Q-Logic Fibre Channel Switch User Manual

QLogic

Fibre Channel Switch

Event Message Guide

Firmware Version 7.4

59060-05 A

QLogic Fibre Channel Switch Event Message Guide

Information furnished in this manual is believed to be accurate and reliable. However, QLogic Corporation assumes no responsibility for its use, nor for any infringements of patents or other rights of third parties which may result from its use. QLogic Corporation reserves the right to change product specifications at any time without notice. Applications described in this document for any of these products are for illustrative purposes only. QLogic Corporation makes no representation nor warranty that such applications are suitable for the specified use without further testing or modification. QLogic Corporation assumes no responsibility for any errors that may appear in this document.

QLogic, QuickTools, SANbox, SANblade, and Enterprise Fabric Suite 2007 are trademarks or registered trademarks of QLogic Corporation.

All other brand and product names are trademarks or registered trademarks of their respective owners.

S

Document Revision History

Release, Revision A, April 2008 Firmware version 7.4

QLogic Corporation, 26650 Aliso Viejo Parkway, Aliso Viejo, CA 92656, (800) 662-4471 or (949) 389-6000

Page ii 59060-05 A

First Published: April 2004

1 Introduction

This manual describes the alarm messages for QLogic Fibre Channel switches. This manual is organized as follows:

 Section 1 describes the intended audience, related materials, and technical

support.

 Section 2 describes event logging concepts, including definitions of severity

levels, how to configure the event log, how to display the event log, and how to download the event log from the switch.

 Section 3 describes the message format and lists the messages.

Intended Audience

This manual is for Storage Area Network (SAN) administrators to provide a reference for switch alarm messages, their meanings, and follow up actions.

Related Materials

The Fibre Channel Standards are available from:

Global Engineering Documents 15 Inverness Way East Englewood, CO 80112-5776

Phone: (800) 854-7179 or (303) 397-7956 Fax: (303) 397-2740

59060-05 A 1-1

1 – Introduction Technical Support

Technical Support

Customers should contact their authorized maintenance provider for technical support of their QLogic switch products. QLogic-direct customers may contact QLogic Technical Support; others will be redirected to their authorized maintenance provider.

Visit the QLogic support Web site listed in Contact Information for the latest firmware and software updates.

Availability

QLogic Technical Support for products under warranty is available during local standard working hours excluding QLogic Observed Holidays.

Training

QLogic offers certification training for the technical professional for both the SANblade™ HBAs and the QLogic switches. From the training link at

www.qlogic.com

intensive "hands-on" Certification course.

, you may choose Electronic-Based Training or schedule an

S

Technical Certification courses include installation, maintenance and troubleshooting QLogic SAN products. Upon demonstrating knowledge using live equipment, QLogic awards a certificate identifying the student as a Certified Professional. The training professionals at QLogic may be reached by email at tech.training@qlogic.com.

1-2 59060-05 A

A

Contact Information

Support Headquarters QLogic Corporation

QLogic Web Site www.qlogic.com Technical Support Web Site http://support.qlogic.com Technical Support Email support@qlogic.com Technical Training Email tech.training@qlogic.com

Email support@qlogic.com Phone +1-952-932-4040

1 – Introduction

Technical Support

4601 Dean Lakes Boulevard Shakopee, MN 55379 USA

North American Region

Europe, Middle East, and Africa Region

Email emeasupport@qlogic.com Phone Numbers by Language +353 1 6924960 - English

+353 1 6924961 - Français +353 1 6924962 - Deutsch +353 1 6924963 - Español +353 1 6924964 - Português +353 1 6924965 - Italiano

Asia Pacific Region

Email apacsupport@qlogic.com Phone Numbers by Language +63-2-885-6712 - English

+63-2-885-6713 - (Mandarin) +63-2-885-6714 - (Japanese) +63-2-885-6715 - (Korean)

Latin and South America Region

Email calasupport@qlogic.com Phone Numbers by Language +52 55 5278 7016 - English

+52 55 5278 7017 - Español +52 55 5278 7015 - Português

59060-05 A 1-3

1 – Introduction Technical Support

S

Notes

1-4 59060-05 A

2 Events and Event Logging

Messages originate from the switch, from Enterprise Fabric Suite 2007, or from the QuickTools web applet in response to events that occur in the fabric. This chapter describes the following topics:

 Understanding Severity Levels  Displaying Events using the Event Browser  Displaying the Events Using the Command Line Interface  Configuring the Event Log  Archiving and Downloading the Event Log  Configuring Port Alarm Thresholds

Understanding Severity Levels

Events are classified by the following severity levels:

Table 2-1. Event Serverity Levels

Severity Level Description

Fault Describes events that may require assistance from your autho-

rized maintenance provider . Each fault event has a correspond ing alarm message.

Alarm Describes events that are disruptive to the administration or oper-

ation of a fabric and require administrator intervention. Alarms are always logged and always displayed on the screen. Alarm thresholds can be defined for certain port er rors, allowin g you to custo mize the point at which an alarm will be generated.

Critical Describes events that are generally disruptive to the administra-

tion or operation of the fabric, but require no action.

Warning Describes events that are generally not disruptive to the adminis-

tration or operation of the fabric, but are mo re imp or tant than the informative level events.

Informative Describes routine events associated with a normal fabric.

59060-05 A 2-1

2 – Events and Event Logging Displaying Events using the Event Browser

Displaying Events using the Event Browser

Both Enterprise Fabric Suite 2007 and QuickTools have an event browser that displays a list of events generated by the switches in the fabric and by the applications themselves. Event browser messages are permanently discarded when you close an Enterprise Fabric Suite 2007 or QuickTools session; however, you can save these events to a file on the workstation before you close the session and read the file later with a text editor or browser.

The information in the event browsers is presented in the following order: seve rity, time, source, type, and description of the event. The maximum number of entries allowed on a switch is 1,200. Both the Enterprise Fabric Suite 2007 and QuickTools event browser can contain a maximum of 10,000 event messages. Once the maximum is reached, the event list wraps, and the oldest events in the event list are deleted.

Event browser entries from the switch use the switch time stamp. Event browser entries from Enterprise Fabric Suite 2007 and QuickTools use the management station and workstation time stamps, respectively. You can filter and sort the contents of both event browsers.

S

The Event Browser begins recording when enabled and Enterprise Fabric Suite 2007 or QuickTools is running. If the Event Browser is enabled using the Preferences dialog, the next time Enterprise Fabric Suite 2007 or QuickTools is started, all events from the switch log will be displayed. If the Event Browser is disabled when Enterprise Fabric Suite 2007 or QuickTools is started and later enabled, only those events from the time the Event Browser was enabled and forward will be displayed.

Displaying the Events Using the Command Line Interface

When you log into a switch through Telnet, the command line interface automatically displays the alarm history. You can use the Show Alarm or Show Log command to display the alarm history at any time. New alarm messages are displayed in the command stream as they occur.

2-2 59060-05 A

A

2 – Events and Event Logging

Displaying the Events Using the Command Line Interface

In the CLI, each message has the following format:

[ordinal][time_stamp][severity][source][message_ID][message_text]

Table 2-2. Event Log Message Format

Component Description

[ordinal] A number assigned to each message in sequence since that last

time the alarm history was cleared.

[time_stamp] The time the alarm was issued in the format

day-month-hh:mm:ss:ms-yyyy. This time stamp comes from the switch for events that originate with the switch, and from the workstation for events that originate from Enterprise Fabric Suite

2007.

[severity] The event severity: A–Alarm, C–Critical, W–Warning, I–Informa-

tive.

[source] The program module or application that generated the event.

Sources include Zoning, Switch, PortApp, EPort, Management Server. Alarms do not include the source.

[message_ID] A number that identifies the message using the following format:

category.message_number

[message_text] The alarm message text

Here is a sample of an informative-level message from the Switch source:

[1][Wed May 26 12:30:29.965 UTC 2004][I][8400.0022][Switch][Successful login user (snmp@IB-session6) with admin privilege]

For more information about the CLI commands, refer to the Command Line Interface Guide for your switch.

59060-05 A 2-3

2 – Events and Event Logging Configuring the Event Log

Configuring the Event Log

You can customize what events are recorded in the switch event log using the Set Log command. With the Set Log command, you can filter the events to be recorded by component, specific ports, and severity level. You can choose from the following component events:

 E_Port events  Management server events  Name server events  Port events  Switch management events  Simple Network Management Protocol (SNMP) events  Zoning events

For more information about the CLI commands, refer to the Command Line Interface Guide for your switch.

S

Archiving and Downloading the Event Log

You can use the CLI to create a file on the switch that contains the most recent 1200 entries. This file can then be downloaded to the workstation using FTP. To create and download a log file, do the following:

1. Log into the switch through Telnet and create an archive of the event log using the Set Log Archive command.

SANbox #> admin start SANbox (admin) #> set log archive

This creates a file on the switch named logfile.

2. Open an FTP session on the switch and login with the account name images and password images. Transfer the file logfile in binary mode with the Get command.

>ftp ip_address user:images password: images

ftp>bin ftp>get logfile xxxxx bytes sent in xx secs. ftp>quit

2-4 59060-05 A

A

Configuring Port Alarm Thresholds

You can configure the switch to generate alarms for selected events. Configuring an alarm involves choosing an event type, rising and falling triggers, a sample window, and finally enabling or disabling the alarm. You can configure port alarm thresholds for the following port events using Enterprise Fabric Suite 2007 or the CLI:

 Cyclic Redundancy Check (CRC) errors  Decode errors  Inter-switch Link (ISL) connections  Device logins  Device logouts  Loss-of-signal errors

To configure port threshold alarms using Enterprise Fabric Suite 2007, do the following:

2 – Events and Event Logging

1. Open the Switch menu in the faceplate display, and select Port Threshold

Alarm Configuration.

2. The Port Threshold Alarm Configuration dialog prompts you to enable or disable all alarms, select an event, set triggers, set a sample window and enable or disable an individual alarm. For more information, refer to the Enterprise Fabric Suite 2007 User Guide for your switch.

To configure port threshold alarms using the command line interface, use the Set Config Threshold command. For more information, refer to the Command Line Interface Guide for your switch.

59060-05 A 2-5

2 – Events and Event Logging Configuring Port Alarm Thresholds

Notes

S

2-6 59060-05 A

3 Event Messages

This section lists event messages from the command line interface and Enterprise Fabric Suite 2007 in message ID sequence by the following severity levels:

 Fault Events  Alarm Events  Critical Events  Warning Events  Informative Events

You can look up a message by its message ID or by searching for the message text. If the message you are looking for does not appear in this section, contact your authorized maintenance provider.

Fault Events

The following fault messages apply only to SANbox 9000 series switches. Fault events, like alarms, require administrator attention and may require assistance from your authorized maintenance provider.

AC_FAULT

Meaning: AC power may be unplugged or switched off.

AUX_PORT_ERROR

Meaning: At least one internal FC link is not functional.

FAN_FAULT_DETECTED

Meaning: Fan blade reports an internal fault.

FAN_FLOW_MISMATCH

Meaning: Incompatible air flow directions (FAN0, FAN1, PS0, PS1)

FAN0_MISSING

Meaning: FAN0 is not installed.

59060-05 A 3-1

3 – Event Messages Fault Events

FAN1_MISSING

Meaning: FAN1 is not installed.

FW_APP_FAIL

Meaning: Internal application failure.

FW_APP_PEER_FAULT

Meaning: Application declared an error communicating with other CPU.

FW_APP_SELF_FAULT

Meaning: Application declared an internal fault.

FW_APP_STARTUP_FAIL

Meaning: Application is unable to complete startup processing.

FW_FILE_SYSTEM_REMADE

Meaning: A Remake Filesystem command was performed in maintenance

S

mode.

FW_FT_APP_REG_FAIL

Meaning: Application is unable to register with Fault Tolerant (FT) manager.

FW_FT_APP_SYNC_FAIL

Meaning: Failure to synchronize data to the secondary CPU blade.

FW_FT_CPU_FAILOVER_FAILED

Meaning: Unable to complete failover process.

FW_FT_NO_ABDICATE_REPLY

Meaning: Unable to failover due to lack of secondary CPU blade response.

FW_HEARTBEAT_LOST

Meaning: Communication with the blade was lost.

FW_INIT_FAIL

Meaning: Blade did not complete the initialization sequence.

FW_POST_FAIL

Meaning: Power-On Self Test failure.

FW_UPDATE_FAIL

Meaning: Firmware update to the secondary CPU blade failed.

3-2 59060-05 A

A

HW_BAD_SEATING

Meaning: Blade is improperly seated.

HW_MP_ACCESS_CPU0

Meaning: The maintenance panel SPROM data accessed through CPU0 is

HW_MP_ACCESS_CPU1

Meaning: The maintenance panel SPROM data accessed through CPU1 is

HW_MP_DATA_MISMATCH

Meaning: The maintenance panel SPROMs accessed through CPU0 and

HW_POWERUP_FAIL

Meaning: Blade never established initial communications.

3 – Event Messages

Fault Events

either inaccessible or invalid.

CPU1 are not identical.

HW_SENSOR_FAULT

Meaning: Hardware temperature/voltage sensors are not functional.

HW_UNSUPPORTED_BLADE

Meaning: Installed blade is unknown or not supported.

SENSOR_FAULT

Meaning: Power Supply blade reports an internal fault.

temp_sensor_TEMP

Meaning: The temperature sensor reading is out of range; it is too high.

temp_sensor can be BOARD_0, BOARD, BOARD_1, DS1780_0, DS1780, DS1780_1, MAX1617_0, MAX1617, ASIC_0, ASIC, MAX1617_1, ASIC_1, or MEZZ_BOARD.

voltage_sensor_HIGH

Meaning: The voltage_sensor voltage supply is out of range; it is too high.

voltage_sensor can be 1.55V, 2.5V, 1.5V, ASIC_1.8V, 1.25V, 1.8V,

3.3V, CPU_1.8V, 5V, 12V, ASIC_0_1.5V, or ASIC_1_1.5V.

voltage_sensor_LOW

Meaning: The voltage_sensor voltage supply is out of range; it is too low.

1.55V, 2.5V, 1.5V, ASIC_1.8V, 1.25V, 1.8V, 3.3V, CPU_1.8V, 5V, 12V, ASIC_0_1.5V, or ASIC_1_1.5V.

59060-05 A 3-3

3 – Event Messages Alarm Events

Alarm Events

An alarm event requires action before you can proceed any further. The following lists each alarm event ID numbers and message displayed, and provides a description of the meaning of the message and recommended action to take.

(A1000.000F) (The switch is canceling the hotreset - try again later)

Meaning: You cannot move forward with the hot reset. All applications and

switch resources are backing out of the procedure and returning to normal operation.

Action: Ensure that the fabric is stable and that no changes are being

made to switch configurations or connections and then try again.

(A1000.001D) (Hotreset failed and the switch must be reset normally)

Meaning: The hot reset has failed and left the switch in an indeterminate

state.

Action: Reset the switch.

S

(A1000.001E) (Hotreset failed and the switch is being reset)

Meaning: There was a failure during the hotreset process; the switch is being

reset normally.

Action: None

(A1003.000B) (Failing release of fabric lock held by switch with domain domain_ID)

Meaning: The local switch is locked because zoning changes are being

made by a remote switch.

Action: Wait for the lock to time out and try again.

(A1003.000C) (Fabric Busy, failing lock request from domain domain_ID)

Meaning: The command failed because the fabric is busy with another

command in progress.

Action: Wait 10 seconds and retry the command.

(A1003.000D) (Fabric already locked by domain domain_ID)

Meaning: The switch given by the domain_ID has locked the fabric. Action: Unlock the domain_ID lock on the switch given by domain_ID.

(A1003.000E) (Couldn't acquire lock from domain domain_ID)

Meaning: The fabric may be changing, and therefore could not acquire the

lock.

Action: Wait for the fabric to stabilize, then try again.

