Powerware 9335 User Manual

Uninterruptible Power

Supply

80 kVA

and

120 kVA

335

9

Installation and Operation

Manual

164201396 Rev. A

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

This manual contains important instructions for your Uninterruptible Power
Supply (UPS) system. You should follow these instructions during the
installation and maintenance of the UPS, options, accessories and batteries.

This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference with the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at their
own expense.

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation ii
164201396 REV. A 071103

A

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Basic System Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

Using This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

Conventions Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . x

Safety Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii

Section I Installation

1 Getting Started

1.1 Installing the UPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1

1.1.1 Creating an Installation Plan . . . . . . . . . . . . . . . . . . . . 1 - 1

1.1.2 Preparing Your Site . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2

1.1.3 Environmental Considerations . . . . . . . . . . . . . . . . . . . 1 - 2

1.1.4 Preparing for Wiring the UPS System . . . . . . . . . . . . . . 1 - 2

1.1.5 Inspecting and Unpacking Each Cabinet . . . . . . . . . . . 1 - 3

2 Installing the UPS System

2.1 Preliminary Installation Information . . . . . . . . . . . . . . . 2 - 1

2.2 UPS Cabinet Installation . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.1 Unloading the Powerware 9335 (80kVA-120 kVA)

UPS Cabinet from the Pallet . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.2 Installing Remote Battery Power Wiring . . . . . . . . . . . . 2 - 3

2.2.3 Installing UPS External Power Wiring . . . . . . . . . . . . . . 2 - 3

2.2.4 Installing Customer Connections . . . . . . . . . . . . . . . . . . 2 - 4

2.2.5 Prepare for Installing Accessories . . . . . . . . . . . . . . . . 2 - 4

2.3 Battery Cabinet Installation . . . . . . . . . . . . . . . . . . . . . . 2 - 5

2.4 Initial Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 5

2.5 Completing the Installation Checklist . . . . . . . . . . . . . . 2 - 5

2.5.1 Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 6

3 Installing and Connecting Batteries

3.1 Important Safety Instructions . . . . . . . . . . . . . . . . . . . . 3 - 1

4 Installing a Remote EPO Control

4.1 Installation Procedures . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.2 To Install a Remote EPO . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.3 To Operate a Remote EPO . . . . . . . . . . . . . . . . . . . . . . 4 - 2

iii Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV. A 071103

Section II Operation

5 Understanding UPS Operation

5.1 Looking Inside the UPS System . . . . . . . . . . . . . . . . . 5 - 1

5.2 Normal, Battery and Bypass Modes . . . . . . . . . . . . . 5 - 3

5.2.1 Normal Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4

5.2.2 Bypass Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6

5.2.3 Battery Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 8

5.2.4 Maintenance Bypass Mode . . . . . . . . . . . . . . . . . . . . 5 - 10

5.3 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . 5 - 11

5.3.1 Input Rectifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 11

5.3.2 Boost Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 11

5.3.3 Inverter and Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 11

5.3.4 Battery and Battery Charger . . . . . . . . . . . . . . . . . . . . 5 - 11

5.3.5 Static Bypass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 12

5.3.6 Maintenance Bypass . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 12

6 Operational Controls and Features

6.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1

6.2 UPS Operational Controls . . . . . . . . . . . . . . . . . . . . 6 - 2

6.2.1 Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2

6.2.2 System and Load ON/OFF . . . . . . . . . . . . . . . . . . . 6 - 2

6.2.3 Maintenance Bypass Switch . . . . . . . . . . . . . . . . . . 6 - 3

6.2.4 Cold Start Capability . . . . . . . . . . . . . . . . . . . . . . . . 6 - 3

6.3 UPS Standard Features . . . . . . . . . . . . . . . . . . . . . . 6 - 3

6.3.1 Customer Interface . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 3

6.3.2 Battery Management . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 3

6.3.3 Installation Features . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 3

6.4 Options and Accessories . . . . . . . . . . . . . . . . . . . . . 6 - 4

6.4.1 Remote EMERGENCY POWER OFF . . . . . . . . . . . 6 - 4

6.4.2 Battery Cabinets . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 4

6.4.3 Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 4

6.4.4 Other Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 4

6.5 Safety Considerations . . . . . . . . . . . . . . . . . . . . . . . . 6 - 5

6.6 Symbols, Controls and Indicators . . . . . . . . . . . . . . . 6 - 6

7 Using the Control Panel

7.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 1

7.2 Using the Control Panel . . . . . . . . . . . . . . . . . . . . . . 7 - 2

7.2.1 Power Management Display . . . . . . . . . . . . . . . . . . 7 - 2

7.2.2 LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 2

7.2.3 Pushbutton Functions . . . . . . . . . . . . . . . . . . . . . . . 7 - 3

7.2.4 ON/OFF Shutdown and Startup Pushbuttons . . . . . 7 - 3

7.3 Description of the LCD Screen . . . . . . . . . . . . . . . . . 7 - 4

7.3.1 Status Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 4

7.3.2 LCD Display Structure and Navigation . . . . . . . . . . . 7 - 5

7.3.3 Main Menu Screen . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 6

7.3.4 Event Log Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 6

7.3.5 Measurements Screen . . . . . . . . . . . . . . . . . . . . . . . 7 - 6

7.3.6 Command Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 7

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation iv
164201396 REV. A 071103

7.3.7 UPS Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 8

7.3.8 Set-Up User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 8

7.3.9 Set-Up Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 9

7.4 Operating Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 10

7.4.1 “ON-LINE” Mode (Inverter Mode) . . . . . . . . . . . . . . . 7 - 10

7.4.2 “OFF-LIINE” Mode (BYPASS or ECONOMY Mode) . 7 - 10

7.4.3 “MAINTENANCE BYPASS” Mode . . . . . . . . . . . . . . 7 - 11

7.4.4 Parallel Isolator (IA2) . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 12

8 UPS Operating Instructions

8.1 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 1

8.2 Start-Up Procedure for the UPS . . . . . . . . . . . . . . . . 8 - 1

8.3 Shut-Down Procedure for the UPS . . . . . . . . . . . . . 8 - 3

8.4 Load Transfer to Maintenance Bypass . . . . . . . . . . . 8 - 4

9 Responding to System Events

9.1 Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 1

9.2 Menu, Commands, Event Log, Measurements . . . . 9 - 1

9.3 Fault Identification and Correction . . . . . . . . . . . . . . 9 - 2

10 Communications

10.1 X – Slot Communication Modules . . . . . . . . . . . . . . 10 - 1

10.2 Single-Port Module . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 2

11 Options

11.1 Generator ON Facility . . . . . . . . . . . . . . . . . . . . . . . . 11 - 1

12 Maintaining the UPS System

12.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 - 1

12.2 Important Safety Instructions . . . . . . . . . . . . . . . . . . . 12 - 1

12.3 Performing Preventive Maintenance . . . . . . . . . . . . . 12 - 2

13 Product Specifications

13.1 System Information . . . . . . . . . . . . . . . . . . . . . . . . . . 13 - 1

13.2 UPS System Input . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 - 1

13.3 UPS System Output . . . . . . . . . . . . . . . . . . . . . . . . . . 13 - 2

13.4 Environmental Specifications . . . . . . . . . . . . . . . . . . 13 - 2

Appendix A – Customer Information . . . . . . . . . . . . . . . . . . A - 1

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . W - 1

v Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV. A 071103

L

ist of Figures

Figure 1 – 1 Powerware 9335 (80 kVA and 120 kVA) UPS Cabinet
Figure 4 – 1 Typical Remote EPO Control
Figure 5 – 1 Main Elements of the UPS System
Figure 5 – 2 Path of Current through the UPS in Normal Mode
Figure 5 – 3 Path of Current through the UPS in Bypass Mode
Figure 5 – 4 Path of Current through the UPS in Battery Mode
Figure 5 – 5 Path of Current through the UPS in Maintenance Bypass Mode
Figure 6 – 1 Powerware 9335 (80 kVA and 120 kVA) Controls and Indicators
Figure 6 – 2 Powerware 9335 (80 kVA and 120 kVA) Control Panel
Figure 7 – 1 UPS Control Panel
Figure 7 – 2 LCD Screen and Pushbuttons
Figure 7 – 3 LCD Screen Navigation Chart
Figure 10 – 1 X – Slot Location on Front of Powerware 9335 UPS Cabinet
Figure 10 – 2 The Communication Port on the Single Port Serial Card
Figure 11 – 1 Generator ON Connection

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation vi
164201396 REV. A 071103

L

ist of Tables

Table 4 – 1 Remote EPO Wire Terminations
Table 4 – 2 Remote EPO
Table 10 – 1 Communication Port Pin Assignments

vii Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV. A 071103

I

18

00 mm (70.9 in.)

1800 mm (70.9 in.)

1800 mm (70.9 in.)

ntroduction

Powerware 9335 UPS true double conversion online power protection can be utilized to
prevent loss of valuable electronic information, minimize equipment downtime, and/or
minimize the adverse effect on equipment production due to unexpected power
problems.

The Powerware UPS System continuously monitors incoming electrical power and
removes the surges, spikes, sags, and other irregularities that are inherent in
commercial utility power. Working with your building’s electrical system, the UPS
System supplies clean consistent power that your sensitive electronic equipment
requires for reliable operation. During brownouts, blackouts and other power
interruptions, optional battery strings provide emergency power to safeguard your
operation.

The UPS system is housed in free-standing cabinets. The cabinet sections are
matching in design and color, and have safety shields behind the front panels for
hazardous voltage protection. The following illustration depicts a typical Powerware
9335 (80 kVA and 120 kVA) UPS System.

700

700 mm (27.6 in.)

700 mm (27.6 in.)

700 mm (27.6 in.)

Operator

Operator

Operator
Control Panel

Control Panel

Control Panel

1800

Removable
Conduit Landing
Panel (bottom
rear of cabinet)

750 mm (29.6 in.)

00

5

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation viii
164201396 REV. A 071103

Basic System Configurations

These basic UPS system configurations are possible:

• Single Cabinet UPS with External Battery Cabinet, Single Utility Feed

• Single Cabinet UPS with External Battery Cabinet, Dual Utility Feed

You can enhance any of these system configurations by adding optional accessories,
such as Remote Emergency Power Off (EPO) control and X–Slot communications
connectivity features.

Using This Manual

Your UPS functions automatically and requires very little attention during normal
operation. However, you should read and understand the procedures described in this
manual to ensure trouble-free operation. In particular, you should be thoroughly familiar
with the Remote Emergency Power Off procedure described in Chapter 4 of this
manual.

The information in this manual is divided into the sections and chapters listed. The
system you are installing dictates which parts of the manual you should read. Everyone
should read the Introduction, Chapters 1, 2, 7, and 8.

