Philips SA4025-02 User Manual

Philips
Flash audio player

2GB*

SA4025

Wear it and flaunt it

Enjoy your MP3 and WMA music on the go with the Philips SA40XX. Transfer music and
data quickly and easily via USB2.0. PlayForSure* ensures it works with Windows XP PC.
Listen to music all day long on an AAA battery

Ready to wear, Ready to go

• Enjoy up to 10 hours of music playback*

• Small and wearable for ultimate portability

• Plug and play data

Easy, intuitive music experience

• Backlight LCD display with 7 color choices

• Equalizer for optimized sound to suit your music style

Your music, your data - on the go, everyday

• MP3 and WMA playback

• Voice recording to take notes or record anything, anytime

• FM radio headphone for use with any portable audio player

• Fast downloads from your PC via USB 2.0*

• Supports downloaded music

Flash audio player

2GB*

SA4025/02

Specifications

Picture/Display

• Backlight: Yes, 7 color backlight

•Lines of text: 2

• Resolution: 32 x 128

•Type: LCD

Sound

• Channel separation: 45 dB

• Equalizer settings: Clas

• Frequency response: 30 - 18 000 Hz Hz

• Output power (RMS): 2 x 3 mW

• Signal to noise ratio: > 85 dB

Audio Playback

• Compression format: MP3, WAV, Windows
Media™ Audio

• ID3 Tag support: Track title and artist name

• MP3 bit rates: 8-320 kbps and VBR

• MP3 sample rates: 8, 11.025, 16, 22.050, 24, 32,

.1, 48 kHz

44

• WMA bit rates: 5-192 kbps

• WMA sample rates: 8, 11.025, 16, 22.050, 32, 44.1,

kHz

48

•DRM: Version 10

Audio Capturing

• Audio file format: WAV

• Built-in microphone: mono

• Voice recording: ADPCM

sic, Jazz, Pop, Rock

Connectivity

• Headphone: 3.5 mm

•USB: High-speed USB 2.0

Convenience

• Firmware upgradeable

• Function: Keypad lock

Accessories

• Batteries: AAA Alkaline

• Headphones: AY3810 FM radio headphones

• USB cable: USB extension cable

• User Guide on CD-ROM

Software

• Device manager: Device Manager to restore and
upgrade

• Windows Media Player 10

Green Specifications

• Lead-free soldered product

System Requirements

•CD-ROM drive

• Internet connection: Yes (for access to updated

upport documents, manuals, future firmware and

s
PC software upgrades)

• PC OS: Windows XP (SP2 or above)

• USB: Free USB port

Highlights

MP3 and WMA playback

Audio compression technology allows large digital
music files to be reduced up to 10 times in size
without radically degrading their audio quality. MP3
or WMA are two of the compression formats that
let you enjoy a world of digital music on your
GoGear player. Download MP3 or WMA songs
from authorized music sites on the Internet or
create your own MP3 or WMA music files by ripping
your audio CDs and transferring them onto your
player.

Voice recording

Storage Media

• Built-in memory capacity: 2 GB

• Built-in memory type: NAND Flash

• Mass storage class compliant

• Music memory capacity, WMA: Up to 920 tracks *

Tuner/Reception/Transmission

• Tuner Bands: FM

Dimensions

• Blister dimensions (WxDxH): 135 x 38 x 195 mm

• Packaging type: Clamshell

• Product dimensions (WxDxH
mm

): 31.5 X 23 X 77.8

Power

•Batteries included

• Battery type: AAA / LR03 Alkaline

• Playtime on external batt

•

ery: Up to 10 hours

Voice recording converts your GoGear player into a
handy dictation machine. Besides playing music or
listening to radio, you can also record notes or
reminders for work or school, record shopping lists
and phone numbers – even song lyrics. By pressing
the recording button and speaking into the built-in
microphone, voice messages are compressed and
stored in the built-in internal memory. Voice
recording gives you a highly portable voice recorder
allowing you to record anything, anytime and
anywhere!

LCD display with color choices

Backlight LCD display with 7 color choices

FM radio headphones

Enjoy the convenience of listening to your favorite
FM radio stations anytime, without having to carry
your portable audio player with FM tuner. This
combination of tuner functionality into the
headphones allow you to enjoy FM music. Or you
can switch off the radio, and simply plug them into
your portable audio player to enjoy your own music.
Savor up to 15 hours of non-stop FM music, thanks
to its replaceable button battery.

Issue date 2009-03-27

Version: 1.2.5

12 NC: 8670 000 29183
EAN: 87 12581 33021 7

© 2009 Koninklijke Philips Electronics N.V.
All Rights reserved.

Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.

www.philips.com

* 1MB = 1 million bytes; available storage capacity will be less.
* Actual transfer speed may vary based on your operating system and

software configuration.

* Storage capacity based on 4 minutes per song and 64 kbps WMA

encoding.

* Supports download and subscription services compatible with WMA

DRM10
