enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 1

Quick Start

Contents

Introduction

...................................... 4

Features .................................................... 4

Safety Instructions .................................... 7

What’s in the Box .................................... 10

Charging the Battery .............................. 12

inno Controls .......................................... 13

Using this Guide ...................................... 15

inno Display ............................................ 16

Remote .................................................... 17

Subscribing to XM

........................ 18

Using Your inno Alone

.............. 20

Setup ...................................................... 20

Live XM .................................................. 26

TuneSelect™ .......................................... 29

Info Extras .............................................. 31

Recording XM.......................................... 33

Listening to Recorded XM Content

(My Music) .............................................. 37

Organizing Your Music ............................ 38

Using inno with a PC

.................. 48

System Requirements .............................. 48

Setup ...................................................... 49

Registering with XM+Napster ................ 51

What Can You Do with XM+Napster? .... 54

Exploring ................................................ 54

Purchasing Music .................................... 55

Organizing Your Music ............................ 56

Disconnecting Your inno From the PC...... 60

Listening to XM Radio Online (XMRO) .... 61

Using Your CDs or MP3/WMA Files ........ 62

Updating inno Firmware

.......... 64

Using XM+Napster.................................. 64

Using the Update Tool ............................ 65

Using the Web ........................................ 65

Settings

.............................................. 66

FM Modulator ........................................ 66

Aiming the Antenna ................................ 69

Audio ...................................................... 70

Display .................................................... 71

Channel Access........................................ 73

Clock and Sleep Timer ............................ 75

Vehicle Mode .......................................... 76

Memory Partition .................................... 77

Restoring Factory Defaults ...................... 78

Customer Support

........................ 80

Troubleshooting ...................................... 80

Specifications .......................................... 83

Patent Information .................................. 85

FCC Statement ........................................ 86

Warranty.................................................. 88

1. Charge battery for at least 8 hours (page 12).

2. Set up your inno™ (page 20).

3. Activate your XM subscription (page 18).

4. Listen to and record live XM* (pages 26 and 33).

5. Listen to recorded content (page 37).

6. Buy songs from XM+Napster (page 55).

7. Manage your songs and playlists from your computer (page 56).

*Hardware and required monthly subscription sold separately. Recorded music not for use in commercial establishments. Installation cost and other fees and taxes, including a one-time activation fee may apply. Subscription fee is consumer only. XM products, programming, services, and fees are subject to change, at any time, without notice. Channels with frequent explicit language are indicated with an XL. Channel blocking is available for XM radio receivers by calling 1-800-XM-RADIO. Subscriptions subject to Customer Agreement available at xmradio.com. XM service only available in the 48 contiguous United States. ©2006 XM Satellite Radio Inc. All rights reserved.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 2

Introduction

Features

Congratulations on your purchase of the Pioneer inno™. It’s the next-generation XM2go

radio, with an XM receiver, built-in antenna, and storage for XM, MP3, or WMA music files in one portable device.

Enjoy XM’s 170 channels from coast to coast, with over 80,000 hours of entertainment each month. XM offers musical choice, variety, and discovery – worlds beyond your own collection – plus a wide range of news, sports, talk, comedy, kids, and entertainment channels. Hear XM live, or save XM programming on your inno to listen at your leisure.

We’ve also teamed up with Napster, a leading provider of online music. Imagine discovering a new artist on XM and then, with just a few clicks of a mouse, buying high-fidelity tracks and albums by that artist and similar artists. It’s that simple.

Manage all your music – XM tracks, songs you purchase from Napster, and MP3/WMA files you rip from your CDs – with the easy-to-use XM+Napster program on your Microsoft

Windows®PC.

One device, all the music you could ever hope for, and the easiest way to find the music you want – now that’s a music experience!

We recommend that you read the entire manual before using your inno.

inno™, Undocked

■

Listen to live and recorded XM* content

■

Play MP3 and WMA files

■

Manage your tracks, favorite channels, and playlists

■

Listen on the go

inno + Dock + Antenna

■

Listen to live and recorded XM* content

■

Play MP3 and WMA files

■

Manage your tracks, favorite channels, and playlists

■

Listen in your car or home

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 4

Introduction

Safety Instructions

Please read and understand all the instructions to avoid injury to yourself and/or damage to your inno. Please be aware that Pioneer claims no responsibility for damage from data loss due to breakdown, repair, or other causes.

inno Digital Audio Player

■

Do not expose to extreme temperatures (above 140°F or below -4°F, or above 60°C or below -20°C).

■

Do not expose to moisture. Do not use inno near or in water.

■

Do not let any foreign matter spill into inno.

■

Do not expose to chemicals such as benzene and thinners. Do not use liquid or aerosol cleaners. Clean with a soft damp cloth only.

■

Do not expose to direct sunlight, fire, flame or other heat sources for a prolonged period.

■

Do not try to disassemble and/or repair inno yourself.

■

Do not drop your inno or subject it to severe impact.

■

Do not place heavy objects on inno.

■

Do not subject inno to excessive pressure.

■

Do not touch the inno with wet hands.

■

Do not store in dusty areas.

inno + Dock + Antenna + PC

■

Manage content using inno or your PC

■

Listen to XM Radio Online

■

Purchase music from XM+Napster and upload it to your inno

WA R N I N G : Handling the cord on this product or cords associated with accessories sold

with the product will expose you to lead, a chemical known to the State of California and other governmental entities to cause cancer and birth defects or other reproductive harm.

Wash hands after handling

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 6

Introduction

Protect Your Ears

Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of sound. So what sounds “normal” can actually be loud and harmful to your hearing. Set your equipment at a safe level BEFORE your hearing adapts. To establish a safer level: Start your volume control at a low setting; Slowly increase the sound until you can hear it comfortably and clearly, without distortion. Once you have established a comfortable sound level: Set the dial and leave it there; taking a minute to do this now will help to preserve hearing.

Pioneer and the Consumer Electronics Association recommend you avoid prolonged exposure to excessive noise. Under constant exposure such as sustained listening, sound levels above 85 decibels can be dangerous without hearing protection. (For reference, a garbage disposal or loud shouting at 3 feet away are around 80 decibels; a food blender or gas lawn mower at 3 feet away are around 90 decibels.) The longer your exposure and/or higher the sound level, the greater the danger of permanent hearing damage. Pioneer disclaims all liability for hearing loss, bodily injury or property damage as a result of use or misuse of this product.

Introduction

Battery Charger Safety

Caution: Opening the case may result in electric shock. Caution: The uninsulated parts inside the power adapter and dock may cause electric shock

or fire. For your safety, please do not open these components. Do not let metallic objects, such as necklaces or coins, come into contact with the power adapter plugs or battery terminal. Caution: To avoid electric shock, use the power adapter only with an outlet that matches the shape of the adapter’s plug.

Caution: Make sure that you insert the adapter’s plug all the way into the outlet. Caution: Do not plug several devices into the same electrical outlet. Important: Always read and understand the user guide to prevent problems. Warning: Use the power adapter and dock away from water sources to avoid fire or

electric shock.

Environmental Information

■

Follow local guidelines for waste disposal when discarding packaging, batteries, and

electronic appliances.

■

Your player is packaged with cardboard, polyethylene, etc., and does not contain any unnecessary materials.

Earbuds and Headphones

■

Follow traffic safety instructions.

■

Do not use earbuds or headphones while operating a bicycle, automobile, or motorcycle.

Not only is it dangerous, it may be prohibited by law in some areas.

■

For your safety, make sure the earbud or headphone cable does not get in the way of your

arm or other surrounding objects while you’re walking or exercising.

■

Maintain a moderate volume when walking or exercising, so that you can be aware of what is happening around you.

■

Using earbuds or headphones for an extended time can cause serious damage to your hearing.

■

We strongly advise you to set the volume level to medium, which is usually less than 2/3 of the maximum.

■

If you hear ringing in your ear(s), lower the volume or stop using the earbuds or headphones.

