RCA RTD206, RTD207 User Manual
Home Theater
User’s Guide
RTD206/207
RTD206/207 cover-US 26/4/06 3:56 PM Page 3
FCC Information
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two : (1) This
device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that
may cause undesired operation. This equipment has
been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide
reasonable protection against harmful interference
in a residential installation. This equipment
generates, uses and radiates radio frequency energy
and, if not installed and used in accordance with
the
instruction, may cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation.
In accordance with FCC requirements, changes or
modifications not expressly approved by Thomson
multimedia Inc. could void the user’s authority to
operate this product.
This device generates and uses radio frequency (RF)
energy, and if not installed and used properly, this
equipment may cause interference to radio and
television reception. If this equipment does cause
interference to radio or television reception (which
you can determine by unplugging the unit), try to
correct the interference by one or more of the
following measures:
• Re-orient the receiving antenna (that is, the
antenna for the radio or television that is
“receiving” the interference).
• Move the unit away from the equipment that is
receiving interference.
• Plug the unit into a different wall outlet so that
the unit and the equipment receiving interference
are on different branch circuits.
If these measures do not eliminate the interference,
please consult your dealer or an experienced
radio/television technician for additional
suggestions.
Also, the Federal Communications Commission has
prepared a helpful booklet, “How To Identify and
Resolve Radio TV Interference Problems.” This
booklet is available from the U.S. Government
Printing Office, Washington, DC 20402. Please
specify stock number 004000-00345-4 when ordering
copies.
This product complies with
DHHS Rules 21 CFR
Subchapter J. Applicable at
the date of manufacture.
For Your Safety
The AC power plug is polarized (one blade is wider
than the other) and only fits into AC power outlets
one way. If the plug won’t go into the outlet
completely, turn the plug over and try to insert it
the other way. If it still won’t fit, contact
a qualified electrician to change the outlet, or use a
different one. Do not attempt to bypass this safety
feature.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
CAUTION – To reduce the risk of fire, use only No.
26 AWG or larger telecommunication line cord.
ATTENTION – Pour réduire les risques d’incendie,
utiliser uniquement des conducteurs de
télécommunications 26 AWG au de section
supérleure.
Note:
This DVD player is designed and manufactured to
respond to the Region Management Information. If
the Region number of a DVD disc does not
correspond to the Region number of this DVD
player, this player cannot play the disc. The Region
number for this DVD player is Region No. 1.
SERVICE INFORMATION
This product should be serviced only by those
specially trained in appropriate servicing techniques.
For instructions on how to obtain service, refer to
the warranty included in this Guide.
RFC: CTM-9800723-KS5
Main plug is used as the disconnect device, it shall
remain operable and should not be obstructed
during intended used. To be completely
disconnected the apparatus from supply mains, the
main plug of the apparatus shall be disconnected
from the mains socket outlet completely.
CAUTION
THIS PRODUCT UTILIZES A LASER. USE OF
CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE. DO NOT
OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la class B est
conforme à la norme du NMB-003 du Canada
WARNING
To reduce the risk of fire or electric shock, do
not expose this product to rain or moisture. No
objects filled with liquids, such as vases, should
be placed on the apparatus.
EN
RTD206/207 EN 26/4/06 3:22 PM Page 2
CAUTION
RISK OF ELECTRIC SHOCK
THE LIGHTNING
FLASH AND ARROWHEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
"DANGEROUS
VOLTAGE" INSIDE
THE PRODUCT.
WARNING: TO PREVENT FIRE
SHOCK HAZARD,
TO RAIN OR MOISTURE.
DO NOT OPEN
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
DO NOT EXPOSE THIS PRODUCT
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
OR ELECTRICAL
Illustrations contained in this document are for representation only.
