WP-153001-00 120V Rev. A
Part Number Description Qty Ref Des
CA-005001-GP 5P, +0.25P, 100V, CTC, 0805, 0/30 1 C39
CA-015005-GP 15PF, 5 PCNT, 50V, CERAMIC, 0805, 2 C368, C369
CA-033003-GP 33PF, 5%, 50V, CC, 0805, 1.2X 2 C11, C12
CA-068003-GP 68PF, 5%, , CTC, 0805, 0/30 1 C307
CA-110005-GP CC 50V 100PF 5% 0805 1.2 1 C47
CA-110007-GP 100P, 5%, 100V, CTC, 0805, 0/30 1 C49
CA-122005-GP CC 50V 220PF 5% 0805 5 C31, C42, C45, C46, C6
CA-147006-GP 470PF 5% 50V CER NPO 2 C302, C303
CA-156002-GP 560P, 5%, 50V, CM, , RLT P5.0 3 C362, C364, C366
CA-222014-GP 2200P, 5%, 63V, CM, , RBT 3 C338, C340, C341
CA-222015-GP 2200P, 5%, 50V, CTC, 0805, 0/30 2 C26, C40
CA-233009-GP 3300P, 5%, 100V, CTC, 1206, 0/30 1 C4
CA-233010-GP 3300P, 5%, 63V, CM, , RBT, 7.5X 3 C348, C351, C352
CA-247005-GP .0047UF, 5 PCNT, 50V, FILM, DIPPED, 4 C324, C328, C331, C333
CA-268002-GP 6800P, 5%, 63V, CM, , RBT 7 C339, C343, C344, C349, C354, C355, C361
CA-310010-GP 0.01U, 5%, 63V, CM, , RBT 7.5X 2 C350, C365
CA-318002-GP 0.018U, 5%, 63V, CM, , RBT 3 C342, C345, C346
CA-322011-GP 0.022U, 5%, 63V, CM, , RBT 6 C325, C329, C332, C335, C347, C359
CA-333001-GP 0.033UF, 5%, 63V, CM, , RB, 7.5 1 C360
CA-368006-GP .068UF, 5 PCNT, 50V, FILM, , 4 C353, C356, C357, C358
CA-410014-GP 0.1UF 10% 50V CER X7R 0805 21 C17, C22, C27, C29, C301, C304, C305, C306, C309, C310, C312, C316, C317, C319, C32, C33, C34, C370, C43, C50, C7
CA-410018-GP CM 250V .1UF 5% RL 2 C8, C9
CA-410023-GP 0.1UF, 5%, 63V, CM, , RBT, 7.5X6 1 C363
CA-410024-GP CC 200V 0.1U 5% 1210 2 C21, C38
CA-415006-GP .15UF, 5 PCNT, 200V, CC, 1210, 1 C2
CA-422010-GP 0.22U, 10%, 50V, CC, 0805, 2 C10, C30
CA-422011-GP 0.22U, 5%, 63V, CM, , RBT, 7.5X 8 C311, C313, C320, C321, C327, C330, C334, C336
CA-510016-GP 1U, 10%, 25V, CC, 0805, 1 C314
CA-510017-GP 1UF, 20 PCNT, 50V, CC, SMT, 1210 2 C24, C25
CA-610009-GP CE 35V 10UF 20% RL 5 X 11 1 C35
CA-622010-GP 22UF, 20%, 35V, CE, , RLT, 5x11 1 C36
CA-647006-GP CE 16NP 47UF 20% RL 6 C1, C20, C308, C326, C337, C37
CA-710014-GP 100U, 20%, 25V, CE, , RLT, 6X11 1 C315
CA-722007-GP 220UF, 20 PCNT, 25V, CE, RL, 1 C318
CA-747009-GP 470UF, 20%, 16V, CE, , RLT 2 C322, C323
CA-810007-GP 1000UF, 20%, 25V, CE, , RLT 2 C18, C19
CA-868002-GP 6800UF, 20 PCNT, 63V, CE, RL, 4 C13, C14, C15, C16
CH-000173-GP COVER, XFMR, STEEL, LARGE 1
CH-000489-GP PLATE-SPRING STEEL, , , , 5
CH-000490-GP HEATSINK, 381X189.2X38.1, , HPR, 1
CH-000547-GP PANEL, INPUT, , HPR153i, 1
CH-000550-GP PANEL, AC, , HPRi, 1
CO-000058-GP XLR, CONNECTOR, 3PM, , , 1 J301
CO-000204-GP CONN XLR F VERT PLASTIC 1 J302
CO-000211-GP AC INLET 250V 15A 1
CO-000213-GP CONN 2 PIN STRAIGHT WAFER 1 J304A
CO-000214-GP CONN 3 PIN STRAIGHT WAFER 1 J3
CO-000347-GP TERMINAL BLOCK, 5MM, 5POS(1X5), FEMALE, RIGHT ANGLE 1 J2
CO-000348-GP TERMINAL BLOCK, 5MM, 6POS (1X6), FEMALE, RIGHT ANGLE 1 J4
CO-000349-GP WIRE HOLDER, RIBBON CABLE, 10 POS, FEMALE, 3 J303, J305B, J306
CO-000350-GP WIRE TRAP, RIBBON CABLE, 10 POS, FEMALE, RELEASEABLE 3 J305A, J5, J6