3-4 59060-05 A

A

(A1003.0010) (Segmenting, zoneset zone_set_name not defined)

Meaning: In non-interop mode, there is a conflict in the zoning configuration,

causing the Inter-Switch Link (ISL) to isolate. The zone set is not found within the local zoning data base while interop mode is disabled.

Action: Contact your authorized maintenance provider.

(A1003.0011) (Segmenting, zoneset zone_set_name already active)

Meaning: In non-interop mode, there is a conflict in the zoning configuration,

causing the Inter-Switch Link (ISL) to isolate. A switch tried to activate a zone set that is already active while interop mode is disabled.

Action: Contact your authorized maintenance provider.

(A1003.0012) (Segmenting, zoneset zone_set_name merge conflict)

Meaning: In non-interop mode, there is a conflict in the zoning configuration,

causing the Inter-Switch Link (ISL) to isolate. After a zone merge with interop mode disabled, two zone sets were discovered in the local zoning database with the same name, but different membership.

3 – Event Messages

Alarm Events

Action: Contact your authorized maintenance provider.

(A1003.0013) (Segmenting, zone zone_name merge conflict)

Meaning: In non-interop mode, there is a conflict in the zoning configuration,

causing the Inter-Switch Link (ISL) to isolate. After a zone merge with interop mode disabled, two zone were discovered in the local zoning database with the same name, but different membership.

Action: Contact your authorized maintenance provider.

(A1003.0014) (Segmenting, alias alias_name merge conflict)

Meaning: There is a conflict in the zoning configuration causing the

Inter-Switch Link (ISL) to isolate. Two aliases with the same name but different membership were discovered in the local zoning database.

Action: Reconcile the active zone sets so that the two aliases have

identical membership.

(A1003.0015) (Zoneset Activation received from switch with domain domain_ID failed,

unknown zoneset zone_set_name)

Meaning: A zone set activation received from the named switch failed

because the zone set was not in the zoning database.

Action: Examine the named switch to verify that the zoning database is

correct.

59060-05 A 3-5

3 – Event Messages Alarm Events

(A1003.0016) (Releasing Lock held too long by domain_ID)

Meaning: A zone merge could not be completed in the acceptable time. Action: Check the status of the switch given by domain_ID.

(A1003.0017) (Activation of zoneset by management server failed due to port port_number

out of range.)

Meaning: A zone member defined by domain ID and port was received within

a management server AZSD command with a port number out of range.

Action: Check the management server application zoning configuration to

ensure zone members are properly configured.

(A1003.001B) (Failing remote zoning configuration, total zoneset limit would be e xceed ed)

Meaning: The maximum number of zone sets allowed on the switch has

been exceeded because of a zone merge.

Action: Reduce the number of zone sets on the remote switch.

S

(A1003.001C) (Failing remote zoning configuration, tota l member limit would be exceed ed)

Meaning: The maximum number of zone members allowed on the switch has

been exceeded because of a zone merge.

Action: Reduce the number of zone members on the remote switch.

(A1003.001D) (Failing remote zoning configuration, total zones in zonesets limit would be

exceeded)

Meaning: The maximum number of zones allowed in all zone sets has been

exceeded because of a zone merge.

Action: Reduce the number of zones on the remote switch.

(A1003.001F) (Failing remote zoning configuration, member limit for zone zone_name

exceeded, (size= number_of_zones, limit= maximum_number_of_zones))

Meaning: The maximum number of members allowed for the given zone has

been exceeded because of a zone merge.

Action: Reduce the number of members in the given zone on the remote

switch.

(A1003.0020) (Failing remote zoning configuration, total zone limit would be exceeded)

Meaning: The maximum number of zones allowed on the switch has been

exceeded because of a zone merge.

Action: Reduce the number of zones on the remote switch.

3-6 59060-05 A

3 – Event Messages

A

(A1003.0021) (Failing remote zoning configuration, Zoneset is empty)

Meaning: An empty zone set was included as part of a zone merge and was

rejected.

Action: Modify the zoning database on the remote switch to remove or

correct the empty zone set.

(A1003.0022) (Unable to update dat abase with newly activated information, Zoning Save in

Progress)

Meaning: Modifications were being made to the security or zoning database

while a security set or zone set was being activated or deactivated from a remote switch.

Action: Try the activation or deactivation again later.

(A1003.0023) (Fabric Busy Zoneset operation failed)

Meaning: The activation or deactivation of a zone set failed because the

fabric is currently busy.

Action: Try the activation or deactivation again later.

Alarm Events

(A1003.0024) (Request already in progress (internal lock held))

Meaning: A fabric operation is currently in progress. Action: Wait and try again.

(A1003.0025) (Error reading security set.)

Meaning: There was a problem handling the activate direct management

server command. The format of the command was not standard.

Action: Check the security configuration.

(A1003.0028) (SFC failure received from remote switch with domain domain_ID)

Meaning: The remote switch given by domain_ID rejected the Staged Fabric

Configuration (SFC) message, so the SFC request has failed.

Action: Check the status of the remote switch at the given domain ID.

There could be an issue with the security configuration or the zoning configuration.

(A1003.0029) (No response received from switch with domain ID domain_ID)

Meaning: The remote switch given by domain_ID did not reply to an Acquire

Change Authorization (ACA) message, so the ACA request has failed.

Action: Check the status of the remote switch at the given domain ID.

There could be an issue with the security configuration or the zoning configuration.

59060-05 A 3-7

3 – Event Messages Alarm Events

(A1003.002A) (No response received from switch with domain ID domain_ID)

Meaning: A Staged Fabric Configuration (SFC) frame was sent to the switch

given by domain_ID, but a response was not received.

Action: Check the status of the remote switch at the given domain ID.

There could be an issue with the security configuration or the zoning configuration.

(A1003.002B) (No response received from switch with domain ID domain_ID)

Meaning: A Update Fabric Configuration (UFC) frame was sent to the switch

given by domain_ID, but a response was not received.

Action: Check the status of the switch.

(A1003.002C) (Zone Merge response indicates failure due to zoning limits, Isolating link)

Meaning: Response from other switch indicates that the active zone sets

could not be merged.

Action: Edit or delete the conflicting zone objects or deactivate the zone

set on the remote switch.

S

(A1003.002D) (Zone Merge response indicates failure to merge, Isolating link)

Meaning: The attempt to merge two fabrics failed because each active zone

set contained a zone with the same name, but different membership.

Action: Edit the affected zone to remove the conflict or deactivate one of

the zone sets.

(A1003.002F) (SW2 Zoning Not Supported by other switch, Isolating link)

Meaning: The inter-switch link isolated because the local switch is configured

for FC-SW-2-compliant zoning (interoperability mode set to Standard), but the remote switch is not.

Action: Set the interoperability mode on the remote switch to Standard.

(A1003.002E) (Zoning merge has been rejected.)

Meaning: The attempt to merge two fabrics failed because the active zone

sets each contained a zone with the same name, but different membership.

Action: Either edit the affected zone to remove the conflict, or deactivate

one of the zone sets.

(A1003.0030) (Zone Merge rejected by remote switch.)

Meaning: The zone merge failed. Action: See the switch log for more details on why the merge failed.

3-8 59060-05 A

3 – Event Messages

A

(A1003.0031) (Error reading zoneset from activate direct.)

Meaning: A device supporting the management server has sent an Activate

Zoneset Direct $(AZSD) command that did not follow the expected standard layout.

Action: Contact your authorized maintenance provider.

(A1003.0032) (Zoneset zone_set_name failed validity checks (empty or contains empty

zone/alias))

Meaning: The zone set either has no zones or contains a zone or alias

without members.

Action: Add zones and members, or remove the empty zones and aliases

from the zone set.

(A1003.0033) (No memory for command completion)

Meaning: Insufficient switch memory. Action: Contact your authorized maintenance provider.

Alarm Events

(A1003.0034) (Merge failed, total zoneset limit would be exceeded.)

Meaning: A fabric merge failed because the combined number of zone sets

exceeds the zoning database limit.

Action: Remove zone sets from the local switch zoning database to allow

the fabric merge to complete.

(A1003.0035) (Merge failed, invalid zone data received, ISOLATING)

Meaning: A remote switch sent a zone merge that was invalid. Action: Reconcile interoperability modes on the local and remote switches

so that they are the same.

(A1003.0036) (Merge failed, member limit for zone zone_name exceeded, (size=

member_number, limit= member_limit))

Meaning: A fabric merge failed because the combined number of members

in two zones having the same name exceeds the limit for the number of members in a zone.

Action: Remove members either from the zone on the local switch or the

remote switch so that the combined sum is less than member limit.

(A1003.0037) (Merge failed, Total zone member limit would be exceeded)

Meaning: A fabric merge failed because the total number of zone members

exceeds the zoning database limit.

Action: Remove zone members either from the local switch or the remote

switch so that the combined sum is less than member limit.

59060-05 A 3-9

3 – Event Messages Alarm Events

(A1003.0038) (Merge failed, Total zones in zonesets limit would be exceeded.)

Meaning: A fabric merge failed because the total number of zones in zone

sets exceeds the zoning database limit.

Action: Remove zones either from the local switch or the remote switch so

that the combined sum is less than the zones-in-zone sets limit.

(A1003.0039) (Merge failed, total zone limit would be exceeded.)

Meaning: A fabric merge failed because the total number of zones exceeds

the zoning database limit.

Action: Remove zones either from the local switch or the remote switch so

that the combined sum is less than maximum zone limit.

(A1003.003A) (Zone Merge conflict for ZoneSet zone_set_name (Zone mismatch for zone=

zone_name, check type or members), ISOLATING)

Meaning: A fabric merge failed because two zones of the same name in two

zone sets of the same name have different membership.

Action: Reconcile the membership in the two zones so that they are the

same.

S

(A1003.003B) (Incomplete merge request sequence received, unable to process request.)

Meaning: A remote switch sent a merge request that was not understood. Action: Check the remote switch for configuration errors or equipment

malfunction.

(A1003.003C) (Incompatible Zoning mode, Isolating link)

Meaning: The fabric contains switches with a mix of interoperability mode

settings.

Action: Configure all switches in the fabric to have the same value for

interoperability mode.

(A1003.003E) (Security: Ports downed for INVALID_ATTACH require administrative action

to be brought online.)

Meaning: When deactivating a security set, ports that were previously

downed due to security violations remain down.

Action: Reset the ports or place the ports online.

(A1003.003F) (ISL group empty and links up. Set ports offline to activate.)

Meaning: An attempt to activate fabric binding with an ISL group that has no

members is not allowed because there are inter-switch links (ISL) logged in to the switch.

Action: Configure all ISLs offline or add each ISL member with fabric

binding information to the ISL group before activating.

3-10 59060-05 A

3 – Event Messages

A

(A1003.0040) (Zone Member type member_type unsupported.)

Meaning: An invalid zone member type was discovered in a zone. ACL hard

zone membership must be defined by domain_ID and port number.

Action: Correct the member type.

(A1003.0041) (Zoning objects which contain Fibre Channel (FC) Address Members not

being sent to remote switch on save, not supported in this mode)

Meaning: An attempt was made to assign a zone member by FC address

while interoperability mode was disabled. When Interop mode is disabled, zone membership must be defined by worldwide name or domain_ID and port number.

Action: Enable Interop mode or change the zone membership type.

(A1003.0048) (Active Zone Set zoneset_name no longer in database, please deactivate

zone set if not already in progress (the save will be deferred until zone set no longer active!)

Meaning: The switch will not allow you to delete a zone set that has the same

name as the active zone set from the zoning database.

Action: Deactivate the active zone set before deleting the zone set has the

same name.

Alarm Events

(A1003.004C) (Active ZoneSet containing Fibre Channel Address may cause fabric to

segment due to switches that do not support this zone member type)

Meaning: Some switches in the fabric may not support Fibre Channel

address zone members in the active zone set.

Action: Edit the necessary zone sets to use worldwide name zone

membership.

(A1003.004D) (Port group does not contain entry for this switch)

Meaning: The security set cannot be activated because the port group does

not have an entry for the local switch worldwide name.

Action: Edit the port group to include the local switch worldwide name.

(A1003.004E) (Group entry for local switch does not support authentication)

Meaning: The local switch worldwide name group entry is not configured for

authentication, but other members within the group are. This configuration is not allowed.

Action: Change the local switch worldwide name entry to run Challenge

Handshake Authentication Protocol (CHAP) authentication or remove CHAP authentication from other members of the group.

59060-05 A 3-11

3 – Event Messages Alarm Events

(A1003.004F) (No Zone Merge Response)

Meaning: A merge request was sent out to all switches in the fabric but a

response was not received from at least one switch.

Action: Check other switches in fabric to determine why a response was

not sent.

(A1003.0050) (ISL group does not contain entry for this switch)

Meaning: The Inter-Switch Link (ISL) group does not contain an entry for the

local switch worldwide name. This is a required entry.

Action: Add the switch worldwide name to the ISL group, then activate the

security set.

(A1003.0051) (Domain ID for local switch does not match fabric binding)

Meaning: The configured fabric binding value for the local switch worldwide

name does not match the current domain ID for the switch.

Action: Change the fabric binding value for local switch worldwide name

within the ISL group to the current value of the domain ID.

S

(A1003.0052) (ISL group does not contain entry for switch domain_ID)

Meaning: The ISL group does not contain an entry for each switch in the

fabric. Fabric binding requires an entry for each switch.

Action: Make sure there is an entry in the ISL group for each switch in the

fabric, and try activating the security set again.

(A1003.0053) (Fabric binding must be unique, domains are assigned to multiple security

group members

Meaning: The fabric binding setting for the members of the ISL group are not

unique.

Action: Make the fabric binding settings unique for each member of the ISL

group, or set them to 0 so that they are not enforced.

(A1003.0054) (Failure at remote switch)

Meaning: A frame was sent to a remote switch, but the expected response

was not received.

Action: Check the status of the remote switch.

(A1003.0055) (Problem on zoning save of following switches: domain_ID_list)

Meaning: A zoning save could not be performed on some remote switches. Action: Examine the named switches. If there are no obvious problems,

contact your authorized maintenance provider.

3-12 59060-05 A

3 – Event Messages

A

(A1003.0058) (Active ZoneSet zone_set no longer in dat abase, please deactivate zone set if

not already in progress or fabric will be inconsistent)

Meaning: A zone set with the same name as the current active zone set no

longer resides in the zoning database. The active zone set will not be added to the full zone set sequence to prevent inconsistency in the zoning database.

Action: Deactivate the active zone set to keep the fabric consistent.

(A1003.0059) (Failing remote zoning configuration, zone member type not supported)

Meaning: A remote switch's zoning configuration contains a zone member

type that is not supported.

Action: Edit the zone to remove the unsupported member type.

(A1003.0060) (Zone Merge conflict (Alias mismatch for alias= alias, check members)

Meaning: The zone merge failed due to an alias mismatch. Action: Examine the zoning configuration for conflicts.

Alarm Events

(A1003.0062) (Failing delete orphans zoning request, fabric locked by switch with domain

ID domain_ID. Retry command later.)

Meaning: An attempt was made to delete the orphan zones while the fabric

was locked.

Action: Retry the command later.

(A1003.0063) (Failing delete orphans zoning request, fabric busy. Retry command later.)

Meaning: An attempt was made to delete the orphan zones while the fabric

was busy.

Action: Retry the command later.

(A1003.0064) (UFC failure received from domain domain_ID)

Meaning: An Update Fabric Configuration (UFC) message was received with

a failed status from the switch given by domain_ID.

Action: Check the status of the switch at the given domain ID.

(A1003.0066) (ISL group entry for switch wwn does not contain valid binding

configuration. Entry should have binding domain domain_ID)

Meaning: A switch in the fabric is using a domain ID that differs from the

configured fabric binding domain ID.

Action: Change either the current switch domain ID or the fabric-binding

domain ID so that they match.

59060-05 A 3-13

3 – Event Messages Alarm Events

(A1003.0069) (Failing remote zoning configuration, invalid zone data received)

Meaning: Zoning activation failed because the switch detected invalid zoning

data that is not supported in the local interop mode.

Action: Check your zoning configuration and remove incompatible zone

members.

