Quectel Wireless Solutions 201408UG95 User Manual

UG95 Hardware Design

UMTS/HSPA Module Series

Rev. UG95_Hardware_Design_FCC

Date: 2014-09-02

www.quectel.com

UMTS/HSPA Module Series

UG95 Hardware Design

Our aim is to provide customers with timely and comprehensive service. For any assistance, please contact our company headquarters:

Quectel Wireless Solutions Co., Ltd.

Office 501, Building 13, No.99, Tianzhou Road, Shanghai, China, 200233

Tel: +86 21 5108 6236

Mail: info@quectel.com

Or our local office, for more information, please visit:

http://www.quectel.com/support/salesupport.aspx

For technical support, to report documentation errors, please visit:

http://www.quectel.com/support/techsupport.aspx

GENERAL NOTES

QUECTEL OFFERS THIS INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION

PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT

TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT

MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT

ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR

RELIANCE UPON THE INFORMATION. THE INFORMATION SUPPLIED HEREIN IS SUBJECT TO

CHANGE WITHOUT PRIOR NOTICE.

COPYRIGHT

THIS INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF

QUECTEL CO., LTD. TRANSMITTABLE, REPRODUCTION, DISSEMINATION AND EDITING OF THIS

DOCUMENT AS WELL AS UTILIZATION OF THIS CONTENTS ARE FORBIDDEN WITHOUT

PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF DAMAGES. ALL RIGHTS

ARE RESERVED IN THE EVENT OF A PATENT GRANT OR REGISTRATION OF A UTILITY MODEL

OR DESIGN.

UG95_Hardware_Design Confidential / Released 1 / 67

UMTS/HSPA Module Series

Revision

Date

Author

Description

1.0

2014-06-20

Yeoman CHEN

Initial

1.1

2014-08-21

Yeoman CHEN

1. Updated transmitting power information.

2. Added reference design for power supply in

Chapter 3.6.3.

3. Updated timing of turning on module in Figure 9.

4. Added definition for the backup capacitor value

in Chapter 3.9.

5. Added reference design of 5V level match circuit

in Figure 18.

6. Updated RS232 level match circuit in Figure 19.

7. Updated frequency range in Table 23.

8. Updated reference circuit of USB interface in

Figure 24.

9. Added diagram for USB upgrade test points.

10. Updated RF output power in Table 28.

11. Updated recommended footprint in Figure 36.

UG95 Hardware Design

About the Document

History

UG95_Hardware_Design Confidential / Released 2 / 67

UMTS/HSPA Module Series

UG95 Hardware Design

Contents

About the Document ................................................................................................................................... 2

Contents ....................................................................................................................................................... 3

Table Index ................................................................................................................................................... 5

Figure Index ................................................................................................................................................. 6

1 Introduction .......................................................................................................................................... 7

1.1. Safety Information...................................................................................................................... 8

2 Product Concept .................................................................................................................................. 9

2.1. General Description ................................................................................................................... 9

2.2. Directives and Standards ........................................................................................................... 9

2.2.1. FCC Statement ............................................................................................................... 10

2.2.2. FCC Radiation Exposure Statement .............................................................................. 10

2.3. Key Features ........................................................................................................................... 10

2.4. Functional Diagram ................................................................................................................. 12

2.5. Evaluation Board ..................................................................................................................... 13

3 Application Interface ......................................................................................................................... 14

3.1. General Description ................................................................................................................. 14

3.2. Pin Assignment ........................................................................................................................ 15

3.3. Pin Description ......................................................................................................................... 16

3.4. Operating Modes ..................................................................................................................... 21

3.5. Power Saving ........................................................................................................................... 21

3.5.1. Sleep Mode .................................................................................................................... 21

3.5.1.1. UART Application ................................................................................................. 21

3.5.1.2. USB Application with Suspend Function ............................................................. 22

3.5.1.3. USB Application without Suspend Function ........................................................ 22

3.5.2. Minimum Functionality Mode ......................................................................................... 23

3.6. Power Supply ........................................................................................................................... 24

3.6.1. Power Supply Pins ......................................................................................................... 24

3.6.2. Decrease Voltage Drop .................................................................................................. 24

3.6.3. Reference Design for Power Supply .............................................................................. 25

3.6.4. Monitor the Power Supply .............................................................................................. 26

3.7. Turn on and off Scenarios ....................................................................................................... 26

3.7.1. Turn on Module .............................................................................................................. 26

3.7.2. Turn off Module .............................................................................................................. 28

3.7.2.1. Turn off Module Using the PWRDWN_N Pin ...................................................... 28

3.7.2.2. Turn off Module Using AT Command ................................................................... 30

3.7.2.3. Automatic Shutdown ............................................................................................ 30

3.8. Reset the Module..................................................................................................................... 31

3.9. RTC Interface .......................................................................................................................... 33

3.10. UART Interface ........................................................................................................................ 34

3.11. USIM Card Interface ................................................................................................................ 37

UG95_Hardware_Design Confidential / Released 3 / 67

UMTS/HSPA Module Series

UG95 Hardware Design

3.11.1. USIM Card Application ................................................................................................... 37

3.11.2. Design Considerations for USIM Card Holder ............................................................... 39

3.12. USB Interface .......................................................................................................................... 41

3.13. PCM and I2C Interface ............................................................................................................ 43

3.14. Network Status Indication ........................................................................................................ 45

3.15. Operating Status Indication ..................................................................................................... 46

4 Antenna Interface ............................................................................................................................... 47

4.1. UMTS Antenna Interface ......................................................................................................... 47

4.1.1. Pin Definition .................................................................................................................. 47

4.1.2. Operating Frequency ..................................................................................................... 47

4.1.3. Reference Design .......................................................................................................... 47

4.2. Antenna Installation ................................................................................................................. 48

4.2.1. Antenna Requirement .................................................................................................... 48

4.2.2. Install the Antenna with RF Connector .......................................................................... 49

5 Electrical, Reliability and Radio Characteristics ............................................................................ 51

5.1. Absolute Maximum Ratings ..................................................................................................... 51

5.2. Power Supply Ratings ............................................................................................................. 51

5.3. Operating Temperature ............................................................................................................ 52

5.4. Current Consumption .............................................................................................................. 52

5.5. RF Output Power ..................................................................................................................... 53

5.6. RF Receiving Sensitivity .......................................................................................................... 53

5.7. Electrostatic Discharge ............................................................................................................ 54

6 Mechanical Dimensions .................................................................................................................... 55

6.1. Mechanical Dimensions of the Module.................................................................................... 55

6.2. Footprint of Recommendation ................................................................................................. 57

6.3. Top View of the Module ........................................................................................................... 58

6.4. Bottom View of the Module ...................................................................................................... 58

7 Storage and Manufacturing .............................................................................................................. 59

7.1. Storage..................................................................................................................................... 59

7.2. Manufacturing and Welding ..................................................................................................... 59

7.3. Packaging ................................................................................................................................ 60

8 Appendix A Reference ....................................................................................................................... 61

9 Appendix B GPRS Coding Scheme ................................................................................................. 65

10 Appendix C GPRS Multi-slot Class .................................................................................................. 66

11 Appendix D EDGE Modulation and Coding Scheme ................................................................... 67

UG95_Hardware_Design Confidential / Released 4 / 67

UMTS/HSPA Module Series

UG95 Hardware Design

Table Index

TABLE 1: UG95 SERIES FREQUENCY BANDS ................................................................................................ 9

TABLE 2: UG95 KEY FEATURES ..................................................................................................................... 10

TABLE 3: IO PARAMETERS DEFINITION ........................................................................................................ 16

TABLE 4: PIN DESCRIPTION ........................................................................................................................... 16

TABLE 5: OVERVIEW OF OPERATING MODES ............................................................................................. 21

TABLE 6: VBAT AND GND PINS ....................................................................................................................... 24

TABLE 7: PWRKEY PIN DESCRIPTION .......................................................................................................... 26

TABLE 8: PWRDWN_N PIN DESCRIPTION .................................................................................................... 29

TABLE 9: RESET_N PIN DESCRIPTION ......................................................................................................... 31

TABLE 10: PIN DEFINITION OF THE MAIN UART INTERFACE ..................................................................... 34

TABLE 11: LOGIC LEVELS OF DIGITAL I/O .................................................................................................... 35

TABLE 12: PIN DEFINITION OF THE USIM INTERFACE ............................................................................... 37

TABLE 13: PIN DESCRIPTION OF MOLEX USIM CARD HOLDER ................................................................ 40

TABLE 14: PIN DESCRIPTION OF AMPHENOL USIM CARD HOLDER ........................................................ 41

TABLE 15: USB PIN DESCRIPTION ................................................................................................................ 41

TABLE 16: PIN DEFINITION OF PCM AND I2C INTERFACE .......................................................................... 43

TABLE 17: PIN DEFINITION OF NETWORK INDICATOR ............................................................................... 45

TABLE 18: WORKING STATE OF THE NETWORK INDICATOR..................................................................... 45

TABLE 19: PIN DEFINITION OF STATUS ........................................................................................................ 46

TABLE 20: PIN DEFINITION OF THE RF ANTENNA ....................................................................................... 47

TABLE 21: THE MODULE OPERATING FREQUENCIES ................................................................................ 47

TABLE 22: ANTENNA CABLE REQUIREMENTS ............................................................................................. 48

TABLE 23: ANTENNA REQUIREMENTS .......................................................................................................... 48

TABLE 24: ABSOLUTE MAXIMUM RATINGS .................................................................................................. 51

TABLE 25: THE MODULE POWER SUPPLY RATINGS .................................................................................. 51

TABLE 26: OPERATING TEMPERATURE ........................................................................................................ 52

TABLE 27: THE MODULE CURRENT CONSUMPTION .................................................................................. 52

TABLE 28: CONDUCTED RF OUTPUT POWER ............................................................................................. 53

TABLE 29: CONDUCTED RF RECEIVING SENSITIVITY ................................................................................ 53

TABLE 30: RELATED DOCUMENTS ................................................................................................................ 61

TABLE 31: TERMS AND ABBREVIATIONS ...................................................................................................... 61

TABLE 32: DESCRIPTION OF DIFFERENT CODING SCHEMES .................................................................. 65

TABLE 33: GPRS MULTI-SLOT CLASSES ...................................................................................................... 66

TABLE 34: EDGE MODULATION AND CODING SCHEME ............................................................................. 67

