PIONEER DEH-P7000R, 6000R Service Manual
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER ELECTRONIC CORPORATION 1999
K-ZZB. APR. 1999 Printed in Japan
ORDER NO.
CRT2337
MULTI-CD/MD/DAB CONTROL HIGH POWER CD PLAYER WITH RDS TUNER
DEH-P7000R X1B/EW
- This additional service manual is designed to be used together with Model DEH-P7000R/EW and DEHÂP6000R/EW Service Manual CRT2375. Refer to it for finding parts numbers and adjustment,etc. which
are not shown in this manual.
DEH-P6000R X1B/EW
EXPLODED VIEWS AND PARTS LIST
PACKING (Page 3)
- PACKING SECTION PARTS LIST *: Non Spare Part
Part No.
Mark No. Description DEH-P7000R/EW DEH-P7000R/X1B/EW
* 2 Accessory Assy CEA2397 UEA2397
* 6 Polyethylene Bag E36-615 Not used
7 Polyethylene Bag CEG-162 UEG-012
8-1 Owner's Manual CRD2910 URD2910
8-2 Owner's Manual CRD2911 URD2911
8-3 Owner's Manual CRD2912 URD2912
8-4 Installation Manual CRD2913 URD2913
* 8-5 Passport CRY1013 CRY1014
8-6 Warranty Card CRY1087 URY1087
8-7 Polyethylene Bag CEG1116 UEG1116
9 Case Assy CXB3520 UXB3520
10 Carton CHG3750 UHG3750
11 Contain Box CHL3750 UHL3750
12 Protector CHP2101 UHP2101
13 Protector CHP2102 UHP2102
14 Inner Box CHW1754 UHW1754
Caution Card CRP1208 URP1208
2
DEH-P7000R,P6000R
EXTERIOR (Page 6)
- EXTERIOR SECTION PARTS LIST
Part No.
Mark No. Description DEH-P7000R/EW DEH-P7000R/X1B/EW
13 Holder CNC6798 UNC6798
20 Tuner Amp Unit CWM6190 UWM6190
25 Pin Jack(CN431) CKB1028 CKB1035
50 FM/AM Tuner Unit CWE1500 UWE1500
80 Detach Grille Assy CXB3686 UXB3686
93 Keyboard Unit CWM6198 UWM6198
- PACKING SECTION PARTS LIST *: Non Spare Part
Part No.
Mark No. Description DEH-P6000R/EW DEH-P6000R/X1B/EW
* 2 Accessory Assy CEA2397 UEA2397
* 6 Polyethylene Bag E36-615 CEG-127
7 Polyethylene Bag CEG-162 UEG-012
8-1 Owner's Manual CRD2918 URD2918
8-2 Owner's Manual CRD2919 URD2919
8-3 Owner's Manual CRD2920 URD2920
8-4 Installation Manual CRD2921 URD2921
* 8-5 Passport CRY1013 CRY1014
8-6 Warranty Card CRY1087 URY1087
8-7 Polyethylene Bag CEG1116 UEG1116
9 Case Assy CXB3520 UXB3520
10 Carton CHG3753 UHG3753
11 Contain Box CHL3753 UHL3753
12 Protector CHP2101 UHP2101
13 Protector CHP2102 UHP2102
14 Inner Box CHW1754 UHW1754
Caution Card CRP1208 URP1208
Part No.
Mark No. Description DEH-P6000R/EW DEH-P6000R/X1B/EW
13 Holder CNC6798 UNC6798
20 Tuner Amp Unit CWM6194 UWM6194
25 Pin Jack(CN431) CKB1028 CKB1035
50 FM/AM Tuner Unit CWE1500 UWE1500
80 Detach Grille Assy CXB3690 UXB3690
93 Keyboard Unit CWM6198 UWM6198
