Polar F11 User Manual 2

Download
Polar F11
User Manual
™
ENGLISH

Contents

1. GETTING STARTED . ..... ... ........ ........ ... 3
Get to Know Your Polar F11 ....... ... ..... ... 3
2. BEFORE EXERCISE....... ... ..... ... ........ ... 5
Wear the Transmitter .. ... ........ ........ ... . 5
Test Your Fitness Level .. ... ..... ... ..... ... .. 6
Get Your Workout Program ....... ... ..... ... 10
3. DURING EXERCISE...... ... ..... ... ........ ... 15
Record Your Exercise.. ..... ... ........ ...... 15
Views During Exercise ... ... ..... ... ........ .17
Stop Recording and View Summary .... ... ..19
4. AFTER EXERCISE ........ ... ..... ... ........ ..20
Data Transfer. ... ..... ... ..... ... ........ ... ..27
5. SETTINGS. ........ ... ..... ... ........ ........ . 28
6. CUSTOMER SERVICE INFORMATION ... ...... 35
Caring for Your Heart Rate Monitor ........ . 35
Troubleshooting.... ........ ... ..... ... .......42
Technical Specification ........ ... ..... ... ..43

1. GETTING STARTED

Get to Know Your Polar F11

Wrist Unit displays and records your heart rate and other exercise data during exercise. Buttons:
UP/DOWN: Move thru menu and selection lists, and adjust values.
OK: Enter menu and confirm selections.
LIGHT: Illuminate display.
BACK: Exit menu and return to previous level. Cancel selection and leave setting unchanged.
Transmitter sends the heart rate signal to the wrist unit. The transmitter consists of a connector and strap.
ENGLISH
Getting Started 3
ENGLISH

Enter Basic Settings

1.
To activate your Polar F11, press OK twice. Once activated, it cannot be switched off!
2.
WELCOME TO POLAR FITNESS WORLD is displayed.
Press OK.
3.
Language: Select ENGLISH, DEUTSCH, ESPAÑOL, FRANÇAIS or ITALIANO with UP/DOWN. Press
OK.
4.
START WITH BASIC SETTINGS is displayed. Press
OK.
5.
Time: Select either 12 H or 24 H.
6.
Date: Enter date; dd = day, mm = month, yy =
year.
7.
Units: metric (KG/CM) or imperial (LB/FT). By
selecting LB/FT, calories are displayed as Cal, otherwise they are shown as kcal.
4 Getting Started
8.
Weight: Enter your weight. To change units,
press and hold LIGHT.
9.
Height: Enter your height. In LB/FT format, first
enter feet then inches.
10.
Birthday: Enter your date of birth; dd = day,
mm = month, yy = year.
11.
Sex: Select MALE or FEMALE.
12.
SETTINGS OK? is displayed. YES: settings are
accepted and saved. The display returns to Time mode. NO: Basic settings can still be changed.
Press BACK to return to the data you want to change.
After saving the basic settings, the F11 enters Time mode.

2. BEFORE EXERCISE

Wear the Transmitter

Wear the transmitter to measure heart rate.
1.
Wet the electrode areas of the strap under running water and make sure that they are well moistened.
2.
Attach the connector to the strap. Adjust the strap length to fit snugly and comfortably.
3.
Tie the strap around your chest, just below the chest muscles, and attach the hook to the other end of the strap.
4.
Check that the wet electrode areas are firmly against your skin and that the Polar logo of the connector is in a central, upright position.
Detach the connector from the strap when not in use.
ENGLISH
Before Exercise 5
ENGLISH