Introduction

The introduction provides a brief description of the UPS system, a description of the
content of each chapter, safety, and text conventions used in the manual and reference
information.

Section I – Installation

• Chapter 1 – Getting Started – tells you how to prepare your site for the

installation of your UPS system. It discusses equipment environmental
requirements, inspecting, and unpacking cabinets.

Chapter 2 – Installing the UPS System

•

cabinets and optional equipment.

Chapter 3 – Installing and Connecting Batteries

•

installation and connection information.

Chapter 4 – Installing a Remote EPO Control

•

installing the optional Remote Emergency Power Off (REPO) control.

– describes how to install the UPS

– provides battery safety,

– contains information for

ix Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV. A 071103

Section II – Operation

Chapter 5 – Understanding UPS Operation

•

understanding how your UPS works.

Chapter 6 – Operational Controls and Features

•

and optional operational features and controls of the UPS system.

Chapter 7 – Using the Control Panel

•

indicators found on the Control Panel and shows the various information
screens displayed on the LCD screen.

Chapter 8 - UPS Operating Instructions

•

procedures for the UPS system.

Chapter 9 – Responding to System Events

•

and notices that can occur during operation of the UPS system.

• Chapter 10 – Communications

available with the UPS system.

Chapter 11 – Options

•

system.

Chapter 12 – Maintaining the UPS System

•

instructions for the UPS system.

Chapter 13 – Product Specifications

•

the UPS system.

Appendix A – Customer Information

•

wiring requirements and recommendations, and important diagrams of the
cabinet’s mechanical details and electrical access.

Warranty

•

Read through each procedure before you begin. Perform only those procedures that
apply to the UPS system you are installing or operating.

– provides the Powerware warranty for this product.

– describes the available options for this UPS

– describes the controls and

– describes the communication feature

– provides detailed specifications for

– contains important information on

– provides information on

– describes the standard

– contains startup and shutdown

– lists all the alarm messages

– contains maintenance

Conventions Used in This Manual

The text in this manual uses these conventions:

• Bold type

procedures, and menu options.

highlights important concepts in discussions, key terms in

• Italic type highlights notes and new terms where they are defined.

• Rectangular boxes containing bold type are warnings or cautions that pertain

to the UPS system or its electrical connections.

In this manual, the term UPS refers only to the UPS cabinet and its internal elements.
The term UPS system refers to the entire power protection system-the UPS cabinet,
battery strings and options or accessories installed.

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation x
164201396 REV. A 071103

Safety Considerations

y

The UPS cabinet is designed for industrial or computer room applications, and
contain safety shields behind the doors. However, the UPS system is a
sophisticated power system and should be handled with appropriate care, following
these guidelines:

Keep surroundings clean and free from excess moisture

•

Do not operate the UPS system close to gas or electric heat sources.

•

The system is not intended for outdoor use.

•

.

• The operating environment should be maintained within the parameters

stated in the manual.

• Keep the cabinet doors closed and locked to ensure proper cooling

airflow and to protect personnel from dangerous voltages inside the unit.

• The UPS system contains its own power source. Lethal voltages are

present even when the UPS is disconnected from utility power.

WARNING:
Only AUTHORIZED SERVICE PERSONNEL should perform maintenance
on or service the UPS s

If service or routine maintenance is required:

stem.

• Ensure all power is disconnected before performing installation or

service.

• Ensure the area around the UPS system is clean and uncluttered.

Battery maintenance or battery replacement should be performed only by

•

authorized service personnel.

Observe all DANGER, CAUTION and WARNING notices affixed to the

•

inside and outside of the equipment.

Getting Help

If you need to schedule initial startup, need regional locations and telephone
numbers, have a question about any of the information in this manual, or have a
question this manual does not answer, please call Powerware Corporation at:

United States 1 – 800 – 843 – 9433

Canada 1 – 800 – 461 – 9166

Outside the U.S. Call your local representative

xi Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV. A 071103

Section I

Installation

This page left intentionally blank

Getting Started

1

1.1 Installing the UPS

The complete UPS cabinet is shipped on a single pallet. Use a forklift or a pallet jack, rated
to handle the weight of the cabinets (refer to Table J in Appendix A for cabinet weights) to
move the packaged cabinet to the installation site, or as close as possible to the site, before
unloading from the pallet.

This is the basic sequence of the installation steps:

1.

Create an installation plan for the UPS system. (Chapter 1)

2. Prepare your site for the UPS system (Chapter 1)

3.

Inspect, unpack, and unload the UPS cabinet. (Chapter 1)

4.

Wire the system. (Chapter 2)

5. Install features, accessories, and/or options, as applicable. (Chapter 4 and 10)

6.

Complete the installation checklist. (Chapter 2)

7.

Have authorized service personnel perform preliminary operational checks and startup.

NOTE:

Startup and operational checks should be performed only by authorized service

personnel. This service is usually offered as part of the service contract for your
UPS. Contact Global Services in advance (usually a two week notice is required) to
reserve a preferred startup date.)

1.1.1 Creating an Installation Plan

Before beginning to install the UPS system, read and understand how this manual applies to
the system being installed. Use the procedures and illustrations in the following chapters to
create a logical plan for installing the system.

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation 1-1
164201396 REV A 071103

1.1.2 Preparing Your Site

For your UPS to operate at peak efficiency, your installation site should meet the
environmental parameters outlined in this manual. If you intend to operate the system at an
altitude higher than 1500 meters (5000 feet), contact your local sales or service office for
important information about high altitude operation. The operating environment must meet
the weight, airflow, size and clearance requirements specified in Appendix A.

The basic environmental requirements of the UPS system are:

Maximum Relative Humidity: 95% (non-condensing)

The UPS cabinet uses forced air cooling to regulate internal component temperature. Air
inlets are in the bottom sides and front of the cabinet, and outlets in the top of the cabinet.
You must allow clearance in back of the cabinet for proper air circulation. Refer to Table K
of Appendix A for clearance requirements.

Ambient Temperature Range:

Recommended Operating Range:

0 – 40˚C (32 – 104˚F)

20 – 25˚C (68 – 77˚F)

1.1.3 Environmental Considerations

The life of the UPS system is adversely affected if the installation does not meet the
following guidelines:

1.

The system must be installed on a level floor suitable for computer or electronic

equipment.

2. The system must be installed in a temperature-controlled indoor area free of conductive
contaminants.

Failure to follow guidelines may invalidate the UPS warranty.

1.1.4 Preparing for Wiring the UPS System

For external wiring requirements, including the minimum AWG size of external wiring, refer
to Tables A and B in Appendix A for the Powerware 9335 (80 kVA and 120 kVA) UPS. The
power wiring connections for this equipment are rated using copper wire at 90˚C. Note that
wiring to an external battery cabinet may be either 75˚C or 90˚C rated. Control wiring for
EPO and optional accessories (such as building alarm and monitoring interface) should be
connected at the customer interface connections inside the front of the UPS using class 1
wiring methods.

1-2 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV A 071103

1.1.5 Inspecting and Unpacking Each Cabinet

The first task in preparing for installation is inspecting and unpacking the UPS. The UPS
and accessory cabinets are shipped bolted to wooden pallets, as shown in Figure 1
protected with outer protective packaging material.

NOTE: Packed
inside the shipping
carton on top of
the UPS cabinet is
an accessory
carton containing
the metal grilles to
be installed at the
unit base after it is
fixed in the final
position. Remove
this box from the
cabinet before
moving UPS to its
final position

–

1, and

Figure 1–1. Powerware 9335 (80 kVA and 120 kVA) UPS Packaging

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation 1-3
164201396 REV A 071103

1.

Carefully inspect the outer packaging for evidence of damage during transit.

CAUTION:
Do not install a damaged cabinet. Report any damage to the carrier and
contact your local sales or service office immediately

.

2.

Use a forklift or other material handling equipment to move the cabinet to a
convenient unpacking area. Insert the forklift forks between the pallet supports on
the bottom of the unit.

CAUTION:
Do not tilt cabinets more than

±

10 degrees from vertical.

3.

Set each cabinet on a firm, level surface, allowing a minimum clearance of 3 m
(10 ft) on each side for removing the cabinets from the pallets.

4

. Remove accessory installation kit located at the top of the unit (see figure 1.1) by

opening top of outer box.

CAUTION:
If accessory kit is not moved, box will be top heavy upon removal.
Approximate weight of accessory kit is 25 lbs. (11 kg.)

5.

Remove the protective covering from the cabinets.

6.

Remove the packing material, and discard or recycle them in a responsible manner.

7.

After removing the protective covering, inspect the contents for any evidence of
physical damage, and compare each item with the Bill of Lading. If damage has
occurred or shortages are evident, contact the Powerware Customer Service
Department immediately to determine the extent of the damage and its impact upon
further installation.

NOTE:

While awaiting installation, protect the unpacked UPS cabinet from moisture, dust,

and other harmful contaminants. Failure to store and protect the UPS properly may
invalidate the warranty.

1-4 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV A 071103

I

nstalling the UPS System

2.1 Preliminary Installation Information

Refer to the following while installing the UPS system:

WARNING:
Only qualified personnel should perform installation. All wiring
and installation of the UPS system must be done in accordance
with the most current NEC standards or local electrical code.

•

Refer to Appendix A of this manual for installation drawings and additional
installation notes.

• Dimensions in this manual, unless otherwise noted, are in millimeters and (inches).

•

Do not tilt the cabinets more than

• The conduit landing plates are to be removed to add conduit landing holes as

required. Plate material is 14 gauge steel (2 mm. thick)

•

The cabinets must be installed on a level floor suitable for computer or electronic
equipment.

• If perforated floor tiles are required for ventilation, place them in front of the UPS.

Refer to Table J in Appendix A for equipment weight and point loading, and Figure
A–5 in Appendix A for air inlet locations.

•

Details about control wiring are provided in each procedure for connecting options
and features. Figure A–1 and Tables G and H in Appendix A identify the control
wiring terminations.

±

10 degrees during installation.

2

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation 2-1
164201396 REV A 071103

2.2 UPS Cabinet Installation

jury

y

g

To install an UPS cabinet, perform the procedures in the following paragraphs.

2.2.1 Unloading the Powerware 9335 (80 kVA and 120 kVA) UPS

Cabinet from the Pallet

The UPS cabinet is bolted to a wooden shipping base using two steel angles. To remove
the shipping material, perform the following procedure.

