Quick Charge SCX User Manual

101712

O P E R A T I N G I N S T R U C T I O N S

Select-A-Charge Battery Chargers

models: SCP, SCPX, SCS, SCSX, SCX

For Industrial Use:

(Lithiu m ion appl icat ion s must be fact ory pr ogr am med)

Designed for gel, wet cell, AGM, and Lithium Ion batteries

Quick Charge Corp.
800 658-2841
e-mail [e-mail]

www.quickcharge.com

Made in the U.S.A

If your charger is programmed for
Lithium Ion batteries the display will
read “FC” Final Charge instead of 80%

To discontinue charging, switch the power off, and disconnect
battery.

EQUALIZATION:

When using multiple batteries in a series string, cells become
uneven during charge and discharge cycles. At least once a month
perform two charge cycles back to back, this will give a chance for
cells that are lagging behind to catch up, and is important to overall
battery performance. NOTE: This only needs to be done when
using F2, F3, F4, settings, and a gassing/absorption setting of d0
or d2.

SAFETY INFORMATION AC WIRING:
Before making AC connections, refer to the requirements on the
charger ID label. If your charger is not equipped with an AC plug,
for example, a 230 volt charger, have a qualified electrician install
one.

To reduce the risk of fire, use this charger only on branch circuits
that are protected by a circuit breaker or fuse, and that are adequate
to carry the power drawn by the charger. All wiring should be in
accordance with the National Electric Code, ANSI/NFPA 70, and
all local codes and ordinances.

This battery charger must be grounded to reduce the risk of electric
shock. 117 volt chargers are equipped with a grounding type plug,
230 volt chargers are shipped without a plug. Have a qualified
electrician install a properly grounded 3 wire plug.

DO NOT USE THIS CHARGER ON A TWO POLE
UNGROUNDED OUTLET OR ATTEMPT TO BREAK OFF
THE GROUND PRONG FOR USE ON A RECEPTACLE OR
EXTENSION CORD NOT HAVING A GROUND.

If an extension cord must be used, make sure it is in good
condition. Use a three conductor cord no smaller than the size
being used on the charger, and keep it as short as possible. The use
of an improper extension cord could result in a risk of a fire or
electric shock. Locate all cords so that they will not be stepped on,
tripped over, or otherwise subjected to damage or stress.