Table of Contents
1
Connections and Setup
Things to consider before you connect ....................2
Accessories provided ..................................................2
Front panel controls...................................................3
Connecting to audiovisual equipment ......................4
Connecting the speakers ............................................5
Positioning speakers ..................................................5
Front speaker placement...........................................6
Preferred surround placement .................................6
Test tone/Channel balance ........................................7
The Remote Control
Remote control functions in DVD/CD mode .............8
Remote control functions in TUNER mode ...............9
Using the remote to Navigate through On-Screen
Menus...........................................................................9
Inserting batteries in the remote control .................9
Playing Discs – Basic Functions
Compatible discs ......................................................10
Compatible formats .................................................10
Regional coding ........................................................10
Operating the DVD receiver ....................................10
Loading discs............................................................. 10
Playing discs ............................................................. 10
Types of Menus ........................................................11
Basic Playback Operations .......................................11
Playback ....................................................................11
Accelerated play .......................................................12
Pause .........................................................................12
Frame advance ..........................................................12
Variable slow motion ...............................................12
Changing chapter/track ...........................................12
Zoom .........................................................................12
The Info Menu
Using the Info menu ................................................13
Title/chapter (DVD)/track (audio CD and VCD) ......14
Time display................................................................14
Audio (DVD, VCD) .....................................................14
Subtitles (DVD) ..........................................................14
Camera angle (DVD) .................................................14
Play mode (all discs exceot mp3/WMA/JPEG) .........15
Creating a Program list for Play mode
(Audio CDs, DVD and VCD discs)..............................15
Creating a Program list for Play mode
(mp3 CDs)...................................................................15
Bookmark (DVD and audio CD) ...............................16
Sleep ..........................................................................16
PBC.............................................................................16
IntroScan....................................................................16
mp3/WMA Files and JPEG Files
Playing mp3/WMA Files or displaying JPEG
files.............................................................................17
Radio
Manual Tuning..........................................................18
Storing radio stations................................................18
USB
Connecting/Disconnecting USB devices to the Main
Unit............................................................................19
USB Device Playback Features..................................19
The Setup Menu
General Setup............................................................20
Password.............................................................20
Rating..................................................................21
Slide Time............................................................21
Default................................................................21
Display Setup.............................................................21
Display Type.........................................................21
Dark Level...........................................................21
Video...................................................................22
Speaker Setup...........................................................22
Night Mode........................................................22
Distance..............................................................22
Test Tone.............................................................22
Language Setup........................................................23
Player
Menu.........................................................................23
Audio..................................................................23
Subtitles..............................................................23
Disc Menu...........................................................23
Additional Information
Troubleshooting.........................................................24
Precautions.................................................................25
Disc Formats you can play.........................................26
Sound Enhancement Systems...................................27
Limited Warranty......................................................28
EN
RTD206/207 EN 26/4/06 3:22 PM Page 3
Illustrations contained in this document are for representation only.
Connections and Setup
Things to consider befor
e you connect
• Ensure that the mains supply in your house complies with that indicated on the identification
sticker located on the back of your unit.
• Install your unit horizontally, away from any source of heat (fireplace) or appliances creating
strong magnetic or electromagnetic fields. The components of this unit are sensitive to heat. The
maximum ambient temperature should not exceed 35° Celsius/95 Fahrenheit.
• Leave enough space around the unit to allow adequate ventilation: 10 cm/4 inches on either side
and above the top, and 5 cm/2 inches at the rear.
• The humidity of the room should not exceed 75%. If you have to use the unit outdoors, do not
expose it to rain or splashing water. The apparatus should not be exposed to dripping or
splashing and no objects filled with liquids, such as vases, should be placed on the apparatus.
• Moving the unit from a cold place to a warm one can cause condensation on some components
inside the unit. Let the condensation disappear on its own before turning the unit on again.
• Before moving the player, make sure the disc tray is empty.
• Where the mains plug or an appliance coupler is used as a disconnect device, the disconnect
device shall remain readily operable.
Other important use and cleaning information at the end of the booklet.
Accessories provided
Caution!
Invisible laser radiation when open. Avoid exposure to beam. Class 1 laser product. This system
must be opened only by qualified technicians to prevent accidents caused by the laser beam.
DVD copy protection
In accordance with the DVD standard, your DVD player is equipped with a Copy Protection system,
which can be switched on and off by the DVD disc itself, in order to make any recording of the
relevant DVD disc onto a videotape of very poor picture quality, or even impossible. This product
incorporates copyright protection technology that is protected by method claims of certain
U.S. patents and other intellectual property rights owned by Macrovision Corporation and other
rights owners. Use of this copyright protection technology must be authorized by Macrovision
Corporation, and is intended for home use only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
Remote control and 2
non-rechargeable AAA
batteries
Left and right rear speakers
2
One Pig-Tail
antenna wire
Left and right
front speakers
One external AM loop
antenna
Subwoofer
Center speaker
Composite
video cable
EN
RTD206/207 EN 26/4/06 3:22 PM Page 4
+ -
+ -
Illustrations contained in this document are for representation only.
Connections and Setup
Fr
ont panel controls
OPEN/CLOSE - Open and close the disc tray.
SUBWOOFER - Toggle between different subwoofer output levels.
DISC SKIP – Goes to the next slot in the disc tray.
