Pure Siesta Flow User Manual
Owner’s Manual
Version 1.0
Copyright
Copyright 2009 by Imagination
Technologies Limited. All rights
reserved. No part of this publication
may be copied or distributed,
transmitted, transcribed, stored in
a retrieval system, or translated into
any human or computer language, in
any form or by any means, electronic,
mechanical, magnetic, manual or
otherwise, or disclosed to third parties
without the express written permission
of Imagination Technologies Limited.
Portions Copyright ©2004 Intel
Corporation.
Copyright
Copyright 2009 by Imagination
Technologies Limited. Alle Rechte
vorbehalten. Kein Teil dieser Publikation
darf ohne ausdrückliche und schriftliche
Zustimmung von Imagination
Technologies Limited in irgendeiner
Form (elektronisch, mechanisch,
magnetisch, manuell oder auf andere
Weise) kopiert, verteilt, übermittelt,
überschrieben, in einem Suchsystem
gespeichert, in eine andere natürliche
oder Computersprache übersetzt oder
Dritten zugänglich gemacht werden.
Copyright
Copyright 2009 Imagination
Technologies Limited. Tous droits réser
vés. Aucune par tie de la présente
publication ne doit être copiée ou
diffusée, transmise, retranscrite,
stockée dans un système de
récupération de données ou traduite,
que ce soit dans une langue humaine
ou dans un langage informatique, sous
quelque forme et par quelque moyen
que ce soit, électronique, mécanique,
magnétique, manuel ou autre, ou
encore dif fusée auprès de tiers
sans autorisation écrite expresse de
Imagination Technologies Limited.
Copyright
Copyright 2009 by Imagination
Technologies Limited. Tutti i diritti
riservati. Nessuna parte della presente
pubblicazi può essere copiata o
distribuita, trasmessa, trascritta,
memorizzata in un sistema di archiviazi,
o tradotta in un formato normalmente
comprensibile, in qualsiasi forma o
con qualsiasi mezzo, elettronico,
meccanico, magnetico, manuale o
altro, o divulgata a terze parti senza
il permesso scritto di Imagination
Technologies Limited.
Copyright
Copyright 2009 tilhører Imagination
Technologies Limited. Alle rettigheder
forbeholdes. Ingen dele af denne
publikation må kopieres eller
distribueres, transmitteres, omskrives,
gemmes i et system, hvor den
kan hentes, eller oversættes til
menneskeligt forståeligt sprog eller
computersprog, i nogen som helst
form eller med nogen som helst midler,
det være sig elektroniske, mekaniske,
magnetiske, manuelle eller på anden
måde, eller fremvises til tredje parter
uden udtrykkelig, skriftlig tilladelse fra
Imagination Technologies Limited.
Copyright
Copyright 2009 por Imagination
Technologies Limited. Reservados
todos los derechos. Ninguna parte
de esta publicación puede copiarse o
distribuirse, transmitirse, transcribirse,
almacenarse en un sistema de
recuperación, o traducirse a ningún
idioma humano o informático, de
ninguna forma o por ningún medio, ya
sea electrónico, mecánico, magnético,
manual o de otro tipo, ni revelarse a
terceras partes sin el consentimiento
explícito por escrito de Imagination
Technologies Limited.
Trademarks
Siesta Flow, the Siesta Flow logo,
PURE, the PURE logo, PURE, the
PURE logo, Imagination Technologies,
and the Imagination Technologies
logo are trademarks or registered
trademarks of Imagination Technologies
Limited. The Wi-Fi CERTIFIED Logo is a
certification mark of the Wi-Fi Alliance.
All other product names are trademarks
of their respective companies. Version
1 2009.
Warenzeichen
Siesta Flow, das Siesta Flow Logo,
PURE, das PURE Logo, PURE, das
PURE Logo, Imagination Technologies
und das Imagination Technologies Logo
sind Warenzeichen oder eingetragene
Warenzeichen von Imagination
Technologies Limited. Alle anderen
Produktnamen sind Warenzeichen ihrer
jeweiligen Besitzer. Version 1 2009.
