Powerware 9355 Parallel UPS
®
10/15 kVA
User’s Guide
Class A EMC Statements
FCC Part 15
NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
ICES-003
This Class A Interference Causing Equipment meets all requirements of the Canadian Interference Causing
Equipment Regulations ICES-003.
Cet appareil numérique de la classe A respecte toutes les exigences du Reglement sur le matériel brouilleur du
Canada.
IEC 62040-2
Some configurations are classified under IEC 62040-2 as “Class-A UPS for Unrestricted Sales Distribution.” For
these configurations, the following applies:
WARNING This is a Class A-UPS Product. In a domestic environment, this product may cause radio interference, in
which case, the user may be required to take additional measures.
Powerware, ABM, and Powerware Hot Sync are registered trademarks and X-Slot and LanSafe are trademarks of
Eaton Power Quality Corporation.
Greenlee is a registered trademark of Greenlee Textron.
ECopyright 2005 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be
reproduced in any way without the express written approval of Eaton Corporation.
Requesting a Declaration of Conformity
Units that are labeled with a CE mark comply with the following harmonized standards and EU directives:
S Harmonized Standards: IEC 62040-1-1 and IEC 62040-2; IEC 60950 Third Edition
S EU Directives: 73/23/EEC, Council Directive on equipment designed for use within certain voltage limits
The EC Declaration of Conformity is available upon request for products with a CE mark. For copies of the EC
Declaration of Conformity, contact:
Eaton Power Quality Oy
Koskelontie 13
FIN-02920 Espoo
Finland
Phone: +358 -9-452 661
Fax: +358 -9-452 665 68
93/68/EEC, Amending Directive 73/23/EEC
89/336/EEC, Council Directive relating to electromagnetic compatibility
92/31/EEC, Amending Directive 89/336/EEC relating to EMC
Special Symbols
The following are examples of symbols used on the UPS or accessories to alert you to important
information:
RISK OF ELECTRIC SHOCK - Indicates that a risk of electric shock is present and the
associated warning should be observed.
CAUTION: REFER TO OPERATOR’S MANUAL - Refer to your operator’s manual for
additional information, such as important operating and maintenance
instructions.
This symbol indicates that you should not discard the UPS or the UPS batteries
in the trash. This product contains sealed, lead-acid batteries and must be
disposed of properly. For more information, contact your local recycling/reuse or
hazardous waste center.
This symbol indicates that you should not discard waste electrical or electronic
equipment (WEEE) in the trash. For proper disposal, contact your local
recycling/reuse or hazardous waste center.
ON - Indicates that the switch is in the ON position.
OFF - Indicates that the switch is in the OFF position.
PHASE - The word “phase.”
Table of Contents
1 Introduction 1.........................................................
2 Safety Warnings 3.....................................................
3 UPS Setup 7..........................................................
Inspecting the Equipment 7................................................................
Floor Loading 8........................................................................
Clearances 8..........................................................................
Unloading the Cabinet(s) 9................................................................
Three-High Cabinets or Two-High EBMs 9...................................................
Two-High UPS Cabinets 13..............................................................
4 Parallel Installation 17...................................................
5 Installing Options 27....................................................
Powerware Hot Sync CAN Bridge Card 28......................................................
6 Stabilizing the Cabinet 33................................................
7 Extended Battery Module Installation 37.....................................
8 Operation 41...........................................................
Control Panel Functions 41.................................................................
Changing the Language 42..............................................................
Display Functions 42...................................................................
User Settings 44......................................................................
Initial Startup 46........................................................................
Configuring the UPS f or EBMs 47............................................................
Parallel System Shutdown 48...............................................................
Individual UPS Shutdown 49................................................................
Restarting the Parallel System 50............................................................
9 Parallel Bypass 51......................................................
10 Troubleshooting 53......................................................
Typical Alarms and Conditions 53............................................................
Silencing the Alarm 55....................................................................
Service and Support 56...................................................................
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
i
TABLE OF CONTENTS
ii
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Chapter 1 Introduction
A parallel system with up to four uninterruptible power supplies (UPSs)
can be installed to provide a parallel capacity and/or redundant system.
This load sharing system provides more capacity than a single UPS and
can provide backup, depending on the load and configuration. In
addition, when one UPS is taken out of service for maintenance or is not
operating properly, a redundant UPS continues to supply uninterrupted
power to the critical load. A parallel Powerware
Area Network (CAN) Bridge Card provides connectivity for system
metering and operational mode control. The parallel system consists of
two to four UPSs, each with a parallel CAN Bridge Card and a parallel
cabinet.
Figure 1 shows the Powerware 9355 UPS and an optional Extended
Battery Module (EBM).
®
Hot Sync®Computer
Figure 1. The Powerware 9355 UPS and EBM (3-High Cabinets Shown)
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
1
INTRODUCTION
2
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Chapter 2 Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions that you should follow during installation and
maintenance of the UPS and batteries. Please read all instructions before operating the
equipment and save this manual for future reference.
This UPS contains LETHAL VOLTAGES. All repairs and service should be performed by
AUTHORIZED SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE PARTS
inside the UPS.
S This UPS contains its own energy source (batteries). The UPS output may carry live
voltage even when the UPS is not connected to an AC supply.
S To reduce the risk of fire or electric shock, install this UPS in a temperature and humidity
controlled, indoor environment, free of conductive contaminants. Ambient temperature
must not exceed 40°C (104°F). Do not operate near water or excessive humidity (95%
maximum).
S To reduce the risk of fire, connect only to a circuit provided with 100 amperes maximum
branch circuit overcurrent protection in accordance with the National Electrical Code,
ANSI/NFPA 70.
S Output overcurrent protection and disconnect switch must be provided by others.
DANGER
WARNING
CAUTION
S Batteries can present a risk of electrical shock or burn from high short circuit current.
Observe proper precautions. Servicing should be performed by qualified service
personnel knowledgeable of batteries and required precautions. Keep unauthorized
personnel away from batteries.
S Proper disposal of batteries is required. Refer to your local codes for disposal
requirements.