STOP - Stop disc playback.
PLAY/PAUSE - Start playing a disc. Pause.
SOURCE - Select the input source.
VOLUME - Adjusts the volume.
Surround sound light indicator - The LED lights when Surround mode is active.
ON/STANDBY - Switch the unit on and off.
USB Socket - Connects USB devices.
Connecting the Antennas
The AM and FM antennas connect to the AM and FM terminals on the system’s back panel.They
must be hooked up in order to receive clear reception.
AM Loop Antenna and FM Indoor Antenna
1. Uncoil the AM Antenna wire.
2. Press down on the Antenna tab to open the terminal
Note: Make sure the white wire on the AM lop antenna is inserted into
the upper AM LOOP terminal.
3
EN
RTD206/207 EN 26/4/06 3:22 PM Page 5
FM 75
AM LOOP
GND
White
Ω
Illustrations contained in this document are for representation only.
Connections and Setup
Connecting to audiovisual equipment
Explanation of jacks and cables
The jacks on the back of your receiver (pictured left) and
the cables shown below are used to connect to other
components.
The video jacks are OUT jacks, which need to be
connected to IN jacks on the TV or monitor you’re
connecting to (so the video content goes from the
receiver to the screen). The audio jacks are IN jacks,
which need to be connected to OUT jacks
on the component you’re connecting to, so the sound
from the component comes into the receiver (and out
through the speakers).
Video cables
Composite video cable (included)
The basic Video jack (usually color-coded yellow) is also referred to as composite
video. Usually the video cable is bundled with the audio cables (white and red).
Component video cables (Pr, Pb, Y) (not included)
The Y, Pb, Pr jacks provide optimum picture quality by separating the video
signal into three parts. To ensure maximum picture quality, use three videograde cables for the connection. You can also buy bundled component video
cables that are color-coded to match the Y, Pb, Pr inputs (green, blue and red).
Note: If your television is a high definition television, use the DVD player’s progressive scan output
to get the highest possible video resolution. Set the Progressive Scan option in the Display menu
to On (see page 20).
Note: If one of the devices is not working, check that all the cables have been inserted
properly into the jacks.
Audio cables (not included)
AUDIO IN L (left) and AUDIO IN R (right)
These jacks and cables are often color-coded (red for right audio, and white for
left audio).
Note: If your component has only one input for audio (mono), connect it to the left (white
L/Mono) audio jack on the TV and don’t connect the right audio part of the cable.
4
Component
video cable
Audio cables
(red and white)
Composite
video cable
EN
RTD206/207 EN 26/4/06 3:22 PM Page 6
S-VIDEO
Illustrations contained in this document are for representation only.
Connections and Setup
Connecting the speakers
Six speakers are provided with the unit (2 front,
1 center, 2 rear, 1 subwoofer). To achieve good
surround effects, all six speakers need to be
connected to the receiver.
One speaker wire is provided with each
speaker. Speaker wires are color-coded to
match the terminals.
Connect the speaker wire from the back of
each speaker to the corresponding color
terminal at the back of the unit. Press down
the tab to open the terminal and insert the
wire (1). Release the tab to lock wire in the
terminal (2). Do the same for center speaker,
rear speakers and the subwoofer.
Note: When connecting the speakers, make sure
the polarities (“+” speaker wire to “+” on the
receiver) of speaker wires and terminals match.
If the cords are reversed, the sound will be
distorted. Do not ground the output line, it will
damage the speaker.
Positioning speakers
Left, Right (Front Speakers)
Front speakers carry primarily music and sound
effects.
Center
In surround mode, the center speaker carries
most of the dialog as well as music and effects.
It should be set between the left and right
speakers.
Surround (Rear Speakers)
The rear speakers’ overall sound balance should
be as close as possible to the front speakers.
Proper placement is vital to establish an evenly
distributed sound field.
Subwoofer
A subwoofer is designed to reproduce powerful
low bass effects (explosions, the rumble of
spaceships, etc.) which dramatically heighten
the action on the screen.
1
2
3
5
Courtesy Dolby Laboratories
1
1
3
3
2
EN
RTD206/207 EN 26/4/06 3:22 PM Page 7
Illustrations contained in this document are for representation only.
Front speaker placement
Follow the suggestions for speaker placement below to
get the best results.
Alignment
Align the center speaker evenly with (A) or slightly
behind (B) (the left and right speakers), but not ahead
of them.
Angle
Place the left and right speakers to form a 45-degree
angle with your favorite viewing position to duplicate
the soundtrack mixer’s perspective.