HW-000075-GP FUSE HOLDER, , , , , 3 F1, F2, F3
HW-000102-GP BRASS POST, D6X10, , , , 3
IC-000075-GP IC VOLTAGE REG, +5, LM78L05, SMT, 1 U310
IC-000076-GP IC LM339, SMD COMPARATORS, , , 1 U2
IC-000077-GP IC LM13700M, , , SMT, 1 U305
IC-000078-GP IC LM19, THERMAL SENSOR, , TO-92, 1 U4
IC-000079-GP IC MC33078, OP-AMP, , SMT, 4 U1, U302, U7, U8
IC-000377-GP IC 7805, REGULATOR, 5V, , 1 U3
IC-000378-GP IC LM7915CT, REGULATOR, -15V, , 1 U6
IC-000379-GP IC LM7815CT, REGULATOR, 15V, , 1 U5
IC-000380-GP IC TL072, OPAMP, DUAL, SO-8, 1 U301
IC-000381-GP IC TL074CD-SO14, OPAMP, QUAD, SO-14, 7 U303, U304, U306, U307, U308, U309, U311
LB-000627-GP LABEL, WARNING, TOP BOX, HPRi, 1
MS-000070-GP 2.5A, FAST ACT 5X20, , , 2 F2, F3
MS-000073-GP FUSE, FAST, ACTING 5A, SMT, 1206, 2 F4, F5
MS-000292-GP FUSE, 6.3A, 5 X 20MM, FAST, 1 F1
NW-000070-GP M3, NUT, , , , 3
NW-000072-GP NUT, HEX, M4, , 1
NW-040002-GP SPRING WASHER M4 X 7 1
NW-040003-GP I/T WASHER M4X0.4X8, YZ 1
PC-122001-00 PCB, MAIN, HPR122i, , , 1
PC-122002-00 PCB, INPUT, HPR151i, , , 1
PL-000066-GP EVA GASKET, 5X500, , , , 3
PL-000152-GP CABLE TIE, ISA 4
PL-000327-GP PAD, XFMR, EPDM 40A, 1/8" THK, BLACK, 2
PL-000391-GP KNOB, GAIN, HPR SERIES, , , 1
PL-000454-GP INSULATION SHEET IC, , , SILPAD 800, , 5
PL-000455-GP LED HOLDER, LED3-11, , , , 3 LD301-1, LD302-1, LD303-1
PL-000456-GP SPRINGSEAT, TRANSISTOR, HPR, NYLON, , 5
PL-000457-GP SPACER, L=4.0, ELM 3, , , 1 U4
PL-000458-GP SPONGE CUSHION, , , , , 2
PT-110002-GP TRIM, 100, 20 PCNT, 0.15W, , 3 VR1, VR2, VR3
PT-250003-GP VR 5K, XVB12111YNPVB25F, , , , 1 VR301
QD-000201-GP DIODE LL4148 SM 15 D10, D11, D12, D20, D24, D25, D27, D30, D301, D302, D303, D304, D305, D38, D8
Page 4
WP-153001-00 120V Rev. A
Part Number Description Qty Ref Des
QD-000204-GP XISTOR NPN 60V 200MA 3904 SOT-23 23 Q11, Q16, Q2, Q24, Q25, Q28, Q3, Q301, Q309, Q310, Q311, Q312, Q313, Q314, Q315, Q33, Q37, Q38, Q41, Q42, Q45, Q50, Q6
QD-000205-GP XISTOR PNP 40V 0.2A TR3906 SOT-23 20 Q1, Q10, Q17, Q19, Q23, Q29, Q302, Q303, Q304, Q305, Q306, Q307, Q308, Q32, Q36, Q39, Q40, Q46, Q49, Q7
QD-000206-GP DIOD RECT FAST, IN4934 AT 12 D1, D2, D22, D23, D28, D29, D32, D33, D34, D35, D4, D5
QD-000208-GP XISTOR PNP 230V 15A 2SA1943 4 Q12, Q14, Q34, Q51
QD-000209-GP XISTOR NPN 230V 15A 2SC5200 4 Q13, Q15, Q35, Q52
QD-000227-GP BRIDGE RECT 400V 25A 2 BR1, BR2
QD-000260-GP MOSFET, N-CH, 60V, 52A, 52N06V 2 Q21, Q22
QD-000300-GP LED SC, 2.9 X 5.4 XL 0.5 BL, , , , , 1 LD302
QD-000301-GP LED, 3MM, GREEN SP, , , , 1 LD303
QD-000302-GP LED SP, 2.9 X 5.4 XL 0.5 RED, , , , , 1 LD301
QD-000303-GP DIODE, BAV21WS 250V, , , , , 5 D21, D3, D31, D6, D9
QD-000304-GP DIODE, MUR810 RL 8A, , , , , 2 D13, D15
QD-000305-GP DZ 1/2W, 6.2VB RLZ6.2B, , , , SMT, 2 D14, D7
QD-000306-GP DZ 1/2W, 7.5VB RLZ7.5B LL, , , , SMT, 1 D26
QD-000307-GP SMD DIODE, ISR154-400, , , , , 6 D16, D17, D18, D19, D36, D37
QD-000308-GP TR MMBTA42 NPN SMD, , , , , SOT-23, 4 Q20, Q27, Q44, Q5
QD-000309-GP TR 2SA1837, 100-320 RL, , , , , 3 Q26, Q4, Q43
