Polar FIN-90440 User Manual

Contents
How does Polar Fitwatch work ................................................ 5
Polar Fitwatch parts ..................................................
Getting going ...........................................................
How to start heart rate measurement ..................................... 7
Functions during heart rate measurement .............................. 8
See your heart rate ...................................................
Illuminate the display ...............................................
Check the time of day ..............................................
Stop heart rate measurement ...................................
How to set your Target Zone ................................................. 10
How to set the watch ............................................................ 12
Setting the alarm clock ...........................................
Setting the time of day ...........................................
Exercising with your Polar Heart Rate Monitor ..................... 15
General exercise recommendation ........................
Intensity of exercise ...............................................
Frequency of training .............................................
Mode of activity ......................................................
Structure of an exercise session ............................
References .............................................................
Quick guide for exercising .................................................... 21
Define the amount of your physical activity ...........
Determine your exercise goals ..............................
Examples of exercise recommendations ...............
Care and maintenance ......................................................... 25
Taking care .............................................................
Batteries .................................................................
Precautions ........................................................................... 27
In a water environment ...........................................
Interference ............................................................
Frequently asked questions .................................................. 29
Technical specifications ........................................................ 31
Polar books and accessories ............................................... 32
Service .................................................................................. 33
Check list ................................................................
Sending instructions ...............................................
Polar’s service procedure .......................................
Limited Polar warranty .......................................................... 35
Disclaimer ............................................................................. 36
5 6
8 8 8 9 9
12 14
16 16 19 19 20 20
21 23 23
25 26
27 28
33 34 34
FITWATCH.manual GBR/E 5.1.2001, 10:552-3
Congratulations on purchasing the Polar Fitwatch Heart Rate Monitor. We are proud to assist you in achieving your personal fitness goals.
This guide will provide you with the basic information on how to exercise with your Polar Heart Rate Monitor and how to get the best benefit of its functions.
Wirelessly and continuously yours,
How does
Polar Fitwatch
Work
POLAR FITWATCH PARTS
Your Polar Fitwatch consists of three parts:
VISUAL CUES TO READ THIS GUIDE
Indicates a tip to do things faster.
Indicates important issues. Please, pay attention!
Indicates a useful tip. It is good to know these things.
See also
IMPORTANT TO REMEMBER!
• Adjust the strap length snug enough and wet the transmitter electrodes to ensure flawless heart rate measurement.
• Do not bend or stretch the transmitter.
• Do not operate the buttons of the wrist receiver under water.
• Wash and dry your transmitter regularly after use.
• Do not store your Polar Heart Rate Monitor wet. Store it in a dry and cool place.
• Keep the Polar Heart Rate Monitor out of extreme cold and heat.
4
1. Polar T31™ Transmitter
• Grooved electrode areas
2. Elastic strap
3. Polar Fitwatch Wrist Receiver
5
FITWATCH.manual GBR/E 5.1.2001, 10:554-5
GETTING GOING
How to Start
1. Attach the Transmitter to the elastic strap.
2. Adjust the strap length to fit snugly and comfortably.
3. Secure the strap around your chest, below the chest muscles. Lock the buckle. Check that the Polar logo is in a central upright position.
4. Pull the Transmitter off your chest and wet the grooved electrode areas on the back of it.
5. Check that the wet electrode areas are firmly against your skin.
6. Wear the Wrist Receiver as you would wear an ordinary watch.
Alternatively, if you go biking, you may attach the Wrist Receiver to a Polar Bike Mount. Polar Products. Keep the Wrist Receiver within the transmission range (1 metre / 3 feet ).
It is recommended that you wear the Transmitter against your bare skin to ensure flawless operation. However, if you wish to wear the Transmitter over a shirt, moisten the shirt well under the electrodes.
Heart Rate
Measurement
1. Wear the Transmitter and the Wrist Receiver as described previously.
2. Begin with the display showing time of day.
3. To start, choose from the following alternatives:
One touch start:
mode press and hold the right button of the Receiver for a few second.
Quick start:
bring the Polar logo of the Receiver to the Transmitter’s Polar logo
wait for a beep signal.
Heart rate measurement commences and heart symbol starts flashing. Your heart rate (in beats per minute) appears in the display in approximately 5 seconds.