UG95_Hardware_Design Confidential / Released 5 / 67

UMTS/HSPA Module Series

UG95 Hardware Design

Figure Index

FIGURE 1: FUNCTIONAL DIAGRAM ............................................................................................................... 13

FIGURE 2: PIN ASSIGNMENT (TOP VIEW) .................................................................................................... 15

FIGURE 3: UART SLEEP APPLICATION ......................................................................................................... 22

FIGURE 4: USB SLEEP APPLICATION WITHOUT SUSPEND FUNCTION .................................................... 23

FIGURE 5: STAR STRUCTURE OF THE POWER SUPPLY............................................................................ 25

FIGURE 6: REFERENCE CIRCUIT OF POWER SUPPLY .............................................................................. 26

FIGURE 7: TURN ON THE MODULE USING DRIVING CIRCUIT ................................................................... 27

FIGURE 8: TURN ON THE MODULE USING KEYSTROKE ........................................................................... 27

FIGURE 9: TIMING OF TURNING ON MODULE ............................................................................................. 28

FIGURE 10: TURN OFF THE MODULE USING DRIVING CIRCUIT ............................................................... 29

FIGURE 11: TURN OFF THE MODULE USING KEYSTROKE ........................................................................ 29

FIGURE 12: TIMING OF TURNING OFF MODULE ......................................................................................... 30

FIGURE 13: REFERENCE CIRCUIT OF RESET_N BY USING DRIVING CIRCUIT ...................................... 32

FIGURE 14: REFERENCE CIRCUIT OF RESET_N BY USING BUTTON ...................................................... 32

FIGURE 15: TIMING OF RESETTING MODULE ............................................................................................. 32

FIGURE 16: RTC SUPPLY FROM CAPACITOR .............................................................................................. 33

FIGURE 17: REFERENCE CIRCUIT OF LOGIC LEVEL TRANSLATOR ......................................................... 35

FIGURE 18: REFERENCE CIRCUIT WITH TRANSISTOR CIRCUIT .............................................................. 36

FIGURE 19: RS232 LEVEL MATCH CIRCUIT .................................................................................................. 36

FIGURE 20: REFERENCE CIRCUIT OF THE 8-PIN USIM CARD .................................................................. 38

FIGURE 21: REFERENCE CIRCUIT OF THE 6-PIN USIM CARD .................................................................. 38

FIGURE 22: MOLEX 91228 USIM CARD HOLDER ......................................................................................... 39

FIGURE 23: AMPHENOL C707 10M006 512 2 USIM CARD HOLDER ........................................................... 40

FIGURE 24: REFERENCE CIRCUIT OF USB APPLICATION ......................................................................... 42

FIGURE 25: TEST POINTS OF FIRMWARE UPGRADE ................................................................................. 42

FIGURE 26: PCM MASTER MODE TIMING ..................................................................................................... 44

FIGURE 27: REFERENCE CIRCUIT OF PCM APPLICATION WITH AUDIO CODEC .................................... 44

FIGURE 28: REFERENCE CIRCUIT OF THE NETLIGHT ............................................................................... 45

FIGURE 29: REFERENCE CIRCUIT OF THE STATUS ................................................................................... 46

FIGURE 30: REFERENCE CIRCUIT OF ANTENNA INTERFACE ................................................................... 48

FIGURE 31: DIMENSIONS OF THE UF.L-R-SMT CONNECTOR (UNIT: MM) ................................................ 49

FIGURE 32: MECHANICALS OF UF.L-LP CONNECTORS (UNIT: MM) .......................................................... 50

FIGURE 33: SPACE FACTOR OF MATED CONNECTOR (UNIT: MM) ........................................................... 50

FIGURE 34: UG95 TOP AND SIDE DIMENSIONS ........................................................................................... 55

FIGURE 35: UG95 BOTTOM DIMENSION (TOP VIEW) .................................................................................. 56

FIGURE 36: RECOMMENDED FOOTPRINT (TOP VIEW) .............................................................................. 57

FIGURE 37: TOP VIEW OF THE MODULE ...................................................................................................... 58

FIGURE 38: BOTTOM VIEW OF THE MODULE .............................................................................................. 58

FIGURE 39: REFLOW SOLDERING PROFILE ................................................................................................ 60

UG95_Hardware_Design Confidential / Released 6 / 67

UMTS/HSPA Module Series

UG95 Hardware Design

1 Introduction

This document defines the UG95 module and describes its hardware interface which are connected with

your application and the air interface.

This document can help you quickly understand module interface specifications, electrical and

mechanical details. Associated with application notes and user guide, you can use UG95 module to

design and set up mobile applications easily.

UG95_Hardware_Design Confidential / Released 7 / 67

UMTS/HSPA Module Series

Full attention must be given to driving at all times in order to reduce the risk of an

accident. Using a mobile while driving (even with a handsfree kit) cause distraction

and can lead to an accident. You must comply with laws and regulations restricting

the use of wireless devices while driving.

Switch off the cellular terminal or mobile before boarding an aircraft. Make sure it

switched off. The operation of wireless appliances in an aircraft is forbidden to

prevent interference with communication systems. Consult the airline staff about

the use of wireless devices on boarding the aircraft, if your device offers a Airplane

Mode which must be enabled prior to boarding an aircraft.

Switch off your wireless device when in hospitals or clinics or other health care facilities. These requests are desinged to prevent possible interference with sentitive medical equipment.

UMTS cellular terminals or mobiles operate over radio frequency signal and

cellular network and cannot be guaranteed to connect in all conditions, for example

no mobile fee or an invalid SIM card. While you are in this condition and need

emergent help, please remember using emergency call. In order to make or

receive call, the cellular terminal or mobile must be switched on and in a service

area with adequate cellular signal strength.

Your cellular terminal or mobile contains a transmitter and receiver. When it is ON ,

it receives and transmits radio frequency energy. RF interference can occur if it is

used close to TV set, radio, computer or other electric equipment.

In locations with potencially explosive atmospheres, obey all posted signs to turn

off wireless devices such as your phone or other cellular terminals. Areas with

potencially exposive atmospheres including fuelling areas, below decks on boats,

fuel or chemical transfer or storage facilities, areas where the air contains

chemicals or particles such as grain, dust or metal powders.

UG95 Hardware Design

1.1. Safety Information

The following safety precautions must be observed during all phases of the operation, such as usage,

service or repair of any cellular terminal or mobile incorporating UG95 module. Manufacturers of the cellular

terminal should send the following safety information to users and operating personnel and to incorporate

these guidelines into all manuals supplied with the product. If not so, Quectel does not take on any liability

for customer failure to comply with these precautions.

UG95_Hardware_Design Confidential / Released 8 / 67

UMTS/HSPA Module Series

Module

GSM

850

EGSM

900

DCS

1800

PCS

1900

UMTS

850

UMTS

900

UMTS

1900

UMTS

2100

UG95



1)

UG95 indicates Data-only and Telematics versions. Data-only version does not support voice function,

Telematics version supports it.

NOTE

UG95 Hardware Design

2 Product Concept

2.1. General Description

UG95 serials are embedded 3G wireless communication modules, support UTMS/HSDPA/HSUPA

networks. It can also provide voice functionality1) for your specific application. UG95 offers a maximum

data rate of 7.2Mbps on downlink and 5.76Mbps on uplink in HSPA mode.

Table 1: UG95 Series Frequency Bands

More details about GPRS/EDGE multi-slot configuration and coding schemes, please refer to Appendix

B, C and D.

With a tiny profile of 23.6mm × 19.9mm × 2.2mm, UG95 can meet almost all requirements for M2M

application such as automotive, metering, tracking system, security solutions, routers, wireless POS,

mobile computing devices, PDA phone and tablet PC, etc..

UG95 is an SMD type module, which can be embedded in application through its 102 LGA pads.

UG95 is integrated with internet service protocols like TCP/UDP and PPP. Extended AT commands have

been developed for you to use these internet service protocols easily.

2.2. Directives and Standards

The UG95 module is designed to comply with the FCC statements. FCC ID: XMR201408UG95

UG95_Hardware_Design Confidential / Released 9 / 67

UMTS/HSPA Module Series

Part

Number

Frequency Range (MHz)

Peak Gain

(XZ-V)

Average Gain

(XZ-V)

VSWR

Impedance

3R007

UMTS850: 824~894MHz

UMTS1900: 1850~1990MHz

1 dBi typ.

2 max

50Ω

Feature

Details

Power Supply

Supply voltage: 3.4V~4.3V.

Typical supply voltage: 3.8V.

Frequency Bands

UG95

UMTS Dual-band: 850/1900MHz.

Transmission Data

HSPA R6: Max 7.2Mbps (DL)/Max 5.76Mbps (UL).

UMTS R4: Max 384kbps (DL)/Max 384kbps (UL).

UG95 Hardware Design

The Host system using UG95 should have label “contains FCC ID: XMR201408UG95”.

2.2.1. FCC Statement

Changes or modifications not expressly approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

2.2.2. FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

This equipment should be installed and operated with minimum distance 20cm between the radiator and

your body as well as kept minimum 20cm from radio antenna depending on the Mobile status of this

module usage. This module should NOT be installed and operating simultaneously with other radio.

The manual of the host system, which uses UG95, must include RF exposure warning statement to

advice user should keep minimum 20cm from the radio antenna of UG95 module depending on the

Mobile status.

Note: If a portable device (such as PDA) uses UG95 module, the device needs to do permissive change

and SAR testing.

The following list indicates the performance of antenna gain in certificate testing.

2.3. Key Features

The following table describes the detailed features of UG95 module.

Table 2: UG95 Key Features

UG95_Hardware_Design Confidential / Released 10 / 67

UMTS/HSPA Module Series

Transmitting Power

Class 3 (22.25Bm+1/-1dB) for UMTS 850/1900.

HSPA/UMTS Features

HSPA data rate is corresponded with 3GPP release 6 7.2Mbps on

downlink and 5.76Mbps on uplink.

WCDMA data rate is corresponded with 3GPP R4. 384kbps on

downlink and 384kbps on uplink.

Support both QPSK and 16-QAM modulations.

Internet Protocol Features

Support TCP/UDP/PPP protocols.

Support the protocols PAP (Password Authentication Protocol) and

CHAP (Challenge Handshake Authentication Protocol) usually used

for PPP connections.

SMS

Text and PDU mode.

Point to point MO and MT.

SMS cell broadcast.

SMS storage: SM by default.

USIM Interface

Support USIM card: 1.8V, 3.0V.