QD-000310-GP TR 2SC4793, 100-320-RL, , , , , 3 Q31, Q48, Q9
QD-000311-GP TR MMBTA92 SOT 23 KEC, , , , , , 4 Q18, Q30, Q47, Q8
RE-.01002-GP 0.1R, 5 PCNT, 2W, RMF, ATS METAL, 12 R115, R116, R117, R25, R26, R27, R28, R29, R30, R74, R75, R78
RE-.47006-GP RMF, 1W, 4R7, 5%, AT, 3 R49, R6, R88
RE-000003-GP RMG 1/10W 0 OHM 5% 0805 17 R123, R124, R125, R358, R362, R368, R384, R389, R392, R393, R400, R401, R405, R406, R423, R433, R434
RE-001009-GP 10 1% 1/8W THK FLM 1206 2 R337, R338
RE-001012-GP 10OHM, 1/4W, 1%, AT, RMF, 2 R126, R127
RE-001013-GP 10, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R128
RE-004753-GP RMG 1/10W 47.5 OHM 1% 0805 13 R109, R110, R111, R112, R113, R21, R22, R23, R24, R67, R68, R71, R72
RE-010011-GP 100 1% 1/10W THK FLM 0805 100V 17 R103, R104, R107, R108, R14, R15, R19, R20, R301, R302, R307, R317, R318, R60, R61, R64, R65
RE-018001-GP 180R, 1 PCNT, 1/10W, RMG, 0805, 2 R449, R8
RE-020003-GP 200 1% 1/10W THK FLM 0805 100V 1 R93
RE-030006-GP 300 OHM, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R51
RE-040200-GP 402R, 1 PCNT, 1/10W, RMG, 0805, 2 R436, R95
RE-047012-GP 470, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R77
RE-063405-GP 634 OHMS 1% 1/10W 0805 1 R319
RE-091002-GP 910R, 1 PCNT, 1/10W, RMG, 0805, 14 R100, R101, R105, R106, R11, R12, R17, R18, R54, R57, R58, R62, R63, R9
RE-110702-GP 1.07K, 1 PCNT, 1/10W, RMG, 0805, 2 R327, R331
RE-115008-GP 1.5K, 1 PCNT, 1/10W, THK FLM, 0805, 100V 2 R414, R440
RE-120004-GP RMG 1/10W 2K 1% 0805 1 R343
RE-122010-GP 2.2K 1% 1/10W THK FM 0805 100V 3 R102, R16, R59
RE-124001-GP 2.4K, 1 PCNT, 1/10W, RMG, 0805, 4 R2, R35, R44, R81
RE-127001-GP 2.7K, 1 PCNT, 1/10W, RMG, 0805, 1 R313
RE-130006-GP 3K, 1 PCNT, 1/10W, THICK FILM, 0805, 3 R381, R383, R402
RE-130103-GP RMG 1/10W 3.01K 1% 0805 1 R33
RE-133008-GP 3.3K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R435
RE-136003-GP 3.6K, 1 PCNT, 1/10W, RMG, 0805, 3 R361, R373, R443
RE-139006-GP 3.9K, 1 PCNT, 1/10W, THICK FILM, 0805, 3 R396, R411, R424
RE-143001-GP 4.3K, 1 PCNT, 1/10W, RMG, 0805, 1 R378
RE-143202-GP 4.32K, 1 PCNT, 1/10W, RMG, 0805, 1 R316
RE-147002-GP 4.7K 1% 1/10W THK FLM 0805 11 R334, R366, R39, R394, R408, R412, R445, R56, R66, R79, R97
RE-147506-GP 4.75K, 1 PCNT, 1/10W, THICK FILM, 0805, 2 R328, R332
RE-151006-GP 5.1K, 1 PCNT, 1/10W, THICK FILM, 0805, 5 R321, R339, R377, R451, R452
RE-152302-GP 5.23K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R303
RE-156004-GP 5.6K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R335
RE-159003-GP 5.9K 1% 1/10W THK FLM 0805 2 R96, R98
RE-162001-GP 6.2K, 1 PCNT, 1/10W, RMG, 0805, 1 R352
RE-164901-GP 6.49K, 1 PCNT, 1/10W, RMG, 0805, 1 R48
RE-168007-GP 6.8K, 1 PCNT, 1/10W, RMG, 0805, 1 R344
RE-169802-GP 6.98K, 1 PCNT, 1/10W, THK FLM, 0805, 100V 1 R312
RE-175004-GP 7.5K 1% 1/10W THK FM 0805 100V 4 R348, R354, R390, R397
RE-182007-GP 8.2K, 1 PCNT, 1/10W, THICK FILM, 0805, 4 R326, R330, R341, R418
RE-191001-GP 9.1K, 1 PCNT, 1/10W, RMG, 0805, 1 R357