S Never dispose of batteries in a fire. Batteries may explode when exposed to flame.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
3
SAFETY WARNINGS
Consignes de Sécurité
CONSIGNES DE SÉCURITÉ IMPORTANTES
CONSERVER CES INSTRUCTIONS
CE MANUEL CONTIENT DES CONSIGNES DE SÉCURITÉ
IMPORTANTES
Cet onduleur contient des TENSIONS MORTELLES. Toute opération d’entretien et de
réparation doit être EXCLUSIVEMENT CONFIÉE A UN PERSONNEL QUALIFIÉ AGRÉÉ.
AUCUNE PIÈCE RÉPARABLE PAR L’UTILISATEUR ne se trouve dans l’onduleur.
S Cet onduleur renferme sa propre source d’éner gie (batteries). Les prises de sortie
S Pour réduire les risques d’incendie et de décharge électrique, installer l’onduleur
S La protection contre une surintensité pour le(s) circuit(s) de sortie de courant alternatif
S Les interrupteurs de déconnexion convenables pour le(s) circuit(s) de sortie de courant
DANGER!
WARNING
peuvent être sous tension même lorsque l’onduleur n’est pas branché sur le secteur.
uniquement à l’intérieur, dans un lieu dépourvu de matériaux conducteurs, où la
température et l’humidité ambiantes sont contrôlées. La température ambiante ne doit
pas dépasser 40 °C. Ne pas utiliser à proximité d’eau ou dans une atmosphère
excessivement humide (95 % maximum).
doit être fournie par un autre fournisseur.
alternatif doivent être fournie par un autre fournisseur.
ATTENTION!
S Les batteries peuvent présenter un risque de décharge électrique ou de brûlure par des
courts-circuits de haute intensité. Prendre les précautions nécessaires.
S Une mise au rebut réglementaire des batteries est obligatoire. Consulter les règlements
en vigueur dans votre localité.
S Ne jamais jeter les batteries au feu. L’exposition aux flammes risque de les faire
exploser.
4
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Advertencias de Seguridad
INSTRUCCIONES DE SEGURIDAD IMPORTANTES
GUARDE ESTAS INSTRUCCIONES
ESTE MANUAL CONTIENE INSTRUCCIONES DE SEGURIDAD
IMPORTANTES
Este SIE contiene VOLTAJES MORTALES. Todas las reparaciones y el servicio técnico deben
ser efectuados SOLAMENTE POR PERSONAL DE SERVICIO TÉCNICO AUTORIZADO. No hay
NINGUNA PARTE QUE EL USUARIO PUEDA REPARAR dentro del SIE.
S Este SIE contiene su propia fuente d e energía (las baterías). Los receptáculos de salida
pueden transmitir corriente eléctrica aun cuando el SIE no esté conectado a un
suministro de corriente alterna (c.a.).
S Para reducir el riesgo de incendio o de choque eléctrico, instale este SIE en un lugar
cubierto, con temperatura y humedad controladas, libre de contaminantes conductores.
La temperatura ambiente no debe exceder los 40°C. No trabaje cerca del agua o con
humedad excesiva (95% máximo).
S La protección contra exceso de corriente para el/los circuito(s) de CA de salida será
suministrada por terceros.
S Los interruptores de desconexión debidamente clasificados para el/los circuito(s) de CA
de salida serán suministrados por terceros.
SAFETY WARNINGS
PELIGRO
WARNING
PRECAUCIÓN
S Las baterías pueden presentar un riesgo de descargas eléctricas o de quemaduras
debido a la alta corriente de cortocircuito. P reste atención a las instrucciones
correspondientes.
S Es necesario desechar las baterías de un modo adecuado. Consulte las normas locales
para conocer los requisitos pertinentes.
S Nunca deseche las baterías en el fuego. Las baterías pueden explotar si se las expone a
la llama.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
5
SAFETY WARNINGS
6
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Chapter 3 UPS Setup
This chapter describes:
S Equipment inspection
S Floor loading and clearances
S Unloading the cabinet(s)
The instructions are intended for the chief operator/system supervisor,
electrical consultants, and installation electricians. Local regulations and
electrical code must be followed during the UPS installation.
Inspecting the Equipment
If any equipment has been damaged during shipment, keep the shipping
and packing materials for the carrier or place of purchase and file a claim
for shipping damage. If you discover damage after acceptance, file a
claim for concealed damage.
To file a claim for shipping damage or concealed damage: 1) File with
the carrier within 15 days of receipt of the equipment; 2) Send a copy of
the damage claim within 15 days to your service representative.
NOTE Check the battery recharge date on the packaging label. If the date has expired and
the batteries were never recharged, do not use the UPS. Contact your service representative.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
7
UPS SETUP
Floor Loading
When planning the installation, consider the UPS weight for floor
loading. The strength of the installation surface must be adequate for
point and distributed loadings. The approximate weights are shown in
the following table.
Standard Model Floor Loadings (2-High/3-High Cabinets)
Clearances
Powerware 9355
2-High UPS 381 lb (173 kg) 95 (6.7)
3-High UPS-32 587 lb (266 kg) 147 (10.3)
3-High UPS-64 619 lb (281 kg) 155 (10.9)
2-High EBM 480 lb (218 kg) 120 (8.4)
3-High EBM 710 lb (322 kg) 178 (12.5)
Maximum
Weight
Point Loading
2
lb/in
(kg/cm2)
The following clearances are recommended for the Powerware 9355
UPS:
From Front of Cabinet 36” (91.4 cm) working space
From Back of Cabinet 6” (15.2 cm)
8
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Unloading the Cabinet(s)
The following tools are required for unloading the cabinet(s):
S 15 mm wrench or socket
S 7 mm nut driver or socket
The UPS and Extended Battery Module (EBM) are heavy (see page 8). Unloading the
cabinets requires at least two people to safely remove the cabinets from the pallet.
To unload three-high cabinets or two-high EBMs, continue to the
following section. To unload two-high UPS cabinets, proceed to page 13.
