WP-151001-00 120V Rev. A
Part Number Description Qty Ref Des
CA-015005-GP 15PF, 5 PCNT, 50V, CERAMIC, 0805, 5 C48, C544, C545, C546, C547
CA-033003-GP 33PF, 5%, 50V, CC, 0805, 1.2X 2 C11, C12
CA-110005-GP CC 50V 100PF 5% 0805 1.2 1 C548
CA-110007-GP 100P, 5%, 100V, CTC, 0805, 0/30 1 C49
CA-122005-GP CC 50V 220PF 5% 0805 3 C45, C522, C6
CA-147006-GP 470PF 5% 50V CER NPO 4 C501, C502, C503, C504
CA-233009-GP 3300P, 5%, 100V, CTC, 1206, 0/30 1 C4
CA-368006-GP .068UF, 5 PCNT, 50V, FILM, , 1 C538
CA-410014-GP 0.1UF 10% 50V CER X7R 0805 15 C17, C22, C27, C34, C50, C523, C526, C528, C531, C532, C534, C535, C539, C540, C7
CA-410018-GP CM 250V .1UF 5% RL 2 C8, C9
CA-410023-GP 0.1UF, 5%, 63V, CM, , RBT, 7.5X6 1 C533
CA-415006-GP .15UF, 5 PCNT, 200V, CC, 1210, 1 C2
CA-422010-GP 0.22U, 10%, 50V, CC, 0805, 2 C10, C30
CA-422011-GP 0.22U, 5%, 63V, CM, , RBT, 7.5X 14 C505, C506, C507, C508, C509, C510, C511, C512, C513, C514, C515, C516, C529, C536
CA-510017-GP 1UF, 20 PCNT, 50V, CC, SMT, 1210 2 C24, C25
CA-610009-GP CE 35V 10UF 20% RL 5 X 11 1 C35
CA-622010-GP 22UF, 20%, 35V, CE, , RLT, 5x11 1 C36
CA-647006-GP CE 16NP 47UF 20% RL 4 C1, C520, C527, C537
CA-710013-GP 100U, 20%, 25V, CE, , 5X11, RLT 1 C530
CA-747009-GP 470UF, 20%, 16V, CE, , RLT 2 C542, C543
CA-810007-GP 1000UF, 20%, 25V, CE, , RLT 2 C18, C19
CA-912001-GP 12000UF, 20 PCNT, 63V, CE, RL, , 4 C13, C14, C15, C16
CH-000173-GP COVER, XFMR, STEEL, LARGE 1
CH-000489-GP PLATE-SPRING STEEL, , , , 5
CH-000490-GP HEATSINK, 381X189.2X38.1, , HPR, 1
CH-000548-GP PANEL, INPUT, , HPR151i, 1
CH-000550-GP PANEL, AC, , HPRi, 1
CO-000058-GP XLR, CONNECTOR, 3PM, , , 4 J501, J502, J505, J506
CO-000204-GP CONN XLR F VERT PLASTIC 2 J503, J504
CO-000211-GP AC INLET 250V 15A 1
CO-000213-GP CONN 2 PIN STRAIGHT WAFER 1 J509A
CO-000214-GP CONN 3 PIN STRAIGHT WAFER 1 J3
CO-000347-GP TERMINAL BLOCK, 5MM, 5POS(1X5), FEMALE, RIGHT ANGLE 1 J2
CO-000349-GP WIRE HOLDER, RIBBON CABLE, 10 POS, FEMALE, 3 J507, J508B, J510
CO-000350-GP WIRE TRAP, RIBBON CABLE, 10 POS, FEMALE, RELEASEABLE 3 J5, J508A, J6
CO-000352-GP TERMINAL BLOCK, 5MM, 2POS (1X2), FEMALE, RIGHT 1 J4
HW-000075-GP FUSE HOLDER, , , , , 2 F1
HW-000102-GP BRASS POST, D6X10, , , , 3
IC-000075-GP IC VOLTAGE REG, +5, LM78L05, SMT, 1 U509
IC-000076-GP IC LM339, SMD COMPARATORS, , , 1 U2
IC-000077-GP IC LM13700M, , , SMT, 1 U506
IC-000078-GP IC LM19, THERMAL SENSOR, , TO-92, 1 U4
