Quantum Scalar 1000 Release Notes

Release Notes

Product: Scalar® 1000 641A.00003
Date: December 2006

Contents

Page Topic

1 Purpose of this Release

1 New Enhancement

2 Compatibility Matrix

3 Resolved Issues

4 Known Issues

4 Documentation

Purpose of this Release

This Scalar 1000 641 firmware release adds one new enhancement that extend the capabilities of the
Scalar 1000 Library. This document describes the new enhancement, as well as corrections made to issues
encountered in previous releases of the library. Visit www.adic.com for additional information about
Scalar 1000 641 Firmware and previous releases.

New Enhancement

The following enhancement is in this release of the Scalar 1000:

• Improved label scanning during teaching

Previously, teach values could vary as much as 2mm between teaches, which could generate SAC
7C errors.

To improve scanning accuracy and reduce variance errors, labels are now scanned at least twice.
If the X or Y value exceeds 0.5mm, either X, Y, or both are scanned again. After scanning, the
largest X value and smallest Y value are passed to the teach function to calculate cell positions.

Also, to help eliminate SAC 7B errors that occurred during teach mastering, the reach motor
extends 1mm farther while extending to the teach master bracket.

Finally, to alert users when a scanner might need replacing, during the teach a warning message
appears on the operator panel when the scan beam is not level or is jittery.

© December 2006, ADIC®
ADIC and Scalar are registered trademarks of Advanced Digital Information Corporation. All
other product, company, or service names mentioned herein are the property of their respec­tive owners.

6-00017-26 Rev A

Compatibility Matrix

Refer to Table 1 for information on drive and auxiliary firmware compatibility with Scalar 1000 641 firmware.

Table 1 Drive and Auxiliary Firmware Compatibility Matrix

Component Firmware Version

RMU 161A.00005, 186A.00007, and 210A.00002

SNCs

SNC 3000 3.43.18

SNC 5100 4.45.10, 4.45.15, and 4.45.16

Scalar DLC 2.6

Drive Types

LTO - 1

LTO-2 53Y2, 42D1 and 4AP0

AIT-1 04E5

AIT-2 0200_CY10

AIT-3 0209_0001

3590-B1A D0IA_572

3590-E1A D0IF_26E

DLT-4000 V151

DLT-7000 V107

DLT-8000 V80

SDLT 220 V82

SDLT 320 V82

53J1, 36UC and 4561