WA R N I N G : inno should be placed in your vehicle where it will not interfere with the func-

tion of safety features, e. g . , deployment of airbags. Failure to correctly place inno may result in injury to you or others if the unit becomes detached during an accident and/or obstructs the deployment of an airbag.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 8

Introduction

What’s in the Box

inno

(GEX-INNO1)

Battery

Home dock

Earbuds

Remote

What’s in the Box

Home XM antenna

RCA audio cable

Also included:

User guide

XM+Napster install CD

USB cable

AC power

adapter

Carrying

case/holster

Travel power

cable

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 10

3. Plug adapter into dock and wall socket. When you insert inno into a dock, wait for the beep before powering on.

Introduction

Charging the Battery

Charge the battery for at least 8 hours before using inno for the first time, or if you have not used it for several months. Be sure to charge the battery in a place where the temperature is between 32°F and 113°F (0°C to 45°C).

1. Open battery compartment.

2. Insert battery into player.

inno Controls

Power button – Slide

down to turn power on or off. Slide up to “hold” controls, preventing you from accidentally pressing a button.

Display button –

Change what’s showing on the display.

XM button – Start

here; press to access channels, playlists, menus, and confirm selections.

Mode – Switch

between “Live XM” or “My Music” (recorded content).

Arrow buttons –

Select menu entries, change channels.

Display

Volume

Earbud jack

USB jack

Play/Pause

Left arrow button –

Pressing the left arrow button allows you to “back out” of or exit most menus.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 12

Introduction

Using This Guide

Throughout this guide, you will see instructions such as “Select XM➝Settings➝Setup

➝

Antenna Aiming.” This tells you to perform the following actions:

1. Press the XM button.

2. You will see a menu whose last option is “Settings.” Press the down arrow button several times to highlight “Settings,” then press the XM button to select it.

3. You will see another menu whose third option is “Setup.” Again, press the down arrow button to highlight “Setup,” and press the XM button to select it.

4. You will see another menu; one of the options is “Antenna Aiming.” Press the down arrow button to highlight “Antenna Aiming,” and the XM button to select it.

Not all of the menu items described in this guide may appear on your inno display. For example, if you have not created any playlists, you will not see “Playlists” if you press the

XM button while listening to “My Music.”

Introduction

inno Controls

When you put inno in its home dock, both the display and arrow buttons rotate by 90° so that “up” really points up!

✍

NOTE: In most instances,pressing the left arrow button allows you to “back out” of

any menu.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 14

Available memory or signal strength –

Green portion indicates amount of storage taken up by locked XM songs (page 40). In “Live XM” mode, you will see a signal strength indicator instead.

Indicates XM channel, playlist, or MP3 genre.

Introduction

inno Display

play

reverse or fast-forward through track

pause

skip to previous or next track

PC track (MP3 or WMA file)

track assigned to a playlist

PC track assigned to a playlist

XM track is locked

repeat track

play tracks randomly

Additional symbols:

Battery charge

Mode – (((XM))) shows

you’re listening to live XM. (((My Music))) shows you’re listening to stored XM content or MP3/WMA tracks.

H – ”H” indicates that the

power switch is set in the “hold” position.

Clock

Channel number

Artist name

Song title

Remote

Power button

Left arrow button –

Pressing the left arrow button allows you to “back out” of or exit most menus.

Volume

Record – Record a song

or channel.

Bookmark – Tag interesting

songs or tracks.

Numeric keypad – Select

XM channels by channel number.

Mode – “Live XM” or

“My Music” (recorded content).

XM button – Access

menus and confirm selections.

Arrow buttons –

Select menu entries, change channels.

Pause/Mute – Pause

playback or mute live XM.

Favorites – Go to

favorite channels.

Jump – Switch to previous

channel you listened to.

Display – Change what’s

showing on the display.

Progress bar – Shows

total track length and current location within a track while playing songs in “My Music.”

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 16

Subscribing to XM

18 19

Subscribing to XM

Before you can listen to or record XM content, you must activate your inno.

1. Set up your inno, dock station, power adapter, and antenna (page 20 or page 22). Make sure inno can receive the XM signal.

2. Place inno in the “Live XM” mode (page 26).

3. Find the 8-character XM Radio ID, which is printed on the package or in the battery compartment underneath the battery. Or select XM channel 0 to view the Radio ID. Record the Radio ID here for reference:

■■■■ ■ ■ ■■

The XM Radio ID does not use the letters I, O, S, or F.

4. Activate your XM Satellite Radio service online at http://activate.xmradio.com or by calling

1-800-XM-RADIO (1-800-967-2346). You will need a major credit card.

XM will send a signal from the satellites to activate the full channel lineup. A c t i vation normally takes 10 to 15 minutes, but during peak busy periods you may need to keep your player on for up to an hour. When you can access the full channel lineup on your inno, you’re finished!

Product registration

Visit us at the following site:

1. Register your product. We will keep the details of your purchase on file to help you refer to this information in the event of an insurance claim such as loss or theft.

2. Receive updates on the latest products and technologies.

3. Download owner’s manuals, order product catalogues, research new products, and much more.

I M P O R TANT (Serial Number) The serial number of this device is located on the back

of this unit. For your own security and convenience, be sure to record this number on the enclosed warranty card.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 18

Using Your inno Alone

Setup

At Home

1. Insert inno into home dock.

2. Connect inno to your audio system as shown. Connect power adapter and home antenna. Point antenna toward the southern sky through a window.

3. To optimize signal reception, you may mount the home antenna outdoors, facing south. Make sure the antenna is not blocked by buildings or trees.

To AC power adapter

To your audio system’s line input or AUX input

To home antenna

While Traveling

If you’re traveling, you can connect the power adapter directly to inno using the travel power cable.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 20

Using Your inno Alone

Setup

In a Vehicle (requires Car Accessory Kit CD-INCAR1, sold separately)

Every vehicle is different; for your safety, follow all instructions carefully. Consult a professional installer if you have questions.

You can listen to your inno through your car stereo by using inno’s built-in FM transmitter. Simply find an unused FM frequency on the stereo and set inno to transmit on that same frequency.

1. Mount antenna to the roof or trunk of the vehicle. During installation, make sure you are outdoors and the antenna is not obstructed by tall buildings.

Using Your inno Alone

2. Insert inno into car dock.

3. Connect car dock to antenna cable and power adapter.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 22

4. To install the swivel mount, first find a suitable location. The swivel mount’s adhesive is very strong and may be difficult to remove. Do not install this mount on leather surfaces and make sure the air temperature is at least 60°F (15°C).

Clean the mounting surfaces with the surface preparation kit. Peel away the adhesive liner and firmly press the swivel mount to the surface for 30 seconds. Allow 24 hours before using the mount.

If you need to remove the mount, carefully lift the adhesive pad with your fingers or a spoon. Warming with a hair dryer for several minutes will help soften the adhesive.

Using Your inno Alone

5. To install the vent mount, find a horizontal vent that is strong enough to hold your inno and dock. To remove the vent mount, push it into the vent and lift upwards slightly to release the mount’s hooks from the vent vane.

6. Find an unused FM frequency on your car stereo.

7. Set your inno to the same FM frequency. (Refer to the section marked “Settings,” “FM Frequency.”)

8. Tune inno to XM channel 1. You should be able to hear XM through your car stereo.

You can adjust the tension of the mount with a screwdriver.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 24

Using Your inno Alone

Live XM

Turn on your inno. Subscribe to XM (page 18) if you haven’t done so already.

If you see “XM” at the top of the display, you’re listening to XM content that is currently being broadcast from the satellites.

If you see “My Music” on the display, you’re listening to recorded XM or MP3/WMA tracks. Press the Mode button to switch to “Live XM.”

Selecting Channels

Press the up or down arrow buttons to scroll through the list of channels.

- OR –

Press the number keys on the remote that correspond to the channel number.

- OR –

1. Press the left arrow button on your inno. You will see a virtual keypad on the display.

2. Use the arrow buttons to select the digits corresponding to the channel number. Press the XM button after highlighting each digit.

3. When you’ve entered a valid channel number, your inno will tune to that channel within 2 seconds.

✍

NOTE: You must receive a live XM signal for at least 8 hours a month (which may be split over several listening sessions). This authenticates your XM subscription and ensures that you can continue to enjoy your recorded XM content and live XM programming. If you do not dock your inno as described, you will lose access to your recorded content and live XM programming.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 26

Using Your inno Alone

Favorite Channels

You can save your favorite channels in an easily accessible list.