WARNING:
The UPS cabinet is heavy. Refer to Table J in Appendix A for weight of
cabinets. If unloading instructions are not closely followed, the cabinet may
cause serious in

CAUTION:
Do not tilt cabinets more than ±10 degrees from vertical. Do not cut the
outside protective cardboard packing box open. Damage to the enclosed
cabinet ma

CAUTION:
Carefully open top of outer package and remove accessory installation kit
before removin

1. Remove accessory installation kit located at the top of the unit (see figure 1.1) by

opening top of outer box.
Use a forklift or other material handling equipment to move the cabinet to the
installation area. Insert the forklift forks under the unit and keep the unit elevated
approximately 3 inches above the ground.

occur.

.

outer packaging. Approximate weight is 25 lbs. (11 kg.)

Remove the 4 jacking bolts from the accessory pack.

2.

Remove the outer stretch wrapping. The two steel angles which connect the UPS
cabinet to the wooden shipping base contain 2 threaded holes for inserting jacking
bolts..

3.

Unbolt the wooden cross members on the shipping base by removing the four nuts
(10 mm) which fasten the wooden pallet to the steel brackets. Remove the wooden
cross members from the steel brackets. Insert the jacking bolts into the holes and
lower them to the ground, in order for the weight of the unit to be supported by the 4
bolts. Place small metal plates under the jacking bolts to prevent floor damage.
Ensure the unit does not tilt more than specified in the caution note above. Remove
the forklift or pallet jack once the unit is supported on the jacking bolts. Slowly lower
the UPS by alternating between the four jacking bolts, until the steel brackets are on
the floor. Remove the jacking bolts. Detach the UPS cabinet from the angle steel by
removing all of the M5 Phillips-head machine screws that fasten them, using a #3
Phillips head screwdriver. Tilt the unit slightly to enable the steel bracket to be
removed from beneath two legs. Lower the unit down to the floor.

4.

Repeat the process for the other side by tilting the unit and removing the steel bracket.
(See illustrated procedure packed on the outside of the shipping carton.)

5.

The UPS cabinet may now be moved to its final position for installation.

2-2 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV A 071103

2.2.2 Installing External Battery Power Wiring

The Powerware 9335 contains no internal batteries and must therefore be used with an
external battery system. The procedure for wiring the battery system to the 9335 is
described as follows. Also read the manual provided with the battery system to ensure
proper interconnections on the battery side.

1.

If not already done, open the UPS cabinet door using the provided operator handle

and remove the bottom internal protective panel. Retain hardware.

NOTE

: Remove the UPS cabinet conduit landing plate to punch out conduit holes.

2.

Route battery cables from the battery cabinet through the conduit landing plate at the

UPS cabinet bottom rear to the battery terminals at the bottom front of the cabinet.
Refer to Appendix A of this manual for wiring access information.

NOTE:

3.

Remove the UPS cabinet input and output conduit landing plate to punch conduit

holes as required. When reinstalling, ensure that the protective ground wire is
reconnected if it has been removed for conduit hole punching in the plate.

Connect positive, negative and neutral DC power wiring from the external battery
source to the DC input (positive and negative) and neutral (battery center tap)
terminals in the UPS cabinet. Refer to Appendix A of this manual for wiring and
termination requirements and wiring access information.

2.2.3 Installing UPS External Power Wiring

1.

Open the front cabinet door using the provided removable operator handle (packed
separately with the UPS). Remove the internal safety shield panel by removing the
fastening hardware to gain access to the input and output terminals at the bottom front
of the cabinet.

NOTE:

2. Route input and output cables through wireway to UPS terminal blocks. Refer to

3.

Remove the UPS cabinet input and output conduit landing plate to punch conduit

holes as required. When reinstalling, ensure that the protective ground wire is
reconnected if it has been removed for conduit hole punching in the plate.

Appendix A of this manual for wiring access information.

For bypass input or single feed, connect phase A, B, C, Neutral (N) and earth ground
(G) input power wiring from the source to the bypass input terminals (2A, 2B, 2C) in
the UPS cabinet. Refer to Appendix A of this manual for wiring and termination
requirements and wiring access information. Note wiring connections for single feed
systems.

DANGER:
Never connect the earth ground (G) to the Neutral connection (N) inside the
UPS equipment cabinet. Never connect input and output neutrals (N)

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation 2-3
164201396 REV A 071103

WARNING:
The Powerware 9335 UPS requires a neutral input power connection for
proper operation. Internal input and output neutrals are permanently
connected inside the cabinet.

WARNING:

An insulated grounding conductor must be provided per NEC.

4.

If the installation is for a single utility feed with common rectifier and bypass input,
proceed to step 7. For a separate bypass and rectifier input, proceed to step 5.

5.

Remove the single feed bus bar jumper connections from between X6 and X7, Phase
A, B, and C and discard them. They will not be used again.

6. Connect ground, phase A, B, C, and Neutral mains input power wiring from the source
to the Mains input terminals (1A, 1B, 1C) on the In/Out Terminal Block. Phase A input
connects to input terminal 1A, phase B to input terminal 1B and phase C to input
terminal 1C. Refer to Appendix A of this manual for wiring and termination
requirements and wiring access information. Note wiring connections for dual feed
systems.

7.

Connect ground, phase A, B, C, and Neutral power wiring from the output terminals
(3A, 3B, 3C) on the In/Out Terminal Block to the critical load. Output terminal 3A
connects to phase A of the load, output 3B to phase B and output 3C to phase C,
respectively. Refer to Appendix A of this manual for wiring and termination
requirements and wiring access information.

8.

Secure the UPS by reinstalling the safety shield panels, and closing the front cabinet
door, latching the cabinet door with the removable door handle.

2.2.4 Installing Customer Connections

See Chapter 10, “Communications”

2.2.5 Prepare for Installing Optional Accessories

NOTE:

1.

Be sure the UPS system is turned off and all power sources are removed. (See the
operation section of this manual for shutdown instructions.)

2-4 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV A 071103

If you are installing accessories, including the Remote Emergency Power Off

(REPO) switch, you must install conduit between each device and the UPS
cabinet for wiring these options.

2.

Remove Customer Interface conduit landing plate from the UPS cabinet. Drill or
punch conduit holes for interface wiring.

3. Open UPS cabinet front door and remove the front safety shield panel to gain access
to the wire way to bring wires from the conduit landing panel at the bottom rear of the
cabinet.

4.

Locate required connection points by referring to Figure A–1 in Appendix A.

5.

Refer to Appendix A of this manual for wiring and termination requirements.

6.

Reinstall Customer Interface conduit landing plate.

7. Install conduit and wiring.

8. When wiring is complete, secure UPS by reinstalling all panels removed in previous
steps.

2.3 Battery Cabinet Installation

The Powerware 9335 has no batteries within the UPS cabinet. An external battery
cabinet with appropriate batteries installed is required for proper system operation.
See installation instruction provided with the battery cabinet for proper installation of that
portion of the system.

WARNING:
It is very important to ensure that a proper protective device is installed
between the battery system and the UPS DC input terminals. See Tables A
and B in Appendix A for proper wire and protective device sizing.

2.4 Initial Startup

Startup and operational checks should be performed only by authorized service
personnel. Contact service in advance (usually a two week notice is required) to reserve
a preferred startup date.

2.5 Completing the Installation Checklist

The final step in installing your UPS system is completing the following Installation
Checklist. This checklist ensures that you have completely installed all hardware,
cables, and other equipment. Completing all items listed on the checklist will ensure a
smooth installation. You should make a copy of the Installation Checklist before filling it
out, and retain the original.

After your installation is complete, a service representative will be able to verify the
operation of your UPS system and commission it to support your critical load. The
service representative cannot perform any installation tasks other than verifying software
and operating setup parameters. Service personnel may request a copy of the

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation 2-5
164201396 REV A 071103

completed Installation Checklist to be sure you have completed all applicable equipment
installation.

NOTE:

The Installation Checklist MUST be completed prior to starting the UPS

system for the first time.

2.5.1 Installation Checklist

 All packing materials and restraints have been removed from each cabinet.

 Each cabinet in the UPS system is placed in the installed location.



All conduits and cables are properly routed to the UPS and auxiliary cabinets.



All power cables are properly sized and terminated.



All network connections have been completed.



A ground conductor is properly installed.



Battery cabinet installation instructions have been completed.



Air conditioning equipment is installed and operating properly.



The area around the installed UPS system is clean and dust-free. (It is recommended
that the UPS be installed on a level floor suitable for computer or electronic equipment.)

 Adequate workspace exists around the UPS and other cabinets.

 Adequate lighting is provided around all UPS equipment.

 Any optional accessories are mounted in their installed location and properly wired.

 Summary alarms and/or building alarms are wired appropriately. (OPTIONAL)

 Startup and operational checks performed by authorized service personnel.

2-6 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV A 071103

I

nstalling and Connecting Batteries

3

3.1 Important Safety Instructions

The Powerware 9335 UPS does not contain batteries. It must, however, be used with a
properly configured battery cabinet or rack with a properly sized battery system for
proper operation.

The installation of batteries should be performed or supervised by personnel
knowledgeable of batteries and their associated precautions. Keep unauthorized
personnel away from batteries.

CAUTION:
Refer to the battery manufacturers installation manual for battery installation
and maintenance instructions.

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation 3-1
164201396 REV A 071103

This page left intentionally blank

3-2 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV A 071103

I

nstalling a Remote EPO Control

4.1 Installation Procedures

Figure 4–1. Typical Remote EPO Control

EMERGENCY OFF

4

4.2 To Install a Remote EPO:

NOTE:

To Install a Remote EPO control:

1.

2. Install wiring from the remote EPO switch using appropriate sized conduit through

3.

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation 4-1
164201396 REV A 071103

Before installing a Remote EPO, be sure you have prepared the UPS according

to the instructions in Chapter 2.

Securely mount the remote EPO switch. Recommended locations include near
operator’s consoles or near exit doors. Refer to Remote EPO switch manufacturers
installation instructions for enclosure dimensions and wiring knockouts.

the Customer Interface conduit landing plate on the bottom rear of the UPS cabinet.
Refer to Figure A-10 for conduit landing area,

Connect the Remote EPO wiring as shown in Tables 4–1 and 4–2.

Table 4 – 1. Remote EPO Wire Terminations

From Remote
EPO Switch(s)

Refer to switch
manufacturers
installation
instructions

REMOTE

SWITCH

(N.C.)

Remote EPO switch rating is 24 VDC, 1 Amp maximum

NOTE: This switch must be a dedicated switch not tied into any
other circuits.

EPO

To X1 connector on front

of inner UPS panel

X1 - 1

X1 - 2

Table 4 – 2. Remote EPO

TWISTED

WIRES (2)

X1 UPS

Remarks

Twisted

wires (2) 14-

18 gauge

4. If you are installing multiple Remote EPO stations, wire additional stations in series
with the first Remote EPO.

5.