Test Your Fitness Level

The Polar Fitness TestTMis an easy, safe, and quick way to measure your aerobic (cardiovascular) fitness at rest. The Polar Fitness Test is developed for healthy adults.
Polar OwnIndex is a result of this test. It is comparable to maximal oxygen uptake (VO which is commonly used to evaluate aerobic fitness. Your OwnIndex reading is most meaningful when comparing your individual values over time.
To make sure the test results are reliable, the following basic requirements apply:
6 Before Exercise
2max
),
•
The more relaxed you are and the more peaceful the testing environment is the more accurate the test result. (No television, telephone or other people talking to you.)
•
Repeat the test always in similar conditions and on the same time of day.
•
Avoid heavy physical effort, alcohol and unprescribed pharmacological stimulants on the test day and the day before. Avoid eating a heavy meal and smoking 2-3 hours prior to the test.
You can stop the test at any time by pressing BACK.
Read more about Fitness on Polar Article Library at http://articles.polar.fi.
ENGLISH
Perform Polar Fitness Test
Before you start, make sure that your user settings are correct!
1.
Wearing the transmitter, lie down and relax for 1-3 minutes.
2.
Select Test > TEST. The fitness test begins instantly.
3.
Approximately 5 minutes later, a beep indicates the test has ended. OwnIndex is displayed with a numerical value and a written fitness level description.
4.
Press OK and UPDATE USER SET? is displayed. Select Yes to save the OwnIndex value to your User Settings and Fitness Test Trend menu. Select No only if you know your VO and if it differs more than one fitness level
2max
value,
class from the OwnIndex result. Your OwnIndex value is saved only to the Fitness Test Trend menu.
Troubleshooting:
•
Activity > You have not set your activity level in
User Settings. Read more information on page
33.
•
USER SETTINGS MISSING > Press OK to complete
all your settings.
•
Fitness Test Failed > Your most recent
OwnIndex value is not replaced.
•
No heart rate shown > Test fails. Check that the transmitter electrodes are moist enough and that the strap is snug enough around your chest.
Before Exercise 7
ENGLISH
Fitness Test Results
Your OwnIndex is most meaningful when comparing your individual values and changes in them over time. OwnIndex can also be interpreted based on gender and age. Locate your OwnIndex on the table, and find out how your aerobic fitness compares to others of the same gender and age.
This classification is based on a literature review of 62 studies where VO2max was measured directly in healthy adult subjects in the USA, Canada and 7 European countries. Reference: Shvartz E, Reibold RC: Aerobic fitness norms for males and females aged 6 to 75 years: a review. Aviat Space Environ Med; 61:3-11,
1990.
8 Before Exercise
Fitness Test Trend
Select Test > TREND
In the Trend menu, you can see how your OwnIndex value has been developing. Up to 47 OwnIndex values and respective dates can be included in the display.
To delete an OwnIndex value, press and hold LIGHT. DELETE VALUE? is displayed. Select YES.
Generally, it takes an average of six weeks of regular training to improve your aerobic fitness noticeably. To best improve your aerobic fitness, you need to exercise large muscle groups.
ENGLISH
Before Exercise 9
ENGLISH

Get Your Workout Program

The Polar Keeps U Fit - Own Workout Program guides towards your fitness goals.
1.
Select Program > CREATE.
2.
Your latest OwnIndex value is displayed. Adjust the value if required.
3.
Select your exercise Target:
MAXIMIZE your fitness level: You have been
exercising regularly for at least 10-12 weeks and are able to train nearly every day. The program recommends about 5 h/week in 4-6 sessions.
IMPROVE your fitness level: You are able to
exercise regularly. The program recommends about 3 h/week, in 3-5 sessions.
MAINTAIN your fitness level: If you have not
exercised recently, this is a good place to start. The program recommends about 1½ h/week in 2-3 sessions.
10 Before Exercise
4.
Select the number of times a week you want to exercise (Exe.Count).
5.
YOUR PERSONAL PROGRAM and your weekly
exercise targets are displayed in a few seconds. Scroll UP and DOWN to examine your program in different views.
Troubleshooting:
•
OWNINDEX MISSING. DEFAULT USED > Perform
Polar Fitness Test.
•
START WITH BASIC SETTINGS > Press OK and
complete your personal settings.
•
OVERWRITE CURRENT? > Select YES to create a
new program and to replace the excising one.
View Your Workout Program
Select Program > EDIT
Weekly Targets
Number of exercise sessions per week Total exercise time per week Total calories to expend per week
Weekly HR Zones shows the heart rate intensity zone, Light / Moderate / Hard , of your
weekly workout The height of the bar indicates the weekly time that should be spent in each exercise intensity zone. To view the time to be spent in each intensity zone, press OK. To return to the Weekly HR Zones view, press BACK.
ENGLISH
Before Exercise 11
ENGLISH
12 Before Exercise
Weekly Exercises
A summary of your weekly exercises sessions. To view the targets of each exercise, press OK and select the exercise you wish to examine.
Targets
Press UP/DOWN to view the target time, calories and intensity zones of each session. Press BACK to return to the Weekly Exercises view.
Edit Your Workout Program
•
To add an exercise session select Program >
EDIT > Weekly Exercises > ADD. Enter Duration. Press DOWN to view the added
exercise session's heart rate intensity zones.
•
To edit the duration of an exercise session in program select Program > EDIT > Weekly
Exercises > The exercise you wish to edit.
Select YES to EDIT DURATION?. Adjust the duration and press OK. When you edit your programmed exercises, the rest of the data regarding that exercise session and your weekly exercise targets are automatically updated.
•
To delete an exercise session select Program >
EDIT > Weekly Exercises > The exercise you
wish to delete. Press and hold LIGHT. Select YES to DELETE
EXERCISE? and ARE YOU SURE?.
After you have deleted an exercise session, you cannot restore it!
•
To turn your workout program on/off, select
Program > SETTINGS > ON/OFF.
When your program is switched off, it remains in the memory but the exercise targets do not show in the Diary view and you cannot select program exercise sessions in the Exercise menu.
Troubleshooting
•
Empty > Create a program.
Before Exercise 13
ENGLISH
ENGLISH
Program Settings
Select Program > SETTINGS
OWNZONE: Turning OwnZone on means that your
heart rate monitor determines your target heart rate zone automatically in the beginning of every exercise. The OwnZone function recommends for optimal exercise intensity based on your current condition. Note that switching OwnZone on/off affects all program exercises. For more information on Polar OwnZone, see page 30.
RENAME: You can rename each exercise session by
using eight letters.
14 Before Exercise