Three-High Cabinets or Two-High EBMs
To remove a three-high cabinet or a two-high EBM from the shipping
pallet:
1. Remove the two M10 bolts securing the stabilizing bracket to the
pallet (see Figure 2).
UPS SETUP
CAUTION
M10 Bolts
Figure 2. Removing the Stabilizing Bracket Bolts
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
9
UPS SETUP
2. Remove the four M4 screws securing the stabilizing bracket to the
cabinet rear panel and remove the bracket (see Figure 3). Retain the
hardware for later use.
NOTE Be sure to retain the stabilizing bracket and hardware for later re-assembly onto the
cabinet.
3. Remove the front cover from the bottom cabinet to access the
front shipping bracket.
Press and release the handle latch at the bottom of the cover and
then lift the cover up and off the cabinet.
4. Remove the three M10 bolts securing the rear shipping pad to the
pallet and remove the shipping pad.
10
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
UPS SETUP
NOTE Hold the back of the cabinet so that the bolts can be removed easily without the
cabinet rolling backward.
5. Remove the two M10 bolts securing the front shipping bracket and
remove the bracket.
If needed, adjust the leveling feet to release the bracket.
Front Shipping
Bracket
M10 Bolts
Stabilizing Bracket
M10 Bolts
M4 Screws
Shipping Pad
Figure 3. Removing the Brackets and Shipping Pad
6. Reinstall the front cover removed in Step 3.
Hang the top edge of the cover on the cabinet first, then lower the
bottom edge and snap into place.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
11
UPS SETUP
NOTE Be sure to support the front and back of the cabinet when rolling it off the pallet to
prevent tipping.
7. Slowly roll the cabinet toward the rear of the pallet. Once the pallet
tilts, continue rolling the cabinet down the pallet until the cabinet
touches the floor (see Figure 4).
If needed, adjust the leveling feet so that the cabinet will roll.
12
Figure 4. Unloading the Cabinet
8. With the cabinet supported, slowly pull the pallet away from the
cabinet (see Figure 5).
Figure 5. Removing t he Pallet
9. Roll the cabinet to the desired location.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
UPS SETUP
Two-High UPS Cabinets
To remove a two-high UPS from the shipping pallet:
1. Remove the M10 bolt securing the vertical bracket to the pallet (see
Figure 6).
2. Remove and retain the three M4 screws securing the vertical
bracket to the UPS. Remove the vertical bracket.
M4 Screws
M10 Bolt
Figure 6. Removing t he Vertical Bracket
3. Reinstall the M4 screws to the UPS (see Figure 7).
M4 Screws
Figure 7. Reinstalling the M4 Screws
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
13
UPS SETUP
4. Repeat Steps 1 through 3 to remove the vertical bracket on the
other side.
5. Remove the front cover from the bottom cabinet to access the
front shipping bracket.
Press and release the handle latch at the bottom of the cover and
then lift the cover up and off the cabinet.
6. Remove the three M10 bolts securing the rear shipping pad to the
pallet and remove the shipping pad (see Figure 8).
NOTE Hold the back of the cabinet so that the bolts can be removed easily without the
cabinet rolling backward.
7. Remove the two M10 bolts securing the front shipping bracket and
remove the bracket.
If needed, adjust the leveling feet to release the bracket.
Front Shipping
Bracket
14
M10 Bolts
M10 Bolts
Shipping Pad
Figure 8. Removing the Front Shipping Bracket and Shipping Pad
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
UPS SETUP
8. Reinstall the front cover removed in Step 5.
Hang the top edge of the cover on the cabinet first, then lower the
bottom edge and snap into place.
NOTE Be sure to support the front and back of the cabinet when rolling it off the pallet to
prevent tipping.
9. Slowly roll the cabinet toward the rear of the pallet. Once the pallet
tilts, continue rolling the cabinet down the pallet until the cabinet
touches the floor (see Figure 9).
If needed, adjust the leveling feet so that the cabinet will roll.
Figure 9. Unloading the Cabinet
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
15
UPS SETUP
10. With the cabinet supported, slowly pull the pallet away from t he
cabinet (see Figure 10).
Figure 10. Removing the Pallet
11. Roll the cabinet to the desired location.
16
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Chapter 4 Parallel Installation
The Powerware 9355 has the following power connections:
S 3-phase (L1, L2, and L3), neutral, and ground connection for
rectifier/bypass input
S 3-phase (L1, L2, and L3), neutral, and ground connection for load
output
The nominal input/output voltages are:
S 120/208 or 127/220 Vac
Output overcurrent protection and disconnect switch must be provided
by others.
Figure 19 and Figure 20 beginning on page 25 show the oneline
diagrams.
Only qualified service personnel (such as a licensed electrician) should perform the UPS
installation and initial startup. Risk of electrical shock.
To hardwire the parallel system:
WARNING
1. Verify that the electrical connections to the installation site have
been properly installed.
2. A wall-mounted, user-supplied, readily-accessible disconnection
device must be incorporated in the input wiring.
Compare the circuit breaker ratings to the ones in Table 1 on
page 21.
NOTE To accommodate the feature of easy system expandability, it is recommended that
initial installation of the Powerware 9355 UPS contain wiring to support the maximum
capacity of the UPS cabinet.
3. Switch off utility power to the distribution point where the parallel
tie cabinet and UPSs will be connected. Be absolutely sure there is
no power.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
17
PARALLEL INSTALLATION
4. Determine your equipment’s grounding requirements according to
your local electrical code.
5. Remove the parallel tie cabinet front cover (see Figure 11).
Figure 11. Parallel Tie Cabinet Front Cover
18
6. Remove the internal cover to gain access to the breakers (see
Figure 12).
Internal
Cover
Figure 12. Internal Cover
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
PARALLEL INSTALLATION
7. Punch holes for the conduit (AC input, UPS output, load connection,
®
and maintenance bypass contact wires) using a Greenlee
punch or
similar device.
8. Verify that the parallel bypass breaker is in the OFF position (see
Figure 13).