IC-000079-GP IC MC33078, OP-AMP, , SMT, 2 U1, U502
IC-000377-GP IC 7805, REGULATOR, 5V, , 1 U3
IC-000378-GP IC LM7915CT, REGULATOR, -15V, , 1 U6
IC-000379-GP IC LM7815CT, REGULATOR, 15V, , 1 U5
IC-000380-GP IC TL072, OPAMP, DUAL, SO-8, 4 U501, U504, U505, U508
IC-000381-GP IC TL074CD-SO14, OPAMP, QUAD, SO-14, 2 U503, U507
LB-000530-GP PC INLAY, WARNING LABEL, , , 1
MS-000073-GP FUSE, FAST, ACTING 5A, SMT, 1206, 2 F4, F5
MS-000293-GP 10A FUSE, QUICK-ACTING, , , 1 F1
NW-000070-GP M3, NUT, , , , 3
NW-000072-GP NUT, HEX, M4, , 1
NW-040002-GP SPRING WASHER M4 X 7 1
NW-040003-GP I/T WASHER M4X0.4X8, YZ 1
PC-122001-00 PCB, MAIN, HPR122i, , , 1
PC-151002-00 PCB, INPUT, HPR151i, , , 1
PL-000066-GP EVA GASKET, 5X500, , , , 3
PL-000152-GP CABLE TIE, ISA 4
PL-000327-GP PAD, XFMR, EPDM 40A, 1/8" THK, BLACK, 2
PL-000391-GP KNOB, GAIN, HPR SERIES, , , 1
PL-000454-GP INSULATION SHEET IC, , , SILPAD 800, , 5
PL-000455-GP LED HOLDER, LED3-11, , , , 3 LD501-1, LD502-1, LD503-1
PL-000456-GP SPRINGSEAT, TRANSISTOR, HPR, NYLON, , 5
PL-000457-GP SPACER, L=4.0, ELM 3, , , 1 U4
PL-000458-GP SPONGE CUSHION, , , , , 2
PT-110002-GP TRIM, 100, 20 PCNT, 0.15W, , 1 VR1
PT-250003-GP VR 5K, XVB12111YNPVB25F, , , , 1 VR501
QD-000201-GP DIODE LL4148 SM 19 D10, D11, D12, D20, D24, D25, D27, D30, D38, D501, D502, D503, D504, D505, D506, D507, D508, D509, D8
QD-000204-GP XISTOR NPN 60V 200MA 3904 SOT-23 11 Q11, Q16, Q2, Q3, Q37, Q38, Q503, Q504, Q505, Q507, Q6
QD-000205-GP XISTOR PNP 40V 0.2A TR3906 SOT-23 10 Q1, Q10, Q17, Q19, Q36, Q39, Q501, Q502, Q506, Q7
QD-000206-GP DIOD RECT FAST, IN4934 AT 4 D1, D2, D4, D5
QD-000208-GP XISTOR PNP 230V 15A 2SA1943 4 Q12, Q14, Q34, Q51
QD-000209-GP XISTOR NPN 230V 15A 2SC5200 4 Q13, Q15, Q35, Q52
QD-000227-GP BRIDGE RECT 400V 25A 2 BR1, BR2
QD-000260-GP MOSFET, N-CH, 60V, 52A, 52N06V 2 Q21, Q22
QD-000300-GP LED SC, 2.9 X 5.4 XL 0.5 BL, , , , , 1 LD502
QD-000301-GP LED, 3MM, GREEN SP, , , , 1 LD503
QD-000302-GP LED SP, 2.9 X 5.4 XL 0.5 RED, , , , , 1 LD501
QD-000303-GP DIODE, BAV21WS 250V, , , , , 3 D3, D6, D9
Page 4
WP-151001-00 120V Rev. A
Part Number Description Qty Ref Des
QD-000304-GP DIODE, MUR810 RL 8A, , , , , 2 D13, D15
QD-000305-GP DZ 1/2W, 6.2VB RLZ6.2B, , , , SMT, 2 D14, D7
QD-000306-GP DZ 1/2W, 7.5VB RLZ7.5B LL, , , , SMT, 1 D26
QD-000307-GP SMD DIODE, ISR154-400, , , , , 6 D16, D17, D18, D19, D36, D37