(A1004.0001) (Port in active hard zone, but not installed or present on this switch.)

Meaning: A zone member in an ACL zone on this switch is defined with an

invalid port number.

Action: Examine the fabric and correct the zone membership.

(A1004.0005) (No communication from neighbor switch on port port_number with domain

ID domain_ID, lost route)

Meaning: This switch has not received a hello from the remote switch for 80

seconds. The routes learned through this link are discarded.

Action: None

S

(A1004.0008) (Eport Isolating due to ELP Incompatibility)

Meaning: An E_Port isolated due to an ELP (Exchange Link Parameter)

incompatibility.

Action: Review the accompanying alarms for a specific cause.

(A1004.0009) (Eport Isolating due to ESC Incompatibility)

Meaning: An E_Port isolated because the connecting switch failed to support

the standard routing protocol FSPF.

Action: Connect a compatible switch.

(A1004.000A) (Eport Isolating due to EFP Domain Overlap)

Meaning: An E_Port isolated because each fabric has a switch with the same

domain ID.

Action: Change the domain ID on one of the conflicting switches.

(A1004.000B) (Eport Isolating due to Switch Administratively Offline)

Meaning: An E_Port isolated because the local switch has been placed

offline.

Action: Configure the administrative state to Online to establish the link.

3-14 59060-05 A

3 – Event Messages

A

(A1004.000C) (Eport Isolating due to Domain ID Locked, Domain ID unavailable)

Meaning: An E_Port isolated because the requested domain ID matches

another in the fabric, and assigning an alternative is prohibited by the domain ID Lock parameter.

Action: Disable the domain ID lock parameter or reconfigure the domain

IDs.

(A1004.000D) (Eport Isolating due to RDI SW Reject)

Meaning: An E_Port isolated because the principal switch rejected the local

switch domain ID.

Action: Change the domain ID so that it is unique in the fabric.

(A1004.000E) (Eport Isolating due to RDI Domain out of Range)

Meaning: An E_Port isolated because the principal switch rejected the local

switch domain ID as being out of range (1–239).

Action: Change the domain ID to a valid number.

Alarm Events

(A1004.000F) (Eport Isolating due to Merge Zone Failure)

Meaning: An inter-switch link failed because the two active zone sets have a

zone with the same name, but different members.

Action: Modify one or both of the zones so that their membership is the

same, or deactivate one of the active zone sets. To connect the two fabrics, reset the affected E_Ports.

(A1004.0010) (Eport Isolating due to Remote switch using same domain ID)

Meaning: An E_Port isolated because the remote switch has the same

domain ID.

Action: Change the domain ID on one of the switches.

(A1004.0011) (Eport Isolating due to Remote switch isolated)

Meaning: An E_Port isolated because the remote switch has the same

domain ID.

Action: Change the domain ID on one of the switches.

(A1004.0012) (Eport Isolating due to ISL Security)

Meaning: A remote switch attempted to log in but was rejected because it

failed to satisfy the ISL group membership requirements.

Action: Review the ISL group configuration and make the necessary

corrections to include the remote switch as a member.

59060-05 A 3-15

3 – Event Messages Alarm Events

(A1004.0013) (Eport Isolating due to all switches incapable of becoming Principal Switch)

Meaning: An E_Port isolated because the principal priority on all switches is

set to 254.

Action: Configure one of the switches to be the principal switch by

changing the principal priority.

(A1004.0014) (Eport Isolating due to TOV mismatch indicated on ELP)

Meaning: An E_Port isolated because the R_A_TOV or E_D_TOV time out

values are different on the two switches.

Action: Modify the switch configurations so that R_A_TOV or E_D_TOV

values are the same.

(A1004.0015) (Eport Isolating due to Invalid Attach)

Meaning: An E_Port isolated because of invalid attachment. Action: Check for invalid attachment due to security or authentication

incompatibility.

S

(A1004.0020) (R_A_TOV mismatch indicated. Reconfigure to connect to remote switch.)

Meaning: An E_Port isolated because the R_A_TOV timeout values on the

two switches do not match.

Action: Modify R_A_TOV so that it is the same on both switches. The

recommended value is 10 seconds.

(A1004.0021) (E_D_TOV mismatch indicated. Reconfigure to connect to remote switch.)

Meaning: An E_Port isolated because the E_D_TOV timeout values on the

two switches do not match.

Action: Modify E_D_TOV so that it is the same on both switches. The

recommended value is 2 seconds.

(A1004.0023) (Attempting to connect to switch with incompatible time out value

configured (R_A_TOV/E_D_TOV).)

Meaning: An E_Port isolated because the values for R_A_TOV or E_D_TOV

are not the same on both switches.

Action: Modify the switches so that the time out values are the same.

(A1004.0024) (Attempting to connect to switch that is in non-interop mode)

Meaning: An attempt was made to connect to a switch with a different value

for Interop Mode.

Action: Modify the Interop Mode values so that they are the same on both

switches.

3-16 59060-05 A

3 – Event Messages

A

(A1004.0026) (Configured Domain ID domain_ID not available and Domain ID is locked on

this switch)

Meaning: An attempt was made to connect a switch to a fabric with a

conflicting domain ID, and the domain ID could not be reassigned.

Action: Change the domain ID so that it is unique in the fabric, or disable

the domain ID lock so that the domain ID can be automatically reassigned.

(A1004.0029) (No Switch capable of being Principal Switch. Reconfigure Principal Switch

Priority.)

Meaning: An E_Port isolated because the principal priority on all switches is

set to 254.

Action: Configure one of the switches to be the principal switch by

changing the principal priority.

(A1004.002B) (Port port_number not configured for E-Port capability, reconfigure to G/GL

to connect to remote switch)

Alarm Events

Meaning: An attempt was made by a remote switch to connect through a port

that could not configure itself as an E_Port.

Action: Change the port type on the remote switch to G_Port or GL_Port.

(A1004.002D) (Non-interop Legacy switch setting prevents domain/port zoning)

Meaning: Zone members involving switches of other vendors cannot be

defined by domain ID and port number when Interop Mode is disabled and Legacy Address Formatting is enabled.

Action: Disable (False) the Legacy Address Formatting, enable Interop

Mode, or reassign the zone members using a method other than domain ID and port number.

(A1004.002F) (Request for Domain ID rejected, WorldWide Name (WWN) device_WWN not

allowed to join fabric.)

Meaning: The switch with the specified worldwide name is not allowed to join

the fabric.

Action: Add the switch to a group in the active security set.

(A1004.0030) (Topology change, lost route to switch with domain ID domain_ID)

Meaning: Connection to a switch in the fabric was lost. Action: Inspect switch connections and device hardware for proper

operation. Review accompanying alarms for other causes.

59060-05 A 3-17

3 – Event Messages Alarm Events

(A1004.0032) (E_Port not supported on remote port. Reconfigure remote switch to

connect.)

Meaning: An E_Port isolated because the port on the remote switch could

not configure itself as an E_Port.

Action: Change the port type on the remote switch to G_Port or GL_Port.

(A1004.0033) (Remote switch is in Interop mode or using Legacy Address Format)

Meaning: A remote switch is attempting to connect with conflicting settings

for Interop mode or legacy address format.

Action: Configure the switches so that Interop mode and Legacy Address

Format settings are the same throughout the fabric.

(A1004.0034) (Failed to connect to a switch due to incompatibility - contact technical

support.)

Meaning: The two switches are incompatible. Possible causes include

incompatible interoperability mode configurations, incompatible firmware versions, and incompatible licensing.

S

Action: Verify that the interoperability mode settings, firmware versions,

and licensing on the remote switch are compatible. Otherwise, contact your authorized maintenance provider.

(A1004.0035) (Failed to connect to a switch due to incompatibility - check interop

settings.)

Meaning: The remote switch failed to connect possibly because the

interoperability mode setting is different from that of the local switch.

Action: Reconcile the interoperability mode settings on the local and

remote switch so that they are the same. If necessary , cont act your authorized maintenance provider.

(A1004.0036) (Domain ID domain_ID assigned to different switches. Cannot join fabrics.)

Meaning: An attempt was made to join two fabrics that had switches with the

same domain_ID.

Action: Change the domain_ID on one of the switches so that it is unique,

and then join the fabrics again.

(A1004.0037) (Fabric Binding Error - please reconfigure: Local switch assigned domain

domain_ID which is locked, fabric binding indicates domain domain_ID should be used.)

Meaning: The local switch has a conflicting domain ID and cannot be

automatically reassigned because the domain ID is locked.

Action: Change the domain ID of the local switch.

3-18 59060-05 A

3 – Event Messages

A

(A1004.0038) (WorldWide Name (WWN) device_WWN assigned domain domain_ID, fabric

binding indicates this domain is reserved for device_WWN.)

Meaning: The user-activated fabric binding conflicts with the current domain

ID assignment.

Action: Change the domain ID of the device.

(A1004.0039) (WorldWide Name (WWN) device_WWN currently in fabric, no fabric binding

in active security set for this WWN.)

Meaning: Fabric binding failed due to security incompatibility. Action: Check the security settings of the named device.

(A1004.003F) (Request for Domain ID rejected, WorldWide Name (WWN) device_WWN not

allowed to join fabric.)

Meaning: The switch with the specified WWN is not allowed to join the fabric. Action: Add the switch to a group in the active security set.

(A1004.0040) (World Wide Name (WWN) device_WWN assigned domain domain_ID, fabric

binding indicates it should use domain_ID.)

Meaning: A fabric binding configuration was activated that conflicts with the

current domain ID assignment.

Action: Change the domain ID of the named device, and then reconfigure

the fabric.

Alarm Events

(A1004.0041) (Eport isolating due to E_Port License Exceeded.)

Meaning: An E_Port isolated because all licensed E_Ports are in use. Action: Obtain a license key to license additional E_Ports.

(A1004.0043) (Forcing Domain ID change due to Interoperability setting from

old_domain_ID to new_domain_ID.)

Meaning: The Domain ID of the switch is changed due to an interoperability

configuration change. The old Domain ID does not conform to the range of allowed Domain IDs for the new interoperability setting.

Action: None

(A1004.0048) (Eport Isolating due to Port Binding failure)

Meaning: A switch device attempted to login as an Inter-Switch Link (ISL),

but that device was not configured in the port binding list.

Action: Add the device to the port binding list.

59060-05 A 3-19

3 – Event Messages Alarm Events

(A1004.0049) (Eport Isolating due to Remote inactive)

Meaning: The remote switch is unresponsive, and the link has not been

brought up. The port will be isolated because the remote switch failed to respond.

Action: Investigate the remote switch for connection problems.

(A1004.0050) (Maximum hard zoning member limit exceeded, Reverting to soft zoning.

Requires port reset.)

Meaning: The maximum number of zone members associated with a port is

limited to 64. If this number is exceeded, the switch cannot enforce hard zoning and will revert to soft zoning.

Action: Reduce the number of zone members associated with the port and

reset the port.

(A1004.0051) (Blade IO blade_number isolated due to startup problem)

Meaning: There is an internal communication issue with an IO blade. It will

be set down until it clears.

S

Action: If this problem persists, contact your authorized maintenance

provider.

(A1004.0052) (Eport Isolating due to Switch Binding failure)

Meaning: A device attempted to login as an inter-switch link, but that device

was not configured in the switch binding list.

Action: Add the device to the switch binding list.

(A1004.0053) (Adding Denial of Service entry for source FC Address 0xaddress)

Meaning: A number of frames from the indicated address have been

received. These frames are from a source that is not zoned with the destination. A denial of service entry will be set up to discard these frames.

Action: Investigate the source at the specified Fibre Channel address.

(A1004.0054) (Eport Isolating due to Link to self)

Meaning: Two ports on the same switch cannot be connected together. Action: Disconnect one or both ports.

(A1004.0055) (Chassis Interconnect cables misconfigured, see configuration guide for

optimal setup)

Meaning: Two SANbox 9000 switches are interconnected with

HyperStacking cables in a manner that is not supported.

Action: Refer to the Installation Guide for information about how to connect

SANbox 9000 switches with HyperStacking cables.

3-20 59060-05 A

3 – Event Messages

A

(A1004.0056) (Blade compromised due to internal data link failure (SET))

Meaning: An I/O blade has been compromised due to failure of its internal

data link to the CPU blade.

Action: Contact your authorized maintenance provider.

(A1004.0057) (Blade no longer compromised due to internal data link failure (CLEAR))

Meaning: The I/O blade link failure has been resolved. Action: None

(A1004.0060) (Virtual Lanes configuration change will take effect on next port reset)

Meaning: The virtual lanes configuration does not become active until you

reset the port.

Action: Reset the port.

(A1005.0006) (Request from WWN device_WWN address FC_address, failed authentic ation,

verify MS security configuration)

Meaning: Management server authentication is enabled, and the received

frame failed authentication.

Alarm Events

Action: Verify the MS group configuration.

(A1005.000A) (Cannot enforce zoning for member domain_ID, port_number, this zone

member will be ignored)

Meaning: A zone member given by domain ID and port number could not be

found in the fabric.

Action: Examine the fabric connections and zoning definitions.

(A1005.000C) (Configuration error, insufficient credit in pool. Extended credit not granted

for port port_number)

Meaning: Insufficient credits were available in the credit pool to grant the

credit request.

Action: Decrease the number of requested credits or add more donor

ports.

(A1005.000D) (Configuration error, insufficient credit in pool. Extended credit not granted

for port port_number)

Meaning: Insufficient credits were available in the credit pool to grant the

credit request.

Action: Decrease the number of requested credits or add more donor

ports.

59060-05 A 3-21

3 – Event Messages Alarm Events

(A1005.000E) (Configuration error, can't extend credit on loop capable ports. Extended

credit not granted for port: port_number)

Meaning: Loop ports cannot borrow credits from the credit pool. Action: Change the port type to G_Port or F_Port.

(A1005.0013) (Hotswap procedure failed - must hardreset switch)

Meaning: The blade hot-swap procedure failed or the procedure was not

followed correctly.

Action: Perform a hard reset.

(A1005.0020) (Warning - development logging is enabled)

Meaning: Development logging is enabled. Action: Contact your authorized maintenance provider.

3(A1005.0024) (Switch must be reset after leaving the Diagnostics Admin State)

Meaning: After changing the switch administrative state from Diagnostics to

any other state, the switch must be reset to complete the state change.

S

Action: Reset the switch.

(A1005.0034) (System resource error - contact technical support)

Meaning: There is a system resources problem on the switch. Action: Contact technical support.

(A1005.0035) (System resource error - contact technical support)

Meaning: There is an internal problem on the switch. Action: Contact technical support.

(A1005.0036) (Hotswap procedure failed before last reset - must hardreset switch)

Meaning: The blade hotswap procedure failed and the switch was reset

without a power-on self test.

Meaning: Reset the switch with a hard reset.

(A1005.0037) (Hotswap procedure never completed - the blade will not be functional until

the switch is hardreset)

Meaning: The blade hot-swap procedure was not completed. Action: Reset the switch with a hard reset.

(A1005.0038) (Switch incompatibility error - contact technical support)

Meaning: Switch incompatibility error. Action: Contact technical support.

3-22 59060-05 A

3 – Event Messages

A

(A1005.0039) (Fabric Login (FLOGI) from address FC_address failed)

Meaning: The payload of the FLOGI was not valid. Action: Check the device connection or replace the device. If the problem

persists, contact your authorized maintenance provider.

(A1005.003A) (Fabric Login (FLOGI) from address FC_address failed

authorization/authentication)

Meaning: Security authentication failed. Action: Check the security configuration on both the device and the switch

to ensure that they are configured properly.

(A1005.003B) (Warning - Debug logging filter level is set)

Meaning: Debug logging has been set using the Set Log Level command. Action: Confirm that you intended to do this. If not, use the Set Log Level

command to change the severity level to Info, Warn, or Critical.

(A1005.003C) (User Port(s) port_numbers, isolated, lost steering path, administering them

to state DOWNED.)

Meaning: The ports required for steering the user ports have failed. Action: Contact your authorized maintenance provider.

