27 A190 4088 Seal 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0451 3006B Tapping Screw - M3x6
102 0954 301 2B Screw - M3X12
103 0951 3006B Philips Screw With Flat Washer - M3x6

Part No.

Description

Q’ty Per
Assembly

37

17.TRANSFER AND EXIT SECTION (A245)

38

17.TRANSFER AND EXIT SECTION (A245)

Index
No.

1 A048 3860 Transport Bracket Holder 1
2 A190 4097 Idle Gear - 16Z 1
3 A190 4096 Idle Gear - 18Z 1
4 A245 4472 Lower Guide Plate 1
5 A190 4465 Exit Roller 1
6 A190 4471 Upper Guide Plate 1
7 AF04 0031 Upper Exit Roller 3
8 A190 4474 Exit Roller Holder 3
9 A190 4456 Exit Sensor Feeler Spring 1
10 A190 4455 Exit Sensor Feeler 1
11 AG07 0009 Magnetic Catch 2
12 A190 4479 Shielding Plate 1
13 A190 4478 Exit Cover 1
14 A19 0 4476 D ecal - High Temperat ure 1
15 A190 4463 Exit Roller Gear - 23Z 1
16 A190 3906 Spring Plate 3
17 A190 3905 Transfer Corona Rail 1
18 A190 3900 Transfer Guide 1
19 A190 3903 Transfer Release Guide 2
20 A190 3851 T/S Unit 1
21 A190 1073 Paper Exit Pin Bracket 1
22 A190 3880 Discharge Plate Unit 1
23 A190 3864 Rear End Block Cover 1

24 A190 3866 Transfer Corona Wire 1

25 A190 3863 Front Block Cover 1
26 A184 3863 Corona Wire Spring 1
27 AA06 3040 Spring 1
28 AA06 3036 Terminal Spring 1
29 A190 3890 T/S Corona Receptacle 1
30 A190 3914 Bushing 2
31 A190 3911 T/S Position Plate 1
32 G020 3912 Transport Lev er 1
33 A190 1085 Exit Rear Bracket 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0451 3006B Tapping Screw - M3x6
102 0720 0040E Retaining Ring - M4
103 0413 0082W Tapping Screw - M 3x8
104 0805 3480 Bushing - 6mm
105 0452 3008B Tapping Screw - M3x8
107 0720 0025E Retaining Ring - M2.5

Part No.

Description

Q’ty Per
Assembly

39

18.DRIVE SECTION 1 (A245)

40

18.DRIVE SECTION 1 (A245)

Index
No.

1 A190 1145 Release Spring 1
2 A190 1146 Tightner Ass‘y 1

3 A190 1149 Tightner Pulley 1
4 G020 1114 By-pass Feed Clutch 1
5 A190 1141 Timing Belt - SM699 1
6 AB03 0273 Timing Pulley - T20 1
7 A190 1122 Development Drive Bracke t 1
8 A245 1148 Timing pulley - 37Z 1
9 A190 1185 Development Drive Shaft 1
10 A219 1169 Gear - 40Z 1
11 G020 1130 Gear - 65Z/24 Z 1
12 A190 1144 Tightner Pulley 1
13 G020 1131 Gear - 58Z/35 Z 1
14 A190 1117 Support Plate - Drive Unit 1
15 5053 0223 Bushing - 8mm 1
16 G020 1132 Gear - 68Z 1
17 G020 1168 Gear - 52Z/26 T 1
18 G020 1115 Registration Clutch 1
19 A190 1182 Gear - 21Z/40Z 1
20 A190 1180 Pulley - 20Z/63Z 1
21 A190 1181 Timing Belt - S3M288 1
22 A190 1198 Development Bias Terminal 1
23 A190 1124 Tightner Spring 1
24 A190 1165 Tightner Bracket 1
25 A190 1112 Drive Bracket 1
26 A190 1125 Tightner Bracket 1
27 G020 1138 Pulley - 24T 1
28 A190 1128 Tightner Pulley 1
29 5446 1205 Release Spring 1
30 G020 1178 Pulley - 51T 1
31 G020 1187 Timing Belt - S2M 158MM 1
32 G020 1177 Gear - 26Z 1
33 A190 1118 Imaging Unit Drive Shaft 1
34 A190 1183 Pressure Spring 1
35 A190 1123 Development Driv e G ear 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

36 A190 1171 Imaging Unit Holder 1
37 A190 1174 Pressure Spring 1

101 0720 0040E Retaining Ring - M4
102 0805 3480 Bushing - 6mm
103 0720 0060E Retaining Ring - M6
104 0633 0120E Spring Pin - M3x12
105 0741 3808 Ball Bearing - 8x16x5mm
106 0451 3006B Tapping Screw - M3x6
107 0451 3012B Tapping Screw With Washer - M3x12
108 0450 3006B Tapping Screw - M3X6

Part No.

Description

Q’ty Per
Assembly

41

19.DRIVE SECTION 2 (A245)

42

19.DRIVE SECTION 2 (A245)

Index
No.

1 G020 1112 Paper Feed Clutch 2
2 G020 1145 Shaft - Paper Feed Roller 2
3 AA08 0111 Bushing - 8x12x7 4
4 5447 2681 Snap Ring 2
5 G020 1144 Gear - 27Z 1
6 A190 1176 Paper Feed Drive Unit 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0451 3006B Tapping Screw - M3x6
102 1105 0199 Clamp
103 1105 0310 Wire Clamp

Part No.

Description

Q’ty Per
Assembly

43

20.ELECTRICAL SECTION 1 (A245)

44

20.ELECTRICAL SECTION 1 (A245)

Index
No.

1 A190 1195 Right Harness Cover 2
2 AX64 0058 Fan Motor - DC 24V 4.32W 1
3 A190 1192 Main Switch Bracket 1
4 A152 5220 Main Switch 1
5 A190 5150 High Voltage Supply Board 1
6 A245 5120 Main Control Board - 120V 1
6 A245 5100 Main Control Board - 230V 1
7 A245 5310 DC Harness 1
8 A190 5301 AC Main Harness - 120V 1
8 A245 5301 AC Main Harness - 230V 1
9 A219 5551 AC Drive DC Power Supply Board-120V 1
9 A245 5651 AC Drive DC Power Supply Board-230V 1
10 A190 5335 DC Power Harness 1
11 A184 5344 Scanner Grounding Harness 1
12 A245 1111 DC Motor 28W 1
13 A190 1155 Duct Bracket 1
14 A184 5225 Exhaust Fan Motor - DC24V 3.6W 1

15 A190 1157 Ozone Filter 1

16 A190 1156 Ozone Filter Cap 1
17 A219 5552 Transformer - 120V 1
17 A219 5652 Transformer - 230V 1
18 A245 1190 Power Cord Bracket 1
19 A219 5581 Power Supply Cord - 120V 1
19 A219 5681 Power Supply Cord - 230V 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 1105 0199 Clamp
102 1105 0413 Harness Clamp
103 1105 0310 Wire Clamp
104 0313 0300W Philips Pan Head Screw - M3x30
105 0451 3006B Tapping Screw - M3x6
106 0450 4030B Tapping Screw - M4x30
107 1107 0485 Fuse (ceramic Case) - 15A - 125V
107 1107 0885 Fuse - 6.3A 250V
108 1107 0855 Fuse - 8A 125V
108 1107 0885 Fuse - 6.3A 250V
109 1107 087 2 Fuse - 3.15A 125V
109 1107 088 3 Fuse - 3.15A 250V
110 1107 0868 Fuse - 5A 125V
110 1107 0883 Fuse - 3.15A 250V

Part No.

Description

Q’ty Per
Assembly

45

21.ELECTRICAL SECTION 2 (A245)

46

21.ELECTRICAL SECTION 2 (A245)

Index
No.