3. DURING EXERCISE

ENGLISH

Record Your Exercise

1.
Wear the transmitter and wrist unit. Start heart rate measurement by pressing OK. Preferably, there should be no other heart rate monitors nearby (within 1m / 3ft) to avoid interference.
2.
Within 15 seconds, your heart rate appears on the display.
3.
Press OK. Exercise and the name of the next exercise session alternate in the top row. Record the exercise session by selecting START and pressing OK. You can change your exercise session and adjust Exercise settings by selecting SETTINGS. For more information, see page 28.
4.
Press BACK to stop recording. Select EXIT to view an exercise summary.
Troubleshooting:
•
Your exercise information is saved only if the stopwatch has been on for more than one minute.
•
OwnZone > Your heart rate monitor has started
to determine your target heart rate zone automatically. Skip the process by pressing OK. In this case, if you have not determined your OwnZone before, your age-based heart rate limits are used. For more information on determing OwnZone, see page 31.
•
START WITH BASIC SETTINGS > Press OK to
complete your Basic settings.
During Exercise 15
ENGLISH

Buttons During Exercise

LIGHT
•
Press once and the display will light up with every button press.
•
Press and hold to lock or unlock buttons.
BACK
•
Pause / exit exercise recording.
UP / DOWN
•
Change exercise mode view.
•
Press and hold UP to customize Exercise and Calories views. Choose the upper row information from Time of day, Calories/Stopwatch and Fitness bullets. A fitness bullet appears for every 10 minutes in the target zone equaling one hour in total if all the bullets appear.
OK
•
Press and hold to change exercise settings without pausing the exercise recording.
16 During Exercise
Bring the wrist unit near the transmitter to see the time of day in Exercise mode.

Views During Exercise

View combinations of exercise data. Switch displays with UP/DOWN.
Exercise
Stopwatch Heart rate
Calories
The calories expended Heart rate
InZone view is only displayed when you have set heart rate limits active.
InZone symbol and time spent in zone* Lower / upper limit values and Zone Pointer Heart rate
*Smiley face means that OwnZone determination was succesful.
ENGLISH
During Exercise 17
ENGLISH
18 During Exercise
HR zones are only displayed when you have selected a program exercise
The time spent in your present intensity zone The intensity zone symbol shows you the zone you are in at the moment The target intensity zone bar is highlighted, if you are within your target zone Heart rate
Exercise targets are only displayed when you have selected a program exercise
Exercise name Target duration Target calories Heart rate
ENGLISH

Stop Recording and View Summary

Press BACK to pause exercise recording. Select EXIT to stop recording and to view a Summary of your exercise session:
Summary
Exercise duration (hh.mm.ss) Calories burned during exercise (Cal/kcal) The maximum (max) and average (avg) heart rate of the exercise session (bpm/%HR
Detach the transmitter connector from the strap and rinse the strap under running water after every use.
Wash the strap regularly in a washing machine or at least after every fifth use. This ensures reliable measurement and maximizes the life span of the transmitter.
For complete instructions, consult Care and Maintenance.
During Exercise 19
) alternate
max
ENGLISH

4. AFTER EXERCISE

Diary

In the Diary, you can compare achieved exercise duration, quantity and calories in different intensity zones to your target values. Diary contains data for the current calendar week only, and records exercise data only if the session lasts at least ten minutes.
To enter Diary, on Time display, press UP.
Diary
The three bars stand for exercise count (#), exercise time (Ø) and expended calories (c). Press OK and UP/DOWN to examine more details.
Exe.Count / Exe.Time / Calories
Weekly target exercise count/duration/calories (The relevant bar is highlighted.) The total exercise count/duration/expended calories you have achieved Press BACK to return the Diary view. Press DOWN to enter the HR zones view.
20 After Exercise
ENGLISH
HR zones
The three bars stand for Light, Moderate and Hard heart rate zone. Press OK and UP/DOWN to examine more details.
Light / Moderate / Hard
Your target exercise duration in concerned zone The relevant bar is highlighted The exercise duration in zone Note: When you press BACK to return to the Diary or HR zones view, the value you last viewed will be set as a default value on the bottom row of the Diary or HR zones view.
After Exercise 21
ENGLISH