1. While you’re tuned to a channel, press the XM button.

2. Select Favorites ➝Add Channel.

3. Once you’ve saved your favorites, you can quickly access the list. From the “Live XM” screen, simply press the right arrow button to see your “Favorites” list. Press the up and down arrow buttons, then the XM button to select the desired channel.

4. To remove a channel from the “Favorites” list, select XM ➝Favorites ➝Edit

Channels ➝(channel name) ➝Remove Channel.

Categories

XM channels are organized into categories, or genres, such as “Rock,” “Jazz,” or “News.”

To find a channel by category:

1. Press the right arrow button one or more times. The category name appears in the display.“Favorites” is your first category if you have designated any channel as a “favorite channel.”

2. When you’ve found the category you want, press the up or down arrow buttons to select a channel.

3. Press the XM button to tune to that channel.

TuneSelect

™

TuneSelect™finds your favorite artist or song whenever they’re currently being played on any XM channel.

1. When you hear one of your favorite songs, select XM ➝Bookmark.

2. You should see the following menu:

3. When any song or artist on your TuneSelect list is currently playing on any other XM channel, inno will beep and flash “Artist/Song Found” on the display. Switch to that channel by pressing the XM button.

4. To edit the TuneSelect list, select XM➝Settings➝Preferences➝TuneSelect

➝

Edit List. Choose song or artist and follow the directions on the display.

5. To turn TuneSelect on or off, select XM ➝Settings ➝Preferences ➝TuneSelect

➝

Alert and choose the desired setting.

Select either “TuneSelect Artist” or “TuneSelect Song” to add the artist or song to your TuneSelect list.

What’s a “bookmark”? See page 45.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 28

Using Your inno Alone

Using Your inno AloneUsing Your inno Alone

TuneSelect also allows you to type an artist name or song title even if the song isn’t currently playing on your inno.

1.Select XM➝Settings➝Preferences➝TuneSelect➝Edit List➝Add TuneSelect.

2. Press the up or down arrow buttons to choose the artist or song title field.

3. Press the XM button. You will see a virtual keyboard. Type in the artist name or song title.

4. Select “Enter” when you’re finished, or select “Exit” to cancel.

5. Select “Accept” to add that name or title to your TuneSelect list. You can also select “Change” or “Cancel.”

✍

NOTE: The artist name and song title fields are case-sensitive.

Info Extras

XM Satellite Radio broadcasts information such as sports scores, stocks, and other features from time to time.

To Choose Sports or Teams:

1. Select XM➝Settings➝Preferences➝Info Extras➝Sports.

2. Use the arrow buttons to highlight (in yellow) a sport or team.

3. Press the XM button to select that sport or team. The name of the sport or team will turn green.

4. You may select more than one sport or team to display.Your chosen selections are shown in blue. To remove a selection, go to that entry and press the XM button; the entry will change color from blue to gray.

5. When you’re finished, press the left arrow button repeatedly until you return to the normal display. Or just wait several seconds for inno to return to its home screen automatically.

To Select Stocks*:

1. Press XM➝Settings➝Preferences➝Info Extras➝Stock Ticker➝Add Stocks.

2. You should see a virtual keyboard that will allow you to enter a stock symbol.

3. Use the arrow buttons to highlight the first letter in the stock symbol. Choose that letter by pressing the XM button.

*Quotes are provided by ComStock, Inc. and cover most stocks listed on the NYSE, AMEX, or NASDAQ. Market information is delayed by approximately 25 minutes.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 30

Using Your inno Alone

4. Continue selecting letters by using the arrow and XM buttons.

5. Select “Enter” when you’ve entered the entire stock symbol. Your inno is smart enough to automatically complete some stock symbols.

6. You can track up to 20 stock symbols. When you’ve entered all your desired stock symbols, select “Exit.”

7. Press the left arrow button repeatedly (or simply wait a few seconds) until your inno returns to normal operation.

To display Info Extras, press the Display button several times until you see sports scores or a stock ticker at the bottom of the display.

Recording XM

Your inno enables you to record XM content for personal, non-commercial use. You may record XM content while listening to live XM or by scheduling a recording session. You can then listen to recorded XM content on the go. You can also personalize your XM content by creating playlists for every mood and occasion.*

Recording a Single Song

1. While you’re listening to live XM, select XM➝Record➝Record Song. Don’t worry if you miss the beginning of the song; your inno captures the entire song even if you start up to 10 minutes after the song begins, as long as you’re already tuned to that channel.

By selecting “Record Song,” you instruct your inno to stop recording at the end of the song.

2. You can continue recording the channel you’re listening to by selecting XM➝Record

➝

Rec Channel.

3. To stop recording at any time, select XM➝Record➝Stop Recording. If you change channels, inno automatically stops recording.

S H O R T C U T:To immediately start recording at any time, press and hold the XM button

until you see the “Recording …” message appear on the display.

*XM content cannot be exported from the inno digital audio player. If you wish to own a complete, high-fidelity version of digital content on demand, you should purchase content from XM+Napster. This may allow you to store the content on multiple devices depending upon the digital rights management of such content.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 32

Using Your inno Alone

Recording a Channel

1. While you’re listening to live XM, select XM➝Record➝Rec Channel. You will record the channel you’re currently listening to.

2. To stop recording at any time, select XM➝Record➝Stop Recording. If you change channels, inno automatically stops recording.

3. You can choose to stop recording at the end of the song you’re currently listening to by selecting XM➝Record➝Record Song.

Scheduling a Recording Session

You can set inno to record XM at a later time. When you schedule a recording session, remember that inno must be able to receive a live XM signal when the session begins.

1. To schedule a recording session, select XM➝Record➝Schedule Rec➝New Session.

2. The “Scheduled Rec” display allows you to set various options. Use the up and down arrow buttons to adjust each entry. Press the left or right arrow buttons to move to the previous or next option.

You can choose to schedule a session for “Today,” ”Everyday,” or a specific “Date.”

Set start and stop times using the up and down arrow buttons. If the session length exceeds the available memory, you will record over the oldest XM tracks in the memory, so you’ll always have the latest content.

Choose the channel you want recorded. You can enter the channel number using the remote’s numeric keys.

Choose “OK” to save the session or “CANCEL” to start over.

inno informs you if there is a scheduling conflict such as overlapping sessions.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 34

Using Your inno Alone

3. To edit an existing session, select XM➝Record➝Schedule Recording. You will see a list of sessions. Highlight the session you wish to edit.

You may not see all the sessions that you scheduled in the past. Sessions that have expired are automatically removed from the list.

4. Choose Edit Session to change the session’s options.

5. To delete a session, choose Cancel Session.

At the scheduled time, your recording session will begin and change channels if needed. Remember that when you schedule a recording session, you are instructing inno to switch to the desired channel.

✍

NOTE: Scheduled recording sessions will begin only if inno is put in a home dock or in a boombox with AC power. Your inno can be powered off or on. M a ke sure your inno can receive a strong XM signal!

Listening to Recorded XM Content (My Music)

When you see “My Music” at the top of the display, you’re listening to XM content that you have recorded and any MP3/WMA files you have transferred to your inno.

1. To switch to “My Music” from “Live XM,” press the Mode button.

2 . Press the up and down arrow buttons to view a list of songs that you have stored on inno.

Highlight the song you want to listen to, then press XM➝Play to start playing from that song.

3. You can press the right arrow button to skip to the next song. Press the left arrow button to skip to the previous song.

4. While you’re listening to a song, you can also press and hold the right arrow button to fast-forward through that song. Press and hold the left arrow button to reverse through the song.

✍

NOTE: In order to access your XM content you have recorded on inno, you must (1) maintain an active XM Satellite Radio subscription, and (2) receive the live XM signal at least 8 hours a month.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 36

Using Your inno Alone

Organizing Your Music

Finding Your Music

All songs and tracks that are stored in your inno are normally played in the order that they were recorded or transferred into your inno. You can also sort the selections by artist, category, or channel.

1. While listening to recorded tracks in “My Music,” select XM➝Find.

2. Choose how to view your stored music. For example, to sort your stored music by artist, select Artists.

3. Press the up or down arrow buttons to scroll through the list of artists. Press the XM button to select an artist.

View all songs on your inno.

You can also sort songs by artists, by categories, by channels, or by recording sessions.

