Headphones
4000 Series
TAE4205
User manual
Register your product and get support at
www.philips.com/support
Contents
1 Important safety instructions 2
Hearing Safety 2
General information 2
2 Your Bluetooth in-ear
headphones 3
What's in the box 3
Other devices 3
Overview of your Bluetooth
wireless headphone 4
3 Get started 5
Charge the battery 5
Pair the headphones with your
mobile phone 5
4 Use your headphones 6
Connect the headphones to a
Bluetooth device 6
Manage your calls and music 6
5 Technical data 8
6 Notice 9
Declaration of conformity 9
Disposal of your old product
and battery 9
Remove the integrated battery 9
Compliance with EMF 9
Environmental information 10
Notice of compliance 10
7 Trademarks 11
8 Frequently asked questions 12
1 Important
General information
safety
instructions
Hearing Safety
Danger
To avoid hearing damage, limit the time you
use headphones at high volume and set the
volume to a safe level. The louder the
volume, the shorter the safe listening time is.
Be sure to observe the following guidelines when using your headphone.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume
continuously upwards as your
hearing adapts.
• Do not turn up the volume so high
that you can't hear what's around
you.
• You should use caution or temporarily discontinue use in potentially
hazardous situations.
• Excessive sound pressure from
earphones and headphones can
cause hearing loss.
• Using headphones with both ears
covered while driving is not recommended and may be illegal in some
areas while driving.
• For your safety, avoid distractions
from music or phone calls while in
trac or other potentially dangerous
environments.
To avoid damage or malfunction:
Caution
Do not expose headphones to excessive heat
Do not drop your headphones.
Headphones shall not be exposed to dripping
or splashing.
Do not allow your headphones to be
submerged in water.
Do not use any cleaning agents containing
alcohol, ammonia, benzene, or abrasives.
If cleaning is required use a soft doth, if
necessary dampened with a minimum amount
of water or diluted mild soap, to clean the
product.
The integrated battery shall not be exposed to
excessive heat such as sunshine, re or the
like.
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
About operating and storage
temperatures and humidity
• Operate or store in a place where
temperature is between -20°C (4°F)
and 60°C (140 °F) (up to 90%
relative humidity.
• Battery life may be shorter in high
or low temperature conditions.
2 Your
Bluetooth
in-ear
headphones
Congratulations on your purchase, and
welcome to Philips! To fully benet
from the support that Philips oers,
register your product at
www.philips.com/welcome.
With this Philips in-ear headphones,
you can:
• enjoy convenient wireless
handsfree calls;
• enjoy and control wireless music;
• switch between calls and music.
What's in the box
USB-C charging cable (for charging only)
Quick start guide
Global Warranty
Philips Bluetooth in-ear headphones
Philips TAE4205
Replaceable rubber ear caps x 2 pairs
Safety leaet
Other devices
A mobile phone or device (e.g. notebook, PDA, Bluetooth adapters, MP3
players etc) which supports Bluetooth
and is compatible to the headphone
(see 'Technical data' on page 8).
Overview of your
Bluetooth wireless
headphone
6
LED indicator
Next / Volume up
Charging slot
(Power On / O / Pairing)
BASS+ button
Previous/Volume down
3 Get started
Charge the battery
Note
Before you use your headphone for the rst
time, place the headphones in the charging
case and charge the battery for 2 hours for
optimum battery capacity and lifetime.
Use only the original USB charging cable to
avoid any damage.
Finish your call before charging the
headphone, as connecting the headphone for
charging will power the headphone o.
Connect the supplied USB charging
cable to the charging slot on the
headphones and the charger/USB port
of a computer.
LED turns white during charging and
turns o when the headphones is fully
charged.
Make sure that the headphones are
fully charged and turned o.
Press and hold the on/o
button(>6s), blue and whites LED
ashes alternately which means the
headphones enter Bluetooth pairing
mode. The headphones remain in
pairing mode for 5 minutes.