RE-210007-GP 10K 1% 1/10W THK FLM 0805 20 R1, R122, R3, R320, R329, R333, R336, R340, R353, R386, R415, R419, R43, R437, R439, R45, R50, R7, R80, R85
RE-211305-GP 11.3K .1% 1/10W RMG 0805 4 R304, R305, R309, R310
RE-212003-GP 12K 1% 1/10W THK FLM 0805 100V 3 R359, R380, R447
RE-212004-GP 12K, 1 PCNT, 1/8W, THICK FILM, 1206, 1 R448
RE-212105-GP 12.1K, 1 PCNT, 1/10W, RMG, 0805, 1 R441
RE-213005-GP 13K, 1 PCNT, 1/10W, RMG, 0805, 3 R36, R89, R90
RE-215003-GP 15K, 1 PCNT, 1/10W, RMG, 0805, 5 R347, R376, R410, R431, R442
RE-216001-GP 16K, 1 PCNT, 1/10W, RMG, 0805, 1 R342
RE-218006-GP 18K, 1 PCNT, 1/10W, THICK FILM, 0805, 4 R346, R372, R417, R91
RE-218702-GP 18.7K, 1 PCNT, 1/10W, THICK FILM, 0805, 2 R308, R311
RE-220005-GP RMG 1/10W 20K 1% 0805 3 R407, R46, R86
RE-220006-GP 20K, 1 PCNT, 1/10W, THICK FILM, 1206, 1 R38
RE-222001-GP 22K 1% 1/10W 0805 9 R32, R34, R37, R375, R391, R413, R421, R422, R446
RE-224001-GP 24.0K 1% 1/10W THK FLM 0805 2 R314, R453
RE-227001-GP 27K 1% 1/10W 0805 3 R349, R426, R429
RE-230006-GP 30K, 1 PCNT, 1/10W, THICK FILM, 0805, 4 R345, R351, R4, R428
RE-230104-GP 30.1K 1% 1/8W RMG 1206 4 R40, R47, R5, R87
RE-230105-GP 30.1K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R53
RE-236001-GP 36K, 1 PCNT, 1/10W, RMG, 0805, 2 R355, R385
RE-239003-GP 39K, 1 PCNT, 1/10W, MET FLM, 0805, 100V 2 R323, R450
RE-239204-GP 39.2K, 1 PCNT, 1/10W, THICK FILM, 0805, 3 R315, R325, R356
RE-247006-GP 47K 1% 1/10W THK FLM 0805 100V 3 R430, R69, R76
RE-291001-GP 91K, 1 PCNT, 1/10W, RMG, 0805, 3 R367, R388, R427
RE-310007-GP 100K 1% 1/10W THK FLM 0805 5 R306, R350, R364, R370, R438
RE-310008-GP 100K 1% 1/8W THK FLM 1206 6 R10, R31, R52, R83, R92, R94
Page 5
WP-153001-00 120V Rev. A
Part Number Description Qty Ref Des
RE-312006-GP 120K 1% 1/10W RMG 0805 2 R374, R404
RE-315006-GP 150K, 1 PCNT, 1/10W, THICK FILM, 0805, 5 R324, R363, R369, R399, R409
RE-320006-GP 200K, 1 PCNT, 1/10W, THICK FILM, 0805, 2 R322, R454
RE-349901-GP 499K 1% 1/8W THICK FILM 1206 1 R82
RE-410003-GP 1M 1% 1/10W RMG 0805 4 R13, R55, R84, R99
SC-000081-GP T3X8MM, SELF TAPPING, , , , 2
SC-000082-GP SCREW, BIND, HEAD, M3.2 X 8, , B-TITE, 6
SC-000083-GP SCREW, BIND, HEAD, M3.5 X 16, , B-TITE, 10
SC-000084-GP SCREW, BIND, SERRATED HEAD, M4X25, B-TITE, 4
SC-000085-GP SELF SCREW, 3X8, WITH, SERRATED HEAD, , , 2
SC-000086-GP SCREW, M8X101.5, BZ, , , , 1
SC-030002-GP M3 B-TITE FLAT-CS 2
SC-030004-GP M3 X 8 BLK MACHINE 6
SC-040001-GP SCREW M4-18 X 10MM, BLK ZN 2
SW-000088-GP ROCKER POWER SWITCH 1
SW-000093-GP CIRCUIT BREAKER, 5 AMP, , 1
SW-000119-GP CIRCUIT BREAKER, 3A, 230V, HPR, 1
SW-000122-GP SWITCH, 1P2T, , 1 SW302
SW-000123-GP SWITCH, 2P2T, , 1 SW301
WC-000188-GP SLEEVE, PVC, 5MM ID, BLK 0
WC-000410-GP UL1672, AWG#18, BROWN, , , , , 0
WC-000411-GP UL1672, AWG#18, BLUE, , , , , 0
WC-000412-GP GRND WIRE, UL1015 #14, , , , , 1
WC-000413-GP WIRE-FLAT, 10P P1.5 #26, , , , , 3 J303, J305B, J306
WC-000423-GP SHRINKAGE TUBE, ID=6MM, UL, , , , , 0
XF-000293-GP POWER TRANSFORMER, 120V, , , , HPR SERIES, , 1