If required, install appropriate sized conduit and wiring from the Remote EPO switch

to trip circuitry of upstream protective devices. A separate contact block, with the
appropriate normally open or normally closed contacts, must be used for this
function. Remote EPO switch wiring must be in accordance with UL Class 1
requirements.

6.

Secure the UPS by reversing all steps taken to prepare it for Remote EPO
installation.

4.3 To Operate a Remote EPO:

1. Activation of an EPO switch will interrupt the EPO circuit and immediately shut off
UPS main circuit power to the load, as well as the DC input from the battery supply.

2

. Even though the EPO switch is opened, the UPS will not re-energize until the normal

startup procedure is followed, which requires operator intervention at the UPS
cabinet controls.

4-2 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV A 071103

Section II

Operation

Powerware 9335 (80 kVA and120 kVA) Installation and Operation
164201396 REV. A 071103

This page left intentionally blank

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

5

Understanding UPS Operation

5.1 Looking Inside the UPS System

The Powerware 9335 is a continuous duty, solid-state, transformerless (at 480 VAC) three
phase, true online system that provides conditioned and uninterruptible AC power to the
UPS systems output. The UPS supports process control, data processing,
telecommunications/PBX, and research equipment. The Powerware 9335 maintains power
to the critical loads during commercial electrical power brownout, blackout, overvoltage,
undervoltage and out-of-tolerance frequency conditions.

The basic system consists of a:

• rectifier

• battery charger

• DC booster

•

Inverter

•

monitoring/operation control panel

•

integrated communications server

•

microprocessor controlled logic

In this manual, the power required by your equipment is called the critical load. The UPS
supplies the critical load with conditioned power that is synchronized with your utility power.
Figure 5–1 shows the main elements of the UPS.

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 5-1
164201396 REV. A 071103

Mai ntenance

Bypass Switch

IA1

EMI Filter

EMI Filter

Contac tor

K1

Cont actor

K4

Input F il ter

Rectifier

Booste r

Battery

Stati c By pass

Swi tc h

Inverter

Battery

Char ger

Output filter

N

Output

Contac tor

K2

Output
Swi tch

IA2

Fig. 5–1. Main Elements of the UPS System

If utility power is interrupted or falls outside the parameters specified in Chapter 13, “Product
Specifications,” the UPS uses a backup battery supply to maintain power to the critical load
for a specified period of time or until the utility power returns. For extended power outages,
the UPS is designed to operate with an alternative power system (such as a generator) or
will shut down your critical load in an orderly manner, if Powerware shutdown software is
used.

In the event of a severe output overload or failure of a critical internal UPS component, an
emergency bypass, consisting of a continuous duty static switch, and backfeed protection
contactor (K4) is utilized. The backfeed protection contactor is located in series with the
static switch, to ensure safety to anyone working upstream of the UPS system. For manual
transfers to bypass, the static switch is also used. The static switch is armed and ready
during both types of transfers.

If maintenance of the UPS system is required, an internal Maintenance Bypass switch
provides a means of isolating the UPS Rectifier/Booster/Inverter components for servicing,
while still supplying power to the critical load.

The operation of the UPS is described in greater detail in the following paragraphs.

EMI Filter

5-2 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

5.2 Normal, Battery and Bypass Modes

The UPS system functions automatically to supply AC electrical power to the critical load.
There are four standard operation modes.

•

• In Battery mode, the critical load is supplied by the inverter which derives its

•

•

The UPS continually monitors itself and the incoming utility power, and automatically
switches between these modes as required, with no operator intervention, except for the
Maintenance Bypass mode. The sophisticated detection and switching logic inside the
UPS ensures that operating mode changes are automatic and transparent to the critical
load.

System events are alarms and notices that are displayed on the LCD monitor panel.
They may or may not require operator intervention. See Chapter 9.

The following descriptions provide the differences in UPS operating modes.

In Normal mode, the critical load is supplied by the inverter, which derives its
power from rectified utility AC power. In this mode, the battery charger also
provides charging current for the battery, if needed.

power from the battery DC power.

In Bypass mode, the critical load is directly supported by utility power via the
static switch. In this mode, the critical load is not protected.

In Maintenance Bypass mode, the critical load is directly supported by utility
power, but the UPS can be shut down for maintenance. The operator switching
the Maintenance Bypass Switch to the Bypass position accomplishes this,
however, the critical load is not protected.

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 5-3
164201396 REV. A 071103

5.2.1 Normal Mode

Figure 5–2 shows the path of electrical power through the UPS system when the UPS is
operating in Normal mode.

Normal Mode

IA1

Battery

Static Switch

Battery
Breaker

Inverter

Battery
Charger

K2

Main Power

Trickle Current

Energized

De-Energized

Closed

Open

K1

F1

Breaker Contactors

K4

RectifierInput Filter Booster

Switches

Figure 5–2. Path of Current Through the UPS in Normal Mode

During normal UPS operation, power for the system is derived from a utility input source
through the input contactor K1 (and externally protected utility feed). “Load Protected”
appears on the LCD display and indicates the incoming power is within voltage and
frequency acceptance windows. Three phase AC input power is converted to DC using a
full-wave, six-pulse, solid-state rectifier block which supplies unregulated DC voltage to a
boost converter which in turn supplies a higher, regulated DC voltage to the inverter.

A separate internal battery charger is used to maintain the proper charge level on the
battery during normal operation. The battery charger derives its input from the booster
output and provides regulated DC voltage and charge current to the battery. The battery
charge condition is monitored by the UPS and, when abnormal, reported by the status
indicators located on the LCD display. The battery is always connected to the UPS and
ready to support the inverter should the utility input become unavailable.

IA2

5-4 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

The DC boost converter derives power from the unregulated DC rectifier and produces a
higher, stable DC voltage and current source for the inverter. A fixed system neutral is also
carried through the boost converter to allow full support of single phase AC loads from any
phase of the inverter output. The output neutral of the system is connected to the required
neutral, both from the main utility supply and the bypass supply and should never be bonded
to protective earth ground at the UPS output.

The inverter produces three phase AC power to a customer load without the use of a
transformer. The inverter derives power from the boost converter regulated DC and utilizes
IGBT devices and pulse-width modulation (PWM) to produce a regulated and low harmonic
content AC output. The AC output of the inverter is delivered to the system output through
the output contactor K2.

If the utility AC power is interrupted or is out of specification, the UPS automatically switches
to Battery mode to support the critical load with no interruption. When utility power returns,
the UPS returns to normal mode.

If the UPS becomes overloaded or unavailable, the UPS switches to Bypass mode. The
UPS automatically returns to Normal mode when the overload condition is cleared and
system operation is restored within specified limits.

If the UPS experiences an internal failure, it switches automatically to Bypass mode and
remains in that mode until the failure is corrected and the UPS is back in service.

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 5-5
164201396 REV. A 071103

5.2.2 Bypass Mode

The UPS automatically switches to Bypass mode if it detects an overload, load fault, or
internal failure. The bypass source supplies the commercial AC power to the load directly.

Figure 5–3 shows the path of electrical power through the UPS system when operating in
the Bypass mode.

CAUTION:
The critical load is not protected while the UPS is in the Bypass mode.

Static Bypass

IA1

Battery

Static Switch

Battery
Breaker

Inverter

Battery
Charger

K2

NOTE: In this mode K2 is energized.
Switching between bypass and inverter
is performed by either turning on or off
the inverter IGBT or bypass switch.

Main Power

Trickle Current

Energized

De-Energized

IA2

Closed

Open

K1

F1

Breaker Contactors

K4

RectifierInput Filter Booster

Switches

Figure 5–3. Path of Current Through the UPS in Bypass Mode

In BYPASS mode, the output of the system is provided with three phase AC power directly
from the systems input. While in this mode, the output of the system is not protected from
voltage or frequency fluctuations or power outages from the source. Some power line
filtering and spike protection is provided to the load but no active power conditioning or
battery support is available to the output of the system in the bypass mode of operation.

The internal bypass is comprised of a solid state silicon controlled rectifier (SCR) static
switch (SSW), and a back feed protection contactor (K4). The static switch is rated as a
continuous duty device that is used anytime the boost converter and inverter is unable to
support the applied load. The static switch is wired in series with the back feed protection

5-6 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

contactor and together are wired to enable the inverter and rectifier to be bypassed when
this path is active. The static switch, as an electronically controlled device, can be turned on
immediately to pick up the load from the inverter. The backfeed protection contactor is
normally always closed, ready to support the static switch unless the bypass input source
becomes unavailable.

During an outage, transfers to bypass are prohibited and for the safety of those who may be
working on the power lines upstream from the UPS, the back feed protection contactor is
opened, preventing system output voltage from bleeding across the static switch snubber
components to the bypass input source. In the bypass mode, which can be used for higher
efficiency operation, the static switch is turned on to supply the load current directly from the
bypass supply, with the inverter ready to take over the load if the bypass supply should vary
outside preset limits.

If the inverter is unable to support the load on the output of the system, the UPS will transfer
the critical load to the internal bypass. The critical load will be transferred automatically to
the internal bypass if any of the following abnormal conditions occur on the output of the
system: If the output of the system exceeds acceptable voltage tolerances; Critical load
current exceeds the overload specifications of the inverter; Inverter failure. The transfer is
initiated by turning on the static switch and blocking the IGBT gate signal. This kind of
transfer is normally referred to as a Make-Before-Break transfer. The transfer takes place in
less than 4 ms (one-quarter cycle) to ensure loads on the systems output are not
interrupted. The static switch remains on until either the inverter is able to support the
system output or the unit is placed into a maintenance position where repairs can be made.

If the UPS initiates its own transfer to bypass for any reason other than operator
intervention, the UPS will attempt to restart the inverter (if not running already) and attempt
a retransfer back on line to support the output of the system. Three attempts will be made
within ten minutes to bring the inverter back on-line automatically before the UPS will lock
out any further attempts. After three attempts have been made, the UPS will remain in
bypass and an alarm condition will be annunciated. The UPS can also be transferred to
bypass using the front panel controls.

Bypass mode is a normal operating mode, not requiring an alarm condition. However, if the
UPS is unable to return to Normal mode following an automatic transfer to Bypass mode, an
alarm condition is recorded.

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 5-7
164201396 REV. A 071103

5.2.3 Battery Mode

The UPS transfers to battery mode automatically if a utility power outage occurs, or if the
utility power does not conform to specified parameters. In Battery mode, the battery
provides emergency DC power that the inverter converts to AC power.

Figure 5–4 shows the path of electrical power through the UPS system when operating in
Battery mode.