Follow-Up

Every Sunday at midnight, your Polar F11 automatically reviews your progress, resets the Diary and Heart Rate Zone views, saves Diary data to Weekly File and reminds you to check your Diary with an envelope symbol.
At in the beginning of each month, if you have not performed the Fitness Test for 30 days, your Polar F11 will automatically remind you to do so by displaying TEST YOUR OWNINDEX.
To open the reminder, press UP and OK.
Result
Total exercise count of the last week Total exercise duration Total calories burned while exercising (Cal/kcal) Percentage of the weekly target reached (if the program is on)
A trophy symbol is all yours for the following week if you have reached at least 75 % of your weekly target. Well done!
22 After Exercise
ENGLISH

Files

Daily File
Select File > DAILY
In the Daily File, view detailed exercise information from your 12 most recent exercise sessions.
When the File becomes full, the oldest information is replaced by the most recent. To save the exercise data for a longer period, transfer the file to the polarpersonaltrainer.com web service. For more information, see page 27.
Exercise name is shown if a program exercise was selected, otherwise Exercise
Each bar represents a session. The higher the bar the longer the exercise. Date of the exercise
After Exercise 23
ENGLISH
Select an exercise you wish to view with UP/DOWN and OK.
Duration
Name of the exercise Time session started Exercise duration (hh.mm.ss)
Calories
Calories expended while exercising (Cal/kcal) Fat percentage of the burned calories
Heart Rate
Maximum (Max) and average (Avg) heart rate in beats per minute alternate with the percentage of maximum heart rate reading
24 After Exercise
ENGLISH
HR zones are only displayed when an exercise from your workout program was chosen
Press OK to view information for the Light, Moderate and Hard intensity zones.
Light / Moderate / Hard
The intensity zone bar is highlighted when examined Exercise duration in the zone Press BACK to return to the HR zones view.
Time in Zone view is only displayed if a manual exercise was carried out and HR limits were set on.
Heart rate limits Exercise duration between heart rate limits
To delete a Daily File, press and hold LIGHT in Duration view until DELETE FILE? is displayed. Select YES.
ARE YOU SURE? is displayed. Confirm deletion with YES.
After Exercise 25
ENGLISH
Weekly File and Totals File
Select File > WEEKLY or TOTALS
In the Weekly and Totals Files, you can view exercise count, duration, and burned calories from the last 12 weeks or starting from the previous reset.
Weekly File
EXE.COUNT / EXE.TIME / CALOREIS / HR ZONES
The last Sunday of the selected week The height of a bar indicates the week's total exercises / exercise time / expended calories / time spent in target zones Cumulative count for the week's total exercises / exercise time / expended calories / time spent in target zones*
* Press OK to view the exercise duration in different intensity zones.
Totals File
Total Exe.Count / Duration / Calories
The last reset date Total cumulative exercise / duration / expended calories count, starting from the previous reset
To empty the Totals File, press DOWN until Reset Total Counters? is displayed. Press OK and select the information you wish to erase. ARE YOU SURE? is displayed. Confirm deletion with YES.
26 After Exercise

Data Transfer

Your Polar F11 offers two means of data communication with a PC:
•
Send data with Polar WebLink™: Transfer data to the polarpersonaltrainer.com web service using Polar WebLink software. For this you need to register for polarpersonaltrainer.com web service. You will find detailed instructions on how to send data at Polar WebLink's Help file.
•
Receive data with Polar UpLink™ Tool: Edit settings and upload logos from a PC to your wrist unit using Polar UpLink Tool software.
Fore more information about system requirements, see page 43. To download the Polar WebLink and Polar UpLink Tool free of charge visit www.polar.fi.
ENGLISH
After Exercise 27
ENGLISH

5. SETTINGS

Exercise Settings

Select Exercise > SETTINGS
•
EXERCISE: You can choose an exercise only if
your workout program is activated. Choose an exercise session by pressing OK. SELECT the exercise or VIEW session targets. In a MANUAL exercise there are no preset goals.
•
HR ALARM: Adjust the target zone alarm sound
volume.
•
HR LIMITS: In a program exercise your target heart
rate limits are automatically defined. If you have chosen a MANUAL exercise session or you have set the program off, you can choose to exercise from four different heart rate limits:
1.
OWNZONE: The wrist unit determines your
individual target heart rate zone automatically in the beginning of every exercise. Select HARD,
MODERATE, LIGHT or BASIC intensity for your
OwnZone.
2.
AUTOMATIC: Limits are determined using an
28 Settings
age-based formula (220 minus age). Choose
HARD, MODERATE, LIGHT or BASIC. Make sure you
have entered the correct date of birth in User Settings!
3.
MANUAL: Set your target heart rate limits
manually.
4.
For exercise without any given limits, select
OFF.
•
HR VIEW: Select HR to display your heart rate in
beats per minute (bpm) or HR% to view a percentage of maximum heart rate.
Choose your OwnZone or Automatic heart rate limits from four exercise intensities:
HARD (80-90% HR
• exercise at high intensity. MODERATE (70-80% HR
• particularly for improving aerobic fitness. It is
) is for a relatively short
max
) is effective
max
recommended for people exercising regularly. LIGHT (60-70% HR
• health and fitness. It also improves basic
) is good for improving
max
endurance and helps you to recover from heavier exercise. BASIC (65-85% HR
• intensity exercise.
) is suitable for aerobic
max
ENGLISH
Settings 29
ENGLISH