Support USIM and SIM.

PCM Interface

Used for audio function with external codec.

Supports 8, 16, 32 bit mode with short frame synchronization.

Support master mode.

UART Interface

Support one UART interface.

 7-wire on UART interface, without DSR.  Support RTS and CTS hardware flow control.  Baud rate can reach up to 921600bps, auto baud rate by default.  Used for AT command, data transmission or firmware upgrade.  Multiplexing function.

USB Interface

Compliant with USB 2.0 specification (slave only), the data transfer

rate can reach up to 480Mbps.

Used for AT command communication, data transmission, software

debug and firmware upgrade.

USB Driver: Support Windows XP, Windows Vista, Windows 7,

Windows 8, Windows CE5.0/6.0*, Linux 2.6/3.0, Android 2.3/4.0/4.2.

AT Commands

Compliant with 3GPP TS 27.007, 27.005 and Quectel enhanced AT

commands.

Real Time Clock

Implemented.

Network Indication

One pin NETLIGHT to indicate network connectivity status.

Antenna Interface

UMTS antenna, 50Ω.

Physical Characteristics

Size: 19.9±0.15 × 23.6±0.15 × 2.2±0.2mm.

Interface: LGA.

Weight: 2.5g.

Temperature Range

Normal operation: -35°C ~ +70°C.

UG95 Hardware Design

UG95_Hardware_Design Confidential / Released 11 / 67

UMTS/HSPA Module Series

Restricted operation: -40°C ~ -35°C and +70°C ~ +85°C 1).

Storage temperature: -45°C ~ +90°C.

Firmware Upgrade

USB interface or UART interface.

RoHS

All hardware components are fully compliant with EU RoHS directive.

1.

1)

means when the module works within this temperature range, RF performance might degrade. For

example, the frequency error or the phase error would increase.

2. * means this feature is under development.

NOTES

UG95 Hardware Design

2.4. Functional Diagram

The following figure shows a block diagram of UG95 and illustrates the major functional parts.

 RF transceiver  Baseband  DDR+NAND flash  Radio frequency  Peripheral interface

--UART interface

--USIM card interface

--USB interface

--PCM interface

--I2C interface

--Status indication

--Control interface

UG95_Hardware_Design Confidential / Released 12 / 67

UMTS/HSPA Module Series

UG95 Hardware Design

Figure 1: Functional Diagram

2.5. Evaluation Board

In order to help you to develop applications with UG95, Quectel supplies an evaluation board

(UC20-EVB), RS-232 to USB cable, USB data cable, power adapter, earphone, antenna and other

peripherals to control or test the module. For details, please refer to document [2].

UG95_Hardware_Design Confidential / Released 13 / 67

UMTS/HSPA Module Series

UG95 Hardware Design

3 Application Interface

3.1. General Description

UG95 is equipped with a 62-pin 1.1mm pitch SMT pads plus 40-pin ground pads and reserved pads that

connect to customer’s cellular application platform. Sub-interfaces included in these pads are described in

detail in the following chapters:

 Power supply  RTC interface  UART interface  USIM interface  USB interface  PCM interface  Status indication

UG95_Hardware_Design Confidential / Released 14 / 67

UMTS/HSPA Module Series

RESERVED

PCM_SYNC

PCM_CLK

PCM_DIN

PCM_DOUT

RESERVED

PWRKEY

PWRDWN_N

RESET_N

RESERVED

1

2

3

4

5

6

7

11

12

13

14

15

16

17

18

50

51

52

53

54

55

58

59

60

61

62

USB_DM

AP_READY

STATUS

NETLIGHT

RESERVED

VDD_EXT

DTR

GND

USIM_CLK

USIM_DATA

USIM_RST

USIM_VDD

RI

DCD

CTS

TXD

RXD

VBAT_BB

USIM_GND

GND

RESERVED

31

30

29

28

27

26

23

22

21

20

19

10

9

USB_DP

USB_VBUS

RESERVED

GND

RESERVED

RTS

I2C_SCL

I2C_SDA

8

49

48

47

46

45

44

43

40

41

42

39

38

37

36

35

34

33

32

24

25

57

56

GND

RF_ANT

GND

RESERVED

VBAT_RF

GND

RESERVED

VRTC

GND

USIM_PRESENCE

63

64

65

66

67

68

83

84

85

86

87

88

98

97

96

95

94

93

78

77

76

75

74

73

91 92

89 90

71

72

69 70

80 79

82 81

100

99

102 101

POWER USB UART

USIM

OTHERSGND

RESERVED

PCM ANT

1. Keep all RESERVED pins and unused pins unconnected.

2. GND pads should be connected to ground in the design.

NOTES

UG95 Hardware Design

3.2. Pin Assignment

The following figure shows the pin assignment of the UG95 module.

Figure 2: Pin Assignment (Top View)

UG95_Hardware_Design Confidential / Released 15 / 67

UMTS/HSPA Module Series

Type

Description

IO

Bidirectional input/output

DI

Digital input

DO

Digital output

PI

Power input

PO

Power output

AI

Analog input

AO

Analog output

OD

Open drain

Power Supply

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

VBAT_BB

32,33

PI

Power supply for

module baseband

part.

Vmax = 4.3V

Vmin = 3.4V

Vnorm = 3.8V

It must be able to

provide sufficient

current up to 0.8A.

VBAT_RF

52,53

PI

Power supply for

module RF part.

Vmax = 4.3V

Vmin = 3.4V

Vnorm = 3.8V

It must be able to

provide sufficient

current in a transmitting

burst which typically

rises to 2.0A.

VRTC

51

PI/

PO

Power supply for

internal RTC circuit.

VOmax = 1.9V

when VBAT ≥ 3.4V.

VI = 1V~1.9V at

IIN max = 2uA when

VBAT is not applied.

Keep this pin

unconnected if unused.

UG95 Hardware Design

3.3. Pin Description

The following tables show the UG95’s pin definition.

Table 3: IO Parameters Definition

Table 4: Pin Description

UG95_Hardware_Design Confidential / Released 16 / 67

UMTS/HSPA Module Series

VDD_EXT

29

PO

Provide 1.8V for

external circuit.

Vnorm = 1.8V

IOmax = 20mA

Power supply for

external GPIO’s pull up

circuits.

GND

3,31,48,

50,54,55,

58,59,61,

62,67~74,

79~82,

89~91,

100~102

Ground.

Turn On/Off

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

PWRKEY

15

DI

Turn on the module.

RPU ≈ 200kΩ

VIHmax = 2.1V

VIHmin = 1.3V

VILmax= 0.5V

Pull-up to 1.8V

internally.

Active low.

PWRDWN_N

16

DI

Turn off the module.

RPU ≈ 4.7kΩ

VIHmax = 2.1V

VIHmin = 1.3V

VILmax = 0.5V

Pull-up to 1.8V

internally.

Active low.

RESET_N

17

DI

Reset the module.

RPU ≈ 200kΩ

VIHmax = 2.1V

VIHmin = 1.3V

VILmax = 0.5V

Pull-up to 1.8V

internally.

Active low.

Status Indication

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

STATUS

20

DO

Indicate the module

operating status.

VOHmin =1.3V

VOLmax = 0.5V

1.8V power domain.

NETLIGHT

21

DO

Indicate the module

network status.

VOHmin = 1.3V

VOLmax = 0.5V

1.8V power domain.

USB Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

USB_VBUS

8

PI

USB insert

detection.

Vmax = 5.25V

Vmin = 2.5V

Vnorm = 5.0V

USB insert detection.

USB_DP

9

IO

USB differential data

bus.

Compliant with USB

2.0 standard

specification.

Require differential

impedance of 90Ω.

UG95 Hardware Design

UG95_Hardware_Design Confidential / Released 17 / 67

UMTS/HSPA Module Series

USB_DM

10

IO

USB differential data

bus.

Compliant with USB

2.0 standard

specification.

Require differential

impedance of 90Ω.

USIM Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

USIM_GND

47

Specified ground for

USIM card.

USIM_VDD

43

PO

Power supply for

USIM card.

For 1.8V USIM:

Vmax = 1.85V

Vmin = 1.75V

For 3.0V USIM:

Vmax = 2.9V

Vmin = 2.8V

Either 1.8V or 3.0V is

supported by the

module automatically.

USIM_DATA

45

IO

Data signal of USIM

card.

For 1.8V USIM:

VILmax = 0.35V

VIHmin = 1.25V

VOLmax = 0.25V

VOHmin = 1.25V

For 3.0V USIM:

VILmax = 0.5V

VIHmin = 2.05V

VOLmax = 0.25V

VOHmin = 2.05V

Pull-up to USIM_VDD

with 4.7k resistor

internally.

USIM_CLK

46

DO

Clock signal of USIM

card.

For 1.8V USIM:

VOLmax = 0.25V

VOHmin = 1.25V

For 3.0V USIM:

VOLmax = 0.25V

VOHmin = 2.05V

USIM_RST

44

DO

Reset signal of

USIM card.

For 1.8V USIM:

VOLmax = 0.25V

VOHmin = 1.25V

For 3.0V USIM:

VOLmax = 0.3V

VOHmin = 2.05V

USIM_PRES

ENCE

42

DI

USIM card input

detection.

VILmax = 0.35V

VIHmin = 1.3V

VIHmax = 1.85V

1.8V power domain.

External pull-up

resistor is required.

UG95 Hardware Design

UG95_Hardware_Design Confidential / Released 18 / 67

UMTS/HSPA Module Series

Main UART Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

RI

39

DO

Ring indicator.

VOLmax = 0.25V

VOHmin = 1.55V

1.8V power domain.

DCD

38

DO

Data carrier

detection.

VOLmax = 0.25V

VOHmin = 1.55V

1.8V power domain.

CTS

36

DO

Clear to send.

VOLmax = 0.25V

VOHmin = 1.55V

1.8V power domain.

RTS

37

DI

Request to send.

VILmax = 0.35V

VIHmin = 1.3V

VIHmax = 1.85V

1.8V power domain.

DTR

30

DI

Data terminal ready.

VILmax = 0.35V

VIHmin = 1.3V

VIHmax = 1.85V

1.8V power domain. TXD

35

DO

Transmit data.

VOLmax = 0.25V

VOHmin = 1.55V

1.8V power domain.

RXD

34

DI

Receive data.

VILmax = 0.35V

VIHmin = 1.3V

VIHmax = 1.85V

1.8V power domain.