QD-000308-GP TR MMBTA42 NPN SMD, , , , , SOT-23, 2 Q20, Q5
QD-000309-GP TR 2SA1837, 100-320 RL, , , , , 1 Q4
QD-000310-GP TR 2SC4793, 100-320-RL, , , , , 1 Q9
QD-000311-GP TR MMBTA92 SOT 23 KEC, , , , , , 2 Q18, Q8
RE-.01002-GP 0.1R, 5 PCNT, 2W, RMF, ATS METAL, 12 R111, R114, R25, R26, R27, R28, R29, R30, R41, R42, R70, R73
RE-.82001-GP 8.2 OHM, 1W, 5 PCNT, AT, RMF, 1 R6
RE-000003-GP RMG 1/10W 0 OHM 5% 0805 4 R539, R544, R545, R564
RE-001009-GP 10 1% 1/8W THK FLM 1206 2 R584, R585
RE-001012-GP 10OHM, 1/4W, 1%, AT, RMF, 2 R126, R127
RE-001013-GP 10, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R128
RE-004753-GP RMG 1/10W 47.5 OHM 1% 0805 4 R21, R22, R23, R24
RE-010011-GP 100 1% 1/10W THK FLM 0805 100V 13 R14, R15, R19, R20, R502, R503, R504, R505, R537, R538, R558, R559, R576
RE-015008-GP 150, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R587
RE-033001-GP 330 OHM, 1 PCNT, 1/10W, RMG, 0805, 2 R531, R532
RE-034801-GP 348R, 1 PCNT, 1/10W, RMG, 0805, 1 R8
RE-047012-GP 470, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R77
RE-063405-GP 634 OHMS 1% 1/10W 0805 1 R567
RE-091002-GP 910R, 1 PCNT, 1/10W, RMG, 0805, 6 R11, R12, R123, R17, R18, R9
RE-111801-GP 1.18K, 1 PCNT, 1/10W, RMG, 0805, 2 R575, R578
RE-112001-GP RMG 1/10W 1.2K 1% 0805 3 R510, R516, R517
RE-115008-GP 1.5K, 1 PCNT, 1/10W, THK FLM, 0805, 100V 1 R543
RE-120004-GP RMG 1/10W 2K 1% 0805 1 R566
RE-122010-GP 2.2K 1% 1/10W THK FM 0805 100V 1 R16
RE-124001-GP 2.4K, 1 PCNT, 1/10W, RMG, 0805, 2 R2, R35
RE-130103-GP RMG 1/10W 3.01K 1% 0805 1 R33
RE-133008-GP 3.3K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R525
RE-143202-GP 4.32K, 1 PCNT, 1/10W, RMG, 0805, 1 R557
RE-145303-GP 4.53K, 1 PCNT, 1/10W, RMG, 0805, 1 R579
RE-147002-GP 4.7K 1% 1/10W THK FLM 0805 5 R39, R56, R66, R79, R97
RE-151006-GP 5.1K, 1 PCNT, 1/10W, THICK FILM, 0805, 6 R522, R523, R528, R529, R588, R589
RE-152302-GP 5.23K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R573
RE-159003-GP 5.9K 1% 1/10W THK FLM 0805 2 R96, R98
RE-162001-GP 6.2K, 1 PCNT, 1/10W, RMG, 0805, 1 R577
RE-164901-GP 6.49K, 1 PCNT, 1/10W, RMG, 0805, 1 R48
RE-169802-GP 6.98K, 1 PCNT, 1/10W, THK FLM, 0805, 100V 1 R546
RE-182007-GP 8.2K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R565
RE-210007-GP 10K 1% 1/10W THK FLM 0805 13 R1, R122, R3, R520, R521, R526, R527, R533, R549, R550, R553, R572, R582
RE-211305-GP 11.3K .1% 1/10W RMG 0805 8 R506, R507, R508, R509, R512, R513, R514, R515