Alarm Events

(A1005.003E) (Warning, port(s) port_numbers configured ONLINE, but remain DOWN after

NDCLA.)

Meaning: Ports that were down before a non-disruptive code load and

activation remain down. This message serves as a reminder because the alarm log is cleared during the non-disruptive code load and activation.

Action: None

(A1005.003F) (Badly formatted SML Notification Ack session session_ID string - string)

Meaning: The switch sent a notification that was not formatted correctly;

there may be a resource problem on the switch.

Action: If this is a recurring message, contact your authorized maintena nce

provider.

(A1005.0040) (Unsupported SFP within port.)

Meaning: An unsupported SFP transceiver was installed in the port. Action: Replace the transceiver.

(A1005.0041) (Setting port admin state DOWN due to POST failure)

Meaning: The port failed the power-on self test and has been disabled. Action: Contact your authorized maintenance provider.

59060-05 A 3-23

3 – Event Messages Alarm Events

(A1005.0042) (Target device port_address attached to port port_number with

IOStreamGuard Enabled)

Meaning: The target device is attached to a port with IO StreamGuard

enabled.

Action: Disable I/O StreamGuard on the port.

(A1005.0045) (Configured port data conflicting within hardware capabilities)

Meaning: Configured port settings conflict with the hardware capabilities of

the port. The port is down.

Action: Reconfigure the port to be compatible with the port hardware.

(A1005.0047) (Attempts to login backend switch fail because backend switch does not

support NPIV.)

Meaning: The backend fabric switch does not support N_Port ID

Virtualization (NPIV) which in turn brings down the TF_Port.

Action: Ensure that the backend fabric switch supports NPIV.

S

(A1005.004A) (Temporary license for Fabric Security will expire in hours hour(s))

Meaning: The temporary Fabric Security license will expire in the time

displayed.

Action: Purchase and install the Fabric Security license to continue using

the security feature.

(A1005.004B) (The switch was reset due to firmware upgrade issues)

Meaning: After a firmware upgrade, the Serial Prom Cyclic Redundancy

Check (CRC) did not match what was expected. It is likely that licenses were updated on the switch while running older firmware.

Action: Check your license configuration for changes.

(A1005.004C) (ICCnumber cable installed - ALARM CLEARED)

Meaning: A HyperStack cable has been connected to the specified

Inter-Chassis Connection (ICC) port and the associated alarm has been cleared.

Action: None

(A1005.004D) (ICCnumber cable not installed - ALARM SET)

Meaning: A HyperSta ck cable is not connected to the specified Inter-Chassis

Connection (ICC) port and the associated alarm has been set.

Action: None

3-24 59060-05 A

3 – Event Messages

A

(A1005.004E) (Attempts to login backend switch fail because backend switch does not

support NPIV.)

Meaning: The backend fabric switch does not support N_Port ID

Virtualization (NPIV), which in turn brings down the TF_Port.

Action: Ensure that the backend fabric switch supports NPIV.

(A1005.004F) (Media device sensor is value units. Transitioning from state to state)

Meaning: The specified sensor (temperature, voltage, TxBias, TxPower,

RxPower) has set a fault. The sensor reports its value (°Celsius, volts, milliAmps, milliWatts) and transition states (low alarm, low warning, normal, high warning, high alarm).

Action: For the temperature sensor transitioning from low alarm to high

alarm, cool the system. For all other sensors transitioning from low alarm to high alarm, replace the media.

(A1005.0050) (Media device device_name is value units. Transitioning from state to state)

Meaning: The specified sensor (temperature, voltage, TxBias, TxPower,

RxPower) has cleared an existing fault. The sensor reports its value (°Celsius, volts, milliAmps, milliWatts) and transition states (low alarm, low warning, normal, high warning, high alarm).

Alarm Events

Action: None

(A1005.0051) (Canceling config edit mode as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while a Config Edit session was

open. The Config Edit session was canceled.

Action: Reopen the Config Edit session.

(A1005.0052) (Canceling IP ping as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while an Ethernet ping was in

progress. The Ethernet ping was canceled.

Action: Retry the Ping command.

(A1005.0053) (Canceling FC ping as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while an Fibre Channel ping was

in progress. The Fibre Channel ping was canceled.

Action: Retry the Fcping command.

(A1005.0054) (Canceling FC Trace Route as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while an Fibre Channel trace

route was in progress. The trace route was canceled.

Action: Retry the Fctrace command.

59060-05 A 3-25

3 – Event Messages Alarm Events

(A1005.0055) (Canceling TFTP operation as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while a Trivial File Transfer

Protocol (TFTP) operation was in progress. The operation was canceled.

Action: Retry the operation.

(A1005.0057) (Canceling the unpacking of a firmware image as a result of a CPU

switchover)

Meaning: A CPU blade switchover occurred while an firmware image unpack

was in progress. The unpack was canceled.

Action: Retry the image unpack.

(A1005.0058) (Canceling the zoning edit mode as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while a Zoning Edit session was

in progress. The Zoning Edit session was canceled.

Action: Reopen the Zoning Edit session.

S

(A1005.0059) (Canceling the security edit mode as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while a Security Edit session

was in progress. The Security Edit session was canceled.

Action: Reopen the Security Edit session.

(A1005.005A) (Canceling CIM edit mode as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while a CIM Edit session was in

progress. The edit session was canceled.

Action: Reopen the CIM Edit session.

(A1005.005B) (Canceling system edit mode as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while a system edit session was

in progress. The edit session was canceled.

Action: Reopen the system edit session.

(A1005.005C) (Canceling SNMP edit mode as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while an SNMP edit session was

in progress. The edit session was canceled.

Action: Reopen the SNMP edit session.

(A1005.005D) (Canceling Radius edit mode as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while a Remote Authentication

Dial In Service (RADIUS) edit session was in progress. The edit session was canceled.

Action: Reopen the RADIUS Edit session.

3-26 59060-05 A

3 – Event Messages

A

(A1005.005E) (Canceling Services edit mode as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while a services edit session

was in progress. The edit session was canceled.

Action: Reopen the services edit session.

(A1005.005F) (Canceling Nicknames edit mode as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while a nicknames edit session

was in progress. The edit session was canceled.

Action: Reopen the nicknames edit session.

(A1005.0060) (A control link between blade_ID and blade_ID (via blade_ID) has faile d, blade

control is not fully redundant, contact technical support.).

Meaning: A portion of the control plane network on the switch has failed. The

switch should continue to function normally, but any further failures may cause the switch to malfunction.

Action: Contact your authorized maintenance provider.

Alarm Events

(A1005.0061) (A control link between blade_ID and blade_ID (via blade_ID) is now

functioning normally.

Meaning: The control link has recovered and is functioning normally. Action: None

(A1005.0063) (CPU never entered HotStandby state)

Meaning: Secondary CPU never entered Hot Standby state, and therefore

the switch is not fault tolerant.

Action: Contact your authorized maintenance provider.

(A1005.0064) (Switch is not fault-tolerant. Fault Tolerant license is installed, but only 1

CPU blade installed)

Meaning: The Fault Tolerant license key was installed on a SANbox 9000

switch with only one CPU blade.

Action: Install the second CPU blade.

(A1005.0065) (Fault Tolerant license is installed, but secondary CPU's latch is open so

unable to become Fault Tolerant)

Meaning: The SANbox 9000 switch is not fault tolerant because the

secondary CPU blade is not fully installed.

Action: Close the secondary CPU blade latch.

59060-05 A 3-27

3 – Event Messages Alarm Events

(A1005.0066) (Switch is not fault-tolerant. Fault Tolerant license is installed, but secondary

CPU is faulted)

Meaning: The SANbox 9000 switch is not fault tolerant because of a fault on

the secondary CPU blade.

Action: Replace the secondary CPU blade.

(A1005.0067) (HyperStack(tm) license installed, but only 1 CPU blade installed - alarm

status)

Meaning: A SANbox 9000 switch that is licensed for HyperStacking must

have two CPU blades to make use of the HyperStack feature. If only one CPU blade is installed, this alarm message is issued with alarm status ALARM SET. When the second CPU blade is installed, the alarm message is reissued with alarm status ALARM CLEAR.

Action: If the alarm status is ALARM SET, install the second CPU blade.

(A1005.0068) (Primary blade seating is questionable)

S

Meaning: The SANbox 9000 primary CPU blade is not fully installed. Action: Reseat the primary CPU blade.

(A1005.0069) (Primary blade seating was resolved)

Meaning: The SANbox 9000 primary CPU blade seating problem has been

corrected.

Action: None

(A1005.006A) (User account account_name has expired)

Meaning: The named user account has exceeded its expiration date. Action: Review the user account and make the necessary corrections.

(A1005.006B) (Temperature too high, turning off lasers)

Meaning: The switch has overheated and the Fibre Channel port lasers have

been turned off.

Action: Power down the switch, correct the conditions that caused the

switch to overheat, and power up the switch.

(A1005.006C) (3.3V out of spec, turning off lasers)

Meaning: Fibre Channel switch ports are receiving incorrect voltages. Lasers

have been turned off.

Action: Contact your authorized maintenance provider.

3-28 59060-05 A

A

(A1005.006D) (Unable to synchronize with NTP server)

Meaning: The switch was unable to synchronize its time clock with the

Network Time Protocol (NTP) server.

Action: Confirm that the NTP service and NTP client are enabled. Confirm

that the NTP server IP address is correct and that the server is operating.

(A1005.006E) (A reset is required to activate this version of firmware)

Meaning: The installed firmware cannot be activated without disrupting I/O

traffic.

Action: Perform a hard reset.

(A1005.006F) (Hotreset Vversion -> Vversion is not supported)

Meaning: The installed firmware cannot be activated without disrupting I/O

traffic.

Action: Perform a hard reset.

3 – Event Messages

Alarm Events

(A1005.0070) (Hotreset to older firmware version not supported. A reset is required to

activate this version of firmware)

Meaning: The installed firmware cannot be activated without disrupting I/O

traffic.

Action: Perform a hard reset.

(A1005.0071) (Unable to obtain dynamic IP address, falling back to static IP address of

address on interface interface)

Meaning: The switch was unable to obtain its IP address from the Dynamic

Host Configuration Protocol (DHCP) server. The static IP address will be used.

Action: Investigate the DHCP server.

(A1005.0072) (Unable to turn off lasers, please power off the switch)

Meaning: Conditions exist that could damage the switch and the switch was

unable to turn off the Fiber Channel port lasers.

Action: Power down the switch and contact your authorized maintenance

provider.

(A1005.0073)(Blade fault fault reported)

Meaning: The named blade fault has occurred. Action: Contact your authorized maintenance provider.

59060-05 A 3-29

3 – Event Messages Alarm Events

(A1005.0074) (Blade seating is questionable)

Meaning: A SANbox 9000 blade is improperly installed. Action: Examine the switch and reinstall blades as needed.

(A1005.0075) (Blade seating problem was resolved)

Meaning: The SANbox 9000 blade seating problem as resolved. Action: None

(A1005.0076) (Extraction latch is open)

Meaning: A SANbox 9000 blade latch is open. Action: Examine the switch and close open latches.

(A1005.0077) (Extraction latch was closed)

Meaning: The SANbox 9000 blade latch has been closed. Action: None

(A1005.0078) (Extraction latch ignored until hotreset completes)

S

Meaning: Extraction latch was opened while a switch hot reset was in

progress.

Action: Return the extraction latch to the closed position. Wait until the hot

reset is complete, then remove the blade.

(A1005.0079) (Blade fault fault reported from primary CPU, resetting switch)

Meaning: A blade fault has occurred on the SANbox 9000 primary CPU

blade and the switch is resetting.

Action: Contact your authorized maintenance provider.

(A1005.007A) (Blade fault fault reported from primary CPU, powering off blades/ports)

Meaning: A blade fault has occurred on the SANbox 9000 primary CPU

blade. I/O blades are being powered down.

Action: Contact your authorized maintenance provider.

(A1005.007C) (Secondary CPU's latch is closed so now able to become Fault Tolerant)

Meaning: The SANbox 9000 secondary CPU blade latch has been closed;

the switch is now fault tolerant.

Action: None

(A1005.007D) (Canceling callhome edit mode as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while a CallHome Edit session

was open. The CallHome Edit session was canceled.

Action: Reopen the CallHome Edit session.

3-30 59060-05 A

A

(A1005.0099) (Canceling IPsec edit mode as a result of a CPU switchover)

Meaning: A CPU switchover occurred while an Ipsec Edit session was in

progress. The edit session was canceled.

Action: Open another Ipsec Edit session.

(A1005.0101) (ipv6: duplicate address detected)

Meaning: Another IP version 6 system on the local network is using the same

address as this switch.

Action: If the discovery method is static, assign a different IP version 6

address, or disconnect the device that is using the same address.

(A1005.009B) (IPSec configuration error: error_description)

Meaning: An error occurred while saving changes to an IP Security

configuration. None of the configuration modifications have been applied to the switch’s active database.

Action: Resolve any other IP Security alarms. If this alarm persists, cont act

your authorized maintenance provider.

3 – Event Messages

Alarm Events

(A1005.009C) (IPSec configuration error: Association assocation_name : error_description

Meaning: An error occurred affecting the specified association while saving

the IP Security configuration. The association has not been applied to the active database.

Action: Redo modifications to the association and save it.

(A1005.009D) (IPSec configuration error: Policy policy_name : reason)

Meaning: An error occurred affecting the specified policy while saving the IP

Security configuration. The policy has not been applied to the active database.

Action: Redo modifications to the policy and save it.

(A1006.0004) (Zoning conflict, device_WWN is in an ACL hard zone, but device_WWN

share a soft zone)

Meaning: The named zone members cannot communicate because they are

members of different ACL hard zones.

Action: Place both zone members in the same ACL hard zone or exclude

both from ACL hard zones.

(A1006.0005) (Zoning enforcement error in Nameserver)

Meaning: An error occurred while checking ACL zoning. Action: Contact your authorized maintenance provider.

59060-05 A 3-31

3 – Event Messages Alarm Events

(A1006.0006) (Zoning conflict, device_WWN and device_WWN do not share an ACL hard

zone, but device_WWN share a soft zone)

Meaning: The named zone members cannot communicate because they are

members of different ACL hard zones.

Action: Place both zone members in the same ACL hard zone or exclude

both from ACL hard zones.

(A1007.0001) (Security: Unspecified zoning enforcement error)

Meaning: A device was not authorized or it failed security checks and will not

be allowed to join the fabric.

Action: None

(A1007.0002) (Security: Remote Switch with WorldWide Name (WWN) wwn configured for

chap, no chap configured for local switch. 2-way Authentication Failure)

Meaning: The device WWN is either not configured in the security database ,

or it is not configured for Challenge Handshake Authentication Protocol (CHAP).

S

Action: Add the device WWN to the active security set if it missing, or

modify the group to allow for CHAP authentication with the other devices.

(A1007.0005) (Security: Authentication request was rejected by port.)

Meaning: Indicates that a remote switch rejected a security authentication

attempt. The port will isolate.

Action: Checks the security configuration on the remote switch to

determine the problem.

(A1007.0006) (Security: Could not validate Authentication Response from port_number,

payload seems to be incorrect.)

Meaning: The format of the payload of the response frame does not match

what was expected.

Action: Check for errors on the remote side of the link. Check the

transceiver and cable. Update firmware on remote switch.

(A1007.0007) (Security: Fabric Binding (ESA) not supported on remote switch and Fabric

Binding is enabled, failing security checks)

Meaning: Either fabric binding is not enabled on the remote switch or the

remote switch does not support security at all.

Action: Check the security configuration on the remote switch.

3-32 59060-05 A

3 – Event Messages

A

(A1007.0008) (Security: ESA Response failure, failing security checks)

Meaning: A failure was received during processing of the ESA received

frame. Either the payload did not match the standard layout or the payload status indicated a reject.

Action: Check for errors on the remote side of the link. Check the

transceiver and cable. Update firmware on the remote switch.

(A1007.0009) (Security checks EFMD response failure, failing security check.)

