Philips P89LPC924, P89LPC925 Technical data

Download

UM10108

P89LPC924/925 User manual

Rev. 02 — 2 March 2005 User manual

Document information

Info Content

Keywords P89LPC924, P89LPC925

Abstract Technical information for the P89LPC924 and P89LPC925 devices.

Philips Semiconductors

Revision history

Rev Date Description

02 20050302 Updated to include 18 MHz information.

01 20040628 Initial version (9397 750 13338).

UM10108

P89LPC924/925 User manual

Contact information

For additional information, please visit: http://www.semiconductors.philips.com

For sales office addresses, please send an email to: sales.addresses@www.semiconductors.philips.com

User manual Rev. 02 — 2 March 2005 2 of 105

Philips Semiconductors

1. Introduction

The P89LPC924/925 are single-chip microcontrollers designed for applications demanding high-integration, low cost solutions over a wide range of performance requirements. The architecture that executes instructions in two to four clocks, six times the rate of standard 80C51 devices. Many system-level functions have been incorporated into the P89LPC924/925 in order to reduce component count, board space, and system cost.

1.1 Pin Configuration

UM10108

P89LPC924/925 User manual

P89LPC924/925 is based on a high performance processor

handbook, halfpage

KBI0/CMP2/P0.0

P1.7

P1.6

RST/P1.5

XTAL1/P3.1

CLKOUT/XTAL2/P3.0

INT1/P1.4

SDA/INT0/P1.3

SCL/T0/P1.2

P89LPC924FDH

P89LPC925FDH

002aaa787

P0.1/CIN2B/KBI1/AD10

P0.2/CIN2A/KBI2/AD11

P0.3/CIN1B/KBI3/AD12

P0.4/CIN1A/KBI4/AD13/DAC1

P0.5/CMPREF/KBI5

P0.6/CMP1/KBI6

P0.7/T1/KBI7

P1.0/TXD

P1.1/RXD

Fig 1. TSSOP20 pin configuration.

User manual Rev. 02 — 2 March 2005 3 of 105

Philips Semiconductors

P89LPC924/925 User manual

Table 1: Pin description

Symbol Pin Typ e Description

P0.0 to P0.7 I/O Port 0: Port 0 is an 8-bit I/O port with a user-configurable output type. During reset

Por t 0 latches are configured in the input only mode with the internal pull-up disabled. The operation of Port selected. Each port pin is configured independently. Refer to Section 5.1 “Port

configurations” for details.

The Keypad Interrupt feature operates with Port 0 pins.

All pins have Schmitt triggered inputs.

Por t 0 also provides various special functions as described below:

1 I/O P0.0 — Por t 0 bit 0.

O CMP2 — Comparator 2 output.

I KBI0 — Keyboard input 0.

20 I/O P0.1 — Port 0 bit 1.

I CIN2B — Comparator 2 positive input B.

I KBI1 — Keyboard input 1.

I AD10 — ADC1 channel 0 analog input.

19 I/O P0.2 — Port 0 bit 2.

I CIN2A — Comparator 2 positive input A.

I KBI2 — Keyboard input 2.

I AD11 — ADC1 channel 1analog input.

18 I/O P0.3 — Port 0 bit 3.

I CIN1B — Comparator 1 positive input B.

I KBI3 — Keyboard input 3.

I AD12 — ADC1 channel 2 analog input.

17 I/O P0.4 — Port 0 bit 4.

I CIN1A — Comparator 1 positive input A.

I KBI4 — Keyboard input 4.

I AD13 — ADC1 channel 3 analog input.

I DAC1 — Digital-to-analog converter output 1.

16 I/O P0.5 — Port 0 bit 5.

I CMPREF — Comparator reference (negative) input.

I KBI5 — Keyboard input 5.

14 I/O P0.6 — Port 0 bit 6.

O CMP1 — Comparator 1 output.

I KBI6 — Keyboard input 6.

13 I/O P0.7 — Port 0 bit 7.

I/O T1 — Timer/counter 1 external count input or overflow output.

I KBI7 — Keyboard input 7.

0 pins as inputs and outputs depends upon the port configuration

UM10108

User manual Rev. 02 — 2 March 2005 4 of 105

Philips Semiconductors

Table 1: Pin description

Symbol Pin Typ e Description

P1.0 to P1.7 I/O, I

12 I/O P1.0 — Port 1 bit 0.

11 I/O P1.1 — Port 1 bit 1.

10 I/O P1.2 — Port 1 bit 2 (open-drain when used as output).

9 I/O P1.3 — Por t 1 bit 3 (open-drain when used as output).

8 I/O P1.4 — Por t 1 bit 4.

4 I P1.5 — Por t 1 bit 5 (input only).

3 I/O P1.6 — Por t 1 bit 6.

2 I/O P1.7 — Por t 1 bit 7.

[1]

Port 1: Port 1 is an 8-bit I/O port with a user-configurable output type, except for three pins as noted below. During reset Port 1 latches are configured in the input only mode with the internal pull-up disabled. The operation of the configurable Port and outputs depends upon the port configuration selected. Each of the configurable port pins are programmed independently. Refer to Section 5.1 “Port configurations” for details.

P1.2 and P1.3 are open drain when used as outputs. P1.5 is input only.

All pins have Schmitt triggered inputs.

Por t 1 also provides various special functions as described below:

O TXD — Transmitter output for the serial port.

I RXD — Receiver input for the serial port.

I/O T0 — Timer/counter 0 external count input or overflow output (open-drain when used as

output).

I/O SCL — I2C serial clock input/output.

I INT0 — External interrupt 0 input.

I/O SDA — I2C serial data input/output.

I INT1 — External interrupt 1 input.

I RST — External Reset input (if selected via FLASH configuration). A LOW on this pin

resets the microcontroller, causing I/O ports and peripherals to take on their default states, and the processor begins execution at address

frequency above 12 MHz, the reset input function of P1.5 must be enabled. An external circuit is required to hold the device in reset at powerup until V reached its specified level. When system power is removed V minimum specified operating voltage. When using an oscillator frequency above

MHz, in some applications, an external brownout detect circuit may be

12 required to hold the device in reset when V operating voltage.

UM10108

P89LPC924/925 User manual

1 pins as inputs

0. When using an oscillator

has

will fall below the

falls below the minimum specified

User manual Rev. 02 — 2 March 2005 5 of 105

Philips Semiconductors

P89LPC924/925 User manual

Table 1: Pin description

Symbol Pin Typ e Description

P3.0 to P3.1 I/O Port 3: Port 3 is an 2-bit I/O port with a user-configurable output type. During reset

Por t 3 latches are configured in the input only mode with the internal pull-up disabled. The operation of Port selected. Each port pin is configured independently. Refer to Section 5.1 “Port

configurations” for details.

All pins have Schmitt triggered inputs.

Por t 3 also provides various special functions as described below:

7 I/O P3.0 — Por t 3 bit 0.

O XTAL2 — Output from the oscillator amplifier (when a crystal oscillator option is

selected via the FLASH configuration.

O CLKOUT — CPU clock divided by 2 when enabled via SFR bit (ENCLK - TRIM.6). It

can be used if the CPU clock is the internal RC oscillator, Watchdog oscillator or external clock input, except when XTAL1/XTAL2 are used to generate clock source for the real time clock/system timer.

6 I/O P3.1 — Por t 3 bit 1.

I XTAL1 — Input to the oscillator circuit and internal clock generator circuits (when

selected via the FLASH configuration). It can be a port pin if internal RC oscillator or Watchdog oscillator is used as the CPU clock source, and if XTAL1/XTAL2 are not used to generate the clock for the real time clock/system timer.

5 I Ground: 0 V reference.

15 I Power Supply: This is the power supply voltage for normal operation as well as Idle

and Power-down modes.

3 pins as inputs and outputs depends upon the port configuration

UM10108

[1] Input/Output for P1.0 to P1.4, P1.6, P1.7. Input for P1.5.

User manual Rev. 02 — 2 March 2005 6 of 105

Philips Semiconductors

UM10108

P89LPC924/925 User manual

CRYSTAL

RESONATOR

P89LPC924/925

4 kB/8 kB

CODE FLASH

256-BYTE

DATA RAM

PORT 3

CONFIGURABLE I/Os

PORT 1

CONFIGURABLE I/Os

PORT 0

CONFIGURABLE I/Os

KEYPAD

INTERRUPT

PROGRAMMABLE

OSCILLATOR DIVIDER

CONFIGURABLE

OSCILLATOR

HIGH PERFORMANCE

ACCELERATED 2-CLOCK 80C51 CPU

INTERNAL BUS

CPU CLOCK

ON-CHIP

OSCILLATOR

UART

REAL-TIME CLOCK/

SYSTEM TIMER

I2C

TIMER 0 TIMER 1

WATCHDOG TIMER

AND OSCILLATOR

ANALOG

COMPARATORS

ADC1/DAC1

Fig 2. P89LPC924/925 block diagram.

POWER MONITOR (POWER-ON RESET, BROWNOUT RESET)

002aaa786

User manual Rev. 02 — 2 March 2005 7 of 105

Philips Semiconductors

1.2 Special function registers

Remark: Special Function Registers (SFRs) accesses are restricted in the following ways:

• User must not attempt to access any SFR locations not defined.

• Accesses to any defined SFR locations must be strictly for the functions for the SFRs.

• SFR bits labeled ‘-’, ‘0’ or ‘1’ can only be written and read as follows:

– ‘-’ Unless otherwise specified, must be written with ‘0’, but can return any value

– ‘0’ must be written with ‘0’, and will return a ‘0’ when read.

– ‘1’ must be written with ‘1’, and will return a ‘1’ when read.

UM10108

P89LPC924/925 User manual

when read (even if it was written with ‘0’). It is a reserved bit and may be used in future derivatives.

User manual Rev. 02 — 2 March 2005 8 of 105

xxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxx x x x xxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxx xx xx xxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxx xxxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxx x x xxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxx

User manual Rev. 02 — 2 March 2005 9 of 105

Table 2: Special function registers

* indicates SFRs that are bit addressable.

Name Description SFR

ACC* Accumulator E0H 00 00000000

ADCON1 A/D control register 1 97H ENBI1 ENADCI1TMM1 EDGE1 ADCI1 ENADC1 ADCS11 ADCS10 00 00000000

ADINS A/D input select A3H ADI13 ADI12 ADI11 ADI10 - - - - 00 00000000

ADMODA A/D mode register A C0H BNDI1 BURST1 SCC1 SCAN1 - - - - 00 00000000

ADMODB A/D mode register B A1H CLK2 CLK1 CLK0 - ENDAC1 - BSA1 - 00 000x0000

AD1BH A/D_1 boundary HIGH

AD1BL A/D_1 boundary LOW

AD1DAT0 A/D_1 data register 0 D5H 00 00000000

AD1DAT1 A/D_1 data register 1 D6H 00 00000000

AD1DAT2 A/D_1 data register 2 D7H 00 00000000

AD1DAT3 A/D_1 data register 3 F5H 00 00000000

AUXR1 Auxiliary function register A2H CLKLP EBRR ENT1 ENT0 SRST 0 - DPS 00

B* B register F0H 00 00000000

BRGR0

BRGR1

BRGCON Baud rate generator control BDH - - - - - - SBRGS BRGEN 00 xxxxxx00

CMP1 Comparator 1 control register ACH - - CE1 CP1 CN1 OE1 CO1 CMF1 00

CMP2 Comparator 2 control register ADH - - CE2 CP2 CN2 OE2 CO2 CMF2 00

DIVM CPU clock divide-by-M

DPTR Data pointer (2 bytes)

DPH Data pointer HIGH 83H 00 00000000

DPL Data pointer LOW 82H 00 00000000

FMADRH Program Flash address HIGH E7H 00 00000000

xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx

Bit functions and addresses Reset value

[2]

Baud rate generator rate LOW

[2]

Baud rate generator rate HIGH

control

addr.

Bit address E7 E6 E5 E4 E3 E2 E1 E0

C4H FF 11111111

BCH 00 00000000

Bit address F7 F6 F5 F4 F3 F2 F1 F0

BEH 00 00000000

BFH 00 00000000

95H 00 00000000

MSB LSB Hex Binary

[1]

000000x0

xx000000

Philips Semiconductors

P89LPC924/925 User manual

UM10108

User manual Rev. 02 — 2 March 2005 10 of 105

Table 2: Special function registers

* indicates SFRs that are bit addressable.

Name Description SFR

FMADRL Program Flash address LOW E6H 00 00000000

FMCON Program Flash control (Read) E4H BUSY - - - HVA HVE SV OI 70 01110000

FMDATA Program Flash data E5H 00 00000000

I2ADR I2C slave address register DBH I2ADR.6 I2ADR.5 I2ADR.4 I2ADR.3 I2ADR.2 I2ADR.1 I2ADR.0 GC 00 00000000

I2CON* I2C control register D8H - I2EN STA STO SI AA - CRSEL 00 x00000x0

I2DAT I2C data register DAH

I2SCLH Serial clock generator/SCL

I2SCLL Serial clock generator/SCL

I2STAT I2C status register D9H STA.4 STA.3 STA.2 STA.1 STA.0 0 0 0 F8 11111000

IEN0* Interrupt enable 0 A8H EA EWDRT EBO ES/ESR ET1 EX1 ET0 EX0 00

IEN1* Interrupt enable 1 E8H EAD EST - - - EC EKBI EI2C 00

IP0* Interrupt priority 0 B8H - PWDRT PBO PS/PSR PT1 PX1 PT0 PX0 00

IP0H Interrupt priority 0 HIGH B7H - PWDRTHPBOH PSH/

IP1* Interrupt priority 1 F8H PA D PST - - - PC PKBI PI2C 00

IP1H Interrupt priority 1 HIGH F7H PA D H PSTH - - - PCH PKBIH PI2CH 00

KBCON Keypad control register 94H - - - - - - PAT N

KBMASK Keypad interrupt mask

K BPAT N Keypad pattern register 93H FF 11111111

xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx

Bit functions and addresses Reset value

addr.

Program Flash control (Write) E4H FMCMD.7FMCMD.6FMCMD.5FMCMD.4FMCMD.3FMCMD.2FMCMD.1FMCMD.

Bit address DF DE DD DC DB DA D9 D8

DDH 00 00000000

duty cycle register HIGH

DCH 00 00000000

duty cycle register LOW

Bit address AF AE AD AC AB AA A9 A8

Bit address EF EE ED EC EB EA E9 E8

Bit address BF BE BD BC BB BA B9 B8

Bit address FF FE FD FC FB FA F9 F8

86H 00 00000000

MSB LSB Hex Binary

PT1H PX1H PT0H PX0H 00

PSRH

KBIF 00

_SEL

[1]

00000000

00x00000

x0000000

00x00000

xxxxxx00

Philips Semiconductors

P89LPC924/925 User manual

UM10108

User manual Rev. 02 — 2 March 2005 11 of 105

Table 2: Special function registers

* indicates SFRs that are bit addressable.

Name Description SFR

P0* Por t 0 80H T1/KB7 CMP1

P1* Por t 1 90H - - RST INT1 INT0/

P3* Por t 3 B0H - - - - - - XTAL1 XTAL2

P0M1 Por t 0 output mode 1 84H (P0M1.7) (P0M1.6) (P0M1.5) (P0M1.4) (P0M1.3) (P0M1.2) (P0M1.1) (P0M1.0) FF 11111111

P0M2 Por t 0 output mode 2 85H (P0M2.7) (P0M2.6) (P0M2.5) (P0M2.4) (P0M2.3) (P0M2.2) (P0M2.1) (P0M2.0) 00 00000000

P1M1 Por t 1 output mode 1 91H (P1M1.7) (P1M1.6) - (P1M1.4) (P1M1.3) (P1M1.2) (P1M1.1) (P1M1.0) D3

P1M2 Por t 1 output mode 2 92H (P1M2.7) (P1M2.6) - (P1M2.4) (P1M2.3) (P1M2.2) (P1M2.1) (P1M2.0) 00

P3M1 Por t 3 output mode 1 B1H - - - - - - (P3M1.1) (P3M1.0) 03

P3M2 Por t 3 output mode 2 B2H - - - - - - (P3M2.1) (P3M2.0) 00

PCON Power control register 87H SMOD1 SMOD0 BOPD BOI GF1 GF0 PMOD1 PMOD0 00 00000000

PCONA Power control register A B5H RTCPD - VCPD ADPD I2PD - SPD - 00

PSW* Program status word D0H CY AC F0 RS1 RS0 OV F1 P 00H 00000000

PT0AD Port 0 digital input disable F6H - - PT0AD.5 PT0AD.4 PT0AD.3 PT0AD.2 PT0AD.1 - 00H xx00000x

RSTSRC Reset source register DFH - - BOF POF R_BK R_WD R_SF R_EX

RTCCON Real-time clock control D1H RTCF RTCS1 RTCS0 - - - ERTC RTCEN 60

RTCH Real-time clock register HIGH D2H 00

RTCL Real-time clock register LOW D3H 00

SADDR Serial port address register A9H 00 00000000

SADEN Serial port address enable B9H 00 00000000

SBUF Serial Port data buffer

SCON* Serial port control 98H SM0/FE SM1 SM2 REN TB8 RB8 TI RI 00 00000000

xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx

Bit functions and addresses Reset value

addr.

Bit address 87 86 85 84 83 82 81 80

Bit address 97 96 95 94 93 92 91 90

Bit address B7 B6 B5 B4 B3 B2 B1 B0

Bit address D7 D6 D5 D4 D3 D2 D1 D0

99H xx xxxxxxxx

Bit address 9F 9E 9D 9C 9B 9A 99 98

MSB LSB Hex Binary

/KB6

CMPREF

/KB5

CIN1A

/KB4

CIN1B

/KB3

SDA

CIN2A

/KB2

T0/SCL RXD TXD

CIN2B

/KB1

CMP2

/KB0

[1]

[1][6]

[6]

Philips Semiconductors

[1]

11x1xx11

00x0xx00

xxxxxx11

xxxxxx00

00000000

[3]

P89LPC924/925 User manual

00000000

UM10108

User manual Rev. 02 — 2 March 2005 12 of 105

Table 2: Special function registers

* indicates SFRs that are bit addressable.

Name Description SFR

SSTAT Serial port extended status

SP Stack pointer 81H 07 00000111

TA MO D Timer 0 and 1 auxiliary mode 8FH - - - T1M2 - - - T0M2 00 xxx0xxx0

TCON* Timer 0 and 1 control 88H TF1 TR1 TF0 TR0 IE1 IT1 IE0 IT0 00 00000000

TH0 Timer 0 HIGH 8CH 00 00000000

TH1 Timer 1 HIGH 8DH 00 00000000

TL0 Timer 0 LOW 8AH 00 00000000

TL1 Timer 1 LOW 8BH 00 00000000

TMOD Timer 0 and 1 mode 89H T1GATE T1C/T T1M1 T1M0 T0GATE T0C/T T0M1 T0M0 00 00000000

TRIM Internal oscillator trim register 96H RCCLK ENCLK TRIM.5 TRIM.4 TRIM.3 TRIM.2 TRIM.1 TRIM.0

WDCON Watchdog control register A7H PRE2 PRE1 PRE0 - - WDRUN WDTOF WDCLK

WDL Watchdog load C1H FF 11111111

WFEED1 Watchdog feed 1 C2H

WFEED2 Watchdog feed 2 C3H

xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx

Bit functions and addresses Reset value

addr.

BAH DBMOD INTLO CIDIS DBISEL FE BR OE STINT 00 00000000

Bit address 8F 8E 8D 8C 8B 8A 89 88

MSB LSB Hex Binary

Philips Semiconductors

[5] [6]

[4] [6]

[1] All por ts are in input only (high-impedance) state after power-up.

[2] BRGR1 and BRGR0 must only be written if BRGEN in BRGCON SFR is logic 0. If any are written while BRGEN = 1, the result is unpredictable.

