Renesas FP-128, 7FF2 User Manual

H8S/2636 Series
FP-128
User System Interface Cable
(HS2636ECH61H)
for E6000 Emulator
User’s Manual
HS2636ECH61HE(B)
1. Renesas neither warrants nor grants licenses of any rights of Renesas’s or any third party’s patent, copyright, trademark, or other intellectual property rights for information contained in this document. Renesas bears no responsibility for problems that may arise with third party’s rights, including intellectual property rights, in connect ion with use of the information contained in this document.
2. Products and product specifications may be subject to change without notice. Confirm that you have received the latest product standards or specifications before final design, purchase or use.
3. Renesas makes every attempt to ensure that its products are of high quality and reliability. However, contact Renesas’s sales office before using the product in an application t hat demands especially high quality and reliability or where its failure or malfunction may directly threaten human life or cause risk of bodily injury, such as aerospace, aeronautics, nuclear power, combustion control, transportation, traffic, safety equipment or medical equipment for life support.
4. Design your application so that the product is used within the ranges guaranteed by Renesas particularly for maximum rating, operating supply voltage range, heat radiation characteristics, installation conditions and other characteristics. Renesas bears no responsibility for failure or damage when used beyond the guaranteed ranges. Even within the guaranteed ranges, consider normally foreseeable failure rates or failure modes in semiconductor devices and employ systemic measures such as fail-safes, so that the equipment incorporating Renesas product does not cause bodily injury, fire or other consequential damage due to operation of the Renesas product.
5. This product is not designed to be radiation resistant.
6. No one is permitted to reproduce or duplicate, in any form, the whole or part of this document without written approval from Renesas.
7. Contact Renesas’s sales office for any questions regarding this document or Renesas semiconductor products.

Preface

Thank you for purchasing this user system interface cable (HS2636ECH61H) for the Renesas’s original microcomputer H8S/2636 series.
The HS2636ECH61H is a user system interface cable that connects an H8S/2636 and H8S/2646 series E6000 emulator (HS2646EPI61H; hereinafter referred to as the emulator) to the IC socket for a FP-128 package for the H8S/2636 series MCU on the user system.
i
Section 1 Configuration....................................................................................1
Section 2 Connection Procedures......................................................................4
2.1 Connecting User System Interface Cable to Emulator Station.........................................4
2.2 Connecting User System Interface Cable to User System................................................6
2.2.1 Installing IC Socket .............................................................................................6
2.2.2 Soldering IC Socket.............................................................................................7
2.2.3 Inserting Cable Head ...........................................................................................7
2.2.4 Fastening Cable Head..........................................................................................8
2.2.5 Fastening Cable Body..........................................................................................10
2.3 Recommended Dimensions for User System Mount Pad.................................................11
2.4 Dimensions for User System Interface Cable Head..........................................................12
2.5 Resulting Dimensions after Connecting User System Interface Cable .............................13
Section 3 Installing the MCU to the User System.............................................14
Section 4 Verifying Operation...........................................................................16
Section 5 Notice ................................................................................................17
ii

Section 1 Configuration

CAUTION
Use an NQPACK128RD socket (manufactured by Tokyo Eletech Corporation) for the FP-128 package IC socket on the user system.
Figure 1 shows the configuration of the HS2636ECH61H user system interface cable for the FP-128 package.
1
Figure 1 HS2636ECH61H User System Interface Cable
2
3
Table 1 lists the HS2636ECH61H components. Please make sure y ou have all of these component s when unpacking.
Table 1 HS2636ECH61H Components
No. Component Quantity Remarks
1 Cable body 1 Flat cable 2 Cable head 1 3 IC socket 1 For the FP-128 package 4 Socket cover 1 For installing anFP-128 packaged MCU 5 Screws (M2 x 10 mm) 4 For fastening cable head 6 Screws (M2 x 6 mm) 4 For installing an FP-128 packaged MCU 7 Guide pins 3 For determining the IC socket location 8 Screwdriver 1 For tightening screws 9 Documentation 1 User’s manual for HS2636ECH61H (this manual)