Meaning: A remote switch rejected a Exchange Fabric Membership Data

(EFMD) frame. The port will be isolated.

Action: Check remote switch for the reason that the EFMD frame was

rejected. It is possible that the FabricBindingEnabled parameter is different on the two switches.

(A1007.000A) (Security: Dropping lock held by domain domain_id for number seconds)

Meaning: A remote switch has held the fabric lock for too long. The local

switch is dropping the lock in order to send out a Exchange Fabric Membership Data (EFMD) frame.

Action: None

Alarm Events

(A1007.000B) (Security: EFMD Rejected, bad revision)

Meaning: The remote switch is running at a different Exchange Fabric

Membership Data (EFMD) version level than the local switch. Ports will isolate.

Action: None

(A1007.000C) (Security policy restrict mode, security db differs)

Meaning: The current security policy calls for Restrict Mode, which means

that all switches in the fabric must have the same security databases or the inter-switch links will not log in. In this case, the security databases differ.

Action: Reconfigure the active security set so that the ISL group members

are the same.

(A1007.000D) (Security policy in mode mode, other switch in mode mode, sec db conflict)

Meaning: The security policy on the local switch differs from that of the

remote switch.

Action: Configure the security policy on the remote switch to match that of

the local switch.

59060-05 A 3-33

3 – Event Messages Alarm Events

(A1007.000E) (Security: Auth challenge received from WWN port_WWN, not Authorized to

join)

Meaning: A challenge authentication frame was received from a remote

switch, but the local switch does not have an entry for itself within the active security set ISL group.

Action: Edit the ISL group to include the local switch.

(A1007.000F) (Security: Chap session Gen Response indicates error, chap unable to

authenticate)

Meaning: An Authentication Response frame cannot be built because the

Challenge Handshake Authentication Protocol (CHAP) session is not in the right state. The port will isolate.

Action: Check the remote device for a possible error condition. Reset the

port to retry again. If errors continue, disable CHAP for this device if the device belongs in the fabric.

(A1007.0010) (Security: Chap session Receive Challenge indicates bad st ate, chap unable

to authenticate)

S

Meaning: The Challenge Handshake Authentication Protocol (CHAP)

session state is not in the correct state for a challenge message. The port will isolate.

Action: Check the remote device for a possible error condition. Reset the

port to retry again. If errors continue, disable CHAP for this device if the device belongs in the fabric.

(A1007.0011) (Chap failure, isolating with Invalid Attach)

Meaning: Frame does not match format for a Challenge Handshake

Authentication Protocol (CHAP) status frame. Ports will isolate.

Action: Check the remote device for a possible error condition. Reset the

port to retry again. If errors continue, disable CHAP for this device if it belongs in the fabric.

(A1007.0012) (Port with World Wide Name (WWN) port_WWN address FC_address not

authorized to login, verify MS security configuration)

Meaning: The port cannot login with the current security configuration. Action: Add the named port to the Management Server group in the active

security set.

3-34 59060-05 A

3 – Event Messages

A

(A1007.0013) (Response from address FC_address, lacks authentication, discarding)

Meaning: A response received on the indicated port lacked Common

Transport (CT) authentication.

Action: Verify that the CT security configuration of the management

application using the remote port is compatible with the configuration of the Management Server security group on the switch.

(A1007.0014) (Response from WorldWide Name (WWN) device_WWN address FC_address,

failed authentication, discarding)

Meaning: A request received on the indicated port failed Common Transport

(CT) authentication.

Action: Verify that the CT security configuration of the management

application using the remote port is compatible with the configuration of the Management Server security group on the switch.

Alarm Events

(A1007.001C) (Security: Bad Authentication Flags)

Meaning: The received AUTH frame did not meet the standard format for the

frame payload. Within the header portion of the payload, there are some flags that are supposed to be set to zero (0). This frame has the flags set to something other than zero (0).

Action: Check the remote device for a possible error condition. Reset the

port to retry again. If errors continue, disable Challenge Handshake Authentication Protocol (CHAP) for this device if it belongs in the fabric.

(A1007.001D) (Ignoring RADIUS Server Radius_Server, invalid IP address configured)

Meaning: A Remote Authentication Dial In Service (RADIUS) server could

not be found at the configured IP address.

Action: Check the RADIUS server, or change the configuration to use an

IP address for a valid RADIUS server.

(A1007.001F) (Access reject from RADIUS server IP_address:port for device on this port)

Meaning: Security authentication has reached the maximum retry count. The

port will now isolate.

Action: Check the security configuration.

59060-05 A 3-35

3 – Event Messages Alarm Events

(A1007.0020) (MAX Retry count reached on CHAP Authentication Protocol Reset, failing

Authentication)

Meaning: A Remote Authentication Dial In Service (RADIUS) server has

rejected a RADIUS authentication request.

Action: Check the configuration on both the switch and on the RADIUS

server for incompatibilities.

(A1007.0021) (No response to RADIUS access request for device on port port)

Meaning: A configured Remote Authentication Dial In Service (RADIUS)

server did not respond to an authentication request within the timeout period.

Action: Check RADIUS server configuration and the RADIUS server.

(A1007.0022) (Invalid response authenticator from RADIUS server IP_address:port, check

shared secret)

Meaning: There is a Remote Authentication Dial In Service (RADIUS) server

configuration problem.

S

Action: Check the shared secret. The shared secret must be configured on

both the RADIUS server and the switch.

(A1007.0023) (Invalid response authenticator from RADIUS server IP_address:port, check

shared secret

Meaning: There is a Remote Authentication Dial In Service (RADIUS)

configuration problem.

Action: Confirm that the shared secret configured on the switch is identical

to the shared secret configured on the RADIUS server.

(A1007.0024) (Invalid access accept from RADIUS server IP_address:port, bad or missing

Service-Type)

Meaning: A service-type Remote Authentication Dial In Service (RADIUS)

attribute was not found in a RADIUS packet.

Action: This is a RADIUS server configuration issue. Consult your RADIUS

server documentation.

(A1007.0025) (Security feature not supported.)

Meaning: The switch is coming out of Non-Disruptive Code Load and

Activation (NDCLA) and had an active security prior to the NDCLA, but the security feature is no longer supported.

Action: A license key may be required for the security feature.

3-36 59060-05 A

3 – Event Messages

A

(A1007.0026) (Unable to validate Chap Response from device_WWN, possible Chap secre t

misconfiguration or security breach attempt.)

Meaning: A Challenge Handshake Authentication Protocol (CHAP)

authentication attempt failed due to failure while comparing secrets.

Action: Check security configuration.

(A1007.0027) (Radius server could not validate authentication response from port_number)

Meaning: Remote Authentication Dial In Service (RADIUS) authentication

failed.

Action: Confirm that the secret is the same on the switch as it is on the

RADIUS server.

(A1007.0028) (Security: 2-Way Authentication, No security entry found for port)

Meaning: Unable to locate a security member entry to complete a two-way

authentication.

Action: Edit the group to include the port.

Alarm Events

(A1007.0029) (Security protocol not using chap, unable to authenticate.)

Meaning: A Challenge Handshake Authentication Protocol (CHAP) negotiate

frame that specifies an unsupported authentication protocol was received.

Action: Check the remote device for a possible error condition. Reset the

port to try again. If errors continue, disable CHAP for this device if the device belongs in the fabric.

(A1007.002A) (Inconsistent Fabric Binding configuration. Enabled on remote switch(s),

disabled on local switch.

Meaning: Inconsistent fabric binding configuration settings between local and

remote switch. All switches in the fabric must have the same configured fabric binding setting.

Action: Enable or disable fabric binding on all switches.

59060-05 A 3-37

3 – Event Messages Alarm Events

(A1007.002B) (Security: Chap session Negotiate Authentication failed)

Meaning: The local switch received an authentication negotiate frame which

failed processing. Either the payload of the frame did not match th e standard layout of the frame or the Challenge Handshake Authentication Protocol (CHAP) session between the devices being authenticated was not in the state where the negotiate frame was expected.

Action: Check the remote device for a possible error condition. Reset the

port to retry again. If errors continue, disable Challenge Handshake Authentication Protocol (CHAP) for this device if it belongs in the fabric.

(A1007.002C) (Security: Authentication protocol msg (AUTH_DONE) inconsistent with

Authentication protocol in progress)

Meaning: The local switch received an AUTH_DONE command

authentication frame while the Challenge Handshake Authentication Protocol (CHAP) session was not in the correct state to expect this type of frame. The remote device is not following standard authentication protocol.

S

Action: Check the remote device for a possible error condition. Reset the

port to retry again. If errors continue, disable CHAP for this device if the device belongs in the fabric.

(A1007.002D) (Ignoring RADIUS Server RADIUS_server, invalid UDP port configured)

Meaning: A Remote Authentication Dial In Service (RADIUS) server was

configured with invalid data for the User Datagram Protocol (UDP) port. This configuration field is required to use the RADIUS server.

Action: Set the UDP port value in the switch RADIUS server configuration

using the Set Setup Radius command.

(A1007.002E) (Ignoring RADIUS Server RADIUS_server, zero timeout configured)

Meaning: A Remote Authentication Dial In Service (RADIUS) server was

configured with invalid data for the timeout value. A valid time out value is required to use the RADIUS server.

Action: Set the timeout value in the switch RADIUS server configuration.

using the Set Setup Radius command.

(A1007.002F) (Ignoring RADIUS Server RADIUS_server, no shared secret is configured)

Meaning: A Remote Authentication Dial In Service (RADIUS) server was

configured with invalid data for the shared secret. A valid time out value is required to use the RADIUS server.

Action: Set the shared secret in the switch RADIUS server configuration.

using the Set Setup Radius command.

3-38 59060-05 A

A

(A1007.0030) (Security protocol not using chap, unable to authenticate.)

Meaning: A Challenge Handshake Authentication Protocol (CHAP) negotiate

frame was received that specifies an unsupported Diffie-Helmann (DH) group type.

Action: Check the remote device for a possible error condition. Reset the

port. If errors continue, disable CHAP for this device if it belongs in the fabric.

(A1007.0031) (Security protocol not using chap, unable to authenticate.)

Meaning: A Challenge Handshake Authentication Protocol (CHAP) negotiate

frame was received that specified an unsupported hashing algorithm or an algorithm that is not allowed for this security member's configuration.

Action: Check the remote device for a possible error condition. Reset the

port. If errors continue, disable CHAP for this device if it belongs in the fabric.

3 – Event Messages

Alarm Events

(A1007.0032) (Fabric conditions or configurations do not currently allow for changing

fabric binding.)

Meaning: An attempt to change the fabric binding setting was rejected due to

current fabric binding configuration settings within the active security set.

Action: Check fabric binding settings and the domain IDs of the switches

within the fabric. Add missing switches to the ISL group of the active security set.

(A1007.0033) (Device device_WWN failed port binding.)

Meaning: A device attempted fabric login (FLOGI), but that device was not

configured in the port binding list for the specified port.

Action: Add the device to the port binding list.

(A1007.0034) (Device device_wwn failed switch binding.)

Meaning: A device attempted fabric login (FLOGI), but that device was not

configured in the switch binding list for the specified switch.

Action: Add the device to the switch binding list.

(A1007.0035) (Port taken offline due to switch binding failure following configuration

change.)

Meaning: A configuration change was made to the switch binding list such

that the device(s) on the port were no longer allowed to be logged in.

Action: Add the devices to the switch binding list.

59060-05 A 3-39

3 – Event Messages Alarm Events

(A1007.0036) (Port taken offline due to port binding failure following configuration

change.)

Meaning: A configuration change was made to the port binding list such that

the device(s) on the port were no longer allowed to be logged in.

Action: Add the devices to the port binding list.

(A1007.0037) (Device device_wwn failed port binding)

Meaning: A switch device attempted to login as an Inter-Switch Link (ISL),

but that device was not configured in the port binding list for the specified port.

Action: Add the device to the port binding list.

(A1007.0038) (Device device_wwn failed switch binding)

Meaning: A switch device attempted to login as Inter-Switch Link (ISL), but

that device was not configured in the switch binding list.

Action: Add the device to the switch binding list.

S

(A1007.0039) (Ignoring RADIUS Server server, no shared secret configured)

Meaning: An attempt was made to authenticate a switch login through a

Remote Authentication Dial In Service (RADIUS) server, but no shared secret exists.

Action: Configure a shared secret.

(A1007.003A) (Using local user authentication. No radius servers configured for user

authentication)

Meaning: A Remote Authentication Dial In Service (RADIUS) configuration

was set to authenticate user accounts through a RADIUS server, but no RADIUS server was configured. User accounts will be authenticated by the switch.

Action: Correct the user authentication order or configure a RADIUS

server.

(A2000.0001) (Pwr1 removed - ALARM SET)

Meaning: Power supply #1 has failed or was removed from the switch. Action: Contact your authorized maintenance provider.

(A2000.0002) (Pwr2 failure - ALARM SET)

Meaning: Power supply #2 has failed or was removed from the switch. Action: Contact your authorized maintenance provider.

3-40 59060-05 A

3 – Event Messages

A

(A2000.0004) (power_supply_number AC power may be unplugged or switched off -

ALARM SET)

Meaning: One of the two power supplies is not receiving power. Action: Check the switch power supply and the AC power source.

(A2001.0001) (Pwr2 was installed - ALARM CLEARED)

Meaning: Power supply #2 was installed. Action: None

(A2001.0002) (Pwr1 OK - ALARM CLEARED)

Meaning: Power supply OK. Action: None

(A2001.0004) (power_supply_number AC power is good - ALARM CLEARED)

Meaning: AC power has been restored. Action: None

Alarm Events

(A2002.0001) (fan_number was removed)

Meaning: A field replaceable fan was removed from the switch. Action: Reinstall the fan.

(A2002.0002) (Fan fan_blade failure - ALARM SET)

Meaning: A cooling fan has failed. Action: Replace the fan if it is a customer replaceable unit. Otherwise,

contact your authorized maintenance provider.

(A2002.0003) (Fan or power supply flow mismatch - ALARM SET)

Meaning: The switch has two cooling fans with opposite air flow directions. Action: Replace one of the fans with another fan with the correct air flow

direction.

(A2003.0001) (fan_blade inserted - ALARM CLEARED)

Meaning: The switch fan blade has been installed and the alarm is cleared. Action: None

(A2003.0002) (fan_blade OK - ALARM CLEARED)

Meaning: The switch fan blade is operational and the alarm is cleared. Action: None

59060-05 A 3-41

3 – Event Messages Alarm Events

(A2003.0003) (Fan flow match - ALARM CLEARED)

Meaning: The opposing fan air flow condition has been corrected. Action: None

(A2004.0001) (Secondary cpu_blade assuming control of system due to a failure of Prima ry

cpu_blade)

Meaning: Control is transferring from the primary CPU blade to the

secondary CPU blade on a SANbox 9000 switch.

Action: Investigate the former primary CPU blade for the cause of the

failure.

(A2004.0002) (Secondary cpu_blade assuming control of system due to an administrative

switchover)

Meaning: Control is transferring from the primary CPU blade to the

secondary CPU blade on a SANbox 9000 switch.

Action: None

S

(A2004.0003) (Secondary cpu_blade assuming control of system due to an opening of the

latch or removal of Primary cpu_blade)

Meaning: Control is transferring from the primary CPU blade to the

secondary CPU blade on a SANbox 9000 switch.

Action: None

(A3000.0001) (Temp overheat, sensor_name sensor reads value C - ALARM SET)

Meaning: The chassis temperature has reached a failure threshold. Action: Check air flow, fan operation, and ambient temperature. If the

problem cannot be corrected, power down the switch.

(A3000.0002) (Temp sensor sensor_name on blade slot_number reads value C - ALARM

SET)

Meaning: The chassis temperature has reached a failure threshold. Action: Check air flow, fan operation, and ambient temperature. If the

problem cannot be corrected, power down the switch.

(A3001.0001) (Temp overwarm, sensor_name sensor reads value C - ALARM SET)

Meaning: The chassis temperature has reached a warning threshold. Action: Check air flow, fan operation, and ambient temperature.