9. Mount the parallel tie cabinet to the wall and install the conduit.
Figure 13. Parallel Bypass Breaker
10. Verify that each UPS battery circuit breaker is in the OFF position
(see Figure 14).
11. From each UPS, remove the UPS wiring access cover and one of
the conduit landing plates and retain.
12. Punch two holes in the conduit landing plate for the input and
output conduit using a Greenlee punch or similar device.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
19
PARALLEL INSTALLATION
Battery Circuit Breaker
UPS Wiring
Access Cover
20
Conduit Landing Plates
Figure 14. UPS Rear View (3-High Shown)
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
PARALLEL INSTALLATION
p
120lbin
p
120lbin
p
120lbin
p
120lbin
13. Hardwire the UPS input terminations.
See Table 1 for specifications and Figure 15 for a detailed view of
the UPS terminal block.
NOTE Input neutral must be wired for proper operation. Failure to connect an input neutral
will void the warranty.
NOTE The Powerware 9355 UPS is a single-feed UPS only.
Table 1. UPS Terminal Block Wiring
10 kVA
Input Voltage
208
220
208
220
15 kVA
Input Voltage
208
220
208
220
1
Use only 90°C-rated copper wire. Minimum wire size is based on 120/208 full load ratings applied to NEC Code
Wire
Function
Input
Output
Wire
Function
Input
Output
Input Circuit
Breaker Size
45A
45A
Input Circuit
Breaker Size
60A
60A
L1, L2, L3, N
Wire Size
1
Ground
Wire Size
6AWG 10 AWG
8AWG 10 AWG
8AWG 10 AWG
8AWG 10 AWG
L1, L2, L3, N
Wire Size
1
Ground
Wire Size
4AWG 10 AWG
4AWG 10 AWG
6AWG 10 AWG
6AWG 10 AWG
Tightening
1
Tightening
1
Torque
(13.5 Nm)
(13.5 Nm)
Torque
(13.5 Nm)
(13.5 Nm)
Conduit Size
(Number of Conduits)
1.00” conduit (1)
1.00” conduit (1)
Conduit Size
(Number of Conduits)
1.25” conduit (1)
1.25” conduit (1)
1.00” conduit (1)
2, 3
2, 3
Table 310-16. Code may require a larger AWG size than shown in this table because of temperature, number of
conductors in the conduit, or long service runs. Wire l engths should be the same size. Follow local requirements.
2
Per NEC article 300-20(a), all three-phase conductors must be run in the same conduit. Neutral and ground must be
run in the same conduit as the phase conductors.
3
Conduit is sized to accommodate one neutral conductor the same size as the phase conductor and one #8 AWG
ground conductor. If two neutral conductors or an oversized neutral conductor are to be installed, check the size of the
conduit needed to accommodate the extra wire or size and use that conduit size in place of the conduit size listed.
Conduit sizes were chosen from NEC Table C1, type letters RHH, RHW, RHW-2, TW, THW, THHW, THW-2.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
21
PARALLEL INSTALLATION
Maintenance
Bypass
Contacts
TB2
Ground
Figure 15. UPS Terminal Block (3-High Shown)
14. Hardwire the output terminations from the UPS t o the parallel tie
cabinet (see Figure 16).
22
Ground
Neutral
Line 1
Line 2
Line 3
Figure 16. UPS Output to Parallel Tie Cabinet Wiring
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
PARALLEL INSTALLATION
15. Hardwire the load to the parallel tie cabinet (see Figure 17).
16. Wire the maintenance bypass contacts and terminate t o the
maintenance bypass wires in the parallel tie cabinet (see Figure 15).
Connect the black and the red wire to TB2 on the UPS. Cap the
blue wire.
NOTE The maintenance bypass contacts are normally-open. To ensure proper bypass
operation, DO NOT use the blue wire (it is normally-closed).
17. Replace the UPS wiring access cover and conduit landing plate.
18. Repeat Steps 12 through 17 for each UPS.
Maintenance Bypass
Wiring to UPS TB2
Ground
Line 1
Line 2 Line 3
Figure 17. Load Connections
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Neutral
23
PARALLEL INSTALLATION
19. Wire the AC input to the bypass breaker (see Figure 18).
Line 1
Line 2
Line 3
Figure 18. Bypass AC Input Wiring
24
20. Verify the phase rotation for each UPS and the bypass input.
21. Reinstall the internal cover removed in Step 6.
22. Reinstall the parallel tie cabinet front cover removed in Step 5.
23. Continue to “Installing Options” on page 27.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Bypass Input
From UPS 1 Output
From UPS 2 Output
From UPS 3 Output
From UPS 4 Output
225A Breaker
Auxiliary Contacts
225A
80A (4X)
Figure 19. Parallel Wiring Diagram
PARALLEL INSTALLATION
Red Wire
(open when breaker is open)
Black Wire
(common)
Blue Wire
(closed when breaker is open)
LOAD
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
25
PARALLEL INSTALLATION
26
*
Figure 20. Parallel UPS Schematic
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Chapter 5 Installing Options
This section describes the Powerware Hot Sync CAN Bridge Card.
For other options, such as additional X-Slot
LanSafe
(REPO), relay output contacts, or programmable signal inputs, refer to
the Powerware 9355 UPS (10/15 kVA) User’s Guide.
Figure 21 shows the location of the communication options and control
terminals on the UPS.
X-Slot Communication Bay #1
Signal Input 1
X-Slot Communication Bay #2
Signal Input 2
REPO (normally open)
REPO (normally closed)
DB-9 Communication Port
Relay Output Contacts
t cards, Powerware
t Power Management Software, remote emergency power-off
Signal Input 2
Wiring
1
2
1
2
1
2
1
2
1
2
3
Figure 21. Communication Options and Control Terminals
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
27
INSTALLING OPTIONS
Powerware Hot Sync CAN Bridge Card
The Powerware Hot Sync CAN Bridge Card, shown in Figure 22, can be
installed to provide connectivity for operational mode control and
metering of a parallel system at any UPS in the system.
Figure 22. Powerware Hot Sync CAN Bridge Card
To install the Powerware Hot Sync CAN Bridge Card:
1. Remove the front covers of all cabinets, starting with the top
cabinet.