OwnZone

Your Polar F11 automatically determines your individual and safe exercise intensity zone, your OwnZone. The function guides you through warm-up. Your OwnZone limits may vary daily, depending on your physical and mental condition.
You can select an exercise intensity from four different heart rate zones: Light, Moderate, Hard, and Basic. For more information on exercise intensities, see page 29.
It is advisable to use OwnZone every time you exercise, or at least,
•
When changing exercise environment or exercise mode.
•
When taking up exercise after more than a week’s break.
•
If you are feeling unusual. For example, if you are not recovered from previous exercise, not feeling well or are stressed.
•
After changing your user settings.
30 Settings
OwnZone has been developed for healthy persons. Some health conditions may cause heart rate variability-based OwnZone determination to fail, e.g. high blood pressure, certain cardiac arrhythmias, and some medication. In such cases, your age-based limits will be used for OwnZone determination.
Determining Your OwnZone
Find your OwnZone limits in 1-5 minutes during warm-up by walking, jogging, or doing some other sport. Before you start, make sure that your User settings are correct and the OwnZone function is activated.
1.
Start recording the exercise. The OwnZone symbol appears on the display and determination begins. The process is carried out in five stages. A beep will signal the end of each stage. Avoid stopping during OwnZone determination.
•
OZ> Walk at a slow pace for 1 min. Keep your
heart rate below 100 bpm/ 50% HR this first stage.
•
OZ>> Walk at a normal pace for 1 min. Smoothly
max
during
increase your heart rate about 10 bpm/ 5% HRmax.
•
OZ>>>Walk at a brisk pace for 1 min. Smoothly
increase your heart rate about 10 bpm/ 5% HRmax.
•
OZ>>>>Jog at a slow pace for 1 min. Smoothly
increase your heart rate about 10 bpm/ 5% HRmax.
•
OZ>>>>>Jog at brisk pace or run for 1 min.
2.
When you hear two, consecutive beeps, your OwnZone has been determined. OwnZone
Updated alternates with the heart rate limits on
the display after a succesful determination. If OwnZone determination fails, OwnZone
Limits and your previous OwnZone limits will
appear on the display. If OwnZone has not previously been determined, age-based limits will be used.
3.
Proceed with your exercise. Try to stay inside the given heart rate zone to maximize exercise benefits.
Settings 31
ENGLISH
ENGLISH

Other Settings

WATCH settings
Select Settings > WATCH
•
TIMER: Set the countdown timer to sound once.
Restart the timer by pressing and holding OK while it is running, or stop it by pressing BACK. To hide the running timer, press and hold UP.
•
REMIND: You can activate seven different
reminders in your Polar F11. To create a new reminder, select ADD. Enter Date and Time. Select when the reminder alarm will be activated: 1 DAY, 1 HOUR, 30 MIN, or 10 MIN before or at the reminder time (ON TIME). Determine whether the reminder should sound at the same time YEARLY, MONTHLY, WEEKLY, DAILY,
HOURLY, ONCE, or turn the reminder OFF. Select
an exercise to be linked to the reminder, or NONE if you do not want to link it. Rename the reminder if you like. Choose an excisting reminder to change it's attributes or to DELETE it. Stop the alarm sound by pressing LIGHT. Press OK to snooze for 10 minutes and BACK to exit
32 Settings
the reminder view.
•
ALARM: Set the alarm to sound DAILY, from
Monday to Friday (MON-FRI) or turn it OFF. The alarm functions in all modes except in Exercise mode. Press BACK to stop the alarm or OK to snooze for 10 minutes.
•
TIME / TIME2: Set two different time of day
settings. In Time mode, quickly change from Time1 to Time2 by pressing and holding DOWN.
•
DATE: Set the date.
HR SET (Heart rate settings)
Select Settings > HR SET
•
HR ALARM: Select VOL 2 (loud), VOL 1 (quiet), or
alarm OFF.
•
HR VIEW: Select HR (beats per minute), or HR%
(a percentage of your maximum heart rate).
ENGLISH
USER settings
Select Settings > USER
•
Weight: To change units press and hold LIGHT.
•
Height: To change units press and hold LIGHT.
•
Birthday: Adjust your date of birth.
•
Sex : Select MALE or FEMALE.
•
Activity: Select the alternative that best
describes the overall amount and intensity of your physical activity during the past three months.
1. TOP: You participate in heavy physical
exercise at least 5 times a week, or you exercise to improve performance for competitive purposes.
2. HIGH: You participate at least 3 times a
week in heavy physical exercise, e.g. you run 10-40 km or 6-25 miles per week or spend 2-4 hours per week in comparable physical activity.
3. MODERATE: You participate regularly in
recreational sports, e.g. you run 5-10 km or
3-6 miles per week or spend ½-2 hours per week in comparable physical activity, or your work requires modest physical activity.
4. LOW: You do not participate regularly in
programmed recreational sport or heavy physical activity, e.g. you walk only for pleasure, or exercise hard enough to cause heavy breathing or perspiration only occasionally.
Settings 33
ENGLISH
•
HR max (the highest number of heartbeats per
minute (bpm) during maximum physical exertion): Change the default value only if you know your laboratory-measured value. For more information, see http://support.polar.fi.
•
V02 max (the maximum capacity for oxygen
consumption by your body during maximum exertion): Change the default value only if you know your laboratory-measured value. For more information, see http://support.polar.fi.
•
HR sit: Your typical heart rate when you are not
doing any physical activity (while sitting). To determine HR and do not engage in any physical activity. After
, wear your transmitter, sit down
sit
two or three minutes, press OK in Time mode to view your heart rate. This is your HR more precise measurement, repeat the procedure
. For a
sit
several times and calculate your average.
34 Settings
GENERAL settings
Select Settings > GENERAL
•
SOUND: Adjust button and activity sounds; VOL 2
(loud), VOL 1 (quiet), or OFF (no sounds).
•
KEYLOCK: To lock or unlock buttons MANUALly,
press and hold LIGHT. AUTOMATIC keylock is activated when you have not pressed the buttons for a minute.
•
UNITS: Select metric (KG/CM) or imperial (LB/FT)
units.
•
LANGUAGE: Select ENGLISH, DEUTSCH, ESPAÑOL, FRANÇAIS or ITALIANO.