4. Once you’ve selected an artist, you will see a list of songs by that artist that you have recorded.

5. Select the song you want to hear using the arrow and XM buttons. Select XM ➝ Play to begin playing that song.

6. To return to the list of artists, press XM ➝Find ➝Artists and select another artist as in steps 3 and 4.

7. You can also sort your tracks by categories or by channels. WMA and MP3 songs show the category or genre that they are assigned to using their ID3 tags, which may or may not be the same as the XM category. WMA and MP3 songs are also assigned to a channel named “MP3/WMA.”

8. To view all the songs stored in your inno, press XM➝Find➝All Songs.

S H O R T C U T:As soon as you’ve highlighted a song, simply press the right arrow button to start

p l a y b a c k .

Shows the artist’s songs in the order they were recorded.

Opens the Edit window, allowing you to add an artist to a playlist, lock or unlock all the artist’s songs, or delete all the artist’s songs.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 38

Playlists – Adding Songs

You can create one or more custom lists, called playlists. Each playlist is an index of songs that play in a certain order. You can create a “morning drive” playlist, a “workout” playlist, a “best of” playlist, and more.

1. To add a song to a playlist, first select a song using the up or down arrow buttons. The song may be a recorded XM track, an MP3 track, or a WMA track, including songs purchased through XM+Napster.

2. Select XM➝Edit Song➝Add to Playlist.

3. You can choose to add the song to an existing playlist or to create a new playlist. To choose an existing playlist, simply highlight and select the playlist name. To create a new playlist, choose New Playlist and use the virtual keyboard to name that playlist.

4. The display confirms by showing “(playlist name) (song title) Added.”

5. Adding a song to a playlist automatically locks that song.

You can add a song to more than one playlist or a song to the same playlist more than once.

You can also add all songs by an artist to a playlist: select XM➝Organize➝Artists

➝

(artist name)➝Add to Playlist. You can also add all songs in a particular XM channel or category to a playlist.

Using Your inno Alone

Locking and Unlocking XM Content

When you record XM, your inno records over the oldest XM tracks first. This ensures that you always hear the latest XM content. You can “lock” a song or track to prevent inno from recording over it. Locked songs occupy memory on your inno and reduce your available recording time. Remember that you can buy high-fidelity songs or albums from XM+Napster that can be stored either on your inno or on your PC.

1. While you’re listening to a song in “My Music,” press the up or down arrow buttons to view the list of songs.

2. Highlight the song you want to lock.

3. Select XM➝Edit Song➝Lock Song.

4. The locked song is indicated with a padlock symbol to the left of the song title.

5. To unlock a song, highlight the song in the list and select XM➝Edit Song➝Unlock Song.

You can also lock all songs by an artist, in a category, or in a channel. To lock all songs by an artist:

1. Select XM➝Organize➝Artists➝(artist name)➝Lock Artist.

2. All songs by this artist are displayed with a padlock symbol to the left of the song title.

If you add a song to a playlist, that song is automatically locked.

S H O R T C U T: To lock the song you’re currently listening to, press and hold the XM b u t t o n ,

then select Lock Song.

S H O R T C U T : When you’re in “My Music,”you can add the recorded XM song that you’re

currently hearing to a playlist by pressing and holding the XM b u t t o n , then selecting Add to Playlist.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 40

Using Your inno Alone

Playlists – Removing Entries

You can remove entries from a playlist. Remember that removing a song from one playlist does not remove it from any other playlist, and does not delete that song from inno.

To remove one or more songs from a playlist:

1. Select XM➝Playlists➝(playlist name)➝Edit Playlist➝Remove Songs.

2. Use the up and down arrow buttons to highlight a song.

3. Press XM➝Select. The song’s name will change to green.

4. Use the up and down arrow buttons to highlight another song, and press the XM button to select that song. Do this for all the songs you want to remove; these songs are displayed in blue.

5. Select XM➝Remove Song(s)➝Yes.

6. inno confirms by displaying “Songs Removed.”

S H O R T C U T: Instead of steps 3 and 4, press the right arrow button to select the song you wa n t

to remove.

Playlists – Playing

1. Select XM➝Playlists➝(playlist name)➝Select.

2. Choose a song you want to hear and press the XM button.

3. You will see the following options:

4. To exit a playlist and return to all songs, select XM➝Find➝All Songs.

Play songs in the order listed in the playlist, starting from the selected song.

Play songs in random order, starting from the selected song. To cancel random play, select a song but choose “Play” instead of “Random.”

Repeat the selected song. To cancel repeat play, select a song but choose “Play” instead of “Repeat Song.”

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 42

Using Your inno Alone

Playlists – Other Options

Normally, the songs in a playlist appear in the order that they were added.

To rearrange the songs in a playlist:

1. Select XM➝Playlists➝(playlist name)➝Edit Playlist➝Arrange Songs.

2. Use the up and down arrow buttons to highlight a song.

3. “Pick up” that song by pressing the XM button. The song title changes to green.

4. Move the song using the up and down arrow buttons.

5. “Put down” the song by pressing the XM button. The song title changes back to yellow.

6. Repeat steps 2-5 for any song you want to move. When you’re finished, press the left arrow button repeatedly until you return to normal operation.

To rename a playlist:

1. Select XM➝Playlists➝(playlist name)➝Edit Playlist➝Rename Playlist.

2. Use the virtual keyboard to change the name of the playlist.

3. Select “Enter” when you’re finished, or “Exit” if you don’t want to save your changes.

✍

N O T E : You can also manage the playlists on your inno by using the XM+Napster application

on your PC.

Bookmarking Songs

“Bookmarks” are a great way to remember interesting songs. You can view all your bookmarks through the XM+Napster application, look up information about the artist or album, or purchase a complete, high-fidelity version of the song that you may play on multiple devices through XM+Napster.You may also purchase songs by the same artist (or similar artists) through XM+Napster.

To bookmark a song in “My Music”:

1. Press the up or down arrow buttons until you highlight the song you want to bookmark.

2. Press XM➝Edit Song➝Bookmark Song.

3. inno confirms by displaying “Info Added.”

To bookmark a song in “Live XM”:

1. Select XM➝Bookmark➝Bookmark Only.

2. inno confirms by displaying “Info Added.”

S H O R T C U T: To bookmark the song that you’re currently listening to in “My Music,” p r e s s

and hold the XM button,then select Bookmark Song. You can only bookmark live or recorded XM tracks, not MP3 or WMA tracks.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 44

Using Your inno Alone

Deleting Songs

When you’re no longer interested in a song or track, you can delete it from your inno. “Deleting” a song permanently erases it from memory, and is different from “removing” a song from a playlist.

To delete one song from “My Music”:

1. Press the up or down arrow buttons until you highlight the song you want to delete.

2. Select XM➝Edit Song➝Delete➝Yes.

3. inno confirms the song is erased by displaying “Song Deleted.”

S H O R T C U T: To delete the song that you’re currently listening to,press and hold the XM

b u t t o n , then select Delete.

To delete multiple songs from “My Music”:

1. Select XM➝Organize➝Songs.

2. Use the up and down arrow buttons to highlight a song.

3. Select XM➝Select Song. The song’s name will be displayed in green.

4. Use the up and down arrow buttons to highlight another song, and press the XM button to select that song. Do this for all the songs you want to remove.

5. Select XM➝Delete➝Yes.

6. inno confirms that the songs are erased by displaying “Songs Deleted.”

S H O R T C U T: Instead of steps 3 and 4,press the right arrow button to select the song you

want to delete.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 46

Using inno with a PC

Click here to begin the installation.

Click here when you’re finished with the installation procedure.

Follow the directions indicated on the screen. If you have any questions about the XM+Napster software, see the XM+Napster FAQs at http://napster.xmradio.com.

System Requirements

The inno will not work with all computers.

The PC system must meet the following requirements:

■

Intel®Pentium®- class CPU

■

Microsoft Windows XP Home, Windows XP Professional, or Windows 2000 operating system*

■

At least 64 MB of RAM.

■

At least 13 MB of available hard disk space for XM+Napster application.

■

Internet Explorer 5.1 or higher.

■

Windows Media Player 9 or higher; Windows Media Player 10 recommended for Windows XP.