[3] The RSTSRC register reflects the cause of the P89LPC924/925 reset. Upon a power-up reset, all reset source flags are cleared except POF and BOF; the power-on reset value is

xx110000.

[4] After reset, the value is 111001x1, i.e., PRE2-PRE0 are all logic 1, WDRUN = 1 and WDCLK = 1. WDTOF bit is logic 1 after Watchdog reset and is logic 0 after power-on reset.

Other resets will not affect WDTOF.

[5] On power-on reset, the TRIM SFR is initialized with a factory preprogrammed value. Other resets will not cause initialization of the TRIM register.

[6] The only reset source that affects these SFRs is power-on reset.

P89LPC924/925 User manual

UM10108

Philips Semiconductors

1.3 Memory organization

FF00h

FFEFh

1FFFh

1E00h

1C00h 1BFFh

1800h 17FFh

1400h 13FFh

1000h

0FFFh

0C00h 0BFFh

0800h 07FFh

0400h 03FFh

0000h

IAP entry-

points

ISP CODE

(512B)*

SECTOR 7

SECTOR 6

SECTOR 5

SECTOR 4

SECTOR 3

SECTOR 2

SECTOR 1

SECTOR 0

Read-protected

IAP calls only

IDATA routines

entry points for:

-51 ASM. code

-C code

ISP serial loader

entry points for:

-UART (auto-baud)

-I2C, SPI, etc.*

Flexible choices:

-as supplied (UART)

-Philips libraries*

-user-defined

FFEFh

FF1Fh

FF00h

1FFFh

1E00h

entry points

SPECIAL FUNCTION

REGISTERS

(DIRECTLY ADDRESSABLE)

UM10108

P89LPC924/925 User manual

IDATA (incl. DATA)

128 BYTES ON-CHIP

DATA MEMORY (STACK

AND INDIR. ADDR.)

DATA

128 BYTES ON-CHIP

DATA MEMORY (STACK,

DIRECT AND INDIR. ADDR.)

4 REG. BANKS R[7:0]

data memory

(DATA, IDATA)

002aaa948

Note: ISP code is located at the end of Sector 4 on the LPC924, and at the end of Sector 7 on the LPC925.

Fig 3. P89LPC924/925 memory map.

The various P89LPC924/925 memory spaces are as follows:

DATA — 128 bytes of internal data memory space (00h:7Fh) accessed via direct or indirect addressing, using instruction other than MOVX and MOVC. All or part of the Stack may be in this area.

IDATA — Indirect Data. 256 bytes of internal data memory space (00h:FFh) accessed via indirect addressing using instructions other than MOVX and MOVC. All or part of the Stack may be in this area. This area includes the DATA area and the 128 immediately above it.

SFR — Special Function Registers. Selected CPU registers and peripheral control and status registers, accessible only via direct addressing.

CODE — 64 kB of Code memory space, accessed as part of program execution and via the MOVC instruction. The

Table 3: Data RAM arrangement

Type Data RAM Size (bytes)

DATA Directly and indirectly addressable memory 128

IDATA Indirectly addressable memory 256

bytes

P89LPC924/925 has 4 kB/8 kB of on-chip Code memory.

User manual Rev. 02 — 2 March 2005 13 of 105

Philips Semiconductors

2. Clocks

2.1 Enhanced CPU

The P89LPC924/925 uses an enhanced 80C51 CPU which runs at six times the speed of standard 80C51 devices. A machine cycle consists of two CPU clock cycles, and most instructions execute in one or two machine cycles.

2.2 Clock definitions

The P89LPC924/925 device has several internal clocks as defined below:

OSCCLK — Input to the DIVM clock divider. OSCCLK is selected from one of four clock sources and can also be optionally divided to a slower frequency (see

Section 2.8 “CPU Clock (CCLK) modification: DIVM register”). Note: f

OSCCLK frequency.

CCLK — CPU clock; output of the DIVM clock divider. There are two CCLK cycles per machine cycle, and most instructions are executed in one to two machine cycles (two or four CCLK cycles).

RCCLK — The internal 7.373 MHz RC oscillator output.

PCLK — Clock for the various peripheral devices and is CCLK/2.

UM10108

P89LPC924/925 User manual

Figure 5 and

is defined as the

osc

2.2.1 Oscillator Clock (OSCCLK)

The P89LPC924/925 provides several user-selectable oscillator options. This allows optimization for a range of needs from high precision to lowest possible cost. These options are configured when the FLASH is programmed and include an on-chip Watchdog oscillator, an on-chip RC oscillator, an oscillator using an external crystal, or an external clock source. The crystal oscillator can be optimized for low, medium, or high frequency crystals covering a range from 20

kHz to 18 MHz.

2.2.2 Low speed oscillator option

This option supports an external crystal in the range of 20 kHz to 100 kHz. Ceramic resonators are also supported in this configuration.

2.2.3 Medium speed oscillator option

This option supports an external crystal in the range of 100 kHz to 4 MHz. Ceramic resonators are also supported in this configuration.

2.2.4 High speed oscillator option

This option supports an external crystal in the range of 4 MHz to 18 MHz. Ceramic resonators are also supported in this configuration.When using an oscillator frequency

above 12 is required to hold the device in reset at powerup until V level. When system power is removed V operating voltage. When using an oscillator frequency above 12 applications, an external brownout detect circuit may be required to hold the device in reset when V

MHz, the reset input function of P1.5 must be enabled. An external circuit

falls below the minimum specified operating voltage.

has reached its specified

will fall below the minimum specified

MHz, in some

User manual Rev. 02 — 2 March 2005 14 of 105

Philips Semiconductors

2.3 Clock output

The P89LPC924/925 supports a user-selectable clock output function on the XTAL2 / CLKOUT pin when the crystal oscillator is not being used. This condition occurs if a different clock source has been selected (on-chip RC oscillator, Watchdog oscillator, external clock input on X1) and if the Real-time Clock is not using the crystal oscillator as its clock source. This allows external devices to synchronize to the output is enabled by the ENCLK bit in the TRIM register.

The frequency of this clock output is 1⁄2 that of the CCLK. If the clock output is not needed in Idle mode, it may be turned off prior to entering Idle, saving additional power. Note: on reset, the TRIM SFR is initialized with a factory preprogrammed value. Therefore when setting or clearing the ENCLK bit, the user should retain the contents of bits 5:0 of the TRIM register. This can be done by reading the contents of the TRIM register (into the ACC for example), modifying bit 6, and writing this result back into the TRIM register. Alternatively, the ‘ANL direct’ or ‘ORL direct’ instructions can be used to clear or set bit 6 of the TRIM register.

UM10108

P89LPC924/925 User manual

P89LPC924/925. This

quartz crystal or

ceramic resonator

P89LPC924/925

XTAL1

[1]

Note: The oscillator must be configured in one of the following modes: Low frequency crystal, medium frequency crystal, or high frequency crystal.

(1) A series resistor may be required to limit crystal drive levels. This is especially important for low

frequency crystals (see text).

Fig 4. Using the crystal oscillator.

XTAL2

002aaa951

2.4 On-chip RC oscillator option

The P89LPC924/925 has a TRIM register that can be used to tune the frequency of the RC oscillator. During reset, the TRIM value is initialized to a factory pre-programmed value to adjust the oscillator frequency to 7.373 better than 1 applications can write to the TRIM register to adjust the on-chip RC oscillator to other frequencies. Increasing the TRIM value will decrease the oscillator frequency.

%; please refer to the data sheet for behavior over temperature). End user

MHz, ± 1 %. (Note: the initial value is

Table 4: On-chip RC oscillator trim register (TRIM - address 96h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol RCCLK ENCLK TRIM.5 TRIM.4 TRIM.3 TRIM.2 TRIM.1 TRIM.0

Reset 0 0 Bits 5:0 loaded with factory stored value during reset.

User manual Rev. 02 — 2 March 2005 15 of 105

Philips Semiconductors

UM10108

P89LPC924/925 User manual

Table 5: On-chip RC oscillator trim register (TRIM - address 96h) bit description

Bit Symbol Description

0 TRIM.0 Trim value. Determines the frequency of the internal RC oscillator. During reset, these bits are

1 TRIM.1

2 TRIM.2

3 TRIM.3

4 TRIM.4

5 TRIM.5

6 ENCLK when = 1, CCLK/2 is output on the XTAL2 pin provided the crystal oscillator is not being used.

7 RCCLK when = 1, selects the RC Oscillator output as the CPU clock (CCLK)

loaded with a stored factory calibration value. When writing to either bit 6 or bit 7 of this register, care should be taken to preserve the current TRIM value by reading this register, modifying bits 6 or 7 as required, and writing the result to this register.

2.5 Watchdog oscillator option

The Watchdog has a separate oscillator which has a frequency of 400 kHz. This oscillator can be used to save power when a high clock frequency is not needed.

2.6 External clock input option

In this configuration, the processor clock is derived from an external source driving the XTAL1 / P3.1 pin. The rate may be from 0

Hz up to 18 MHz. The XTAL2 / P3.0 pin may be

used as a standard port pin or a clock output. When using an oscillator frequency

above 12 is required to hold the device in reset at powerup until V level. When system power is removed V operating voltage. When using an oscillator frequency above 12

MHz, the reset input function of P1.5 must be enabled. An external circuit

has reached its specified

will fall below the minimum specified

MHz, in some applications, an external brownout detect circuit may be required to hold the device in reset when V

falls below the minimum specified operating voltage.

XTAL1

XTAL2

High freq. Med. freq.

Low freq.

OSCILLATOR

(7.3728 MHz)

WATCHDOG

OSCILLATOR

(400 kHz)

PCLK

OSCCLK

DIVM

CCLK

RTC

ADC1/

DAC1

CPU

WDT

TIMER 0 and

TIMER 1

Fig 5. Block diagram of oscillator control.

User manual Rev. 02 — 2 March 2005 16 of 105

I2C

BAUD RATE

GENERATOR

UART

002aaa79

Philips Semiconductors

2.7 Oscillator Clock (OSCCLK) wake-up delay

The P89LPC924/925 has an internal wake-up timer that delays the clock until it stabilizes depending to the clock source used. If the clock source is any of the three crystal selections, the delay is 992 OSCCLK cycles plus 60 either the internal RC oscillator or the Watchdog oscillator, the delay is 224 OSCCLK cycles plus 60

2.8 CPU Clock (CCLK) modification: DIVM register

The OSCCLK frequency can be divided down, by an integer, up to 510 times by configuring a dividing register, DIVM, to provide CCLK. This produces the CCLK frequency using the following formula:

UM10108

P89LPC924/925 User manual

µs to 100 µs. If the clock source is

µs to 100 µs.

Where: f

Since N ranges from 0 to 255, the CCLK frequency can be in the range of f (for N = 0, CCLK = f

This feature makes it possible to temporarily run the CPU at a lower rate, reducing power consumption. By dividing the clock, the CPU can retain the ability to respond to events other than those that can cause interrupts (i.e., events that allow exiting the Idle mode) by executing its normal program at a lower rate. This can often result in lower power consumption than in Idle mode. This can allow bypassing the oscillator start-up time in cases where Power-down mode would otherwise be used. The value of DIVM may be changed by the program at any time without interrupting code execution.

2.9 Low power select

The P89LPC924/925 is designed to run at 12 MHz (CCLK) maximum. However, if CCLK is 8 power consumption further. On any reset, CLKLP is logic This bit can then be set in software if CCLK is running at 8

3. A/D converter

CCLK frequency = f

is the frequency of OSCCLK

osc

N is the value of DIVM.

osc

/ (2N)

osc

to f

MHz or slower, the CLKLP SFR bit (AUXR1.7) can be set to a logic 1 to lower the

0 allowing highest performance.

MHz or slower.

osc

/510.

The P89LPC924/925 has an 8-bit, 4-channel, multiplexed successive approximation analog-to-digital converter module (ADC1) and one DAC module (DAC1). A block diagram of the A/D converter is shown in feeds a sample and hold circuit providing an input signal to one of two comparator inputs. The control logic in combination with the successive approximation register (SAR) drives a digital-to-analog converter which provides the other input to the comparator. The output of the comparator is fed to the SAR.

User manual Rev. 02 — 2 March 2005 17 of 105

Figure 6. The A/D consists of a 4-input multiplexer which

Philips Semiconductors

Fig 6. A/D converter block diagram.

3.1 Features

INPUT

MUX

COMP

–

DAC1

UM10108

P89LPC924/925 User manual

SAR

CONTROL

LOGIC

CCLK

002aaa791

• An 8-bit, 4-channel, multiplexed input, successive approximation A/D converter

• Four A/D result registers

• Six operating modes

– Fixed channel, single conversion mode

– Fixed channel, continuous conversion mode

– Auto scan, single conversion mode

– Auto scan, continuous conversion mode

– Dual channel, continuous conversion mode

– Single step mode

• Three conversion start modes

– Timer triggered start

– Start immediately

– Edge triggered

• 8-bit conversion time of ≥ 3.9 µs at an ADC clock of 3.3 MHz

• Interrupt or polled operation

• Boundary limits interrupt

• DAC output to a port pin with high output impedance

• Clock divider

• Power-down mode

User manual Rev. 02 — 2 March 2005 18 of 105

Philips Semiconductors

3.2 A/D operating modes

3.2.1 Fixed channel, single conversion mode

A single input channel can be selected for conversion. A single conversion will be performed and the result placed in the result register which corresponds to the selected input channel (See completes. The input channel is selected in the ADINS register. This mode is selected by setting the SCAN1 bit in the ADMODA register.

Table 6: Input channels and Result registers for fixed channel single, auto scan single,

Result register Input channel Result register Input channel

AD1DAT0 AD10 AD1DAT2 AD12

AD1DAT1 AD11 AD1DAT3 AD13

3.2.2 Fixed channel, continuous conversion mode

A single input channel can be selected for continuous conversion. The results of the conversions will be sequentially placed in the four result registers enabled, will be generated after every four conversions. Additional conversion results will again cycle through the four result registers, overwriting the previous results. Continuous conversions continue until terminated by the user. This mode is selected by setting the SCC1 bit in the ADMODA register.

UM10108

P89LPC924/925 User manual

Ta bl e 6). An interrupt, if enabled, will be generated after the conversion

and autoscan continuous conversion modes.

Ta bl e 7. An interrupt, if

3.2.3 Auto scan, single conversion mode

Any combination of the four input channels can be selected for conversion by setting a channel’s respective bit in the ADINS register. The channels are converted from LSB to MSB order (in ADINS). A single conversion of each selected input will be performed and the result placed in the result register which corresponds to the selected input channel (See

Ta bl e 6). An interrupt, if enabled, will be generated after all selected channels have

been converted. If only a single channel is selected this is equivalent to single channel, single conversion mode. This mode is selected by setting the SCAN1 bit in the ADMODA register.

Table 7: Result registers and conversion results for fixed channel, continuous conversion

mode.

Result register Contains

AD1DAT0 Selected channel, first conversion result

AD1DAT1 Selected channel, second conversion result

AD1DAT2 Selected channel, third conversion result

AD1DAT3 Selected channel, forth conversion result

3.2.4 Auto scan, continuous conversion mode

Any combination of the four input channels can be selected for conversion by setting a channel’s respective bit in the ADINS register. The channels are converted from LSB to MSB order (in ADINS). A conversion of each selected input will be performed and the result placed in the result register which corresponds to the selected input channel (See

Ta bl e 6). An interrupt, if enabled, will be generated after all selected channels have been

converted. The process will repeat starting with the first selected channel. Additional

User manual Rev. 02 — 2 March 2005 19 of 105

Philips Semiconductors

conversion results will again cycle through the result registers of the selected channels, overwriting the previous results. Continuous conversions continue until terminated by the user. This mode is selected by setting the BURST1 bit in the ADMODA register.

3.2.5 Dual channel, continuous conversion mode

Any combination of two of the four input channels can be selected for conversion. The result of the conversion of the first channel is placed in the first result register. The result of the conversion of the second channel is placed in the second result register. The first channel is again converted and its result stored in the third result register. The second channel is again converted and its result placed in the fourth result register (See An interrupt is generated, if enabled, after every set of four conversions (two conversions per channel). This mode is selected by setting the SCC1 bit in the ADMODA register.

Table 8: Result registers and conversion results for dual channel, continuous conversion

Result register Contains

AD1DAT0 First channel, first conversion result

AD1DAT1 Second channel, first conversion result

AD1DAT2 First channel, second conversion result

AD1DAT3 Second channel, second conversion result

UM10108

P89LPC924/925 User manual

Ta bl e 8).

mode.

3.2.6 Single step

This special mode allows ‘single-stepping’ in an auto scan conversion mode. Any combination of the four input channels can be selected for conversion. After each channel is converted, an interrupt is generated, if enabled, and the A/D waits for the next start condition. The result of each channel is placed in the result register which corresponds to the selected input channel (See mode is selected by clearing the BURST1, SCC1, and SCAN1 bits in the ADMODA register.

Ta bl e 6). May be used with any of the start modes. This

3.2.7 Conversion mode selection bits

The A/D uses three bits in ADMODA to select the conversion mode. These mode bits are summarized in shown, are undefined.

Table 9: Conversion mode bits.

BURST1 SCC1 Scan1 ADC1 conversion

0 0 0 single step 0 0 0 single step

0 0 1 fixed

0 1 0 fixed channel,

1 0 0 auto scan,

Ta bl e 9, below. Combinations of the three bits, other than the combinations

mode

channel,single

auto scan, single auto scan, single

continuous

dual channel, continuous

continuous

BURST0 SCC0 Scan0 ADC0 conversion

mode

0 0 1 fixed

channel,single

0 1 0 fixed channel,

continuous

dual channel, continuous

1 0 0 auto scan,

continuous

User manual Rev. 02 — 2 March 2005 20 of 105

Philips Semiconductors

3.3 Trigger modes

3.3.1 Timer triggered start

An A/D conversion is started by the overflow of Timer 0. Once a conversion has started, additional Timer 0 triggers are ignored until the conversion has completed. The Timer triggered start mode is available in all A/D operating modes. This mode is selected by the TMM1 bit and the ADCS11 and ADCS10 bits (See

3.3.2 Start immediately

Programming this mode immediately starts a conversion. This start mode is available in all A/D operating modes. This mode is selected by setting the ADCS11 and ADCS10 bits in the ADCON1 register (See

3.3.3 Edge triggered

An A/D conversion is started by rising or falling edge of P1.4. Once a conversion has started, additional edge triggers are ignored until the conversion has completed. The edge triggered start mode is available in all A/D operating modes. This mode is selected by setting the ADCS11 and ADCS10 bits in the ADCON1 register (See

UM10108

P89LPC924/925 User manual

Ta bl e 11).

3.3.4 Boundary limits interrupt

The A/D converter has both a HIGH and LOW boundary limit register. After the four MSBs have been converted, these four bits are compared with the four MSBs of the boundary HIGH and LOW registers. If the four MSBs of the conversion are outside the limit an interrupt will be generated, if enabled. If the conversion result is within the limits, the boundary limits will again be compared after all eight bits have been converted. An interrupt will be generated, if enabled, if the result is outside the boundary limits. The boundary limit may be disabled by clearing the boundary limit interrupt enable.

3.4 DAC output to a port pin with high-impedance

The AD0DAT3 register is used to hold the value fed to the DAC. After a value has been written to AD0DAT3 the DAC output will appear on the DAC0 pin. The DAC output is enabled by the ENDAC0 bit in the ADMODB register (See

3.5 Clock divider

The A/D converter requires that its internal clock source be in the range of 500 kHz to

3.3

MHz to maintain accuracy. A programmable clock divider that divides the clock from 1

to 8 is provided for this purpose (See

Ta bl e 15).

3.6 I/O pins used with A/D converter functions

The analog input pins used with for the A/D converter have a digital input and output function. In order to give the best analog performance, pins that are being used with the ADC or DAC should have their digital outputs and inputs disabled and have the 5 tolerance disconnected. Digital outputs are disabled by putting the port pins into the input-only mode as described in the Port Configurations section (see

Ta bl e 15).