Page 6
WP-153001-02 230V Rev. A
Part Number Description Qty Ref Des
CA-005001-GP 5P, +0.25P, 100V, CTC, 0805, 0/30 1 C39
CA-015005-GP 15PF, 5 PCNT, 50V, CERAMIC, 0805, 2 C368, C369
CA-033003-GP 33PF, 5%, 50V, CC, 0805, 1.2X 2 C11, C12
CA-068003-GP 68PF, 5%, , CTC, 0805, 0/30 1 C307
CA-110005-GP CC 50V 100PF 5% 0805 1.2 1 C47
CA-110007-GP 100P, 5%, 100V, CTC, 0805, 0/30 1 C49
CA-122005-GP CC 50V 220PF 5% 0805 5 C31, C42, C45, C46, C6
CA-147006-GP 470PF 5% 50V CER NPO 2 C302, C303
CA-156002-GP 560P, 5%, 50V, CM, , RLT P5.0 3 C362, C364, C366
CA-222014-GP 2200P, 5%, 63V, CM, , RBT 3 C338, C340, C341
CA-222015-GP 2200P, 5%, 50V, CTC, 0805, 0/30 2 C26, C40
CA-233009-GP 3300P, 5%, 100V, CTC, 1206, 0/30 1 C4
CA-233010-GP 3300P, 5%, 63V, CM, , RBT, 7.5X 3 C348, C351, C352
CA-247005-GP .0047UF, 5 PCNT, 50V, FILM, DIPPED, 4 C324, C328, C331, C333
CA-268002-GP 6800P, 5%, 63V, CM, , RBT 7 C339, C343, C344, C349, C354, C355, C361
CA-310010-GP 0.01U, 5%, 63V, CM, , RBT 7.5X 2 C350, C365
CA-318002-GP 0.018U, 5%, 63V, CM, , RBT 3 C342, C345, C346
CA-322011-GP 0.022U, 5%, 63V, CM, , RBT 6 C325, C329, C332, C335, C347, C359
CA-333001-GP 0.033UF, 5%, 63V, CM, , RB, 7.5 1 C360
CA-368006-GP .068UF, 5 PCNT, 50V, FILM, , 4 C353, C356, C357, C358
CA-410014-GP 0.1UF 10% 50V CER X7R 0805 21 C17, C22, C27, C29, C301, C304, C305, C306, C309, C310, C312, C316, C317, C319, C32, C33, C34, C370, C43, C50, C7
CA-410018-GP CM 250V .1UF 5% RL 2 C8, C9
CA-410023-GP 0.1UF, 5%, 63V, CM, , RBT, 7.5X6 1 C363
CA-410024-GP CC 200V 0.1U 5% 1210 2 C21, C38
CA-415006-GP .15UF, 5 PCNT, 200V, CC, 1210, 1 C2
CA-422010-GP 0.22U, 10%, 50V, CC, 0805, 2 C10, C30
CA-422011-GP 0.22U, 5%, 63V, CM, , RBT, 7.5X 8 C311, C313, C320, C321, C327, C330, C334, C336
CA-510016-GP 1U, 10%, 25V, CC, 0805, 1 C314
CA-510017-GP 1UF, 20 PCNT, 50V, CC, SMT, 1210 2 C24, C25
CA-610009-GP CE 35V 10UF 20% RL 5 X 11 1 C35
CA-622010-GP 22UF, 20%, 35V, CE, , RLT, 5x11 1 C36
CA-647006-GP CE 16NP 47UF 20% RL 6 C1, C20, C308, C326, C337, C37
CA-710014-GP 100U, 20%, 25V, CE, , RLT, 6X11 1 C315
CA-722007-GP 220UF, 20 PCNT, 25V, CE, RL, 1 C318
CA-747009-GP 470UF, 20%, 16V, CE, , RLT 2 C322, C323
CA-810007-GP 1000UF, 20%, 25V, CE, , RLT 2 C18, C19
CA-868002-GP 6800UF, 20 PCNT, 63V, CE, RL, 4 C13, C14, C15, C16
CH-000173-GP COVER, XFMR, STEEL, LARGE 1
CH-000489-GP PLATE-SPRING STEEL, , , , 5
CH-000490-GP HEATSINK, 381X189.2X38.1, , HPR, 1
CH-000547-GP PANEL, INPUT, , HPR153i, 1
CH-000550-GP PANEL, AC, , HPRi, 1
CO-000058-GP XLR, CONNECTOR, 3PM, , , 1 J301
CO-000204-GP CONN XLR F VERT PLASTIC 1 J302
CO-000211-GP AC INLET 250V 15A 1
CO-000213-GP CONN 2 PIN STRAIGHT WAFER 1 J304A
CO-000214-GP CONN 3 PIN STRAIGHT WAFER 1 J3
CO-000347-GP TERMINAL BLOCK, 5MM, 5POS(1X5), FEMALE, RIGHT ANGLE 1 J2
CO-000348-GP TERMINAL BLOCK, 5MM, 6POS (1X6), FEMALE, RIGHT ANGLE 1 J4
CO-000349-GP WIRE HOLDER, RIBBON CABLE, 10 POS, FEMALE, 3 J303, J305B, J306
CO-000350-GP WIRE TRAP, RIBBON CABLE, 10 POS, FEMALE, RELEASEABLE 3 J305A, J5, J6