■

Active Internet connection; we recommend a broadband (cable, DSL, or fiber) connection for optimal performance.

■

inno may not work with all computers meeting these requirements depending on system configuration and user demands on existing hardware and software.

*The following operating systems are not supported: Windows 95, Windows 98, Windows NT, Windows Me, and Mac OS.

Setup

We recommend reading this entire section before using your inno with a PC.

To connect your inno to your PC:

1. If you haven’t done so already, disconnect your inno and its dock from your PC.

2. Insert the XM+Napster CD into your computer’s CD or DVD drive.

3. The software should start automatically. You should see the following screen on your PC:

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 48

Using inno with a PC

Registering with XM+Napster

Choose either the XM+Napster Light service or the XM+Napster service. XM+Napster Light allows you to buy individual songs or albums whenever you want. XM+Napster lets you stream music to your PC for an additional monthly subscription.

XM+Napster XM+Napster Light

Manage XM content and MP3/WMA files on your inno

Transfer MP3/WMA files from your PC to your inno

Buy individual songs or albums to keep forever, burn to CD, and transfer onto your inno

Additional monthly subscription with XM+Napster required

Download and listen to all the Napster music you want on your PC

Listen to 75+ XM channels on your PC from XM Radio Online

Community and music discovery tools

✔

4. Reboot your PC if necessary, then launch the XM+Napster program from the shortcut on your desktop.

5. Set up inno as shown and plug the USB cable into the PC. You can also connect the USB cable directly between your PC and inno without using the home dock, home antenna, and AC power adapter.

6. Your PC should recognize inno. Close any file folders that appear on your screen. You can manage the contents of inno entirely by using the XM+Napster program.

7. When taking your inno with you, you must disconnect inno from the PC by following the procedure described in “Disconnecting Your inno from the PC” (page 60).

WA R N I N G : Only use the USB cable supplied in the package. Other USB cables may not allow

your inno to charge its battery or communicate with your PC.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 50

Using inno with a PC

3. If you choose XM+Napster, you must provide a valid credit card. Registering for XM+Napster Light does not require a credit card; you only need one when you purchase individual songs or albums. Simply select “Start XM+Napster Light” instead of entering your billing information.

For XM+Napster, enter your credit card information.

For XM+Napster Light, simply click here.

4. The next time you use XM+Napster, sign in with your user name and password to access the XM+Napster service. You can also use the XM+Napster software off-line, without signing in, and still retain the ability to manage your inno.

To register, follow these steps:

1. Click File/Sign In on the XM+Napster application. Click on the link for new members.

2. Follow the directions indicated on the registration screen. You must provide your active XM Radio ID and billing ZIP code to register.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 52

Using inno with a PC

Purchasing Music

The XM+Napster store allows you to stream, download, or buy songs or albums.

■

S t r e a m – Listen to a song while your PC is connected to the Internet.

■

D o w n l o a d – Store music on your PC. You can listen to these songs any time,

even if your PC is off-line.

■

B u y – Purchase the track or album. You can transfer these songs to your

inno at any time.

“download” – Available to buy,

download, or stream from XM+Napster.

“buy only” – Only available to buy or to

sample a 30-second clip from XM+Napster.

What Can You Do with XM+Napster?

Using XM+Napster, you can:

■

Manage songs, playlists, and recording sessions on your inno.

■

Transfer MP3 and WMA files between inno and your PC.

■

Explore and purchase music from XM+Napster’s enormous online store.

■

Listen to XM Radio Online.

Exploring

Explore XM+Napster’s online store and community, with over 1.5 million songs, 100,000 albums, and 80,000 artists.

Search by entering an artist name, song title, or album.

Drag and drop tracks or albums onto the “playlist/ radio” pane to play them on your PC.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 54

Using inno with a PC

Recording Sessions

View and edit your inno recording sessions by selecting Library/inno/XM Recordings on the XM+Napster application.

Enter the options for the recording session.

Create a new recording session or choose an existing session.

Organizing Your Music

The “Folder” pane lets you view the tracks stored on inno or on your PC, playlists, recording sessions, bookmarks, and more. Click on the desired folder to see its contents on the main pane.

Drag and drop purchased tracks into the “transfer” pane to move them from your PC to your inno.

The main pane shows the contents of a folder.

View and manage all the XM content you recorded, WMA, and MP3 tracks on your inno and your PC.

Drag and drop tracks or albums onto the “playlist/radio” pane to play them on your PC.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 56

Using inno with a PC

Transferring Between PC and inno

To transfer a track or playlist from your PC to your inno, drag and drop the track or playlist into the “transfer” pane on the lower right-hand side of the XM+Napster application.

You can only transfer songs that you have purchased from XM+Napster or songs that you have ripped from your audio CDs. inno only recognizes file names that use single-byte characters; double-byte and multi-byte character sets (Asian languages such as Chinese, Korean,or Japanese) are not supported.

WA R N I N G : Though you can transfer non-MP3/WMA files to your inno using W i n d o w s, t h o s e

files cannot be played as audio files. F u r t h e r m o r e, do not attempt to format the inno storage; doing so may cause damage to the device.

Playlists

You can manage your inno playlists using XM+Napster. Simply dock your inno, then select Library/inno/Playlists. You can create new playlists, or edit or delete any playlists that are stored in your inno.

You can also create and manage playlists for any music content stored on your PC. Select Library/My Playlists.

To add a track to any playlist, select that track on the main pane and drag it to the playlist name in the “Folder” pane.Alternatively, right-click on the track name, then select the playlist you want to add the track to.

You can move a PC playlist onto your inno by dragging that playlist name into the Library/ inno/Playlists line.When you move tracks and playlists onto your inno, you may have to purchase that content from XM+Napster, if you have not done so already.

inno playlists

PC playlists

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 58

Using inno with a PC

Listening to XM Radio Online (XMRO)

XM Radio Online gives you access to over 75 channels of the same amazing programming you hear on XM Satellite Radio, plus 10 select AOL Radio channels for even more choice.

To access XM Radio Online, click on Home/Radio/XM Radio Online. Then simply choose your desired channel from the channel list.

Save favorite channels in the preset buttons (at the top of the screen) by dragging a channel onto the desired button. Note that these presets are not the same as the “Favorite Channels” on your inno.

You can enjoy XM Radio Online anywhere you have a PC and a high-speed connection. Remember that you cannot save or transfer XMRO programming onto your inno.

Disconnecting Your inno From the PC

Before you remove your inno from its dock or unplug the USB cable from the dock or the PC, you must disconnect using one of the following methods:

■

In Windows: right-click on the Safely Remove Hardware icon , which is on the right side of the Windows taskbar. Select “USB Mass Storage Device,” and click on Stop.

■

On XM+Napster: click on the Disconnect Device icon or select File/Disconnect portable device.

If you want to connect inno to your PC again, re-insert inno into its dock.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 60

Using inno with a PC

Burning CDs

Transfer MP3 and WMA files onto a recordable CD or DVD. Please note that the content recorded from XM cannot be burned onto a CD or DVD or otherwise transferred off your inno.

1. Insert a recordable CD or DVD into your PC’s CD/DVD drive.

2. Click Library.

3. Pull up the Burn screen at the bottom of the main pane.

4. Drag and drop tracks into the “Burn” pane.

5. When you’ve finished selecting tracks, click Burn Disc.

Using inno with a PC

Using Your CDs or MP3/WMA Files

Ripping Your CDs

Use the XM+Napster application to rip tracks from a CD into your Napster library.

1. Insert an audio CD into your PC’s CD drive.

2. Click on Library, then click on the CD icon in the “Folders” pane. You will see a listing of the CD tracks in the main pane.

3. Click the Rip icon on the bottom of the main pane. By default, the tracks will be encoded into the WMA format at 128 kbps. You can change this setting by clicking File/

Options/CD Options.

Importing Tracks Into XM+Napster

If you have already created MP3 or WMA files in your computer, you can import them into your Napster library.

1. Click File/Import Tracks to My Library …

2. Follow the directions on the screen.

For more information, please see the XM+Napster FAQs at http://napster.xmradio.com.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 62

Updating inno Firmware

Occasionally we make improvements to the inno firmware, which is the software that makes your inno work. Updating the firmware is a quick and easy process.