Ta bl e 21).

User manual Rev. 02 — 2 March 2005 21 of 105

Philips Semiconductors

Digital inputs will be disconnected automatically from these pins when the pin has been selected by setting its corresponding bit in the ADINS register and the A/D or DAC has been enabled. Pins selected in ADINS will be 3 and the device is not in power-down, otherwise the pin will remain 5

P89LPC924/925 User manual

V tolerant provided that the A/D is enabled

UM10108

V tolerant.

3.7 Power-down and idle mode

In idle mode the A/D converter, if enabled, will continue to function and can cause the device to exit idle mode when the conversion is completed if the A/D interrupt is enabled. In Power-down mode or Total Power-down mode, the A/D does not function. If the A/D is enabled, it will consume power. Power can be reduced by disabling the A/D.

Table 10: A/D Control register 1 (ADCON1 - address 97h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol ENBI1 ENADCI1 TMM1 EDGE1 ADCI1 ENADC1 ADCS11 ADCS10

Reset 0 0 0 0 0 0 0 0

Table 11: A/D Control register 1 (ADCON1 - address 97h) bit description

Bit Symbol Description

0 ADCS10 A/D start mode bits [11:10]:

1 ADCS11

2 ENADC1 Enable A/D channel 1. When set = 1, enables ADC1. Must also be set for D/A

3 ADCI1 A/D Conversion complete Interrupt 1. Set when any conversion or set of multiple

4 EDGE1 When = 0, an Edge conversion start is triggered by a falling edge on P1.4.

5 TMM1 Timer Trigger Mode 1. Selects either stop mode (TMM1 = 0) or timer trigger mode

6 ENADCI1 Enable A/D Conversion complete Interrupt 1. When set, will cause an interrupt if the

7 ENBI1 Enable A/D boundary interrupt 1. When set, will cause an interrupt if the boundary

00 — Timer Trigger Mode when TMM1 = 1. Conversions starts on overflow of Timer 0. Stop mode when TMM1 = 0, no start occurs.

01 — Immediate Start Mode. Conversions starts immediately.

10 — Edge Trigger Mode. Conversion starts when edge condition defined by bit

EDGE1 occurs.

operation of this channel.

conversions has completed. Cleared by software.

When = 1, an Edge conversion start is triggered by a rising edge on P1.4.

(TMM1 = 1) when the ADCS11 and ADCS10 bits = 00.

ADCI1 flag is set and the A/D interrupt is enabled.

interrupt 1 flag, BNDI1, is set and the A/D interrupt is enabled.

Table 12: A/D Mode Register A (ADMODA - address C0h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol BNBI1 BURST1 SCC1 SCAN1 - - - -

Reset 0 0 0 0 0 0 0 0

Table 13: A/D Mode Register A (ADMODA - address C0h) bit description

Bit Symbol Description

0:3 - reserved

4 SCAN1 when = 1, selects single conversion mode (auto scan or fixed channel) for ADC1

User manual Rev. 02 — 2 March 2005 22 of 105

Philips Semiconductors

P89LPC924/925 User manual

Table 13: A/D Mode Register A (ADMODA - address C0h) bit description

Bit Symbol Description

5 SCC1 when = 1, selects fixed channel, continuous conversion mode for ADC1

6 BURST1 when = 1, selects auto scan, continuous conversion mode for ADC1

7 BNBI1 ADC1 boundary interrupt flag. When set, indicates that the converted result from

ADC1 is outside of the range defined by the ADC1 boundary registers

Table 14: A/D Mode Register B (ADMODB - address A1h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol CLK2 CLK1 CLK0 - ENDAC1 - BSA1 -

Reset 0 0 0 0 0 0 0 0

Table 15: A/D Mode Register B (ADMODB - address A1h) bit description

Bit Symbol Description

0 - reserved

1 BSA1 ADC1 Boundary Select All. When = 1, BNDI1 will be set if any ADC1 input exceeds

the boundary limits. When = 0, BNDI1 will be set only if the AD10 input exceeded the boundary limits.

2 - reserved

3 ENDAC1 When = 1 selects DAC mode for ADC1; when = 0 selects ADC mode.

4 - reserved

5 CLK0 Clock divider to produce the ADC clock. Divides CCLK by the value indicated below.

6 CLK1

7 CLK2

The resulting ADC clock should be 3.3 MHz or less. A minimum of 0.5 MHz is required to maintain A/D accuracy. A/D start mode bits:

CLK2:0 — divisor

000 — 1

001 — 2

010 — 3

011 — 4

100 — 5

101 — 6

110 — 7

111 — 8

UM10108

Table 16: A/D Input Select register (ADINS - address A3h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol AIN13 AIN12 AIN11 AIN10 - - - -

Reset 0 0 0 0 0 0 0 0

Table 17: A/D Input Select register (ADINS - address A3h) bit description

Bit Symbol Description

0:3 - reserved

4 AIN10 when set, enables the AD10 pin for sampling and conversion

5 AIN11 when set, enables the AD11 pin for sampling and conversion

6 AIN12 when set, enables the AD12 pin for sampling and conversion

7 AIN13 when set, enables the AD13 pin for sampling and conversion

User manual Rev. 02 — 2 March 2005 23 of 105

Philips Semiconductors

4. Interrupts

The P89LPC924/925 uses a four priority level interrupt structure. This allows great flexibility in controlling the handling of the

Each interrupt source can be individually enabled or disabled by setting or clearing a bit in the interrupt enable registers IEN0 or IEN1. The IEN0 register also contains a global enable bit, EA, which enables all interrupts.

Each interrupt source can be individually programmed to one of four priority levels by setting or clearing bits in the interrupt priority registers IP0, IP0H, IP1, and IP1H. An interrupt service routine in progress can be interrupted by a higher priority interrupt, but not by another interrupt of the same or lower priority. The highest priority interrupt service cannot be interrupted by any other interrupt source. If two requests of different priority levels are received simultaneously, the request of higher priority level is serviced.

If requests of the same priority level are pending at the start of an instruction cycle, an internal polling sequence determines which request is serviced. This is called the arbitration ranking. Note that the arbitration ranking is only used for pending requests of the same priority level. addresses, enable bits, priority bits, arbitration ranking, and whether each interrupt may wake up the CPU from a Power-down mode.

UM10108

P89LPC924/925 User manual

P89LPC924/925’s 12 interrupt sources.

Ta bl e 19 summarizes the interrupt sources, flag bits, vector

4.1 Interrupt priority structure

Table 18: Interrupt priority level

Priority bits

IPxH IPx Interrupt priority level

0 0 Level 0 (lowest priority)

0 1 Level 1

1 0 Level 2

1 1 Level 3

There are four SFRs associated with the four interrupt levels: IP0, IP0H, IP1, IP1H. Every interrupt has two bits in IPx and IPxH (x = 0,1) and can therefore be assigned to one of four levels, as shown in

The P89LPC924/925 has two external interrupt inputs in addition to the Keypad Interrupt function. The two interrupt inputs are identical to those present on the standard 80C51 microcontrollers.

These external interrupts can be programmed to be level-triggered or edge-triggered by clearing or setting bit IT1 or IT0 in Register TCON. If ITn = 0, external interrupt n is triggered by a LOW level detected at the triggered. In this mode if consecutive samples of the cycle and a LOW level in the next cycle, interrupt request flag IEn in TCON is set, causing an interrupt request.

Ta bl e 18.

INTn pin. If ITn = 1, external interrupt n is edge

INTn pin show a HIGH level in one

Since the external interrupt pins are sampled once each machine cycle, an input HIGH or LOW level should be held for at least one machine cycle to ensure proper sampling. If the external interrupt is edge-triggered, the external source has to hold the request pin HIGH

User manual Rev. 02 — 2 March 2005 24 of 105

Philips Semiconductors

for at least one machine cycle, and then hold it LOW for at least one machine cycle. This is to ensure that the transition is detected and that interrupt request flag IEn is set. IEn is automatically cleared by the CPU when the service routine is called.

If the external interrupt is level-triggered, the external source must hold the request active until the requested interrupt is generated. If the external interrupt is still asserted when the interrupt service routine is completed, another interrupt will be generated. It is not necessary to clear the interrupt flag IEn when the interrupt is level sensitive, it simply tracks the input pin level.

If an external interrupt has been programmed as level-triggered and is enabled when the P89LPC924/925 is put into Power-down or Idle mode, the interrupt occurrence will cause the processor to wake up and resume operation. Refer to

modes” on page 32 for details.

4.2 External Interrupt pin glitch suppression

Most of the P89LPC924/925 pins have glitch suppression circuits to reject short glitches (please refer to the specifications). However, pins SDA/ suppression circuits. Therefore,

UM10108

P89LPC924/925 User manual

Section 6.3 “Power reduction

P89LPC924/925 data sheet, Dynamic characteristics for glitch filter

INT0/P1.3 and SCL/T0/P1.2 do not have the glitch

INT1 has glitch suppression while INT0 does not.

Table 19: Summary of interrupts

Description Interrupt flag

bit(s)

External interrupt 0 IE0 0003h EX0 (IEN0.0) IP0H.0,IP0.0 1 (highest) Ye s

Timer 0 interrupt TF0 000Bh ET0 (IEN0.1) IP0H.1,IP0.1 4 No

External interrupt 1 IE1 0013h EX1 (IEN0.2) IP0H.2,IP0.2 7 Ye s

Timer 1 interrupt TF1 001Bh ET1 (IEN0.3) IP0H.3,IP0.3 10 No

Serial port TX and RX TI and RI 0023h ES/ESR (IEN0.4) IP0H.4,IP0.4 13 No

Serial port RX RI

Brownout detect BOF 002Bh EBO (IEN0.5) IP0H.5,IP0.5 2 Ye s

Watchdog timer/Real-time clock WDOVF/RTCF 0053h EWDRT (IEN0.6) IP0H.6,IP0.6 3 Ye s

I2C interrupt SI 0033h EI2C (IEN1.0) IP0H.0,IP0.0 5 No

KBI interrupt KBIF 003Bh EKBI (IEN1.1) IP0H.0,IP0.0 8 Ye s

Comparators 1 and 2 interrupts CMF1/CMF2 0043h EC (IEN1.2) IP0H.0,IP0.0 11 Ye s

Serial port TX TI 006Bh EST (IEN1.6) IP0H.0,IP0.0 12 No

ADC ADCI1,BNDI1 0073h EAD (IEN1.7) IP1H.7,IP1.7 15 (lowest) No

Vector address

Interrupt enable bit(s)

Interrupt priority

Arbitration ranking

Powerdown wake-up

User manual Rev. 02 — 2 March 2005 25 of 105

Philips Semiconductors

RTCF ERTC

(RTCCON.1)

WDOVF

IE0

EX0

IE1

EX1

BOPD

EBO

KBIF

EKBI

EWDRT

CMF2 CMF1

EA (IE0.7)

TF0 ET0

TF1 ET1

TI & RI/RI

ES/ESR

EST

EI2C

UM10108

P89LPC924/925 User manual

WAKE-UP (IF IN POWER-DOWN)

INTERRUPT TO CPU

ENADCI1

ADCI1

ENBI1 BNDI1

EAD

Fig 7. Interrupt sources, interrupt enables, and power-down wake up sources.

5. I/O ports

The P89LPC924/925 has three I/O ports: Port 0, Port 1, and Port 3. Ports 0 and 1 are 8-bit ports and Port 3 is a 2-bit port. The exact number of I/O pins available depends upon the clock and reset options chosen (see

Table 20: Number of I/O pins available

Clock source Reset option Number of I/O

On-chip oscillator or Watchdog oscillator

External clock input No external reset (except during power up) 25

Low/medium/high speed oscillator (external crystal or resonator)

Ta bl e 20).

No external reset (except during power up) 26

External RST pin supported 25

External RST pin supported

No external reset (except during power up) 24

External RST pin supported

002aaa792

pins

[1]

[1] Required for operation above 12 MHz.

User manual Rev. 02 — 2 March 2005 26 of 105

Philips Semiconductors

5.1 Port configurations

All but three I/O port pins on the P89LPC924/925 may be configured by software to one of four types on a pin-by-pin basis, as shown in (standard 80C51 port outputs), push-pull, open drain, and input-only. Two configuration registers for each port select the output type for each port pin.

P1.5 (RST) can only be an input and cannot be configured.

P1.2 (SCL/T0) and P1.3 (SDA/INT0) may only be configured to be either input-only or open drain.

Table 21: Port output configuration settings

PxM1.y PxM2.y Port output mode

0 0 Quasi-bidirectional

0 1 Push-pull

1 0 Input only (high-impedance)

1 1 Open drain

UM10108

P89LPC924/925 User manual

Ta bl e 21. These are: quasi-bidirectional

5.2 Quasi-bidirectional output configuration

Quasi-bidirectional outputs can be used both as an input and output without the need to reconfigure the port. This is possible because when the port outputs a logic HIGH, it is weakly driven, allowing an external device to pull the pin LOW. When the pin is driven LOW, it is driven strongly and able to sink a large current. There are three pull-up transistors in the quasi-bidirectional output that serve different purposes.

One of these pull-ups, called the ‘very weak’ pull-up, is turned on whenever the port latch for the pin contains a logic 1. This very weak pull-up sources a very small current that will pull the pin HIGH if it is left floating.

A second pull-up, called the ‘weak’ pull-up, is turned on when the port latch for the pin contains a logic 1 and the pin itself is also at a logic 1 level. This pull-up provides the primary source current for a quasi-bidirectional pin that is outputting a 1. If this pin is pulled LOW by an external device, the weak pull-up turns off, and only the very weak pull-up remains on. In order to pull the pin LOW under these conditions, the external device has to sink enough current to overpower the weak pull-up and pull the port pin below its input threshold voltage.

The third pull-up is referred to as the ‘strong’ pull-up. This pull-up is used to speed up LOW-to-HIGH transitions on a quasi-bidirectional port pin when the port latch changes from a logic 0 to a logic 1. When this occurs, the strong pull-up turns on for two CPU clocks quickly pulling the port pin HIGH.

The quasi-bidirectional port configuration is shown in Figure 8.

Although the P89LPC924/925 is a 3 V device most of the pins are 5 V-tolerant. If 5 V is applied to a pin configured in quasi-bidirectional mode, there will be a current flowing from the pin to V configured in quasi-bidirectional mode is discouraged.

A quasi-bidirectional port pin has a Schmitt triggered input that also has a glitch suppression circuit.

User manual Rev. 02 — 2 March 2005 27 of 105

causing extra power consumption. Therefore, applying 5 V to pins

Philips Semiconductors

(Please refer to the P89LPC924/925 data sheet, Dynamic characteristics for glitch filter specifications).

UM10108

P89LPC924/925 User manual

port latch

data

Fig 8. Quasi-bidirectional output.

5.3 Open drain output configuration

The open drain output configuration turns off all pull-ups and only drives the pull-down transistor of the port pin when the port latch contains a logic 0. To be used as a logic output, a port configured in this manner must have an external pull-up, typically a resistor tied to V

The open drain port configuration is shown in Figure 9.

2 CPU

CLOCK DELAY

PP P

input

data

very

weak

weakstrong

glitch rejection

port

002aaa914

. The pull-down for this mode is the same as for the quasi-bidirectional mode.

An open drain port pin has a Schmitt triggered input that also has a glitch suppression circuit.

Please refer to the P89LPC924/925 data sheet, Dynamic characteristics for glitch filter specifications.

port

port latch

data

input

data

glitch rejection

Fig 9. Open drain output.

User manual Rev. 02 — 2 March 2005 28 of 105

002aaa915

Philips Semiconductors

5.4 Input-only configuration

The input port configuration is shown in Figure 10. It is a Schmitt triggered input that also has a glitch suppression circuit.

(Please refer to the P89LPC924/925 data sheet, Dynamic characteristics for glitch filter specifications).

UM10108

P89LPC924/925 User manual

input

data

glitch rejection

Fig 10. Input only.

port

002aaa916

5.5 Push-pull output configuration

The push-pull output configuration has the same pull-down structure as both the open drain and the quasi-bidirectional output modes, but provides a continuous strong pull-up when the port latch contains a logic 1. The push-pull mode may be used when more source current is needed from a port output.

The push-pull port configuration is shown in Figure 11.

A push-pull port pin has a Schmitt triggered input that also has a glitch suppression circuit.

(Please refer to the P89LPC924/925 data sheet, Dynamic characteristics for glitch filter specifications).

strong

port

002aaa917

Fig 11. Push-pull output.

port latch

data

input

data

glitch rejection

5.6 Port 0 analog functions

The P89LPC924/925 incorporates two Analog Comparators. In order to give the best analog performance and minimize power consumption, pins that are being used for analog functions must have both the digital outputs and digital inputs disabled.

User manual Rev. 02 — 2 March 2005 29 of 105

Philips Semiconductors

Digital outputs are disabled by putting the port pins into the input-only mode as described in the Port Configurations section (see

Digital inputs on Port 0 may be disabled through the use of the PT0AD register. Bits 1 through 5 in this register correspond to pins P0.1 through P0.5 of Port 0, respectively. Setting the corresponding bit in PT0AD disables that pin’s digital input. Port bits that have their digital inputs disabled will be read as logic port.

On any reset, PT0AD bits 1 through 5 default to logic 0s to enable the digital functions.

5.7 Additional port features

After power-up, all pins are in Input-Only mode. Please note that this is different from the LPC76x series of devices.

• After power-up, all I/O pins except P1.5, may be configured by software.

• Pin P1.5 is input only. Pins P1.2 and P1.3 are configurable for either input-only or

open drain.

UM10108

P89LPC924/925 User manual

Figure 10).

0 by any instruction that accesses the

Every output on the P89LPC924/925 has been designed to sink typical LED drive current. However, there is a maximum total output current for all ports which must not be exceeded. Please refer to the

All ports pins that can function as an output have slew rate controlled outputs to limit noise generated by quickly switching output signals. The slew rate is factory-set to approximately 10 ns rise and fall times.

Table 22: Port output configuration

Port pin Configuration SFR bits

PxM1.y PxM2.y Alternate usage Notes

P0.0 P0M1.0 P0M2.0 KBIO, CMP2

P0.1 P0M1.1 P0M2.1 KBI1, CIN2B, AD10 Refer to Section 5.6 “Port 0

P0.2 P0M1.2 P0M2.2 KBI2, CIN2A, AD11

P0.3 P0M1.3 P0M2.3 KBI3, CIN1B, AD12

P0.4 P0M1.4 P0M2.4 KBI4, CIN1A, AD13,

P0.5 P0M1.5 P0M2.5 KBI5, CMPREF

P0.6 P0M1.6 P0M2.6 KBI6, CMP1

P0.7 P0M1.7 P0M2.7 KBI7, T1

P1.0 P1M1.0 P1M2.0 TXD

P1.1 P1M1.1 P1M2.1 RXD

P1.2 P1M1.2 P1M2.2 T0, SCL Input-only or open-drain

P1.3 P1M1.3 P1M2.3 INTO, SDA input-only or open-drain

P1.4 P1M1.4 P1M2.4 INT1

P1.5 P1M1.5 P1M2.5 RST

P1.6 P1M1.6 P1M2.6

P89LPC924/925 data sheet for detailed specifications.

analog functions” for usage as

analog inputs.

DAC1

User manual Rev. 02 — 2 March 2005 30 of 105

Philips Semiconductors

Table 22: Port output configuration

Port pin Configuration SFR bits

PxM1.y PxM2.y Alternate usage Notes

P1.7 P1M1.7 P1M2.7

P3.0 P3M1.0 P3M2.0 CLKOUT, XTAL2

P3.1 P3M1.1 P3M2.1 XTAL1

6. Power monitoring functions

The P89LPC924/925 incorporates power monitoring functions designed to prevent incorrect operation during initial power-on and power loss or reduction during operation. This is accomplished with two hardware functions: Power-on Detect and Brownout Detect.