RF Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

RF_ANT

60

IO

RF antenna.

50Ω impedance

PCM Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

PCM_IN

6

DI

PCM data input.

VILmin = -0.3V

VILmax = 0.35V

VIHmin = 1.3V

VIHmax = 1.85V

1.8V power domain.

PCM_OUT

7

DO

PCM data output.

VOLmax = 0.25V

VOHmin = 1.55V

1.8V power domain.

PCM_SYNC

5

IO

PCM data frame

sync signal.

VOLmax = 0.25V

VOHmin = 1.55V

VILmin = -0.3V

VILmax = 0.35V

VIHmin = 1.3V

VIHmax = 1.85V

1.8V power domain.

In master mode, it is

an output signal.

UG95 Hardware Design

UG95_Hardware_Design Confidential / Released 19 / 67

UMTS/HSPA Module Series

PCM_CLK

4

IO

PCM data bit clock.

VOLmax = 0.25V

VOHmin = 1.55V

VILmin = -0.3V

VILmax = 0.35V

VIHmin = 1.3V

VIHmax = 1.85V

1.8V power domain.

In master mode, it’s

an output signal.

I2C Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

I2C_SCL

40

DO

I2C serial clock.

VOLmax = 0.25V

VOHmin = 1.55V

1.8V power domain.

External pull-up

resistor is required.

I2C_SDA

41

IO

I2C serial data.

VOLmax = 0.25V

VOHmin = 1.55V

VILmin = -0.3V

VILmax = 0.35V

VIHmin = 1.3V

VIHmax = 1.85V

1.8V power domain.

External pull-up

resistor is required.

Other Pins

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

AP_READY

19

DI

Application

processor sleep

state detection.

VILmin = -0.3V

VILmax = 0.35V

VIHmin = 1.3V

VIHmax = 1.85V

1.8V power domain.

RESERVED Pins

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

RESERV

ED

1,2,

11~14,18

22~28,

49,56,57,

63~66,

75~78,

83~88,

92~99.

Reserved

Keep these pins

unconnected.

AP_READY is under development.

NOTE

UG95 Hardware Design

UG95_Hardware_Design Confidential / Released 20 / 67

UMTS/HSPA Module Series

Mode

Details

Normal Operation

UMTS Idle

Software is active. The module has registered to the UMTS

network and the module is ready to send and receive data.

UMTS

Talk/Data

UMTS connection is ongoing. In this mode, the power

consumption is decided by network setting (e.g. TPC pattern) and

data transfer rate.

HSPA Idle

Software is active. The module has registered to the HSPA

network and the module is ready to send and receive data.

HSPA Data

HSPA data transfer is ongoing. In this mode, the power

consumption is decided by network setting (e.g. TPC pattern) and

data transfer rate.

Minimum

Functionality

Mode

AT+CFUN command can set the module entering into a minimum functionality mode

without removing the power supply. In this case, both RF function and USIM card will

be invalid.

Sleep Mode

In this mode, the current consumption of the module will be reduced to the minimal

level. During this mode, the module can still receive paging message, SMS and voice

call from the network normally.

Power Down

Mode

In this mode, the power management unit shuts down the power supply for the

baseband part and RF part. Only the power supply for RTC remains. Software is not

active. The serial interface is not accessible. Operating voltage (connected to

VBAT_RF and VBAT_BB) remains applied.

UG95 Hardware Design

3.4. Operating Modes

The table below briefly summarizes the various operating modes referred in the following chapters.

Table 5: Overview of Operating Modes

3.5. Power Saving

3.5.1. Sleep Mode

UG95 is able to reduce its current consumption to a minimum value during the sleep mode. The following

section describes power saving procedure of UG95.

3.5.1.1. UART Application

If application processor communicates with module via UART interface, the following preconditions can

UG95_Hardware_Design Confidential / Released 21 / 67

UMTS/HSPA Module Series

RXD

TXD

RI

DTR

AP_READY

TXD

RXD

EINT

GPIO

Module

Processor

GND

UG95 Hardware Design

let the module enter into the sleep mode.

 Execute AT command AT+QSCLK=1 to enable the sleep mode.  Drive DTR to high level.

The following figure shows the connection between the module and application processor.

Figure 3: UART Sleep Application

The RI of module is used to wake up the processor, and AP_READY will detect the sleep state of

processor (can be configured to high level or low level detection). You should pay attention to the level

match shown in dotted line between module and processor. Drive DTR to low level will wake up the

module.

In sleep mode, the module can still receive paging message, SMS, voice call and TCP/UDP data from the

network normally, but the UART port is not accessible

3.5.1.2. USB Application with Suspend Function

TBD

3.5.1.3. USB Application without Suspend Function

If application processor communicates with module via USB interface, and processor does not support

USB suspend function, you should disconnect USB_VBUS with additional control circuit to let the module

enter into sleep mode.

 Execute AT command AT+QSCLK=1 to enable the sleep mode.  Disconnect USB_VBUS.

UG95_Hardware_Design Confidential / Released 22 / 67

UMTS/HSPA Module Series

USB_VBUS

USB_DP

USB_DM

AP_READY

VDD

USB_DP

USB_DM

GPIO

Module Processor

RI

EINT

Power Switch

GPIO

GND

AP_READY is under development.

NOTE

UG95 Hardware Design

Supply power to USB_VBUS will wake up the module.

The following figure shows the connection between the module and application processor.

Figure 4: USB Sleep Application without Suspend Function

In sleep mode, the module can still receive paging message, SMS, voice call and TCP/UDP data from the

network normally.

3.5.2. Minimum Functionality Mode

Minimum functionality mode reduces the functionality of the module to minimum level, thus minimizes the

current consumption at the same time. This mode can be set as below:

Command AT+CFUN provides the choice of the functionality levels: <fun>=0, 1, 4.

 AT+CFUN=0: Minimum functionality, RF part and USIM card will be closed.  AT+CFUN=1: Full functionality (by default).  AT+CFUN=4: Disable RF function (airplane mode). All AT commands related to RF function are not

accessible.

For detailed information about command AT+CFUN, please refer to document [1].

UG95_Hardware_Design Confidential / Released 23 / 67

UMTS/HSPA Module Series

Pin Name

Pin No.

Description

Min.

Typ.

Max.

Unit

VBAT_RF

52,53

Power supply for module RF

part.

3.4

3.8

4.3 V VBAT_BB

32,33

Power supply for module

baseband part.

3.4

3.8

4.3

V

GND

3,31,48,50

54,55,58,

59,61,62,

67~74,

79~82,

89~91,

100~102

Ground

- - -

-

UG95 Hardware Design

3.6. Power Supply

3.6.1. Power Supply Pins

UG95 provides four VBAT pins dedicated to connect with the external power supply. There are two

separate voltage domains for VBAT.

 VBAT_RF with two pads for module RF.  VBAT_BB with two pads for module baseband.

The following table shows the VBAT pins and ground pins.

Table 6: VBAT and GND Pins

3.6.2. Decrease Voltage Drop

The power supply range of the module is 3.4V~ 4.3V. Because of the voltage drop during the transmitting

time, a bypass capacitor of about 100µF with low ESR should be used. Multi-layer ceramic chip (MLCC)

capacitor can provide the best combination of low ESR. Three ceramic capacitors (100nF, 33pF, 10pF)

are recommended to be applied to the VBAT pins. The capacitors should be placed close to the UG95’s

VBAT pins. The following figure shows star structure of the power supply.

The main power supply from an external application has to be a single voltage source and has to be

expanded to two sub paths with star structure. In addition, in order to get a stable power source, it is

suggested to use a zener diode of whose reverse zener voltage is 5.1V and dissipation power is more

than 0.5W.

UG95_Hardware_Design Confidential / Released 24 / 67

UMTS/HSPA Module Series

Module

VBAT_RF

VBAT_BB

VBAT

C1

100uF

C6

100nFC733pFC810pF

+

C2

100nF

C5

100uF

C3

33pF

C4

10pF

D1

5.1V

UG95 Hardware Design

Figure 5: Star Structure of the Power Supply

Please pay special attention to the power supply design for applications. Make sure the input voltage will

never drop below 3.4V. If the voltage drops below 3.4V, the module will turn off automatically. The PCB

traces from the VBAT pins to the power source must be wide enough to ensure that there isn’t too much

voltage drop occurs in the transmitting procedure. The width of VBAT_BB trace should be no less than

1mm, and the width of VBAT_RF trace should be no less than 2mm, and the principle of the VBAT trace is

the longer, the wider.

3.6.3. Reference Design for Power Supply

The power design for the module is very important, since the performance of power supply for the module

largely depends on the power source. The power supply is capable of providing the sufficient current up to

2A at least. If the voltage drop between the input and output is not too high, it is suggested to use a LDO

to supply power for module. If there is a big voltage difference between the input source and the desired

output (VBAT), a buck converter is preferred to be used as a power supply.

The following figure shows a reference design for +5V input power source. The designed output for the

power supply is 3.88V and the maximum load current is 3A.

UG95_Hardware_Design Confidential / Released 25 / 67

UMTS/HSPA Module Series

DC_IN

C1

C2

MIC29302WU U1

IN

OUT

EN

GND

ADJ

2 4

1

3

5

VBAT

100nF

C3

470uF

C4

100nF

R2

100K

47K

R3

470uF

470R

51K

R4

R1

1%

MCU_POWER

_ON/OFF

47K

4.7K

R5

R6

It is suggested to disconnect power supply to turn off the module when the module is in abnormal state.

Pin Name

Pin No.

Description

DC Characteristics

Comment

PWRKEY

15

Turn on the module.

VIHmax = 2.1V

VIHmin = 1.3V

VILmax = 0.5V

Pull-up to 1.8V internally

with 200kΩ resistor.

NOTE

UG95 Hardware Design

Figure 6: Reference Circuit of Power Supply

3.6.4. Monitor the Power Supply

You can use the AT+CBC command to monitor the VBAT_BB voltage value. For more details, please

refer to document [1].

3.7. Turn on and off Scenarios

3.7.1. Turn on Module

Turn on the module using the PWRKEY. The following table shows the pin definition of PWRKEY.

Table 7: PWRKEY Pin Description

UG95_Hardware_Design Confidential / Released 26 / 67

UMTS/HSPA Module Series

Turn on pulse

PWRKEY

4.7K

47K

≥ 100ms

PWRKEY

S1

Close to S1

TVS

UG95 Hardware Design

When UG95 is in power down mode, it can be turned on to normal mode by driving the PWRKEY pin to a

low level at least 100ms. It is recommended to use an open drain/collector driver to control the PWRKEY.