Make sure that the mobile phone is
turned on and its Bluetooth feature
is activated.
Pair the headphones with the
mobile phone. For detailed information, refer to the user manual of
your mobile phone.
Tip
Enter the headset password "0000" (4 zeros) if
prompted. For those mobile phones featuring
Bluetooth 3.0 or higher, no need to enter a
password
Download Philips
Headphones app
Tip
Normally, a full charge takes 2 hours.
Pair the headphones
with your mobile phone
Before you use the headphones with
your mobile phone for the rst time, pair
it with a mobile phone. A successful
pairing establishes a unique encrypted
link between the headphones and
mobile phone. The headphones store
the last 4 devices in the memory. If you
try to pair more than 4 devices, the
earliest paired device is replaced by the
new one.
Download and install the Philips Headphones app from Google Play store or
App Store on your mobile phone.
When your headset is connected to the
mobile phone, you can launch the
Philips Headphones app and use
features listed as below:
Adjust volume
Adjust equalizer
Check the status of remaining battery
Headset software update
4 Use your
headphone
Connect the headphone
to your Bluetooth device
Turn on your mobile phone/
Bluetooth device.
Press and hold the on/o button
(>2s) to turn the headphones on.
The headphones are reconnected to the last connected
device automatically. If the last
one is not available, the
headphones try to reconnect to
the second last connected
device.
Tip
If you turn on the mobile phone or activate
the Bluetooth feature after turning on the
headphones, you have to reconnect the
headphones and mobile phone manually.
If the headphones fail to connect to any
Bluetooth device within range in 5 minutes,
it will switch o automatically to save the
battery life.
Manage your calls and
music
On/o
Task
Power on
Power o
Music control
Task
Play or
pause music.
Adjust volume
Next track
Previous track
Bass boost Bass
Call control
Task
Pick up/
hang up a
call.
Reject a
call
Button
On/o,
music/call
control
On/o,
music/call
control
Button
On/o,
music/call
control
button
Button
On/o,
music/
call control
On/o,
music/
call control
Operation
Press and
hold (>2s)
Press and
hold (>4s)
Operation
Press once.
Press once.
Long press.
Long press.
Press once.
Operation
Press once.
Press and
hold (>2s)
Triger voice assistant (Android/iOS)
Task
Triger
voice
assistant
Factory Reset
Task
Factory
reset
Button
On/o,
music/call
control
Button
Volume +
and -
Operation
Press twice
Operation
Press and hold
together (>4s)
Summary of LED indicator
Headphones status
The headphones
are connected to
a mobile phone.
The headphones
are disconnected
to a mobile phone
The headphones
are ready for
pairing.
Low battery level. White LED
Charging
Indicator
The blue LED
ashes for
every 5
seconds.
The blue LED
ashes for
every 10 seconds.
The LED ashes
blue and white
alternatively.
double ashes
Trigger once in
60 seconds.
The white LED
turns on until
battery is fully
charged.
5 Technical data
Music time: 10 hours
Talk time: 8 hours
Standby time: 60 hours
Normal time for a full charge: 2 hours
Battery: Rechargeable lithium polymer
battery (100 mAh)
Bluetooth version: 5.0
Compatible Bluetooth proles:
Bluetooth prole: HSP, HFP, A2DP, AVRCP
Operating range: Up to 10 meters (33 feet)
Speaker driver: 8.6mm
Transmitter power: < 10 dBm
Frequency response: 20 – 20kHz
DImpedance: 16 ohm
Sensitivity: 108.5db/1mW/1000Hz
Distortion: <3%@1kHz THD
Maximum power input: 5mW
USB-C port for charging
Low battery warning: available
Note
Specications are subject to change without
notice.
6 Notice
Declaration of conformity
Hereby, MMD Hong Kong Holding Limited
declares that this product is in compliance with the essential requirements and
other relevant provisions of Directive
2014/53/EU. You can nd the Declaration
of Conformity on www.p4c.philips.com.