Marques commerciales
Siesta Flow, le logo Siesta Flow,
PURE, le logo PURE, PURE, le logo
PURE, Imagination Technologies et le
logo Imagination Technologies sont
des marques commerciales ou des
marques déposées de Imaginat ion
Technologies Limited. Tous les autres
noms de produits sont des marques
commerciales de leurs détenteurs
respectifs. Version 1 2009.
Marchi
Siesta Flow, il logo Siesta Flow, PURE,
il logo PURE, PURE, il logo PURE,
Imagination Technologies e il logo
Imagination Technologies sono marchi
o marchi registrati di Imagination
Technologies Limited. Tutti gli altri nomi
di prodotti sono marchi di proprietà
delle rispettive società. Version 1 2009.
Varemærker
Siesta Flow, Siesta Flow-logoet,
PURE, PURE-logoet, PURE, PURElogoet, Imagination Technologies og
Imagination Te chnolog ie s - logoe t
er var emær ker el ler r eg i s t r er ede
varemærker, der tilhører Imagination
Technologies Limited. Al le andr e pr
oduk t navne er var emær ker, der t i
lhør er deres respektive virksomheder.
Version 1 2009.
Marcas comerciales
Siesta Flow, PURE, el logotipo Siesta
Flow, el logotipo PURE, Imagination
Technologies y el logotipo Imagination
Technologies son marcas comerciales
o marcas comerciales registradas de
Imagination Technologies Limited.
Todos los demás nombres de
productos son marcas comerciales de
sus respectivas compañías. Versión
1de 2009
2
Siesta Flow Owner’s Manual v1.0
Warranty information
Imagination Technologies Ltd. warrants to the end user that this product will be free from defects in materials
and workmanship in the course of normal use for a period of two years from the date of purchase. This
guarantee covers breakdowns due to manufacturing or design faults; it does not apply in cases such as
accidental damage, however caused, wear and tear, negligence, adjustment, modification or repair not
authorised by us. Please visit www.pure.com/register to register your product with us. Should you have a
problem with your unit please contact your supplier or contact PURE Support at the address shown on the
rear of this manual. If you need to return your product please use the original packaging and include all parts
and accessories. We reserve the right to refuse incomplete or badly packaged returns.
Disclaimer
Imagination Technologies Limited makes no representation or warranties with respect to the content of this
document and specifically disclaims any implied warranties of merchantability or fitness for any particular
purpose. Further, Imagination Technologies Limited reserves the right to revise this publication and to make
changes in it from time to time without obligation of Imagination Technologies Limited to notify any person or
organization of such revisions or changes.
Acknowledgement of License Agreements
Portions of the code used in Siesta Flow are subject to the following GPL and LPGL licenses and copyright:
GNU General Public License Version 2 (GPLv2). For the full text of the license agreement go to:
http://www.gnu.org/licenses/gpl-2.0.txt
GNU Lesser General Public License Version 2.1 (LGPLv2.1). For the full text of the license agreement go to:
http://www.gnu.org/licenses/lgpl-2.1.txt
3
Siesta Flow Owner’s Manual v1.0
Safety instructions
Keep the radio away from heat sources.
Do not use the radio near water.
Avoid objects or liquids getting into the radio.
Do not remove screws from or open the radio casing.
Fit the AC adaptor plug to an easily accessible socket,
located near the radio and ONLY use the AC power
adapter supplied.
Istruzioni di sicurezza
Tenere la radio lontana da fonti di calore.
Non utilizzare la radio vicino all’acqua.
Evitare che oggetti o liquidi penetrino nella radio.
Non rimuovere le viti né aprire l’involucro della radio.
Collegare l’adattatore di rete ad una presa della
corrente facilmente accessibile, situata vicino alla
radio e utilizzare ESCLUSIVAMENTE l’adattatore di
rete fornito.
Sicherheitshinweise
Halten Sie das Radio fern von Heizquellen.
Benutzen Sie das Radio nicht in der Nähe von Wasser.
Verhindern Sie, dass Gegenstände oder Flüssigkeiten
in das Radio gelangen.
Entfernen Sie keine Schrauben vom Gehäuse und
öffnen Sie dieses nicht.