You can monitor the level of the STATUS pin to judge whether the module is turned on or not. The

STATUS pin output a high level, after UG95 is turned on. A simple reference circuit is illustrated in the

following figure.

Figure 7: Turn on the Module Using Driving Circuit

The other way to control the PWRKEY is using a button directly. A TVS component is indispensable to be

placed nearby the button for ESD protection. When pressing the key, electrostatic strike may generate

from finger. A reference circuit is showed in the following figure.

The turn on scenarios is illustrated as the following figure.

UG95_Hardware_Design Confidential / Released 27 / 67

Figure 8: Turn on the Module Using Keystroke

UMTS/HSPA Module Series

V

IL

≤ 0.5V

V

IH

≥ 1.3V

VBAT

PWRKEY (Input)

≥ 100ms

OFF

BOOTING

Module Status

RUNNING

1

≥ 3.5s

RESET_N

STATUS

>2.3s

① Make sure that VBAT is stable before pulling down PWRKEY pin. It is suggested to pull down

PWRKEY pin after VBAT is stable 30ms at a voltage of 3.8V. It is not suggested to pull down

PWRKEY pin always.

NOTE

UG95 Hardware Design

Figure 9: Timing of Turning on Module

3.7.2. Turn off Module

The following procedures can be used to turn off the module:

 Normal power down procedure: Turn off the module using the PWRDWN_N pin.  Normal power down procedure: Turn off the module using command AT+QPOWD.  Automatic shutdown: Turn off the module automatically if under-voltage or over-voltage is detected.

3.7.2.1. Turn off Module Using the PWRDWN_N Pin

The following table shows the pin definition of PWRDWN_N.

UG95_Hardware_Design Confidential / Released 28 / 67

UMTS/HSPA Module Series

Pin Name

Pin No.

Description

DC Characteristics

Comment

PWRDWN_N

16

Turn off the module.

VIHmax = 2.1V

VIHmin = 1.3V

VILmax = 0.5V

Pull-up to 1.8V internally

with 4.7kΩ resistor.

Turn off pulse

PWRDWN_N

4.7K

47K

≥ 100ms

PWRDWN_N

S2

Close to S2

TVS

UG95 Hardware Design

Table 8: PWRDWN_N Pin Description

Driving the PWRDWN_N to a low level voltage at least 100ms, the module will execute power-down

procedure after PWRDWN_N is released. It is recommended to use an open drain/collector driver to

control the PWRDWN_N. You can monitor the level of the STATUS pin to judge whether the module is

turned off or not. The level of STATUS pin is low, after UG95 is turned off. A simple reference circuit is

illustrated in the following figure.

Figure 10: Turn off the Module Using Driving Circuit

The other way to control the PWRDWN_N is using a button directly. A TVS component is indispensable to

be placed nearby the button for ESD protection. When pressing the key, electrostatic strike may generate

from finger. A reference circuit is showed in the following figure.

UG95_Hardware_Design Confidential / Released 29 / 67

Figure 11: Turn off the Module Using Keystroke

UMTS/HSPA Module Series

VBAT

PWRDWN_N (Input)

Log off network about 1s to 60s

≥ 100ms

RUNNING

Power-down procedure

OFF

Module Status

STATUS

UG95 Hardware Design

The power-down scenario is illustrated as the following figure.

Figure 12: Timing of Turning off Module

During power-down procedure, module will log off network and save important data. After logging off,

module sends out “OK”, and then sends out “POWERED DOWN” and shut down the internal power

supply. The power on VBAT pins is not allowed to turn off before the URC “POWERED DOWN” is output

to avoid data loss. If logging off is not done within 60s, module will shut down internal power supply

forcibly.

After that moment, the module enters the power down mode, no other AT commands can be executed

and only the RTC is still active. The power down mode can also be indicated by the STATUS pin.

3.7.2.2. Turn off Module Using AT Command

It is also a safe way to use AT command AT+QPOWD to turn off the module, which is similar to turning off

the module via PWRDWN_N Pin.

Please refer to document [1] for details about the AT command of AT+QPOWD.

3.7.2.3. Automatic Shutdown

The module will constantly monitor the voltage applied on the VBAT, if the voltage ≤ 3.5V, the following

URC will be presented:

+QIND: “vbatt”,-1

UG95_Hardware_Design Confidential / Released 30 / 67

UMTS/HSPA Module Series

1. The value of voltage threshold can be revised by AT command, refer to document [1] for details.

2. Automatic shutdown is under development.

Pin Name

Pin No.

Description

DC Characteristics

Comment

RESET_N

17

Reset the module.

VIHmax = 2.1V

VIHmin = 1.3V

VILmax = 0.5V

Pull-up to 1.8V internally

with 200kΩ resistor.

Active low.

NOTES

UG95 Hardware Design

If the voltage ≥ 4.21V, the following URC will be presented:

+QIND: “vbatt”,1

The uncritical voltage is 3.4V to 4.3V, If the voltage > 4.3V or < 3.4V the module would automatically shut

down itself.

If the voltage < 3.4V, the following URC will be presented:

+QIND: “vbatt”,-2

If the voltage > 4.3V, the following URC will be presented:

+QIND: “vbatt”,2

3.8. Reset the Module

The RESET_N can be used to reset the module.

Table 9: RESET_N Pin Description

You can reset the module by driving the RESET_N to a low level voltage for more than 100ms and then

releasing.

The recommended circuit is similar to the PWRKEY control circuit. You can use open drain/collector

driver or button to control the RESET_N.

UG95_Hardware_Design Confidential / Released 31 / 67

UMTS/HSPA Module Series

Reset pulse

RESET_N

4.7K

47K

≥ 100ms

RESET_N

S3

Close to S3

TVS

VIL ≤ 0.5V

VIH ≥ 1.3V

VBAT

≥ 100ms

RESTARTING

Module Status

RESET_N

RUNNING

> 5s

STATUS

> 3s

RUNNING

OFF

UG95 Hardware Design

Figure 13: Reference Circuit of RESET_N by Using Driving Circuit

Figure 14: Reference Circuit of RESET_N by Using Button

The reset scenario is illustrated as the following figure.

Figure 15: Timing of Resetting Module

UG95_Hardware_Design Confidential / Released 32 / 67

UMTS/HSPA Module Series

Use the RESET_N only when turning off the module by the command AT+QPOWD and the PWRDWN_N

pin failed.

Large Capacitance Capacitor

Module

RTC

Core

1K

VRTC

C

NOTE

UG95 Hardware Design

3.9. RTC Interface

The RTC (Real Time Clock) can be powered by an external capacitor through the pin VRTC when the

module is powered down and there is no power supply for the VBAT. If the voltage supply at VBAT is

disconnected, the RTC can be powered by the capacitor. The capacitance determines the duration of

buffering when no voltage is applied to UG95.

The capacitor is charged from the internal LDO of UG95 when there is power supply for the VBAT. A

serial 1KΩ resistor had been placed on the application inside the module. It limits the input current of the

capacitor.

The following figure shows the reference circuit for VRTC backup.

Figure 16: RTC Supply from Capacitor

In order to evaluate the capacitance of capacitor according to the backup time, we have to consider the

following parameters:

 VRTC - The starting voltage of the capacitor. ( Volt)  VRTC  I - The current consumption of the RTC circuitry when VBAT = 0.(Ampere)  B  C - The backup capacitance. (Farad)

UG95_Hardware_Design Confidential / Released 33 / 67

Time

- The minimum voltage acceptable for the RTC circuit.( Volt)

MIN

- Backup Time.(Second)

UMTS/HSPA Module Series

Pin Name

Pin No. I/O

Description

Comment

DTR

30

DI

Data terminal ready.

1.8V power domain.

RXD

34

DI

Receive data.

1.8V power domain.

TXD

35

DO

Transmit data.

1.8V power domain.

CTS

36

DO

Clear to send.

1.8V power domain.

RTS

37

DI

Request to send.

1.8V power domain.

DCD

38

DO

Data carrier detection.

1.8V power domain.

RI

39

DO

Ring indicator.

1.8V power domain.

UG95 Hardware Design

When the power is off and only VRTC is running, the way of calculating the backup capacitor as follows:

C= B

*I/( VRTC-VRTC

Time

MIN

)

For example, when the capacitor is 1000uF:

 VRTC = 1.8V  VRTC

= 1.0V

MIN

 I = 2uA  C = 1000uF

The backup time is about 400s.

3.10. UART Interface

The module provides 7 lines UART interface.

UART interface supports 4800, 9600, 19200, 38400, 57600, 115200, 230400, 460800 and 921600bps

baud rate, and the default is auto-baud rate. This interface can be used for data transmission, AT

communication or firmware upgrade.

The module is designed as the DCE (Data Communication Equipment), following the traditional

DCE-DTE (Data Terminal Equipment) connection. The following tables show the pin definition of UART

interface.

Table 10: Pin Definition of the Main UART Interface

UG95_Hardware_Design Confidential / Released 34 / 67

UMTS/HSPA Module Series

Parameter

Min.

Max.

Unit

VIL

-0.3

0.35

V

VIH

1.3

1.85

V

VOL 0 0.25

V

VOH

1.55

1.8

V

VCCA VCCB

OE

A1

A2

A3

A4

A5

A6

A7

A8

GND

B1

B2

B3

B4

B5

B6

B7

B8

VDD_EXT

RI

DCD

RTS

RXD

DTR

CTS

TXD

51K

0.1uF

RI_3.3V

DCD_3.3V

RTS_3.3V

RXD_3.3V

DTR_3.3V

CTS_3.3V

TXD_3.3V

VDD_3.3V

TXS0108EPWR

UG95 Hardware Design

The logic levels are described in the following table.

Table 11: Logic Levels of Digital I/O

UG95 provides one 1.8V UART interface. A level shifter should be used if your application is equipped

with a 3.3V UART interface. A level shifter TXS0108EPWR provided by Texas Instruments is

recommended. The following figure shows the reference design of the TXS0108EPWR.

Figure 17: Reference Circuit of Logic Level Translator

The reference design of 5V level match is shown as below. The construction of dotted line can refer to the

construction of solid line. Please pay attention to direction of connection. Input dotted line of module

should refer to input solid line of the module. Output dotted line of module should refer to output solid line

of the module.