Plug-In Terminal Block
28
Press and release the handle latch at the bottom of each cover and
then lift the cover up and off the cabinet (see Figure 23).
Figure 23. Removing the Front Covers
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
INSTALLING OPTIONS
2. Strip shielded, four-wire, twisted-pair wire for CAN Bridge Card
wiring. Recommended wire size is 18 AWG maximum.
3. Install the CAN Bridge Card wiring between each UPS (see
Figure 24). Be sure to check correct polarity for Pins 8 and 9:
S Connect SHIELD Pin 10 on all cards together.
S Connect CAN H Pin 9 and CAN L Pin 8 (twisted pair) on all cards
together.
S Connect COM Pin 4 and NC Pin 3 (twisted pair) on all cards
together.
4. Wire the factory-installed pull-chain wiring to Signal Input 2 on each
UPS and daisy chain the wiring to each UPS as shown in Figure 24.
Be sure to check correct polarity:
S Connect COM Pin 4 to Signal Input 2 Pin 1 on each UPS.
S Connect NC Pin 3 to Signal Input 2 Pin 2 on each UPS.
CAUTION
If polarity or wiring is not correct, the parallel system does not operate normally. For
example, when shutting down one UPS, the remaining UPS transfers the load to bypass
instead of supporting the load. Verify all CAN Bridge Card wiring is correct for proper
operation.
NOTE Signal Input 2 can still be used for building alarms; it is automatically rerouted to
the CAN Bridge Card.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
29
INSTALLING OPTIONS
SHIELD
CAN H
CAN L
TX
TX
NO
COM
NC
ALM RTN
ALARM
10
9
8
7
6
5
4
3
2
1
1
2
1
2
1
2
1
2
J3
J5
UPS #1 UPS #2 UPS #3 UPS #4
30
Figure 24. CAN B ridge Card Wiring
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
INSTALLING OPTIONS
5. On the bottom cover (and also the middle cover if 3-high), remove a
knockout tab in the top edge of the cover for each cable:
With wire cutters, cut either side of the tab and twist down to
remove the tab (see Figure 25).
Figure 25. Removing Knockout Tabs
6. Route the cable(s) to the approximate location of the cover access
holes.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
31
INSTALLING OPTIONS
7. Reinstall the front covers, starting with the bottom cabinet (see
Figure 26).
Hang the top edge of the cover on the cabinet first, then lower the
bottom edge and snap into place. Be sure the cables fit in the
access holes in the covers.
32
Figure 26. Reinstalling t he Front Covers
8. Continue to “Stabilizing the Cabinet” on page 33 to complete the
parallel UPS installation.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Chapter 6 Stabilizing the Cabinet
NOTE For seismic installations, you MUST order and install a Powerware 9355 UPS
seismic kit; do not use the following instructions.
NOTE For non-seismic installations, you MUST install the stabilizing bracket on all 3-high
cabinets. The stabilizing bracket is optional for 2-high cabinets.
To stabilize the cabinet(s):
1. Lower the leveling feet to prevent the cabinet from rolling.
Figure 27. Lowering the Leveling Feet
2. Attach the stabilizing bracket to the bottom of the cabinet rear panel
using the retained hardware from the shipping pallet according to
the cabinet configuration:
S For one cabinet, see Figure 28.
S For two cabinets, see Figure 29.
S For three cabinets, see Figure 30.
NOTE No more than three cabinets can be attached together. For four cabinets, use two of
the two-cabinet installations. For five cabinets, use one three-cabinet and one two-cabinet
installation.
3. Use the holes and slots in the bottom of the bracket to attach the
cabinet to the flooring if desired.
4. Continue to one of the following sections:
S “Extended Battery Module Installation” on page 37 to install
optional EBMs.
S “Operation” on page 41 to start up the parallel UPS system.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
33
STABILIZING THE CABINET
M4 Screws
34
Figure 28. Stabilizing Bracket with One Cabinet
M4 Screws
Figure 29. Stabilizing Bracket with Two Cabinets
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
STABILIZING THE CABINET
M4 Screws
Figure 30. Stabilizing B racket with Three Cabinets
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
35
STABILIZING THE CABINET
36
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Chapter 7 Extended Battery Module Installation
NOTE A maximum of 22 battery strings can be installed in one configuration, including
UPS batteries (4 EBM-64 models or 3 EBM-96 models). UPS-32 models contain 2 strings;
UPS-64 models contain 4 strings; EBM-64 models contain 4 strings; and EBM-96 models
contain 6 strings.
NOTE For non-seismic installations, you MUST install the stabilizing bracket on all 3-high
cabinets. The stabilizing bracket is optional for 2-high cabinets.
NOTE In a parallel system, each UPS should have the same number of Extended Battery
Modules (EBMs) to ensure equivalent runtimes.
To install the optional EBM:
1. Position the EBM adjacent to the next cabinet.
2. Verify that all battery circuit breakers are in the OFF position (see
Figure 31).
3. Remove the two ground straps from the EBM rear panel.
4. Install one ground strap between the UPS and EBM rear panels as
shown in Figure 31.
5. If additional EBMs are installed, attach another ground strap
between the first and second EBM as shown in Figure 31. Repeat
for each additional EBM.
6. Plug the EBM cable into the UPS battery connector.
7. If additional EBMs are installed, plug the EBM cable of the second
cabinet into the battery connector on the first EBM. Repeat for each
additional EBM.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
37
EXTENDED BATTERY MODULE INSTALLATION
EBM Battery
Circuit Breaker
Rear Ground Strap
EBM Cable
EBM Battery Connector
Figure 31. Typical EBM Installation (2-High Cabinets Shown)
UPS Battery Connector
UPS Battery Circuit Breaker
38
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
EXTENDED BATTERY MODULE INSTALLATION
8. Remove the top front covers of all cabinets.
Press and release the handle latch at the bottom of the cover and
then lift the cover up and off the cabinet.
9. Install the remaining ground straps between each cabinet (see
Figure 32).