Height
The mid- and high-frequency drivers of the three front
speakers should be as close as possible to the same
height. This often requires placing the center speaker
directly on top (A) or beneath (B) the TV set.
Preferred surround placement
Location
If possible, place surround speakers to either side of the
listening area, not behind it.
Height
If space permits, install surround speakers 2-3 feet above
viewers. This helps to minimize localization effects.
Aiming
Aim surround speakers straight across the room, not
down at viewers, to help create a more open, spacious
surround sound field.
Alternative Surround Placement
Rear wall
If rear wall mounting is the only choice, aim the
speakers at each other (A), towards the front (B) or
towards the sidewalls (C, D). Experiment with placement
until sounds seem to surround you, rather than come
from behind you.
Connections and Setup
Magnetic shielding
Speakers placed less than two feet from the TV set must be magnetically shielded in order to
prevent picture distortion. Front and center speakers provided with this unit are magnetically
shielded to protect your TV set.
Note: It is not recommended to place the rear speakers and subwoofer near the TV set.
Courtesy Dolby Laboratories
Courtesy Dolby Laboratories
6
A
B
Courtesy Dolby Laboratories
Courtesy Dolby Laboratories
EN
RTD206/207 EN 26/4/06 3:22 PM Page 8
Illustrations contained in this document are for representation only.
No adjacent walls
Surround speakers can go on stands facing each
other to approximate sidewall mounting (A), or
to the sides or rear of the viewing area, aimed
upwards; they can go right on the floor, or
preferably, a few feet off the floor such as on
end tables (B).
Test tone/Channel balance
Channel balance
Your receiver is equipped with a test signal
generator for balancing the channels. As the
signal “travels” from channel to channel, adjust
the level controls until each channel plays at
the same loudness level (see page 22).
Level adjustment and surround channel
level expectation
Even though you adjust the surround channel
to be as loud as the others on the test signal,
on actual program material the surround
channel is usually much lower than the front.
Don’t re-adjust the surround level; program
producers use surround for subtle atmospherics
and ambience, and only rarely for special
effects.
Connections and Setup
7
Courtesy Dolby Laboratories
EN
RTD206/207 EN 26/4/06 3:22 PM Page 9
Illustrations contained in this document are for representation only.
Remote control functions in DVD/CD
mode
ON•OFF -Switches the unit on and off.
DVD - Selects the DVD mode.
TUNER - Selects the TUNER and changes between
AM/FM mode.
USB - Selects the USB.
AUX - Selects the AUX.
0-9 - Number entry. Press 1 through 5 to
directly access a disc in the disc tray.
CLEAR - Quit the current setting manual from the
TV screen without saving change.
INFO - Accesses the Info menu.
TITLE - Accesses the disc menu for DVD disc.
DISC MENU - Accesses the disc menu during
playback (if there is one) or turn on/off PBC for VCD
disc.
OK - Confirm your selection.
MUTE - Mutes and restores the sound.
SETUP - Enter Setup menu.
RETURN - In DVD/CD mode, returns to the
previous menu.
VOL +/- - Adjusts the sound volume.
CH +/- - Directly accesses the next or previous
chapter (DVD) or track (CD). Selects programmed
stations in TUNER mode.
REV - Starts reverse accelerated play or reverse
slow motion.
PLAY - Starts playing a disc.
FWD - Starts forward accelerated play or forward
slow motion. When playback is paused, press to
advance one frame at a time.
REC - Function not available on this model
STOP - Stops playback.
PAUSE - Freeze frame, frame advance or slow
motion.
AUDIO - Accesses the audio function of the
Info menu.
ANGLE - Accesses the camera angle function.
ZOOM - Accesses the Zoom function.
SUBTITLE - Selects the subtitle languages or turns
subtitle off (if available).
MEMORY - Stores station in tuner mode.
SLEEP - Enters sleep mode and selects sleep time.
(not available in AUX/TUNER mode)
SUBWOOFER - Selects among subwoofer output
levels among softe/balance/strong/powerful.
SUb1/SUb2/SUb3/SUb4 will be displayed on the front
display respectively.
RANDOM - Turns on/off random playback.
REPEAT - Accesses the repeat function of the Info
Menu.
EQ LEVEL - Toggles channels for channel level
settings.
SURROUND - Changes the Surround sound setting
The Remote Control
The r
emote control
Navigating through menus
Use the direction buttons to navigate through the menus. Press the OK button on the remote
control to confirm your selection.
8
EN
RTD206/207 EN 26/4/06 3:22 PM Page 10
Loading...