6.1 Brownout detection

The Brownout Detect function determines if the power supply voltage drops below a certain level. The default operation for a Brownout Detection is to cause a processor reset. However, it may alternatively be configured to generate an interrupt by setting the BOI (PCON.4) bit and the EBO (IEN0.5) bit.

UM10108

P89LPC924/925 User manual

Enabling and disabling of Brownout Detection is done via the BOPD (PCON.5) bit, bit field PMOD1-0 (PCON.1-0) and user configuration bit BOE (UCFG1.5). If BOE is in an unprogrammed state, brownout is disabled regardless of PMOD1-0 and BOPD. If BOE is in a programmed state, PMOD1-0 and BOPD will be used to determine whether Brownout Detect will be disabled or enabled. PMOD1-0 is used to select the power reduction mode. If PMOD1-0 = ‘11’, the circuitry for the Brownout Detection is disabled for lowest power consumption. BOPD defaults to logic power-on if BOE is programmed.

If Brownout Detection is enabled, the brownout condition occurs when VDD falls below the Brownout trip voltage, V when V supply that can be below 2.7 device can operate at 2.4 from operating.

If Brownout Detect is enabled (BOE programmed, PMOD1-0 ≠ ‘11’, BOPD = 0), BOF (RSTSRC.5) will be set when a brownout is detected, regardless of whether a reset or an interrupt is enabled. BOF will stay set until it is cleared in software by writing logic bit. Note that if BOE is unprogrammed, BOF is meaningless. If BOE is programmed, and a initial power-on occurs, BOF will be set in addition to the power-on flag (POF RSTSRC.4).

For correct activation of Brownout Detect, certain VDD rise and fall times must be observed. Please see the data sheet for specifications.

rises above VBO. If the P89LPC924/925 device is to operate with a power

0, indicating brownout detection is enabled on

(see P89LPC924/925 Static Characteristics), and is negated

V, BOE should be left in the unprogrammed state so that the

V, otherwise continuous brownout reset may prevent the device

0 to the

User manual Rev. 02 — 2 March 2005 31 of 105

Philips Semiconductors

UM10108

P89LPC924/925 User manual

Table 23: Brownout options

BOE

(UCFG1.5)

0 (erased) XX X X X X Brownout disabled. VDD

1(program

med)

PMOD1-0

(PCON.1-0)

11 (total

power-down)

≠ 11 (any mode

other than total

power-down

[1]

BOPD

(PCON.5)

X X X X

1(brownout

detect

powered

down)

0 (brownout

detect active)

BOI

(PCON.4)

X X X Brownout disabled. VDD

0 (brownout

detect

generates

reset)

1 (brownout

detect

generates an

interrupt)

EBO

(IEN0.5)

X X Brownout reset enabled. VDD

1 (enable brownout interrupt)

0 X Both brownout reset and

X 0

EA (IEN0.7) Description

operating range is 2.4 V to 3.6 V.

operating range is 2.4 V to 3.6 V. However, BOPD is default to logic 0 upon power-up.

operating range is 2.7 V to 3.6 V. Upon a brownout reset, BOF (RSTSRC.5) will be set to indicate the reset source. BOF can be cleared by writing logic 0 to the bit.

1 (global

interrupt

enable)

Brownout interrupt enabled. VDD operating range is 2.7 V to 3.6 V. Upon a brownout interrupt, BOF (RSTSRC.5) will be set. BOF can be cleared by writing logic 0 to the bit.

interrupt disabled. VDD operating range is 2.4 V to 3.6 V. However, BOF (RSTSRC.5) will be set when V Detection trip point. BOF can be cleared by writing logic 0 to the bit.

falls to the Brownout

[1] Cannot be used with operation above 12 MHz as this requires VDD of 3.0 V or above.

6.2 Power-on detection

The Power-On Detect has a function similar to the Brownout Detect, but is designed to work as power initially comes up, before the power supply voltage reaches a level where the Brownout Detect can function. The POF flag (RSTSRC.4) is set to indicate an initial power-on condition. The POF flag will remain set until cleared by software by writing logic

0 to the bit. Note that if BOE (UCFG1.5) is programmed, BOF (RSTSRC.5) will be

set when POF is set. If BOE is unprogrammed, BOF is meaningless.

6.3 Power reduction modes

The P89LPC924/925 supports three different power reduction modes as determined by SFR bits PCON.1-0 (see

User manual Rev. 02 — 2 March 2005 32 of 105

Ta bl e 24).

Philips Semiconductors

P89LPC924/925 User manual

Table 24: Power reduction modes

PMOD1 (PCON.1)

0 0 Normal mode (default) - no power reduction.

0 1 Idle mode. The Idle mode leaves peripherals running in order to allow them to activate the

1 0 Power-down mode:

PMOD0 (PCON.0)

Description

processor when an interrupt is generated. Any enabled interrupt source or reset may terminate Idle mode.

The Power-down mode stops the oscillator in order to minimize power consumption.

The P89LPC924/925 exits Power-down mode via any reset, or certain interrupts - external pins INT0/INT1, brownout Interrupt, keyboard, Real-time Clock/System Timer), Watchdog, and comparator trips. Waking up by reset is only enabled if the corresponding reset is enabled, and waking up by interrupt is only enabled if the corresponding interrupt is enabled and the EA SFR bit (IEN0.7) is set. External interrupts should be programmed to level-triggered mode to be used to exit Power-down mode.

In Power-down mode the internal RC oscillator is disabled unless both the RC oscillator has been selected as the system clock AND the RTC is enabled.

In Power-down mode, the power supply voltage may be reduced to the RAM keep-alive voltage VRAM. This retains the RAM contents at the point where Power-down mode was entered. SFR contents are not guaranteed after VDD has been lowered to VRAM, therefore it is recommended to wake up the processor via Reset in this situation. V before the Power-down mode is exited.

When the processor wakes up from Power-down mode, it will start the oscillator immediately and begin execution when the oscillator is stable. Oscillator stability is determined by counting 1024 CPU clocks after start-up when one of the crystal oscillator configurations is used, or 256 clocks after start-up for the internal RC or external clock input configurations.

Some chip functions continue to operate and draw power during Power-down mode, increasing the total power used during power-down. These include:

must be raised to within the operating range

UM10108

• Brownout Detect

• Watchdog timer if WDCLK (WDCON.0) is logic 1

• Comparators (Note: Comparators can be powered down separately with PCONA.5 set to

logic 1 and comparators disabled)

• Real-time Clock/System Timer (and the crystal oscillator circuitry if this block is using it, unless

RTCPD, i.e., PCONA.7 is logic

1 1 Total Power-down mode: This is the same as Power-down mode except that the Brownout

Detection circuitry and the voltage comparators are also disabled to conserve additional power. Note that a brownout reset or interrupt will not occur. Voltage comparator interrupts and Brownout interrupt cannot be used as a wake-up source. The internal RC oscillator is disabled unless both the RC oscillator has been selected as the system clock AND the RTC is enabled.

The following are the wake-up options supported:

• Watchdog timer if WDCLK (WDCON.0) is logic 1. Could generate Interrupt or Reset, either one

can wake up the device

• External interrupts INTO/INT1 (when programmed to level-triggered mode)

• Keyboard Interrupt

• Real-time Clock/System Timer (and the crystal oscillator circuitry if this block is using it, unless

RTCPD, i.e., PCONA.7 is logic

Note: Using the internal RC-oscillator to clock the RTC during power-down may result in relatively high power consumption. Lower power consumption can be achieved by using an external low frequency clock when the Real-time Clock is running during power-down.

User manual Rev. 02 — 2 March 2005 33 of 105

Philips Semiconductors

P89LPC924/925 User manual

Table 25: Power Control register (PCON - address 87h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol SMOD1 SMOD0 BOPD BOI GF1 GF0 PMOD1 PMOD0

Reset 0 0 0 0 0 0 0 0

Table 26: Power Control register (PCON - address 87h) bit description

Bit Symbol Description

0 PMOD0 Power Reduction Mode (see Section 6.3)

1 PMOD1

2 GF0 General Purpose Flag 0. May be read or written by user software, but has no effect

on operation

3 GF1 General Purpose Flag 1. May be read or written by user software, but has no effect

on operation

4 BOI Brownout Detect Interrupt Enable. When logic 1, Brownout Detection will generate a

interrupt. When logic 0, Brownout Detection will cause a reset

5 BOPD Brownout Detect power-down. When logic 1, Brownout Detect is powered down and

therefore disabled. When logic be logic 0 before any programming or erasing commands can be issued. Otherwise these commands will be aborted.)

6 SMOD0 Framing Error Location:

0, Brownout Detect is enabled. (Note: BOPD must

UM10108

• When logic 0, bit 7 of SCON is accessed as SM0 for the UART

• When logic 1, bit 7 of SCON is accessed as the framing error status (FE) for the

UART

7 SMOD1 Double Baud Rate bit for the serial port (UART) when Timer 1 is used as the baud

rate source. When logic logic 0, the Timer 1 overflow rate is divided by two before being supplied to the UART. (See Section 10)

1, the Timer 1 overflow rate is supplied to the UART. When

Table 27: Power Control register A (PCONA - address B5h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol RTCPD - VCPD - I2PD - SPD -

Reset 0 0 0 0 0 0 0 0

Table 28: Power Control register A (PCONA - address B5h) bit description

Bit Symbol Description

0 - reserved

1 SPD Serial Port (UART) power-down: When logic 1, the internal clock to the UART is

disabled. Note that in either Power-down mode or Total Power-down mode, the UART clock will be disabled regardless of this bit.

2 - reserved

3 I2PD I2C power-down: When logic 1, the internal clock to the I2C-bus is disabled. Note

that in either Power-down mode or Total Power-down mode, the I disabled regardless of this bit.

4 - reserved

User manual Rev. 02 — 2 March 2005 34 of 105

C clock will be

Philips Semiconductors

P89LPC924/925 User manual

Table 28: Power Control register A (PCONA - address B5h) bit description

Bit Symbol Description

5 VCPD Analog Voltage Comparators power-down: When logic 1, the voltage comparators

are powered down. User must disable the voltage comparators prior to setting this bit.

6 - reserved

7 RTCPD Real-time Clock power-down: When logic 1, the internal clock to the Real-time

Clock is disabled.

UM10108

7. Reset

The P1.5/RST pin can function as either an active LOW reset input or as a digital input, P1.5. The RPE (Reset Pin Enable) bit in UCFG1, when set to 1, enables the external reset input function on P1.5. When cleared, P1.5 may be used as an input pin. When using an

oscillator frequency above 12 enabled. An external circuit is required to hold the device in reset at powerup until V

has reached its specified level. When system power is removed VDD will fall

below the minimum specified operating voltage. When using an oscillator frequency above 12 may be required to hold the device in reset when V specified operating voltage.

MHz, in some applications, an external brownout detect circuit

MHz, the reset input function of P1.5 must be

falls below the minimum

NOTE: During a power-on sequence, The RPE selection is overridden and this pin will always functions as a reset input. An external circuit connected to this pin should not hold this pin LOW during a Power-on sequence as this will keep the device in reset. After power-on this input will function either as an external reset input or as a digital input as defined by the RPE bit. Only a power-on reset will temporarily override the selection defined by RPE bit. Other sources of reset will not override the RPE bit.

NOTE: During a power cycle, VDD must fall below V Static characteristics) before power is reapplied, in order to ensure a power-on reset.

Reset can be triggered from the following sources (see Figure 12):

(see P89LPC924/925 data sheet,

POR

• External reset pin (during power-on or if user configured via UCFG1)

• Power-on Detect

• Brownout Detect

• Watchdog timer

• Software reset

• UART break detect reset

For every reset source, there is a flag in the Reset Register, RSTSRC. The user can read this register to determine the most recent reset source. These flag bits can be cleared in software by writing a logic

0 to the corresponding bit. More than one flag bit may be set:

• During a power-on reset, both POF and BOF are set but the other flag bits are

cleared.

• For any other reset, any previously set flag bits that have not been cleared will remain

set.

User manual Rev. 02 — 2 March 2005 35 of 105

Philips Semiconductors

UM10108

P89LPC924/925 User manual

RPE (UCFG1.6)

RST pin

WDTE (UCFG1.7)

Watchdog timer reset

Software reset SRST (AUXR1.3)

Power-on detect

UART break detect

EBRR (AUXR1.6)

Brownout detect reset

BOPD (PCON.5)

Fig 12. Block diagram of reset.

Table 29: Reset Sources register (RSTSRC - address DFh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol - - BOF POF R_BK R_WD R_SF R_EX

[1]

Reset

[1] The value shown is for a power-on reset. Other reset sources will set their corresponding bits.

Table 30: Reset Sources register (RSTSRC - address DFh) bit description

Bit Symbol Description

0 R_EX external reset Flag. When this bit is logic 1, it indicates external pin reset. Cleared by software by writing a

1 R_SF software reset Flag. Cleared by software by writing a logic 0 to the bit or a Power-on reset

2 R_WD Watchdog timer reset flag. Cleared by software by writing a logic 0 to the bit or a Power-on reset.(NOTE:

3 R_BK break detect reset. If a break detect occurs and EBRR (AUXR1.6) is set to logic 1, a system reset will occur.

4 POF Power-on Detect Flag. When Power-on Detect is activated, the POF flag is set to indicate an initial power-up

5 BOF Brownout Detect Flag. When Brownout Detect is activated, this bit is set. It will remain set until cleared by

6:7 - reserved

x x 1 1 0 0 0 0

logic 0 to the bit or a Power-on reset. If RST is still asserted after the Power-on reset is over, R_EX will be set.

UCFG1.7 must be = 1)

This bit is set to indicate that the system reset is caused by a break detect. Cleared by software by writing a

0 to the bit or on a Power-on reset.

logic

condition. The POF flag will remain set until cleared by software by writing a logic Power-on reset, both BOF and this bit will be set while the other flag bits are cleared.)

software by writing a logic other flag bits are cleared.)

0 to the bit. (Note: On a Power-on reset, both POF and this bit will be set while the

0 to the bit. (Note: On a

chip reset

002aaa91

7.1 Reset vector

Following reset, the P89LPC924/925 will fetch instructions from either address 0000h or the Boot address. The Boot address is formed by using the Boot Vector as the HIGH byte of the address and the LOW byte of the address = 00h. The Boot address will be used if a

User manual Rev. 02 — 2 March 2005 36 of 105

Philips Semiconductors

UART break reset occurs or the non-volatile Boot Status bit (BOOTSTAT.0) = 1, or the device has been forced into ISP mode. Otherwise, instructions will be fetched from address 0000H.

8. Timers 0 and 1

The P89LPC924/925 has two general-purpose counter/timers which are upward compatible with the 80C51 Timer 0 and Timer 1. Both can be configured to operate either as timers or event counters (see upon timer overflow has been added.

In the ‘Timer’ function, the timer is incremented every PCLK.

In the ‘Counter’ function, the register is incremented in response to a 1-to-0 transition on its corresponding external input pin (T0 or T1). The external input is sampled once during every machine cycle. When the pin is HIGH during one cycle and LOW in the next cycle, the count is incremented. The new count value appears in the register during the cycle following the one in which the transition was detected. Since it takes 2 machine cycles (4 CPU clocks) to recognize a 1-to-0 transition, the maximum count rate is clock frequency. There are no restrictions on the duty cycle of the external input signal, but to ensure that a given level is sampled at least once before it changes, it should be held for at least one full machine cycle.

UM10108

P89LPC924/925 User manual

Ta bl e 32). An option to automatically toggle the TX pin

⁄4 of the CPU

The ‘Timer’ or ‘Counter’ function is selected by control bits TnC/T (x = 0 and 1 for Timers 0 and 1 respectively) in the Special Function Register TMOD. Timer 0 and Timer 1 have five operating modes (modes 0, 1, 2, 3 and 6), which are selected by bit-pairs (TnM1, TnM0) in TMOD and TnM2 in TAMOD. Modes 0, 1, 2 and 6 are the same for both Timers/Counters. Mode 3 is different. The operating modes are described later in this section.

Table 31: Timer/Counter Mode register (TMOD - address 89h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol T1GATE T1C/T T1M1 T1M0 T0GATE T0C/T T0M1 T0M0

Reset 0 0 0 0 0 0 0 0

Table 32: Timer/Counter Mode register (TMOD - address 89h) bit description

Bit Symbol Description

0 T0M0 Mode Select for Timer 0. These bits are used with the T0M2 bit in the TAMOD register to determine the

1 T0M1

2 T0C/T Timer or Counter selector for Timer 0. Cleared for Timer operation (input from CCLK). Set for Counter

3 T0GATE Gating control for Timer 0. When set, Timer/Counter is enabled only while the INT0 pin is HIGH and the TR0

4 T1M0 Mode Select for Timer 1. These bits are used with the T1M2 bit in the TAMOD register to determine the

5 T1M1

6 T1C/T Timer or Counter Selector for Timer 1. Cleared for Timer operation (input from CCLK). Set for Counter

7 T1GATE Gating control for Timer 1. When set, Timer/Counter is enabled only while the INT1 pin is HIGH and the TR1

Timer 0 mode (see

operation (input from T0 input pin).

control pin is set. When cleared, Timer 0 is enabled when the TR0 control bit is set.

Timer 1 mode (see

operation (input from T1 input pin).

control pin is set. When cleared, Timer 1 is enabled when the TR1 control bit is set.

Ta bl e 34).

User manual Rev. 02 — 2 March 2005 37 of 105

Philips Semiconductors

P89LPC924/925 User manual

Table 33: Timer/Counter Auxiliary Mode register (TAMOD - address 8Fh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol -- - - T1M2 - - - T0M2

Reset x x x 0 x x x 0

Table 34: Timer/Counter Auxiliary Mode register (TAMOD - address 8Fh) bit description

Bit Symbol Description

0 T0M2 Mode Select for Timer 0. These bits are used with the T0M2 bit in the TAMOD register to determine the

Timer 0 mode (see

1:3 - reserved

4 T1M2 Mode Select for Timer 1. These bits are used with the T1M2 bit in the TAMOD register to determine the

Timer 1 mode (see Ta b le 34).

The following timer modes are selected by timer mode bits TnM[2:0]:

000 — 8048 Timer ‘TLn’ serves as 5-bit prescaler. (Mode 0).

001 — 16-bit Timer/Counter ‘THn’ and ‘TLn’ are cascaded; there is no prescaler.(Mode 1).

010 — 8-bit auto-reload Timer/Counter. THn holds a value which is loaded into TLn when it overflows.

(Mode 2).

011 — Timer 0 is a dual 8-bit Timer/Counter in this mode. TL0 is an 8-bit Timer/Counter controlled by the standard Timer 0 control bits. TH0 is an 8-bit timer only, controlled by the Timer 1 control bits (see text). Timer 1 in this mode is stopped. (Mode 3).

100 — Reserved. User must not configure to this mode.

101 — Reserved. User must not configure to this mode.

110 — PWM mode (see Section 8.5).

111 — Reserved. User must not configure to this mode.

5:7 - reserved

Ta bl e 34).

UM10108

8.1 Mode 0

Putting either Timer into Mode 0 makes it look like an 8048 Timer, which is an 8-bit Counter with a divide-by-32 prescaler.

In this mode, the Timer register is configured as a 13-bit register. As the count rolls over from all logic enabled to the Timer when TRn = 1 and either TnGATE = 0 or TnGATE width measurements). TRn is a control bit in the Special Function Register TCON (

Ta bl e 36). The TnGATE bit is in the TMOD register.

The 13-bit register consists of all 8 bits of THn and the lower 5 bits of TLn. The upper 3

bits of TLn are indeterminate and should be ignored. Setting the run flag (TRn) does not

clear the registers.

Mode 0 operation is the same for Timer 0 and Timer 1. See Figure 13. There are two different GATE bits, one for Timer 1 (TMOD.7) and one for Timer 0 (TMOD.3).