(A3002.0001) (sensor name sensor has returned to normal range - ALARM CLEARED)

Meaning: The chassis temperature has returned to the normal range and the

alarm condition has been cleared.

Action: None

3-42 59060-05 A

3 – Event Messages

A

(A3002.0002) (Temp sensor sensor_name on blade slot_number reads value C - ALARM

CLEARED)

Meaning: The named blade has returned to the normal operating

temperature range.

Action: None

(A3003.0001) (IOn) (Hardware error detected. Use 'show switch' for more info.)

Meaning: A fatal hardware error was discovered during the

Power-On-Self-Test (POST) phase of startup. This switch is not currently operational.

Action: Enter the Show Post Log command to investigate.

(A3003.0002) (POST detected a fatal error the last time it ran and will be re-executed.)

Meaning: A fatal hardware error was discovered from the previous

Power-On-Self-Test (POST). This switch is not currently operational.

Action: Enter the Show Post Log command to investigate.

Alarm Events

(A3003.0003) (Diagnostics have detected a fatal error on the I/O blade in slot slot_number.

The blade is not operational.)

Meaning: Diagnostic testing has determined that there is a failure on

specified I/O blade. The blade did not pass the Power-On-Self-Test (POST).

Action: Enter the Show Post Log command to investigate.

(A3004.0001) (Non-fatal hardware error detected. Use 'show post log' for more info)

Meaning: A non-fatal hardware error was discovered during the

Power-On-Self-Test (POST) phase of startup.

Action: Enter the Show Post Log command to investigate.

(A3004.0002) (Diagnostics have detected a partial failure on the I/O blade in slot

slot_number)

Meaning: Diagnostic testing has determined that there is a partial failure on

specified I/O blade. Most likely, at least one of the ports did not pass the Power-On-Self-Test (POST).

Action: Enter the Show Post Log command to investigate.

(A3005.0001-000C) (value voltage sensor shows valueV - ALARM SET)

Meaning: A switch voltage sensor on a SANbox 5000 series switch is

experiencing an out-of-range voltage condition.

Action: Contact your authorized maintenance provider.

59060-05 A 3-43

3 – Event Messages Alarm Events

(A3005.0001-000C) (Blade fault (valueV_HIGH - The [value]V volt age supply is out of range,

it is too high)

Meaning: A high voltage blade fault has occurred on a SANbox 9000 switch. Action: Contact your authorized maintenance provider.

(A3006.0001-000C) (value voltage sensor shows valueV - ALARM SET)

Meaning: An out-of-range voltage condition has occurred on a SANbox 5000

switch.

Action: Contact your authorized maintenance provider.

(A3006.0001-000C) (Blade fault (valueV_LOW - The valueV voltage supply is ou t of range, it

is too low)

Meaning: A low voltage blade fault has occurred on a SANbox 9000 switch. Action: Contact your authorized maintenance provider.

(A3007.0001-000C) (value voltage sensor shows valueV - ALARM CLEAR)

Meaning: The out-of-range voltage condition on a SANbox 5000 series

switch has cleared.

S

Action: None

(A3007.0001-000C) (Blade fault (blade_fault - CLEARED)

Meaning: The high or low voltage SANbox 9000 blade fault has cleared. Action: None

(A3008.0000) (The configuration area was damaged or a Remake Filesystem was

performed from PROM mode. You must perform a 'config restore' to clear this error.)

Meaning: The configuration area was damaged or a Remake Filesystem was

performed from Maintenance mode.

Action: Enter the Config Restore command to clear the error. If this does

not correct the problem, contact your authorized maintenance provider.

(A3014.0001) (Blade in slot slot_number set Down due to failure of all AuxPorts)

Meaning: The blade in the named slot has isolated because all auxiliary ports

to the cross-connect blades have failed.

Action: Contact your authorized maintenance provider.

(A3014.0002) (Blade in slot slot_number set Online due to internal failure recovery)

Meaning: The blade in the named slot has recovered at least one auxiliary

port to a cross-connect blade and is no longer isolated.

Action: None

3-44 59060-05 A

3 – Event Messages

A

(A3014.0003) (IOn) (Blade blade_ID set Down due to the configured blade type not

matching the installed blade)

Meaning: The I/O blade given by blade_ID has isolated because the

operational blade type does not match the configured blade type.

Action: Change the configured blade type to match the I/O blade that is

present, or insert an I/O blade of the configured blade type.

(A4000.0001) (threshold of value hit rising trigger trigger_number in value second window on

port port_number - ALARM SET

Meaning: The switch exceeded the specified threshold for the rising trigger in

the specified sample window.

Action: Investigate the specified port for problems or adjust the rising

trigger or sample window.

(A6000.0002) (Configured port speed for port port_number not compatible with media.)

Meaning: The transceiver in the named port is not capable of transmitting at

the configured port speed.

Alarm Events

Action: Reconfigure the port speed or replace the transceiver.

(A6001.0001) (cmon: insufficient memory)

Meaning: The Hotreset command has failed due to insufficient memory on

the switch. The switch has been returned to its state before the Hotreset command was entered.

Action: If acceptable, enter the Reset Switch command to reboot the

switch. Contact technical support if a non-disruptive code loa d and activation is required.

(A6001.0002) (cmon: blade failed NDCLA)

Meaning: The Non-Disruptive Code Load and Activation (NDCLA) has failed

on this I/O blade.

Action: None

(A6001.0003) (cmon: switch failed NDCLA)

Meaning: The Non-Disruptive Code Load and Activation (NDCLA) has failed.

The switch has performed a hard reset.

Action: None

(A6001.0004) (cmon: Blade was removed during NDCLA)

Meaning: An I/O blade was removed during the Non-Disruptive Code Load

and Activation (NDCLA).

Action: None

59060-05 A 3-45

3 – Event Messages Alarm Events

(A6001.0005) (Secondary CPU firmware update in progress, hotreset aborted.)

Meaning: The firmware image was being updated on the secondary CPU

when a hot reset was attempted.

Action: Wait for the firmware update to complete, then retry the hot reset.

S

3-46 59060-05 A

3 – Event Messages

A

Critical Events

Critical events are events that disrupt the administration or operation of the fa bric, but do not require any action before you can proceed. The following lists each critical event and the event id number and message displayed, and provides an explanation of the message.

(C) (8100.0001) (Name Server) (Port: port_number) (Protocol violation from address

FC_address)

Meaning: There has been a name server protocol violation. Contact your

authorized maintenance provider.

(C) (8300.0006) (Zoning) (Dropping lock held by domain domain_ID, Merge requests

outstanding)

Meaning: Another switch has held the fabric zoning lock too long. It is being

released to accommodate another fabric zoning request.

(C) (8300.000A) (Zoning) (Fabric Busy, failing lock request from domain domain_ID)

Meaning: Another switch in the fabric has requested the fabric zoning lock

from this switch while this switch is processing zoning commands.

(C) (8300.000B) (Zoning) (Failed to lock fabric, lock already held by switch with domain

domain_ID)

Meaning: Unable to complete the requested zoning command because fabric

zoning lock is already held by another switch in the fabric.

(C) (8300.000C) (Zoning) (Couldn't acquire lock from domain domain_ID)

Meaning: Fabric may be changing, couldn't acquire lock. Wait for fabric to

stabilize, try again.

(C) (8300.000E) (Zoning) (Failing release of fabric lock held by switch with domain=

domain_ID)

Meaning: Unable to release fabric zoning lock because it is held by another

switch in the fabric.

(C) (8300.000F) (Zoning) (Failed to lock fabric, lock already held with lock id lock_id)

Meaning: The fabric is already locked.

(C) (8300.0017) (The zoning database has been reset and zoneset zone_set deactivated by

user user_name)

Meaning: The zoning database was reset while a zone set was active. The

zoning information was cleared and the active zone set was deactivated.

59060-05 A 3-47

3 – Event Messages Critical Events

(C) (8300.0018) (ZoneSet zone_set has been activated by user user_name)

Meaning: A zone set in the zoning database has been activated

(C) (8300.0019)(ZoneSet zone_set has been deactivated by user user_name)

Meaning: A zone set in the zoning database has been deactivated.

(C) (8300.001A) (A ZoneSet activation has failed.)

Meaning: An attempt to activate a zone set has failed.

(C) (8400.0002) (Switch) (The switch is being reset - please wait)

Meaning: The switch is being reset.

(C) (8400.0003) (Switch) (The switch is being shutdown - please wait)

Meaning: The switch is being gracefully shutdown.

(C) (8400.0004) (Switch) (The switch is proceeding with a hotreset)

Meaning: Hot reset is in progress.

S

(C) (8400.0005) (Switch) (The switch is now performing a hotreset)

Meaning: Hot reset is in progress.

(C) (8400.0006) (Switch) (Admin mode for user user_name was canceled by user

user_name)

Meaning: Admin authority mode was canceled by another user interface

session that had the authority to do so.

(C) (8400.0008) (Switch) (The switch will be reset in several seconds

Meaning: The switch is being reset as a result of a command from a user

interface.

(C) (8400.0009) (Switch) (The switch will hardreset in several seconds)

Meaning: A hard reset of the switch is pending.

(C) (8400.000A) (Switch) (The switch will hotreset in several seconds)

Meaning: A hot reset is pending.

(C) (8400.000B) (Switch) (The switch will be shutdown several seconds)

Meaning: The switch will be shut down in several seconds.

(C) (8400.000C) (Switch) (Configuration is being restored - this could t ake several minutes)

Meaning: When a complete configuration restore is done on a switch, a

switch reset follows immediately to place the new configuration in effect.

3-48 59060-05 A

3 – Event Messages

A

(C) (8400.000E) (Switch) (Upgrading Licensed Ports to number_of_ports)

Meaning: The number of licensed ports on the switch has been upgraded.

(C) (8400.000F) (Switch) (Attempted Licensed Port upgrade of ports that are already

licensed)

Meaning: The switch has already been upgraded to the number of licensed

ports.

(C) (8400.0011) (Switch) (The switch will be reset in several seconds due to a config

restore)

Meaning: Switch management is processing a config restore command.

(C) (8400.0012) (Switch) (IOn) (Blade was inserted)

Meaning: An I/O blade has been inserted into the chassis.

(C) (8400.0014) (Switch) (IOn) (FC4G16 Blade was removed)

Meaning: An I/O blade has been removed from the chassis.

Critical Events

(C) (8400.0014) (Switch) (CPUn) (CPU Blade was removed)

Meaning: A CPU blade has been removed from the chassis.

(C) (8400.0015) (Switch) (The switch will be reset in several seconds)

Meaning: The switch is being reset as a result of a command from a user

interface.

(C) (8400.0016) (Switch) (Group members are being saved - this may take several

seconds)

Meaning: Group members are being saved in the security database.

(C) (8400.0017) (Switch) (Security edit session has been preempted by a security merge)

Meaning: A security merge has occurred and the security edit session has

been cancelled.

(C) (8400.001C) (Switch) (The switch is being reset - this may take several seconds)

Meaning: The switch is being reset.

(C) (8400.001D) (Switch) (The switch is being shutdown - this may take several seconds)

Meaning: The switch is being shutdown.

(C) (8400.0027) (Switch) (Invalid user account_name attempted to log into switch)

Meaning: Invalid user login attempt.

(C) (8400.0028) (Switch) (Invalid user account_name attempted to log into switch)

Meaning: Invalid user login attempt.

59060-05 A 3-49

3 – Event Messages Critical Events

(C) (8400.0029) (Switch) (User account_name attempted to log into switch with an incorrect

password)

Meaning: Invalid user login attempt.

(C) (8400.002A) (Switch) (User account_name attempted to log into switch with an incorrect

password)

Meaning: Invalid user login attempt.

(C) (8400.002E) (Switch) (number_of_zone_members zone members are being saved - this

may take several seconds)

Meaning: It will take several seconds to save the large zoning database.

(C) (8400.002F) (Switch) (Zoning database of over 3000 zone members may damage some

vendors’ switches, if you have other vendor’s switches in your fabric, please refer to their switch manual/documentation to see what zone member limits the switch supports)

Meaning: You have a large database on the switch consisting of over 3000

zone members. This could cause a problem in mixed fabrics because not all vendors support a configuration this large.

S

(C) (8400.0030) (Switch) (Zoning edit session has been preempted by a zoning merge)

Meaning: A zoning edit session has been preempted by a zone merge. The

zoning edit session has been canceled.

(C) (8400.003B) (Switch) (Creating the support file - this will take several seconds)

Meaning: The switch is creating a support file. This takes a few seconds to

complete.

(C) (8400.003C) (Switch) (Network setup is changing - may lose connection - admin being

released automatically)

Meaning: Changes made to the network configuration may interrupt your

connection to the switch.

(C) (8400.0042) (Switch) (Warning - deleting the active zoneset may cause fabric isolation)

Meaning: Deleting the active zone set from the zoning database could isolate

all switches in the fabric.

(C) (8400.0043) (Switch) (Warning - clearing the active zoneset may cause fabric isolation)

Meaning: Clearing all zoning definitions from the active zone set could isolate

all switches in the fabric.

3-50 59060-05 A

3 – Event Messages

A

(C) (8400.0044) (Switch) (A reset is required since a Power On Self Test (POST) has never

run on these ports)

Meaning: After upgrading ports, it may be necessary to reset the switch so

that the POST can run on the newly licensed ports.

(C) (8400.0045) (Switch) (Upgrading License for 4G capability)

Meaning: Installation of the license key that grants 4-Gbps transmission

speed capability to the Fibre Channel ports is in progress.

(C) (8400.0046) (Switch) (Upgrading License for multiple ISL capability)

Meaning: The switch has been upgraded to allow for multiple inter-switch

links.

(C) (8400.0047) (Switch) (New licenses are being installed

Meaning: New licenses are being installed.

(C) (8400.0049) (Switch) (The Configuration Wizard from ip_address is exiting - switch

configuration may have changed)

Critical Events

Meaning: Changes made to switch may result in loss of communication with

the switch.

(C) (8400.004B) (Switch) (Attempted to license modes on an unsupported switch type)

Meaning: An attempt was made to install a license key for a feature that is

not supported on the switch.

(C) (8400.004C) (Switch) (Services setup is changing - may lose connection - admin being

released automatically)

Meaning: The Services configuration is changing and this may result in the

loss of a connection.

(C) (8400.004D) (Switch) (ntpdate: no server suitable for synchronization found)

Meaning: The Network Time Protocol (NTP) server was not found.

(C) (8400.004E) (Switch) (ntpdate: synchronization lost)

Meaning: The Network Time Protocol (NTP) server synchronization was lost.

(C) (8400.0050) (Switch) (Upgrading License allowing manufacturing setup mode

capability)

Meaning: The license upgrade was successful.

(C) (8400.0052) (Switch) (Upgrading License for EFCM capability)

Meaning: The license upgrade was successful.

59060-05 A 3-51

3 – Event Messages Critical Events

(C) (8400.0053) (Switch) (The switch WWN is being upgraded)

Meaning: The license upgrade was successful.

(C) (8400.0054) (Switch) (radius: All RADIUS servers failed to respond)

Meaning: None of the Remote Authentication Dial In Service (RADIUS)

servers configured responded. Check the RADIUS server configuration.

(C) (8400.0057) (Switch) (User login (user_name) is being closed - Telnet connections have

been disabled

Meaning: A Telnet session has closed.

(C) (8400.0058) (Switch) (User (user_name) is using their initial/default password)

Meaning: The specified user has not changed their password from its initial

value.

(C) (8400.005B) (Switch) (A nicknames configuration edit session has been canceled)

Meaning: A nicknames edit session was canceled by the user.

S

(C) (8400.005C) (Switch) (The switch will be reset in several seconds in order to activate

the Transparent mode configuration changes.)

Meaning: Configuration changes which affect Transparent mode or

Transparent mode port mappings, will result in the switch being reset.