10. Reinstall the top front covers removed in Step 8.
Hang the top edge of the cover on the cabinet first, then lower the
bottom edge and snap into place.
11. Continue to “Operation” on page 41 to start up the UPS.
NOTE After UPS startup, ensure maximum battery runtime by configuring the UPS for the
correct number of EBMs (see page 47).
Front Ground Strap
Figure 32. Front Ground Strap Installation (2-High Cabinets Shown)
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
39
EXTENDED BATTERY MODULE INSTALLATION
40
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Chapter 8 Operation
This chapter contains information on how to use the Powerware 9355,
including front panel operation, UPS startup and shutdown, and
configuring the UPS for Extended Battery Modules (EBMs).
Control Panel Functions
The UPS has a four-button graphical LCD with backlight. It provides
useful information about the UPS itself, load status, events,
measurements, and settings (see Figure 33).
for the LCD Menu Options
Power On Indicator (green)
On Battery Indicator (yellow)
Bypass Indicator (yellow)
Alarm Indicator (red)
Control Buttons
Figure 33. Powerware 9355 Control Panel
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
41
OPERATION
The following table shows the indicator status and description.
Indicator Status Description
On The UPS is operating normally.
Green
Yellow
Yellow
Red
Flashing
Off The UPS is turned off and will not turn on automatically.
On The UPS is in Battery mode.
On The UPS is in Bypass mode.
On The UPS has an active alarm.
Flashing There is a new UPS alarm condition. See “Troubleshooting” on page 53 for
S The UPS is starting up or is shut down and waiting for power to return.
S A new information message is active.
S Bypass is not available.
additional information.
Changing the Language
Press and hold the first button on the left for approximately five seconds
to select the language menu. This action is possible from any LCD menu
screen.
Display Functions
As the default or after 15 minutes of inactivity, the LCD displays the
selectable startup screen. The default is the Eaton Powerware logo and
can be changed to the Mimic screen in the User Settings menu.
42
The backlit LCD automatically dims after a long period of inactivity. Press
any button to restore the screen.
Use the two middle buttons (
structure. Press the
button to enter a submenu. Press the button
to select an option. Press the
and ) to scroll through the menu
ESC
button to cancel or return to the
previous menu.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
OPERATION
The following table shows the basic menu structure.
Table 2. Menu Map for Display Functions
Main Menu Submenu Display Information or Menu Function
UPS Status System normal / Battery floating UPS in Parallel mode / Parallel
Unit Number x / Units on CAN Bus / Units on l oad
Event Log Displays up to 100 events and alarms
Measurements
Parallel System Voltage [by unit] / Voltage [Parallel total] / Output Voltage: L-N /
Output Voltage L-L / Output Current / Output Frequency / Output
Power
Output L-N and L-L / Current / Frequency / Power
Battery Voltage / Current / Runtime
Input L-N and L-L / Current / Frequency
Bypass L-N and L-L / Frequency
Control
Go to Bypass Mode Transfers the UPS system to internal Bypass mode
When this command is active, the option changes to Go to Normal
Mode.
Start Battery Test Initiates a battery test
Display Test Four different selectable tests for the front panel functions: the
LEDs cycle through, the alarm beep sounds, the backlight turns off
and on, and the pixels scroll through to test the LCD.
Settings
User Settings See Table 3 for detail.
Service Settings This screen is password-protected.
Identification UPS Type / Part Number / Serial Number / Firmware / Display /
CAN Bridge
Turn UPS ON/OFF ON and OFF Options UPS Off / System On / System Off
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
43
OPERATION
User Settings
The following table displays the options that can be changed by the
user.
NOTE Changes to the output voltage or frequency options should be made before turning
on the UPS; otherwise, the changes do not take effect.
Table 3. User Settings
Description Available Settings Default Setting
Set Date and Time Set Month
Date: mm/dd/yyyy
Time: 24:00
Display Contrast Adjust contrast with up/down arrow buttons Moderate
01/01/2003
00:00
Change Language Select Language: <English>
Elegir idioma <Español>
Set NominalOutput Voltage Output:
[120V/208V] [127V/220V]
Relay Config Relay: [Alarm 1] [X-Slot 1-1/2/3/4] or
[X-Slot 2-1/2/3/4]
Setup: [Battery Low] [On Battery] [On
Bypass] [UPS ok] [custom] [empty]
Signal Inputs [empty] [Logic]
Signal Input must be wired to the CAN Bridge
Card (see Figure 24 on page 30).
For more information, refer to “Programmable
Signal Inputs” in the Powerware 9355 UPS
(10/15 kVA) User’s Guide.
Serial Port Config Port: [X-Slot-1] [X-Slot-2/Serv]
Speed: [19200] [9600] [2400] [1200]
Modem Config
Modem Installation <Not Installed>
Set Modem Call Events Event #0
Set Modem Init String ATZ0
Set Modem Call Command None
English
120V/208V
Alarm1:empty
X-Slots(1or2)
#1: UPS ok
#2: On Bypass
#3: Summary Alarm
#4: On Battery
<empty>
19200
Call modem: no
44
Set Modem Communication Password None
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Table 3. User Settings (continued)
OPERATION
Default SettingAvailable SettingsDescription
Start Screen Eaton Powerware logo
Eaton Powerware logo
Mimic screen
User Password Enabled/Disabled
Disabled
If Enabled is selected, the password is USER.
Audible Alarms Normal Sound/Disabled Normal Sound
Battery Charging ABM cycling/constant ABM cycling
Automatic Battery Tests Enabled/Disabled
Enabled
Enabled automatically runs the battery test
once a month.