UG95_Hardware_Design Confidential / Released 35 / 67

UMTS/HSPA Module Series

MCU/ARM

/TXD

/RXD

VDD_EXT

4.7K

VCC_MCU

4.7K

VDD_EXT

TXD

RXD

RTS CTS DTR

RI

/RTS /CTS

GND

GPIO DCD

Module

GPIO

EINT

VDD_EXT

Voltage level: 5V

4.7K

GND

1nF

TXS0108EPWR

DCD_3.3V

RTS_3.3V

DTR_3.3V

RXD_3.3V

RI_3.3V

CTS_3.3V

TXD_3.3V

DCD

RTS

DTR

RXD

RI

CTS

TXD

DCD_1.8V

RTS_1.8V

DTR_1.8V

RXD_1.8V

RI_1.8V

CTS_1.8V

TXD_1.8V

VCCA

Module

GND GND

VDD_EXT VCCB

3.3V

DIN1

ROUT3

ROUT2

ROUT1

DIN4

DIN3

DIN2

DIN5 R1OUTB

FORCEON

/FORCEOFF

/INVALID

3.3V

DOUT1 DOUT2

DOUT3 DOUT4 DOUT5

RIN3

RIN2

RIN1

VCC GND

OE

SN65C3238

DB9M

PC side

DCD

RTS

DTR

TXD

RI

CTS

RXD

DSR

GND

1 2

3 4

5

6

7

8

9

UG95 Hardware Design

The following figure is an example of connection between UG95 and PC. A voltage level translator and a

RS-232 level translator chip must be inserted between module and PC, since the UART interface does

not support the RS-232 level, while support the 1.8V CMOS level only.

Figure 18: Reference Circuit with Transistor Circuit

Please visit http://www.ti.com for more information.

UG95_Hardware_Design Confidential / Released 36 / 67

Figure 19: RS232 Level Match Circuit

UMTS/HSPA Module Series

1. The module disables the hardware flow control by default. When hardware flow control is required,

RTS and CTS should be connected to the host. AT command AT+IFC=2,2 is used to enable

hardware flow control. AT command AT+IFC=0,0 is used to disable the hardware flow control. For

more details, please refer to document [1].

2. Rising edge on DTR will let the module exit from the data mode by default. It can be disabled by AT

commands. Refer to document [1] for details.

3. DCD is used as data mode indication. Refer to document [1] for details.

4. It is suggested to set USB_DP, USB_DM and USB_VBUS pins as test points and then place these

test points on the DTE for debug.

Pin Name

Pin No. I/O

Description

Comment

USIM_PRES

ENCE

42

DI

USIM card detection input.

1.8V power domain.

USIM_VDD

43

PO

Power supply for USIM card.

Either 1.8V or 3.0V is supported

by the module automatically.

USIM_RST

44

DO

Reset signal of USIM card.

USIM_DATA

45

IO

Data signal of USIM card.

Pull-up to USIM_VDD with 4.7k

resistor internally.

USIM_CLK

46

DO

Clock signal of USIM card.

USIM_GND

47

Specified ground for USIM

card.

NOTES

UG95 Hardware Design

3.11. USIM Card Interface

3.11.1. USIM Card Application

The USIM card interface circuitry meets ETSI and IMT-2000 SIM interface requirements. Both 1.8V and

3.0V USIM cards are supported.

Table 12: Pin Definition of the USIM Interface

UG95_Hardware_Design Confidential / Released 37 / 67

UMTS/HSPA Module Series

USIM_VDD

USIM_GND/GND

USIM_RST

USIM_CLK

USIM_DATA

USIM_PRESENCE

22R

VDD_EXT

51K

100nF USIM holder

GND

ESDA6V8AV6

33pF 33pF 33pF

VCC RST

CLK

IO

VPP

GND

USIM_VDD

15K

Module

USIM_VDD

USIM_GND

USIM_RST

USIM_CLK

USIM_DATA

22R

100nF

USIM holder

GND

ESDA6V8AV6

33pF 33pF 33pF

VCC RST

CLK IO

VPP

GND

15K

USIM_VDD

UG95 Hardware Design

The following figure shows the reference design of the 8-pin USIM card.

Figure 20: Reference Circuit of the 8-Pin USIM Card

UG95 supports USIM card hot-plugging via the USIM_PRESENCE pin. If you do not need the USIM card

detection function, keep USIM_PRESENCE unconnected. The reference circuit for using a 6-pin USIM

card socket is illustrated as the following figure.

Figure 21: Reference Circuit of the 6-Pin USIM Card

UG95_Hardware_Design Confidential / Released 38 / 67

UMTS/HSPA Module Series

UG95 Hardware Design

In order to enhance the reliability and availability of the USIM card in customer’s application, please follow

the following criterion in the USIM circuit design:

 Keep layout of USIM card as close as possible to the module. Assure the possibility of the length of

the trace is less than 200mm.

 Keep USIM card signal away from RF and VBAT alignment.  Assure the ground between module and USIM holder short and wide. Keep the width of ground and

USIM_VDD no less than 0.5mm to maintain the same electric potential. The decouple capacitor of

USIM_VDD should be less than 1uF and must be near to USIM holder.

 To avoid cross-talk between USIM_DATA and USIM_CLK, keep them away with each other and

shield them with surrounded ground.

 In order to offer good ESD protection, it is recommended to add TVS such as WILL

(http://www.willsemi.com) ESDA6V8AV6. The 22Ω resistors should be added in series between the

module and the USIM card so as to suppress the EMI spurious transmission and enhance the ESD

protection.

3.11.2. Design Considerations for USIM Card Holder

For 8-pin USIM card holder, it is recommended to use Molex 91228. Please visit http://www.molex.com for

more information.

Figure 22: Molex 91228 USIM Card Holder

UG95_Hardware_Design Confidential / Released 39 / 67

UMTS/HSPA Module Series

Name

Function

VDD

C1

USIM card power supply.

RST

C2

USIM card reset.

CLK

C3

USIM card clock.

/

C4

Not defined.

GND

C5

Ground.

VPP

C6

Not connected.

DATA I/O

C7

USIM card data.

/

C8

Pull-down GND with external circuit. When the tray is present, C4

is connected to C8.

UG95 Hardware Design

Table 13: Pin Description of Molex USIM Card Holder

For 6-pin USIM card holder, it is recommended to use Amphenol C707 10M006 512 2. Please visit

http://www.amphenol.com for more information.

Figure 23: Amphenol C707 10M006 512 2 USIM Card Holder

UG95_Hardware_Design Confidential / Released 40 / 67

UMTS/HSPA Module Series

Name

Function

VDD

C1

USIM card power supply.

RST

C2

USIM card reset.

CLK

C3

USIM card clock.

GND

C5

Ground.

VPP

C6

Not connected.

DATA I/O

C7

USIM card data.

Pin Name

Pin No. I/O

Description

Comment

USB_DP

9

IO

USB differential data bus (positive).

Require differential

impedance of 90Ω.

USB_DM

10

IO

USB differential data bus (minus).

Require differential

impedance of 90Ω.

USB_VBUS

8

PI

Used for detecting the USB interface

connected.

2.5~5.25V.

Typical 5.0V.

UG95 Hardware Design

Table 14: Pin Description of Amphenol USIM Card Holder

3.12. USB Interface

UG95 contains one integrated Universal Serial Bus (USB) transceiver which complies with the USB 2.0

specification and supports high speed (480 Mbps), full speed (12 Mbps) and low speed (1.5 Mbps) mode.

The USB interface is primarily used for AT command, data transmission, software debug and firmware

upgrade. The following table shows the pin definition of USB interface.

Table 15: USB Pin Description

More details about the USB 2.0 specifications, please visit http://www.usb.org/home.

UG95_Hardware_Design Confidential / Released 41 / 67

UMTS/HSPA Module Series

Module

USB_VBUS

USB_DP

USB_DM

GND

USB connector

Close to USB connector

Differential layout

USB_VBUS

USB_DP

USB_DM

GND

NM_2pF

ESD

ESD9L5.0ST5G

SD12

0R

NM

Module

USB_DM

USB_DP

VBAT_BB

USB_VBUS

PWRKEY

GND

VBAT_RF

USB_DM

USB_DP

VBAT

USB_VBUS

PWRKEY

GND

Connector

UG95 Hardware Design

The following figure shows the reference circuit of USB interface.

Figure 24: Reference Circuit of USB Application

In order to ensure the USB interface design corresponding with the USB 2.0 specification, please comply

with the following principles:

 It is important to route the USB signal traces as differential pairs with total grounding. The impedance

of USB differential trace is 90ohm.

 Pay attention to the influence of junction capacitance of ESD component on USB data lines. Typically,

the capacitance value should be less than 2pF such as ESD9L5.0ST5G.

 Do not route signal traces under crystals, oscillators, magnetic devices and RF signal traces. It is

important to route the USB differential traces in inner-layer with ground shielding not only upper and

lower layer but also right and left side.

 Keep the ESD components as closer to the USB connector as possible.

 It is suggested to reserve RC circuit near USB connector for debug.

The USB interface is recommended to be reserved for firmware upgrade in your design. The following

figure shows the recommended test points.

UG95_Hardware_Design Confidential / Released 42 / 67

Figure 25: Test Points of Firmware Upgrade

UMTS/HSPA Module Series

1. UG95 module can only be used as a slave device.

2. It is suggested to set USB_DP, USB_DM and USB_VBUS pins as test points and then place these

test points on the DTE for debug.

3. USB interface supports software debug and firmware upgrade by default.

Pin Name

Pin No. I/O

Description

Comment

PCM_CLK

4

IO

PCM data bit clock.

1.8V power domain.

PCM_SYNC

5

IO

PCM data frame sync signal.

1.8V power domain.

PCM_IN

6

DI

PCM data input.

1.8V power domain.

PCM_OUT

7

DO

PCM data output.

1.8V power domain.

I2C_SCL

40

DO

I2C serial clock.

Require external pull-up resistor.

I2C_SDA

41

IO

I2C serial data.

Require external pull-up resistor.

NOTE

UG95 Hardware Design

3.13. PCM and I2C Interface

UG95 provides one Pulse Code Modulation (PCM) digital interface for audio design, which supports the

following features:

 Supports 8, 16, 32 bit mode with short frame synchronization, the PCM support 8 bit mode by default

since the PCM codec default configuration is AT+QDAI=1. Refer to document [1] for more details.

 Supports master mode.  Supports audio sample rate 8 kHz.