1 A190 1286 Front Cover Hing Bracket 1
2 AX31 0024 Total Counter 1
3 A190 2671 Paper Size Switch Bracket 1
4 A190 2684 Guard - Paper Tray Stopper 2
5 A190 2620 Push Switch - Paper Size 2
6 A190 2680 Paper Tray Stopper 2
7 A190 4484 Antistatic Brush 1
8 A190 1045 Safety Switch Stay 1
9 AW02 0075 Photointerrupter 2
10 A190 5345 Exit Sensor Harness 1
11 A190 1048 Fusing Lever Cover 1
12 A190 1186 Main Board Bracket 1
13 A190 1191 By-pass Feed Cover 1
14 A190 1187 High Voltage Supply Board Bracket 1
15 AA06 3249 Grid Terminal Spring 2
16 A190 2040 Transfer Corona Wire Receptacle 1
17 A190 1193 Connector Bracket 1
18 G020 5829 Shoulder Screw - M3x2.5 2
19 A190 5335 DC Power Harness 1
20 A190 5145 Development Relay Board 1
21 G020 2622 Release Arm - Paper End Feeler 2
22 G020 2626 Release Sprin g - Pap er End Feeler 2
23 A190 2801 Tray Stopper Bracket 2
24 G020 2580 Paper End Sensor Bracket 2
25 5447 2681 Snap Ring 2
26 G020 2581 Paper End Feeler 2
27 A190 2805 Roller Holder 2
28 AA06 3206 Spring - Front Side Fence 2
29 A219 3373 Seal - 2x15x95 1
30 A219 3371 DC Motor - 3.36W 1
31 A190 1197 Front Seal - By-pass Feed 1
32 A190 1196 Upper Seal - By-pass Feed 1
33 A219 3372 Motor Bracket 1
34 A190 5335 DC Power Harness 1
35 A219 5319 Toner Motor Harness 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 1105 0290 Harness Clamp - Horizonta l
102 1105 0329 Clamp - ES-0510
103 0451 3006B Tapping Screw - M3x6
104 1105 0199 Clamp
105 0720 0030E Retaining Ring - M3
106 0720 0040E Retaining Ring - M4
107 0450 3008B Tapping Screw - M3x8
108 1105 0413 Harness Clamp

Part No.

Description

Q’ty Per
Assembly

47

22.FRAME SECTION (A245)

Option

Option

48

22.FRAME SECTION (A245)

Index
No.

1 A134 1071 Left Grip Plate 4
2 A190 1084 Front Right Grip Bracket 2
3 A134 1072 Right Bracket - Grip Plate 2
4 G020 2643 Front Grounding Plate - Paper Tray 2
5 G020 1052 Stand 4
6 A190 1076 Base Cover 1
7 G020 2650 Right Guide - Paper Tra y 1
8 A190 2825 Heater Bracket 2
9 AX40 0063 Anticondensation Heater - 120V 9W 1
(Option)
9 AX40 0064 Anticondensation Heater - 230V 9W 1
(Option)
10 A190 1080 Exit Stay 1
11 G020 2652 Middle Rail - Paper Tray 2
12 A190 1081 Stay - Paper End Sensor 1
13 G020 2655 Upper Front Gu ide - Paper Tray 2
14 G020 2654 Upper Rear Guide - Paper Tray 2
15 G020 1078 Right Sielding Plat e 1
16 G020 1072 Fusing Uni t Gui de 1
17 A193 1074 Relay Harness Cover 1
18 G020 2678 Guide Plate - Paper Tra y 2
19 G020 2653 Left Rail - Paper T ra y 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0451 3006B Tapping Screw - M3x6
102 0451 3010B Tapping Screw - M3x10
103 0434 006 0B Pan Head Self-tapping Screw - M4x 6
104 1105 0199 Clamp
105 1105 0310 Wire Clamp

Part No.

Description

Q’ty Per
Assembly

49

23.MAIN CONTROL BOARD (A245)

50

23.MAIN CONTROL BOARD (A245)

51

23.MAIN CONTROL BOARD (A245)

(115V)

(230V)

52

23.MAIN CONTROL BOARD (A245)

Index
No.

* A245 5100 Main Control Board - 230V 1
* A245 5120 Main Control Board - 120V 1
1 A077 5717 Resistor - 1K Ω ±5% 1W 1
2 A184 5105 IC - RF5A93 1
3 A190 5107 Resistor - 180 Ω ±5% 3W 1
5 A245 5104 IC - UVEPROM 1M X8 120N 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 1102 4201 Connector - 2p
102 1102 4202 Connector - 3p
103 1102 4203 CT Header - 4P
104 1102 4204 Ct Header - 5p
105 1102 4205 Ct Header- 6p
106 1102 4206 Connector - 7p
107 1102 4208 Connector - 9p
108 1102 4209 Ct Header - 10p
109 1102 4211 Ct Header - 12p
110 1102 4619 Connector - 2p
111 1102 4624 Ct Connector - 7p
112 1102 4631 Ct Connector - 2p
113 1102 4634 Ct Connector - 5P
114 1102 4646 Connector - 5P
115 1102 5303 Connector - 4p
116 1103 1770 Connector - 4p
117 1103 1771 Connector - 5p
118 1103 1772 Pin Header - 6p
119 1103 1778 Pin Header - 12P
120 1104 0511 IC Socket - 8P - DICF-8CS-E
121 1104 0589 Dip Socket : 32p
122 1400 0072 Transistor - 2SC372Y
123 1400 0291 Transistor - 2SA1020Y
124 1400 0652 Transistor - 2SA1287
125 1401 0694 Zener Diode - RD6.8FB
126 1402 0277 Zener Diode - 1Z12
127 1402 1050 Silicon Diode - 100V 1A
128 1402 1125 Zener Diode - 1W - RD33FB2
129 1402 1160 Diode - S5688
130 1402 1310 Diode - D1NL20U
131 1407 153 5 IC - TD62308AP
132 1407 218 7 TTLIC - SN74LS07N S
133 1407 2836 IC - HD74C14FP
134 1407 376 4 IC - TC7SU04F
135 1407 385 7 IC - TC7SU04F

Part No.

Description

Q’ty Per
Assembly

Index
No.

136 1407 4315 IC - TE7751
137 1407 4642 IC - MTD1110
138 1407 467 2 TTL HD74LS368FP
139 1407 467 8 EPROM BR93LC56A
140 1408 0150 IC - ULN2003AN
141 1408 0595 IC - NJM2904M
142 1408 0611 IC - 3771
143 1408 0826 IC - TA8428K
144 1503 0563 Oscillator - 9.83mtz040
145 1601 5295 Resistor - 0.47Ω ±2% 1W
146 1601 8157 Variable Resistor - 100K Ω
147 1607 0878 Inductor - BLM21A102S
148 1630 3101 Resistor - 100Ω - 1/10W
149 1630 3102 Resistor - 1KΩ 1/10W ±5%
150 1630 3103 Resistor - 10KΩ 1/10W ±5%
151 1630 3105 Resistor - 1M Ω ±5% 1/ 10W
152 1630 3204 Resistor - 200K Ω 1/10W ±5%
153 1630 3222 Resistor - 2.2KΩ 1/10W ± 5%
154 1630 3223 Resistor - 22kΩ - 1/10W
155 1630 3393 Resistor - 39K Ω 1/10W
156 1630 3472 Resistor - 4.7KΩ 1/10W ± 5%
157 1630 3512 Resistor - 5.10KΩ - 1/10W
158 1630 3751 Resistor - 750Ω±5% 1/10W
159 1630 3752 Resistor - 7.5K Ω ±5 % 1/ 10W
160 1632 0000 Resistor - 0 Ω 1/8W
161 1633 0000 Resistor - 0Ω 1/10W:JAMPER CHI P
162 1633 1001 Resistor - 1K Ω ±1% 1/10W
163 1633 1002 Resistor - 10K Ω ±1% 1/10W
164 1633 1050 Resistor - 105 Ω ±1% 1/ 10W
165 1633 2150 Resistor - 215Ω ±1% 1/10W
166 1633 3901 Resistor - 3.9 Ω ±1% 1/ 10W
167 1633 7870 Resistor - 787 Ω ±1% 1/ 10W
168 1633 9319 Resistor - 93.1 Ω ±1% 1/10W
169 1640 5100 Capacitor - 10µF+20% 35V

Part No.

