Epoca
Epoca
CARROZZERIA
BODY TAV.10310/04
CARROCIERIAE
Rif. |
CODICE |
DESCRIZIONE |
DESCRIPTION |
DESCRIPCION |
00 |
10705265 |
KIT SCALDATAZZE 2GR. |
KIT HEAT-CUP 2GR. |
KIT CALIENTA TAZAS 2GR.. |
002 |
32331064 |
TETTOIA 2GR. |
TOP 2GR |
COBERTIZO 2GR |
003 |
38123754 |
FIANCHETTO ROSSO SX |
SIDE PANEL RED SX |
LATERAL ROJO SX |
|
38123758 |
FIANCHETTO GRIGIO SX |
SIDE PANEL GREY SX |
LATERAL GRIS SX |
005 |
38123755 |
PANNELLO COMANDI 2GR |
CONTROL PANEL RED 2GR |
PANEL BOTON ROJO 2GR |
|
38123759 |
PANNELLO COM.GRIGIO 2GR |
CONTROL PANEL GREY 2GR. |
PANEL BOTON GRIS 2GR |
006 |
38123760 |
COPRITASTIERA GRIGIO |
P.B.PANEL COVER GREY |
COBERTURA TECLADO GRIS |
|
38123761 |
COPRITASTIERA ROSSO |
P.B.PANEL COVER RED |
COBERTURA TECLADO ROUGE |
007 |
21300741 |
COPRIGRUPPO |
GROUP COVER |
CUBRE GRUPO |
008 |
32330957 |
MASCHERINA 2GR. |
TEMPLATE 2GR |
REJA 2GR. |
009 |
32330955 |
GRIGLIA POSAT.2GR. |
CUP-TRAY GRATE 2GR. |
PARRILLA POSA TAZAS 2GR |
010 |
38123751 |
BASAMENTO 2 GR |
BASE 2GR |
BASE 2GR |
01 |
42200122 |
TARGH.RANCILIO MM.115 |
RANCILIO PLATE MM115 |
TARJ. RANCILIO MM 115 |
012 |
36310010 |
PIEDINO |
FOOT |
PIED |
013 |
10781304 |
PIEDINO |
FOOT |
PIE |
014 |
10880313 |
PIASTRA SOST.CALDAIA 2GR |
PLATE 2GR. |
PLACA 2GR. |
015 |
32550814 |
SQUADR.SX |
SUPPORT SX |
ANGULAR SX |
016 |
32550758 |
SQUADRETTA X MASCHERINA |
SUPPORT FOR TMPLATE |
ANGULAR PARA REJA |
017 |
34030970 |
NTERR.BIP.LUM.VERDE |
GREEN SWITCH |
NTERRUPTOR VERDE |
018 |
32550756 |
SQUADRETTA DX |
SUPPORT DX |
ANGULAR DX |
019 |
10880311 |
TELAIO 2GR. |
CHASSIS 2GR |
CHASIS 2GR. |
020 |
32330951 |
FRONTALE POSTERIORE 2GR. |
FRONT PANEL 2GR |
FRONTAL 2GR. |
02 |
38123753 |
FIANCHETTO ROSSO DX |
SIDE PANEL RED DX |
LATERAL ROJO DX |
|
38123757 |
FIANCHETTO GRIGIO DX |
SIDE PANEL GREY DX |
LATERAL GRIS DX |
022 |
36220004 |
GUARN.FLANGIA |
FLANGE GASKET |
JUNTA BRIDA |
023 |
10111031 |
SCHEDA+TASTIERA CAFFE’ DE |
CARD+P.B.BOARD COFFEE DE |
CEDULA+TECLADO CAFE’ DE |
025 |
10111032 |
SCHEDA+TASTIERA CAFFE’ CD |
CARD+P.B.BOARD COFFEE CD |
CEDULA+TECLADO CAFE’ CD |
026 |
10111035 |
TASTO CAFFE’CON SPIA S |
COFFEE PUSH BUTTON+WARN.LIGHT S |
BOTON CAFE’ CON INDICATOR S |
Epoca
CARROZZERIA
BODY TAV.10310/04
CARROCIERIAE
1 |
25 |
26 |
23 |
||
mod. DE |
mod. CD |
|
5 |
22 |
|
|
|
24 |
|
6 |
|
21 |
8 |
|
|
7 |
9 |
7 |
|
|
|
20 |
10 |
15 |
14
16
19
18
11 |
17 |
|
13
12
Epoca
PARTI ELETTRICHE / ELETTRONICHE
ELECTRIC PARTS / ELECTRONIC TAV.10340/04
PARTES ELECTRICAS / ELETTRÓNICAS
Rif. |
CODICE |
DESCRIZIONE |
DESCRIPTION |
DESCRIPCION |
