Page 1
RCT6672W23
7 Mercury
User Manual
English (EN)
BC
It's important to read these instructions prior to using your
new product for the first time.
Page 2
Safety Precautions
EN
Equipment tested for
compliance as a
RCT6672W23
complete unit
FCC Information
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
EN - 1
Page 3
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio /TV
technician for help.
Warning: Changes or modifications not expressly
approved by the party responsible for compliance (MLB
International Inc., P.O. Box 1535, Buffalo, NY 14226, Tel:
516-236-4556)could void the user’s authority to operate
the equipment.
CAN ICES-3(B) / NMB-3(B)
Warning: The AC adapter is used as disconnect device
and it should remain readily operable during intended
EN
use. In order to disconnect the mains plug from mains
completely, the AC adapter should be disconnected from
the mains socket outlet completely.
Service Information
This product should be serviced only by those specially
trained in appropriate servicing techniques. For instructions
on how to obtain service, refer to the warranty included in
this guide.
EN - 2
Page 4
IMPORTANT SAFETY INSTRUCTIONS
EN
PLEASE READ AND
SAVE THIS FOR FUTURE REFERENCE
Some of the following information may not apply to your
particular product; however, as with any electronic product,
precautions should be observed during handling and use.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
• Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
• Only use attachments / accessories specified by the
manufacturer.
• Unplug this apparatus during lightning storms or when
unused for long periods of time.
EN - 3
Page 5
• Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
ADDITIONAL SAFETY INFORMATION
• The AC adapter and apparatus shall not be exposed to
dripping or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
• Always leave sufficient space around the product for
EN
ventilation. Do not place product in or on a bed, rug,
in a bookcase or cabinet that may prevent air flow
through vent openings.
• Do not place lighted candles, cigarettes, cigars, etc. on
the product.
• Care should be taken so that objects do not fall into
the product.
• Do not attempt to disassemble the cabinet. This
product does not contain customer serviceable
components.
• To prevent the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
• Do not play your headset at high volume. Hearing
experts warn against extended high-volume play.
EN - 4
Page 6
EN
Contents
Safety Precautions ............................................ 1-2
Important Safety Instructions .................................. 3-4
Startup ....................................................................... 6-12
Overview of Controls ..................................................... 6-7
Buttons .......................................................................... 7-8
Accessory ........................................................................ 8
Navigating the Home Screen ....................................... 9-12
Connections ............................................................ 13-18
Battery Management and Charging ........................... 13-14
Micro-USB ...................................................................... 15
Headphone .................................................................... 15
Micro SD ......................................................................... 16
Wi-Fi ......................................................................... 17-18
VPN ............................................................................... 18
Basic Operation ...................................................... 19-26
First Time Operation ...................................................... 19
Basic Operation ........................................................ 19-21
TM
Google Now
................................................................ 21
Voice Search & Voice Actions ......................................... 22
Google PlayTM ................................................................. 23
Settings ..................................................................... 23-25
GoogleTM ................................................................... 25-26
Preinstalled Apps ......................................................... 26
Additional Information ............................................ 26-28
Trouble Shooting ....................................................... 26-27
Specifications ............................................................ 28
Copyright and Trademark Notices .................................. 28
Limited Warranty ..................................................... 29-32
EN - 5
Page 7
Startup
Overview of Controls
EN
Front Camera
Rear Camera
Power Button
Headphone Jack
Microphone
Micro-USB Port
DC Jack
Vol+/- Button
Micro
SD Card Slot
Reset
Speaker
EN - 6
Page 8
Item Description
EN
Power Button
Press to enter standby/wake up
mode, press and hold to switch On/
Off the unit.
Headphone Port Headphone connection for personal
listening.
Microphone For voice input.
Micro-USB Port MINI USB Port, connect to a PC or
USB storage device; for charging.
DC Jack Connect with 5V DC charger.
Vol+/- Key Press to increase/decrease the
volume.
Micro SD Card Slot Accepts micro SD card (up to 32G).
Reset Reset the tablet.
Buttons
Power Button
Power the Tablet On
Press & hold the Power
appears.
button until the RCA logo
Power the Tablet Off
Press & hold the Power
button until a message box
displays. Select "Power off". Tap "OK" and the tablet will
be powered off.
EN - 7
Page 9
Sleep Mode
Briefly press the Power button to put the tablet in sleep
mode.
If you don’t operate for some time, the tablet will enter
sleep mode automatically.
Tip: You can go to Settings > DEVICE > Display >
Sleep to set the screen timeout.
Wake the Tablet from Sleep Mode
Press the Power button to wake the tablet from sleep
mode.