HW-000075-GP FUSE HOLDER, , , , , 3 F1, F2, F3
HW-000102-GP BRASS POST, D6X10, , , , 3
IC-000075-GP IC VOLTAGE REG, +5, LM78L05, SMT, 1 U310
IC-000076-GP IC LM339, SMD COMPARATORS, , , 1 U2
IC-000077-GP IC LM13700M, , , SMT, 1 U305
IC-000078-GP IC LM19, THERMAL SENSOR, , TO-92, 1 U4
IC-000079-GP IC MC33078, OP-AMP, , SMT, 4 U1, U302, U7, U8
IC-000377-GP IC 7805, REGULATOR, 5V, , 1 U3
IC-000378-GP IC LM7915CT, REGULATOR, -15V, , 1 U6
IC-000379-GP IC LM7815CT, REGULATOR, 15V, , 1 U5
IC-000380-GP IC TL072, OPAMP, DUAL, SO-8, 1 U301
IC-000381-GP IC TL074CD-SO14, OPAMP, QUAD, SO-14, 7 U303, U304, U306, U307, U308, U309, U311
LB-000627-GP LABEL, WARNING, TOP BOX, HPRi, 1
MS-000070-GP 2.5A, FAST ACT 5X20, , , 2 F2, F3
MS-000073-GP FUSE, FAST, ACTING 5A, SMT, 1206, 2 F4, F5
MS-000292-GP FUSE, 6.3A, 5 X 20MM, FAST, 1 F1
NW-000070-GP M3, NUT, , , , 3
NW-000072-GP NUT, HEX, M4, , 1
NW-040002-GP SPRING WASHER M4 X 7 1
NW-040003-GP I/T WASHER M4X0.4X8, YZ 1
PC-122001-00 PCB, MAIN, HPR122i, , , 1
PC-122002-00 PCB, INPUT, HPR151i, , , 1
PL-000066-GP EVA GASKET, 5X500, , , , 3
PL-000152-GP CABLE TIE, ISA 4
PL-000327-GP PAD, XFMR, EPDM 40A, 1/8" THK, BLACK, 2
PL-000391-GP KNOB, GAIN, HPR SERIES, , , 1
PL-000454-GP INSULATION SHEET IC, , , SILPAD 800, , 5
PL-000455-GP LED HOLDER, LED3-11, , , , 3 LD301-1, LD302-1, LD303-1
PL-000456-GP SPRINGSEAT, TRANSISTOR, HPR, NYLON, , 5
PL-000457-GP SPACER, L=4.0, ELM 3, , , 1 U4
PL-000458-GP SPONGE CUSHION, , , , , 2
PT-110002-GP TRIM, 100, 20 PCNT, 0.15W, , 3 VR1, VR2, VR3
PT-250003-GP VR 5K, XVB12111YNPVB25F, , , , 1 VR301
QD-000201-GP DIODE LL4148 SM 15 D10, D11, D12, D20, D24, D25, D27, D30, D301, D302, D303, D304, D305, D38, D8
QD-000204-GP XISTOR NPN 60V 200MA 3904 SOT-23 23 Q11, Q16, Q2, Q24, Q25, Q28, Q3, Q301, Q309, Q310, Q311, Q312, Q313, Q314, Q315, Q33, Q37, Q38, Q41, Q42, Q45, Q50, Q6
Page 7
WP-153001-02 230V Rev. A
Part Number Description Qty Ref Des
QD-000205-GP XISTOR PNP 40V 0.2A TR3906 SOT-23 20 Q1, Q10, Q17, Q19, Q23, Q29, Q302, Q303, Q304, Q305, Q306, Q307, Q308, Q32, Q36, Q39, Q40, Q46, Q49, Q7
QD-000206-GP DIOD RECT FAST, IN4934 AT 12 D1, D2, D22, D23, D28, D29, D32, D33, D34, D35, D4, D5
QD-000208-GP XISTOR PNP 230V 15A 2SA1943 4 Q12, Q14, Q34, Q51
QD-000209-GP XISTOR NPN 230V 15A 2SC5200 4 Q13, Q15, Q35, Q52
QD-000227-GP BRIDGE RECT 400V 25A 2 BR1, BR2
QD-000260-GP MOSFET, N-CH, 60V, 52A, 52N06V 2 Q21, Q22
QD-000300-GP LED SC, 2.9 X 5.4 XL 0.5 BL, , , , , 1 LD302
QD-000301-GP LED, 3MM, GREEN SP, , , , 1 LD303
QD-000302-GP LED SP, 2.9 X 5.4 XL 0.5 RED, , , , , 1 LD301
QD-000303-GP DIODE, BAV21WS 250V, , , , , 5 D21, D3, D31, D6, D9
QD-000304-GP DIODE, MUR810 RL 8A, , , , , 2 D13, D15
QD-000305-GP DZ 1/2W, 6.2VB RLZ6.2B, , , , SMT, 2 D14, D7
QD-000306-GP DZ 1/2W, 7.5VB RLZ7.5B LL, , , , SMT, 1 D26
QD-000307-GP SMD DIODE, ISR154-400, , , , , 6 D16, D17, D18, D19, D36, D37
QD-000308-GP TR MMBTA42 NPN SMD, , , , , SOT-23, 4 Q20, Q27, Q44, Q5
QD-000309-GP TR 2SA1837, 100-320 RL, , , , , 3 Q26, Q4, Q43