Description

Q’ty Per
Assembly

Index
No.

170 1640 5109 Capacitor - 1µF- ±20% - 50V
171 1640 5470 Capacitor - 47µF± 20% 50V
172 1660 3101 Capacitor - 100pF 50V
173 1660 3471 Capacitor - 470pF 50V
174 1660 5332 Capacitor - 3300pF ±10% 50V
175 1660 7103 Capacitor - 10000pF 50V
176 1660 7104 Capacitor - 100000pF 50V
177 1660 7473 Capacitor - 47000pF +80% -20% 50V
178 1002 0307 Jumper Wire

Part No.

Description

Q’ty Per
Assembly

53

24.DECAL AND DOCUMENT (A245)

12 13

>PS<

54

24.DECAL AND DOCUMENT (A245)

Index
No.

1 A219 1380 Decal - Symbol Explanation 5 Lang. 1
2 A153 1285 Emblem (RIC) 1
2 A156 6413 Emblem (SVN) 1
3 A19 0 4476 Decal - Hig h Temperat ure 1
4 A190 2708 Decal - By-pass Feed 1
5 A190 2690 Decal - 1st Paper Tray 1
5 A190 2691 Decal - 2nd Paper Tray 1
6 A245 8607 Operating Instructions - English LT (RIC) 1
6 A245 8650 Operating Instructions - Englis h LT ( SVN ) 1
6 A245 8697 Operating Instructions - Engli sh LT (NRG) 1
6 A245 8608 Operating Instructions - Engli sh A4 (RIC) 1
6 A245 8690 Operating Instructions - Engli sh A4 (NRG) 1
6 A245 8660 Operating Instructions - Engli sh A4 (INF) 1
6 A245 8661 Operating Instructions - German (INF) 1
6 A245 8662 Operating Instructions - French (INF) 1
6 A245 8663 Operating Instructions - Italian (INF) 1
6 A245 8664 Operating Instructions - Spanish (INF) 1
7 A219 1284 Operation Guide Sheet 1
8 A219 1265 Decal - Main Switch 1
9 A190 2692 Decal - Paper Tray Operation 1
9 A245 2694 Decal - Paper Tray Operation (4 Language) 1
10 A245 6182 Model Name Plate - GES 1
10 A245 6184 Model Name Plate - NSA 1
10 A245 6186 Model Name Plate - REX 1
10 A219 6187 Model Name Plate - GENERIC 1
11 C225 2867 Decal - Cover - Panel (NSA) 1
11 C225 2866 Decal - Key Top Cover (REX) 1
11 A153 6409 Decal - Keytop Cover (GES) 1
12 A219 2696 Decal - Size Selection 1
13 G020 2668 Decal - Paper Set 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

Part No.

Description

Q’ty Per
Assembly

55

25.SPECIAL TOOLS (A245)

56

25.SPECIAL TOOLS (A245)

Index
No.

1 A184 9501 Optics Adjustment Tool 1
2 5420 9516 Test Chart - OS - A3 (10PSC/SET) 1
3 5442 9103 Launa Oil 40 1
4 5203 9501 Grease 501 1
5 5420 9507 Digital Multimeter - Beckm an 1
6 5442 9101 Setting Powder 1
7 A028 9300 Grease Barrierta JFE 55/2 1
8 A190 9002 Grease - CP501 (5 Pcs /s et ) 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

Part No.

Description

Q’ty Per
Assembly

57

PARTS INDEX

PM Parts Index

Section Name

PLATEN COVER (A245) 5448 2804 Platen Cover Sheet Platen Cover Sheet 1 9- 6
PAPER TRAY (A245) G020 2645 Tray Bottom Plate Pad Frictio n Pad 1 13- 16
PAPER FEED SECTION 1 (A245) G020 2555 Feed Roller Paper Feed Roller 2 17- 19

PAPER FEED SECTION 2 (A245) G020 2555 Feed Roller Paper Feed Roller 2 19- 10
PAPER REGISTRATION (A245) G020 2716 Friction Pad Friction Pad 1 21- 18
IMAGING UNIT - 1 (A245) A190 2060 Charge Corona Grid Charge Corona Grid 1 31- 3

IMAGING UNIT - 2 (A245) A219 9510 OPC Drum OPC Drum 1 33- 16

FUSING UNIT (A245) A184 4072 Stripper Pawl Stripper Pawl 5 37- 4

TRANSFER AND EXIT SECTION (A245) A190 3866 Tranfer Corona Wire Transfer Corona Wire 1 39- 24
ELECTRICAL SECTION 1 (A245) A190 1157 Ozone Filter Ozone Filter 1 45- 15

Part No.

G020 2721 By-pass Feed Roller By-pass Feed Roller 1 17- 13

A190 2065 Charge Corona Wire Charge Corona Wire 1 31- 4
A190 2070 Charge Corona Cleaning Pad Corona Wire Cleaner Ass‘y 1 31- 12

A190 3550 Cleaning Blade Cleaning Blade 1 33- 20

A245 4100 Hot Roller Hot Roller 1 37- 15
A245 4103 Pressure Roller Pressure Roller 1 37- 18

Description in Service Manual

Description in Parts Catalog

Q’ty Per
Assembly

Page and
Index No

60

Parts Index

Part No.

A245 1111 DC Motor 28W 45- 12
A245 1148 Timing pulley - 37Z 41- 8
A245 1190 Power Cord Bracket 45- 18
A245 1270 Front Cover Ass‘y (R I C ) 7- 1

A245 1305 Left Lower Cover 7- 16
A245 1330 Rear Cover 7- 22
A245 1450 Operation Panel Ass‘y - LT (RIC/ NR G ) 7- 11
A245 1450 Operation Panel Ass‘y - LT (RIC/NRG ) 11- *
A245 1451 Operation Panel Ass’y - A4 7- 11
A245 1451 Operation Panel Ass’y - A4 11- *
A245 1452 Operation Panel Ass’y -LT (SVN) 7- 11
A245 1452 Operation Panel Ass’y - LT (SVN) 11- *
A245 1461 Indication Sheet - LT (RIC/NRG) 11- 2
A245 1462 Indication Sheet - A4 11- 2
A245 1463 Indication Sheet - LT (SVN) 11- 2
A245 1700 1st Scanner Unit - 120V 23- 19
A245 1701 1st Scanner Unit - 230V 23- 19
A245 1740 1st Scanner Cushion 23- 26
A245 2551 Paper Tray Ass’y - LT 13- *
A245 2552 Paper Tray Ass’y - A4 13- *
A245 2610 Lower Paper Guide 19- 20
A245 2694 Decal - Paper Tray Operation (4 Language) 55- 9
A245 4023 Fusing Unit - 120V 37- *
A245 4024 Fusing Unit - 230V 37- *
A245 4100 Hot Roller 37- 15
A245 4103 Pressure Roller 37- 18
A245 4108 Pressure Roller Lever 37- 20
A245 4109 Pressure Spring 37- 19
A245 4120 Fusing Lamp - 230V 760W 37- 12
A245 4472 Lower Guide Plate 39- 4
A245 5100 Main Control Board - 230V 45- 6
A245 5100 Main Control Board - 230V 53- *
A245 5104 IC - UVEPROM 1M X8 120N 53- 5
A245 5120 Main Control Board - 120V 53- *
A245 5120 Main Control Board - 120V 45- 6

Description

Page and
Index No.

Part No.