In the Time
In the Time mode,
and
It is important that the electrodes are wet during exercise. After exercising to preserve the electrodes and battery life:
1. Wash the Transmitter carefully with a mild soap water solution.
2. Rinse it with pure water.
3. Dry the Transmitter carefully.
6
FITWATCH.manual GBR/E 5.1.2001, 10:556-7
4. You can now start exercising with your Polar Fitwatch.
7
Functions During
Heart Rate
Measurement
SEE YOUR HEART RATE
You can see your heart rate in beats per minute. A flashing heart symbol indicates an ongoing heart rate measurement and it flashes at the pace of your heart.
ILLUMINATE THE DISPLAY
Press the right button briefly.
Backlight is activated for a few seconds.
TURN THE TARGET
ZONE SOUND
SIGNAL ON/OFF
When the Target Zone sound symbol appears in the display, you will hear an alarm sound with each heart beat if you go above the Upper Limit or below the Lower Limit of your Target Zone.
CHECK THE TIME OF DAY
Whilst exercising you can check the time of day momentarily by bringing the Wrist Receiver near the Transmitter’s Polar logo.
The time of day and backlight will be on for a few seconds.
STOP HEART RATE MEASUREMENT
1. Press and hold the left button to stop heart rate measurement.
Heart rate measurement stops. Time of day appears in the display.
In case you forget to stop the heart rate measurement when ending your exercise session and taking off the Transmitter, the Wrist Receiver turns itself into Time mode if no heart rate signal is received for 5 minutes.
Press and hold the right button to turn the Target Zone sound signal on or off.
sound signal is on
Also a flashing heart rate reading informs you of being outside your Target Zone.
8
FITWATCH.manual GBR/E 5.1.2001, 10:558-9
9
How to Set
Your
Target Zone
5. Press the right button to select the correct value for the Lower Limit.
The value for the Lower Limit starts to increase in 5 beats increments.
6. Press the left button to lock your selection.
Polar Fitwatch enters the Time mode.
1. Begin with the display showing time of day.
2. Press the left button to enter the Target Zone setting mode.
The Upper Limit reading appears flashing in the display. An arrow ( ), indicating the Upper Limit, appears in the upper left corner of the display.
3. Press the right button to set the Upper Limit value of your personal Target Zone.
The value for the Upper Limit starts to increase in 5 beat increments.
The digits run faster if you press and hold the right button. Release the button at the desired value.
4. Press the left button to lock your selection.
The Lower Limit reading appears flashing in the display. An arrow ( ), indicating the Lower Limit, appears in the lower left corner of the display.
The Upper Limit cannot be set below the Lower Limit. When the Lower Limit value reaches the Upper Limit value, the Lower Limit will be reset to 15, the lowest possible setting.
It may be necessary to reduce the Lower Limit value first and then return to set the Upper Limit.
To return to the Time mode at any point in the setting procedure, press both buttons simultaneously.
10
FITWATCH.manual GBR/E 5.1.2001, 10:5510-11
11
How
to Set
the Watch
5. Press the left button to lock your selection.
The first digits representing the hours start flashing.
6. Press the right button to select the desired hour.
The digits run faster if you press and hold the right button. Release the button at the desired value.
Polar Fitwatch has two watch functions: alarm clock and time of day. In the setting mode you can first set the alarm clock function and thereafter the time of day function.
Start the watch settings by pressing both buttons simultaneously in the Time mode. In case you do not want to set the alarm clock, you can skip to the time of day settings by pressing the left button five times.
To return to the Time mode at any point in the watch setting procedure, and to interrupt the watch settings, press both buttons simultaneously.
You can distinguish the mode you are in from the display:
• The heart symbol will be displayed in the time of day mode but not in the setting modes.
SETTING THE ALARM CLOCK
1. With display showing time of day, press both
buttons simultaneously.
Alarm signal symbol starts flashing.
2. Press the right button to set the alarm clock on/off.
3. Press the left button to lock your selection.
AM/PM starts flashing.
4. Press the right button to select AM or PM for the alarm
clock time. AM - before 12 o’clock, PM - after 12 o’clock.
7. Press the left button to lock your selection.
The digit representing the tens of minutes starts flashing.
8. Press the right button to select the desired tens of minutes.
Left Button:
LOCK YOUR
SELECTION
Right Button:
SELECT
9. Press the left button to lock your selection.
The digit representing the minutes starts flashing.
10. Press the right button to select the desired minutes.
11. Press the left button to lock your selection.
You enter the time of day setting mode. AM/PM starts flashing.
12. To set the time of day continue with Setting time of day, step 3. To return to the Time mode, press both buttons simultaneously.
You can turn the alarm off by pressing any of the two buttons. When the alarm comes on it will sound for one minute unless you turn it off before that.
12
FITWATCH.manual GBR/E 5.1.2001, 10:5512-13
13