(C) (8400.005C) (Switch) (The switch will be reset in several seconds due to switch mode

transition)

Meaning: The configuration is changing between transparent mode and full

fabric mode. This will result in an automatic switch reset to activate the change.

(C) (8400.005D) (Switch) (Upgrading License for SANdoctor)

Meaning: The SANdoctor bundle license was applied successfully.

(C) (8400.005E) (Switch) (Upgrading License for Transparent Switch Mode change

capability.)

Meaning: The Transparent Mode license was applied successfully.

(C) (8400.005F) (Switch) (Upgrading License for SMI-S capability)

Meaning: The Common Information Model (CIM) license was applied

successfully.

3-52 59060-05 A

3 – Event Messages

A

(C) (8400.0060) (Switch) (Warning-Illegal transparent mode configuration, primary and

backup cannot be mapped to the same port. Port port_number 's backup mapping has been deleted.

Meaning: When mapping TH ports to TF ports, the primary and backup TF

ports cannot be the same for a given TH port.]

(C) (8400.0061) (Switch) (Warning-Illegal transparent mode configuration, Either the

primary or backup map for port port_number was set to a port whose type is not TF. The mapping for this port has been cleared.

Meaning: An attempt was made to map a TH port to a port that was not of

type TF.

(C) (8400.0062) (Switch) (New firmware has been installed.)

Meaning: New firmware was successfully installed.

(C) (8400.0065) (Switch) (The switch is being automatically hardreset after leaving the

Diagnostics AdminState.)

Meaning: The switch automatically undergoes a hard reset after leaving the

Diagnostics administrative state.

Critical Events

(C) (8400.0066) (Switch) (IOn) (Blade is being automatically hardreset after leaving the

Diagnostics AdminState.)

Meaning: I/O blade is undergoing a hard reset after leaving the Diagnostics

administrative state.

(C) (8400.0067) (Switch) (The switch is entering Diagnostics AdminState and will

automatically hardreset and have the configured AdminState when leaving the Diagnostics AdminState.)

Meaning: The switch is entering the Diagnostics state and will automatically

undergo a hard reset. The switch will return to the configured administrative state after leaving the Diagnostics administrative state.

(C) (8400.0068) (Switch) ( IOn) (Blade is entering Diagnostics AdminState and will

automatically hardreset and have the configured AdminState when leaving the Diagnostics AdminState.)

Meaning: The I/O blade is entering Diagnostics state and will automatically

undergo a hard reset. The I/O blade will return to the configured administrative state after leaving the Diagnostics administrative state.

59060-05 A 3-53

3 – Event Messages Critical Events

(C) (8400.0069) (Switch) (Warning-When leaving the Diagnostics AdminState of the

primary CPU blade, an automatic reset of the blade will occur . The blade and the switch will come back up in the configured AdminState.)

Meaning: The primary CPU blade is entering Diagnostics state and will

automatically undergo a hard reset. The I/O blade will return to the configured administrative state after leaving the Diagnostics administrative state.

(C) (8400.006A) (Switch) (Upgrading License for Fabric Security)

Meaning: The Fabric Security Bundle license was applied successfully.

(C) (8400.006B) (Switch) (Upgrading License for CLI Extended Credits capability)

Meaning: The CLI Extended Credits license was applied successfully.

(C) (8400.0070) (blade_ID blade is operational)

Meaning: The specified blade is powered on and fully operational.

(C) (8400.0071) (Extraction latch was opened)

S

Meaning: The latch has been pulled down. The blade is not accessible.

(C) (8400.0072) (Extraction latch was closed)

Meaning: The latch has been closed. The blade is inserted into the chassis.

(C) (8400.0073) (Blade was powered off)

Meaning: The blade is powered off after a latch pull.

(C) (8400.0074) (Blade was powered on)

Meaning: The blade was powered on after an extraction latch was closed.

(C) (8400.0075) (Upgrading License for Fault Tolerant capability)

Meaning: The Fault Tolerant license was applied successfully.

(C) (8400.0076) (Upgrading License for HyperStack(tm) capability)

Meaning: The HyperStack license was applied successfully.

(C) (8400.0079) (Canceling config edit mode as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while a Config Edit session was

open.

(C) (8400.007A) (Resaving the zoning config as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while saving the configured

zoning database. A save ‘retry’ is occurring.

3-54 59060-05 A

3 – Event Messages

A

(C) (8400.007B) (Resaving the security config as a result of a CPU switchover)

Meaning: A CPU blade switchover occurred while saving the security

database. A save ‘retry’ will now occur.

(C) (8400.007C) (CPUn) (Switching over to Secondary blade_ID)

Meaning: Control is transferring from the primary CPU to the specified

secondary CPU blade.

(C) (8400.0080) (Switch) (blade_ID) (Blade fault blade_fault processing in progress,

gathering support information...)

Meaning: The system is gathering support information in response to the

blade fault that occurred on the specified blade.

(C) (8400.008A) (A Zoning merge has occurred)

Meaning: Two fabrics have been conn ected and their zoning databases h ave

been merged.

(C) (8400.008D) (Illegal configuration detected based on licensing. Configuration will be

updated.)

Meaning: The restoration of a configuration backup has violated current

feature licensing. The active configuration will be automatically updated based on current licensing.

Critical Events

(C) (8400.008E) (Inconsistent configuration defaults detected. Defaults will be updated.)

Meaning: Two fabrics have been connected, and their zoning databases

have been merged.

(C) (8400.008F) (Attempted speed licensed upgrade that is already enabled)

Meaning: An attempt was made to install a license for a port speed that is

already operable on the switch.

(C) (8400.0096) (Secondary CPU firmware update complete)

Meaning: The update of the firmware image on the secondary CPU is

complete.

(C) (8600.0009) (PortApp) (Port: port_number) (Link reset (LR) to be performed on port

port_number.)

Meaning: The port will perform a link reset (LR) due to a loss of credit

problem.

(C) (8600.000A) (PortApp) (Port: port_number) (Link reset (LR) to be performed on port

port_number.)

Meaning: The port will perform a link reset (LR) due to a loss of credit

problem.

59060-05 A 3-55

3 – Event Messages Critical Events

(C) (8600.000B) (PortApp) (Port: port_number) (Link reset (LR) to be performed on port

port_number.)

Meaning: The port will perform a link reset (LR) due to loss of credit issue.

(C) (8600.0013) (PortApp) (Invalid vendor data from media device for port port_number)

Meaning: The switch could not read and verify the media module ID. This

may indicate a discovery error or a bad checksum in the serial ID. Other possibilities include an improperly installed media module or an internal media I/O hardware fault.

(C) (8600.0014) (PortApp) (Invalid vendor data from media device for port port_number)

Meaning: The switch could not read and verify the media module ID. This

could be caused by a media discovery error, a bad checksum in the media serial ID, an improperly installed media, or an internal media I/O hardware fault.

(C) (8600.0015) (PortApp) (Unresponsive device alpa on port port_number removed from

the fabric.)

Meaning: A device on the loop port did not take an OPN primitive of f the loop

destined for it. This suggests the device either has been physically removed or is faulty. In addition, it has been removed from the fabric nameserver.

S

(C) (8600.0016) (PortApp) (Online port(s) port_numbers were reset due to disruption during

hot reset.)

Meaning: Some ports were disrupted during the hot reset operation.

(C) (8600.0017) (PortApp) (External port license count exceeded, downing external port

port_number)

Meaning: The named external port is down because the number of licensed

external ports has been exceeded.

(C) (8600.0018) (PortApp) (External port license became available, re-starting downed

external ports)

Meaning: An external port that was previously down because of insufficient

port licenses is now online.

(C) (8600.0019) (PortApp) (Internal port license count exceeded, downing internal port

port_number)

Meaning: A device attempted to login to an internal port, but a license was

not available. A license upgrade may be required, or a lice nse may be released by downing ports.

3-56 59060-05 A

3 – Event Messages

A

(C) (8600.001A) (PortApp) (Internal port license became available, re-starting downed

internal ports)

Meaning: A license has become available and ports that had been previously

downed to due to unavailable licenses will be restarted.

(C) (8600.001B) (RX Seq Error D_ID sequence_destination S_ID sequence_source SEQ_ID

sequence_ID OX_ID originator_exchange RX_ID recipient_exchange CMPLT complete_status NFRAMES frame_count)

Meaning: An error was encountered while handling the receive sequence

referenced in the log message. Contact your authorized maintenance provider.

(C) (8700.0007) (EPort) (Port: port_number) (Received frame from address not in Access

Control List (ACL) hard zone (src address = FC_address, dest address = FC_address))

Meaning: The destination for the receive frame is in an ACL zone and the

source is not. The frame will not be forwarded.

Critical Events

(C) (8700.000D) (EPort) (Port: port_number) (Resetting Inter-Switch Link (ISL), a time out

value has been reconfigured.)

Meaning: The Resource Allocation (R_A_TOV) or Error Detect (E_D_TOV)

timeout value has been reconfigured. E_Ports will be automatically reset to inform the neighbor switch of the change.

(C) (8700.000E) (EPort) (Port: port_number) (InteropCredit value was reconfigured,

resetting port.)

Meaning: The InteropCredit parameter has changed. The affected port will

be automatically reset.

(C) (8700.000F) (EPort) (Port: port_number) (Broadcast frame received & broadcast

disabled, discarding broadcast frames.)

Meaning: Broadcast is disabled and the switch has received a broadcast

frame. Enable broadcast to receive broadcast frames.

(C) (8700.0010) (EPort) (Port: port_number) (Inter-Switch Link (ISL) unstable. ISL init will be

held back until ISL up time is 5 seconds)

Meaning: The ISL is unstable, indicating that the media module or the cable

is bad.

(C) (8700.0011) (Eport) (Port: port_number) (Connection failure, remote switch not

compatible)

Meaning: The remote switch is not compatible with the local switch. The

E_Port cannot exchange switch capabilities with the remote switch.

59060-05 A 3-57

3 – Event Messages Critical Events

(C) (8700.0012) (Eport) (Port: port_number) (Connection failure, fabric limited to two

switches)

Meaning: The switch cannot be connected to the fabric due to a license

restriction.

(C) (8700.0013) (Connection failure, fabric limited to two switches)

Meaning: The switch cannot be connected to the fabric due to license

restriction.

(C) (8B00.0005) (Unable to test profile profile because the CallHome service is disabled)

Meaning: The test of the named profile failed because the Call Home service

is disabled.

(C) (8B00.0006) (Unable to test profile because the CallHome service is disabled)

Meaning: The test of the named profile failed because the Simple Mail

Transfer Protocol (SMTP) server IP addresses are the factory defaults or the servers are disabled in the Call Home service configuration.

S

(C) (8B00.0007) (Unable to test profile profile because the FromEmailAddress has not been

configured in the CallHome setup)

Meaning: The test of the named profile failed because the

FromEmailAddress was not specified in the Call Home service configuration.

(C) (8B00.0008) (Unable to test profile profile because the CallHome service is updating

configuration)

Meaning: The profile cannot be tested while the Call Home service

configuration is being updated.

(C) (8B00.0009) (Unable to send test result for profile profile)

Meaning: The pass or fail notification for the test could not be sent to the

requestor.

(C) (8B00.000A) (Unable to provide profile processing information, the CallHome service

is updating configuration)

Meaning: Profile status information is not available while the Call Home

service configuration is being updated.

(C) (8B00.000B) (Unable to change SMTP servers because the CallHome service is

updating configuration)

Meaning: You cannot change the active Simple Mail Transfer Protocol

(SMTP) server while updating the Call Home service configuration.

3-58 59060-05 A

3 – Event Messages

A

(C) (8B00.000C) (FromEmailAddress has not been configured in the CallHome setup.

Messages cannot be sent to the SMTP server until this condition is corrected.)

Meaning: The FromEmailAddress must be specified in the Call Home service

configuration. This e-mail address will receive notifications from the Simple Mail Transfer Protocol (SMTP) servers concerning e-mail messages that could not be delivered.

(C) (8B00.0012) (Critical protocol failure with SMTP server)

Meaning: Communications have failed, or an unrecoverable Simple Mail

Transfer Protocol (SMTP) protocol error has occurred on the active SMTP server.

(C) (8B00.0014) (Successful recovery of SMTP communications)

Meaning: Communications have been re-established with one of the Simple

Mail Transfer Protocol (SMTP) servers following a communications failure.

Critical Events

(C) (8B00.0016) (SMTP server ip_address, port port_number, did not accept any recipients

from profile profile. Email message will not be sent for this profile.)

Meaning: The Simple Mail Transfer Protocol (SMTP) server does not

recognize or could not resolve any of the recipient e-mail addresses listed for the profile.

(C) (8F00.000C) Fabric Status

Meaning: The severity level of the fabric status has changed. The description

(C) (8F00.000D) Switch Status

Meaning: The severity level of the switch status has changed. The

(C) (8F00:000E) Link Status

Meaning: The severity level of the link status has changed. The description

status

field will show the reason for fabric status.

status

description field will show the reason for the switch status.

status

field will show the reason for the link status.

59060-05 A 3-59

3 – Event Messages Warning Events

Warning Events

Warning events are generally not disruptive, but are more significant than Informative-level events. The following lists the Warning events and the event ID number and message displayed, and provides an explanation of the message.

(W) (8300.0000) (User) (Releasing Lock held too long by account_name)

Meaning: A lock was held by a user for too long. The lock will be

automatically released.

(W) (8300.0011) (User) Releasing Lock held too long by domain_ID.

Meaning: A lock was held by another switch for too long. The lock will be

automatically released.

(W) (8300.0012) (User) SFC received with unknown operation operation_code.

Meaning: Received a frame from another switch with an unknown Staged

Fabric Configuration (SFC) operation code. Ignoring operation.

S

(W) (8300.0013) (User) Unlock failed, resource unavailable, will retry.

Meaning: A fabric unlock performed through a Release Change

Authorization failed because the switch ran out of buffer memory. The unlock mechanism will retry when memory is freed up.

(W) (8300.0014) (User) Bad release change authorization response received from switch

with domain ID domain_ID

Meaning: The switch is attempting to do a fabric unlock through a Release

Change Authorization request, but a remote switch indicated a failure. This switch will proceed with the unlock.

(W) (8300.0015) (User) No RCA response received from domain_ID, proceeding with unlock

Meaning: The switch never received a reply to a message sent to r elease the

change authorization. The release of the change authorization will occur regardless.

(W) (8300.0016) (User) Zoning activation failed, resource limitation

Meaning: This switch is attempting to activate a zone set but cannot do so

due to a resource problem.

(W) (8400.0007) (Switch) (Attempted unauthenticated login username account_name)

Meaning: A login was attempted with an account name that was not in the list

of allowable users of switch management.

3-60 59060-05 A

3 – Event Messages

A

(W) (8400.0018) (Switch) (User account_name login rejected - maximum logins already in

use)

Meaning: The attempted login was rejected because there are too many

sessions. There may be switch management sessions open on the switch that are no longer in use.

(W) (8400.001F) (Switch) (User account_name login rejected - maximum logins already in

use)

Meaning: The attempted login was rejected because there are too many

sessions. There may be switch management sessions open on the switch that are no longer in use.

(W) (8400.0020) (Switch) (User account_name login rejected - maximum logins already in

use)

Meaning: The attempted login was rejected because there are too many

sessions. There may be switch management sessions open on the switch that are no longer in use.

Warning Events

(W) (8400.0021) (Switch) (User account_name login rejected - maximum logins already in

use)

Meaning: The attempted login was rejected because there are too many

sessions. There may be switch management sessions open on the switch that are no longer in use.

(W) (8400.0034) (Switch) (Port port_number was Downed before hotreset due to excessive

errors - still DOWNED)

Meaning: A port was disabled by the threshold monitoring application before

the hot reset and is still disabled after the hot reset.

(W) (8400.0035) (Switch) (Retrying port port_number that was Downed due to excessive

errors)

Meaning: A port that was disabled by the threshold monitoring application is

periodically being retried to see if the error conditions have been cleared.

(W) (8400.003D) (Switch) (Invalid user (user_name) attempted to log into switch)

Meaning: Invalid user login attempt.