Battery Mode

IA1

Battery

Static Switch

Battery
Breaker

Inverter

Battery
Charger

K2

Main Power

Trickle Current

Energized

De-Energized

IA2

Closed

Open

K1

F1

Breaker Contactors

K4

RectifierInput Filter Booster

Switches

Figure 5–4. Path of Current Through the UPS in Battery Mode

During a utility power failure, the rectifier no longer has an AC utility source from which to
supply the DC output current required to support the battery charger and boost converter.
The input contactor (K1) is opened, the battery charger is turned off, and the battery SCRs
(+ and -) both receive signals to turn on to provide battery power to the system. Because
the battery SCRs are electronic devices, battery power is instantly available to the boost
converter so that the inverter and customers load can be supported without interruption. In
a single feed installation, where the bypass input is connected to the rectifier input, the back
feed protection contactor (K4) will also open. The opening of contactors K1 and K4
prevents static system voltage from bleeding backwards through the static switch and
rectifier snubber components and re-energizing the input source.

5-8 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

While in battery mode, the UPS will enunciate an audible horn, indicate the status change
on the front panel display with the message “MAINS NOT OK”, and make an entry into the
alarm event history. As the battery discharges, the boost converter and inverter constantly
make small adjustments to ensure a steady output. The UPS will remain in this operating
mode until the input power to the rectifier is again within the specified voltage or frequency
acceptance window.

If the input power fails to return or is not within the acceptance parameters required for
normal operation, the battery will continue discharging until a DC voltage level is reached
where the inverter output can no longer support the connected loads. When this occurs, the
unit will issue another set of audible and visual alarms indicating “BATTERY IN
DISCHARGE”. Unless the rectifier has a valid input soon, the critical load will only be
supported for about 3 minutes before the output of the system shuts down completely.
When this occurs, the LCD display will show the message “BATTERY DISCHARGED”.

If at any time during the battery discharge, the input power becomes available again,
contactors K1 and K4 are closed and the rectifier will begin to supply DC current to the
boost converter and inverter. The battery SCRs will be switched off while the battery
charger is turned back on to begin recharging the battery. At this point, the unit returns to
normal operation.

The systems total operating time on battery will depend on many factors. Some factors that
affect battery support times are battery type and capacity, number of parallel strings,
environmental temperatures, age of the battery, and fluctuations in load demand during the
discharge. The greater the load, the less support time the battery will provide. Decrease
the load and the battery support time will generally increase.

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 5-9
164201396 REV. A 071103

5.2.4 Maintenance Bypass Mode

An internal maintenance switch (IA1) is used to safely supply utility power to the system
output during periods of maintenance or repairs. Before this switch is used, the system
should be transferred to bypass. This switch has two positions: “O” (OFF) and “l” (ON).
When switched to “l” (ON), the bypass source supplies the commercial AC power to the
load directly.

While on internal (static) bypass, when a user rotates the maintenance switch from the
“O” (OFF) to the “l” (ON) position, the load is wrapped around the UPS, and power is
removed from the entire upper portion of the UPS allowing service work to be completed
on the UPS safely.

Figure 5–5 shows the path of electrical power through the UPS system when operating
in Maintenance Bypass mode.

CAUTION:
The critical load is not protected while the UPS is in the Maintenance Bypass
mode.

DANGER:
LETHAL VOLTAGE PRESENT: This unit should not be operated with the
cabinet doors open or protective panels removed. Do not make any
assumptions about the electrical state of any cabinet in the UPS system.

Maintenance Bypass Mode

IA1

K4

Static Switch

F1

Input Filter

Switches

Rectifier

Battery

Booster

Battery
Breaker

Inverter

Battery
Charger

K2

Main Power

Trickle Current

Energized

De-Energized

IA2

K1

Breaker Contactors

Closed

Open

Figure 5–5. Path of Current through the UPS in Maintenance Bypass Mode

5-10 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

Functional Description

5.3

The UPS is an online double-conversion unit with a series power train. An uncontrolled
rectifier feeds a boost converter, which in turn powers the inverter. The internal static
bypass utilizes a static switch and an independent maintenance bypass switch is also
included internal to the UPS cabinet. The unit input must be 4-wire in (plus ground) at
the rectifier and 4-wire in (plus ground) at the bypass. The output can be either 4-wire
plus ground or 3-wire plus ground depending on customer requirement. The unit does
not incorporate any galvanic isolation, input to output. The battery string comprises 240
cells (480 volts nominal) arranged in a positive string of 120 cells and a negative string
of 120 cells with the center of the series connected strings tied to system neutral, for the
80 kVA model. The 120 kVA model utilizes 144 cells on each side of the center
connection (nominal 288 volts positive and negative, for 576 volts total). The battery is
charged by positive and negative side chargers, which are powered from the output of
the boost converter.

5.3.1 Input Rectifier

The Input Rectifier is a full wave bridge uncontrolled rectifier, which produces
unregulated DC of approximately +390 and –390 volts DC. A pre-charge system
charges the DC bus prior to the input contactor being closed, to control inrush current to
no higher than rated current levels.

5.3.2 Boost Converter

A Boost Converter converts the raw DC input to a regulated DC link voltage of
approximately +450 and –450 volts DC. It is operated in the current mode and is
controlled using a variable modulation technique with a frequency in the range of
20 kHz. The neutral connection is maintained from the input to the output as a fixed
connection.

5.3.3 Inverter and Filter

The inverter is a traditional (current mode controlled) hard-switched IGBT 3-phase
topology. The IGBTs are modulated by a variable frequency, current-mode control
technique at approximately 20 kHz. An output filter filters out the high frequency
switching components (line to neutral).

5.3.4 Batteries and Battery Charger

The battery for the Powerware 80 kVA system is comprised of a positive string of 120
cells and a negative string of 120 cells, each made up of twenty 12-volt battery blocks.
For the Powerware 120 kVA system, the battery strings are 144 cells positive and
negative, respectively. The battery charger is divided into a positive side charger and a
negative side charger, each powered from the respective positive and negative
controlled DC bus voltages. The chargers operate automatically in the constant current

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 5-11
164201396 REV. A 071103

or constant voltage mode (temperature compensated, available as an option) based on
battery condition.
All batteries used in conjunction with the Powerware 9335 are external to the UPS
cabinet. The internal charger charges the entire battery system, with a maximum current
as indicated in Chapter 13, “Product Specifications”. Note that the higher the battery
capacity, the longer the recharge time required to fully recharge the batteries.

5.3.5 Static Bypass

The bypass has a continuous-duty SCR switch and a back-feed contactor (K4) in the
Bypass circuit. In normal mode, the contactor connects the inverter to the output. A
contactor (K2) provides isolation to the inverter when the system is on bypass.

5.3.6 Maintenance Bypass

A user accessible shrouded 4-wire Mechanical Maintenance Bypass switch is provided
internal to the cabinet.

5-12 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

Operational Controls and Features

)

(

6.1 General

The UPS system should function automatically and require very little attention during
normal operation. The controls and indicators identified in this section are used during
startup to monitor normal operation and during abnormal events.

Figure 6–1 identifies and shows the location of the controls and indicators on the
Powerware 9335 (80 kVA and 120 kVA) UPS. The descriptions provide a brief overview
of the UPS controls, and standard and optional features.

NOTE: Read the Operation section of this manual and have thorough knowledge of UPS

operation before attempting to operate any of the UPS controls or optional
components.

Customer
Communication
Interfaces

Maintenance
Bypass
Switch (IA1)

IA1 IA2

Customer
Power
Connections

Figure 6–1. Powerware 9335 (80 kVA and 120 kVA) Controls and Indicators

JD8

SW2-9

SW1-1

JD2

JD1

X4
X3
X2
X1

Control Panel

Rear side of User
control panel
(mounted on UPS
cabinet door)

System
configuration
DIP switches

SW1 & SW2)

Parallel Isolator
Switch (IA2)
(used only for
inverter output
isolation

6

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 6-1
164201396 REV. A 071103

6.2 UPS Operational Controls

The UPS has many standard features that provide cost effective and consistently reliable
power protection.

6.2.1 Control Panel

The Control Panel on the front of the UPS, pictured in Fig. 6–2, contains a LCD screen
to display the current status of the UPS system. You can view a statistical history and
log of system events and display a real-time representation of power flow through the
system components. LED status indicators show the operating mode of the UPS and
alert you to system events. Panel push buttons provide navigation through the
information and control screens. The load ON/OFF pushbuttons are located at the right
of the control panel. Both must be pressed simultaneously to activate the LOAD
ON/OFF function. Below the LCD screen are the user control pushbuttons, RESET, UP,
DOWN, and ENTER, which provide access to the control and measurement functions of
the UPS. The control panel is described in detail in chapter 7, “Using the Control Panel”.

LCD Display

System
ON/OFF

System Status LEDs

Display and Operation
Push Buttons

Figure 6–2. Powerware 9335 (80 kVA and 120 kVA) Control Panel

6.2.2 System and Load ON/OFF

Two load ON/OFF pushbuttons are located on the right side of the LCD display.
Activating both pushbuttons simultaneously will effect immediate system shutoff. This
feature prevents accidental system shutdown if one of the pushbuttons is inadvertently
depressed. System turn on is achieved in the same manner, by simultaneously
depressing both buttons. Operation of the system ON/OFF pushbuttons is described in
detail in Chapter 7, “Using the Control Panel” and Chapter 8, “UPS Operating
Instructions.”

6-2 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

6.2.3 Maintenance Bypass Switch

An internal Maintenance Bypass Switch is provided to completely isolate the main power
processing of the UPS during service. The Maintenance Bypass Switch is described in
detail in Chapter 8, “UPS Operating Instructions.”

6.2.4 Cold Start Capability

The 9335 UPS system cannot be powered up without a utility input initially present.
Accordingly, it is not able to power a load if the system is not started first on utility power.

6.3 UPS Standard Features

6.3.1 Customer Interface

Computer Interface

One serial communications port, using the standard Powerware XCP interface, is
provided via a plug-in interface card inserted in the communications slot on the front of
the unit. This interface is supplied as standard with each Powerware 9335. You can use
this port to link the UPS to the features described in Chapter 10, “Communications” and
Chapter 11, “Options.”

6.3.2 Battery Management

A two-stage charging system ensures that the initial recharge is done in an optimal time,
with current limited, constant current, DC applied to the batteries. When terminal voltage
reaches a certain level, the charger switches to constant voltage.

6.3.3 Installation Features

Power wiring can be routed through the rear and bottom of the UPS cabinet with
connections made to easily accessible terminal blocks at the bottom front of the cabinet.
External monitoring and communication control wiring must be installed in accordance
with approved wiring methods. Communication wiring can be routed through the top of
each cabinet.