Full Power Battery Test Enabled/Disabled Enabled
Number of Battery Strings 0 through 22
(see “Configuring the UPS for EBMs” on
2 strings for UPS-32 models
4 strings for UPS-64 models
page 47)
Battery Capacity 1 through 65535 watts per cell 34 W/cell
Battery Low Alarm Level 1.750 through 1.950 volts per cell 1.880 V/cell
Bypass Voltage High Limit +1 through +20% (1% increments) 120V +10%
Bypass Voltage Low Limit -1 through -20% (1% increments) 120V -15%
Nominal Output Frequency 50 Hz or 60 Hz 60 Hz
Synchronization Enabled/Disabled Enabled
Synchronization Window ±0.5 through ±3.0 Hz
±2.0 Hz
(0.1 Hz increments)
Unsynchronized Transfer to Bypass Allowed/Not Allowed Not Allowed
Output Frequency Slew Rate 0.1 though 5 hertz per second
0.5 Hz/s
(0.1 Hz increments)
Usage of Bypass Enabled/Disabled Enabled
Transfer to Bypass When Overload After a delay/Immediately After a delay
Automatic Start Delay -1 through 32767 seconds
0s
(-1 means disabled)
Control Commands from X-Slot1 Allowed/Disabled Allowed
Control Commands from X-Slot2/Serv Allowed/Disabled Allowed
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
45
OPERATION
Table 3. User Settings (continued)
Default SettingAvailable SettingsDescription
X-Slot Signal Input Activation Delay 0 through 65 seconds 5s
Input signal delayed shutdown delay 1 through 65535 seconds 120s
Site Wiring Fault Notice Enabled/Disabled Enabled
Reset Custom Event Settings 0 through 32 Total: 0/32
Auto Output Configuration Enabled/Disabled Enabled for initial startup
Disabled after initial startup
Initial Startup
Startup and operational checks must be performed by an authorized
Eaton Customer Service Engineer, or the warranty terms as specified in
the Powerware 9355 UPS (10/15 kVA) User’s Guide become void. This
service is offered as part of the sales contract for the UPS. Contact
service in advance (usually a two-week notice is required) to reserve a
preferred startup date.
46
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Configuring the UPS for EBMs
NOTE Each UPS in a parallel system must have its own EBM and the same number of
EBMs to ensure consistent runtimes.
To ensure maximum battery runtime, configure the UPS for the correct
number of EBMs:
1. Press any button on the front panel display to activate the menu
options.
OPERATION
2. Using the
3. Press the
4. Using the
and press the
5. Use the
button, scroll to the Settings menu.
button twice to select the User Settings menu.
button, scroll to the Number of Battery Strings option
button.
or buttons to select the number of strings according to
your UPS configuration:
All 2-High UPS and EBM Cabinets*
UPS + 1 EBM 6
UPS + 2 EBMs 10
UPS + 3 EBMs 14
UPS + 4 EBMs 18
All 3-High UPS and EBM Cabinets* Number of Strings
UPS + 1 EBM 10
UPS + 2 EBMs 16
UPS + 3 EBMs 22
*UPS-32 models contain 2 strings; EBM-64 models contain 4 strings.
UPS-64 models contain 4 strings; EBM-96 models contain 6 strings.
Number of Strings
6. Press the button to save the setting.
7. Press the
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
ESC
button until the Eaton Powerware logo appears.
47
OPERATION
Parallel System Shutdown
To remove power to the parallel UPS system output:
1. Press any button on the front panel display to activate the menu
options.
2. Press the
button on the front panel display and then press the
button to select the TURN UPS ON/OFF menu.
3. Press the
button to select the System Off option; press the
button.
4. Confirm the selection. Press and hold the
button for three
seconds, until the UPS stops beeping.
The UPS removes power to the parallel UPS system output.
ESC
5. Press the
button until the Eaton Powerware logo appears.
6. If you want to completely remove power from the UPS, continue to
the following section, “Individual UPS Shutdown,” to shut down
each UPS.
48
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Individual UPS Shutdown
To shut down a single UPS in the parallel system:
1. Press any button on the front panel display to activate the menu
options.
OPERATION
2. Press the
button on the front panel display and then press the
button to select the TURN UPS ON/OFF menu.
3. Press the
button to select the UPS Off option; press the
button.
4. Confirm the selection. Press and hold the
button for three
seconds, until the UPS stops beeping.
The input contactor opens.
5. Switch the UPS battery circuit breaker to the OFF position.
The UPS is disconnected from the batteries and is on logic power
only.
6. Switch the UPS breaker on the parallel tie cabinet to the OFF
position.
NOTE If there is only one breaker for all UPSs, do not switch off utility power until all UPSs
are shut down.
7. Switch off utility power where the UPS is connected.
If you are shutting down all the UPSs in a parallel system, repeat
Steps 2 through 6 for each UPS then remove utility power.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
49
OPERATION
Restarting the Parallel System
To restart the parallel system:
1. Verify that all UPS breakers on the parallel tie cabinet are in the OFF
position.
2. Switch on utility power where the UPSs are connected.
3. Wait for the front panel LCD to illuminate.
The
indicator flashes on each UPS.
4. Switch all battery circuit breakers to the ON position.
The
indicator stops flashing on each UPS.
5. Switch the UPS breakers on the parallel tie cabinet to the ON
position.
6. Verify that no alarms appear on the UPS front panel display.
If the
indicator is flashing, do not proceed until all alarms are
clear. Check the UPS status from the front panel to view the active
alarms. Correct the alarms and restart if necessary.
ESC
7. Press the
button once and then press the button to select
the TURN UPS ON/OFF menu.
8. Press the
button to select the System On option; press the
button.
9. Confirm the selection. Press and hold the
button for three
seconds, until the UPS stops beeping.
The UPS goes to Bypass mode for five seconds, and then the
indicator illuminates. Each UPS should be in Normal mode.
10. Press the
ESC
button until the Eaton Powerware logo appears.
50
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Chapter 9 Parallel Bypass
To switch the parallel UPS to maintenance bypass from Normal mode:
1. From any UPS, set the system to internal Bypass mode:
S Using the button on the front panel display, scroll to the Control
menu option and press the
S Press the button to select the Go to Bypass Mode option.
button.
The
is operating in Bypass mode.
2. Switch the bypass breaker on the parallel tie cabinet to the ON
position.