RE-212003-GP 12K 1% 1/10W THK FLM 0805 100V 1 R7
RE-212004-GP 12K, 1 PCNT, 1/8W, THICK FILM, 1206, 1 R586
RE-212703-GP 12.7K, 1 PCNT, 1/10W, THICK FILM, 0805, 2 R501, R511
RE-213005-GP 13K, 1 PCNT, 1/10W, RMG, 0805, 3 R36, R89, R90
RE-215003-GP 15K, 1 PCNT, 1/10W, RMG, 0805, 3 R518, R568, R580
RE-218006-GP 18K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R519
RE-218702-GP 18.7K, 1 PCNT, 1/10W, THICK FILM, 0805, 2
RE-220006-GP 20K, 1 PCNT, 1/10W, THICK FILM, 1206, 1 R38
RE-222001-GP 22K 1% 1/10W 0805 3 R32, R34, R37
RE-226101-GP 26.1K, 1 PCNT, 1/10W, RMG, 0805, 1 R4
RE-230104-GP 30.1K 1% 1/8W RMG 1206 2 R40, R5
RE-230105-GP 30.1K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R53
RE-239204-GP 39.2K, 1 PCNT, 1/10W, THICK FILM, 0805, 3 R555, R570, R581
RE-247006-GP 47K 1% 1/10W THK FLM 0805 100V 5 R541, R554, R571, R69, R76
RE-268003-GP RMG 1/8W 68K 1% 1206 1 R524
RE-291001-GP 91K, 1 PCNT, 1/10W, RMG, 0805, 1 R583
RE-310007-GP 100K 1% 1/10W THK FLM 0805 2 R569, R574
RE-310008-GP 100K 1% 1/8W THK FLM 1206 4 R10, R31, R83, R92
RE-320006-GP 200K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R590
RE-349901-GP 499K 1% 1/8W THICK FILM 1206 1 R82
RE-410003-GP 1M 1% 1/10W RMG 0805 4 R13, R55, R84, R99
SC-000081-GP T3X8MM, SELF TAPPING, , , , 6
SC-000082-GP SCREW, BIND, HEAD, M3.2 X 8, , B-TITE, 6
SC-000083-GP SCREW, BIND, HEAD, M3.5 X 16, , B-TITE, 10
SC-000084-GP SCREW, BIND, SERRATED HEAD, M4X25, B-TITE, 4
SC-000085-GP SELF SCREW, 3X8, WITH, SERRATED HEAD, , , 6
SC-000086-GP SCREW, M8X101.5, BZ, , , , 1
SC-030002-GP M3 B-TITE FLAT-CS 2
SC-030004-GP M3 X 8 BLK MACHINE 5
SC-040001-GP SCREW M4-18 X 10MM, BLK ZN 2
SW-000088-GP ROCKER POWER SWITCH 1
SW-000093-GP CIRCUIT BREAKER, 5 AMP, , 1
SW-000122-GP SWITCH, 1P2T, , 1 SW502
SW-000123-GP SWITCH, 2P2T, , 1 SW501
WC-0.6023-GP 0.6 JUMPER 23AWG 1 C519
WC-000188-GP SLEEVE, PVC, 5MM ID, BLK 0
WC-000339-GP JUMPER, BARE, 18GA, SOLID, HPR, , 8 W1, W2, W3, W4, W5, W6, W7, W8
WC-000410-GP UL1672, AWG#18, BROWN, , , , , 0
Page 5
WP-151001-00 120V Rev. A
Part Number Description Qty Ref Des
WC-000411-GP UL1672, AWG#18, BLUE, , , , , 0
WC-000412-GP GRND WIRE, UL1015 #14, , , , , 1
WC-000413-GP WIRE-FLAT, 10P P1.5 #26, , , , , 3 J507, J508B, J510
WC-000423-GP SHRINKAGE TUBE, ID=6MM, UL, , , , , 0
XF-000293-GP POWER TRANSFORMER, 120V, , , , HPR SERIES, , 1
Page 6