A245 5301 AC Main Harness - 230V 45- 8
A245 5310 DC Harness 45- 7
A245 5310 DC Harness 19- 3
A245 5651 AC Drive DC Power Supply Board-230V 45- 9
A245 6182 Model Name Plate - GES 7- 21
A245 6182 Model Name Plate - GES 55- 10
A245 6184 Model Name Plate - NSA 55- 10
A245 6184 Model Name Plate - NSA 7- 21
A245 6186 Model Name Plate - REX 55- 10
A245 6186 Model Name Plate - REX 7- 21
A245 6270 Front Cover Ass’y (INF) 7- 1
A245 6470 Front Cover Ass’y (SVN) 7- 1
A245 8607 Operating Instructions - English LT (RIC) 55- 6
A245 8608 Operating Instructions - English A4 (RIC) 55- 6
A245 8650 Operating Instructions - Engli sh LT (SVN) 55- 6
A245 8660 Operating Instructions - English A4 (INF) 55- 6
A245 8661 Operating Instructions - German (INF) 55- 6
A245 8662 Operating Instructions - Fr ench (INF) 55- 6
A245 8663 Operating Instructions - Italian (INF) 55- 6
A245 8664 Operating Instructions - Spanish (INF) 55- 6
A245 8690 Operating Instructions - English A4 (NRG) 55- 6
A245 8697 Operating Instructions - English LT (NRG) 55- 6

Description

Page and
Index No

61

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

AA06 0331 Release Spring 21- 14
AA06 3036 Terminal Spring 39- 28
AA06 3040 Spring 39- 27
AA06 3180 Adjust Spring 27- 23
AA06 3206 Spring - Front Side Fence 47- 28
AA06 3249 Grid Terminal Spring 47- 15
AA06 3489 Spring - 45mm 35- 4
AA06 3523 Adjust Spring 27- 13
AA08 0111 Bushing - 8x12x7 43- 3
AA14 3070 Shoulder Screw - M2x2 7- 15
AA14 3424 Knob Screw - M4x8 9- 2
AA14 3716 Stepped Screw 35- 26
AA15 0234 Mylar Seal - Base 27- 26
AA16 2067 Platen Cover Pad 9- 5
AB01 3868 Gear - 16Z 13- 19
AB01 7129 Gear - 20Z AND 72Z 27- 20
AB01 7361 Gear - 24Z/56Z 27- 17
AB03 0273 Timing Pulley - T20 41- 6
AC01 2042 Exposure Glass 7- 13
AC02 0077 Lens - F8/180 25- 8
AC06 3001 White Reference Plate 23- 3
AF02 0283 Pressure Roller 19- 14
AF04 0031 Upper Exit Roller 39- 7
AG07 0004 Magnetic Catch 7- 9
AG07 0009 Magnetic Catch 39- 11
AW02 0075 Photointerrupter 47- 9
AW02 0075 Photointerrupter 27- 5
AW02 0075 Photointerrupter 23- 4
AW10 0033 Thermistor 23- 7
AX31 0024 Total Counter 47- 2
AX40 0052 Anti-Condensation Heater - 115V 18W 25- 4
AX40 0053 Anti-Condensation Heater - 240V 18W 25- 4
AX40 0063 Anticondensation Heater - 120V 9W 49- 9
AX40 0064 Anticondensation Heater - 230V 9W 49- 9
AX64 0058 Fan Motor - DC 24V 4.32W 45- 2

C225 2866 Decal - key Top Cover (REX) 7- 3
C225 2866 Decal - Key Top Cover (REX) 55- 11
C225 2867 Decal - Cover - Panel (NSA) 55- 11
C225 2867 Decal - Cover - Panel (NSA) 7- 3
G011 3305 Gear - 16T 15- 12
G020 1052 Stand 49- 5
G020 1072 Fusing Unit Guide 49- 16
G020 1078 Right Sielding Plate 49- 15
G020 1112 Paper Feed Clutch 43- 1
G020 1114 By-pass Feed Clutch 41- 4
G020 1115 Registration Clutch 41- 18
G020 1130 Gear - 65Z/24Z 41- 11
G020 1131 Gear - 58Z/35Z 41- 13
G020 1132 Gear - 68Z 41- 16
G020 1138 Pulley - 24T 41- 27
G020 1144 Gear - 27Z 43- 5
G020 1145 Shaft - Paper Feed Roller 43- 2
G020 1157 Gear - 28Z 35- 12
G020 1168 Gear - 52Z/26T 41- 17
G020 1177 Gear - 26Z 41- 32
G020 1178 Pulley - 51T 41- 30
G020 1187 Timing Belt - S2M 158MM 41- 31
G020 1923 CS Ring - M2.4 33- 24
G020 2327 Pressure Spring 31- 20
G020 2355 Transport Guide Shaft 33- 12
G020 2554 Paper Feed Roller Ass’y 19- 19

G020 2554 Paper Feed Roller Ass’y 17- 22
G020 2555 Paper Feed Roller 17- 19
G020 2555 Paper Feed Roller 19- 10
G020 2557 Tray Bottom Plate 13- 15
G020 2558 Rear Corner Separator 13- 12
G020 2565 Paper Guide 17- 18
G020 2565 Paper Guide 19- 9
G020 2567 Rear Side Fence 13- 11
G020 2570 Shaft - Paper Feed Roller 17- 17

62

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

G020 2570 Shaft - Paper Feed Roller 19- 8
G020 2573 Front Paper Separator 13- 21
G020 2576 Guide - Vertical Transport 19- 17
G020 2577 Spring Plate - Driven Roller 19- 15
G020 2580 Paper End Sensor Bracket 47- 24
G020 2581 Paper End Feeler 47- 26
G020 2585 Front Pin - Paper Feed Roller 17- 16
G020 2585 Front Pin - Paper Feed Roller 19- 6
G020 2586 Rear Pin - Paper Feed Roller 17- 15
G020 2586 Rear Pin - Paper Feed Roller 19- 7
G020 2587 Bushing - Paper Feed 17- 12
G020 2587 Bushing - Paper Feed 19- 1
G020 2592 Release Lever - Bottom Plate 13- 7
G020 2593 Paper Size Sensor - LT 13- 4
G020 2595 Paper Size Sensor - A4 13- 4
G020 2599 Spring - Release Lever 13- 8
G020 2613 Virtical Relay Guide 19- 13
G020 2622 Release Arm - Paper End Feeler 47- 21
G020 2626 Release Spring - Paper End Feeler 47- 22
G020 2630 Magnetic Catch 19- 16
G020 2643 Front Grounding Plate - Paper Tray 49- 4
G020 2644 End Fence 13- 20
G020 2645 Friction Pad 13- 16
G020 2647 Paper Tray Cover 13- 1
G020 2648 Holder - Paper Size Detector 13- 6
G020 2650 Right Guide - Paper Tray 49- 7
G020 2652 Middle Rail - Paper Tray 49- 11
G020 2653 Left Rail - Paper Tray 49- 19
G020 2654 Upper Rear Guide - Pape r Tray 49- 14
G020 2655 Upper Front Guide - Paper Tray 49- 13
G020 2656 Pressure Spring - Bottom Plate 13- 17
G020 2658 Grounding Plate - Bottom Plate 13- 18
G020 2661 Bottom Plate Ass’ y 13- 26

G020 2663 Paper Size Actuator 13- 5
G020 2664 Front Stopper Lever 13- 23

G020 2668 Sheet - Paper Set 13- 2
G020 2668 Decal - Paper Set 55- 13
G020 2677 Support - Paper Tray - Left 7- 10
G020 2678 Guide Plate - Paper Tray 49- 18
G020 2702 Pressure Spring - By-pass Feed 15- 8
G020 2712 Holder - By-pass Feed Friction Pad 21- 10
G020 2713 Pressure Spring 21- 20
G020 2716 Friction Pad 21- 18
G020 2721 By-pass Feed Roller 17- 13
G020 2723 By-pass Feed Shaft 17- 11
G020 2735 Guide - By-pass Feed Table 15- 1
G020 2741 Upper Registration Ro l l er 21- 11
G020 2743 Tension Spring 21- 4
G020 2745 Lower Guide Plate - Regist 21- 6
G020 2745 Lower Guide Plate - Regist 21- 13
G020 2753 Bracket - Registration Sensor 17- 7
G020 2754 Upper Paper Guide 21- 16
G020 2765 Knob - Lower Transport Guide 21- 12
G020 2784 Lever - By-pass Feed Table 15- 6
G020 2785 Cover - Feed Roller Shaft 17- 4
G020 2786 Shaft - By-pass Release Lever 15- 5
G020 2787 Cover - By-pass Paper End Sensor 17- 9
G020 3313 Spring 29- 4
G020 3326 Cushion 29- 13
G020 3334 Slider Ass‘y 29- 12
G020 3345 Right Seal 29- 3
G020 3565 Grounding Plate 33- 13
G020 3571 Toner Correction Gear - 14/24Z 33- 19
G020 3888 Pin - Transfer Guide 21- 1
G020 3912 Transport Lever 39- 32
G020 4175 Bushing - Pressure Roller 37- 17
G020 4177 Gear - 40Z 37- 16
G020 5829 Shoulder Screw - M3x2.5 47- 18