Vol +/- Button
Press the Vol +/- button to increase or decrease the
EN
volume.
Tip: You can go to Settings > DEVICE > Sound
> Volumes to adjust volume settings for Music,
Video,Games & other media, Notifications and Alarms.
Accessory
The following accessory is included.
AC Adapter ............................................................................. x1
EN - 8
Page 10
Navigating the Home Screen
EN
Notication Bar
Google
Search
Status Bar
TM
Back
Home Speakers
Recent
Apps
All App
App Icons
Settings
EN - 9
Page 11
Notification & Status Bar
Some indicators that inform you about the status of your
tablet are shown at the top of the screen.
Notification Shade
Notifications may come from the system, a game, an
application such as E-mail, or the music player.
When Notifications are available, related icons will
appear in the top left corner of the screen. To open the
Notification Shade, touch the Notification icon and swipe
your finger down. Some notifications allow you to take
specific actions by tapping icons within the notification.
After you are finished with a notification, just slide
EN
it away to the left or right. If you want to dismiss all
notifications, tap the Dismiss icon
at the top of the
notification.
Status Bar & Quick Settings
The Status Bar in the top right corner shows various
indicators, including Wi-Fi connection and battery status.
To access "Quick Settings", touch the status bar and
swipe down. You can then adjust various settings on the
tablet by touching the corresponding square.
EN - 10
Page 12
Notification & Status Icons
The below table lists some of the frequently used icons
EN
in the Notification & Status bar:
Item Description
Message Received new message.
Music The Google Play Music app is
running.
Screenshots Screenshot captured.
USB tethering Has connected to a PC and the
USB tethering is turned on.
Wi-Fi Has a Wi-Fi Internet connection.
Play Store An update for an app is available.
Home Screen Icons
All Apps
Tap the All Apps icon
In All Apps screen, you can:
to enter the All Apps screen.
• Move between screens: Slide left or right.
• Open an App: Tap its icon.
• Copy an App icon to the Home screen: Press & hold
the icon or widget icon and slowly to drag it to the
Home screen.
• View widgets: Tap the widgets tab at the top of a All
EN - 11
Page 13
Apps screen. Widgets are app information displays
that can be placed on your Home screen.
• Get more apps: Tap the Google Play Store icon
.
• View info about an App: Press & hold it, and drag it to
the top of the screen, then drop the app over the App
Info icon
Tip: Most apps include a Menu icon
i
.
near the top or
bottom of the screen that lets you control the app’s
settings.
Back
Tap Back icon
to return to the previous screen.
• The Back icon remains on the bottom of the screen at
EN
all times, allowing you to navigate back to the previous
screen.
• Once you go back to the Home screen, you can’t go
back any further in your history.
Home
Tap Home icon
from anywhere on your tablet to
return to the Home screen.
Recent Apps
Tap Recent Apps icon
to view recently used apps.
Tap an app to use it again.
You can slide down to see more apps. You can also slide
it away to the left or right.
Speakers
&
Tap Speaker icon to increase volume.
Tap Speaker icon
to decrease volume.
EN - 12
Page 14
EN
Connections
Battery Management and Charging
The tablet has a built-in rechargeable battery.
Battery Icon
The battery icon in the upper-right corner shows the
battery level or charging status.
Full battery
Low battery Need to be
Charging the Battery
To DC Jack
Charging
charged
AC Adapter
To Wall Outlet
Note: In order to keep the battery working in best
condition, please pay attention to the following:
• The included AC adapter is for use with this unit only.
Do not use it with other equipment.
• Please do not charge the battery in high temperatures.
• Do not wait for the battery to be fully depleted before
EN - 13
Page 15
charging again. Keep the battery charged as needed.
• If tablet has not been used for a long period of time,
the battery might be in over discharge protection mode
and may take longer to charge.
Prolong the Battery Life
Here are some tips for how to prolong the life of the
battery:
• If you aren’t using Wi-Fi, go to Settings > Wireless &
Networks >Wi-Fi, turn it off.
• Don’t leave the Maps or Navigation apps open on the
screen when you’re not using them.
EN
• Turn down screen brightness and set a shorter screen
timeout: Settings > Device >Display.
• If you don’t need it, turn off automatic syncing for all
apps: Settings > Accounts >[Google account-name].
This means you need to sync manually to collect
messages, email, and other recent information, and
won’t receive notifications when updates occur.
EN - 14
Page 16
EN
Micro-USB
Connect your tablet to a PC or a USB storage device
with a USB cable (not included), to transfer music,
pictures and other files in both directions.
Note: To change your tablet’s USB connection options,
you should go to Settings > Device > Storage, and tap
Menu icon
at the upper right corner. Then tap USB
computer connection to enter to setup.