1s to all logic 0s, it sets the Timer interrupt flag TFn. The count input is

= 1 allows the Timer to be controlled by external input INTn, to facilitate pulse

Figure 13 shows Mode 0 operation.

INTn = 1. (Setting

8.2 Mode 1

Mode 1 is the same as Mode 0, except that all 16 bits of the timer register (THn and TLn) are used. See

Figure 14.

User manual Rev. 02 — 2 March 2005 38 of 105

Philips Semiconductors

8.3 Mode 2

Mode 2 configures the Timer register as an 8-bit Counter (TLn) with automatic reload, as shown in contents of THn, which must be preset by software. The reload leaves THn unchanged. Mode 2 operation is the same for Timer 0 and Timer 1.

8.4 Mode 3

When Timer 1 is in Mode 3 it is stopped. The effect is the same as setting TR1 = 0.

Timer 0 in Mode 3 establishes TL0 and TH0 as two separate 8-bit counters. The logic for Mode 3 on Timer 0 is shown in T0GATE, TR0, INT0, and TF0. TH0 is locked into a timer function (counting machine cycles) and takes over the use of TR1 and TF1 from Timer 1. Thus, TH0 now controls the ‘Timer 1’ interrupt.

Mode 3 is provided for applications that require an extra 8-bit timer. With Timer 0 in Mode 3, an

P89LPC924/925 device can look like it has three Timer/Counters.

Note: When Timer 0 is in Mode 3, Timer 1 can be turned on and off by switching it into and out of its own Mode 3. It can still be used by the serial port as a baud rate generator, or in any application not requiring an interrupt.

UM10108

P89LPC924/925 User manual

Figure 15. Overflow from TLn not only sets TFn, but also reloads TLn with the

Figure 16. TL0 uses the Timer 0 control bits: T0C/T,

8.5 Mode 6

In this mode, the corresponding timer can be changed to a PWM with a full period of 256 timer clocks (see

Figure 17). Its structure is similar to mode 2, except that:

• TFn (n = 0 and 1 for Timers 0 and 1 respectively) is set and cleared in hardware

• The LOW period of the TFn is in THn, and should be between 1 and 254, and

• The HIGH period of the TFn is always 256 − THn

• Loading THn with 00h will force the TX pin HIGH, loading THn with FFh will force the

TX pin LOW

Note that interrupt can still be enabled on the LOW to HIGH transition of TFn, and that TFn can still be cleared in software like in any other modes.

Table 35: Timer/Counter Control register (TCON) - address 88h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol TF1 TR1 TF0 TR0 IE1 IT1 IE0 IT0

Reset 0 0 0 0 0 0 0 0

Table 36: Timer/Counter Control register (TCON - address 88h) bit description

Bit Symbol Description

0 IT0 Interrupt 0 Type control bit. Set/cleared by software to specify falling edge/LOW level triggered external

interrupts.

1 IE0 Interrupt 0 Edge flag. Set by hardware when external interrupt 0 edge is detected. Cleared by hardware

when the interrupt is processed, or by software.

2 IT1 Interrupt 1 Type control bit. Set/cleared by software to specify falling edge/LOW level triggered external

interrupts.

User manual Rev. 02 — 2 March 2005 39 of 105

Philips Semiconductors

UM10108

P89LPC924/925 User manual

Table 36: Timer/Counter Control register (TCON - address 88h) bit description

Bit Symbol Description

3 IE1 Interrupt 1 Edge flag. Set by hardware when external interrupt 1 edge is detected. Cleared by hardware

when the interrupt is processed, or by software.

4 TR0 Timer 0 Run control bit. Set/cleared by software to turn Timer/Counter 0 on/off.

5 TF0 Timer 0 overflow flag. Set by hardware on Timer/Counter overflow. Cleared by hardware when the processor

vectors to the interrupt routine, or by software. (except in mode 6, where it is cleared in hardware)

6 TR1 Timer 1 Run control bit. Set/cleared by software to turn Timer/Counter 1 on/off

7 TF1 Timer 1 overflow flag. Set by hardware on Timer/Counter overflow. Cleared by hardware when the interrupt

is processed, or by software (except in mode 6, see above, when it is cleared in hardware).

PCLK

Tn pin

TRn

Gate

INTn pin

C/T = 0

C/T = 1

control

Fig 13. Timer/counter 0 or 1 in Mode 0 (13-bit counter).

PCLK

Tn pin

TRn

Gate

INTn pin

C/T = 0

C/T = 1

control

Fig 14. Timer/counter 0 or 1 in mode 1 (16-bit counter).

TLn

(5-bits)

TLn

(8-bits)

THn

(8-bits)

THn

(8-bits)

overflow

toggle

overflow

toggle

TFn

ENTn

002aaa919

TFn

ENTn

002aaa920

interrupt

Tn pin

interrupt

Tn pin

PCLK

Tn pin

TRn

Gate

INTn pin

C/T = 0

C/T = 1

control

TLn

(8-bits)

THn

(8-bits)

reload

overflow

toggle

TFn

ENTn

002aaa921

interrupt

Tn pin

Fig 15. Timer/counter 0 or 1 in Mode 2 (8-bit auto-reload).

User manual Rev. 02 — 2 March 2005 40 of 105

Philips Semiconductors

UM10108

P89LPC924/925 User manual

PCLK

T0 pin

TR0

Gate

INT0 pin

C/T = 0

C/T = 1

Osc/2

TR1

control

Fig 16. Timer/counter 0 Mode 3 (two 8-bit counters).

PCLK

TRn

Gate

INTn pin

C/T = 0

control

TL0

(8-bits)

TH0

(8-bits)

overflow

toggle

overflow

toggle

TLn

THn

overflow

reload THn on falling transition

and (256-THn) on rising transition

toggle

TF0

ENT0

(AUXR1.4)

TF1

ENT1

(AUXR1.5)

TFn

ENTn

interrupt

T0 pin

(P1.2 open drain)

interrupt

T1 pin (P0.7)

002aaa92

interrupt

Tn pin

002aaa923

Fig 17. Timer/counter 0 or 1 in mode 6 (PWM auto-reload).

8.6 Timer overflow toggle output

Timers 0 and 1 can be configured to automatically toggle a port output whenever a timer overflow occurs. The same device pins that are used for the T0 and T1 count inputs and PWM outputs are also used for the timer toggle outputs. This function is enabled by control bits ENT0 and ENT1 in the AUXR1 register, and apply to Timer 0 and Timer 1 respectively. The port outputs will be a logic 1 prior to the first timer overflow when this mode is turned on. In order for this mode to function, the C/

T bit must be cleared selecting

PCLK as the clock source for the timer.

9. Real-time clock system timer

The P89LPC924/925 has a simple Real-time Clock/System Timer that allows a user to continue running an accurate timer while the rest of the device is powered down. The Real-time Clock can be an interrupt or a wake-up source (see

User manual Rev. 02 — 2 March 2005 41 of 105

Figure 18).

Philips Semiconductors

The Real-time Clock is a 23-bit down counter. The clock source for this counter can be either the CPU clock (CCLK) or the XTAL1-2 oscillator, provided that the XTAL1-2 oscillator is not being used as the CPU clock. If the XTAL1-2 oscillator is used as the CPU clock, then the RTC will use CCLK as its clock source regardless of the state of the RTCS1:0 in the RTCCON register. There are three SFRs used for the RTC:

RTCCON — Real-time Clock control.

RTCH — Real-time Clock counter reload HIGH (bits [22:15]).

RTCL — Real-time Clock counter reload LOW (bits [14:7]).

The Real-time clock system timer can be enabled by setting the RTCEN (RTCCON.0) bit. The Real-time Clock is a 23-bit down counter (initialized to all 0’s when RTCEN = 0) that is comprised of a 7-bit prescaler and a 16-bit loadable down counter. When RTCEN is written with logic count down. When it reaches all 0’s, the counter will be reloaded again with (RTCH, RTCL, ‘1111111’) and a flag - RTCF (RTCCON.7) - will be set.

UM10108

P89LPC924/925 User manual

1, the counter is first loaded with (RTCH, RTCL, ‘1111111’) and will

Power-on

reset

RTCH RTCL RTC Reset

Reload on underflow

MSB LSB

23-bit down counter

Wake-up from power-down

Interrupt if enabled (shared with WDT)

Fig 18. Real-time clock/system timer block diagram.

ERTC

RTCF

RTC underflow flag

9.1 Real-time clock source

RTCS1-0 (RTCCON[6:5]) are used to select the clock source for the RTC if either the Internal RC oscillator or the internal WD oscillator is used as the CPU clock. If the internal crystal oscillator or the external clock input on XTAL1 is used as the CPU clock, then the RTC will use CCLK as its clock source.

9.2 Changing RTCS1-0

7-bit prescaler

128

RTCEN

RTC enable

XTAL2 XTAL1

LOW FREQ. MED. FREQ.

HIGH FREQ.

CCLK

internal

oscillators

RTCS1 RTCS2

RTC clk select

002aaa92

RTCS1-0 cannot be changed if the RTC is currently enabled (RTCCON.0 = 1). Setting RTCEN and updating RTCS1-0 may be done in a single write to RTCCON. However, if RTCEN = 1, this bit must first be cleared before updating RTCS1-0.

User manual Rev. 02 — 2 March 2005 42 of 105

Philips Semiconductors

P89LPC924/925 User manual

UM10108

9.3 Real-time clock interrupt/wake-up

If ERTC (RTCCON.1), EWDRT (IEN1[6:0]) and EA (IEN0.7) are set to logic 1, RTCF can be used as an interrupt source. This interrupt vector is shared with the Watchdog timer. It can also be a source to wake up the device.

9.4 Reset sources affecting the Real-time clock

Only power-on reset will reset the Real-time Clock and its associated SFRs to their default state.

Table 37: Real-time Clock/System Timer clock sources

RTCS1 (RTCCON.6)

x x 0 0 CCLK 0 High frequency crystal

x x 0 0 1 CCLK Medium frequency

x x 0 1 0 Low frequency

0 0 0 1 1 High

0 1 Medium

1 0 Low frequency

1 1 CCLK

0 0 1 0 0 High

0 1 Medium

1 0 Low frequency

1 1 CCLK

x x 0 1 1 undefined undefined

x x 1 1 0 undefined undefined

x x 1 1 1 CCLK External clock input

RTCS0 (RTCCON.5)

FOSC2 (UCFG1.2)

FOSC1 (UCFG1.1)

FOSC0 (UCFG1.0)

RTCS1 (RTCCON.6)

crystal

frequency crystal

crystal

frequency crystal

crystal

CPU clock source

crystal

CCLK

Internal RC oscillator

Watchdog oscillator

Table 38: Real-time Clock Control register (RTCCON - address D1h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol RTCF RTCS1 RTCS0 - - - ERTC RTCEN

Reset 0 1 1 x x x 0 0

User manual Rev. 02 — 2 March 2005 43 of 105

Philips Semiconductors

P89LPC924/925 User manual

Table 39: Real-time Clock Control register (RTCCON - address D1h) bit description

Bit Symbol Description

0 RTCEN Real-time Clock enable. The Real-time Clock will be enabled if this bit is logic 1. Note that this bit will not

power-down the Real-time Clock. The RTCPD bit (PCONA.7) if set, will power-down and disable this block regardless of RTCEN.

1 ERTC Real-time Clock interrupt enable. The Real-time Clock shares the same interrupt as the Watchdog timer.

Note that if the user configuration bit WDTE (UCFG1.7) is logic 0, the Watchdog timer can be enabled to generate an interrupt. Users can read the RTCF (RTCCON.7) bit to determine whether the Real-time Clock caused the interrupt.

2:4 - reserved

5 RTCS0 Real-time Clock source select (see Ta bl e 37).

6 RTCS1

7 RTCF Real-time Clock Flag. This bit is set to logic 1 when the 23-bit Real-time Clock reaches a count of logic 0. It

can be cleared in software.

UM10108

10. UART

The P89LPC924/925 has an enhanced UART that is compatible with the conventional 80C51 UART except that Timer 2 overflow cannot be used as a baud rate source. The P89LPC924/925 does include an independent Baud Rate Generator. The baud rate can be selected from the oscillator (divided by a constant), Timer 1 overflow, or the independent Baud Rate Generator. In addition to the baud rate generation, enhancements over the standard 80C51 UART include Framing Error detection, break detect, automatic address recognition, selectable double buffering and several interrupt options.

The UART can be operated in four modes, as described in the following sections.

10.1 Mode 0

Serial data enters and exits through RXD. TXD outputs the shift clock. 8 bits are transmitted or received, LSB first. The baud rate is fixed at

10.2 Mode 1

10 bits are transmitted (through TXD) or received (through RXD): a start bit (logic 0), 8 data bits (LSB first), and a stop bit (logic 1). When data is received, the stop bit is stored in RB8 in Special Function Register SCON. The baud rate is variable and is determined by the Timer 1 overflow rate or the Baud Rate Generator (see

generator and selection”).

10.3 Mode 2

11 bits are transmitted (through TXD) or received (through RXD): start bit (logic 0), 8 data bits (LSB first), a programmable 9th data bit, and a stop bit (logic 1). When data is transmitted, the 9th data bit (TB8 in SCON) can be assigned the value of 0 or 1. Or, for example, the parity bit (P, in the PSW) could be moved into TB8. When data is received, the 9th data bit goes into RB8 in Special Function Register SCON and the stop bit is not saved. The baud rate is programmable to either determined by the SMOD1 bit in PCON.

⁄16 of the CPU clock frequency.

Section 10.6 “Baud Rate

⁄16 or 1⁄32 of the CCLK frequency, as

User manual Rev. 02 — 2 March 2005 44 of 105

Philips Semiconductors

10.4 Mode 3

11 bits are transmitted (through TXD) or received (through RXD): a start bit (logic 0), 8 data bits (LSB first), a programmable 9th data bit, and a stop bit (logic 1). Mode 3 is the same as Mode 2 in all respects except baud rate. The baud rate in Mode 3 is variable and is determined by the Timer 1 overflow rate or the Baud Rate Generator (see

“Baud Rate generator and selection” on page 45).

In all four modes, transmission is initiated by any instruction that uses SBUF as a destination register. Reception is initiated in Mode 0 by the condition RI = 0 and REN = 1. Reception is initiated in the other modes by the incoming start bit if REN = 1.

10.5 SFR space

The UART SFRs are at the following locations shown in Tab l e 40.

Table 40: UART SFR addresses

PCON Power Cont rol 87H

SCON Serial Port (UART) Control 98H

SBUF Serial Port (UART) Data Buffer 99H

SADDR Serial Port (UART) Address A9H

SADEN Serial Port (UART) Address Enable B9H

SSTAT Serial Port (UART) Status BAH

BRGR1 Baud Rate Generator Rate HIGH Byte BFH

BRGR0 Baud Rate Generator Rate LOW Byte BEH

BRGCON Baud Rate Generator Control BDH

UM10108

P89LPC924/925 User manual

Section 10.6

10.6 Baud Rate generator and selection

The P89LPC924/925 enhanced UART has an independent Baud Rate Generator. The baud rate is determined by a value programmed into the BRGR1 and BRGR0 SFRs. The UART can use either Timer 1 or the baud rate generator output as determined by BRGCON.2-1 (see (PCON.7) is set. The independent Baud Rate Generator uses CCLK.

Figure 19). Note that Timer T1 is further divided by 2 if the SMOD1 bit

10.7 Updating the BRGR1 and BRGR0 SFRs

The baud rate SFRs, BRGR1 and BRGR0 must only be loaded when the Baud Rate Generator is disabled (the BRGEN bit in the BRGCON register is logic loading of an interim value to the baud rate generator. (CAUTION: If either BRGR0 or BRGR1 is written when BRGEN = 1, the result is unpredictable.)

Table 41: UART baud rate generation.

SCON.7 (SM0)

0 0 X X CCLK/16

0 1 0 0 CCLK/(256 − TH1)64

User manual Rev. 02 — 2 March 2005 45 of 105

SCON.6 (SM1)

PCON.7 (SMOD1)

1 0 CCLK/(256 − TH1)32

X 1 CCLK/((BRGR1,BRGR0) + 16)

BRGCON.1 (SBRGS)

Receive/transmit baud rate for UART

0). This avoids the

Philips Semiconductors

UM10108

P89LPC924/925 User manual

Table 41: UART baud rate generation.

SCON.7 (SM0)

1 0 0 X CCLK/32

1 1 0 0 CCLK/(256 − TH1)64

Table 42: Baud Rate Generator Control register (BRGCON - address BDh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol -- - - - - - SBRGS BRGEN

Reset x x x x x x 0 0

Table 43: Baud Rate Generator Control register (BRGCON - address BDh) bit description

Bit Symbol Description

0 BRGEN Baud Rate Generator Enable. Enables the baud rate generator. BRGR1 and BRGR0 can only be written

1 SBRGS Select Baud Rate Generator as the source for baud rates to UART in modes 1 and 3 (see Tab l e 41 for

2:7 - reserved

SCON.6 (SM1)

when BRGEN = 0.

details)

PCON.7 (SMOD1)

1 X CCLK/16

1 0 CCLK/(256 − TH1)32

X 1 CCLK/((BRGR1,BRGR0) + 16)

BRGCON.1 (SBRGS)

Receive/transmit baud rate for UART

Timer 1 Overflow

(PCLK-based)

Baud Rate Generator

(CCLK-based)

Fig 19. Baud rate generation for UART (Modes 1, 3).

10.8 Framing error

A Framing error occurs when the stop bit is sensed as a logic 0. A Framing error is reported in the status register (SSTAT). In addition, if SMOD0 (PCON.6) is 1, framing errors can be made available in SCON.7. If SMOD0 is 0, SCON.7 is SM0. It is recommended that SM0 and SM1 (SCON.7-6) are programmed when SMOD0 is logic

10.9 Break detect

A break detect is reported in the status register (SSTAT). A break is detected when any 11 consecutive bits are sensed LOW. Since a break condition also satisfies the requirements for a framing error, a break condition will also result in reporting a framing error. Once a break condition has been detected, the UART will go into an idle state and remain in this idle state until a stop bit has been received. The break detect can be used to reset the device and force the device into ISP mode by setting the EBRR bit (AUXR1.6).

SMOD1 = 1

SMOD1 = 0

SBRGS = 0

Baud Rate Modes 1 and 3

SBRGS = 1

002aaa419

User manual Rev. 02 — 2 March 2005 46 of 105

Philips Semiconductors

P89LPC924/925 User manual

Table 44: Serial Port Control register (SCON - address 98h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol SM0/FE SM1 SM2 REN TB8 RB8 TI RI

Reset x x x x x x 0 0

Table 45: Serial Port Control register (SCON - address 98h) bit description

Bit Symbol Description

0 RI Receive interrupt flag. Set by hardware at the end of the 8th bit time in Mode 0, or approximately halfway

through the stop bit time in Mode 1. For Mode 2 or Mode 3, if SMOD0, it is set near the middle of the 9th data bit (bit 8). If SMOD0 = 1, it is set near the middle of the stop bit (see SM2 - SCON.5 - for exceptions). Must be cleared by software.

1 TI Transmit interrupt flag. Set by hardware at the end of the 8th bit time in Mode 0, or at the stop bit (see

description of INTLO bit in SSTAT register) in the other modes. Must be cleared by software.

2 RB8 The 9th data bit that was received in Modes 2 and 3. In Mode 1 (SM2 must be 0), RB8 is the stop bit that

was received. In Mode 0, RB8 is undefined.

3 TB8 The 9th data bit that will be transmitted in Modes 2 and 3. Set or clear by software as desired.

4 REN Enables serial reception. Set by software to enable reception. Clear by software to disable reception.

5 SM2 Enables the multiprocessor communication feature in Modes 2 and 3. In Mode 2 or 3, if SM2 is set to 1, then

Rl will not be activated if the received 9th data bit (RB8) is 0. In Mode 0, SM2 should be 0. In Mode 1, SM2 must be 0.