63

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A028 9300 Grease Barrierta JFE 55/2 57- 7
A048 2276 Ring - Transport Bracket 33- 11
A048 3860 Transport Bracket Holder 39- 1
A069 1883 Shoe - Scanner 23- 11
A077 1690 Spring Plate - Mirror 27- 14
A077 1690 Spring Plate - Mirror 23- 9
A077 1745 Cover - ADS Sensor 27- 4
A077 1746 Mirror Adjusting Screw 27- 21
A077 5717 Resistor - 1K Ω ±5% 1W 53- 1
A111 1753 Seal - 0.1x18x49 25- 11
A111 1753 Seal - 0.1x18x49 23- 2
A126 4400 Copy Tray 7- 20
A126 4460 Slide Copy Tray 7- 18
A126 4470 Copy Tray Guide 7- 19
A134 1071 Left Grip Plate 49- 1
A134 1072 Right Bracket - Grip Plate 49- 3
A152 5120 Optics Control Board 27- 3
A152 5220 Main Switch 45- 4
A153 1285 Emblem (RIC/NRG) 7- 2
A153 1285 Emblem (RIC) 55- 2
A153 1354 Hinge Pin 7- 4
A153 1906 Adjust Shoe 27- 12
A153 4087 Thermistor Holder 37- 7
A153 6409 Decal - key Top Cover (GES) 7- 3
A153 6409 Decal - Keytop Cover (GES) 55- 11
A153 6423 Support Cover (INF) 7- 2
A156 6413 Emblem (SVN) 7- 2
A156 6413 Emblem (SVN) 55- 2
A157 2769 Rear Stopper Spring 13- 13
A184 1672 Thermofuse - 128 23- 24
A184 2455 Toner Density Sensor 33- 15
A184 3411 Chuck Spring 29- 11
A184 3420 Bottle Chuck 29- 17
A184 3421 Chuck Shaft 29- 16
A184 3422 Toner Slider 29- 7

A184 3611 Toner Recycle Belt 33- 2
A184 3863 Corona Wire Spring 31- 14
A184 3863 Corona Wire Spring 39- 26
A184 4072 Stripper Pawl 37- 4
A184 4081 Right Retaining Ring - 31 37- 13
A184 4105 Left Retaining Ring - 31 37- 5
A184 5105 IC - RF5A93 53- 2
A184 5205 Scanner Motor - DC24V 96W 25- 19
A184 5225 Exhaust Fan Motor - DC24V 3.6W 45- 14
A184 5344 Scanner Grounding Harness 45- 11
A184 9501 Optics Adjustment Tool 57- 1
A190 1040 Front Safety Switch Arm 35- 24
A190 1041 Front Door Switch Lever 35- 2
A190 1042 Front Lever Bracket 35- 1
A190 1043 Fusing Switch Lever 35- 18
A190 1045 Safety Switch Stay 47- 8
A190 1048 Fusing Lever Cover 47- 11
A190 1073 Paper Exit Pin Bracket 39- 21
A190 1076 Base Cover 49- 6
A190 1080 Exit Stay 49- 10
A190 1081 Stay - Paper End Sensor 49- 12
A190 1084 Front Right Grip Bracket 49- 2
A190 1085 Exit Rear Bracket 39- 33
A190 1112 Drive Bracket 41- 25
A190 1117 Support Plate - Drive Unit 41- 14
A190 1118 Imaging Unit Drive Shaft 41- 33
A190 1122 Development Drive Bracket 41- 7
A190 1123 Development Drive Gear 41- 35
A190 1124 Tightner Spring 41- 23
A190 1125 Tightner Bracket 41- 26
A190 1128 Tightner Pulley 41- 28
A190 1131 Drive Gear Joint Bracket 35- 11
A190 1132 Gear - 32Z 35- 13
A190 1134 Support Bracket 35- 16
A190 1136 Gear Shaft 35- 15

64

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A190 1138 Spacer 35- 14
A190 1139 Magnetic Clutch - Vertical 19- 11
A190 1139 Magnetic Clutch - Vertical 17- 1
A190 1141 Timing Belt - SM699 41- 5
A190 1144 Tightner Pulley 41- 12
A190 1145 Release Spring 41- 1
A190 1146 Tightner Ass‘y 41- 2

A190 1149 Tightner Pulley 41- 3
A190 1151 Duct Cover 35- 8
A190 1152 Guide Rail 35- 7
A190 1153 Duct 35- 9
A190 1155 Duct Bracket 45- 13
A190 1156 Ozone Filter Cap 45- 16
A190 1157 Ozone Filter 45- 15
A190 1160 Safety Switch Bracket 35- 6
A190 1162 Safety Switch Arm 35- 23
A190 1163 Drive Release Wire 35- 10
A190 1164 Safety Switch Lever 35- 5
A190 1165 Tightner Bracket 41- 24
A190 1171 Imaging Unit Holder 41- 36
A190 1174 Pressure Spring 41- 37
A190 1176 Paper Feed Drive Unit 43- 6
A190 1180 Pulley - 20Z/63Z 41- 20
A190 1181 Timing Belt - S3M288 41- 21
A190 1182 Gear - 21Z/40Z 41- 19
A190 1183 Pressure Spring 41- 34
A190 1185 Development Drive Shaft 41- 9
A190 1186 Main Board Bracket 47- 12
A190 1187 High Voltage Supply Board Bracket 47- 14
A190 1191 By-pass Feed Cover 47- 13
A190 1192 Main Switch Bracket 45- 3
A190 1193 Connector Bracket 47- 17
A190 1195 Right Harness Cover 45- 1
A190 1196 Upper Seal - By-pass Feed 47- 32
A190 1197 Front Seal - By-pass Feed 47- 31

A190 1198 Development Bias Terminal 41- 22
A190 1260 Upper Cover 7- 12
A190 1282 Magnet Catch 7- 6
A190 1283 Magnet Catch 7- 26
A190 1286 Front Cover Hing Bracket 47- 1
A190 1287 Front Lower Cover 7- 7
A190 1290 Rear Right Cover 7- 23
A190 1295 Front Right Cover 7- 25
A190 1297 Right Lower Cover 7- 24
A190 1300 Left Upper Cover 7- 17
A190 1337 Inner Cover 7- 8
A190 1341 Front Door Lever 35- 22
A190 1342 Front Lever Support Plate 35- 19
A190 1345 Release Spring - Front Leve r 35- 20
A190 1452 Keytop - Start (RIC/NRG) 11- 4
A190 1453 Keytop - Clear/Stop (RIC/NRG) 11- 5
A190 1454 Keytop - Clear Mode (RIC/NRG) 11- 6
A190 1455 Keytop - 10keys (RIC/NRG) 11- 7
A190 1651 Left Scale Support Plate 23- 5
A190 1652 Exposure Glass Seal 23- 6
A190 1654 Right Bracket - Exposure Glass 23- 23
A190 1655 Scale - A4 7- 14
A190 1660 Scanner Guide Rail 23- 1
A190 1663 Lens Guide Rail 25- 14
A190 1664 Pulley Bracket 25- 16
A190 1666 Pulley Bracket 25- 2
A190 1669 Lens Support Bracket 25- 18
A190 1671 Mirror Drive Motor Ass‘y DC24V 81.6W 27- 2
A190 1672 Lens Drive Motor Ass‘y DC24V 81.6W 27- 1
A190 1674 6th Mirror Bracket - Front 27- 24
A190 1675 6th Mirror Bracket - Rear 27- 22
A190 1676 Rod Bracket 27- 7
A190 1678 3rd Scanner Brakcet 27- 11
A190 1679 Mirror Sensor Shuter 27- 10
A190 1682 Lens Caridge 25- 6