3. Switch the UPS breakers on the parallel tie cabinet to the OFF
position.
and indicators illuminate, indicating the UPS system
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
51
PARALLEL BYPASS
To return to Normal mode from maintenance bypass:
1. Verify that all UPS breakers on the parallel tie cabinet are in the OFF
position.
2. Switch on utility power where the UPSs are connected.
In a parallel capacity system (N+0 or N+1), apply utility to the
minimum number of UPSs required for capacity.
NOTE Use the same UPS that was u sed to set internal bypass to return the parallel system
to Normal mode.
3. Set the system to internal Bypass mode:
S Using the button on the front panel display, scroll to the Control
menu option and press the
button.
S Press the button to select the Go to Bypass Mode option.
The
and indicators illuminate, indicating the UPS system
is operating in Bypass mode.
4. Switch all UPS breakers on the parallel tie cabinet to the ON
position.
5. Switch the bypass breaker on the parallel tie cabinet to the OFF
position.
6. On the same UPS front panel, set the UPS to Normal mode:
S Press the button to select the Go to Normal Mode option.
S Each UPS should go to Normal mode.
52
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Chapter 10 Troubleshooting
The Powerware 9355 is designed for durable, automatic operation and
also alerts you whenever potential operating problems may occur.
Usually the alarms shown by the control panel do not mean that the
output power is affected. Instead, they are preventive alarms intended
to alert the user. Use the following troubleshooting chart to determine
the UPS alarm condition.
Typical Alarms and Conditions
The following table describes typical alarms and conditions; check the
Event Log through the control panel for a list of active alarms. If an alarm
appears with a service code, please contact the Help Desk (see
page 56).
Alarm or Condition Possible Cause Action
On Battery
LED is on.
1 beep every second.
Battery Low
LED is on.
Continuous beep for
10 seconds.
Battery Breaker
LED is on.
1 beep every second.
Overload
LED is on.
1 beep every second.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
A utility failure has occurred and the
UPS is in Battery mode.
The battery is running low. Five minutes or less of battery power remains
The UPS does not recognize the
internal batteries.
Power requirements exceed the UPS
capacity (greater than 100% of
nominal).
The UPS is powering the equipment with battery
power. Prepare your equipment for shutdown.
(depending on load configuration and battery
charge). Save your work and turn off your
equipment.
When utility power is restored, the UPS restarts
automatically, provides power to the load, and
charges the battery.
Verify the battery circuit breaker is in the ON
position. If the condition persists, contact your
service representative.
Remove some of the equipment from the UPS. The
UPS continues to operate, but may switch to
Bypass mode if the load increases. The alarm
resets when the condition becomes inactive.
53
TROUBLESHOOTING
p
ActionPossible CauseAlarm or Condition
Overtemperature
UPS internal temperature is too high
or the fan has failed.
Turn the maintenance bypass switch to the
SERVICE position. Otherwise, shut down the UPS.
Clear vents and remove any heat sources. Allow
LED is on.
1 beep every second.
the UPS to cool. Ensure the airflow around the UPS
is not restricted.
If the alarm disappears, turn the maintenance
bypass switch back to the UPS position.
If the condition persists, contact your service
representative.
Battery test failed The batteries need service. Contact your service representative.
The UPS does not start.
The main utility breaker is off. Verify that the main utility breaker is on.
If an optional isolation transformer is
installed, the input circuit breaker is
Verify that the isolation transformer input circuit
breaker is on.
off.
The remote emergency power-off
(REPO) switch is active or the REPO
Reset the REPO switch and restart the UPS. Verify
that the REPO connector is present.
connector is missing.
Power is not available at
the UPS output
receptacles.
The UPS is in Standby mode. Supply power to the connected equipment: Press
any button on the front panel display to activate the
menu options. Press the button on the front panel
display and then press the button to select the
TURN UPS ON/OFF menu. Press the button to
select the System On option; press the button.
Press and hold the button for three seconds,
until the UPS stops beeping.
The UPS does not
provide the expected
backup time.
The batteries need charging or
service.
Battery circuit breakers are in the OFF
position.
Apply utility power for 48 hours to charge the
batteries. If the condition persists, contact your
service representative.
Switch all battery circuit breakers to the ON
position.
54
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
TROUBLESHOOTING
ActionPossible CauseAlarm or Condition
Check Parallel Board The UPS is not recognizing another
parallel unit.
Abnormal output voltage
at startup
Selective Trip The Powerware Hot Sync CAN Bridge
The UPS breaker on the parallel tie
cabinet was not switched to the ON
position properly.
Card is not wired correctly.
Silencing the Alarm
Before silencing an alarm, check the alarm condition and perform the
applicable action to resolve the condition.
From the UPS Status menu, select the Units on CAN
Bus option and verify that all UPSs appear in the
list.
If any UPS is missing, verify the Powerware Hot
Sync CAN Bridge Card connections and recheck
the status from the UPS front panel.
If all UPSs appear in the list, check the pull-chain
wiring (see page 29).
Set the system to internal Bypass mode (see
page 51).
If the condition persists, contact your service
representative.
Shut down the UPS where the alarm is indicated.
Switch the UPS breaker on the parallel tie cabinet
to the ON position.
Start up the UPS.
Select the System On option through the front
panel of the UPS that was turned off.
Verify the CAN wiring (see page 29).
Verify the pull-chain wiring (see page 29).
If the condition persists, contact your service
representative.
Press any button on the front panel display to silence the alarm. If the
alarm status changes, the alarm beeps again, overriding the previous
alarm silencing.
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
55
TROUBLESHOOTING
Service and Support
If you have any questions or problems with the UPS, call your Local
Distributor or the Help Desk at one of the following telephone numbers
and ask for a UPS technical representative.
United States:
Canada: 1-800-461-9166 ext 260
All other countries: Call your local service representative
Please have the following information ready when you call for service:
1-800-843-9433 or 1-919-870-3028
S Model number
S Serial number
S Firmware version number
S Date of failure or problem
S Symptoms of failure or problem
S Customer return address and contact information
56
EATON Powerware®9355 Parallel UPS (10/15 kVA) User’s Guide S 164201601 Rev A www.powerware.com
Loading...
