Reliable 8000DT Specifications

8000DT

AUTOMATIC CHAINSTITCH DRAPERY TACKER PRODUCT SPECIFICATIONS

AUTOMATIC CHAINSTITCH DRAPERY TACKER

Sewing a 3/4 “ drapery pleat has been virtually impossible with
all but the lightest fabrics until now. We’ve modified the head
and installed the remarkable SewQuiet 5000 DC servomotor for
the extra torque required to tack heavy fabrics

QUALITY YOU CAN COUNT ON

For tacking on all types of drapery work, the 8000DT with
automatic thread trimmer and 8 or 16 stitch setting adjustment
offers the whole package. Low noise and vibration design, and
outstanding build quality; made in Taiwan.

FEATURES

• SewQuiet DC servomotor

• ÜberLight LED light

• Heavy-duty K-legs and table

• Instruction/parts manual included

• Tool kit, drawer and thread stand
included

• Individually tested and sewn-off
before shipping

MAXIMUM SEWING SPEED

FEED LENGTH (LENGTHWISE)

FEED LENGTH (CROSSWISE)

NEEDLE BAR STROKE

NEEDLE SYSTEM #

SEWING THICKNESS

8-16 STITCH SETTING

ADJUSTMENT

LUBRICATION

COUNTRY OF ORIGIN

WARRANTY

1,445 RPM

0.25 – 6.5 mm

2.5 – 6.5 mm

48.6 mm

MT x 190LR #24

Up to 3⁄4“ pleat

Yes

Manual

Taiwan

Limited 1 year