Disposal of your old
product and battery
Your product is designed and manufactured with high quality materials and
components, which can be recycled and
reused.
This symbol on a product means that
the product is covered by European
Directive 2012/19/EU.
This symbol means that the product
contains a built-in rechargeable battery
covered by European Directive
2013/56/EU which cannot be disposed
of with normal household waste. We
strongly advise you to take your product
to an ocial collection point or a Philips
service centre to have a professional
remove the rechargeable battery.
Inform yourself about the local separate
collection system for electrical and
electronic products and rechargeable
batteries. Follow local rules and never
dispose of the product and rechargeable
batteries with normal household waste.
Correct disposal of old products and
rechargeable batteries helps prevent
negative consequences for the environment and human health.
Remove the integrated battery
If there is no collection/recycling system
for electronic products in your country,
you can protect the environment by
removing and recycling the battery
before disposing the headphones.
• Make sure the headphone is
disconnected from the charging
case before removing the battery.
Compliance with EMF
This product complies with all applicable standards and regulations regarding
exposure to electromagnetic elds.
Environmental information
All unnecessary packaging has been
omitted. We have tried to make the
packaging easy to separate into three
materials: cardboard (box), polystyrene
foam (buer) and polyethylene (bags,
protective foam sheet.)
Your system consists of materials which
can be recycled and reused if disassembled by a specialized company. Please
observe the local regulations regarding
the disposal of packaging materials,
exhausted batteries and old equipment.
Notice of compliance
The device complies with the FCC rules,
Part 15. Operation is subject to the
following two conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any
interference received, including
interference that may cause
undesired operation.
FCC rules
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to part
15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio
frequency energy and, if not installed
and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio or
television reception, which can be
determined by turning the equipment o
and on, the user is encouraged to try to
correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between
equipment and receiver
Connect the equipment into an outlet
on a circuit dierent from that to which
the receiver is connected.
Consult the dealer or an experienced
radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC
radiation exposure limits set forth for an
uncontrolled environment.
This transmitter must not be co-located
or operating in conjunction with any
other antenna or transmitter.
Caution:
changes or modications not expressly
approved by the party responsible for
compliance could void the user's
authority to operate the equipment.
Canada:
This device contains licence-exempt
transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic
Development Canada’s licence- exempt
RSS(s). Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation of
the device.
CAN ICES-3(B)/NMB-3(B)
IC Radiation Exposure Statement:
This equipment complies with Canada
radiation exposure limits set forth for
uncontrolled environments.
This transmitter must not be co-located
or operating in conjunction with any
other antenna or transmitter.
The user is cautioned that
7 Trademarks
Bluetooth
The Bluetooth® word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by MMD Hong Kong Holding
Limited is under license. Other trademarks and trade names are those of
their respective owners.
Siri
Siri is a trademark of Apple Inc., registered in the U.S. and other countries.
8 Frequently
asked
questions
My Bluetooth headphone does not turn
on.
The battery level is low. Charge the
headphone.
I cannot pair my Bluetooth headphones
with my Bluetooth device.
The Bluetooth is disabled. Enable the
Bluetooth feature on your Bluetooth
device and turn on the Bluetooth device
before you turn on the headphone.
The audio quality is poor and crackling
noise can be heard.
• The Bluetooth device is out of range.
Reduce the distance between your
headset and Bluetooth device, or
remove obstacles between them.
• Charge your headset.
How to reset the headset
• Power on the headset.
• Press and hold vol+ and vol- button
together for more than 4 second.
For further support, visit www.philips.com/support.
Philips and the Philips Shield Emblem are registered trademarks of
Koninklijke Philips N.V. and are used under license. This product has been
manufactured by and is sold under the responsibility of MMD Hong Kong
Holding Limited or one of its aliates, and MMD Hong Kong Holding
Limited is the warrantor in relation to this product.
UM_TAE4205_00_EN_V1.0
Loading...