Remember that:

■

Your inno must be docked with a power adapter and must be connected to your PC. You cannot update the firmware if inno is not docked and powered.

■

Your PC must be connected to the Internet

Using XM+Napster

If you have installed and use XM+Napster, it automatically checks the firmware when you connect inno to your PC. XM+Napster notifies you when it’s necessary to update the firmware. Simply follow the instructions.

Don’t worry if you miss a firmware update. XM+Napster will always check whether your inno needs an update or not.

Using the Update Tool

If you don’t use XM+Napster, you can update the inno firmware manually.

1. Insert the XM+Napster CD in your PC’s CD-ROM or DVD drive. The XM+Napster software should start automatically.

2. Click on Browse CD.

3. Click on Utils, then click on XMFirmwareUpdateClient.

4. Follow the instructions on the PC screen.

You can run this firmware update tool at any time. If the firmware needs to be updated, the tool will install it automatically. If the firmware is already up-to-date, nothing happens.

Using the Web

Point your Web browser to http://fwupdt.xmradio.com and follow directions.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 64

Settings

FM Modulator

(for optional Car Kit use only)

Set the FM frequency that inno transmits on.

Adjust the volume level of the FM transmission.

FM Frequency

(for optional Car Kit use only)

Your inno contains a built-in FM modulator (or FM transmitter) that allows you to listen to whatever your inno is playing using a car FM radio. All you have to do is set your inno and the FM radio in your car to the same frequency.

1. Place inno in the car dock.

2. Find an unused FM frequency on your FM radio. Note that FM frequency.

3. Select XM➝Settings➝FM Modulator➝FM Frequency.

4. Use the up and down arrow buttons to choose the same FM frequency as in step 2. You should hear XM programming over your FM radio when your inno and radio frequencies match.

5. Press the XM button to confirm your selection.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 66

Settings

Aiming the Antenna

For optimal reception of XM’s live satellite signal, your inno antenna should have an unobstructed view of the XM satellites in the southern sky. In large cities, XM also has a network of ground repeaters to help increase the signal coverage.

Your inno can help you aim the home antenna to pull in the strongest possible signal.

1. Select XM➝Settings➝Setup➝Antenna Aiming.

2. Slowly turn and tilt the antenna. The signal bars on the display will change.

3. The antenna aiming screen remains as long as it’s needed to help you position the antenna. When you’ve found the best position, press the left arrow button repeatedly to exit the Settings menu.

4. Select XM channel 1. You should be able to listen to the XM Preview Channel.

FM Level

When listening to your inno using the FM modulator,you can adjust its volume level to match other audio sources (your CD player, other FM stations, or MP3 player).

1. Select XM➝Settings➝FM Modulator➝FM Level.

2. Press the left arrow button to decrease the volume level or the right arrow button to increase the volume level.

3. Press the XM button to confirm your selection.

Move the antenna around until either “Satellite” or “Terrestrial” is at least half strength.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 68

Settings

Audio

Tone

You can adjust the audio tone quality to suit the kind of music you’re listening to.

1. Select XM➝Settings➝Preferences➝Set Tone.

2. Press the up or down arrow buttons to select either “Bass” or “Treble.”Adjust the tone settings by pressing the left or right arrows.

3. Press the XM button to save your setting and exit the tone control menu. Then press the left arrow button repeatedly until you return to normal operation.

Line Out Level

If you connect inno to another stereo system, you can adjust inno’s audio level to match other audio sources. This is not a volume control; use the volume control on your stereo instead.

1. Select XM➝Settings➝Setup➝Line Out Level.

2. Use the left or right arrow buttons to decrease or increase the audio level.

3. Press the XM button to confirm your selection. Then press the left arrow button repeatedly until you return to normal operation.

Display

Brightness and Contrast

To change the screen’s brightness and contrast:

1. Select XM➝Settings➝Preferences➝Change Display➝Brightness.

2. Press the left or right arrow buttons to adjust brightness.

3. Press the XM button to confirm your selection. Then press the left arrow button repeatedly until you return to normal operation.

Backlight Timer

Your inno screen remains lit for a short time after you press a button.To adjust this time period:

1. Select XM➝Settings➝Preferences➝Change Display➝Backlight Timer.

2. Press the up and down arrow buttons to select the desired time period.

3. Press the XM button to confirm your selection.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 70

Settings

Stock Ticker

If you created a stock ticker, you will see stock symbols and their prices displayed at the bottom of inno’s display.You can control the way the ticker is displayed.

1. Select XM➝Settings➝Preferences➝Change Display➝Display Appearance➝Stock Ticker.

2. Select Scrolling to see the ticker move across the screen from right to left. Select By Pages to view the ticker as if you’re flipping pages of a book.

3. Press the XM button to confirm your selection.

Info Extras

If you choose sports or other Info Extras features, you will see sports scores and other information displayed at the bottom of inno’s display. You can control the way this information is displayed.

1. Select XM➝Settings➝Preferences➝Change Display➝Display Appearance➝Info Extras.

2. Select Scrolling to see the ticker move across the screen from right to left. Select By Pages to view the ticker as if you’re flipping pages of a book.

3. Press the XM button to confirm your selection.

Channel Access

Direct Tune

Normally, as you scroll through live XM channels using the up and down arrow buttons, you can preview the channel list before selecting one channel. inno does not switch to that channel until you push the XM button. You can change this so that inno automatically tunes to the channel that you’re previewing.

1. Select XM➝Settings➝Preferences➝Channel Access➝Direct Tune.

2. Select Direct Tune On.

3. Press the XM button to confirm your selection. Then press the left arrow button repeatedly until you return to normal operation.

To return inno to its default behavior, select Direct Tune Off.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 72

Settings

Clock and Sleep Timer

Time

1. The time is automatically set using the XM signal. Select XM ➝Settings ➝Setup

➝

Set Time ➝Set Clock ➝Select Time Zone to set the correct time zone for your location.

2. Your inno automatically adjusts for Daylight Savings Time. To turn this feature off, select XM➝Settings➝Setup➝Set Time➝Set Clock➝Daylight Savings Time➝No.

3. To display time in 12- or 24-hour format, select the desired format through XM

➝

Settings➝Setup➝Set Time➝Set Clock➝12/24 Hour Mode.

Sleep Timer

Your inno has a sleep timer that can automatically shut off the unit after a period of time.

1. Select XM➝Settings➝Setup➝Set Time➝Sleep Timer.

2. Select the desired time period.

3. Press the XM button to confirm the selection. Your inno will remember this setting the next time you turn it on.

The sleep timer resets to “Off” every time you turn inno off.

Settings

Channel Skip/Add

You can simplify the list of channels that you see when you press the up and down arrow buttons. To skip a channel:

1. Select XM➝Settings➝Preferences➝Channel Access➝Channel Skip/Add.

2. You will see a list of channels. Press the XM button to skip a channel. You’ll see the Channel Skip icon displayed beside the channel name. You can choose to skip more than one channel.

3. To add a channel that has been skipped, highlight that channel then press the XM button.

4. Press the left arrow button when you’re finished.

5. inno confirms by displaying “Channel List Updated.”

You can still tune to a channel directly by using the virtual keypad to enter its channel number.

Channel Skip/Add should not be used as a form of parental control. To completely block access to an XM channel, contact XM Listener Care at 1-800-XM-RADIO (1-800-967-2346).

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 74

Settings

Vehicle Mode

If you listen to your inno in a vehicle, you’ve probably plugged the power adapter into the cigarette lighter socket. In some vehicles, the cigarette lighter is turned on or off with the ignition key; in other vehicles, the cigarette lighter is powered all the time. To prevent your battery from being drained, choose one of the following settings:

1. Select XM➝Settings➝Setup➝Set Time➝Vehicle Mode.

2. Choose one of the following settings:

3. The setting is saved even if you turn inno off. The vehicle mode setting is only active when you use the car dock.

OFF Choose this option if the cigarette lighter

is always powered. You must turn inno on or off using its own power switch.

ON Choose this option if the ignition key

switches the cigarette lighter on and off.

OFF or Another option if the cigarette lighter is 60-180 minutes always powered: inno automatically turns

off 60 to 180 minutes after you turn it on.