6. CUSTOMER SERVICE INFORMATION

ENGLISH

Caring for Your Heart Rate Monitor

Wrist Unit: Clean with a mild soap and water solution, dry with towel. Never use alcohol or any abrasive material (steel wool or cleaning chemicals). Keep in a cool and dry place. Do not store in a damp environment, in non-breathable material (a plastic bag or a sports bag) nor with conductive material (a wet towel). Do not expose to direct sunlight for extended periods.
Transmitter: Detach the transmitter connector from the strap and rinse the strap under running water after every use. Dry the connector with a soft
towel. Never use alcohol or any abrasive material (steel, wool or cleaning chemicals).
Wash the strap regularly in a washing machine at 40ºC/104ºF or at lest after every fifth use. This
ensures reliable measurement and maximizes the life span of the transmitter. Use a washing pouch. Do not soak, spin-dry, iron, dry clean or bleach the strap. Do not use detergent with bleach or fabric
softener. Never put the transmitter connector in the washing machine or drier!
Dry and store the strap and the transmitter connector separately. Wash the strap in a washing
machine before long-term storage, and always after use in pool water with high chlorine content.
Customer Service Information 35
ENGLISH
Service
Your Polar F11 Heart Rate Monitor is designed to help you achieve personal fitness goals, indicate the level of physiological strain and intensity during an exercise session. No other use is intended or implied.
During the two-year guarantee/warranty period we recommend that you have service done by an authorized Polar Service Center only. The warranty does not cover damage or consequential damage caused by service not authorized by Polar Electro.
Changing Wrist Unit Batteries
Do not open the wrist unit yourself. To ensure water resistance properties and the use of qualified components, the wrist unit battery should be replaced by an authorized Polar Service Center only. At the same time, a full periodic check of the heart rate monitor will be done.
36 Customer Service Information
A low battery symbol will appear when 10-15% of the battery capacity is left. The backlight and sounds are automatically deactivated. Excessive use of the backlight drains the battery more rapidly. In cold conditions, the low battery indicator may appear, and disappear again when you return to a warmer environment.
Changing Transmitter Batteries
1.
Open the battery cover by turning it counterclockwise to OPEN using a coin.
2.
Place the battery inside the cover with the positive (+) side facing the cover.
3.
Make sure the sealing ring is in the groove to ensure water resistance.
4.
Place the cover with the battery inside it into the connector. Press the cover in place and close it by turning clockwise from OPEN to CLOSE using a coin.
In order to ensure maximum life span of the battery cover, open it only when you need to change the battery. Change the sealing ring of the battery cover every time you change the battery. You can purchase the sealing ring/battery kits at well-equipped Polar retailers and authorized Polar Services. In the USA and Canada, the additional sealing rings are available at authorized Polar Service Centers only.
Keep the batteries away from children. If swallowed, contact a doctor immediately.
Batteries should be disposed of properly according to local regulations.
ENGLISH
Customer Service Information 37
ENGLISH