The following table shows the pin definition of PCM and I2C interface which can be applied on audio

codec design.

Table 16: Pin Definition of PCM and I2C Interface

In PCM audio format the MSB of the channel included in the frame (PCM_SYNC) is clocked on the

second CLK falling edge after the PCM_SYNC pulse rising edge. The period of the PCM_SYNC signal

(frame) lasts for Data word bit +1 clock pulses.

UG95’s firmware has integrated the configuration on ALC5616 application with I2C interface. You can

execute command AT+QDAI=3 to configure the ALC5616 codec, and refer to document [1] for more

UG95_Hardware_Design Confidential / Released 43 / 67

UMTS/HSPA Module Series

PCM_CLK

PCM_SYNC

PCM_IN/OUT

32

1 0

31

Sampling freq. = 8 KHz

32-bit data word

BCLK = 264 KHz

33

MSB

PCM_IN

PCM_OUT

PCM_SYNC

PCM_CLK

I2C_SCL

I2C_SDA

CODEC

Module

1.8V

1K

BCLK

LRCLK

DACDAT

ADCDAT

SCL

SDA

BIAS

MICBIAS

MIC+

MIC-

SPK+

SPK-

It is recommended to reserved RC (R=22Ω, C=22pF) circuit on the PCM lines, especially for PCM_CLK.

NOTE

UG95 Hardware Design

details. Data bit is 32 bit and the sampling rate is 8 KHz. The following figure shows the timing of the

application with ALC5616 codec.

Figure 26: PCM Master Mode Timing

In general, the BitClockFrequency (CLK) is furnished by the following expression:

BitClockFrequency = (DataWordBit +1) × SamplingFrequency

The following figure shows the reference design of PCM interface with external codec IC.

Figure 27: Reference Circuit of PCM Application with Audio Codec

UG95_Hardware_Design Confidential / Released 44 / 67

UMTS/HSPA Module Series

Pin Name

Pin No. I/O

Description

Comment

NETLIGHT

21

DO

Indicate the module network activity

status.

1.8V power domain.

Pin Name

Status

Description

NETLIGHT

Flicker slowly (200ms High/1800ms Low)

Networks searching.

Flicker slowly (1800ms High/200ms Low)

Idle.

Always High

Voice&CSD calling.

4.7K

47K

VBAT

2.2K

Module

NETLIGHT

UG95 Hardware Design

3.14. Network Status Indication

The NETLIGHT signal can be used to drive a network status indication LED. The following tables describe

pin definition and logic level changes in different network status.

Table 17: Pin Definition of Network Indicator

Table 18: Working State of the Network Indicator

A reference circuit is shown in the following figure.

Figure 28: Reference Circuit of the NETLIGHT

UG95_Hardware_Design Confidential / Released 45 / 67

UMTS/HSPA Module Series

Pin Name

Pin No. I/O

Description

Comment

STATUS

20

DO

Indicate the module operation status.

1.8V power domain.

4.7K

47K

VBAT

2.2K

Module

STATUS

UG95 Hardware Design

3.15. Operating Status Indication

The STATUS pin is set as an output pin and can be used to judge whether module is power-on. In

customer’s design, this pin can be used to drive an LED in order to judge the module’s operation status.

The following table describes pin definition of STATUS.

Table 19: Pin Definition of STATUS

A reference circuit is shown as below.

UG95_Hardware_Design Confidential / Released 46 / 67

Figure 29: Reference Circuit of the STATUS

UMTS/HSPA Module Series

Pin Name

Pin No.

I/O

Description

Comment

GND

58 ground

GND

59 ground

RF_ANT

60

IO

RF antenna pad

50Ω impedance

GND

61 ground

GND

62 ground

Band

Receive

Transmit

Unit

UMTS1900

1930 ~ 1990

1850 ~ 1910

MHz

UMTS850

869 ~ 894

824 ~ 849

MHz

UG95 Hardware Design

4 Antenna Interface

The Pin 60 is the RF antenna pad. The RF interface has an impedance of 50Ω.

4.1. UMTS Antenna Interface

4.1.1. Pin Definition

Table 20: Pin Definition of the RF Antenna

4.1.2. Operating Frequency

Table 21: The Module Operating Frequencies

4.1.3. Reference Design

The RF external circuit is recommended as below. It should reserve a π-type matching circuit for better

RF performance. The capacitors are not mounted by default.

UG95_Hardware_Design Confidential / Released 47 / 67

UMTS/HSPA Module Series

RF_ANT

R1 0R

C1

NM

C2

NM

Module

Type

Requirements

UMTS 850

Cable insertion loss <1dB

UMTS 1900/2100

Cable insertion loss <1.5dB

Type

Requirements

Frequency Range

UG95

UMTS Dual-band: 850/1900MHz.

VSWR

≤ 2

UG95 Hardware Design

Figure 30: Reference Circuit of Antenna Interface

UG95 provides an RF antenna PAD for customer’s antenna connection. The RF trace in host PCB

connected to the module RF antenna pad should be micro-strip line or other types of RF trace, whose

characteristic impendence should be close to 50Ω. UG95 comes with grounding pads which are next to

the antenna pad in order to give a better grounding.

4.2. Antenna Installation

4.2.1. Antenna Requirement

The following table shows the requirement on UMTS antenna.

Table 22: Antenna Cable Requirements

Table 23: Antenna Requirements

UG95_Hardware_Design Confidential / Released 48 / 67

UMTS/HSPA Module Series

Gain (dBi)

1

Max Input Power (W)

50

Input Impedance (Ω)

50

Polarization Type

Vertical

UG95 Hardware Design

4.2.2. Install the Antenna with RF Connector

The following is the antenna installation with RF connector provided by HIROSE. The recommended RF

connector is UF.L-R-SMT.

You can use U.FL-LP serial connector listed in the following figure to match the UF.L-R-SMT.

UG95_Hardware_Design Confidential / Released 49 / 67

Figure 31: Dimensions of the UF.L-R-SMT Connector (Unit: mm)

UMTS/HSPA Module Series

UG95 Hardware Design

Figure 32: Mechanicals of UF.L-LP Connectors (Unit: mm)

The following figure describes the space factor of mated connector

Figure 33: Space Factor of Mated Connector (Unit: mm)

For more details, please visit http://www.hirose.com.

UG95_Hardware_Design Confidential / Released 50 / 67

UMTS/HSPA Module Series

Parameter

Min.

Max.

Unit

VBAT_RF/VBAT_BB

-0.3

4.7

V

USB_VBUS

-0.3

5.5 V Peak Current of VBAT_BB

0

0.8 A Peak Current of VBAT_RF

0 2 A

Voltage at Digital Pins

-0.3

2.3

V

Parameter

Description

Conditions

Min.

Typ.

Max.

Unit

VBAT

VBAT_BB and

VBAT_RF

Voltage must stay within the

min/max values, including voltage

drop, ripple, and spikes.

3.4

3.8

4.3

V USB_VBUS

USB insert

detection

2.5

5.0

5.25

V

UG95 Hardware Design

5 Electrical, Reliability and Radio

Characteristics

5.1. Absolute Maximum Ratings

Absolute maximum ratings for power supply and voltage on digital and analog pins of module are listed in

the following table.

Table 24: Absolute Maximum Ratings

5.2. Power Supply Ratings

Table 25: The Module Power Supply Ratings

UG95_Hardware_Design Confidential / Released 51 / 67

UMTS/HSPA Module Series

Parameter

Min.

Typ.

Max.

Unit

Normal Temperature

-35

25

70

ºC

Restricted Operation1)

-40~ -35

70 ~ 85

ºC

Storage Temperature

-45 90

ºC

1)

When the module works within the temperature range, the deviations from the RF specification may

occur. For example, the frequency error or the phase error would increase.

Parameter

Description

Conditions

Min.

Typ.

Max.

Unit

I

VBAT

OFF state

supply current

Power down

70 uA

WCDMA

supply current

Sleep (USB disconnected)

@DRX=6

1.98

mA

Sleep (USB disconnected)

@DRX=7

1.46

mA

Sleep (USB disconnected)

@DRX=8

1.24

mA

Sleep (USB disconnected)

@DRX=9

1.15

mA

Idle (USB disconnected) @DRX=6

12 mA

NOTE

UG95 Hardware Design

5.3. Operating Temperature

The operating temperature is listed in the following table.

Table 26: Operating Temperature

5.4. Current Consumption

The values of current consumption are shown below.

Table 27: The Module Current Consumption

UG95_Hardware_Design Confidential / Released 52 / 67

UMTS/HSPA Module Series

Parameter

Description

Conditions

Min.

Typ.

Max.

Unit

Idle (USB connected) @DRX=6

31.7

mA

WCDMA data

transfer

UMTS2100 HSDPA @max power

524

mA

UMTS2100 HSUPA @max power

536

mA

UMTS1900 HSDPA @max power

522

mA

UMTS1900 HSUPA @max power

563

mA

UMTS850 HSDPA @max power

490

mA

UMTS850 HSUPA @max power

520

mA

UMTS900 HSDPA @max power

510

mA

UMTS900 HSUPA @max power

512

mA

Frequency

Max.

Min.

UMTS1900

22.25dBm+1/-1dB

<-50dBm

UMTS850

22.25dBm+1/-1dB

<-50dBm

Frequency

Receive Sensitivity (Typ.)

UMTS1900

-110.5dBm

UG95 Hardware Design

5.5. RF Output Power

The following table shows the RF output power of UG95 module.

Table 28: Conducted RF Output Power

5.6. RF Receiving Sensitivity

The following table shows the conducted RF receiving sensitivity of UG95 module.

Table 29: Conducted RF Receiving Sensitivity

UG95_Hardware_Design Confidential / Released 53 / 67

UMTS/HSPA Module Series

UMTS850

-110.5dBm

UG95 Hardware Design

5.7. Electrostatic Discharge

The module is not protected against electrostatics discharge (ESD) in general. Consequently, it is subject

to ESD handling precautions that typically apply to ESD sensitive components. Proper ESD handling and

packaging procedures must be applied throughout the processing, handling and operation of any

application that incorporates the module.

UG95_Hardware_Design Confidential / Released 54 / 67

UMTS/HSPA Module Series

0.8+/-0.1

2.2+/-0.2

19.9+/-0.15

23.6+/-0.15

UG95 Hardware Design

6 Mechanical Dimensions

This chapter describes the mechanical dimensions of the module. All dimensions are measured in mm.

