Prima PRDO 202, PRDO 204, PRDO 205, PRDO 203 Features List

PRDO 202/203
PRDO 204/205

Feature List

Top cavity
1 Temperature selector.
2 Function selector.
3 Heating indicator light. Indicates that the

heat is going to the food and it goes out
when the set temperature is reached.

Main cavity
4 Electronic clock.
5 Function selector.
6 Temperature selector.
7 Heating indicator light.
8 Fan oven + temperature selector.

Model PRDO204/PRDO205

Model PRDO202/PRDO203

Control Panel

Oven Functions

3 2 1 4 8 7

1 2 3 4 57 6

Model PRDO204/PRDO205

Top cavity: / / / /

Main cavity:

Model PRDO202/PRDO203

Top cavity: / / / /

Main cavity:

////

Switch off oven

Conventional

It is used for sponges and cakes where the
heat received must be uniform to achieve a
spongy texture.

Lower Element

Heats only from beneath. Suitable for heating
dishes and raising pastry and similar.

2

3

ENGLISH

Model PRDO204/PRDO205
Setting the Time on the Clock

On connecting the oven you will notice that
daytime flashes on the display, starting from
0:00 and the auto symbol A flashes.

Press the “+” and “-” buttons simultaneously
and then pressing the “+” or “-” buttons the
correct time can be set on the display.

Manual Use

After setting the correct time, the oven is ready
for use. The symbol is illuminated on the dis­play. Select a temperature and a cooking func­tion.

To switch off the oven, set the controls to the

position.

Warning Function

This function generates a buzzer interval alarm
signal at a specified time.

1 Press the MODE button until the symbol

begins to flash.

2 Choose the time when you want the alarm to

sound, pressing the “+” or “-” buttons.

Use of the Oven

MaxiGrill

Allows greater surfaces to be prepared, than
with the grill, together with higher power
reducing the time required for browning of the
food.

Grill

For preparing dishes with superficial roasting.
It allows the outer layer to be browned without
affecting the inside of the food. Ideal for flat
food, such as steaks, ribs, fish, toast.

MaxiGrill with fan

Allows uniform roasting at the same time as
surface browning. Ideal for grills. Special for
large volume pieces, such as poultry game
etc. It is recommended to put the item on a
rack with a tray beneath to collect the stock
and juices.

Caution

While using the Grill, MaxiGrill or MaxiGrill with
fan, the door must be kept closed.

Turbo

The fan distributes the heat produced by an
element located at the rear of the oven. Due
to the uniform heat distribution, it allows
roasting and baking to take place on two
levels at the same time.

Defrosting

This cooking mode is suitable for gentle
defrosting of delicate food to be consumed
unheated, e.g.: cream, custard, pastry, tarts,
cakes, fruit,...

Note

The pilot light remains on in any cooking
function.

3 Subsequently, the symbol will remain on

indicating that the alarm is programmed.

4 At the end of the programmed time, an

acoustic interval signal will sound and
the symbol will begin to flash.

5 Press any button to turn off the acoustic

signal.

The buzzer signal frequency can be changed by
MINUS in 3 circular steps. For listening to the
actual valid signal, press “-” button for some
seconds while the display reads the time of
the day. Every new key press within the time
window changes the buzzer signal. Now this
tone is valid as program end alarm signal.

Programming the Cooking Time

This function allows to programme the oven to
cook for a specified time, after which it will
switch itself off.

1 Press the MODE button until the display

automatically switches over between “dur”
display and duration time setting mode. The
symbol A is flashing.