Schließen Sie das Netzteil an eine leicht erreichbare
Steckdose in der Nähe des Radios an, und benutzen
Sie AUSSCHLIESSLICH das mitgelieferte Netzteil.
Consignes de sécurité
Tenir la radio éloignée de toute source de chaleur.
Ne pas utiliser la radio à proximité d’un point d’eau.
Éviter que des objets ou des liquides ne pénètrent à
l’intérieur de la radio.
Ne pas ouvrir le boîtier de la radio ou en enlever les vis.
Branchez l’adaptateur sur une prise de courant
facilement accessible, à proximité de la radio et utilisez
UNIQUEMENT l’adaptateur fourni.
Sikkerhedsforskrifter
Hold radioen på afstand af varmekilder.
Brug ikke radioen i nærheden af vand.
Undgå at der kommer genstande eller væske i
radioen.
Fjern ikke skruer fra og åbn ikke radiokabinettet.
De bør tilslutte strømforsyningen til et lettilgængeligt
strømudtag tæt på radioen. De bør KUN bruge den
medfølgende strømforsyning. S
Veiligheidsinstructies
Houd de radio uit de buurt van warmtebronnen.
Gebruik de radio niet in de buurt van water.
Vermijd dat voorwerpen of vloeistoffen in de radio
terechtkomen.
Verwijder geen schroeven uit de omkasting van de
radio en open het niet.
Steek de lichtnetadapter in een gemakkelijk
toegankelijk stopcontact in de buurt van de radio en
gebruik ALLEEN de meegeleverde spanningsadapter
voor het lichtnet.
4
Siesta Flow Owner’s Manual v1.0
Information about internet radio and broadband download limits
You should be aware that listening to internet radio stations, listen again programmes,
podcasts and PURE sounds will contribute towards any download limit on your broadband
account set by your Internet Service Provider (ISP). You can find out if you have a download
limit on your broadband account by checking the terms and conditions of your account
or by contacting your ISP. Please note that listening to DAB or FM, or streaming your own
music files using the ‘Media player’ source, will not contribute towards any download limit
on your account.
Help! I see ‘Time not available’
If you see the message ‘Time not available’ when the radio is in standby you need to select
‘DAB’ audio source and connect to acquire the current time. Providing you have a signal,
Siesta Flow will keep the time up-to-date.
You can also receive the current time by connecting to your wireless network.
5
Siesta Flow Owner’s Manual v1.0
Contents
Contents
1 Discover Siesta Flow 8
1.1 Here’s what you’ll need 8
1.2 Switching on Siesta Flow for the first time 8
1.3 Key phrases used in this manual 9
1.4 Overview of controls and connectors 10
1.5 Quick guide to the display 12
1.6 Quick guide to common functions 12
1.7 Using Fast Scroll 13
1.8 About the PURE Lounge 14
2 Listening to DAB radio 15
2.1 Switching to DAB Radio source 15
2.2 Changing the station 15
2.3 Using presets 16
2.4 Options available in DAB source 17
3 Listening to Internet radio and more 18
3.1 Connecting Siesta Flow to your wireless network for the first time 18
3.2 Listening to and searching for online audio content 21
3.3 Opening groups of items 24
3.4 Adding and viewing your Favourites 24
3.5 Pausing and seeking 25
3.6 Options available in The Lounge source 26
3.7 Wi-Fi settings 26
3.8 Setting up Media player for the first time 28
4 Listening to Media player 28
4.1 Playing albums, tracks and playlists 29
4.2 Skipping, pausing and seeking within tracks 30
4.3 Searching for an artist, track or album 31
4.4 Options available in Media player source 32
6
Contents Siesta Flow Owner’s Manual v1.0
5 Listening to FM radio 33
5.1 Selecting the ‘FM radio’ audio source 33
5.2 Changing the station 33
5.3 Using presets 33
5.4 Options available in FM source 34
6 Listening to an Auxiliary device 35
6.1 Connecting an auxiliary device 35
6.2 Selecting the Auxiliary input source 35
7 Alarms, Timers and Universal options 36
7.1 Setting the sleep timer 36
7.2 Setting alarms 37
7.3 Snoozing and cancelling an alarm 38
7.4 Changing the information shown on screen 38
7.5 Adjusting the screen brightness 40
7.6 Upgrade your radio’s firmware 40
7.7 Factory reset 41
8 Help and advice 42
8.1 Steps to ensure successful connection to your wireless network 42
8.2 Steps to ensure successful listening to online audio content 42
8.3 Steps to ensure successful media streaming 42
8.4 Steps to ensure successful DAB and FM radio listening 43
9 Technical specifications 44
7
Contents Siesta Flow Owner’s Manual v1.0
1 Discover Siesta Flow
Welcome to Siesta Flow, a connected clock radio.