65

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A190 1683 Shading Plate 25- 9
A190 1684 Shielding Plate 25- 10
A190 1685 Lens Cover Bracket 25- 17
A190 1688 Bushing 23- 16
A190 1689 Clamp 23- 18
A190 1691 2nd Scanner Frame 23- 10
A190 1692 2nd Scanner Support Plate 23- 17
A190 1693 Lens Cover 25- 12
A190 1694 Shoe Bracket 23- 12
A190 1696 Motor Bracket 25- 20
A190 1698 Shielding Plate 25- 7
A190 1725 Bushing 23- 20
A190 1751 Harness Guide Pulley Ass‘y 23- 14

A190 1802 Timing Pulley - 30Z 27- 8
A190 1803 Timing Puley - 22Z/44Z 25- 22
A190 1809 6th Mirror 27- 15
A190 1810 Mirror Guide Rod 27- 9
A190 1811 4th/5th Mirror 27- 6
A190 1812 Blue Filter 25- 5
A190 1813 Timing Belt - L824P2M 25- 13
A190 1814 Scanner Guide Rod 23- 22
A190 1815 2nd/3rd Mirror 23- 8
A190 1816 Timing Belt - L1110P2M 25- 1
A190 1817 Timing Belt - L754P2M 25- 23
A190 1818 2nd Scanner Spring 25- 15
A190 1819 1st Scanner Spring 25- 3
A190 1820 Lens Holder Spring 25- 21
A190 1821 Harness Guide Pulley 23- 15
A190 1824 2nd Scanner Support Plate 23- 13
A190 1825 3rd Scanner Support Plate 27- 19
A190 1827 Rack Gear 27- 18
A190 1831 Shield heater Rear 27- 25
A190 1856 Platen Cover Bracket 9- 3
A190 2011 Charge Corona Unit 31- 2
A190 2020 Quenching Lamp Unit 35- 21

A190 2030 Erase Lamp Unit 35- 25
A190 2040 Transfer Corona Wire Receptacle 47- 16
A190 2060 Charge Corona Grid 31- 3
A190 2062 Spring Plate - Charge Corona Grid 31- 7
A190 2065 Charge Corona Wire 31- 4
A190 2070 Corona Wire Cleaner Ass‘y 31- 12
A190 2075 Cleaning Shaft 31- 8
A190 2085 Front Endblock Cover 31- 5
A190 2086 Rear Endblock Cover 31- 11
A190 2105 Corona Wire Terminal 31- 10
A190 2116 Rear Shielding Plate 31- 9
A190 2280 Front Side Plate 31- 1
A190 2290 Rear Side Plate 31- 24
A190 2320 Knob Screw 31- 13
A190 2330 Toner Recycle Cover 33- 21
A190 2560 Front Side Fence 13- 24
A190 2561 Side Fence Rack 13- 22
A190 2564 Relay Roller 17- 14
A190 2564 Relay Roller 19- 5
A190 2611 Paper Guide Plate 19- 12
A190 2620 Push Switch - Paper Size 47- 5
A190 2642 Rear Lever Stopper 13- 14
A190 2671 Paper Size Switch Bracket 47- 3
A190 2680 Paper Tray Stopper 47- 6
A190 2684 Guard - Paper Tray Stopper 47- 4
A190 2690 Decal - 1st Paper Tray 13- 25
A190 2690 Decal - 1st Paper Tray 55- 5
A190 2691 Decal - 2nd Paper Tray 13- 25
A190 2691 Decal - 2nd Paper Tray 55- 5
A190 2692 Decal - Paper Tray Operation 55- 9
A190 2692 Decal - Paper Tray Operation 13- 3
A190 2698 Support Cover - By-pass Feed 15- 9
A190 2700 By-pass Feed Unit 15- *
A190 2701 By-pass Feed Cover 15- 3
A190 2702 Paper Guide 15- 13

66

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A190 2704 Bottom Plate - By-pass Feed 15- 14
A190 2705 Right Side Fence 15- 11
A190 2706 Left Side Fence 15- 15
A190 2707 Side Fence Rack 15- 2
A190 2708 Decal - By-pass Feed 55- 4
A190 2708 Decal - By-pass Feed 15- 4
A190 2711 Friction Pad Stay 21- 5
A190 2714 Friction Pad Holder Ass‘y 21- 19

A190 2717 Friction Pad Guide 21- 17
A190 2740 Lower Registration Roll er 21- 8
A190 2771 Resist Sensor 17- 5
A190 2772 Paper End Sensor 17- 8
A190 2780 Front Bushing 21- 2
A190 2781 Rear Bushing 21- 9
A190 2782 Bottom Plate Stay 15- 10
A190 2783 Resist Roller Knob 21- 7
A190 2801 Tray Stopper Bracket 47- 23
A190 2805 Roller Holder 47- 27
A190 2810 Cassette Stopper 13- 10
A190 2812 Stopper Cover 13- 9
A190 2825 Heater Bracket 49- 8
A190 2900 Switch Bracket 19- 4
A190 2902 Switch Lever 19- 2
A190 2905 Cushion 19- 18
A190 3050 Development Roller Ass‘ y 31- 26
A190 3094 Development Entrance Seal 31- 15
A190 3112 1st Agitator 33- 5
A190 3116 2nd Agitator 33- 7
A190 3125 Busing 33- 8
A190 3128 Seal 6mm 33- 22
A190 3152 Gear - 18Z 31- 16
A190 3153 Transfer Auger Gear 33- 6
A190 3155 Idle Gear - 17Z 31- 17
A190 3156 Cam Gear 31- 25
A190 3162 Imaging Unit Upper Case 31- 23

A190 3165 Long Seal 31- 22
A190 3166 Rear Seal 31- 18
A190 3167 Front Seal 31- 19
A190 3171 Imaging Unit Shutter 31- 21
A190 3183 Harness Holder 33- 9
A190 3192 Lower Seal - 3 x 6 x 396 33- 23
A190 3193 Seal - 5x55 33- 25
A190 3361 Toner Bottle Holder Guide 17- 3
A190 3363 Guide Seal - Toner Supply Unit 17- 6
A190 3550 Cleaning Blade 33- 20
A190 3560 Toner Collection Coil 33- 10
A190 3563 Toner Recycle Roller 33- 3
A190 3564 Toner Cap 33- 1
A190 3568 Rear Bushing 33- 18
A190 3569 Recycle Roller Bushing 33- 4
A190 3570 Cleaning Entrance Seal 33- 14
A190 3851 T/S Unit 39- 20
A190 3863 Front Block Cover 39- 25
A190 3864 Rear End Block Cover 39- 23
A190 3866 Transfer Corona Wire 39- 24
A190 3880 Discharge Plate Unit 39- 22
A190 3890 T/S Corona Receptacle 39- 29
A190 3900 Transfer Guide 39- 18
A190 3903 Transfer Release Guide 39- 19
A190 3905 Transfer Corona Rail 39- 17
A190 3906 Spring Plate 39- 16
A190 3911 T/S Position Plate 39- 31
A190 3914 Bushing 39- 30
A190 4053 Fusing Unit Knob 37- 2
A190 4070 Fusing Unit Cover 37- 11
A190 4071 Fusing Entrance Guide 37- 23
A190 4073 Fusing Stay 37- 9
A190 4076 Fusing Frame 37- 26
A190 4086 Hot Roller Bushing 37- 14
A190 4088 Seal 37- 27