6 SM1 With SM0 defines the serial port mode, see Ta b le 46.

7 SM0/FE The use of this bit is determined by SMOD0 in the PCON register. If SMOD0 = 0, this bit is read and written

as SM0, which with SM1, defines the serial port mode. If SMOD0 = 1, this bit is read and written as FE (Framing Error). FE is set by the receiver when an invalid stop bit is detected. Once set, this bit cannot be cleared by valid frames but is cleared by software. (Note: UART mode bits SM0 and SM1 should be programmed when SMOD0 is logic 0 - default mode on any reset.)

UM10108

Table 46: Serial Port modes

SM0,SM1 UART mode UART baud rate

00 Mode 0: shift register CCLK/16 (default mode on any reset)

01 Mode 1: 8-bit UART Variable (see Tab l e 41)

10 Mode 2: 9-bit UART CCLK/32 or CCLK/16

11 Mode 3: 9-bit UART Variable (see Tab l e 41)

Table 47: Serial Port Status register (SSTAT - address BAh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol DBMOD INTLO CIDIS DBISEL FE BR OE STINT

Reset x x x x x x 0 0

User manual Rev. 02 — 2 March 2005 47 of 105

Philips Semiconductors

P89LPC924/925 User manual

Table 48: Serial Port Status register (SSTAT - address BAh) bit description

Bit Symbol Description

0 STINT Status Interrupt Enable. When set = 1, FE, BR, or OE can cause an interrupt. The interrupt used (vector

address 0023h) is shared with RI (CIDIS = 1) or the combined TI/RI (CIDIS = 0). When cleared = 0, FE, BR, OE cannot cause an interrupt. (Note: FE, BR, or OE is often accompanied by a RI, which will generate an interrupt regardless of the state of STINT). Note that BR can cause a break detect reset if EBRR (AUXR1.6) is set to logic

1 OE Overrun Error flag is set if a new character is received in the receiver buffer while it is still full (before the

software has read the previous character from the buffer), i.e., when bit 8 of a new byte is received while RI in SCON is still set. Cleared by software.

2 BR Break Detect flag. A break is detected when any 11 consecutive bits are sensed LOW. Cleared by software.

3 FE Framing error flag is set when the receiver fails to see a valid STOP bit at the end of the frame. Cleared by

software.

4 DBISEL Double buffering transmit interrupt select. Used only if double buffering is enabled. This bit controls the

number of interrupts that can occur when double buffering is enabled. When set, one transmit interrupt is generated after each character written to SBUF, and there is also one more transmit interrupt generated at the beginning (INTLO = 0) or the end (INTLO = 1) of the STOP bit of the last character sent (i.e., no more data in buffer). This last interrupt can be used to indicate that all transmit operations are over. When cleared = 0, only one transmit interrupt is generated per character written to SBUF. Must be logic 0 when double buffering is disabled. Note that except for the first character written (when buffer is empty), the location of the transmit interrupt is determined by INTLO. When the first character is written, the transmit interrupt is generated immediately after SBUF is written.

5 CIDIS Combined Interrupt Disable. When set = 1, RX and TX interrupts are separate. When cleared = 0, the UART

uses a combined TX/RX interrupt (like a conventional 80C51 UART). This bit is reset to logic combined interrupts.

6 INTLO Transmit interrupt position. When cleared = 0, the TX interrupt is issued at the beginning of the stop bit.

When set = 1, the TX interrupt is issued at end of the stop bit. Must be logic 0 for mode 0. Note that in the case of single buffering, if the TX interrupt occurs at the end of a STOP bit, a gap may exist before the next start bit.

7 DBMOD Double buffering mode. When set = 1 enables double buffering. Must be logic 0 for UART mode 0. In order

to be compatible with existing 80C51 devices, this bit is reset to logic 0 to disable double buffering.

UM10108

0 to select

10.10 More about UART Mode 0

In Mode 0, a write to SBUF will initiate a transmission. At the end of the transmission, TI (SCON.1) is set, which must be cleared in software. Double buffering must be disabled in this mode.

Reception is initiated by clearing RI (SCON.0). Synchronous serial transfer occurs and RI will be set again at the end of the transfer. When RI is cleared, the reception of the next character will begin. Refer to

User manual Rev. 02 — 2 March 2005 48 of 105

Figure 20.

Philips Semiconductors

S1 ... S16 S1 ... S16 S1 ... S16 S1 ... S16S1 ... S16S1 ... S16 S1 ... S16 S1 ... S16 S1 ... S16 S1 ... S16S1 ... S16S1 ... S16 S1 ... S16

write to

SBUF

shift

RXD (data out)

TXD (shift clock)

WRITE to SCON

(clear RI)

shift

RXD

(data in)

TxD (shift clock)

Fig 20. Serial Port Mode 0 (double buffering must be disabled).

D0 D1 D5D2 D6D3 D4 D7

UM10108

P89LPC924/925 User manual

transmit

receive

002aaa92

10.11 More about UART Mode 1

Reception is initiated by detecting a 1-to-0 transition on RXD. RXD is sampled at a rate 16 times the programmed baud rate. When a transition is detected, the divide-by-16 counter is immediately reset. Each bit time is thus divided into 16 counter states. At the 7th, 8th, and 9th counter states, the bit detector samples the value of RXD. The value accepted is the value that was seen in at least 2 of the 3 samples. This is done for noise rejection. If the value accepted during the first bit time is not 0, the receive circuits are reset and the receiver goes back to looking for another 1-to-0 transition. This provides rejection of false start bits. If the start bit proves valid, it is shifted into the input shift register, and reception of the rest of the frame will proceed.

The signal to load SBUF and RB8, and to set RI, will be generated if, and only if, the following conditions are met at the time the final shift pulse is generated: RI = 0 and either SM2 = 0 or the received stop bit = 1. If either of these two conditions is not met, the received frame is lost. If both conditions are met, the stop bit goes into RB8, the 8 data bits go into SBUF, and RI is activated.

User manual Rev. 02 — 2 March 2005 49 of 105

Philips Semiconductors

TX clock

write to

SBUF

shift

TxD

clock

RxD

shift

16 reset

Fig 21. Serial Port Mode 1 (only single transmit buffering case is shown).

start

bit

D0 D1 D5D2 D6D3 D4 D7

start

D0 D1 D5D2 D6D3 D4 D7

bit

UM10108

P89LPC924/925 User manual

stop bit

INTLO = 0

INTLO = 1

stop bit

transmit

receive

002aaa92

TX clock

write to

SBUF

shift

TxD

clock

RxD

shift

10.12 More about UART Modes 2 and 3

Reception is the same as in Mode 1.

The signal to load SBUF and RB8, and to set RI, will be generated if, and only if, the following conditions are met at the time the final shift pulse is generated. (a) RI = 0, and (b) Either SM2 = 0, or the received 9th data bit = 1. If either of these conditions is not met, the received frame is lost, and RI is not set. If both conditions are met, the received 9th data bit goes into RB8, and the first 8 data bits go into SBUF.

start

16 reset

D0 D1 D5D2 D6D3 D4 D7

bit

start

D0 D1 D5D2 D6D3 D4 D7

bit

TB8

stop bit

INTLO = 0 INTLO = 1

RB8

stop bit

SMOD0 = 0 SMOD0 = 1

transmit

receive

002aaa92

Fig 22. Serial Port Mode 2 or 3 (only single transmit buffering case is shown).

10.13 Framing error and RI in Modes 2 and 3 with SM2 = 1

If SM2 = 1 in modes 2 and 3, RI and FE behaves as in the following table.

User manual Rev. 02 — 2 March 2005 50 of 105

Philips Semiconductors

P89LPC924/925 User manual

Table 49: FE and RI when SM2= 1 in Modes 2 and 3.

Mode PCON.6

(SMOD0)

2 0 0 No RI when RB8 = 0 Occurs during STOP bit

3 1 0 No RI when RB8 = 0 Will NOT occur

RB8 RI FE

1 Similar to Figure 22, with SMOD0 = 0, RI occurs during

RB8, one bit before FE

1 Similar to Figure 22, with SMOD0 = 1, RI occurs during

STOP bit

Occurs during STOP bit

UM10108

10.14 Break detect

A break is detected when 11 consecutive bits are sensed LOW and is reported in the status register (SSTAT). For Mode 1, this consists of the start bit, 8 data bits, and two stop bit times. For Modes 2 and 3, this consists of the start bit, 9 data bits, and one stop bit. The break detect bit is cleared in software or by a reset. The break detect can be used to reset the device and force the device into ISP mode. This occurs if the UART is enabled and the the EBRR bit (AUXR1.6) is set and a break occurs.

10.15 Double buffering

The UART has a transmit double buffer that allows buffering of the next character to be written to SBUF while the first character is being transmitted. Double buffering allows transmission of a string of characters with only one stop bit between any two characters, provided the next character is written between the start bit and the stop bit of the previous character.

Double buffering can be disabled. If disabled (DBMOD, i.e. SSTAT.7 = 0), the UART is compatible with the conventional 80C51 UART. If enabled, the UART allows writing to SnBUF while the previous data is being shifted out.

10.16 Double buffering in different modes

Double buffering is only allowed in Modes 1, 2 and 3. When operated in Mode 0, double buffering must be disabled (DBMOD = 0).

10.17 Transmit interrupts with double buffering enabled (Modes 1,2, and 3)

Unlike the conventional UART, when double buffering is enabled, the TX interrupt is generated when the double buffer is ready to receive new data. The following occurs during a transmission (assuming eight data bits):

1. The double buffer is empty initially.

2. The CPU writes to SBUF.

3. The SBUF data is loaded to the shift register and a TX interrupt is generated immediately.

4. If there is more data, go to 6, else continue.

5. If there is no more data, then:

– If DBISEL is logic 0, no more interrupts will occur.

User manual Rev. 02 — 2 March 2005 51 of 105

Philips Semiconductors

– If DBISEL is logic 1 and INTLO is logic 0, a TX interrupt will occur at the beginning

– If DBISEL is logic 1 and INTLO is logic 1, a TX interrupt will occur at the end of the

– Note that if DBISEL is logic 1 and the CPU is writing to SBUF when the STOP bit of

6. If there is more data, the CPU writes to SBUF again. Then:

– If INTLO is logic 0, the new data will be loaded and a TX interrupt will occur at the

– If INTLO is logic 1, the new data will be loaded and a TX interrupt will occur at the

– Go to 3.

TxD

UM10108

P89LPC924/925 User manual

of the STOP bit of the data currently in the shifter (which is also the last data).

STOP bit of the data currently in the shifter (which is also the last data).

the last data is shifted out, there can be an uncertainty of whether a TX interrupt is generated already with the UART not knowing whether there is any more data following.

beginning of the STOP bit of the data currently in the shifter.

end of the STOP bit of the data currently in the shifter.

write to

SBUF

Tx interrupt

Single buffering (DBMOD/SSTAT.7 = 0), early interrupt (INTLO/SSTAT.6 = 0) is shown

TxD

write to

SBUF

Tx interrupt

Double buffering (DBMOD/SSTAT.7 = 1), early interrupt (INTLO/SSTAT.6 = 0) is shown,

no ending Tx interrupt (DBISEL/SSTAT.4 = 0)

TxD

write to

SBUF

Tx interrupt

Double buffering (DBMOD/SSTAT.7 = 1), early interrupt (INTLO/SSTAT.6 = 0) is shown,

with ending Tx interrupt (DBISEL/SSTAT.4 = 1)

Fig 23. Transmission with and without double buffering.

002aaa92

10.18 The 9th bit (bit 8) in double buffering (Modes 1, 2, and 3)

If double buffering is disabled (DBMOD, i.e. SSTAT.7 = 0), TB8 can be written before or after SBUF is written, provided TB8 is updated before that TB8 is shifted out. TB8 must not be changed again until after TB8 shifting has been completed, as indicated by the TX interrupt.

User manual Rev. 02 — 2 March 2005 52 of 105

Philips Semiconductors

If double buffering is enabled, TB8 MUST be updated before SBUF is written, as TB8 will be double-buffered together with SBUF data. The operation described in becomes as follows:

1. The double buffer is empty initially.

2. The CPU writes to TB8.

3. The CPU writes to SBUF.

4. The SBUF/TB8 data is loaded to the shift register and a TX interrupt is generated immediately.

5. If there is more data, go to 7, else continue on 6.

6. If there is no more data, then:

– If DBISEL is logic 0, no more interrupt will occur.

– If DBISEL is logic 1 and INTLO is logic 0, a TX interrupt will occur at the beginning

– If DBISEL is logic 1 and INTLO is logic 1, a TX interrupt will occur at the end of the

7. If there is more data, the CPU writes to TB8 again.

8. The CPU writes to SBUF again. Then:

– If INTLO is logic 0, the new data will be loaded and a TX interrupt will occur at the

– If INTLO is logic 1, the new data will be loaded and a TX interrupt will occur at the

9. Go to 4.

10.Note that if DBISEL is logic 1 and the CPU is writing to SBUF when the STOP bit of the last data is shifted out, there can be an uncertainty of whether a TX interrupt is generated already with the UART not knowing whether there is any more data following.

UM10108

P89LPC924/925 User manual

Section 10.17

of the STOP bit of the data currently in the shifter (which is also the last data).

STOP bit of the data currently in the shifter (which is also the last data).

beginning of the STOP bit of the data currently in the shifter.

end of the STOP bit of the data currently in the shifter.

10.19 Multiprocessor communications

UART modes 2 and 3 have a special provision for multiprocessor communications. In these modes, 9 data bits are received or transmitted. When data is received, the 9th bit is stored in RB8. The UART can be programmed such that when the stop bit is received, the serial port interrupt will be activated only if RB8 = 1. This feature is enabled by setting bit SM2 in SCON. One way to use this feature in multiprocessor systems is as follows:

When the master processor wants to transmit a block of data to one of several slaves, it first sends out an address byte which identifies the target slave. An address byte differs from a data byte in that the 9th bit is 1 in an address byte and 0 in a data byte. With SM2

= 1, no slave will be interrupted by a data byte. An address byte, however, will interrupt all slaves, so that each slave can examine the received byte and see if it is being addressed. The addressed slave will clear its SM2 bit and prepare to receive the data bytes that follow. The slaves that weren’t being addressed leave their SM2 bits set and go on about their business, ignoring the subsequent data bytes.

Note that SM2 has no effect in Mode 0, and must be logic 0 in Mode 1.

User manual Rev. 02 — 2 March 2005 53 of 105

Philips Semiconductors

10.20 Automatic address recognition

Automatic address recognition is a feature which allows the UART to recognize certain addresses in the serial bit stream by using hardware to make the comparisons. This feature saves a great deal of software overhead by eliminating the need for the software to examine every serial address which passes by the serial port. This feature is enabled by setting the SM2 bit in SCON. In the 9 bit UART modes (mode 2 and mode 3), the Receive Interrupt flag (RI) will be automatically set when the received byte contains either the ‘Given’ address or the ‘Broadcast’ address. The 9 bit mode requires that the 9th information bit is a 1 to indicate that the received information is an address and not data.

Using the Automatic Address Recognition feature allows a master to selectively communicate with one or more slaves by invoking the Given slave address or addresses. All of the slaves may be contacted by using the Broadcast address. Two special Function Registers are used to define the slave’s address, SADDR, and the address mask, SADEN. SADEN is used to define which bits in the SADDR are to be used and which bits are ‘don’t care’. The SADEN mask can be logically ANDed with the SADDR to create the ‘Given’ address which the master will use for addressing each of the slaves. Use of the Given address allows multiple slaves to be recognized while excluding others. The following examples will help to show the versatility of this scheme:

UM10108

P89LPC924/925 User manual

Table 50: Slave 0/1 examples

Example 1 Example 2

Slave 0 SADDR = 1100 0000 Slave 1 SADDR = 1100 0000

SADEN = 1111 1101 SADEN = 1111 1110

Given = 1100 00X0 Given = 1100 000X

In the above example SADDR is the same and the SADEN data is used to differentiate between the two slaves. Slave 0 requires a 0 in bit 0 and it ignores bit 1. Slave 1 requires a 0 in bit 1 and bit 0 is ignored. A unique address for Slave 0 would be 1100 0010 since slave 1 requires a 0 in bit 1. A unique address for slave 1 would be 1100 0001 since a 1 in bit 0 will exclude slave 0. Both slaves can be selected at the same time by an address which has bit 0 = 0 (for slave 0) and bit 1 = 0 (for slave 1). Thus, both could be addressed with 1100 0000.

In a more complex system the following could be used to select slaves 1 and 2 while excluding slave 0:

Table 51: Slave 0/1/2 examples

Example 1 Example 2 Example 3

Slave 0 SADDR = 1100 0000 Slave 1 SADDR = 1110 0000 Slave 2 SADDR = 1100 0000

SADEN = 1111 1001 SADEN = 1111 1010 SADEN = 1111 1100

Given = 1100

0XX0

Given = 1110 0X0X Given = 1110 00XX

In the above example the differentiation among the 3 slaves is in the lower 3 address bits. Slave 0 requires that bit 0 = 0 and it can be uniquely addressed by 1110 0110. Slave 1 requires that bit 1 = 0 and it can be uniquely addressed by 1110 and 0101. Slave 2 requires that bit 2 = 0 and its unique address is 1110 0011. To select Slaves 0 and 1 and exclude Slave 2 use address 1110 0100, since it is necessary to make bit 2 = 1 to exclude slave 2. The Broadcast Address for each slave is created by taking the logical OR of SADDR and SADEN. Zeros in this result are treated as don’t-cares. In most cases,

User manual Rev. 02 — 2 March 2005 54 of 105

Philips Semiconductors

interpreting the don’t-cares as ones, the broadcast address will be FF hexadecimal. Upon reset SADDR and SADEN are loaded with 0s. This produces a given address of all ‘don’t cares’ as well as a Broadcast address of all ‘don’t cares’. This effectively disables the Automatic Addressing mode and allows the microcontroller to use standard UART drivers which do not make use of this feature.

11. I2C interface

The I2C-bus uses two wires, serial clock (SCL) and serial data (SDA) to transfer information between devices connected to the bus, and has the following features:

• Bidirectional data transfer between masters and slaves.

• Multimaster bus (no central master).

• Arbitration between simultaneously transmitting masters without corruption of serial

data on the bus.

• Serial clock synchronization allows devices with different bit rates to communicate via

one serial bus.

• Serial clock synchronization can be used as a handshake mechanism to suspend and

resume serial transfer.

• The I

P89LPC924/925 User manual

C-bus may be used for test and diagnostic purposes.

UM10108

A typical I2C-bus configuration is shown in Figure 24. Depending on the state of the direction bit (R/W), two types of data transfers are possible on the I2C-bus:

• Data transfer from a master transmitter to a slave receiver. The first byte transmitted

by the master is the slave address. Next follows a number of data bytes. The slave returns an acknowledge bit after each received byte.

• Data transfer from a slave transmitter to a master receiver. The first byte (the slave

address) is transmitted by the master. The slave then returns an acknowledge bit. Next follows the data bytes transmitted by the slave to the master. The master returns an acknowledge bit after all received bytes other than the last byte. At the end of the last received byte, a ‘not acknowledge’ is returned. The master device generates all of the serial clock pulses and the START and STOP conditions. A transfer is ended with a STOP condition or with a repeated START condition. Since a repeated START condition is also the beginning of the next serial transfer, the I released.

The P89LPC924/925 device provides a byte-oriented I2C interface. It has four operation modes: Master Transmitter Mode, Master Receiver Mode, Slave Transmitter Mode and Slave Receiver Mode.

The P89LPC924/925 CPU interfaces with the I2C-bus through six Special Function Registers (SFRs): I2CON (I Status Register), I2ADR (I HIGH Byte), and I2SCLL (SCL Duty Cycle Register LOW Byte).