Auto ON/OFF

Delayed Power Off

Memory Partition

The internal storage in inno can store recorded XM content and MP3/WMA files. By default, the storage is divided 50/50, but you can select different memory partitions:

To change the memory partition:

1. Place your inno into the home dock and connect the AC power adapter.

2. Select XM ➝Settings ➝Setup ➝Memory Partition.

3. Highlight the desired setting and press the XM button.

4. Confirm by selecting Yes, or cancel by selecting No.

typical storage for content typical storage for PC recorded from XM (MP3 and WMA) tracks

50/50 XM/PC files 25 hours 8 hours

100% XM 50 hours 0 hours

CAUTION: When you change the memory partition, you will erase all your stored XM content

and MP3/WMA tracks from your inno.

setting

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 76

Settings

Restoring Factory Defaults

To restore all inno settings and preferences to a “factory fresh” state:

1. Select XM➝Settings➝Setup➝Factory Defaults.

2. You should see this display:

3. Confirm by selecting Yes, or cancel by selecting No.

Restore just the settings to factory defaults.

Restore settings to factory defaults and erase all music.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 78

Troubleshooting

If this happens: You should:

There is no power or your inno shuts Your inno battery may be low.Charge the battery by putting your off quickly. inno in the dock station and plugging in the AC adapter.

inno shuts off unexpectedly. Check whether you set the sleep timer, and set it to “Off” if desired.

Check whether “Vehicle Mode/Delayed Power Off” is set, and set it to “Off” if desired. inno remembers the “Vehicle Mode” setting even when you turn the device off.

You do not receive all the XM channels you Check that you have not skipped any channels (page 74).If you still do have subscribed to. not receive all channels, your inno may not be activated. Contact XM

Satellite Radio.

No audio. Check all connections between your inno and your stereo system.

No song title or artist name is displayed. Nothing is wrong with your inno. That information may be in the

process of being updated. Some channels, such as news and sports, may not have such information.

No audio when listening to inno through Check that your inno and your radio are tuned to the same FM an FM radio. frequency.

Audio fades or has static when listening You might be hearing interference from another FM station. Set your through an FM radio. inno and your radio to a different FM frequency.

Audio sounds too soft or is distorted when Raise or lower the FM audio level until the sound quality improves. listening to an FM radio.

XM Instant Traffic and Weather channels Nothing is wrong with your inno.These channels use a different sound different from other channels. audio technology than the other XM channels.

Controls do not respond. Check whether the power switch is in the "hold" position.

If so, slide it to the center position to unlock the controls.

The controls still refuse to respond, the display Reset your inno by removing and re-inserting the battery. does not change, or the backlight does not turn on or off.

Battery level meter does not match the Fully charge the battery, then use your inno until the battery is expected charge or playback time. exhausted. This calibrates the battery level meter.

Customer Support

Troubleshooting

If your inno does not work the way you expect, first consult this troubleshooting guide. To reset your inno, remove the battery then re-insert it.

If you see this on the display: You should:

No Signal Something is blocking the XM signal. Move your inno away

from the obstructed area (e.g., an underground garage).

Antenna Plug the antenna into the home or car dock.

Make sure the antenna wire is not bent or broken.

Off Air The channel you’ve selected is not currently broadcasting.

Tune to another channel.

Loading Your inno is acquiring audio or program information from the XM

signal. This message should disappear in a few seconds in good signal conditions.

Updating XM is updating your inno with the latest encryption code. Simply wait

a few seconds until the update is done. – OR – You may be attempting to tune to a channel that is blocked or that you cannot receive with your subscription package.To receive that channel, contact XM Satellite Radio at 1-800-967-2346.

--- (no artist or title) No program information, such as artist name or song title, e x i s t s.

Channel You are attempting to tune to a channel that is not available.

All Recording Features Not Available Activate your XM subscription to enable you to store XM

programming on your inno.

This Channel Not Available for Recording Some programming cannot be recorded due to restrictions placed by

the content owners.

This Program Not Available for Recording Some programming cannot be recorded due to restrictions placed by

the content owners.

Connect to XM Antenna Within 30 Days You must receive a live XM signal for at least 8 hours a m o n t h . This to Avoid Interruption in Listening to authenticate s your XM subscription and ensures t hat you can XM Recordings continue to enjoy your recorded XM content and live XM programming.

Please Connect to XM Antenna to Select “Live XM” and make sure you get a strong signal. Confirm Valid Subscription

Activation Required for Playback Activate your XM subscription.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 80

Troubleshooting

If this happens: You should:

inno does not communicate with your PC. Check the power and USB connections between the dock and your PC.

Be sure to use the supplied USB cable; any others may prevent your inno from charging or communicating properly with your PC. Remove your inno from its dock station, then re-insert.

Artist and song title information does not inno may not correctly show the artist and song information display correctly. (ID3 tags) of certain foreign songs.

You cannot transfer songs that you inno is not compatible with Napster To Go’s monthly subscription downloaded with Napster To Go™ into inno. service.To transfer songs from your PC to your inno, you must

purchase individual songs or albums from XM+Napster Light or XM+Napster.

Customer Support

Specifications

inno Player

Dimensions 56 mm (W) x 94 mm (H) x 16 mm (D)

2.2 in (W) x 3.7 in (H) x 0.6 in (D)

Weight 128 g

4.5 oz

Storage capacity 1 GB (The capacity of the built-in memory may be less than

indicated; a portion of the memory is used by the inno firmware.)

Music file formats MP3 and WMA fixed bitrates:

32, 48, 64, 96, 128, 160, 192, 256, 320 kbps

MP3 and WMA variable bitrates: 64-128, 128-256, 160-320 kbps

Audio output 3.5 mm mini-stereo jack

Antenna connector (home and car dock) RF SMB

Battery Type: lithium ion

Voltage: 3.7 V Capacity: 1750 mAh

External power Voltage: 5 V DC

Current: 2000 mA Polarity:

PostScript Picture

(polarity.eps)

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 82

Customer Support

Specifications

Remote

Dimensions 39 mm (W) x 95 mm (H) x 12 mm (D)

1.5 in (W) x 3.7 in (H) x 0.47 in (D)

Weight 40 g

1.4 oz

Battery Type: CR2032

Voltage: 3 V

Model Numbers

inno player GEX-INNO1

Home kit CD-INHOME1

Car accessory kit CD-INCAR1

Patent Information

Technology. It is prohibited to copy, decompile, disassemble, reverse engineer, hack, manipulate, or otherwise make available any technology incorporated in receivers compatible with the XM Satellite Radio System or that support the XM website, the Online Service or any of its content. Furthermore, the AMBE®voice compression software included in this product is protected by intellectual property rights including patent rights, copyrights, and trade secrets of Digital Voice Systems, Inc. You also agree not to upload, post, transmit or otherwise make available any material that contains software viruses or any other computer code, files,or programs designed to interrupt, disable, or limit the functionality of the XM website or the Online Service. Furthermore, the music, talk, news, entertainment, data, and other content on the Services are protected by copyright and other intellectual property laws and all ownership rights remain with the respective content and data service providers.You are prohibited from any export of the data (or derivative thereof) except in compliance with applicable export laws, rules, and regulations. The user of this or any other software contained in an XM Radio or the XM website and all software used in connection with either is explicitly prohibited from attempting to copy, decompile,reverse engineer, or disassemble the object code, or in any other way convert the object code into human-readable form.The software is licensed solely for use within this product.

The product unit accompanying this user guide is licensed under certain intellectual property rights of certain third parties. In particular, this product is licensed under the following U.S. patents: 5,991,715, 5,740,317, 4,972,484, 5,214,678, 5,323,396, 5,539,829, 5,606,618, 5,530,655, 5,777,992, 6,289,308, 5,610,985, 5,481,643, 5,544,247, 5,960,037, 6,023,490, 5,878,080, and under U.S. Published Patent Application No. 2001-44713-A1.

This license is limited to private non-commercial use by end-user consumers for licensed contents. No rights are granted for commercial use. The license does not cover any product unit other than this product unit and the license does not extend to any unlicensed product unit or process conforming to ISO/IEC 11172-3 or ISO/IEC 13818-3 used or sold in combination with this product unit. The license only covers the use of this product unit to encode and/or decode audio files conforming to the ISO/IEC 11172-3 or ISO/IEC 13818-3. No rights are granted under this license for product features or functions that do not conform to the ISO/IEC 11172-3 or ISO/IEC 13818-3.