67

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A190 4089 Stripper Pawl Bracket 37- 1
A190 4092 Stripper Pawl Spring 37- 3
A190 4096 Idle Gear - 18Z 39- 3
A190 4097 Idle Gear - 16Z 39- 2
A190 4119 Thermistor 37- 8
A190 4120 Front Heater Bracket 37- 25
A190 4121 Rear Heater Bracket 37- 22
A190 4129 Connector Bracket 37- 21
A190 4385 Antistatic Brush 37- 6
A190 4386 Antistatic Brush 37- 24
A190 4455 Exit Sensor Feeler 39- 10
A190 4456 Exit Sensor Feeler Spring 39- 9
A190 4463 Exit Roller Gear - 23Z 39- 15
A190 4465 Exit Roller 39- 5
A190 4471 Upper Guide Plate 39- 6
A190 4474 Exit Roller Holder 39- 8
A190 4476 Decal - High Temperature 39- 14
A190 4476 Decal - High Temperature 55- 3
A190 4478 Exit Cover 39- 13
A190 4479 Shielding Plate 39- 12
A190 4484 Antistatic Brush 47- 7
A190 5107 Resistor - 180 Ω ±5% 3W 53- 3
A190 5145 Development Relay Board 47- 20
A190 5150 High Voltage Supply Board 45- 5
A190 5301 AC Main Harness - 120V 45- 8
A190 5335 DC Power Harness 47- 19
A190 5335 DC Power Harness 47- 34
A190 5335 DC Power Harness 45- 10
A190 5343 Scanner H.P Harness 27- 16
A190 5344 Relay Harness - By-pass Fe ed 17- 10
A190 5345 Exit Sensor Harness 47- 10
A190 5346 Development Unit Harness 33- 17
A190 9002 Grease - CP501 (5 Pcs/set) 57- 8
A193 1074 Relay Harness Cover 49- 17
A193 1246 Platen Cover Hinge Ass‘y 9- 4

A193 2660 Paper Separator Cushion 13- 27
A219 1169 Gear - 40Z 41- 10
A219 1194 ADF Bracket 23- 21
A219 1197 Rear Bracket - ADF 23- 25
A219 1265 Decal - Main Switch 55- 8
A219 1284 Operation Guide Sheet 7- 5
A219 1284 Operation Guide Sheet 55- 7
A219 1380 Decal - Symbol Explanation 5 L ang. 55- 1
A219 1391 Platen Cover 9- 1
A219 1461 Operation Panel Cover 11- 1
A219 1463 Operation Panel Sheet 11- 3
A219 1464 Operation Panel Board 11- 8
A219 1471 Keytop - Start (SVN) 11- 4
A219 1472 Keytop - Clear/Stop (SVN) 11- 5
A219 1473 Keytop - Clear Mode (SVN) 11- 6
A219 1474 Keytop - 10keys (SVN) 11- 7
A219 1476 Operation Panel Sheet - LT (SVN) 11- 3
A219 2205 Imaging Unit 31- *
A219 2696 Decal - Size Selection 13- 28
A219 2696 Decal - Size Selection 55- 12
A219 3030 Toner Supply Unit - 115V (RIC-NA) 29- *
A219 3034 Toner Supply Unit - 230V (RIC-EU) 29- *
A219 3036 Toner Supply Unit (Others) 29- *
A219 3132 Development Cover 31- 6
A219 3311 Toner Collection Cove r 29- 1
A219 3312 Toner Adding Gate 29- 6
A219 3314 Toner Supply Unit Case (RIC-NA) 29- 9
A219 3317 Toner Adding Shutter 29- 5
A219 3319 Sheet - Toner Supply Shutter 29- 21
A219 3322 Toner Bottle Cover 29- 14
A219 3325 Mylar Blade 29- 15
A219 3339 Toner Bottle Holder Lever 29- 8
A219 3341 Cushion - Toner Collection Cover 29- 22
A219 3342 Lower Seal - Tonner Collecti on Cover 29- 2
A219 3360 Toner Bottle Holder Guide - Ass’y 17- 2

68

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A219 3364 Mylar Seal - 8x429 17- 20
A219 3365 Mylar Seal - 8x400 17- 21
A219 3371 DC Motor - 3.36W 47- 30
A219 3372 Motor Bracket 47- 33
A219 3373 Seal - 2x15x95 47- 29
A219 3381 Roller 29- 18
A219 3382 Upper Cover 29- 19
A219 3383 Lower Cover 29- 20
A219 3384 Spring Plate 29- 10
A219 3385 Sheet - Roller Cover 29- 23
A219 3411 Toner Supply Unit Case (RIC-EU) 29- 9
A219 3416 Toner Supply Unit Case (Others) 29- 9
A219 4117 Fusing Lamp - 115V 850W 37- 12
A219 4123 Thermofuse - 169°C 37- 10

A219 5319 Toner Motor Harness 47- 35
A219 5551 AC Drive DC Power Supply Board-120 V 45- 9
A219 5552 Transformer - 120V 45- 17
A219 5581 Power Supply Cord - 120V 45- 19
A219 5652 Transformer - 230V 45- 17
A219 5681 Power Supply Cord - 230V 45- 19
A219 6070 Front Cover Ass‘y (NRG) 7- 1
A219 6186 Model Name Plate - GENERIC 7- 21
A219 6187 Model Name Plate - GENERIC 55- 10
A219 9510 OPC Drum 33- 16
A422 1082 Pick-up Spring 35- 17

5053 0223 Bushing - 8mm 21- 15
5053 0223 Bushing - 8mm 41- 15
5203 9501 Grease 501 57- 4
5206 2684 Shoulder Screw - M3 35- 3
5215 2713 Bottom Plate Pad 15- 16
5420 9507 Digital Multi m et er - Beckman 57- 5
5420 9516 Test Chart - OS - A3 (10PSC/SET) 57- 2
5442 9101 Setting Powder 57- 6
5442 9103 Launa Oil 40 57- 3
5446 1205 Release Spring 41- 29
5447 2681 Snap Ring 47- 25
5447 2681 Snap Ring 43- 4
5447 2681 Snap Ring 21- 3
5447 2681 Snap Ring 15- 7
5448 2804 Platen Cover Sheet 9- 6

69

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

0313 0300W Philips Pan Head Screw - M3x30 45-104
0353 0060B Philips Pan Head Screw - M3x6 31-101
0353 0060B Philips Pan Head Screw - M3x6 27-102
0353 0060B Philips Pan Head Screw - M3x6 23-103
0353 0060B Philips Pan Head Screw - M3x6 33-101
0353 0060B Philips Pan Head Screw - M3x6 7-102
0413 0082W Tapping Screw - M3x8 13-103
0413 0082W Tapping Screw - M3x8 39-103
0414 014 2B Binding Se lf Tapping Screw - M4x14 9-101
0434 0060B Pan Head Self-tapping Screw - M 4x6 49-103
0434 0102W Tapping Screw - M4x1 0 7-103
0450 3006B Tapping Screw - M3x6 25-105
0450 3006B Tapping Screw - M3x6 27-101
0450 3006B Tapping Screw - M3X6 41-108
0450 3008B Tapping Screw - M3x8 47-107
0450 3008B Tapping Screw - M3x8 17-104
0450 3008B Tapping Screw - M3x8 13-101
0450 3010B Tapping Screw - M3x10 25-102
0450 4030B Tapping Screw - M4x30 45-106
0451 3006B Tapping Screw - M3x6 27-103
0451 3006B Tapping Screw - M3x6 39-101
0451 3006B Tapping Screw - M3x6 37-101
0451 3006B Tapping Screw - M3x6 35-101
0451 3006B Tapping Screw - M3x6 25-101
0451 3006B Tapping Screw - M3x6 41-106
0451 3006B Tapping Screw - M3x6 23-102
0451 3006B Tapping Screw - M3x6 7-106
0451 3006B Tapping Screw - M3x6 15-102
0451 3006B Tapping Screw - M3x6 21-101
0451 3006B Tapping Screw - M3x6 43-101
0451 3006B Tapping Screw - M3x6 19-105
0451 3006B Tapping Screw - M3x6 13-104
0451 3006B Tapping Screw - M3x6 45-105
0451 3006B Tapping Screw - M3x6 47-103
0451 3006B Tapping Screw - M3x6 17-103