C Control Register), I2DAT (I2C Data Register), I2STAT (I2C

C Slave Address Register), I2SCLH (SCL Duty Cycle Register

C-bus will not be

User manual Rev. 02 — 2 March 2005 55 of 105

Philips Semiconductors

UM10108

P89LPC924/925 User manual

C-BUS

SDA

SCL

OTHER DEVICE

C-BUS

WITH I

INTERFACE

002aaa952

I2C-BUS

P1.3/SDA P1.2/SCL

P89LPC924/925

Fig 24. I2C-bus configuration.

OTHER DEVICE

WITH I

INTERFACE

11.1 I2C Data register

I2DAT register contains the data to be transmitted or the data received. The CPU can read and write to this 8-bit register while it is not in the process of shifting a byte. Thus this register should only be accessed when the SI bit is set. Data in I2DAT remains stable as long as the SI bit is set. Data in I2DAT is always shifted from right to left: the first bit to be transmitted is the MSB (bit 7), and after a byte has been received, the first bit of received data is located at the MSB of I2DAT.

Table 52: I2C Data register (I2DAT - address DAh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol I2DAT.7 I2DAT.6 I2DAT.5 I2DAT.4 I2DAT.3 I2DAT.2 I2DAT.1 I2DAT.0

Reset 0 0 0 0 0 0 0 0

11.2 I2C Slave Address register

I2ADR register is readable and writable, and is only used when the I2C interface is set to slave mode. In master mode, this register has no effect. The LSB of I2ADR is general call bit. When this bit is set, the general call address (00h) is recognized.

Table 53: I2C Slave Address register (I2ADR - address DBh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol I2ADR.6 I2ADR.5 I2ADR.4 I2ADR.3 I2ADR.2 I2ADR.1 I2ADR.0 GC

Reset 0 0 0 0 0 0 0 0

Table 54: I2C Slave Address register (I2ADR - address DBh) bit description

Bit Symbol Description

0 GC General call bit. When set, the general call address (00H) is recognized, otherwise it is ignored.

1:7 I2ADR1:7 7 bit own slave address. When in master mode, the contents of this register has no effect.

11.3 I2C Control register

The CPU can read and write this register. There are two bits are affected by hardware: the SI bit and the STO bit. The SI bit is set by hardware and the STO bit is cleared by hardware.

User manual Rev. 02 — 2 March 2005 56 of 105

Philips Semiconductors

CRSEL determines the SCL source when the I2C-bus is in master mode. In slave mode this bit is ignored and the bus will automatically synchronize with any clock frequency up to 400

kHz from the master I2C device. When CRSEL = 1, the I2C interface uses the Timer 1 overflow rate divided by 2 for the I by the user in 8 bit auto-reload mode (Mode 2).

Data rate of the I2C-bus = Timer overflow rate / 2 = PCLK / (2*(256 − reload value)),

If f

= 12 MHz, reload value is 0 to 255, so the I2C-bus data rate range is 11.72 Kbit/sec

osc

to 3000

When CRSEL = 0, the I2C interface uses the internal clock generator based on the value of I2SCLL and I2CSCLH register. The duty cycle does not need to be 50 %.

The STA bit is START flag. Setting this bit causes the I2C interface to enter master mode and attempt transmitting a START condition or transmitting a repeated START condition when it is already in master mode.

The STO bit is STOP flag. Setting this bit causes the I2C interface to transmit a STOP condition in master mode, or recovering from an error condition in slave mode.

Kbit/sec.

UM10108

P89LPC924/925 User manual

C clock rate. Timer 1 should be programmed

If the STA and STO are both set, then a STOP condition is transmitted to the I2C-bus if it is in master mode, and transmits a START condition afterwards. If it is in slave mode, an internal STOP condition will be generated, but it is not transmitted to the bus.

Table 55: I2C Control register (I2CON - address D8h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol - I2EN STA STO SI AA - CRSEL

Reset x 0 0 0 0 0 x 0

Table 56: I2C Control register (I2CON - address D8h) bit description

Bit Symbol Description

0 CRSEL SCL clock selection. When set = 1, Timer 1 overflow generates SCL, when cleared = 0, the internal SCL

generator is used base on values of I2SCLH and I2SCLL.

1 - reserved

2 AA The Assert Acknowledge Flag. When set to 1, an acknowledge (LOW level to SDA) will be returned during

the acknowledge clock pulse on the SCL line on the following situations:

(1)The ‘own slave address’ has been received. (2)The general call address has been received while the general call bit (GC) in I2ADR is set. (3) A data byte has been received while the I Master Receiver Mode. (4)A data byte has been received while the I Receiver Mode. When cleared to logic 0, an not acknowledge (HIGH level to SDA) will be returned during the acknowledge clock pulse on the SCL line on the following situations: (1) A data byte has been received while the I interface is in the addressed Slave Receiver Mode.

3 SI I2C Interrupt Flag. This bit is set when one of the 25 possible I2C-bus states is entered. When EA bit and

EI2C (IEN1.0) bit are both set, an interrupt is requested when SI is set. Must be cleared by software by writing 0 to this bit.

4 STO STOP Flag. STO = 1: In master mode, a STOP condition is transmitted to the I2C-bus. When the bus detects

the STOP condition, it will clear STO bit automatically. In slave mode, setting this bit can recover from an error condition. In this case, no STOP condition is transmitted to the bus. The hardware behaves as if a STOP condition has been received and it switches to ‘not addressed’ Slave Receiver Mode. The STO flag is cleared by hardware automatically.

C interface is in the Master Receiver Mode. (2) A data byte has been received while the I2C

C interface is in the addressed Slave

C interface is in the

User manual Rev. 02 — 2 March 2005 57 of 105

Philips Semiconductors

P89LPC924/925 User manual

Table 56: I2C Control register (I2CON - address D8h) bit description

Bit Symbol Description

5 STA Start Flag. STA = 1: The I2C-bus enters master mode, checks the bus and generates a START condition if

the bus is free. If the bus is not free, it waits for a STOP condition (which will free the bus) and generates a START condition after a delay of a half clock period of the internal clock generator. When the I already in master mode and some data is transmitted or received, it transmits a repeated START condition. STA may be set at any time, it may also be set when the I2C interface is in an addressed slave mode. STA = 0: No START condition or repeated START condition will be generated.

6 I2EN I2C Interface Enable. When set, enables the I2C interface. When clear, the I2C function is disabled.

7 - reserved

UM10108

C interface is

11.4 I2C status register

This is a read-only register. It contains the status code of the I2C interface. The lower three bits are always 0. There are 26 possible status codes. When the code is F8H, there is no relevant information available and SI bit is not set. All other 25 status codes correspond to defined I

Ta bl e 62 to Tab le 65 for details.

Table 57: I2C status register (I2STAT - address D9h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol STA.4 STA.3 STA.2 STA.1 STA.0 0 0 0

Reset 0 0 0 0 0 0 0 0

C states. When any of these states entered, the SI bit will be set. Refer to

Table 58: I2C Status register (I2STAT - address D9h) bit description

Bit Symbol Description

0:2 - Reserved, are always set to 0.

3:7 STA.0:4 I2C Status code.

11.5 I2C SCL duty cycle registers I2SCLH and I2SCLL

When the internal SCL generator is selected for the I2C interface by setting CRSEL = 0 in the I2CON register, the user must set values for registers I2SCLL and I2SCLH to select the data rate. I2SCLH defines the number of PCLK cycles for SCL defines the number of PCLK cycles for SCL = LOW. The frequency is determined by the following formula:

Bit Frequency = f

Where f

The values for I2SCLL and I2SCLH do not have to be the same; the user can give different duty cycle’s for SCL by setting these two registers. However, the value of the register must ensure that the data rate is in the I I2SCLL and I2SCLH have some restrictions and values for both registers greater than 3 PCLKs are recommended.

is the frequency of PCLK.

PCLK

/ (2*(I2SCLH + I2SCLL))

PCLK

C data rate range of 0 to 400 kHz. Thus the values of

= HIGH, I2SCLL

User manual Rev. 02 — 2 March 2005 58 of 105

Philips Semiconductors

P89LPC924/925 User manual

Table 59: I2C clock rates selection

Bit data rate (Kbit/sec) at f

I2SCLL+

I2SCLH

6 0 - 307 154 - -

7 0 - 263 132 - -

8 0 - 230 115 - 375

9 0 - 205 102 - 333

10 0 369 184 92 - 300

15 0 246 123 61 400 200

25 0 147 74 37 240 120

30 0 123 61 31 200 100

50 0 74 37 18 120 60

60 0 61 31 15 100 50

100 0 37 18 9 60 30

150 0 25 12 6 40 20

200 0 18 9 5 30 15

- 1 3.6 to 922 Kbps

CRSEL 7.373 MHz 3.6865 MHz 1.8433 MHz 12 MHz 6 MHz

Timer 1 in mode 2

osc

1.8 to 461 Kbps Timer 1 in mode 2

0.9 to 230 Kbps Timer 1 in mode 2

5.86 to 1500 Kbps Timer 1 in mode 2

UM10108

2.93 to 750 Kbps Timer 1 in mode 2

11.6 I2C operation modes

11.6.1 Master Transmitter mode

In this mode data is transmitted from master to slave. Before the Master Transmitter Mode can be entered, I2CON must be initialized as follows:

Table 60: I2C Control register (I2CON - address D8h)

Bit 7 6 5 4 3 2 1 0

- I2EN STA STO SI AA - CRSEL

value - 1 0 0 0 x - bit rate

CRSEL defines the bit rate. I2EN must be set to 1 to enable the I2C function. If the AA bit is logic 0, it will not acknowledge its own slave address or the general call address in the event of another device becoming master of the bus and it can not enter slave mode. STA, STO, and SI bits must be cleared to logic 0.

The first byte transmitted contains the slave address of the receiving device (7 bits) and the data direction bit. In this case, the data direction bit (R/W) will be logic 0 indicating a write. Data is transmitted 8 bits at a time. After each byte is transmitted, an acknowledge bit is received. START and STOP conditions are output to indicate the beginning and the end of a serial transfer.

The I2C-bus will enter Master Transmitter Mode by setting the STA bit. The I2C logic will send the START condition as soon as the bus is free. After the START condition is transmitted, the SI bit is set, and the status code in I2STAT should be 08h. This status code must be used to vector to an interrupt service routine where the user should load the slave address to I2DAT (Data Register) and data direction bit (SLA+W). The SI bit must be cleared before the data transfer can continue.

User manual Rev. 02 — 2 March 2005 59 of 105

Philips Semiconductors

When the slave address and R/W bit have been transmitted and an acknowledgment bit has been received, the SI bit is set again, and the possible status codes are 18h, 20h, or 38h for the master mode or 68h, 78h, or 0B0h if the slave mode was enabled (setting AA

= logic 1). The appropriate action to be taken for each of these status codes is shown

Ta bl e 62.

UM10108

P89LPC924/925 User manual

S R/W A D ATA D ATA

from Master to Slave from Slave to Master

Fig 25. Format in the Master Transmitter mode.

11.6.2 Master Receiver mode

In the Master Receiver Mode, data is received from a slave transmitter. The transfer started in the same manner as in the Master Transmitter Mode. When the START condition has been transmitted, the interrupt service routine must load the slave address and the data direction bit to the I before the data transfer can continue.

When the slave address and data direction bit have been transmitted and an acknowledge bit has been received, the SI bit is set, and the Status Register will show the status code. For master mode, the possible status codes are 40H, 48H, or 38H. For slave mode, the possible status codes are 68H, 78H, or B0H. Refer to

A A/A Pslave address

logic 0 = write logic 1 = read

C Data Register (I2DAT). The SI bit must be cleared

data transferred

(n Bytes + acknowledge)

A = acknowledge (SDA LOW) A = not acknowledge (SDA HIGH) S = START condition P = STOP condition

002aaa929

Ta bl e 64 for details.

S R Aslave address

logic 0 = write logic 1 = read

from Master to Slave from Slave to Master

Fig 26. Format of Master Receiver mode.

DATA DATA

A = acknowledge (SDA LOW) A = not acknowledge (SDA HIGH) S = START condition

A A P

data transferred

(n Bytes + acknowledge)

002aaa93

After a repeated START condition, the I2C-bus may switch to the Master Transmitter Mode.

User manual Rev. 02 — 2 March 2005 60 of 105

Philips Semiconductors

UM10108

P89LPC924/925 User manual

S R ASLA

logic 0 = write

logic 1 = read

from Master to Slave from Slave to Master

Fig 27. A Master Receiver switches to Master Transmitter after sending Repeated Start.

DATA DATA

A W ASLA D ATA A PA RS

data transferred

(n Bytes + acknowledge)

A = acknowledge (SDA LOW) A = not acknowledge (SDA HIGH) S = START condition P = STOP condition SLA = slave address RS = repeat START condition

002aaa931

11.6.3 Slave Receiver mode

In the Slave Receiver Mode, data bytes are received from a master transmitter. To initialize the Slave Receiver Mode, the user should write the slave address to the Slave Address Register (I2ADR) and the I

C Control Register (I2CON) should be configured as

follows:

Table 61: I2C Control register (I2CON - address D8h)

Bit 7 6 5 4 3 2 1 0

- I2EN STA STO SI AA - CRSEL

value - 1 0 0 0 1 - -

CRSEL is not used for slave mode. I2EN must be set = 1 to enable the I2C function. AA bit must be set = 1 to acknowledge its own slave address or the general call address. STA, STO and SI are cleared to 0.

After I2ADR and I2CON are initialized, the interface waits until it is addressed by its own address or general address followed by the data direction bit which is 0(W). If the direction bit is 1(R), it will enter Slave Transmitter Mode. After the address and the direction bit have been received, the SI bit is set and a valid status code can be read from the Status Register (I2STAT). Refer to

S W Aslave address

from Master to Slave from Slave to Master

Fig 28. Format of Slave Receiver mode.

Ta bl e 65 for the status codes and actions.

DATA DATA

A A/A P/RS

logic 0 = write

logic 1 = read

data transferred

(n Bytes + acknowledge)

A = acknowledge (SDA LOW) A = not acknowledge (SDA HIGH) S = START condition P = STOP condition RS = repeated START condition

002aaa932

11.6.4 Slave Transmitter mode

The first byte is received and handled as in the Slave Receiver Mode. However, in this mode, the direction bit will indicate that the transfer direction is reversed. Serial data is transmitted via P1.3/SDA while the serial clock is input through P1.2/SCL. START and

User manual Rev. 02 — 2 March 2005 61 of 105

Philips Semiconductors

UM10108

P89LPC924/925 User manual

STOP conditions are recognized as the beginning and end of a serial transfer. In a given application, the I

C-bus hardware looks for its own slave address and the general call address. If one of

C-bus may operate as a master and as a slave. In the slave mode, the

these addresses is detected, an interrupt is requested. When the microcontrollers wishes to become the bus master, the hardware waits until the bus is free before the master mode is entered so that a possible slave action is not interrupted. If bus arbitration is lost in the master mode, the I

C-bus switches to the slave mode immediately and can detect its own

slave address in the same serial transfer.

S R Aslave address

logic 0 = write

logic 1 = read

from Master to Slave from Slave to Master

Fig 29. Format of Slave Transmitter mode.

DATA DATA

A A P

data transferred

(n Bytes + acknowledge)

A = acknowledge (SDA LOW) A = not acknowledge (SDA HIGH) S = START condition P = STOP condition

002aaa933

User manual Rev. 02 — 2 March 2005 62 of 105

Philips Semiconductors

UM10108

P89LPC924/925 User manual

P1.3/SDA

P1.2/SCL

P1.3

INPUT

FILTER

OUTPUT

STAGE

INPUT

FILTER

OUTPUT

STAGE

P1.2

TIMER 1

OVERFLOW

I2CON

I2SCLH

I2SCLL

ADDRESS REGISTER

COMPARATOR

SHIFT REGISTER

BIT COUNTER /

ARBITRATION

AND SYNC LOGIC

SERIAL CLOCK

GENERATOR

CONTROL REGISTERS AND

SCL DUTY CYCLE REGISTERS

TIMING

CONTROL

LOGIC

I2ADR

INTERNAL BUS

ACK

I2DAT

CCLK

AND

INTERRUPT

STATUS BUS

I2STAT

Fig 30. I2C serial interface block diagram.

STATUS

DECODER

STATUS REGISTER

002aaa421

User manual Rev. 02 — 2 March 2005 63 of 105

Philips Semiconductors

Table 62: Master Transmitter mode

Status code (I2STAT)

08H A START

10H A repeat START

18h SLA+W has been

20h SLA+W has been

28h Data byte in I2DAT

Status of the I2C hardware

condition has been transmitted

transmitted; ACK has been received

transmitted; NOT-ACK has been received

has been transmitted; ACK has been received

UM10108

P89LPC924/925 User manual

Application software response Next action taken by I2C

to/from I2DAT to I2CON

STA STO SI AA

Load SLA+W x 0 0 x SLA+W will be transmitted;

Load SLA+W or

Load SLA+R

Load data byte or 0 0 0 x Data byte will be transmitted;

no I2DAT action or 1 0 0 x Repeated START will be

no I2DAT action or 0 1 0 x STOP condition will be

no I2DAT action 1 1 0 x STOP condition followed by a

Load data byte or 0 0 0 x Data byte will be transmitted;

no I2DAT action or 1 0 0 x Repeated START will be

no I2DAT action or 0 1 0 x STOP condition will be

no I2DAT action 1 1 0 x STOP condition followed by a

Load data byte or 0 0 0 x Data byte will be transmitted;

no I2DAT action or 1 0 0 x Repeated START will be

no I2DAT action or 0 1 0 x STOP condition will be

no I2DAT action 1 1 0 x STOP condition followed by a

x 0 0 x As above; SLA+W will be

hardware

ACK bit will be received

transmitted; the I2C-bus switches to Master Receiver Mode

ACK bit will be received

transmitted;

STO flag will be reset

START condition will be transmitted; STO flag will be reset.

ACK bit will be received

transmitted;

transmitted; STO flag will be reset

START condition will be transmitted; STO flag will be reset

ACK bit will be received

transmitted;

transmitted; STO flag will be reset

START condition will be transmitted; STO flag will be reset

User manual Rev. 02 — 2 March 2005 64 of 105

Philips Semiconductors

Table 62: Master Transmitter mode

Status code (I2STAT)

30h Data byte in I2DAT

38H Arbitration lost in

Status of the I2C hardware

has been transmitted, NOT ACK has been received

SLA+R/W or data bytes

UM10108

P89LPC924/925 User manual

Application software response Next action taken by I2C

to/from I2DAT to I2CON

STA STO SI AA

Load data byte or 0 0 0 x Data byte will be transmitted;

no I2DAT action or 1 0 0 x Repeated START will be

no I2DAT action or 0 1 0 x STOP condition will be

no I2DAT action 1 1 0 x STOP condition followed by a

No I2DAT action or0 0 0 x The I2C-bus will be released;

No I2DAT action 1 0 0 x A START condition will be

hardware

ACK bit will be received

transmitted;

transmitted; STO flag will be reset

START condition will be transmitted. STO flag will be reset.

not addressed slave will be entered

transmitted when the bus becomes free.