Customer Support

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 84

LIMITED WARRANTY

WARRANTY VALID ONLY IN COUNTRY OF PRODUCT PURCHASE

WARRANTY

Pioneer Electronics (USA) Inc. (PUSA), and Pioneer Electronics of Canada, Inc. (POC), warrants that products distributed by PUSA in the U.S.A., and by POC in Canada that fail to function properly under normal use due to a manufacturing defect when installed and operated according to the owner’s manual enclosed with the unit will be repaired or replaced with a unit of comparable value, at the option of PUSA or POC, without charge to you for parts or actual repair work. Parts supplied under this warranty may be new or rebuilt at the option of PUSA or POC.

THIS LIMITED WARRANTY APPLIES TO THE ORIGINAL OR ANY SUBSEQUENT OWNER OF THIS PIONEER PRODUCT DURING THE WARRANTY PERIOD PROVIDED THE PRODUCT WAS PURCHASED FROM AN AUTHORIZED PIONEER DISTRIBUTOR/DEALER IN THE U.S.A. OR CANADA. YOU WILL BE REQUIRED TO PROVIDE A SALES RECEIPT OR OTHER VALID PROOF OF PURCHASE SHOWING THE DATE OF ORIGINAL PURCHASE OR, IF RENTED, YOUR RENTAL CONTRACT SHOWING THE PLACE AND DATE OF FIRST RENTAL. IN THE EVENT SERVICE IS REQUIRED, THE PRODUCT MUST BE DELIVERED WITHIN THE WARRANTY PERIOD, TRANSPORTATION PREPAID, ONLY FROM WITHIN THE COUNTRY OF PURCHASE AS EXPLAINED IN THIS DOCUMENT. YOU WILL BE RESPONSIBLE FOR REMOVAL AND INSTALLATION OF THE PRODUCT. PUSA OR POC, AS APPROPRIATE,WILL PAY TO RETURN THE REPAIRED OR REPLACEMENT PRODUCT TO YOU WITHIN THE COUNTRY OF PURCHASE.

(warranty continues next page)

Customer Support

FCC Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may cause undesired operation.

C A U T I O N : Any changes or modifications in construction of this device which are not expressly

approved by the party responsible for compliance could void the user’s authority to operate the e q u i p m e n t .

N O T E : This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment g e n e r a t e s, u s e s , and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. H o w e v e r, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

■

Reorient or relocate the receiving antenna.

■

Increase the separation between the equipment and receiver.

■

Connect the equipment to an outlet on a circuit different from that to which the receiver

is connected.

■

Consult the dealer or an experienced radio/TV technician for help.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 86

Customer Support

NO OTHER WARRANTIES

IN THE U.S.A. - PIONEER LIMITS ITS OBLIGATIONS UNDER ANY IMPLIED WARRANTIES INCLUDING, BUT NOT LIMITED TO,THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,TO A PERIOD NOT TO EXCEED THE WARRANTY PERIOD. NO WARRANTIES SHALL APPLY AFTER THE WARRANTY PERIOD. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS AND SOME STATES DO NOT ALLOW THE EXCLUSIONS OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE.

IN CANADA – EXCEPT AS EXPRESSLY PROVIDED HEREIN, THERE ARE NO REPRESENTATIONS, WARRANTIES, OBLIGATIONS OR CONDITIONS, IMPLIED, STATUTORY OR OTHERWISE,APPLICABLE TO THIS PRODUCT.

TO OBTAIN SERVICE

PUSA has appointed a number of Authorized Service Companies throughout the U.S.A. should your product require service. To receive warranty service you need to present your sales receipt showing place and date of original owner’s transaction. If shipping the unit you will need to package it carefully and send it, transportation prepaid by a traceable, insured method, to an Authorized Service Company. Package the product using adequate padding material to prevent damage in transit. Include your name, address and telephone number where you can be reached during business hours.

PRODUCT WARRANTY PERIOD Portable Satellite Radio……………………………...… 1 Year Parts & Labor Portable Satellite Radio Battery……………………… 90 Days Parts & Labor

The warranty period for retail customers who rent the product commences upon the date product is first put into use (a) during the rental period or (b) retail sale, whichever occurs first.

WHAT IS NOT COVERED

IF THIS PRODUCT WAS PURCHASED FROM AN UNAUTHORIZED DISTRIBUTOR, THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY AND THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND THIS PRODUCT IS SOLD STRICTLY “AS IS” AND “WITH ALL FAULTS”. PIONEER SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL AND/OR INCIDENTAL DAMAGES. PIONEER DOES NOT WARRANT ANY PRODUCT LISTED ABOVE WHEN IT IS USED IN A TRADE OR BUSINESS OR IN ANY INDUSTRIAL OR COMMERCIAL APPLICATION. THIS WARRANTY DOES NOT APPLY IF THE PRODUCT HAS BEEN SUBJECTED TO POWER IN EXCESS OF ITS PUBLISHED POWER RATING. THIS WARRANTY DOES NOT COVER THE CABINET OR ANY APPEARANCE ITEM, USER ATTACHED ANTENNA,ANY DAMAGE TO THE PRODUCT RESULTING FROM ALTERATIONS, MODIFICATIONS NOT AUTHORIZED IN WRITING BY PIONEER,ACCIDENT, MISUSE OR ABUSE, DAMAGE DUE TO LIGHTNING OR TO POWER SURGES, SUBSEQUENT DAMAGE FROM LEAKING, DAMAGE FROM INOPERATIVE BATTERIES, OR THE USE OF BATTERIES NOT CONFORMING TOTHOSE SPECIFIED IN THE OWNER’S MANUAL. THIS WARRANTY DOES NOT COVER THE COST OF PARTS OR LABOR WHICH WOULD BE OTHERWISE PROVIDED WITHOUT CHARGE UNDER THIS WARRANTY OBTAINED FROM ANY SOURCE OTHER THAN A PIONEER AUTHORIZED SERVICE COMPANY OR OTHER DESIGNATED LOCATION.THIS WARRANTY DOES NOT COVER DEFECTS OR DAMAGE CAUSED BY THE USE OF UNAUTHORIZED PARTS OR LABOR FROM IMPROPER MAINTENANCE. ALTERED, DEFACED, OR REMOVED SERIAL NUMBERS VOID THIS ENTIRE WARRANTY.

(warranty continues next page)

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 88

Customer Support

On all complaints and concerns call Customer Support at 1-800-421-1404

DISPUTE RESOLUTION

Following our response to any initial request to Customer Support, should a dispute arise between you and Pioneer, Pioneer makes available to you, without charge,it’s Complaint Resolution Program. You are required to use the Complaint Resolution Program before you exercise any rights under, or seek any remedies, created by Title I of the Magnuson-Moss Warranty-Federal Trade Commission Improvement Act, 15 U.S.C. 2301 et seq.

To use the Complaint Resolution Program call 1-800-421-1404 and explain to the customer service representative the problem you are experiencing, steps you have taken to have the product repaired during the warranty period and the name of the authorized Distributor / Dealer from whom the Pioneer product was purchased. After the complaint has been explained to the representative, a resolution number will be issued. Within 40 days of receiving your complaint, Pioneer will investigate the dispute and will either: (1) respond to your complaint in writing informing you what action Pioneer will take, and in what time period, to resolve the dispute; or (2) respond to your complaint in writing informing you why it will not take any action.

For hook-up and operation of your unit or to locate an Authorized Service Company, please call or write:

PIONEER ELECTRONICS SERVICE, INC. P.O. BOX 1760 LONG BEACH, CALIFORNIA 90810 1-800-421-1404 http://www.pioneerelectronics.com

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 90

PIONEER ELECTRONICS SERVICE, INC. P.O. BOX 1760 LONG BEACH, CALIFORNIA 90810 1-800-421-1404 http://www.pioneerelectronics.com

XM respects copyrights. This device is for personal use only. XM Programming stored on the device cannot be transferred off the unit. Download legally. Buy digital music from XM+Napster.

enginno_usergd.r2a.qxd 5/17/06 6:32 PM Page 92

Pioneer Inno2BK GEX-INN02B, Inno User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
