Planet Eclipse SLS User Manual
FOREWORD
For the uninitiated, the SLS represents our very best-of-thebest. We take the basic platform of the Ego10 and rework
virtually every aspect and component to create a lighter,
leaner, more focused machine.
Although the SLS is designed with ultimate performance in
mind that does not mean we have done so at the sacrice
of reliability. As you would expect from any Eclipse marker,
the SLS is the perfect blend of lightweight design, rugged
reliability, stunning looks and on-eld ability.
Right now, the most important thing for you to do as a new
owner of this SLS is read through this ‘Feature Supplement’,
as well as the ‘Ego10 Operators Manual’, paying particular
attention to the safety warnings and guidelines, to learn
how to operate and optimise your SLS to your exact
requirements.
Having done that, ensure that you return your warranty
card or complete the online warranty registration form at
www.planeteclipse.com to ensure that your warranty is fully
activated and that you are in our system to receive any free
performance upgrades should they become available to SLS
owners during the lifetime of the marker.
And that leaves little more to say than enjoy your time using
your SLS. Know that it has been developed and prepared
for you by a group of people and players that want nothing
more than it to be the very best you have ever had.
Now go out there and use the SLS in the way we always
intended it to be used. On the eld of battle. In a re-ght.
Winning!
JACK WOOD - CHIEF ENGINEER
WARNING: READ AND ADHERE
STRICTLY TO ALL OF THE SAFETY
INSTRUCTIONS AND GUIDELINES IN
THE EGO10 OPERATORS MANUAL!
04 - SL SHAFT3 BARREL KIT
05 - SLS VALVE GUIDES
06 - SLS TRIGGER SYSTEMS
07 - SLS BOLT SYSTEM
08 - INSTALLING CURE3+ BOLT INSERTS
10 - SL3 INLINE REGULATOR
11 - CLEANING THE SL3 INLINE REGULATOR
14 - ADVANCED SL3 INLINE REGULATOR
MAINTENANCE
15 - THE ECLIPSE E-PORTAL
16 - SLS CUSTOMER SERVICE & SUPPORT
17 - NOTES
18 - SERVICE HISTORY
FEATURE SUPPLEMENT
3
SL SHAFT3 BARREL KIT
The Eclipse SLS marker comes as standard with an
Eclipse SL Shaft 3 Barrel Kit.
The barrel screws into the body of the SLS using a right
hand thread meaning that if you hold the SLS pointing
away from you the barrel screws into the body in a
counter-clockwise direction.
The barrel comprises of two parts, a Barrel Back A and a
Barrel Front B .
The two parts are joined together with a left hand
thread meaning that if you hold the barrel, with the
back nearest you, the front unscrews in a counterclockwise direction. The bore size of the barrel back is
engraved at the end of the Barrel Back C .
C
FEATURE SUPPLEMENT
4
1
D
On the Barrel Back there is a 016 NBR 70 o-ring D which
prevents the barrel from vibrating loose from the SLS
body when the marker is red. There is a 015 NBR 70
o-ring on the Barrel Front E helps with alignment when
the two sections are screwed together.
2
Replace and lubricate these o-rings with Eclipse Grease
as necessary.
E
B
A
1
The bore sizes in your SL Shaft3 Barrel Kit may vary
according to the model of SLS you have.
2
The SLS marker will only accept COCKER threaded
barrels. Do not use any other type of barrel thread.
SLS VALVE GUIDES
WARNING: RE MOVE ALL PAINTB ALLS & DEGAS YOUR
MARKER, DISCHARGING ANY STORED GAS IN A SAFE
DIREC TION, DISCONNE CT THE BATTERY & REMO VE THE
BARREL, LOADER & AIR SYSTEM TO MAKE THE MARKER
Included with the Eclipse SLS marker are two Valve
Guides.
A LP (Low Pressure) Valve Guide which is already
installed inside the SLS, and a HP (High Pressure) Valve
Guide. Both of which will allow you to customize the
set-up and feel of the SLS.
To remove the LP Valve Guide and install the HP version
see the ‘Removing the Valve Assembly’ section of your
‘Ego10 Operators’ Manual. Simply swap over the Valve
Guides during this procedure.
EASIER & SAFER TO WORK ON.
FEATURE SUPPLEMENT
5
THE SLS TRIGGER
SYSTEMS
WARNING: RE MOVE ALL PAINTB ALLS & DEGAS YOUR
MARKER, DISCHARGING ANY STORED GAS IN A SAFE
DIREC TION, DISCONNE CT THE BATTERY & REMO VE THE
BARREL, LOADER & AIR SYSTEM TO MAKE THE MARKER
The Eclipse SLS marker comes with two complete
Trigger Systems (bearing carrier, trigger, spring and setscrews) that are interchangeable within the SLS frame.
For full details of how to change the Trigger System in
the SLS please consult the ‘Ego10 Trigger Assembly’
section in the ‘Ego10 Operators Manual’. If you have
any doubts about how to conduct this procedure then
do not hesitate to contact your nearest Eclipse Service
Center (see Eclipse Certied Service Center pages of
Ego10 Operators Manual).
For full details of how to adjust your trigger please
refer to the ‘Setting the Trigger Section’ of the ‘Ego10
Operators Manual’.
IMPORTANT
When setting the trigger it is essential to ensure that
the electronic trigger detection is working correctly.
When the trigger is fully depressed the Trigger
Detection Indicator (TDI) should point upwards
. When the trigger is fully released the TDI should
point downwards . For more information, see
‘Understanding the Trigger Detection Indicator (TDI)’
FEATURE SUPPLEMENT
and ‘Filter Menu’ in the ‘Ego10 Operators Manual’.
EASIER & SAFER TO WORK ON.
C
A
B
F
A Spring
B Spring Return Strength Screw
C Trigger Pin Locking Screw
D Front Stop Trigger Screw
E Magnet Return Strength Screw
F Micro Switch Activation Screw
G Rear Stop Trigger Screw
A
B
F
ED
G
C
ED
G
6