This chapter explains how to get your new radio up and running, outlines the controls and explains
some phrases used in this manual.
Discover Siesta Flow
1.1 Here’s what you’ll need
To listen to online audio content (internet radio, listen again programmes, podcasts and PURE
sounds) and stream your music collection you’ll need the following:
A broadband internet connection (minimum speed 0.5 MB). If you already surf the web at
home, then your internet connection is active and working correctly.
A wireless router, also called a wireless access point.
If your network is secured, you’ll need the WEP, WPA or WPA2 key or password for your
network (for help see ‘Help! What is a WEP key?’ on page 19.).
A registration code from the Lounge, PURE’s online gateway to connected audio.
To get a registration code, visit www.thelounge.com and click on ‘Connect my PURE radio’
to register your details and receive a registration code by e-mail. You’ll be asked to enter this
code into your Siesta Flow as part of the setup process.
1.2 Switching on Siesta Flow for the first time
1 Uncoil the aerial wire fully.
2 Insert the connector of the supplied mains adapter into the AC power input on the underside of
the radio.
3 Plug the mains plug into the mains supply.
4 The Siesta Flow screen is displayed for a short period.
5 The Select time zone region screen is displayed. tap the and keys on your radio to
highlight your region, then tap select to enter it. The next screen asks you to select time
zone location, use the same process to choose the location closest to you.
6 The Source screen is displayed, which shows the five audio sources you can listen to on Siesta
Flow. Each audio source is explained in a separate chapter of this manual: 2 Listening to DAB
radio; 3 Listening to internet radio and more; 4 Listening to Media player; 5 Listening to FM radio; 6
Listening to an Auxiliary device.
7 To get started, tap Select to select ‘DAB radio’ and read the rest of this chapter for an overview
of how to operate the product.
8
Discover Siesta Flow Siesta Flow Owner’s Manual v1.0
1.3 Key phrases used in this manual
The following key phrases and associated illustrations are used in this manual:
‘Highlight’ Tap the up and down buttons on your Siesta Flow until the
desired item is highlighted.
BBC Radio 2
BBC Radio 3
BBC Radio 4
BBC Radio 5Live
BBC Radio 6Music
‘Select’ Tap the Select button on your radio to select the desired item.
BBC Radio 4
Missed an item? You can
listen to the program again
via our website
Presets Options
‘Press’ Press and release the indicated button on your radio.
‘Press and
Hold your finger on the desired button until the action is complete.
Most often used in relation to the context-sensitive buttons.
Hold’
Sussex Breakfast: 20/08/08
Paused: 00:08.50
Options
9
Discover Siesta Flow Siesta Flow Owner’s Manual v1.0
1.4 Overview of controls and connectors
1.4a Quick guide to top panel
Source
Select audio
source
Source
Standby
Standby
Switch between
standby and on
1.4b Quick guide to front panel
Alarms 1-4
Set or cancel alarms
3
SNOOZE
Snooze an alarm
Sleep
Set sleep
timer
Sleep
Volume
−+
Volume +/−
Adjust the audio
volume
10
1 Light sensor. Adjusts the display
brightness according to the light levels in
your room (operates when the Brightness
level is set to ‘Automatic’). Make sure the
sensor is not covered or blocked.
2 Context-sensitive buttons. The function
is displayed on screen above the relevant
button and changes depending on the
current screen.
3 Navigation/Select buttons. Tap to Navigate
menus and select options.
4 Back button. Tap to go back one step.
Discover Siesta Flow Siesta Flow Owner’s Manual v1.0
1.4c Underside Connectors and Serial
number location
1 USB connector (mini-B type) for
upgrading the radio’s firmware when
a wireless internet connection is not
available.