0451 3006B Tapping Screw - M3x6 49-101
0451 3010B Tapping Screw - M3x10 49-102
0451 3012B Tapping Screw With Wash er - M 3x12 41-107
0451 3014B Tapping Screw - M3-14 7-104
0451 3014B Tapping Screw - M3-14 19-104
0452 3006B Tapping Screw - M3x6 33-102
0452 3006B Tapping Screw - M3x6 29-101
0452 3006B Tapping Screw - M3x6 31-102
0452 3008B Tapping Screw - M3x8 39-105
0452 3008B Tapping Screw - M3x8 13-102
0452 3008Z Bind Tapping Screw - M3x8 7-101
0452 3010Z Bind Tapping Screw - 3x10 7-105
0453 3006Z Tapping Screw - M3x 6 15-101
0453 3006Z Tapping Screw - M3x 6 23-105
0453 3008B Bind Tapping Screw - M3X8 19-107
0633 0120E Spring Pin - M3x12 41-104
0701 0030B Flat Washer - M3 25-103
0720 0025E Retaining Ring - M2.5 39-107
0720 0030E Retaining Ring - M3 19-103
0720 0030E Retaining Ring - M3 47-105
0720 0030E Retaining Ring - M3 35-102
0720 0040E Retaining Ring - M4 39-102
0720 0040E Retaining Ring - M4 47-106
0720 0040E Retaining Ring - M4 17-102
0720 0040E Retaining Ring - M4 41-101
0720 0040E Retaining Ring - M4 19-102
0720 0040E Retaining Ring - M4 27-105
0720 0040E Retaining Ring - M4 23-104
0720 0060E Retaining Ring - M6 25-104
0720 0060E Retaining Ring - M6 41-103
0741 3808 Ball Bearing - 8x16x5mm 41-105
0805 3480 Bushing - 6mm 17-101
0805 3480 Bushing - 6mm 19-101
0805 3480 Bushing - 6mm 39-104
0805 3480 Bushing - 6mm 41-102

70

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

0951 3006B Philips Screw With Flat Washer-M3x6 27-106
0951 3006B Philips Screw With Flat Washer - M3x6 37-103
0954 3012B Screw - M3X12 37-102
1002 0307 Jumper Wire 53-178
1102 4201 Connector - 2p 53-101
1102 4202 Connector - 3p 53-102
1102 4203 CT Header - 4P 53-103
1102 4204 Ct Header - 5p 53-104
1102 4205 Ct Header- 6p 53-105
1102 4206 Connector - 7p 53-106
1102 4208 Connector - 9p 53-107
1102 4209 Ct Header - 10p 53-108
1102 4211 Ct Header - 12p 53-109
1102 4619 Connector - 2p 53-110
1102 4624 Ct Connector - 7p 53-111
1102 4631 Ct Connector - 2p 53-112
1102 4634 Ct Connector - 5P 53-113
1102 4646 Connector - 5P 53-114
1102 5303 Connector - 4p 53-115
1103 1770 Connector - 4p 53-116
1103 1771 Connector - 5p 53-117
1103 1772 Pin Header - 6p 53-118
1103 1778 Pin Header - 12P 53-119
1104 0511 IC Socket - 8P - DICF-8CS-E 53-120
1104 0589 Dip Socket : 32p 53-121
1105 0008 Nylon Clamp - 2n 27-107
1105 0199 Clamp 45-101
1105 0199 Clamp 35-104
1105 0199 Clamp 43-102
1105 0199 Clamp 49-104
1105 0199 Clamp 47-104
1105 0290 Harness Clamp - Horizontal 47-101
1105 0310 Wire Clamp 49-105
1105 0310 Wire Clamp 45-103
1105 0310 Wire Clamp 43-103

1105 0310 Wire Clamp 23-101
1105 0328 Harness Clamp - ES-0505 27-104
1105 0329 Clamp - ES-0510 47-102
1105 0413 Harness Clamp 45-102
1105 0413 Harness Clamp 47-108
1107 0485 Fuse (ceramic Case) - 15A - 125V 45-107
1107 0855 Fuse - 8A 125V 45-108
1107 0868 Fuse - 5A 125V 45-110
1107 0872 Fuse - 3.15A 125V 45-109
1107 0883 Fuse - 3.15A 250V 45-109
1107 0883 Fuse - 3.15A 250V 45-110
1107 0885 Fuse - 6.3A 250V 45-108
1107 0885 Fuse - 6.3A 250V 45-107
1204 2334 Interlock Switch - Fa1l 35-103
1204 2356 Micro Switch - AM51612A531 19-106
1400 0072 Transistor - 2SC3 72Y 53-122
1400 0291 Transistor - 2SA1020Y 53-123
1400 0652 Transistor - 2SA1287 53-124
1401 0694 Zener Diode - RD 6. 8FB 53-125
1402 0277 Zener Diode - 1Z12 53-126
1402 1050 Silicon Diode - 100V 1A 53-127
1402 1125 Zener Diode - 1W - RD33FB2 53-128
1402 1160 Diode - S5688 53-129
1402 1310 Diode - D1NL20U 53-130
1407 1535 IC - TD62308AP 53-131
1407 2187 TTLIC - SN74LS07NS 53-132
1407 2836 IC - HD74C14FP 53-133
1407 3764 IC - TC7SU04F 53-134
1407 3857 IC - TC7SU04F 53-135
1407 4315 IC - TE7751 53-136
1407 4642 IC - MTD1110 53-137
1407 4672 TTL HD74LS368FP 53-138
1407 4678 EPROM BR93LC56A 53-139
1408 0150 IC - ULN2003AN 53-140
1408 0595 IC - NJM2904M 53-141

71

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

1408 0611 IC - 3771 53-142
1408 0826 IC - TA8428K 53-143
1503 0563 Oscillator - 9.83mtz040 53-144
1601 5295 Resistor - 0.47Ω ±2% 1W 53-145
1601 8157 Variable Resis tor - 100K Ω 53-146
1607 0878 Inductor - BLM21A102S 53-147
1630 3101 Resistor - 100Ω - 1/10W 53-148
1630 3102 Resistor - 1KΩ 1/ 10W ±5% 53-149
1630 3103 Resistor - 10KΩ 1/10W ±5% 53-150
1630 3105 Resistor - 1M Ω ±5% 1/10W 53-151
1630 3204 Resistor - 200K Ω 1/10W ±5% 53-152
1630 3222 Resistor - 2.2KΩ 1/10W ±5% 53-153
1630 3223 Resistor - 22kΩ - 1/10W 53-154
1630 3393 Resistor - 39K Ω 1/10W 53-155
1630 3472 Resistor - 4.7KΩ 1/10W ±5% 53-156
1630 3512 Resistor - 5.10KΩ - 1/10W 53-157
1630 3751 Resistor - 750Ω±5% 1/10W 53-158
1630 3752 Resistor - 7.5K Ω ±5% 1/10W 53-159
1632 0000 Resistor - 0 Ω 1/8W 53-160
1633 0000 Resistor - 0Ω 1/10W:JAMPER CHIP 53-161
1633 1001 Resistor - 1K Ω ±1% 1/10W 53-162
1633 1002 Resistor - 10K Ω ±1% 1/10W 53-163
1633 1050 Resistor - 105 Ω ±1% 1/10W 53-164
1633 2150 Resistor - 215Ω ±1% 1/10W 53-165
1633 3901 Resistor - 3.9 Ω ±1% 1/10W 53-166
1633 7870 Resistor - 787 Ω ±1% 1/10W 53-167
1633 9319 Resistor - 93.1 Ω ±1% 1/10W 53-168
1640 5100 Capacitor - 10µF +20% 35V 53-169
1640 5109 Capacitor - 1µF - ±20% - 50V 53-170
1640 5470 Capacitor - 47µF ±20% 50V 53-171
1660 3101 Capacitor - 100pF 50V 53-172
1660 3471 Capacitor - 470pF 50V 53-173
1660 5332 Capacitor - 3300pF ±10% 50V 53-174
1660 7103 Capacitor - 10000pF 50V 53-175

1660 7104 Capacitor - 100000pF 50V 53-176
1660 7473 Capacitor - 47000pF +80% -20% 50V 53-177

72

73