The tablet can be connected to a keyboard, a mouse or
other input devices via USB cable and use it just as you
would with a PC.
Headphone
Headphone can be connected to the tablet’s Headphone
Jack.
To headphone Jack
Headphone (not included)
EN - 15
Page 17
Micro SD
To Micro SD Card Slot
Micro SD Card
(not included)
Insert the micro SD card, with contacts facing the
EN
screen, into the tablet’s Micro SD slot until it clicks.
To check the storage of the micro SD card, go to
Settings > Device > Storage.
Remove the micro SD card by pushing in on the card's
edge. The card will pop out and can be removed.
Notes:
• You can use microSD
TM
card and microSDHCTM card (up
to 32GB, SD card not included).
• Never remove or insert micro SD card in On mode.
EN - 16
Page 18
EN
Wi-Fi
Connect to a Wi-Fi Network
1. Go to Settings > Wireless & networks > Wi-Fi, and
slide the Wi-Fi switch to the ON position.
2. The device will scan Wi-Fi networks automatically and
display the available names.
• If the device finds a network that you connected to
previously, it will connect to it automatically.
3. Tap a network name to connect to it, and enter a
password if necessary.
4. Alternatively, if your Wi-Fi router supports Wi-Fi
Protected Setup, tap the WPS icon
at the top of
the screen, and then press the WPS button on your
router.
EN - 17
Page 19
5. If your network does not broadcast its SSID, tap the
Plus icon + at the top of the screen, and enter the
Network SSID (name) of the network. If necessary,
enter security or other network configuration details.
Note: you can tap Menu icon
at the upper right corner
in the Settings screen for advanced settings.
VPN (Virtual Private Network)
You can create virtual private network (VPN) and
connect to your private network securely through a
public network, such as the internet. You must set a lock
EN
screen PIN or password before you can use credential
storage.
Add VPN network and follow the instructions on the
screen.
EN - 18
Page 20
EN
Basic Operation
First Time Operation
Turning Your Tablet On for the First Time
When using the tablet for the first time, you will be
required to setup the following:
1. Select the language, then tap
.
2. Set the Wi-Fi.
3. If you have a Google Account, select "Yes". Then tap
a network name to see more details or connect to it,
and enter a password if necessary.
When prompted, sign in using the email address and
password for your Google Account. If you don’t have
one yet, go ahead and create one.
4. Follow the onscreen instructions to setup the tablet.
Basic Operation
Using the Touchscreen
Here are some basic procedures for interacting with the
touchscreen.
Tap
To select an item on the touchscreen,
lightly tap it.
EN - 19
Page 21
Press & Hold
In some instances, touching the item and
holding your finger on it will present other
options or menus.
Drag or Swipe
While holding an item such as an icon, it
can sometimes be moved by dragging it
to another area or screen. You may also
be able to swipe your finger across a
screen or item to navigate or move it.
EN
Zoom
By placing two fingers on the screen, you
can slide them apart to "Zoom In", or
pinch them together to "Zoom Out".
EN - 20
Page 22
Customizing the Home Screen
• From All Apps screen to Home screen: Tap All Apps
EN
icon
to open All Apps screen,press & hold an icon
or widget and slowly to drag it to the location of your
choice. This makes it much easier to change your
Home screen layout.
• Moveappsorwidgets:Press&holdaniconorwidget,
slowly to drag it to the screen edge, the screen will
switch.
• Deleteappsorwidgets:Press&holdaniconor
widget, when the "X" icon appears at the left of the
screen, drag the icon or widget into it.
• Press&holdthewallpaperon yourHomescreen,and
choose your wallpaper from Gallery, Live Wallpapers ,
Photos or Wallpapers.
Google Now
To create a truly personalized experience, using your
location and personal Google account information, use
Google Now. Touch and Hold the Home icon, and slide
up to the Google Now icon. Follow the instructions to
setup your Google Now experience.
EN - 21
Page 23
Voice Search & Voice Actions
Turn Voice Search or Voice Action On
You can initiate a Voice Search or Voice Action by
tapping the Microphone icon in the top left corner of the
Home screen.
When you’re viewing the Google Now screen, you don’t
have to touch anything. Just say “Google.”
Note: To detect when you say "Google" to launch Voice
Search or Voice Actions, your tablet analyzes sound
picked up by your tablet's microphone in intervals of a
few seconds or less.
Using Voice Search
EN
After tapping the microphone icon, just say whatever it is
you want Google to search for.