WP-151001-02 230V Rev. A
Part Number Description Qty Ref Des
CA-647006-GP CE 16NP 47UF 20% RL 4 C1, C520, C527, C537
CA-810007-GP 1000UF, 20%, 25V, CE, , RLT 2 C18, C19
CA-610009-GP CE 35V 10UF 20% RL 5 X 11 1 C35
CA-622010-GP 22UF, 20%, 35V, CE, , RLT, 5x11 1 C36
PC-122001-00 PCB, MAIN, HPR122i, , , 1
CO-000214-GP CONN 3 PIN STRAIGHT WAFER 1 J3
CO-000350-GP WIRE TRAP, RIBBON CABLE, 10 POS, FEMALE, RELEASEABLE 3 J5, J508A, J6
IC-000377-GP IC 7805, REGULATOR, 5V, , 1 U3
IC-000378-GP IC LM7915CT, REGULATOR, -15V, , 1 U6
IC-000379-GP IC LM7815CT, REGULATOR, 15V, , 1 U5
IC-000078-GP IC LM19, THERMAL SENSOR, , TO-92, 1 U4
HW-000075-GP FUSE HOLDER, , , , , 2 F1
PL-000457-GP SPACER, L=4.0, ELM 3, , , 1 U4
PT-110002-GP TRIM, 100, 20 PCNT, 0.15W, , 1 VR1
QD-000304-GP DIODE, MUR810 RL 8A, , , , , 2 D13, D15
QD-000309-GP TR 2SA1837, 100-320 RL, , , , , 1 Q4
QD-000310-GP TR 2SC4793, 100-320-RL, , , , , 1 Q9
QD-000209-GP XISTOR NPN 230V 15A 2SC5200 4 Q13, Q15, Q35, Q52
QD-000208-GP XISTOR PNP 230V 15A 2SA1943 4 Q12, Q14, Q34, Q51
QD-000260-GP MOSFET, N-CH, 60V, 52A, 52N06V 2 Q21, Q22
MS-000293-GP 10A FUSE, QUICK-ACTING, , , 1 F1
CA-912001-GP 12000UF, 20 PCNT, 63V, CE, RL, , 4 C13, C14, C15, C16
RE-.82001-GP 8.2 OHM, 1W, 5 PCNT, AT, RMF, 1 R6
RE-.01002-GP 0.1R, 5 PCNT, 2W, RMF, ATS METAL, 12 R111, R114, R25, R26, R27, R28, R29, R30, R41, R42, R70, R73
QD-000206-GP DIOD RECT FAST, IN4934 AT 4 D1, D2, D4, D5
CA-410014-GP 0.1UF 10% 50V CER X7R 0805 15 C17, C22, C27, C34, C50, C523, C526, C528, C531, C532, C534, C535, C539, C540, C7
CA-510017-GP 1UF, 20 PCNT, 50V, CC, SMT, 1210 2 C24, C25
CA-015005-GP 15PF, 5 PCNT, 50V, CERAMIC, 0805, 5 C48, C544, C545, C546, C547
CA-122005-GP CC 50V 220PF 5% 0805 3 C45, C522, C6
CA-422010-GP 0.22U, 10%, 50V, CC, 0805, 2 C10, C30
CA-033003-GP 33PF, 5%, 50V, CC, 0805, 1.2X 2 C11, C12
CA-415006-GP .15UF, 5 PCNT, 200V, CC, 1210, 1 C2
CA-110007-GP 100P, 5%, 100V, CTC, 0805, 0/30 1 C49
CA-233009-GP 3300P, 5%, 100V, CTC, 1206, 0/30 1 C4
IC-000076-GP IC LM339, SMD COMPARATORS, , , 1 U2
IC-000079-GP IC MC33078, OP-AMP, , SMT, 2 U1, U502
RE-001013-GP 10, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R128
RE-010011-GP 100 1% 1/10W THK FLM 0805 100V 13 R14, R15, R19, R20, R502, R503, R504, R505, R537, R538, R558, R559, R576
RE-210007-GP 10K 1% 1/10W THK FLM 0805 13 R1, R122, R3, R520, R521, R526, R527, R533, R549, R550, R553, R572, R582