00 |
10700957 |
KIT TRASFORMATORI 230V DE/SDE |
KIT TRNSF.230V DE/SDE |
KIT TRANSF.230V DE/SDE |
002 |
34200260 |
CONTATTORE 230V 50/60HZ |
CONTACTOR 230V 50/60HZ |
CONTACTOR 230V 50/60HZ |
003 |
34300073 |
CAVO |
CABLE |
CABLE |
004 |
10700972 |
KIT SCHEDA DE 03 |
KIT BOARD DE 03 |
KIT CEDULA DE 03 |
006 |
34150024 |
MORSETTIERA 6 POL |
TERMINAL BOARD 6POL. |
BORNE 6POL. |
007 |
10110436 |
CABLAGGIO AT TELERUTT.POWER |
WIRING AT CONTR.SWITCH POWER |
CABLES AT TELERUPTOR POWER |
008 |
10110435 |
CABLAGGIO AT MORSETT.TELERUTT. |
WIRING CLAMP/CONTROL SWITCH AT |
CABLES BORNE/TELERUPTOR AT |
009 |
10110325 |
SCATOLA CABLATA 230V |
BOX WITH BOARD 230V |
CAJA CON CEDULA 230V |
010 |
10110409 |
CABLAGGIO AT SCATOLA EL. |
EL.BOX WIRING AT |
CABLES CAJA EL. AT |
01 |
10110402 |
CABLAGGIO VENT.1/2 GR. |
FLOWMETER WIRING 1/2GR. |
CABLES HELICE 1/2 GR. |
013 |
10110421 |
CABLAGGIO AT DE 2GR. |
WIRING AT DE 2GR |
CABLES AT DE 2GR |
014 |
10110405 |
CABLAGGIO TASTIERA 2GR |
P.B.PANEL WIRING 2GR |
CABLES TECLADO 2GR |
015 |
10110420 |
CABLAGGIO EV.GRUPPO/ACQUA |
WIRING GROUP/WATER EV. |
CABLES EV. GRUPO/AGUA |
016 |
10110404 |
CABLAGGIO TASTIERA 1GR |
P.B.PANEL WIRING 1GR |
CABLES TECLADO 1 GR |
Epoca
PARTI ELETTRICHE / ELETTRONICHE
ELECTRIC PARTS / ELECTRONIC TAV.10340/04
PARTES ELECTRICAS / ELETTRÓNICAS
2
7
9
1
3
4
10
6
8
13
11
11
15
16
14
Epoca
PARTI ELETTRICHE / ELETTRONICHE
ELECTRIC PARTS / ELECTRONIC TAV.10341/04
PARTES ELECTRICAS / ELETTRÓNICAS
Rif. |
CODICE |
DESCRIZIONE |
DESCRIPTION |
DESCRIPCION |
00 |
34200260 |
CONTATTORE 230V 50/60HZ |
CONTACTOR 230V 50/60HZ |
CONTACTOR 230V 50/60HZ |
002 |
10700957 |
KIT TRASFORMATORI 230V DE/SDE |
KIT TRNSF.230V DE/SDE |
KIT TRANSF.230V DE/SDE |
004 |
10700972 |
KIT SCHEDA DE 03 |
KIT BOARD DE 03 |
KIT CEDULA DE 03 |
005 |
34150024 |
MORSETTIERA 6 POL |
TERMINAL BOARD 6POL. |
BORNE 6POL. |
006 |
34300073 |
CAVO |
CABLE |
CABLE |
007 |
10110435 |
CABLAGGIO AT MORSETT.TELERUTT. |
WIRING CLAMP/CONTROL SWITCH AT |
CABLES BORNE/TELERUPTOR AT |
008 |
10110409 |
CABLAGGIO AT SCATOLA EL. |
EL.BOX WIRING AT |
CABLES CAJA EL. AT |
009 |
10110436 |
CABLAGGIO AT TELERUTT.POWER |
WIRING AT CONTR.SWITCH POWER |
CABLES AT TELERUPTOR POWER |
010 |
10110325 |
SCATOLA CABLATA 230V |
BOX WITH BOARD 230V |
CAJA CON CEDULA 230V |
012 |
10110421 |
CABLAGGIO AT DE 2GR. |
WIRING AT DE 2GR |
CABLES AT DE 2GR |
013 |
10110404 |
CABLAGGIO TASTIERA 1GR |
P.B.PANEL WIRING 1GR |
CABLES TECLADO 1 GR |
014 |
10110405 |
CABLAGGIO TASTIERA 2GR |
P.B.PANEL WIRING 2GR |
CABLES TECLADO 2GR |
