Assembly Instructions
S3.15/S3.19
Leg Press Option
S3.15/S3.19 Leg Press Option Assembly Instructions
page 2
IMPORTANT SAFETY INSTRUCTIONS
Important Safety Instructions
Important Safety Instructions
Before beginning any fitness program, see your
physician for a complete physical examination.
Il est conseillé de subir un examen médical complet
avant d’entreprendre tout programme d’exercise. Si
vous avez des étourdissements ou des faiblesses,
arrêtez les exercices immédiatement.
When using exercise equipment, basic precautions
should always be taken, including the following:
• Read all instructions before using the Leg Press
Option equipment. These instructions are written
for your safety and to protect the unit.
• Do not allow children or those unfamiliar with its
operation on or near the equipment. Do not leave
children unsupervised around the unit.
• Use the equipment only for its intended purpose as
described in this manual. Do not use accessory
attachments that are not recommended by the
manufacturer, as such attachments may cause
injuries.
• Wear proper exercise clothing and shoes for your
workout and avoid loose clothing. Tie long hair
back.
• Use care when getting on or off the unit.
• Do not overexert yourself or work to exhaustion.
• If you feel any pain or abnormal symptoms,
stop your workout immediately and consult
your physician.
• Never operate the unit when it has been dropped
or damaged. Return the equipment to a service
center for examination and repair.
• Never drop or insert objects into any opening.
Keep hands away from moving parts.
• Always check the unit and its cables before each
use. Make sure that all fasteners and cables are
secure and in good working condition.
• Do not use outdoors.
Personal Safety During Assembly
• It is strongly recommended that a qualified
dealer assemble the equipment.
Assistance is
required.
• Read each step in the assembly instructions and
follow the steps in sequence. Do not skip ahead. If
you skip ahead, you may learn later that you have
to disassemble components and that you may
have damaged the equipment.
• Assemble and operate the Leg Press Option on a
solid, level surface. Locate the unit a few feet from
walls or furniture to provide easy access.
Obtaining Service
Do not attempt to service the Leg Press
Option yourself except for the maintenance
tasks described in this guide. This unit does
not contain any user-serviceable parts.
For information about product operation,
or service, refer to the Precor web site at
www.precor.com. Should you need more
information regarding customer support
numbers or a list of Precor authorized
service centers, visit the Precor web site
at www.precor.com/cons.
If you call or e-mail Customer Support,
have the serial number and part numbers
available.
You can find the serial number printed on
a label affixed to the base of the Leg Press
Option. For future reference, write the serial
number in the space provided below.
Serial number: _______________________
S3.15/S3.19 Leg Press Option Assembly Instructions
page 3
Table of Contents
1
2
3
Important Safety Instructions ....................................................................... 2
Personal Safety During Assembly ........................................................................................... 2
Obtaining Service .................................................................................................................... 2
Before You Begin ........................................................................................... 4
Unpacking the Equipment ....................................................................................................... 4
Preparations................................................................................................... 5
Required Tools ......................................................................................................................... 5
Installation Requirements ........................................................................................................ 5
Assembly Tips ......................................................................................................................... 5
Assembly Instructions .................................................................................. 6
1. Attach the Leg Press to the Main Unit .......................................................................... 7
2. Assemble the Seat Pads and Handle ........................................................................... 8
3. Install the Leg Press Arm and Footrest ........................................................................ 9
4. Install the Leg Press Cable ........................................................................................... 10
Warranty .........................................................................................................12
Limited Warranty Statement .................................................................................................... 12
Warranty Registration Card ..................................................................................................... 13
Specifications ............................................................................................................. Back cover
4
Table of Contents
S3.15/S3.19 Leg Press Option Assembly Instructions
page 4
1
Before You Begin
Before You Begin
Thank you for purchasing the Leg Press Option. This
option will add a new dimension to your strengthtraining regimen. For proper installation, please read
this guide thoroughly and follow the assembly
instructions.
Unpacking the Equipment
The Leg Press Option is carefully tested and inspected
before shipment. Precor Strength ships the unit in
several pieces that require assembly. Ask for
assistance during the assembly process.
• Review the
Installation Requirements
.
• Carefully unpack the pieces and lay them on the
floor near the location where you plan to use the
equipment.
If any items are missing, contact the dealer from whom
you purchased the unit. For more information, refer to
Obtaining Service
.
S3.15
Leg Press Option
The S3.15 is shown throughout these assembly instructions.
S3.15/S3.19 Leg Press Option Assembly Instructions
page 5
2
Preparations
Preparations
You must review and follow the instructions in this
guide. If you do not assemble and use the Leg Press
Option according to the following guidelines, you could
void the Precor Limited Warranty.
Required Tools
Tools that you need to obtain before assembling the
unit include:
❏ ⁹⁄₁₆-inch socket
❏ ³⁄₄-inch socket
❏ ⁹⁄₁₆-inch box-end wrench
❏ ³⁄₄-inch box-end wrench
❏ Crescent wrench
❏ Wire tie cutter (cuts plastic tie wraps)
❏ Utility knife
Installation Requirements
Follow these installation requirements when
assembling the unit:
• Fill out and mail the warranty registration card.
• Set up the Leg Press Option on a solid, flat
surface. A smooth, flat surface under the unit
helps keep it level.
• Provide ample space around the machine.
Open space around the machine allows for easier
access.
• Insert all fasteners in the same direction. For
aesthetic purposes, insert all the fasteners in the
same direction unless specified (in text or
illustrations) to do otherwise.
• Leave room for adjustments. Tighten fasteners
(such as screws, nuts, and bolts), so the unit is
stable, but leaves room for adjustments. Do not
fully tighten fasteners until instructed (in the steps)
to do so.
Assembly Tips
• Fasteners may become loose and fall off during
shipment. Inspect the plastic wrap and packaging
for loose parts. To alleviate confusion during
assembly, reattach the loose fasteners and pulleys
found in the packaging.
• A black 6-inch scale with white numbers is
provided at the bottom of every assembly
instruction page. Use this scale to identify the
correct fastener size. The head of a fastener is not
used in measuring the length.
• Most fasteners are ³⁄₈-inch unless otherwise noted.
To find out the length of a particular fastener,
measure its shank (the long, narrow part beneath
the head). Refer to the following diagram:
• Zinc fasteners are used with the titanium parts.
Black fasteners are used when assembling the
stone gray painted surfaces.
• Most fasteners are fitted to the frame or pulley, you
will need to disassemble the fasteners before
proceeding with each step. Some pieces have
extra holes that you will not use. Use only those
holes indicated in the instructions and illustrations.
• Read all caution notes on each page before
completing that step.
• While you may be able to assemble the Leg Press
Option by reading the illustrations only, refer to the
text for important safety cautions and notes. The
S3.15 is shown throughtout the assembly
instructions. If you purchased the S31.9, the Leg
Press Option assembly is identical.
Fastener head
Fastener threads
Shank
To determine the
length of a fastener,
measure its shank.