RE-410003-GP 1M 1% 1/10W RMG 0805 4 R13, R55, R84, R99
RE-212003-GP 12K 1% 1/10W THK FLM 0805 100V 1 R7
RE-213005-GP 13K, 1 PCNT, 1/10W, RMG, 0805, 3 R36, R89, R90
RE-122010-GP 2.2K 1% 1/10W THK FM 0805 100V 1 R16
RE-222001-GP 22K 1% 1/10W 0805 3 R32, R34, R37
RE-124001-GP 2.4K, 1 PCNT, 1/10W, RMG, 0805, 2 R2, R35
RE-226101-GP 26.1K, 1 PCNT, 1/10W, RMG, 0805, 1 R4
RE-130103-GP RMG 1/10W 3.01K 1% 0805 1 R33
RE-230105-GP 30.1K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R53
RE-230104-GP 30.1K 1% 1/8W RMG 1206 2 R40, R5
RE-034801-GP 348R, 1 PCNT, 1/10W, RMG, 0805, 1 R8
RE-047012-GP 470, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R77
RE-147002-GP 4.7K 1% 1/10W THK FLM 0805 5 R39, R56, R66, R79, R97
RE-247006-GP 47K 1% 1/10W THK FLM 0805 100V 5 R541, R554, R571, R69, R76
RE-004753-GP RMG 1/10W 47.5 OHM 1% 0805 4 R21, R22, R23, R24
RE-159003-GP 5.9K 1% 1/10W THK FLM 0805 2 R96, R98
RE-164901-GP 6.49K, 1 PCNT, 1/10W, RMG, 0805, 1 R48
RE-091002-GP 910R, 1 PCNT, 1/10W, RMG, 0805, 6 R11, R12, R123, R17, R18, R9
RE-310008-GP 100K 1% 1/8W THK FLM 1206 4 R10, R31, R83, R92
RE-212004-GP 12K, 1 PCNT, 1/8W, THICK FILM, 1206, 1 R586
RE-220006-GP 20K, 1 PCNT, 1/10W, THICK FILM, 1206, 1 R38
RE-349901-GP 499K 1% 1/8W THICK FILM 1206 1 R82
QD-000303-GP DIODE, BAV21WS 250V, , , , , 3 D3, D6, D9
QD-000201-GP DIODE LL4148 SM 19 D10, D11, D12, D20, D24, D25, D27, D30, D38, D501, D502, D503, D504, D505, D506, D507, D508, D509, D8
QD-000305-GP DZ 1/2W, 6.2VB RLZ6.2B, , , , SMT, 2 D14, D7
QD-000306-GP DZ 1/2W, 7.5VB RLZ7.5B LL, , , , SMT, 1 D26
QD-000307-GP SMD DIODE, ISR154-400, , , , , 6 D16, D17, D18, D19, D36, D37
QD-000205-GP XISTOR PNP 40V 0.2A TR3906 SOT-23 10 Q1, Q10, Q17, Q19, Q36, Q39, Q501, Q502, Q506, Q7
QD-000308-GP TR MMBTA42 NPN SMD, , , , , SOT-23, 2 Q20, Q5
QD-000204-GP XISTOR NPN 60V 200MA 3904 SOT-23 11 Q11, Q16, Q2, Q3, Q37, Q38, Q503, Q504, Q505, Q507, Q6
QD-000311-GP TR MMBTA92 SOT 23 KEC, , , , , , 2 Q18, Q8
MS-000073-GP FUSE, FAST, ACTING 5A, SMT, 1206, 2 F4, F5
PC-151002-00 PCB, INPUT, HPR151i, , , 1
CO-000349-GP WIRE HOLDER, RIBBON CABLE, 10 POS, FEMALE, 3 J507, J508B, J510
QD-000300-GP LED SC, 2.9 X 5.4 XL 0.5 BL, , , , , 1 LD502
QD-000301-GP LED, 3MM, GREEN SP, , , , 1 LD503
QD-000302-GP LED SP, 2.9 X 5.4 XL 0.5 RED, , , , , 1 LD501
PL-000455-GP LED HOLDER, LED3-11, , , , 3 LD501-1, LD502-1, LD503-1