6.1. Mechanical Dimensions of the Module

UG95_Hardware_Design Confidential / Released 55 / 67

Figure 34: UG95 Top and Side Dimensions

UMTS/HSPA Module Series

0.775

1.00

19.90

23.60

1.10

1.15

1.70

1.00

0.85

0.55

0.70

1.70

UG95 Hardware Design

Figure 35: UG95 Bottom Dimension (Top View)

UG95_Hardware_Design Confidential / Released 56 / 67

UMTS/HSPA Module Series

19.90

23.60

0.85

1.70

1.00

1.95

0.55

2.35

0.70

1.10

0.20

1.90

1.00

1. In order to maintain the module, keep about 3mm between the module and other components in the

host PCB.

2. All RESERVED pins must not be connected to GND.

NOTES

UG95 Hardware Design

6.2. Footprint of Recommendation

Figure 36: Recommended Footprint (Top View)

UG95_Hardware_Design Confidential / Released 57 / 67

UMTS/HSPA Module Series

UG95 Hardware Design

6.3. Top View of the Module

Figure 37: Top View of the Module

6.4. Bottom View of the Module

Figure 38: Bottom View of the Module

UG95_Hardware_Design Confidential / Released 58 / 67

UMTS/HSPA Module Series

As plastic container cannot be subjected to high temperature, module needs to be taken out from

container to high temperature (125ºC) bake. If shorter bake times are desired, please refer to

IPC/JEDECJ-STD-033 for bake procedure.

NOTE

UG95 Hardware Design

7 Storage and Manufacturing

7.1. Storage

UG95 is stored in the vacuum-sealed bag. The restriction of storage condition is shown as below.

Shelf life in sealed bag is 12 months at < 40ºC/90%RH.

After this bag is opened, devices that will be subjected to reflow solder or other high temperature process

must be:

 Mounted within 72 hours at factory conditions of ≤ 30ºC/60%RH.  Stored at <10% RH.

Devices require bake, before mounting, if:

 Humidity indicator card is >10% when read 23ºC±5ºC.  Mounted for more than 72 hours at factory conditions of ≤ 30ºC/60% RH.

If baking is required, devices may be baked for 48 hours at 125ºC±5ºC.

7.2. Manufacturing and Welding

The squeegee should push the paste on the surface of the stencil that makes the paste fill the stencil

openings and penetrate to the PCB. The force on the squeegee should be adjusted so as to produce a

clean stencil surface on a single pass. To ensure the module soldering quality, the thickness of stencil at

the hole of the module pads should be 0.13mm. For details, please refer to document [6].

UG95_Hardware_Design Confidential / Released 59 / 67

UMTS/HSPA Module Series

Time

50

100

150 200

250 300

50

100

150

200

250

160 ºC

200 ºC

217

0

70s~120s

40s~60s

Between 1~3 ºC/s

Preheat Heating Cooling

ºC

s

Liquids Temperature

UG95 Hardware Design

It is suggested that peak reflow temperature is 235 ~ 245ºC (for SnAg3.0Cu0.5 alloy). Absolute max

reflow temperature is 260ºC. To avoid damage to the module when it was repeatedly heated, it is

suggested that the module should be mounted after the first panel has been reflowed. The following

picture is the actual diagram which we have operated.

7.3. Packaging

TBD

Figure 39: Reflow Soldering Profile

UG95_Hardware_Design Confidential / Released 60 / 67

UMTS/HSPA Module Series

SN

Document Name

Remark

[1]

Quectel_UG95_AT_Commands_Manual

UG95 AT Commands Manual

[2]

Quectel_UC20_EVB_User_Guide

UC20 EVB User Guide

[3]

Quectel_UG95_Reference_Design

UG95 Reference Design

[4]

Quectel_UG95&M95_Reference_Design

UG95 and M95 Compatible Reference Design

[5]

Quectel_UG95&M95_Compatible_Design

UG95 and M95 Compatibility Design Specification

[6]

Quectel_Module_Secondary_SMT_User_

Guide

Module Secondary SMT User Guide

Abbreviation

Description

AMR

Adaptive Multi-rate

ARP

Antenna Reference Point

bps

Bits Per Second

CHAP

Challenge Handshake Authentication Protocol

CS

Coding Scheme

CSD

Circuit Switched Data

CTS

Clear To Send

DRX

Discontinuous Reception

DCE

Data Communications Equipment (typically module)

DTE

Data Terminal Equipment (typically computer, external controller)

UG95 Hardware Design

8 Appendix A Reference

Table 30: Related Documents

Table 31: Terms and Abbreviations

UG95_Hardware_Design Confidential / Released 61 / 67

UMTS/HSPA Module Series

DTR

Data Terminal Ready

DTX

Discontinuous Transmission

EFR

Enhanced Full Rate

EGSM

Extended GSM900 band (includes standard GSM900 band)

ESD

Electrostatic Discharge

FR

Full Rate

GMSK

Gaussian Minimum Shift Keying

GPS

Global Positioning System

GSM

Global System for Mobile Communications

HR

Half Rate

HSPA

High Speed Packet Access

I/O

Input/Output

IMEI

International Mobile Equipment Identity

Imax

Maximum Load Current

Inorm

Normal Current

LED

Light Emitting Diode

LNA

Low Noise Amplifier

MO

Mobile Originated

MS

Mobile Station (GSM engine)

MT

Mobile Terminated

PAP

Password Authentication Protocol

PBCCH

Packet Broadcast Control Channel

PCB

Printed Circuit Board

PDU

Protocol Data Unit

PPP

Point-to-Point Protocol

UG95 Hardware Design

UG95_Hardware_Design Confidential / Released 62 / 67

UMTS/HSPA Module Series

PSK

Phase Shift Keying

QAM

Quadrature Amplitude Modulation

QPSK

Quadrature Phase Shift Keying

RF

Radio Frequency

RHCP

Right Hand Circularly Polarized

RMS

Root Mean Square (value)

RTC

Real Time Clock

Rx

Receive

SIM

Subscriber Identification Module

SMS

Short Message Service

TDMA

Time Division Multiple Access

TE

Terminal Equipment

TX

Transmitting Direction

UART

Universal Asynchronous Receiver & Transmitter

UMTS

Universal Mobile Telecommunications System

URC

Unsolicited Result Code

USIM

Universal Subscriber Identity Module

USSD

Unstructured Supplementary Service Data

Vmax

Maximum Voltage Value

Vnorm

Normal Voltage Value

Vmin

Minimum Voltage Value

VIHmax

Maximum Input High Level Voltage Value

VIHmin

Minimum Input High Level Voltage Value

VILmax

Maximum Input Low Level Voltage Value

VILmin

Minimum Input Low Level Voltage Value

UG95 Hardware Design

UG95_Hardware_Design Confidential / Released 63 / 67

UMTS/HSPA Module Series

VImax

Absolute Maximum Input Voltage Value

VImin

Absolute Minimum Input Voltage Value

VOHmax

Maximum Output High Level Voltage Value

VOHmin

Minimum Output High Level Voltage Value

VOLmax

Maximum Output Low Level Voltage Value

VOLmin

Minimum Output Low Level Voltage Value

VSWR

Voltage Standing Wave Ratio

WCDMA

Wideband Code Division Multiple Access

UG95 Hardware Design

UG95_Hardware_Design Confidential / Released 64 / 67

UMTS/HSPA Module Series

Scheme

CS-1

CS-2

CS-3

C4-4

Code Rate

1/2

2/3

3/4

1

USF

3 3 3

3

Pre-coded USF

3 6 6

12

Radio Block excl.USF and BCS

181

268

312

428

BCS

40

16

Tail

4 4 4

-

Coded Bits

456

588

676

456

Punctured Bits

0

132

220

-

Data Rate Kb/s

9.05

13.4

15.6

21.4

UG95 Hardware Design

9 Appendix B GPRS Coding Scheme

Table 32: Description of Different Coding Schemes

UG95_Hardware_Design Confidential / Released 65 / 67

UMTS/HSPA Module Series

Multislot Class

Downlink Slots

Uplink Slots

Active Slots

1 1 1

2

2 2 1

3

3 2 2

3

4 3 1 4 5 2 2

4

6 3 2 4 7 3 3

4

8 4 1

5

9 3 2

5

10 4 2 5 11 4 3

5

12 4 4

5

UG95 Hardware Design

10 Appendix C GPRS Multi-slot Class

Twenty-nine classes of GPRS multi-slot modes are defined for MS in GPRS specification. Multi-slot

classes are product dependant, and determine the maximum achievable data rates in both the uplink and

downlink directions. Written as 3+1 or 2+2, the first number indicates the amount of downlink timeslots,

while the second number indicates the amount of uplink timeslots. The active slots determine the total

number of slots the GPRS device can use simultaneously for both uplink and downlink communications.

The description of different multi-slot classes is shown in the following table.

Table 33: GPRS Multi-slot Classes

UG95_Hardware_Design Confidential / Released 66 / 67

UMTS/HSPA Module Series

Coding Scheme

Modulation

Coding Family

1 Timeslot

2 Timeslot

4 Timeslot

CS-1:

GMSK

/

9.05kbps

18.1kbps

36.2kbps

CS-2:

GMSK

/

13.4kbps

26.8kbps

53.6kbps

CS-3:

GMSK

/

15.6kbps

31.2kbps

62.4kbps

CS-4:

GMSK

/

21.4kbps

42.8kbps

85.6kbps

MCS-1

GMSK

C

8.80kbps

17.60kbps

35.20kbps

MCS-2

GMSK

B

11.2kbps

22.4kbps

44.8kbps

MCS-3

GMSK

A

14.8kbps

29.6kbps

59.2kbps

MCS-4

GMSK

C

17.6kbps

35.2kbps

70.4kbps

MCS-5

8-PSK

B

22.4kbps

44.8kbps

89.6kbps

MCS-6

8-PSK

A

29.6kbps

59.2kbps

118.4kbps

MCS-7

8-PSK

B

44.8kbps

89.6kbps

179.2kbps

MCS-8

8-PSK

A

54.4kbps

108.8kbps

217.6kbps

MCS-9

8-PSK

A

59.2kbps

118.4kbps

236.8kbps

UG95 Hardware Design

11 Appendix D EDGE Modulation and

Coding Scheme

Table 34: EDGE Modulation and Coding Scheme

UG95_Hardware_Design Confidential / Released 67 / 67

Quectel Wireless Solutions 201408UG95 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