Precautions

Minimizing Possible Risks
Exercise may include some risk. Before beginning a regular exercise program, answer the following questions concerning your health status. If you answer yes to any of these questions, consult a physician before starting any training program.
•
Have you been physically inactive for the past 5 years?
•
Do you have high blood pressure or high blood cholesterol?
•
Do you have symptoms of any disease?
•
Are you taking any blood pressure or heart medication?
•
Do you have a history of breathing problems?
•
Are you recovering from a serious illness or medical treatment?
•
Do you use a pacemaker or other implanted electronic device?
•
Do you smoke?
•
Are you pregnant?
Note that in addition to exercise intensity, medications for heart conditions, blood pressure,
38 Customer Service Information
psychological conditions, asthma, breathing, etc., as well as some energy drinks, alcohol, and nicotine may also affect heart rate.
It is important to be sensitive to your body’s responses during exercise. If you feel unexpected
pain or excessive fatigue when exercising, stop the exercise or continue at a lighter intensity.
ENGLISH
If you have a pacemaker, defibrillator or other implanted electronic device, you use the Polar
heart rate monitor at your own risk. Before starting use, take a maximal exercise stress test under the supervision of a physician. The test is to ensure the safety and reliability of the simultaneous use of the pacemaker and the Polar heart rate monitor.
If you are allergic to any substance that comes into contact with your skin or if you suspect an allergic reaction due to using the product, check
the listed materials in Technical Specifications. To avoid any skin reaction to the transmitter, wear it over a shirt. Moisten the shirt well under the electrodes to ensure flawless operation.
The combined impact of moisture and intense abrasion may cause a black color to come off the transmitter’s surface, possibly staining light-colored clothes.
If you use insect repellent on your skin, make sure that it does not come into contact with the transmitter.
When in non-coded mode, the wrist unit picks up transmitter signals within 1 m / 3ft. The frame
around the heart symbol on the bottom of the display indicates that transmission is coded. Coding blocks interference from nearby heart rate monitors.
Customer Service Information 39
ENGLISH
Polar F11 may be worn when swimming. To maintain water resistance, do not press buttons under water. For more information visit at http://support.polar.fi.
Water resistance of Polar products is tested according to International Standard ISO 2281. Products are divided into three categories according to their water resistance. Check the back of your Polar product for the water resistance category, and compare it to the chart below. Please note that these definitions do not necessarily apply to products of other manufacturers.
Marking on the case back
Wash splashes, sweat, raindrops etc.
Water resistant
Water resistant 50m
Water resistant 100m
40 Customer Service Information
x - - -
x x - -
x x x -
Bathing and swimming
Skin diving with snorkel (no air tanks)
SCUBA diving (with air tanks)
Water resistant characteristics
Splashes,
raindrops etc.
Minimum for
bathing and
swimming
For frequent
use in water
but not SCUBA
diving
ENGLISH
Electromagnetic disturbances may occur near high-voltage power lines, traffic lights, overhead lines of electric railways, electric bus lines or trams, televisions, car motors, bike computers, some motor driven exercise equipment, cellular phones, or at electric security gates. To avoid erratic readings, move away from possible sources of disturbance.
Exercise equipment with electronic components may cause interfering stray signals. To tackle
these problems, try the following:
1.
Remove the transmitter from your chest and use the exercise equipment as you would normally.
2.
Move the wrist unit around until you fi nd an area in which it displays no stray reading or does not fl ash the heart symbol. Interference is often worst right in front of the display panel of the equipment, while the left or right side of the display is relatively free of disturbance.
3.
Put the transmitter back on your chest and keep the wrist unit in this interference-free area as much as possible.
If the heart rate monitor still does not work, the piece of equipment may be electrically too noisy for wireless heart rate measurement.
Customer Service Information 41
ENGLISH

Troubleshooting

If you don't know where you are in the menu, press and hold BACK until the time of day is displayed.
If there are no reactions to any buttons, reset the wrist unit by pressing all the buttons
simultaneously for two seconds. All other settings but time and date are saved.
If the heart rate reading becomes erratic, extremely high or shows nil (00), make sure that
there are no other heart rate transmitters within 1 m/3 ft and that the transmitter strap/the textile electrodes fit snugly and are moistened, clean and undamaged.
If the heart rate measurement does not work with the sports apparel, try measuring using the strap. If it works, the problem is most probably in the apparel. Please contact the apparel retailer/manufacturer.
Strong electromagnetic signals can cause erratic readings. If the abnormal reading continues
42 Customer Service Information
despite moving away from the source of disturbance, slow down and check your pulse manually. If you feel it corresponds to the high reading on the display, you may be experiencing cardiac arrhythmia. Most cases of arrhythmia are not serious, but consult your doctor nevertheless.
A cardiac event may have altered your ECG waveform. In this case, consult your physician.
If heart rate measurement does not work despite the actions mentioned previously, the battery of your transmitter may be empty. For information about changing batteries, see page 37.
ENGLISH