Communication option cards are quickly installed in the slot behind the front door panel.
X-slot cards are hot pluggable.

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 6-3
164201396 REV. A 071103

6.4 Options and Accessories

Contact your sales representative for information about any of these available options:

6.4.1 Remote EMERGENCY POWER OFF

A REMOTE EMERGENCY POWER OFF pushbutton is an option to provide for
situations where you must instantaneously control the UPS output. The operation of the
REMOTE EMERGENCY POWER OFF pushbutton is described in detail in Chapter 8,
“UPS Operating Instructions.”

6.4.2 Battery Cabinets

A complete UPS system requires one or more battery cabinets to provide the necessary
DC backup power. Battery cabinets are designed to match with the UPS cabinet,
although they do not directly bolt together.

6.4.3 Communications

See Chapter 10, “Communications”.

6.4.4 Other Options

Refer to Chapter 11 of this manual to review other options available for the Powerware
9335 and their use.

6-4 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

6.5 Safety Considerations

The UPS enclosure is designed for industrial or computer room applications and contains
safety shields. However, the system is sophisticated and should be handled with
appropriate care, following these guidelines.

Keep surroundings clean and free from excess moisture.

•

Do not operate the system close to gas or electric heat sources.

•

The system is not intended for outdoor use.

•

• The system operating environment should be maintained within the parameters

stated in this manual.

Keep the system doors closed to ensure proper cooling airflow and to protect

•

personnel from dangerous voltages inside the unit.

• The system contains its own power source. Lethal voltages are present even
when the system is disconnected from utility power.

WARNING:
Only AUTHORIZED SERVICE PERSONNEL should perform service or
maintenance on the UPS.

If service or routine maintenance is required:

• Ensure all power is disconnected before performing installation or service.

Ensure the area around the UPS is clean and uncluttered.

•

Battery cabinet maintenance or battery replacement should be performed only

•

by authorized service personnel.

• Observe all DANGER, CAUTION, and WARNING notices affixed to the inside
and outside of the equipment.

• Always conform to the more detailed safety precautions described in
“Important Safety Instructions” section of Chapter 12, “Maintaining the UPS
System”.

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 6-5
164201396 REV. A 071103

A

pp

6.6 Symbols, Controls, and Indicators

These symbols may appear on your UPS system or on labels inside the UPS. Most
international safety agents accept them. Everyone in your organization who works with
your system should understand the meaning of these symbols:

PROTECTIVE GROUNDING TERMINAL
A terminal which must be connected to earth ground prior to
making any other connection to the equipment.

terminal to which or from which a direct current or voltage may

be a

This symbol indicates the word “phase”.

ON

OFF

DANGER: RISK OF ELECTRIC SHOCK
There is a risk of electric shock present, and you should observe
associated warnings. The UPS contains high voltages.

lied or supplied.

The principal power switch is in the “ON” position.

The principal power switch is in the “OFF” position.

CAUTION: REFER TO MANUAL

Stop and refer to the Operator’s Manual for more information

6-6 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

Using the Control Panel

A

7.1 Description

This chapter describes the UPS Control Panel, including controls and indicators, and
how to monitor UPS operation. The control panel is located on the front of the UPS
(see Figure 7–1).

7

2

1

4

BYPASS

LARM

LINE 1

The Control Panel contains:

Refer to Chapter 8, “UPS Operating Instructions” for use of the operational controls.

INV

3

Figure 7–1. UPS Control Panel

1) the main power ON/OFF switches

2) a flat Liquid Crystal Display (LCD) screen

3) a horizontal row of navigation pushbuttons

4) an array of multi-color LED status indicators

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 7-1
164201396 REV. A 071103

A

7.2 Using the Control Panel

The Control Panel provides an operator interface with the UPS system. Figure 7–2
identifies the display and pushbutton areas discussed in the following sections as well as
LED indicators that provide a visual display of system operating status.

LOAD S
PROTECTED

RESET

Figure 7–2. LCD Screen and Pushbuttons

7.2.1 Power Management Display

The 2 x 20 character LCD Screen simplifies the communication with the UPS and
provides the necessary monitoring information about the UPS. The menu driven LCD
Screen enables access to the

1) EVENT REGISTER

2) Measurements of input and output voltage, current, frequency, power and
battery runtime

3) System commands for start-up and shut-down of the UPS and load transfer
from INVERTER to BYPASS and return

4) DIAGNOSIS (SERVICE MODE)

5) Adjustments and testing information

7.2.2 LED Indicators

The LED indicators display the general status of the UPS. Indicators show the power
flow status and in the event of power failure or load transfer from inverter to bypass or
vise-versa, the corresponding LED indicators will change color from green (normal) to
red (warning). The LINE 1 and LINE 2 LEDs indicate the availability of the input power
supply. The INVERTER and BYPASS LEDs, if green, indicate which of the two power
paths is supplying power to the critical load. When the battery is supplying the load, due
to supply failure, the BATTERY LED will be flashing. The ALARM LED is a visual
indication of any internal or external alarm conditions. At the same time, an audible
alarm will be activated.

LARM

ON/OFF

ON/OFF

7-2 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

INDICATOR INDICATOR STATUS MEANING

ALARM OFF

RED + BUZZER
RED

LINE 1 GREEN

RED

LINE 2 GREEN

RED

BYPASS GREEN

OFF

INV GREEN

RED
OFF

BATTERY GREEN

RED
Flashing GREEN
Flashing GREEN

No alarm condition
Alarm condition
Alarm condition persists
Utility supply to rectifier available
Utility supply to rectifier not available
Bypass supply available
Bypass supply not available or not OK
Load on bypass (Bypass or Eco-mode)
Bypass not operating (or switched off)
Load on inverter
Inverter fault or load not transferable to inverter
Inverter not operating (switched off)
Battery OK
Battery fault or battery is discharged
Battery discharging or battery fuse open
Load OFF command issued

7.2.3 Pushbutton Functions

The pushbuttons allow the user to operate the UPS to perform settings and adjustments,
to start-up and shutdown the UPS, and to monitor on the LCD display the voltages,
currents, frequencies and other variables of system operation.

KEYS FUNCTION

ON/OFF

ON/OFF
UP ( ) Move upwards through the menu
DOWN ( ) Move downwards through the menu
RESET Move to the top of the menu. Cancel the audible alarm. If the alarm

ENTER Confirms a chosen menu item

Turn-on UPS system (press both pushbuttons simultaneously)

or

Shutdown the UPS (press both pushbuttons simultaneously)

condition was only transient, the LED indicator (ALARM) will also
extinguish, otherwise it will remain on (RED)

7.2.4 ON/OFF Startup and Shutdown Pushbuttons

By pressing simultaneously both ON/OFF pushbuttons on the Control Panel, the UPS
can be switched on (if currently OFF) or shutdown immediately (if currently ON).
Requiring both to be simultaneously depressed prevents accidental operation of the
UPS. The two main ON/OFF pushbuttons are also used as a security ON/OFF switch,
making it possible to quickly disconnect the load from the UPS in emergency situations.
Upon startup from initial install or power off disconnect, the UPS starts in NORMAL
(inverter) mode. In subsequent startups, the system will return to the mode previously
used before shutdown, except that ECO mode will require operator intervention to
activate.

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 7-3
164201396 REV. A 071103

CAUTION:
ACTIVATION OF THE ON/OFF PUSHBUTTONS WHEN THE UPS IS NOT IN
MAINTENANCE BYPASS MODE WILL INTERRUPT THE POWER SUPPLY TO
THE CRITICAL LOAD.

If, for security or emergency reasons, it is necessary to immediately disconnect the load
from the UPS, press the two red ON/OFF pushbuttons simultaneously. In this case,
make sure that the maintenance bypass switch (IA1) is in the “O” position (Normal=Off).

7.3 Description of the LCD Screen

7.3.1 Status Screens

DESCRIPTION LCD DISPLAY

Load is protected by UPS power. It is
supplied by the inverter (normal operation)

Load is not protected by UPS power. It is
supplied by utility power. (load on bypass)

Load supply is completely interrupted. UPS
has been switched off by “ON/OFF” buttons

NOTE:

On the right hand side of the LCD display there should be a character “S”

indicating the Single Module is operational.

LOAD

PROTECTED

LOAD

NOT PROTECTED

LOAD OFF

SUPPLY FAILURE

S

S

S

7-4 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

7.3.2 LCD Display Structure and Navigation

The menu structure is shown in Figure 7–3, below. Navigation through the menu is
accomplished by using the “ENTER” pushbutton to go to the menu level, or to activate
an action, then using the “UP” or “DOWN” arrows to select a specific function within
each menu category. The “RESET” pushbutton will immediately return to the highest
screen.

LOAD
PROTECTED

EVENT LOG

LOAD

NOT PROTECTED

LOAD OFF
SUPPLY FAIL

MEASUREMENTS

UPS DATA

SET-UP USER

Figure 7–3. LCD Screen Navigation Chart

PRESS RESET, RETURNS TO TOP LEVEL

• HH-MM-SS

LOAD TO INV.

02-27-02 HH-MM-SS

LOAD TO BYP.

02-27-02 HH-MM-SS

LOAD OFF

LOAD TO INVERTER

COMMANDS

BYPASS

LOAD TO

PERFORM

BATT.TEST

UPS SERIAL NUMBER
M-

DATE OF MANUFACTURE

DATE TIME

BATT. RUN TIME (MIN)

0.0

OUTPUT FREQUENCY (HZ)

60.00

BYPASS FREQUENCY (HZ)

60.00

BATTERY VOLTAGE (V)

+ 240 -240

BATT. CHARGE CUR. (A)

+ 0.0 -0.0

DISCHARGE CURRENT (A)

0

RECTIFIER VOLTAGE (V)

000 000 000

BYPASS VOLTAGE (V)

000 000 000

OUTPUT VOLTAGE (V)

000 000 000

OUTPUT CURRENT (A)

00 00 00

ACTIVE POWER (kW)

00 00 00

REACTIVE POWER (KVAR)

00 00 00

APPARENT POWER ((KVA)

00 00 00

OUTPUT POWER (%)

00.0 00.0 00.0

BATT. CAPACITY (%)

00

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 7-5
164201396 REV. A 071103

0.0

60.00

60.00

7.3.3 Main Menu Screen

DESCRIPTION LCD DISPLAY

•

Logging Control. A log of the last 64 events is

stored in the Power Management Display.

•

Menu Measurements allow monitoring voltages,

power, frequencies, current, battery run time,
and other information.

• Command Menu enables performance of
“Load to Inverter”, “Load to Bypass”, and
battery test functions.