SW-000122-GP SWITCH, 1P2T, , 1 SW502
Page 7
WP-151001-02 230V Rev. A
Part Number Description Qty Ref Des
SW-000123-GP SWITCH, 2P2T, , 1 SW501
WC-000413-GP WIRE-FLAT, 10P P1.5 #26, , , , , 3 J507, J508B, J510
RE-239204-GP 39.2K, 1 PCNT, 1/10W, THICK FILM, 0805, 3 R555, R570, R581
RE-151006-GP 5.1K, 1 PCNT, 1/10W, THICK FILM, 0805, 6 R522, R523, R528, R529, R588, R589
RE-291001-GP 91K, 1 PCNT, 1/10W, RMG, 0805, 1 R583
CA-410018-GP CM 250V .1UF 5% RL 2 C8, C9
QD-000227-GP BRIDGE RECT 400V 25A 2 BR1, BR2
RE-001012-GP 10OHM, 1/4W, 1%, AT, RMF, 2 R126, R127
CO-000213-GP CONN 2 PIN STRAIGHT WAFER 1 J509A
CO-000204-GP CONN XLR F VERT PLASTIC 2 J503, J504
CO-000058-GP XLR, CONNECTOR, 3PM, , , 4 J501, J502, J505, J506
PT-250003-GP VR 5K, XVB12111YNPVB25F, , , , 1 VR501
CA-410023-GP 0.1UF, 5%, 63V, CM, , RBT, 7.5X6 1 C533
CA-422011-GP 0.22U, 5%, 63V, CM, , RBT, 7.5X 14 C505, C506, C507, C508, C509, C510, C511, C512, C513, C514, C515, C516, C529, C536
CA-368006-GP .068UF, 5 PCNT, 50V, FILM, , 1 C538
CA-747009-GP 470UF, 20%, 16V, CE, , RLT 2 C542, C543
CA-710013-GP 100U, 20%, 25V, CE, , 5X11, RLT 1 C530
CA-110005-GP CC 50V 100PF 5% 0805 1.2 1 C548
CA-147006-GP 470PF 5% 50V CER NPO 4 C501, C502, C503, C504
IC-000380-GP IC TL072, OPAMP, DUAL, SO-8, 4 U501, U504, U505, U508
IC-000381-GP IC TL074CD-SO14, OPAMP, QUAD, SO-14, 2 U503, U507
IC-000075-GP IC VOLTAGE REG, +5, LM78L05, SMT, 1 U509
IC-000077-GP IC LM13700M, , , SMT, 1 U506
RE-000003-GP RMG 1/10W 0 OHM 5% 0805 4 R539, R544, R545, R564
RE-310007-GP 100K 1% 1/10W THK FLM 0805 2 R569, R574
RE-111801-GP 1.18K, 1 PCNT, 1/10W, RMG, 0805, 2 R575, R578
RE-112001-GP RMG 1/10W 1.2K 1% 0805 3 R510, R516, R517
RE-212703-GP 12.7K, 1 PCNT, 1/10W, THICK FILM, 0805, 2 R501, R511
RE-015008-GP 150, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R587
RE-115008-GP 1.5K, 1 PCNT, 1/10W, THK FLM, 0805, 100V 1 R543
RE-215003-GP 15K, 1 PCNT, 1/10W, RMG, 0805, 3 R518, R568, R580
RE-218006-GP 18K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R519
RE-218702-GP 18.7K, 1 PCNT, 1/10W, THICK FILM, 0805, 2
RE-120004-GP RMG 1/10W 2K 1% 0805 1 R566
RE-033001-GP 330 OHM, 1 PCNT, 1/10W, RMG, 0805, 2 R531, R532
RE-133008-GP 3.3K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R525
RE-143202-GP 4.32K, 1 PCNT, 1/10W, RMG, 0805, 1 R557
RE-145303-GP 4.53K, 1 PCNT, 1/10W, RMG, 0805, 1 R579
RE-152302-GP 5.23K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R573