QD-000310-GP TR 2SC4793, 100-320-RL, , , , , 3 Q31, Q48, Q9
QD-000311-GP TR MMBTA92 SOT 23 KEC, , , , , , 4 Q18, Q30, Q47, Q8
RE-.01002-GP 0.1R, 5 PCNT, 2W, RMF, ATS METAL, 12 R115, R116, R117, R25, R26, R27, R28, R29, R30, R74, R75, R78
RE-.47006-GP RMF, 1W, 4R7, 5%, AT, 3 R49, R6, R88
RE-000003-GP RMG 1/10W 0 OHM 5% 0805 17 R123, R124, R125, R358, R362, R368, R384, R389, R392, R393, R400, R401, R405, R406, R423, R433, R434
RE-001009-GP 10 1% 1/8W THK FLM 1206 2 R337, R338
RE-001012-GP 10OHM, 1/4W, 1%, AT, RMF, 2 R126, R127
RE-001013-GP 10, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R128
RE-004753-GP RMG 1/10W 47.5 OHM 1% 0805 13 R109, R110, R111, R112, R113, R21, R22, R23, R24, R67, R68, R71, R72
RE-010011-GP 100 1% 1/10W THK FLM 0805 100V 17 R103, R104, R107, R108, R14, R15, R19, R20, R301, R302, R307, R317, R318, R60, R61, R64, R65
RE-018001-GP 180R, 1 PCNT, 1/10W, RMG, 0805, 2 R449, R8
RE-020003-GP 200 1% 1/10W THK FLM 0805 100V 1 R93
RE-030006-GP 300 OHM, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R51
RE-040200-GP 402R, 1 PCNT, 1/10W, RMG, 0805, 2 R436, R95
RE-047012-GP 470, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R77
RE-063405-GP 634 OHMS 1% 1/10W 0805 1 R319
RE-091002-GP 910R, 1 PCNT, 1/10W, RMG, 0805, 14 R100, R101, R105, R106, R11, R12, R17, R18, R54, R57, R58, R62, R63, R9
RE-110702-GP 1.07K, 1 PCNT, 1/10W, RMG, 0805, 2 R327, R331
RE-115008-GP 1.5K, 1 PCNT, 1/10W, THK FLM, 0805, 100V 2 R414, R440
RE-120004-GP RMG 1/10W 2K 1% 0805 1 R343
RE-122010-GP 2.2K 1% 1/10W THK FM 0805 100V 3 R102, R16, R59
RE-124001-GP 2.4K, 1 PCNT, 1/10W, RMG, 0805, 4 R2, R35, R44, R81
RE-127001-GP 2.7K, 1 PCNT, 1/10W, RMG, 0805, 1 R313
RE-130006-GP 3K, 1 PCNT, 1/10W, THICK FILM, 0805, 3 R381, R383, R402
RE-130103-GP RMG 1/10W 3.01K 1% 0805 1 R33
RE-133008-GP 3.3K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R435
RE-136003-GP 3.6K, 1 PCNT, 1/10W, RMG, 0805, 3 R361, R373, R443
RE-139006-GP 3.9K, 1 PCNT, 1/10W, THICK FILM, 0805, 3 R396, R411, R424
RE-143001-GP 4.3K, 1 PCNT, 1/10W, RMG, 0805, 1 R378
RE-143202-GP 4.32K, 1 PCNT, 1/10W, RMG, 0805, 1 R316
RE-147002-GP 4.7K 1% 1/10W THK FLM 0805 11 R334, R366, R39, R394, R408, R412, R445, R56, R66, R79, R97
RE-147506-GP 4.75K, 1 PCNT, 1/10W, THICK FILM, 0805, 2 R328, R332
RE-151006-GP 5.1K, 1 PCNT, 1/10W, THICK FILM, 0805, 5 R321, R339, R377, R451, R452
RE-152302-GP 5.23K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R303
RE-156004-GP 5.6K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R335
RE-159003-GP 5.9K 1% 1/10W THK FLM 0805 2 R96, R98
RE-162001-GP 6.2K, 1 PCNT, 1/10W, RMG, 0805, 1 R352
RE-164901-GP 6.49K, 1 PCNT, 1/10W, RMG, 0805, 1 R48
RE-168007-GP 6.8K, 1 PCNT, 1/10W, RMG, 0805, 1 R344
RE-169802-GP 6.98K, 1 PCNT, 1/10W, THK FLM, 0805, 100V 1 R312
RE-175004-GP 7.5K 1% 1/10W THK FM 0805 100V 4 R348, R354, R390, R397
RE-182007-GP 8.2K, 1 PCNT, 1/10W, THICK FILM, 0805, 4 R326, R330, R341, R418
RE-191001-GP 9.1K, 1 PCNT, 1/10W, RMG, 0805, 1 R357