• UPS Data Menu shows UPS serial number,
date of manufacture, current time & date.

• Set-Up Menu allows user to set Date/Time,
automatic battery test and gen-set mode

• Set-Up Menu for service allows trained.
service personnel to troubleshoot and
adjust system parameters.

7.3.4 Event Log Screen

DESCRIPTION LCD DISPLAY

• Logging Control (sample screen)

• A log of the last 64 events is stored

and presented under the Event Log.

• All events and alarms are displayed
with their date and time of occurrence.

EVENT LOG

MEASUREMENTS

COMMANDS

UPS DATA

SET-UP USER

SET-UP SERVICE

02-27-02 17-03-30
LOAD TO INV.

02-27-02 17-03-30
LOAD TO BYP.

02-27-02 17-03-30
LOAD OFF

7.3.5 Measurements Screen

DESCRIPTION LCD DISPLAY

• Battery Runtime remaining (in minutes)

•

UPS Output Frequency

•

Bypass Frequency

7-6 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

BATT. RUN TIME (MIN)

OUTPUT FREQUENCY (HZ)

BYPASS FREQUENCY (HZ)

164201396 REV A 071103

• Battery Voltage

Battery Charger Current

•

•

Discharge Current

• Rectifier Voltage (all three phases)

• Bypass Voltage (all three phases)

•

Output Voltage (all three phases)

• Output Current (all three phases)

• Active Output Power (all three phases)

•

Reactive Output Power (all three phases)

• Apparent Output Power (all three phases)

BATTERY VOLTAGE (V)

+240 -240

BATT. CHARGE CUR. (A)

+ 0.0 - 0.0

DISCHARGE CURRENT (A)

+ 0.0 - 0.0

RECTIFIER VOLTAGE (V)
00 0

BYPASS VOLTAGE (V)
00 0

OUTPUT VOLTAGE (V)
00 0

OUTPUT CURRENT (A)
00 0

ACTIVE POWER (kW)
00 0

REACTIVE POWER (kVAR)
00 0

APPARENT POWER (KVA)
00 0

• Output Power (%, all three phases)

•

Battery Capacity remaining

7.3.6 Commands Screen

DESCRIPTION LCD DISPLAY

• Transfer Load to Inverter

•

Transfer Load to Bypass

• Battery Test

OUTPUT POWER (%)
0% 0% 0%

BATT. CAPACITY (%)
0%

LOAD TO INVERTER

LOAD TO BYPASS

PERFORM BATT. TEST

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 7-7
164201396 REV. A 071103

7.3.7 UPS Data

DESCRIPTION LCD DISPLAY

• Information displayed is installed
at the time of manufacture.

• Manufacturing Date

•

•

EPROM Version

Actual Date and Time (set by user
under user set-up menu.

7.3.8 Set-Up User

DESCRIPTION LCD DISPLAY

•

(Press ENTER to access)

• Set-up Battery test

(Press ENTER to access)

Set-up Date and Time

UPS SERIAL NUMBER
M-

DATE OF MANUFACTURE
DD-MM-YY

EPROM VERSION
V-000

DATE TIME
DD-MM-YY HH-MM-SS

DD-MM-YY HH-MM-SS

SET-UP DATE/TIME

SET-UP BATT. TEST

DAY OF MONTH

HOUR OF DAY

REPETITIVE (Y/N)

• Set-up operation with Gen-Set

(Press ENTER to access)

•

• Command to prevent use of static bypass

7-8 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

Command to prevent battery charger
operation when on generator operation.

when on generator operation.

SET-UP GEN-SET OPER.

BATTERY CHARGE LOCK
(Y/N)

BYPASS
LOCK/UNLOCK

164201396 REV A 071103

7.3.9 Set-Up Service

DESCRIPTION LCD DISPLAY

•

This menu is reserved for authorized
service engineers. It is not to be
accessed by End-Users.

• Type in password.

NOTE:

Apart from the adjustment of voltages, frequencies, currents, power and battery
run time in the SET-UP Service menu, it is also possible to set and check the
following parameters:

• UPS Rated Power

• Module configuration S or future alternate module configurations

•

Single (standard) or Dual Input feed

•

F-converter, 50/60Hz or 60/50Hz

•

Sync window (2-4%)

SET-UP SERVICE

PASSWORD

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 7-9
164201396 REV. A 071103

7.4 O perating Modes

7.4.1 “ON LINE” Mode (INVERTER MODE)

The ON-LINE Mode is the UPS Operating Mode in which the load is supplied through
the RECTIFIER and INVERTER. LED indicators are illuminated when shown shaded:

LED’s green
when shown
shaded

LINE 2 BYPASS

BATTERY

LINE 1 INV.

Using the control panel (see Figure 7–2) the UPS can easily be transferred to the ON­LINE mode. The ON-LINE mode provides the highest degree of protection, especially in
the event of a supply disturbance or failure. This operating mode is always
recommended if the critical loads (computer systems) will not tolerate any interruption of
the supply, even for a very short time. In the unlikely event of an inverter fault or
overload condition, the UPS will transfer the load automatically and without interruption
to the static bypass-utility supply.

7.4.2 “OFF LINE” Mode (BYPASS or ECONOMY MODE)

In the OFF-LINE mode, the load is supplied from the utility supply through the bypass.
Using the control panel (see Figure 7–2), the UPS may be easily transferred to “Bypass
Mode”.

LED’s green
when shown
shaded

When the UPS is operating in “Bypass Mode”, the efficiency of the system is higher. In
the event of a utility supply failure the load will automatically be transferred from utility to

7-10 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

LINE 2 BYPASS

BATTERY

LINE 1 INV.

164201396 REV A 071103

inverter within 5 milliseconds. When utility power returns, the UPS will startup in

p

NORMAL (inverter) mode. Operator intervention is required to reset to ECO mode.
The battery
recommended only if the loads can tolerate power interruptions of up to 5 ms, the
transfer time from Bypass Mode to ON-LINE Mode.

CAUTION:
In order to provide the load with maximum protection, it is always
recommended that the load be supplied by the inverter (ON-LINE Mode).

charger remains active in the “Bypass-Mode”. The “Bypass-Mode” is

7.4.3 “MAINTENANCE BYPASS” Mode

The Maintenance Bypass Mode is performed by means of the IA1 BYPASS SWITCH on
the front of the UPS. When the switch is in the “O” (OFF) position, the Bypass Switch is
OPEN. This is the normal operating condition, where the load is supplied by the
inverter, or via the static bypass. When the switch is in the “I” (ON) position, the Bypass
Switch is CLOSED, causing load power to be supplied directly from the utility source.

LED’s green
when shown
shaded,
unless noted

CAUTION:
Before transferring the load to Maintenance Bypass using the IA1 switch,
always make sure that the UPS cabinet is in the “Bypass-Mode”. Failure to
observe this

CAUTION:
When the UPS is operated in the Maintenance Bypass mode through the Bypass
Switch IA1, the load will not be protected in the event of a utility supply failure.
It is therefore strongly recommended that the user switch back to ON-LINE
(INVERTER ON) or BYPASS (OFF-LINE MODE) as soon as possible.

LINE 2 BYPASS

BATTERY

(Red)

LINE 1 INV.

rocedure can cause equipment damage.

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 7-11
164201396 REV. A 071103

7.4.4 Parallel Isolator (IA2)

The UPS unit is provided with an output isolator switch (IA2) which, when opened,
isolates the corresponding unit from the LOAD. Once IA2 is open, there is no power
coming from the inverter. This switch should always be in the “I” (ON) position, except
for servicing the UPS when in the maintenance bypass mode. Rotating this switch to the
“O” (OFF) position while the inverter is supplying power to the load will dump the critical
load. This switch is also provided for future expansion requirements.

WARNING:
Rotating the output isolator switch (IA2) to the “O” (OFF) position when the
maintenance bypass switch (IA1) is in the “O” (OFF) position will interrupt
power to the critical load.

7-12 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

UPS Operating Instructions

8

8.1 Operation

The following procedures provide instruction for operating the UPS system. Refer to

Chapters 6 and 7 of this manual for a description of the UPS controls and monitor panel
functions.

NOTE:

8.2 Start-Up Procedure for the UPS

To start the UPS system for normal operation, perform the following procedure:

1. Ensure the UPS switches and external customer circuit breakers are set as follows:

2. Close the UPS utility supply breaker. (Screen event “MAIN RECTIFIER FAULT”

3. If system is dual source, close the UPS Bypass input circuit breaker

4. Observe LED Line 1 indicator turns green and battery indicator LED flashes green.

5. Press both ON/OFF pushbuttons on the control panel simultaneously to turn on the

Before starting the UPS, ensure all installation tasks are complete and

authorized service personnel have performed a preliminary startup. The
preliminary startup verifies all electrical interconnections to ensure the
installation was successful and the UPS operates properly.

CAUTION:
All the operations in this section must be performed by authorized service
technicians or by qualified internal personnel.

UPS Utility Supply Breaker (customer supplied) “O” (OPEN)
UPS Bypass Input Breaker (dual source, customer supplied) “O” (OPEN)
UPS Battery Cabinet Breaker (customer supplied) “O” (OPEN)
UPS Maintenance Bypass Switch (IA1) “O” (OFF)
UPS Parallel Isolator Switch (IA2) “O” (OFF)
Verify Position of DIP Switches SW 2–9 are as in Fig. 6-1. As shown

appears)

(Screen event “LOAD OFF SUPPLY FAILURE” appears)

UPS. “LOAD NOT PROTECTED” will appear on the LCD screen and LED indicators
will display as follows:

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 8-1
164201396 REV. A 071103

LED Indicator Color

LINE 1 Green
LINE 2 Green
BYPASS Green
INVERTER OFF
BATTERY Flashing Green

6. If necessary, perform Command: LOAD TO INVERTER (see sections 7.3.2 and

7.3.6) On LCD Display, “LOAD PROTECTED” will appear and the LED-indicators
will display as follows:

LED Indicator Color

LINE 1 Green
LINE 2 Green
BYPASS OFF
INVERTER Green
BATTERY Flashing Green

7.

Close the external battery cabinet circuit breaker.

8. Scroll through the measurements menu and verify that battery polarity and voltage

are proper and within prescribed limits (see sections 7.3.2 and 7.3.5). For the
80 kVA model, the voltages will be about +260 and –260. For the 120 kVA model,
the voltages will about +312 and –312 volts.

9. Close Parallel Isolator Switch (IA2) to position “I” (ON). UPS power is now present

on the output terminal block and “LOAD PROTECTED” will appear on the LCD
display. After 45-120 seconds, the battery LED will change from Flashing Green to
Solid Green. This state change will take up to one minute.