Using Voice Actions
There are many actions that the tablet can perform using
"Voice Actions". For example, you can send emails, set
alarms, play a song, or navigate to a website. Just tap
the Microphone icon, and say what you want the tablet
to do. As you speak, Voice Search analyzes your speech
and initiates the action.
If Voice Search doesn’t understand you, it lists a set of
possible meanings. Just tap the one you want.
EN - 22
Page 24
Google Play
In addition to the apps that come preinstalled on your
EN
TM
tablet, you can download Android
apps and games,
music, movies, TV shows, and magazines on Google
Play.
1. On the App menu, touch the Google Play Store icon.
2. To search for an item from the Google Play Store app,
touch the search icon in the upper right corner, and
then type a keyword to search.
3. Touch an available item to go to its details page. From
there you can install or download the item.
Settings
Settings lets you configure the tablet, set app options,
add accounts, and change other preferences.
WIRELESS & NETWORKS
Wi-Fi—Enable or disable Wi-Fi, and connect to a
wireless network so that you can check email, search
the Web, or access social media websites.
More... —Enable or disable Airplane mode or VPN.
DEVICE
Sound—Set Volumes, Default notification sound,
and enable or disable Touch sounds and Screen lock
sound.
Display—Set Brightness, Wallpaper, Sleep, Daydream,
Font size, Cast screen and Full screen mode.
EN - 23
Page 25
ScreenshotSetting—Set Select delay time to capture
the screen, Set the location of screenshot storage and
enable or disable Show the screenshot button in the
statusbar.
Storage—View available space in INTERNAL STORAGE,
SD CARD and USB STORAGE /set the related items.
Battery—View battery status.
Apps—View downloaded apps and running apps. To view
information or uninstall an app, tap the relevant app.
User—Set users & Profiles
PERSONAL
EN
Location —Enable or disable Mode ,RECENT LOCATION
REQUESTS and LOCATION SERVICES.
Security—Set preferences for SCREEN SECURITY,
ENCRYPTION,PASSWORDS,
DEVICE ADMINISTRATION, CREDENTIAL STORAGE
and USER Experience Program.
Language & input—Set preferences for Language,
KEYBOARD & INPUT METHODS, SPEECH and
MOUSE/TRACKPAD.
Backup & reset—Set preferences for BACKUP &
RESTORE, and PERSONAL DATA.
ACCOUNTS
You can add an email account or another type of
account.
EN - 24
Page 26
SYSTEM
Date & time—Enable or disable Automatic date & time,
EN
and select preferences for date, time, time zone, time
format, and date format.
Accessibility—Select preferences for SERVICES and
SYSTEM.
Printing — Enable or disable PRINT SERVICES.
About tablet
Check System updates, Status, Legal information etc.
Google
A Google Account lets you organize and access your
personal information from any computer or mobile device.
Add an Account
You can use multiple Google Accounts and Microsoft
Exchange ActiveSync accounts on your tablet.
You may also be able to add other kinds of accounts,
depending on your apps. To add some accounts, you may
need to obtain details from your system administrator
about the service to which the account connects. For
example, you may need to know the account’s domain or
server address.
1. Go to Settings > ACCOUNTS > Add account.
2. Tap the kind of account to add. And then follow the onscreen instructions.
EN - 25
Page 27
Remove an Account
To remove a Google account, go to
Settings > ACCOUNTS > Google > [account- name]
Menu icon
> Remove account.
Preinstalled Apps
Your tablet comes with many apps preinstalled to allow
you to browse the web, send and receive email, and
access entertainment. Spend some time exploring these
apps to learn how your tablet can be most useful for you.
Additional Information
EN
Trouble Shooting
Tablet displays network or service error message
• When you are located in places with poor signals, your
tablet may lose its Wi-Fi connection. Try moving closer
to the Wi-Fi router.
Touch screen response is slow or incorrect
If the tablet’s touch screen response is incorrect, please
try the following:
• Remove any protective film of the touch screen. The
protective film may prevent the device recognition input.
• Make sure that your fingers dry and clean before you
tap the touch screen.
• Restart the tablet to clear any temporary software bugs.
EN - 26
Page 28
Tablet is frozen or a serious error appears
• If the tablet is frozen or suspended, you may need to
EN
close the app program or reset the tablet.
• If the tablet is frozen or slow to respond, press & hold
the power button for 8 seconds to reset the tablet.
• If that doesn't work, insert a paper clip into the RESET
hole on the back of the tablet.
Tablet gets warm
• When using for a long time, the tablet may be warm.
This is normal and will not affect the life or performance
of the unit.
Tablet can not show video of opposite side during skype
call
• The Wi-Fi signal is poor. Please move close to your
wireless router, or disconnect other devices from your
wireless router, or increase bandwidth of internet
connection.