2 Power connector for supplied mains
lead.
3 Serial number (needed for registering
your radio with the Lounge).
1.4d Side panel
1 3.5mm headphone socket
2 PowerPort
for compatible USB accessories
5.5V DC
1.4e Top
1 3.5mm AUX IN socket
11
Standby
Source
3
Sleep
Volume
−+
Discover Siesta Flow Siesta Flow Owner’s Manual v1.0
1.5 Quick guide to the display
The clock is automatically set and updated. If you cannot see the time, tune to a DAB station,
access a broadcast from The Lounge or use Media Player for a few minutes
Icon bar (from left to right):
Now Playing/menu name
The latest news headlines
Info display area
Presets Options
BBC Radio 2
from BBC Radio 2
Context-sensitive options
Audio source: DAB, (the Lounge),
MP (Media player), FM or AUX (Auxiliary
input).
Volume level
Alarm/timer set indicator
Clock
Stereo indicator
Signal strength bar: shows signal
strength when listening to DAB or FM;
wireless signal strength when listening to
the Lounge or Media Player
1.6 Quick guide to common functions
How to change the audio source
Siesta Flow has five audio sources: DAB radio, the Lounge
(online audio content), Media player, FM radio and Auxiliary
input. To change the audio source:
1 Press Source on your Siesta Flow , alternatively tap
Back until the Source screen is displayed.
2 Press the Source button again or use the navigation
buttons to highlight and select a new audio source.
Using the Back key to go back up to a previous menu
Tap Back when browsing stations and other content, or when in a menu, to go up to
the previous screen. Press and hold at any time to return to the ‘now playing’ screen
for the currently selected audio source.
DAB radio
The Lounge
Media player
FM radio
Auxiliary input
The source screen
Back, as on the front panel
of Siesta Flow
12
Discover Siesta Flow Siesta Flow Owner’s Manual v1.0
About the context-sensitive buttons
Siesta Flow has three context-sensitive buttons. The function is displayed above the button and changes
depending on what you are listening to or which menu is active. If there is no option displayed above a button,
then that button has no function in the current screen.
BBC Radio 2
The latest news headlines
from BBC Radio 2
Presets Options
The context-sensitive buttons, with
two on-screen choices, Presets and
Options
1.7 Using Fast Scroll
Fast Scroll makes it quicker and easier to browse through large lists of radio stations, listen again
programmes and podcasts, which can sometimes be thousands of items in length.
Using Fast Scroll to quickly scroll down a list of content
1 To start Fast Scroll press and hold a navigation button to scroll either up or down a list. The list
will begin to scroll slowly in the chosen direction as indicated by the arrows in the scroll bar to
the right.
2 The scroll speed will increase as the button is held down
Clube FM 100.5
Clubtec Radio
Fast scroll in action, scrolling down
(note scroll bar arrows)
Clyde 1 102.5FM
Crazy House Radio
Europe 2 Rock Classics
Search
3 Spotted a station that looks interesting? Stop Fast Scroll by releasing the button.
4. Highlight and select the station you want to listen to or start Fast Scroll again as described
above. When you reach the end of a list Fast Scroll will ‘wrap around’ to the beginning again.
When using Fast Scroll to browse a list of online audio content you may see the message
Note
‘Loading...’ instead of the station name. This happens because the list is scrolling faster
than items can be collected over your wireless network.
13
Discover Siesta Flow Siesta Flow Owner’s Manual v1.0
1.8 About the PURE Lounge
To get the most from Siesta Flow connect your radio to the PURE Lounge (www.thelounge.com), your
online gateway to the world of online audio content. The Lounge contains thousands of internet radio
stations, podcasts and listen again programmes available to listen to wherever you’re in range of your
wireless network. Visit the Lounge now to register your details and connect your radio to receive a
registration code, which is required to enjoy all the features of the Lounge and to save an unlimited
number of your favourite stations on your Siesta Flow.
the Lounge
home page
14
Discover Siesta Flow Siesta Flow Owner’s Manual v1.0
Loading...