On initial start-up follow steps 9-14. On re-start stop at 9.

10. Perform load transfer to Maintenance Bypass

• Use Menu COMMANDS on UPS control panel and choose “LOAD TO

BYPASS” (see sections 7.3.2 and 7.3.6) to transfer the load to the bypass
source.

• Close Maintenance Bypass Switch (IA1) to position “I” (ON). The LCD

display will show “MANUAL BYP. CLOSED” and the LED indicators will
appear as follows:

LED Indicator Color

LINE 1 Green
LINE 2 Green
BYPASS Green
INVERTER Red
BATTERY Green

11. Connect load to the UPS output

• Close external output circuit breakers in the load distribution panel

•

Verify on the LCD Display and LED indicators that the load is on Bypass.

8-2 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

12. Rotate the Maintenance Bypass Switch IA1 to the “O” (OFF) position. On the LCD

Display, “MANUAL BYP. OPEN” will appear followed by “LOAD NOT PROTECTED”.

13. Using the Measurements menu (see sections 7.3.2 and 7.3.5) verify proper values

for output powers, voltages, currents and frequencies.

14. Perform Load transfer to Inverter

• Go to COMMANDS menu on UPS cabinet control panel and choose

command “LOAD TO INVERTER” to transfer the load to inverter output.
(see sections 7.3.2 and 7.3.6)

•

On LCD Display, “LOAD PROTECTED” will appear.

15. Repeat step 13 above to verify that all voltages, currents, power and frequency are

correct.

16. Once the above procedure is performed at initial start-up, subsequent start-ups may

be performed using only step 14, as long as other conditions are unchanged.

THE POWERWARE 9335 UPS NOW PROTECTS THE LOAD.

8.3 Complete Shutdown Procedure for the UPS

The Powerware 9335 may be shut down completely if the load does not need input
power for an extended period of time.

The UPS system may be switched to Maintenance Bypass Mode for service or
maintenance purposes, or transferred to the ECO-Mode if the load does not need the
highest degree of protection and efficiency is to be maximized.

The load may be disconnected by means of the two ON/OFF (LOAD-OFF) pushbuttons
for security or operational reasons.

CAUTION:
If the Powerware 9335 will remain deactivated for an extended period of time,
provision must be made for periodic recharge of the system batteries.

CAUTION:
All the operations in this section must be performed by authorized service
technicians or by qualified internal personnel.

CAUTION:
Activation of both ON/OFF buttons simultaneously during normal operation
will switch off the UPS output and no longer supply power to the load.

1. Verify that the loads are shut down and that there is no need for power supply to the

load.

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 8-3
164201396 REV. A 071103

V

Q

2. If the loads are all disconnected, press simultaneously the two ON/OFF buttons on

the UPS control panel. On the LCD Display, “LOAD OFF, SUPPLY FAILURE” will
appear and the LED-indicator will indicate as shown below:

LED Indicator Color

LINE 1 Green
LINE 2 OFF
BYPASS OFF
INVERTER OFF
BATTERY Flashing Green

3. Rotate the Parallel Isolator Switch (IA2) to the “O” (OFF) position.

4. Open battery cabinet breakers in external battery cabinets or racks.

5. Open the input utility supply circuit breakers, if used.

THE POWERWARE 9335 IS NOW VOLTAGE FREE.

8.4 Load Transfer to Maintenance Bypass

If it is necessary to perform service or maintenance on the UPS, it is possible to transfer
the UPS to MAINTENANCE BYPASS.

CAUTION:
BEFORE YOU ROTATE THE MAINTENANCE BYPASS SWITCH TO POSITION
“I” (ON ), MAKE SURE THAT THE LOAD HAS BEEN TRANSFERRED TO THE
BYPASS MODE. EVEN THOUGH THE UNIT IS IN BYPASS MODE, LETHAL

OLTAGE IS STILL PRESENT WITHIN THE UPS CABINET.

CAUTION:
ALL THE OPERATIONS IN THIS SECTION MUST BE PERFORMED BY
AUTHORIZED ELECTRICIANS OR BY

Status of the UPS-System before starting the Transfer Procedure to Maintenance
Bypass

The load is protected by the Powerware 9335 UPS system in normal operation (the UPS
is operating on inverter).

1) Load transfer to Maintenance Bypass

• Go to Menu COMMANDS and choose command “LOAD TO BYPASS” and

transfer the load to utility supply on control panel of the UPS cabinet.
On the LCD Display: “LOAD NOT PROTECTED” will appear.

UALIFIED INTERNAL PERSONNEL.

8-4 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

• Rotate the Maintenance Bypass Switch IA1 to “I” (ON)

On LCD Display: “MANUAL BYP CLOSED” will appear and the LED
indicators will indicate as shown below:

LED Indicator Color

LINE 1 Green
LINE 2 Green
BYPASS Green
INVERTER Red
BATTERY Green

2

) Simultaneously press both ON/OFF pushbuttons on the UPS cabinet control panel.

• On the LCD Display: “LOAD OFF, SUPPLY FAILURE” will appear and the

LED indicators will indicate as shown below:

LED Indicator Color

LINE 1 Green
LINE 2 OFF
BYPASS OFF
INVERTER OFF
BATTERY Flashing Green

3) Rotate the Parallel Isolator Switch IA2 to “O” (OFF).

4) Open battery breakers in the external battery cabinet or racks

THE LOAD IS NOW SUPPLIED BY THE UTILITY MAINS AND IS NOT PROTECTED.

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 8-5
164201396 REV. A 071103

This page left intentionally blank.

8-6 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

Resp

onding to System Events

9

9.1 Alarms

In the event of an alarm condition, the red LED-Indicator “Alarm”
and the audible alarm will turn on.

In this case proceed as follows:

A. Silence the audible alarm by pressing the "Reset" button.
B. Identify the cause of the alarm condition by means of the

EVENT LOG in the MAIN menu.

C.

In case of alarm conditions, please contact the Global
Service Center.

D. Fault identification and suggested corrective action is given

on the following pages.

9.2 Menu, Commands, Event Log, and Measurements

In Chapter 4 there is a detailed description of the Menu, Commands,
Event Log and Measurements that can be operated and displayed on the
LCD. The List of Alarms and Messages are shown in Section 9.3.

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 9-1
164201396 REV. A 071103

9.3 Fault Identification and Correction

The major alarm conditions that will be encountered are shown in the following table:

Alarm Condition Meaning Suggested Solution

UPS FAULT

MAINS FAILURE

OVERCURRENT OR
SHORT CIRCUIT

OVERLOAD

OVERTEMPERATURE

BATTERY CHARGER
OFF

There is a fault in the UPS
and therefore normal
operation cannot be
guaranteed.

The utility power supply is
outside its prescribed tolerance.

There is a short circuit at the
output of UPS. (on load side)

Load exceeds the UPS rated
power.

UPS temperature has exceeded
the allowed value.

The attached battery and the
battery charger set-up do not
correspond or battery charger
fault.

Call the authorized service center for
assistance

The input power to UPS is too low or
missing.
If site power appears to be OK, check the
input circuit breakers etc. supplying the
UPS

Check all output connections and repair
as required.

Identify which piece of equipment is
causing the overload and remove it from
the UPS.

Check that the ambient temperature of the
UPS is less than 30° C.
If the ambient temperature is normal call
the authorized service center for
assistance.

Call the authorized service center for
assistance.

INVERTER FAULT

NON-SYNCH

BATTERY LOW

MANUAL SWITCH OFF

9-2 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

Inverter is faulty. Call the authorized service center for

assistance.

The inverter and utility power
are not synchronized.

The battery is nearly
discharged.

Maintenance Bypass closed.
Load supplied by utility power.

The frequency of the input voltage to the
UPS is outside operational limits and the
UPS static bypass has been temporarily
disabled.

Shutdown load connected to UPS before
the UPS switches itself off to protect its
batteries
This alarm is only displayed if the UPS is
on Maintenance Bypass

164201396 REV A 071103

Communications

10.1 X – Slot Communication Modules

This section describes the several types of X–Slot cards, which can be used with the
Powerware 9335. X-Slot cards allow the UPS to communicate to a variety of
environments and with different types of devices. The Powerware 9335 is compatible
with any X–Slot card, including, but not limited to:

• ConnectUPS

web-based remote monitoring in addition to SNMP capabilities.

• ConnectUPS

SNMP-based remote monitoring.

• Single-Port Card – provides one serial communication port.

• USB Card – provides a USB connection to your Windows PC.

• Multi-Server Card – provides additional serial communication ports that can

communicate with additional computers.

TM

SNMP/WEB Card – provides 10Base-T Ethernet connectivity for

M SNMP Card – provides 10Base-T Ethernet connectivity for

10

• Modbus Card – provides RS-485 and RS-232 Modbus RTU connectivity for

integration with building management systems.

• Relay Card – provides dry relay contacts for AS/400 signal compatibility.

The Powerware 9335 is factory installed with a Single-Port Serial Card.

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 10-1
164201396 REV. A 071103

X–Slot location
for insertion of
X–Slot Cards

JD8

SW2-9

SW1-1

X4
X3
X2

X1

JD2

JD1

IA1 IA2

Figure 10–1. X–Slot Location on Front of Powerware 9335 UPS Cabinet

Control Panel

10.2 Single-Port Serial Card

To establish communications between the UPS and a computer, connect your computer
to the UPS communication port using the supplied communication cable.

When the communication cable is installed, power management software installed on
your computer can exchange data with the UPS. Powerware supplies monitoring
software with each UPS. See instructions packaged with the software for installation
and operation. The software polls the UPS for detailed information on the status of the

10-2 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 071103

power environment. If a power emergency occurs, the software initiates the saving of all
data and an orderly shutdown of the connected critical load.

The cable pins are identified in Figure 10–2 and the pin functions are described in
Table 10–1.

Figure 10–2. The Communication Port on the Single Port Serial Card

Pin Number Function Input or Output
1 Low Battery Open Collector signal – pulls to common

when the UPS reaches low battery level
2 RS-232 Transmit Data Output
3 RS-232 Receive Data Input
4 Plug and Play sense Input
5 Signal Common (tied to chassis) –
6 Tied internally to pin 4 Output
7 No Connection –
8 AC Fail Open Collector signal – pulls to common during

a power failure
9 DC Supply Voltage (+8 to 24 volts DC power) Output

Table 10–1. Communication Port Pin Assignments

45 23

89

1

7 6

Output

Output

Powerware 9335 (80 kVA and120 kVA) Installation and Operation 10-3
164201396 REV. A 071103

This page left intentionally blank.

10-4 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