• PleasechecktheWi-Fisetting.It'srecommendedtouse
an IEEE 802.11 b/g/n certified Wi-Fi network.
EN - 27
Page 29
Specifications
Power: DC IN 5V (operate with AC adapter)
Front camera: 0.3 Megapixe, rear camera: 2.0 Megapixe
Copyright and Trademark Notices
Android, Google, Google Play and other marks are
trademarks of Google Inc.
The Wi-Fi CERTIFIED Logo is a certification mark of the
EN
Wi-Fi Alliance. The Wi-Fi Protected Setup Mark is a mark
of the Wi-Fi Alliance.
Specifications subject to change without notice.
EN - 28
Page 30
Limited Warranty
AVC MULTIMEDIA (“AVC”) makes the following limited
EN
warranty. This limited warranty extend to the original
consumer purchaser and is limited to non-commercial use
of the product.
One Year Parts & Labor Warranty
AVC products purchased in the United States or Canada are
warranted to be free from defects in materials or workmanship
for a period of one year from the date of their original retail
purchase. If the unit fails to conform to this warranty, we
will service the product using new or refurbished parts and
products, at AVC’s sole discretion.
During a period of one year from the effective warranty date,
AVC will provide, when needed, service labor to repair a
manufacturing defect at its designated Service Center. To
obtain warranty service in the United States or Canada,
you must first call our Customer Support Center at 1-877-
252-6873 or 1-855-475-9646, during the hours listed in
the box below. The determination of service will be made
by AVC Customer Support. PLEASE DO NOT RETURN
YOUR UNIT TO AVC WITHOUT PRIOR AUTHORIZATION.
New or remanufactured replacements for defective parts or
products will be used for repairs by AVC at its designated
Service Center for one year from the effective warranty date.
Such replacement parts or products are warranted for an
additional one year from the date of repair or replacement.
The Customer will be required to ship the unit to the Service
Center indicated at the time Customer Support is contacted
to make the necessary repairs. The customer is responsible
for all transportation charges to the service facility.
EN - 29
Page 31
Packaging and Shipping Instruction
When you send the product to the AVC service facility you
must use the original carton box and packing material or an
equivalent as designated by AVC.
Your Responsibility
(1) You must retain the original sale receipt to provide proof
of purchase.
(2) These warranties are effective only if the product
is purchased and operated in the United States or
Canada.
(3) Warranties extend only to defects in material or
EN
workmanship, and do not extend to any product or
parts which have been lost or discarded, or damage
to product or parts caused by misuse, accident,
improper operation or maintenance, or use in violation
of instructions provided with the product, or to
product which has been altered or modified without
authorization of AVC, or to products or parts thereof
which have had the serial number removed or changed.
Out of Warranty
In the event your product requires repair after the
limited warranty period has expired, please contact our
Customer Support Center at
1-877-252-6873 or 1-855-475-9646 or
www.RCAtablets.com
Hours: Monday–Thursday: 9am–7pm,
Friday: 9am–5pm, Saturday: 9am–NOON Eastern
time.
Important: You are responsible for any transportation,
shipping or insurance relative to the return of product to
our Product Returns Center.
EN - 30
Page 32
All warranties implied by state law, including the implied
warranties of merchantability and fitness for a particular
EN
purpose, are expressly limited to the duration of the
limited warranties set forth above. With the exception of
any warranties implied by state law as hereby limited,
the foregoing warranty is exclusive and in lieu of all other
warranties, guarantees, agreements and similar obligations
of manufacturer or seller with respect to the repair or
replacement of any parts. In no event shall AVC be liable
for consequential or incidental damages.
No person, agent, distributor, dealer or company is
authorized to change, modify or extend the terms of these
warranties in any manner whatsoever. The time within
action must be commenced to enforce any obligation of
AVC arising under the warranty or under any statute, or
law of the United States or Canada or any state thereof,
is hereby limited to one year from the date of purchase.
This limitation does not apply to implied warranties arising
under state law.
This warranty gives you specific legal rights and you
may also have other rights, which may vary, from state to
state. Some states do not allow limitation on how long an
implied warranty lasts, when an action may be brought, or
the exclusion or limitation of incidental or consequential
damages, so the above provisions may not apply to you.
For more information on other products and services,
please visit our web site at :
EN - 31
Page 33
www.RCAtablets.com
Important: Also keep your “Bill of Sale” as proof of
purchase.
FOR SUPPORT, SERVICE AND REPAIR, PLEASE VISIT
www.RCAtablets.com
Specifications and external appearance are subject to change
without notice.
© 2014 AVC MULTIMEDIA
EN
EN - 32
Loading...