RE-162001-GP 6.2K, 1 PCNT, 1/10W, RMG, 0805, 1 R577
RE-063405-GP 634 OHMS 1% 1/10W 0805 1 R567
RE-268003-GP RMG 1/8W 68K 1% 1206 1 R524
RE-169802-GP 6.98K, 1 PCNT, 1/10W, THK FLM, 0805, 100V 1 R546
RE-182007-GP 8.2K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R565
RE-001009-GP 10 1% 1/8W THK FLM 1206 2 R584, R585
RE-211305-GP 11.3K .1% 1/10W RMG 0805 8 R506, R507, R508, R509, R512, R513, R514, R515
CH-000550-GP PANEL, AC, , HPRi, 1
CH-000548-GP PANEL, INPUT, , HPR151i, 1
WC-000188-GP SLEEVE, PVC, 5MM ID, BLK 0
WC-000423-GP SHRINKAGE TUBE, ID=6MM, UL, , , , , 0
WC-000410-GP UL1672, AWG#18, BROWN, , , , , 0
WC-000411-GP UL1672, AWG#18, BLUE, , , , , 0
XF-000294-GP POWER TRANSFORMER, 230V, , , , HPR SERIES, , 1
CO-000211-GP AC INLET 250V 15A 1
PL-000391-GP KNOB, GAIN, HPR SERIES, , , 1
NW-040003-GP I/T WASHER M4X0.4X8, YZ 1
NW-040002-GP SPRING WASHER M4 X 7 1
NW-000070-GP M3, NUT, , , , 3
NW-000072-GP NUT, HEX, M4, , 1
SC-030004-GP M3 X 8 BLK MACHINE 5
SC-030002-GP M3 B-TITE FLAT-CS 2
SC-000081-GP T3X8MM, SELF TAPPING, , , , 6
SC-000082-GP SCREW, BIND, HEAD, M3.2 X 8, , B-TITE, 6
SC-000084-GP SCREW, BIND, SERRATED HEAD, M4X25, B-TITE, 4
SC-000085-GP SELF SCREW, 3X8, WITH, SERRATED HEAD, , , 6
SC-000086-GP SCREW, M8X101.5, BZ, , , , 1
PL-000454-GP INSULATION SHEET IC, , , SILPAD 800, , 5
CH-000173-GP COVER, XFMR, STEEL, LARGE 1
CH-000489-GP PLATE-SPRING STEEL, , , , 5
HW-000102-GP BRASS POST, D6X10, , , , 3
PL-000458-GP SPONGE CUSHION, , , , , 2
PL-000066-GP EVA GASKET, 5X500, , , , 3
PL-000456-GP SPRINGSEAT, TRANSISTOR, HPR, NYLON, , 5
LB-000530-GP PC INLAY, WARNING LABEL, , , 1
PL-000327-GP PAD, XFMR, EPDM 40A, 1/8" THK, BLACK, 2
SW-000119-GP CIRCUIT BREAKER, 3A, 230V, HPR, 1
SW-000088-GP ROCKER POWER SWITCH 1
CH-000490-GP HEATSINK, 381X189.2X38.1, , HPR, 1
Page 8
WP-151001-02 230V Rev. A
Part Number Description Qty Ref Des
PL-000152-GP CABLE TIE, ISA 4
WC-000412-GP GRND WIRE, UL1015 #14, , , , , 1
SC-000083-GP SCREW, BIND, HEAD, M3.5 X 16, , B-TITE, 10
WC-000339-GP JUMPER, BARE, 18GA, SOLID, HPR, , 8 W1, W2, W3, W4, W5, W6, W7, W8
WC-0.6023-GP 0.6 JUMPER 23AWG 1 C519
CO-000347-GP TERMINAL BLOCK, 5MM, 5POS(1X5), FEMALE, RIGHT ANGLE 1 J2
CO-000352-GP TERMINAL BLOCK, 5MM, 2POS (1X2), FEMALE, RIGHT 1 J4
RE-320006-GP 200K, 1 PCNT, 1/10W, THICK FILM, 0805, 1 R590
SC-040001-GP SCREW M4-18 X 10MM, BLK ZN 2
Loading...