Technical Specification

Wrist Unit
Battery type Battery life Average 1.5 years (1 h/day, 7
Operating temperature Wrist strap material Polyurethane Back cover and wrist strap buckle
Watch accuracy Better than ± 0.5 seconds/day at
Accuracy of heart rate measurement
Transmitter
Battery type Battery life Average 2 years (1 h/day, 7
Battery sealing ring O-ring 20.0 x 1.0 Material FPM Operating temperature Connector material Polyamide
CR 2032
days/week exercise)
-10 °C to +50 °C / 14 °F to 122 °F
Stainless steel complying with the EU Directive 94/27/EU and amendment 1999/C 205/05 on the release of nickel from products intended to come into direct and prolonged contact with the skin.
25 °C / 77 °F temperature. ± 1% or ± 1 bpm, whichever larger, defi nition applies to steady state conditions.
CR 2025
days/week)
-10 °C to +50 °C / 14 °F to 122 °F
Strap material 35% Polyester, 35% Polyamide,
30% Polyurethane
Limit values
Chronometer Heart rate 30 - 199 bpm Total time 0 - 9999 h 59 min 59 s Total calories 0 - 999999 kcal/Cal Total exercise count 65 535 Birthday 1921 - 2020
23 h 59 min 59 s
System Requirements
Polar WebLink
Polar UpLink Tool PC, Windows®
PC, Windows® 98/98SE/ME/2000/XP/Vista, Sound card, Microphone
98/98SE/ME/2000/XP/Vista, Sound card, Dynamic loudspeakers or headphones
Customer Service Information 43
ENGLISH

Guarantee and Disclaimer

Limited Polar International Guarantee
This limited Polar international guarantee is issued by Polar Electro Inc. for the consumers who have purchased this product in the USA or Canada. This limited Polar international guarantee is issued by Polar Electro Oy for the consumers who have purchased this product in other countries.
Polar Electro Inc. / Polar Electro Oy guarantees to the original consumer/ purchaser of this product that the product will be free from defects in material or workmanship for two years from the date of purchase.
Please keep the receipt or stamped Polar Customer Service Card as a proof of purchase!
The guarantee does not cover the battery, damage due to misuse, abuse, accidents or non-compliance with the precautions; improper maintenance, commercial use, cracked or broken cases.
The guarantee does not cover any damage/s, losses, costs or expenses, direct, indirect or incidential, consequential or special, arising out of, or related to the product. During the guarantee period the product will be either repaired or replaced at an authorized service center free of charge.
This guarantee does not affect the consumer’s statutory
44 Customer Service Information
rights under applicable national or state laws in force, or the consumer’s rights against the dealer arising from their sales/ purchase contract.
© 2007 Polar Electro Oy, FIN-90440 KEMPELE, Finland.
Polar Electro Oy, FIN-90440 KEMPELE, Finland. Polar Electro Oy is a ISO 9001:2000 certified company. All rights reserved. No part of this manual may be used or reproduced in any form or by any means without prior written permission of Polar Electro Oy. The names and logos marked with a ™ symbol in this user manual or in the package of this product are trademarks of Polar Electro Oy. The names and logos marked with a ® symbol in this user manual or in the package of this product are registered trademarks of Polar Electro Oy, except that Windows is a trademark of Microsoft Corporation.
ENGLISH
Disclaimer
The material in this manual is for informational purposes only. The products it describes are subject to change without prior notice, due to the manufacturer’s continuous development program.
Polar Electro Inc. / Polar Electro Oy makes no representations or warranties with respect to this manual or with respect to the products described herein.
Polar Electro Inc. / Polar Electro Oy shall not be liable for any damages, losses, costs or expenses, direct, indirect or incidental, consequential or special, arising out of, or related to the use of this material or the products described herein.
This product is protected by one or several of the following patents: FI55293, FI88223, US5491474, DE4215549, GB2257523B, FR92.06120, HK113/1996, SG9591671-4, FI110303, WO96/20640, EP 0748185, US6104947, US6714812, FI114202, US 6537227, EP 1055158, US5719825, US58048027. Other patents pending.
Manufactured by Polar Electro Oy, Professorintie 5, FIN-90440 KEMPELE, Tel +358 8 5202 100, Fax +358 8 5202 300, www.polar.fi
This product is compliant with Directive 93/42/EEC. The relevant Declaration of Conformity is available at www.support.polar.fi/declaration_of_conformity.
Polar products are electronic devices and are in the scope of Directive 2002/96/EC of the European Parliament and of the Council on waste electrical and electronic equipment (WEEE). These products should thus be disposed of separately in EU countries. Polar encourages you to minimize possible effects of waste on the environment and human health also outside the European Union by following local waste disposal regulations and, where possible, utilize separate collection of electronic devices.
Customer Service Information 45
Manufactured by
Polar Electro Oy Professorintie 5 FIN-90440 KEMPELE Tel +358 8 5202 100 Fax +358 8 5202 300 www.polar.fi
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