(W) (8400.007D) (Switch) (ntp: attempting to synchronize to server at ip_address]

Meaning: The switch is attempting to synchronize its time with the Network

Time Protocol (NTP) server at the specified IP address.

(W) (8700.0009) (EPort) (Port: port_number) (Inter-Switch Link (ISL) communication error)

Meaning: The remote switch has lost the local switch’s identity.

59060-05 A 3-61

3 – Event Messages Warning Events

(W) (8700.000A) (EPort) (Port: port_number) (No response from remote switch, resetting

Inter-Switch Link (ISL))

Meaning: No communication has been received from the remote switch for

some time, indicating that it may not be functioning properly. The E_Port will be reset in an attempt to reestablish the ISL.

(W) (8B00.000D) (SMTP servers in the CallHome setup are using dupli cate IP a ddress a nd

port number pairs)

Meaning: The Call Home service configuration must not duplicate both the

Simple Mail Transfer Protocol (SMTP) server IP address and port number values. However, the configuration may duplicate either the server IP address or the port number . For better fault tolerance, the SMTP servers should run on different physical systems. The port number value of 25 is the well-known service number for the SMTP protocol.

(W) (8B00.000E) (Message queue is empty, cancelling attempts to retry sending last

message)

Meaning: The Call Home service was waiting to resend a message when the

message expired, or there was a request to clear the queue of all messages.

S

(W) (8B00.000F) (Will retry sending via SMTP server ip_address, port port_number, after

seconds seconds)

Meaning: After a communication failure or Simple Mail Transfer Protocol

(SMTP) protocol error, the switch attempts to resend the e-mail message using the specified server, port, and delay.

(W) (8B00.0010) (Will retry sending via SMTP server ip_address, port port_number)

Meaning: After receiving a transient error from the Simple Mail Transfer

Protocol (SMTP) server on a e-mail message sent to a recipient, the Call Home service will attempt to resend the e-mail message.

(W) (8B00.0011) (SMTP addresses are defaults or disabled, will not retry sending

messages until a valid SMTP address has been configured and enabled)

Meaning: Either both Simple Mail Transfer Protocol (SMTP) server IP

addresses in the Call Home service configuration are the default value (0.0.0.0), or they have not been enabled.

3-62 59060-05 A

3 – Event Messages

A

(W) (8B00.0013) (Encountered failure communicating with SMTP server=ip_address,

port=port_number, Reason=reason, Description=description, Response=response)

Meaning: The Call Home Simple Mail Transfer Protocol (SMTP) client was

unable to establish communications with the specified SMTP server. The Reason, Description, and Response fields describe the error. If the error is a system call failure, the Description field provides more detail. If the error was an SMTP server response failure, the Response field provides more detail.

(W) (8B00.0015) (Profile profile, recipient email_address via SMTP server

ip_address/port_number, SMTP error: error)

Meaning: A Simple Mail Transfer Protocol (SMTP) error has occurred for the

given profile, recipient, server, and port.

(W) (8B00.0017) (CallHome message send for profile profile to recipient email_address

failed on SMTP server ip_address, port port_number. Retry will be attempted.)

Meaning: The Call Home service failed to send an e-mail message to the

recipient in the named profile through the specified Simple Mail Transfer Protocol (SMTP) server because of a transient error. The Call Home service will attempt to resend the message.

Warning Events

(W) (8B00.0018) (CallHome message send for profile profile to recipient email_address

failed on SMTP server ip_address, port port_number. Retry failed, ignoring recipient.)

Meaning: The Call Home service attempt to resend an e-mail message to the

recipient in the named profile through the specified Simple Mail Transfer Protocol (SMTP) server has failed. The Call Home service will not attempt to resend the message.

(W) (8B00.0019) (CallHome message send for profile profile to recipient email_address

failed on SMTP server ip_address, port port_number. Retry will not be attempted, ignoring recipient.)

Meaning: The Call Home service failed to send an e-mail message to the

recipient in the named profile through the specified Simple Mail Transfer Protocol (SMTP) server because of a non-transient error. The Call Home service will not attempt to resend the message.

(W) (8F00.000C) (Fabric Status status)

Meaning: The severity of the fabric status has changed. The description field

will show the reason for fabric status.

(W) (8F00.000D) (Switch Status status)

Meaning: The severity of the switch status has changed. The description field

will show the reason for the switch status.

59060-05 A 3-63

3 – Event Messages Informative Events

(W) (8F00:000E) (Link Status status)

Meaning: The severity of the link status has changed. The description field

will show the reason for link status.

S

Informative Events

Informative events are events that occur in the normal activities of a fabric. The following lists the event ID and text of the message along with an explanation of the message.

(I) (8200.0001) (mserver) (Hotreset is not permitted at this time, try again later)

Meaning: The switch was busy at the time of the attempted hot reset. Try the

hot reset again later.

(I) (8200.0002) (mserver) (Port: port_number) (Rejecting request from address FC_a ddress,

inband management is disabled on port port_number)

Meaning: A Management Server command was received on a port that is

configured to refuse inband management requests.

(I) (8200.0100) (mserver) (Cannot map number_of_characters characters to Switch

Symbolic Name (max number_of_characters))

Meaning: The RIELN management server command was processed, and the

Interconnect Element Logical Name was registered. However, the registered name is of greater length than the maximum length allowed for the Switch Symbolic Name, so therefore the Switch Symbolic Name was not changed to match the registered name.

(I) (8200.0101) (mserver) (Cannot map non-printable characters to Switch Symbolic Name)

Meaning: The RIELN management server command was processed, and the

Interconnect Element Logical Name was registered. However, the registered name contains unprintable characters. These characters are not allowed for the switch symbolic name, therefore the switch symbolic name was not changed to match the registered name.

(I) (8200.0200) (mserver) (Rejecting request (GZM) for zone zone_name containing

unsupported alias member(s)

Meaning: The fabric zone server command GZM (Get Zone Member) was

rejected because the requested zone member was an alias that is not defined in Fibre Channel General Services-3 (FC-GS-3).

3-64 59060-05 A

3 – Event Messages

A

(I) (8200.0201) (mserver) (Rejecting request command:command)

Meaning: A fabric zone server command was rejected for the reason detailed

in the message. This can be caused by two users attempting to configure the switch or zoning database at the same time. Cont act your authorized maintenance provider if the reason for the failure is not clear.

(I) (8200.0202) (mserver) (Rejecting request (GZS) for zone set zone_set_name containing

unsupported alias member(s))

Meaning: The fabric zone server command GZS (Get Zone Set) was rejected

because the requested zone set contains one or more members that are aliases. Since aliases are not defined in GS-3, the request could not be completed.

(I) (8200.0300) (mserver) (Cannot register HBA World Wide Name (WWN) device_WWN,

FDMI database has reached its configured limit.)

Meaning: The switch contains a database that is configured to allow a certain

number of HBAs to register Fabric Device Management Interface (FDMI) information with this switch. An HBA has attempted to register its FDMI information with the switch, but allowing it to do so would cause the FDMI database to exceed the configured limit.

Informative Events

(I) (8200.0301) (mserver) (Port: port_number) (Rejecting FDMI request from address

FC_address on port port_number; FDMI is configured as disabled.)

Meaning: The Fabric Device Management Interface (FDMI) server on this

switch has been disabled so any FDMI requests received by the switch will be rejected.

(I) (8300.0004) (zoning) (New Active ZoneSet zone_set_name)

Meaning: A new zone set has been activated.

(I) (8300.0007) (zoning) (Fabric lock held by domain domain_ID, hotreset not permitted)

Meaning: Another switch has acquired our fabric zoning lock; a zoning

request is about to occur. Retry a hot reset after the fabric zoning lock is released.

(I) (8300.0008) (zoning) (Processing zoning requests, Checkpoint not permitted)

Meaning: Another switch has acquired our fabric zoning lock; a zoning

request is about to occur. Retry a hot reset after the fabric zoning lock is released.

(I) (8300.0009) (Zoning) (Reading zoning database, Checkpoint not permitted)

Meaning: A change to the fabric zoning database forced a read of the

database to occur. Retry a hot reset after the read is complete.

59060-05 A 3-65

3 – Event Messages Informative Events

(I) (8300.0010) (Zoning) (Removing all inactive zoning objects)

Meaning: All zones that were members of the previously active zone set are

being removed from the zoning database.

(I) (8400.0001) (Switch) (Modifying configured DomainID domain_ID to negotiated value

domain_ID)

Meaning: The configuration is changing. The configured domain ID is

changed to the negotiated value.

(I) (8400.0006) (Switch) (Admin mode for user account_name was canceled by user

account_name)

Meaning: An Admin session was canceled by another user interface session

that had the authority to do so.

(I) (8400.001A) (Switch) (Admin access has timed out for user account_name)

Meaning: The Admin session opened by the named user has timed out due

to inactivity.

S

(I) (8400.0022) (Switch) (Successful login user account_name with admin privilege)

Meaning: A user with admin authority has successfully logged into the

switch. The IP address of the user is unknown.

(I) (8400.0023) (Switch) (Successful login user account_name with admin privilege from

address ip_address)

Meaning: A user with admin authority has successfully logged into the switch

with the specified IP address.

(I) (8400.0024) (Switch) (Successful login user account_name without admin privilege)

Meaning: A user without admin authority has successfully logged into the

switch. The IP address of the user is unknown.

(I) (8400.0025) (Switch) (Successful login user account_name without admin privilege)

Meaning: A user without admin authority has successfully logged into the

switch.

(I) (8400.0026) (Switch) (A zoning configuration edit session has been canceled)

Meaning: The zoning configuration edit session has been canceled as a

result of the Zoning Cancel command.

(I) (8400.002B) (Switch) (User login account_name is being closed - In-Band connections

have been disabled)

Meaning: The session has been closed as a result of a configuration change.

3-66 59060-05 A

3 – Event Messages

A

(I) (8400.002C) (Switch) (User login session session_ID user account_name has timed out)

Meaning: A user login session has ended because of inactivity.

(I) (8400.0036) (Switch) (Hotreset not permitted at this time, try again later)

Meaning: Conditions exist that will not allow a hotreset. Try again later.

(I) (8400.0037) (Switch) (VIEnable automatically set to False since MFSEnable h as been set

to True)

Meaning: Setting the Set Config Port parameter MFSEnable to True

automatically sets the Set Config Port parameters VIEnable and LCFEnable to False.

(I) (8400.0038) (Switch) (LCFEnable automatically set to False since MFSEnable has been

set to True)

Meaning: Setting the Set Config Port parameter MFSEnable to True

automatically sets the Set Config Port parameters VIEnable and LCFEnable to False.

Informative Events

(I) (8400.0039) (Switch) (MFSEnable automatically set to False since VIEnable has been set

to True)

Meaning: Setting the Set Config Port parameter VIEnable to True

automatically sets the Set Config Port parameter MFSEnable to False.

(I) (8400.003A) (Switch) (MFSEnable automatically set to False since LCFEnable has been

set to True)

Meaning: Setting the Set Config Port parameter LCFEnable to True

automatically sets the Set Config Port parameter MFSEnable to False.

(I) (8400.003E) (Switch) (Readjusting TempMonitoringWarning from value C to value C)

Meaning: The temperature threshold at which the switch issues a warning

alarm is being changed.

(I) (8400.0040) (Switch) (Readjusting TempMonitoringFailure from value C to value C)

Meaning: The temperature threshold at which the switch issues a failure

alarm is being changed.

(I) (8400.0048) (Switch) (A CIM edit session has been canceled)

Meaning: A Common Information Model (CIM) edit session has been

cancelled.

59060-05 A 3-67

3 – Event Messages Informative Events

(I) (8400.008C) (CallHome configuration has changed)

Meaning: The Call Home service configuration was changed by the

administrator.

(I) (8400.0097) (DNS lookup for host_name failed)

Meaning: The specified host name was not found on the Domain Name

System (DNS) server. Verify that the host name is correct. If so, report the failed host name to your network administrator.

(I) (8600.0007) (PortApp) (Port: port_number) (Cancelling Online Test)

Meaning: The online test was canceled.

(I) (8600.001C) (Bring down TH port because its mapped TF port port_number goes offline)

Meaning: The state of a Transparent Host port has changed to Downed

because the state of the specified active mapped Transparent Fabric port has changed to Offline.

(I) (8600.001D) (PortID port_fcid PortWWN port_wwn logged into nameserver.)

S

Meaning: The device given by the port Fibre Channel address and port WWN

has logged in to the name server.

(I) (8600.001E) (PortID port_fcid PortWWN port_wwn logged out of nameserver)

Meaning: The device given by the port Fibre Channel address and port WWN

has logged out of the name server.

(I) (8600.001F) (SYNC_ACQ)

Meaning: The port identified in previous event messages has acquired

synchronization with a connected device.

(I) (8600.0020) (SYNC_LOSS)

Meaning: The port identified in subsequent event messages has lost

synchronization with a connected device.

(I) (8700.0002) (EPort) (In Fabric Reconfiguration)

Meaning: Changes to the switch configuration are in progress.

(I) (8700.0003) (EPort) (Topology change, switch with domain ID domain_ID joined the

fabric)

Meaning: A switch with the given domain ID has joined the fabric.

(I) (8700.0004) (EPort) (Port: port_number) (Remote Switch World Wide Name (WWN) is

switch_WWN)

Meaning: A switch with the given domain ID has been discovered on the

given port.

3-68 59060-05 A

3 – Event Messages

A

(I) (8700.0005) (EPort) (Port: port_number) (Inter-Switch Link (ISL) Offline)

Meaning: The specified E_Port is offline, possibly due to a loss of

synchronization.

(I) (8700.0006) (EPort) (Port: port_number) (Reinitializing port previously isolated for

reason reason)

Meaning: The E_Port that previously isolated for the stated reason is now

reinitializing.

(I) (8700.0008) (EPort) (Link State Record (LSR) aged out for domain ID =domain_ID)

Meaning: A record in the Link State Database (LSDB) is being aged out. It

will no longer be in the LSDB.

(I) (8700.000B) (EPort) (Hotreset prohibited, fabric is busy.)

Meaning: A hot reset is not possible when configuration changes are being

made anywhere in the fabric.

(I) (8700.000C) (EPort) (Hotreset prohibited, fabric is busy.)

Informative Events

Meaning: A hot reset is not possible when configuration changes are being

made anywhere in the fabric.

(I) (8F00.0006) Fabric Removed

Meaning: The user has removed a fabric from the application.

(I) (8F00.0007) Switch Added

Meaning: The application fabric discovery process has discovered a new

switch in the fabric.

(I) (8F00.0008) Switch Removed

Meaning: The user has removed a switch from the display.

(I) (8F00.0009) Link Added

Meaning: The application fabric discovery process has discovered a new

inter-switch link (ISL) in the fabric

(I) (8F00.000A) Link Removed

Meaning: A link has been removed from the display. This is either because

the fabric discovery process has discovered that the link is no longer in the fabric, or because the user has deleted the link manually.

(I) (8F00.000B) Login Changed

Meaning: The login to the fabric has changed. The description field will show

the reason for the change in the login.

59060-05 A 3-69

3 – Event Messages Informative Events

(I) (8F00.000C) Fabric Status status

Meaning: The severity of the fabric status has changed. The description field

will show the reason for fabric status.

(I) (8F00.000D) Switch Status status

Meaning: The severity of the switch status has changed. The description field

will show the reason for the switch status.

(I) (8F00:000E) Link Status status

Meaning: The severity of the link status has changed. The description field

will show the reason for link status.

S

3-70 59060-05 A

Q-Logic Fibre Channel Switch User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

1 Introduction

Intended Audience

Related Materials

Technical Support

Availability

Training

Contact Information

2 Events and Event Logging

Understanding Severity Levels

Displaying Events using the Event Browser

Displaying the Events Using the Command Line Interface

Configuring the Event Log

Archiving and Downloading the Event Log

Configuring Port Alarm Thresholds

3 Event Messages

Fault Events

Alarm Events

Critical Events

Warning Events

Informative Events