RE-210007-GP 10K 1% 1/10W THK FLM 0805 20 R1, R122, R3, R320, R329, R333, R336, R340, R353, R386, R415, R419, R43, R437, R439, R45, R50, R7, R80, R85
RE-211305-GP 11.3K .1% 1/10W RMG 0805 4 R304, R305, R309, R310
RE-212003-GP 12K 1% 1/10W THK FLM 0805 100V 3 R359, R380, R447
RE-212004-GP 12K, 1 PCNT, 1/8W, THICK FILM, 1206, 1 R448
RE-212105-GP 12.1K, 1 PCNT, 1/10W, RMG, 0805, 1 R441
RE-213005-GP 13K, 1 PCNT, 1/10W, RMG, 0805, 3 R36, R89, R90
RE-215003-GP 15K, 1 PCNT, 1/10W, RMG, 0805, 5 R347, R376, R410, R431, R442
RE-216001-GP 16K, 1 PCNT, 1/10W, RMG, 0805, 1 R342
RE-218006-GP 18K, 1 PCNT, 1/10W, THICK FILM, 0805, 4 R346, R372, R417, R91
RE-218702-GP 18.7K, 1 PCNT, 1/10W, THICK FILM, 0805, 2 R308, R311
RE-220005-GP RMG 1/10W 20K 1% 0805 3 R407, R46, R86
RE-220006-GP 20K, 1 PCNT, 1/10W, THICK FILM, 1206, 1 R38
RE-222001-GP 22K 1% 1/10W 0805 9 R32, R34, R37, R375, R391, R413, R421, R422, R446
RE-224001-GP 24.0K 1% 1/10W THK FLM 0805 2 R314, R453
RE-227001-GP 27K 1% 1/10W 0805 3 R349, R426, R429
RE-230006-GP 30K, 1 PCNT, 1/10W, THICK FILM, 0805, 4 R345, R351, R4, R428
RE-230104-GP 30.1K 1% 1/8W RMG 1206 4 R40, R47, R5, R87
RE-230105-GP 30.1K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R53
RE-236001-GP 36K, 1 PCNT, 1/10W, RMG, 0805, 2 R355, R385
RE-239003-GP 39K, 1 PCNT, 1/10W, MET FLM, 0805, 100V 2 R323, R450
RE-239204-GP 39.2K, 1 PCNT, 1/10W, THICK FILM, 0805, 3 R315, R325, R356
RE-247006-GP 47K 1% 1/10W THK FLM 0805 100V 3 R430, R69, R76
RE-291001-GP 91K, 1 PCNT, 1/10W, RMG, 0805, 3 R367, R388, R427
RE-310007-GP 100K 1% 1/10W THK FLM 0805 5 R306, R350, R364, R370, R438
RE-310008-GP 100K 1% 1/8W THK FLM 1206 6 R10, R31, R52, R83, R92, R94
RE-312006-GP 120K 1% 1/10W RMG 0805 2 R374, R404
RE-315006-GP 150K, 1 PCNT, 1/10W, THICK FILM, 0805, 5 R324, R363, R369, R399, R409
Page 8
WP-153001-02 230V Rev. A
Part Number Description Qty Ref Des
RE-320006-GP 200K, 1 PCNT, 1/10W, THICK FILM, 0805, 2 R322, R454
RE-349901-GP 499K 1% 1/8W THICK FILM 1206 1 R82
RE-410003-GP 1M 1% 1/10W RMG 0805 4 R13, R55, R84, R99
SC-000081-GP T3X8MM, SELF TAPPING, , , , 2
SC-000082-GP SCREW, BIND, HEAD, M3.2 X 8, , B-TITE, 6
SC-000083-GP SCREW, BIND, HEAD, M3.5 X 16, , B-TITE, 10
SC-000084-GP SCREW, BIND, SERRATED HEAD, M4X25, B-TITE, 4
SC-000085-GP SELF SCREW, 3X8, WITH, SERRATED HEAD, , , 2
SC-000086-GP SCREW, M8X101.5, BZ, , , , 1
SC-030002-GP M3 B-TITE FLAT-CS 2
SC-030004-GP M3 X 8 BLK MACHINE 6
SC-040001-GP SCREW M4-18 X 10MM, BLK ZN 2
SW-000088-GP ROCKER POWER SWITCH 1
SW-000119-GP CIRCUIT BREAKER, 3A, 230V, HPR, 1
SW-000122-GP SWITCH, 1P2T, , 1 SW302
SW-000123-GP SWITCH, 2P2T, , 1 SW301
WC-000188-GP SLEEVE, PVC, 5MM ID, BLK 0
WC-000410-GP UL1672, AWG#18, BROWN, , , , , 0
WC-000411-GP UL1672, AWG#18, BLUE, , , , , 0
WC-000412-GP GRND WIRE, UL1015 #14, , , , , 1
WC-000413-GP WIRE-FLAT, 10P P1.5 #26, , , , , 3 J303, J305B, J306
WC-000423-GP SHRINKAGE TUBE, ID=6MM, UL, , , , , 0
XF-000294-GP POWER TRANSFORMER, 230V, , , , HPR SERIES, , 1
Loading...
