PTID-3600/ PTID-3600T
In-Dash 3.6” Monitor
Touch Sensor
DVD/CD/MP3/MP4
MW/FM Radio
Built-in TV tuner
Owner’s Manual
Take the time to read through this owner’s manual.
Familiarity with installation and operation procedures will help you obtain the best Performance from your new DVD-receiver.
Table of Contents |
|
||
Table of Contents....................................................................................................................... |
1 |
||
Important Safeguards................................................................................................................. |
2 |
||
Accessories ....................................................................................................................... |
3 |
||
Installation/Un-Installation .............................................................................................................. |
4 |
||
Wiring Connections....................................................................................................................... |
5 |
||
Detachable Control Panel ........................................................................................................ |
6 |
||
Panel Controls……………..........................................................................................................7 |
|||
IR Remote Controls ........................................................................................................................ |
8 |
||
General Operations.................................................................................................................... |
9 |
||
Digital Tuner................................................................................................................................... |
12 |
||
Memory Card/ USB Operations.................................................................................................. |
12 |
||
Disc |
operations.................................................................................. |
...........................................15 |
|
MP3 |
overview.............................................................................. |
............................................18 |
|
TV OPERATIONS.......................................................................... |
............................................19 |
||
Compatible Files ............................................................................................................................ |
20 |
||
SETUP Menu ...................................................................................................................... |
20 |
||
Other Functions..................................................................................... |
..........................................22 |
||
Anti-theft |
system.................................................................................... |
........................................22 |
|
Note |
on |
Discs................................................................................ |
.............................................23 |
Troubleshooting Guide .............................................................................................................. |
24 |
||
Specification............................................................................................................................. |
25 |
||
Page - 1
Important Safeguards
zUsing the device at temperature below -10 may cause the breakage of the device. BEFORE USING PLEASE HEAT UP THE PASSENGER COMPARTMENT TO THE RECOMMENDED TEMPERATURE!
zRead carefully through this manual to familiarize yourself with this high-quality sound system.
zDisconnect the vehicle's negative battery terminal while mounting and connecting the unit.
zWhen replacing the fuse, be sure to use one with an identical amperage rating. Using a fuse with a higher amperage rating may cause serious damage to the unit.
zDO NOT attempt to disassemble the unit. Laser beams from the optical pickup are dangerous to the eyes.
zMake sure that pins or other foreign objects do not get inside the unit; they may cause malfunctions, or create safety hazards such as electrical shock or laser beam exposure.
zIf you have parked the car for a long time in hot or cold weather, wait until the temperature in the car becomes normal before operating the unit.
zDO NOT open covers and do not repair yourself. Consult the dealer or an experienced technician for help.
zMake sure you disconnect the power supply and aerial if you will not use the system for a long period or during a thunderstorm.
zMake sure you disconnect the power supply if the system appears to be working incorrectly, e. g, making unusual sounds, smelling strange, emitting smokes from inside or liquid having gotten inside it Have a qualified technician check the system.
zThe unit is designed for negative terminal of the battery, which is connected to the vehicle metal. Please confirm it before installation.
zDo not allow the speaker wires to be shorted together when the unit is switched on. Otherwise it may overload or burn out the power amplifier.
zDo not install the detachable panel before connecting the wire.
zDon't remove the detachable panel when encoding.
Page - 2
Accessories
Package contains the following accessories for installation and operation of the unit.
(1) Washer, Spring
Washer, M5 Nut
(2) Mounting Strap
(3) Screw
(4) Bolt
(5) Mounting Collar
(6) Release Key
(7) Rubber Cushion
AV in Cable |
Panel Carrying Case |
Owner’s Manual |
Remote Controller |
Page - 3
Installation/Un-Installation
First complete the electrical connections, and then check them for correctness.
Installation
This unit can be installed in any dashboard having an opening as shown on the picture. The dashboard should be 4.75 – 5.56 mm thick in order to be able to support the unit.
1.Insert mounting collar into the dashboard, and bend the mounting tabs out with a screwdriver. Make sure that lock lever is flush with the mounting collar (not projecting outward).
2.Secure the rear of the unit.
After fixing mounting bolt and power connector, fix the rear of the unit to the car body by rubber cushion.
3. Insert trim plate.
When you prepare to insert trim plate, please check its direction. Once it was up side down, it cannot be fixed.
Lock lever
Un-installation
Remove Trim Ring and insert Release Keys into left and right side-end holes as shown in below picture and pull the unit out of the dashboard.
Page - 4
Wiring Connections
Make sure you have good chassis ground. A good ground connection will eliminate most electrical noise problems. A good
chassis ground requires a tight connection to the vehicle’s metal chassis. The area around the ground connection should be clean, bare metal without rust, paint, plastic, dust, or dirt for a good electrical connection.
**TV antenna is for PTID-3600T only.
Caution: Do not interchange the connection of the wiring!!!
For some car models you may need to modify wiring of the supplied power cord. Contact your authorized car dealer before installing this unit.
Using the ISO Connector
1.If your car is equipped with the ISO connector, then connect the ISO connectors as illustrated.
2.For connections without the ISO connectors, check the wiring in the vehicle carefully before connecting, incorrect connection may cause serious damage to this unit.
3.Cut the connector, connect the colored leads of the power cord to the car battery as shown in the color code table below for speaker and power cable connections.
Location |
Function |
|
|
|
Connector A |
Connector B |
|
1 |
|
Rear Right(+)---Purple |
|
2 |
|
Rear Right(-)---Purple/Black Stripe |
|
3 |
|
Front Right(+)---Grey |
|
4 |
Battery 12V |
Front Right(-)---Grey/Black Stripe |
|
(+)/yellow |
|||
|
|
||
5 |
Auto Antenna/blue |
Front Left(+)---White |
|
6 |
|
Front Left((-)---White/Black Stripe |
|
7 |
ACC+/red |
Rear Left(+)---Green |
|
8 |
Ground/black |
Rear Left(-)---Green/Black Stripe |
Page - 5
Detachable Control Panel
Detaching the control panel
zTurn the Power off.
zPress OPEN button release the panel.
zPull the panel out.
Attaching the control panel
zInsert the left side of the control panel into the main unit.
zPress the control panel right side until the “click” sound is heard.
Caution:
DO NOT insert the control panel from the right side. It can damage the control panel.
The control panel can easily be damaged by shocks. After removing it, place it in a protective case and be careful not to drop it or subject it to strong shocks.
The rear connector that connects the main unit and the control panel is an extremely important part. Be careful not to damage it by pressing on it with fingernails, pens, screwdrivers, etc.
Note:
If the control panel is dirty, wipe off the dirt with soft, dry cloth only. And use a cotton swab soaked in isopropyl alcohol to clean the socket on the back of the control panel.
Page - 6
Panel Controls
Front panel
1. |
AUX IN |
2. |
POWER/ MUTE |
3. IR sensor |
4. |
AS/PS |
5. SEL |
6. |
VOL + |
7. |
PLAY/PAUSE |
8. MENU |
9. |
TFT display |
10. OPEN |
11. MODE |
12. PREVIOUS |
13. VOL |
14. OK |
15. NEXT |
|||
16. BAND |
17. USB |
|
|
|
|
||
18. |
Memory Card slot |
21. |
RESET |
19. |
EJECT button |
22. |
Flashing LED |
20. |
Disc slot |
|
|
Page - 7