Table 63: Master Receiver mode

Status code (I2STAT)

08H A START

10H A repeat START

38H Arbitration lost in

40h SLA+R has been

48h SLA+R has been

Status of the I2C hardware

condition has been transmitted

NOT ACK bit

transmitted; ACK has been received

transmitted; NOT ACK has been received

Application software response Next action taken by the I2C

to/from I2DAT to I2CON

Load SLA+R x 0 0 x SLA+R will be transmitted; ACK bit

Load SLA+R or x 0 0 x As above

Load SLA+W SLA+W will be transmitted; the

no I2DAT action or 0 0 0 x The I2C-bus will be released; it will

no I2DAT action 1 0 0 x A START condition will be

no I2DAT action or 0 0 0 0 Data byte will be received; NOT ACK

no I2DAT action or 0 0 0 1 Data byte will be received; ACK bit

No I2DAT action or1 0 0 x Repeated START will be transmitted

no I2DAT action or 0 1 0 x STOP condition will be transmitted;

no I2DAT action or 1 1 0 x STOP condition followed by a START

STA STO SI STA

hardware

will be received

C-bus will be switched to Master

I Transmitter Mode

enter a slave mode

transmitted when the bus becomes free

bit will be returned

will be returned

STO flag will be reset

condition will be transmitted; STO flag will be reset

User manual Rev. 02 — 2 March 2005 65 of 105

Philips Semiconductors

Table 63: Master Receiver mode

Status code (I2STAT)

50h Data byte has

58h Data byte has

Table 64: Slave Receiver mode

Status code (I2STAT)

60H Own SLA+W has

68H Arbitration lost in

70H General call

78H Arbitration lost in

80H Previously

Status of the I2C hardware

been received; ACK has been returned

been received; NACK has been returned

Status of the I2C hardware

been received; ACK has been received

SLA+R/W as master; Own SLA+W has been received, ACK returned

address (00H) has been received, ACK has been returned

SLA+R/W as master; General call address has been received, ACK bit has been returned

addressed with own SLA address; Data has been received; ACK has been returned

UM10108

P89LPC924/925 User manual

Application software response Next action taken by the I2C

to/from I2DAT to I2CON

STA STO SI STA

Read data byte 0 0 0 0 Data byte will be received; NOT ACK

read data byte 0 0 0 1 Data byte will be received; ACK bit

Read data byte or 1 0 0 x Repeated START will be transmitted;

read data byte or 0 1 0 x STOP condition will be transmitted;

read data byte 1 1 0 x STOP condition followed by a START

Application software response Next action taken by the I2C

to/from I2DAT to I2CON

STA STO SI AA

no I2DAT action or x 0 0 0 Data byte will be received and NOT

no I2DAT action x 0 0 1 Data byte will be received and ACK

No I2DAT action orx 0 0 0 Data byte will be received and NOT

no I2DAT action x 0 0 1 Data byte will be received and ACK

No I2DAT action orx 0 0 0 Data byte will be received and NOT

no I2DAT action x 0 0 1 Data byte will be received and ACK

no I2DAT action or x 0 0 0 Data byte will be received and NOT

no I2DAT action x 0 0 1 Data byte will be received and ACK

Read data byte or x 0 0 0 Data byte will be received and NOT

read data byte x 0 0 1 Data byte will be received; ACK bit

hardware

bit will be returned

will be returned

STO flag will be reset

condition will be transmitted; STO flag will be reset

hardware

ACK will be returned

will be returned

ACK will be returned

will be returned

ACK will be returned

will be returned

ACK will be returned

will be returned

ACK will be returned

will be returned

User manual Rev. 02 — 2 March 2005 66 of 105

Philips Semiconductors

Table 64: Slave Receiver mode

Status code (I2STAT)

88H Previously

90H Previously

98H Previously

Status of the I2C hardware

addressed with own SLA address; Data has been received; NACK has been returned

addressed with General call; Data has been received; ACK has been returned

addressed with General call; Data has been received; NACK has been returned

UM10108

P89LPC924/925 User manual

Application software response Next action taken by the I2C

to/from I2DAT to I2CON

STA STO SI AA

Read data byte or 0 0 0 0 Switched to not addressed SLA

read data byte

read data byte 1 0 0 1 Switched to not addressed SLA

Read data byte or x 0 0 0 Data byte will be received and NOT

read data byte x 0 0 1 Data byte will be received and ACK

Read data byte 0 0 0 0 Switched to not addressed SLA

read data byte 0 0 0 1 Switched to not addressed SLA

read data byte 1 0 0 0 Switched to not addressed SLA

read data byte 1 0 0 1 Switched to not addressed SLA

0 0 0 1 Switched to not addressed SLA

1 0 0 0 Switched to not addressed SLA

hardware

mode; no recognition of own SLA or general address

mode; Own SLA will be recognized; general call address will be recognized if I2ADR.0 = 1

mode; no recognition of own SLA or General call address. A START condition will be transmitted when the bus becomes free

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1. A START condition will be transmitted when the bus becomes free.

ACK will be returned

will be returned

mode; no recognition of own SLA or General call address

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1.

mode; no recognition of own SLA or General call address. A START condition will be transmitted when the bus becomes free.

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1. A START condition will be transmitted when the bus becomes free.

User manual Rev. 02 — 2 March 2005 67 of 105

Philips Semiconductors

Table 64: Slave Receiver mode

Status code (I2STAT)

A0H A STOP condition

Status of the I2C hardware

or repeated START condition has been received while still addressed as SLA/REC or SLA/TRX

UM10108

P89LPC924/925 User manual

Application software response Next action taken by the I2C

to/from I2DAT to I2CON

STA STO SI AA

No I2DAT action 0 0 0 0 Switched to not addressed SLA

no I2DAT action 0 0 0 1 Switched to not addressed SLA

no I2DAT action 1 0 0 0 Switched to not addressed SLA

no I2DAT action 1 0 0 1 Switched to not addressed SLA

hardware

mode; no recognition of own SLA or General call address

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1.

mode; no recognition of own SLA or General call address. A START condition will be transmitted when the bus becomes free.

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1. A START condition will be transmitted when the bus becomes free.

Table 65: Slave Transmitter mode

Status code (I2STAT)

A8h Own SLA+R has

B0h Arbitration lost in

B8H Data byte in

Status of the I2C hardware

been received; ACK has been returned

SLA+R/W as master; Own SLA+R has been received, ACK has been returned

I2DAT has been transmitted; ACK has been received

Application software response Next action taken by the I2C

to/from I2DAT to I2CON

Load data byte or x 0 0 0 Last data byte will be transmitted

load data byte x 0 0 1 Data byte will be transmitted; ACK

Load data byte or x 0 0 0 Last data byte will be transmitted

load data byte x 0 0 1 Data byte will be transmitted; ACK

Load data byte or x 0 0 0 Last data byte will be transmitted

load data byte x 0 0 1 Data byte will be transmitted; ACK

STA STO SI AA

hardware

and ACK bit will be received

will be received

and ACK bit will be received

bit will be received

and ACK bit will be received

will be received

User manual Rev. 02 — 2 March 2005 68 of 105

Philips Semiconductors

Table 65: Slave Transmitter mode

Status code (I2STAT)

C0H Data byte in

C8H Last data byte in

Status of the I2C hardware

I2DAT has been transmitted; NACK has been received

I2DAT has been transmitted

= 0); ACK has

(AA been received

UM10108

P89LPC924/925 User manual

Application software response Next action taken by the I2C

to/from I2DAT to I2CON

STA STO SI AA

No I2DAT action or0 0 0 0 Switched to not addressed SLA

no I2DAT action or 0 0 0 1 Switched to not addressed SLA

no I2DAT action or 1 0 0 0 Switched to not addressed SLA

no I2DAT action 1 0 0 1 Switched to not addressed SLA

No I2DAT action or0 0 0 0 Switched to not addressed SLA

no I2DAT action or 0 0 0 1 Switched to not addressed SLA

no I2DAT action or 1 0 0 0 Switched to not addressed SLA

no I2DAT action 1 0 0 1 Switched to not addressed SLA

hardware

mode; no recognition of own SLA or General call address.

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1.

mode; no recognition of own SLA or General call address. A START condition will be transmitted when the bus becomes free.

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1. A START condition will be transmitted when the bus becomes free.

mode; no recognition of own SLA or General call address.

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1.

mode; no recognition of own SLA or General call address. A START condition will be transmitted when the bus becomes free.

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 START condition will be transmitted when the bus becomes free.

= 1. A

12. Analog comparators

Two analog comparators are provided on the P89LPC924/925. Input and output options allow use of the comparators in a number of different configurations. Comparator operation is such that the output is a logic 1 (which may be read in a register and/or routed to a pin) when the positive input (one of two selectable pins) is greater than the negative input (selectable from a pin or an internal reference voltage). Otherwise the output is a zero. Each comparator may be configured to cause an interrupt when the output value changes.

User manual Rev. 02 — 2 March 2005 69 of 105

Philips Semiconductors

P89LPC924/925 User manual

UM10108

12.1 Comparator configuration

Each comparator has a control register, CMP1 for comparator 1 and CMP2 for comparator

2. The control registers are identical and are shown in

The overall connections to both comparators are shown in Figure 31. There are eight possible configurations for each comparator, as determined by the control bits in the corresponding CMPn register: CPn, CNn, and OEn. These configurations are shown in

Figure 32.

When each comparator is first enabled, the comparator output and interrupt flag are not guaranteed to be stable for 10 microseconds. The corresponding comparator interrupt should not be enabled during that time, and the comparator interrupt flag must be cleared before the interrupt is enabled in order to prevent an immediate interrupt service.

Table 66: Comparator Control register (CMP1 - address ACh, CMP2 - address ADh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol - - CEn CPn CNn OEn COn CMFn

Reset x x 0 0 0 0 0 0

Ta bl e 67.

Table 67: Comparator Control register (CMP1 - address ACh, CMP2 - address ADh) bit description

Bit Symbol Description

0 CMFn Comparator interrupt flag. This bit is set by hardware whenever the comparator output COn changes state.

This bit will cause a hardware interrupt if enabled. Cleared by software.

1 COn Comparator output, synchronized to the CPU clock to allow reading by software.

2 OEn Output enable. When logic 1, the comparator output is connected to the CMPn pin if the comparator is

enabled (CEn = 1). This output is asynchronous to the CPU clock.

3 CNn Comparator negative input select. When logic 0, the comparator reference pin CMPREF is selected as the

negative comparator input. When logic 1, the internal comparator reference, Vref, is selected as the negative comparator input.

4 CPn Comparator positive input select. When logic 0, CINnA is selected as the positive comparator input. When

1, CINnB is selected as the positive comparator input.

logic

5 CEn Comparator enable. When set, the corresponding comparator function is enabled. Comparator output is

stable 10 microseconds after CEn is set.

6 - reserved

7 - reserved

User manual Rev. 02 — 2 March 2005 70 of 105

Philips Semiconductors

UM10108

P89LPC924/925 User manual

CP1

(P0.4) CIN1A

(P0.3) CIN1B

(P0.5) CMPREF

REF

CN1

CP2

(P0.2) CIN2A

(P0.1) CIN2B

CN2

Fig 31. Comparator input and output connections.

Comparator 1

Comparator 2

12.2 Internal reference voltage

An internal reference voltage, Vref, may supply a default reference when a single comparator input pin is used. Please refer to the P89LPC924/925 data sheet for specifications.

12.3 Comparator interrupt

CO1

CO2

OE1

Change Detect

OE2

CMP1 (P0.6)

CMF1

Interrupt

CMF2

CMP2 (P0.0)

002aaa422

Each comparator has an interrupt flag CMFn contained in its configuration register. This flag is set whenever the comparator output changes state. The flag may be polled by software or may be used to generate an interrupt. The two comparators use one common interrupt vector. The interrupt will be generated when the interrupt enable bit EC in the IEN1 register is set and the interrupt system is enabled via the EA bit in the IEN0 register. If both comparators enable interrupts, after entering the interrupt service routine, the user will need to read the flags to determine which comparator caused the interrupt.

When a comparator is disabled the comparator’s output, COx, goes HIGH. If the comparator output was LOW and then is disabled, the resulting transition of the comparator output from a LOW to HIGH state will set the comparator flag, CMFx. This will cause an interrupt if the comparator interrupt is enabled. The user should therefore disable the comparator interrupt prior to disabling the comparator. Additionally, the user should clear the comparator flag, CMFx, after disabling the comparator.

12.4 Comparators and power reduction modes

Either or both comparators may remain enabled when power-down or Idle mode is activated, but both comparators are disabled automatically in Total Power-down mode.

If a comparator interrupt is enabled (except in Total Power-down mode), a change of the comparator output state will generate an interrupt and wake up the processor. If the comparator output to a pin is enabled, the pin should be configured in the push-pull mode

User manual Rev. 02 — 2 March 2005 71 of 105

Philips Semiconductors

in order to obtain fast switching times while in Power-down mode. The reason is that with the oscillator stopped, the temporary strong pull-up that normally occurs during switching on a quasi-bidirectional port pin does not take place.

Comparators consume power in power-down and Idle modes, as well as in the normal operating mode. This should be taken into consideration when system power consumption is an issue. To minimize power consumption, the user can power-down the comparators by disabling the comparators and setting PCONA.5 to logic in Total Power-down mode.

UM10108

P89LPC924/925 User manual

1, or simply putting the device

CINnA

CMPREF

COn

002aaa618

CINnA

CMPREF

a. CPn, CNn, OEn = 0 0 0 b. CPn, CNn, OEn = 0 0 1

REF

CINnA

(1.23V)

COn

002aaa621

REF

CINnA

(1.23 V)

c. CPn, CNn, OEn = 0 1 0 d. CPn, CNn, OEn = 0 1 1

CINnB

CMPREF

002aaa623

COn

CINnB

CMPREF

e. CPn, CNn, OEn = 1 0 0 f. CPn, CNn, OEn = 1 0 1

REF

CINnB

(1.23V)

COn

002aaa625

REF

CINnB

(1.23 V)

g. CPn, CNn, OEn = 1 1 0 h. CPn, CNn, OEn = 1 1 1

Fig 32. Comparator configurations.

COn

002aaa620

002aaa622

COn

002aaa624

002aaa626

COn

CMPn

12.5 Comparators configuration example

The code shown below is an example of initializing one comparator. Comparator 1 is configured to use the CIN1A and CMPREF inputs, outputs the comparator result to the CMP1 pin, and generates an interrupt when the comparator output changes.

CMPINIT:

MOV PT0AD,#030h ;Disable digital INPUTS on pins CIN1A, CMPREF.

ANL P0M2,#0CFh ;Disable digital OUTPUTS on pins that are used ORL P0M1,#030h ;for analog functions: CIN1A, CMPREF. MOV CMP1,#020h ;Turn on comparator 1 and set up for:

; - Positive input on CIN1A.

; - Negative input from CMPREF pin. ; - Output to CMP1 pin enabled. CALL delay10us ;start up for at least 10 microseconds before use. ANL CMP1,#0FEh ;Clear comparator 1 interrupt flag.

User manual Rev. 02 — 2 March 2005 72 of 105

Philips Semiconductors

SETB EC ;Enable the comparator interrupt. The priority is left at the current value. SETB EA ;Enable the interrupt system (if needed). RET ;Return to caller.

The interrupt routine used for the comparator must clear the interrupt flag (CMF1 in this case) before returning.

13. Keypad interrupt (KBI)

The Keypad Interrupt function is intended primarily to allow a single interrupt to be generated when Port 0 is equal to or not equal to a certain pattern. This function can be used for bus address recognition or keypad recognition. The user can configure the port via SFRs for different tasks.

There are three SFRs used for this function. The Keypad Interrupt Mask Register (KBMASK) is used to define which input pins connected to Port 0 are enabled to trigger the interrupt. The Keypad Pattern Register (KBPATN) is used to define a pattern that is compared to the value of Port 0. The Keypad Interrupt Flag (KBIF) in the Keypad Interrupt Control Register (KBCON) is set when the condition is matched while the Keypad Interrupt function is active. An interrupt will be generated if it has been enabled by setting the EKBI bit in IEN1 register and EA = 1. The PATN_SEL bit in the Keypad Interrupt Control Register (KBCON) is used to define equal or not-equal for the comparison.

UM10108

P89LPC924/925 User manual

In order to use the Keypad Interrupt as an original KBI function like in the 87LPC76x series, the user needs to set KBPATN = 0FFH and PATN_SEL = 0 (not equal), then any key connected to Port0 which is enabled by KBMASK register is will cause the hardware to set KBIF = 1 and generate an interrupt if it has been enabled. The interrupt may be used to wake up the CPU from Idle or Power-down modes. This feature is particularly useful in handheld, battery powered systems that need to carefully manage power consumption yet also need to be convenient to use.

In order to set the flag and cause an interrupt, the pattern on Port 0 must be held longer than 6 CCLKs.

Table 68: Keypad Pattern register (KBPATN - address 93h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol K B PATN . 7 K B PATN . 6 K BPAT N . 5 KBPATN.4 K BPAT N .3 K B PAT N. 2 K BPAT N .1 K B PATN . 0

Reset 1 1 1 1 1 1 1 1

Table 69: Keypad Pattern register (KBPATN - address 93h) bit description

Bit Symbol Access Description

0:7 K B PAT N. 7 : 0 R/W Pattern bit 0 - bit 7

Table 70: Keypad Control register (KBCON - address 94h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol - - - - - - PAT N_ S E L KBIF

Reset x x x x x x 0 0

User manual Rev. 02 — 2 March 2005 73 of 105

Philips Semiconductors

P89LPC924/925 User manual

Table 71: Keypad Control register (KBCON - address 94h) bit description

Bit Symbol Access Description

0 KBIF R/W Keypad Interrupt Flag. Set when Port 0 matches user defined conditions specified in KBPATN,

KBMASK, and PATN_SEL. Needs to be cleared by software by writing logic 0.

1 PATN _ S EL R/W Pattern Matching Polarity selection. When set, Port 0 has to be equal to the user-defined

Pattern in KBPATN to generate the interrupt. When clear, Port 0 has to be not equal to the value of KBPATN register to generate the interrupt.

2:7 - - reserved

Table 72: Keypad Interrupt Mask register (KBMASK - address 86h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol KBMASK.7 KBMASK.6 KBMASK.5 KBMASK.4 KBMASK.3 KBMASK.2 KBMASK.1 KBMASK.0

Reset 0 0 0 0 0 0 0 0

Table 73: Keypad Interrupt Mask register (KBMASK - address 86h) bit description

Bit Symbol Description

0 KBMASK.0 When set, enables P0.0 as a cause of a Keypad Interrupt.

1 KBMASK.1 When set, enables P0.1 as a cause of a Keypad Interrupt.

2 KBMASK.2 When set, enables P0.2 as a cause of a Keypad Interrupt.

3 KBMASK.3 When set, enables P0.3 as a cause of a Keypad Interrupt.

4 KBMASK.4 When set, enables P0.4 as a cause of a Keypad Interrupt.

5 KBMASK.5 When set, enables P0.5 as a cause of a Keypad Interrupt.

6 KBMASK.6 When set, enables P0.6 as a cause of a Keypad Interrupt.

7 KBMASK.7 When set, enables P0.7 as a cause of a Keypad Interrupt.

UM10108

[1] The Keypad Interrupt must be enabled in order for the settings of the KBMASK register to be effective.

14. Watchdog timer (WDT)

The Watchdog timer subsystem protects the system from incorrect code execution by causing a system reset when it underflows as a result of a failure of software to feed the timer prior to the timer reaching its terminal count. The Watchdog timer can only be reset by a power-on reset.

14.1 Watchdog function

The user has the ability using the WDCON and UCFG1 registers to control the run /stop condition of the WDT, the clock source for the WDT, the prescaler value, and whether the WDT is enabled to reset the device on underflow. In addition, there is a safety mechanism which forces the WDT to be enabled by values programmed into UCFG1 either through IAP or a commercial programmer.

The WDTE bit (UCFG1.7), if set, enables the WDT to reset the device on underflow. Following reset, the WDT will be running regardless of the state of the WDTE bit.

The WDRUN bit (WDCON.2) can be set to start the WDT and cleared to stop the WDT. Following reset this bit will be set and the WDT will be running. All writes to WDCON need to be followed by a feed sequence (see user to select the clock source for the WDT and the prescaler.

Section 14.2). Additional bits in WDCON allow the

User manual Rev. 02 — 2 March 2005 74 of 105

Philips Semiconductors

When the timer is not enabled to reset the device on underflow, the WDT can be used in ‘timer mode’ and be enabled to produce an interrupt (IEN0.6) if desired.

The Watchdog Safety Enable bit, WDSE (UCFG1.4) along with WDTE, is designed to force certain operating conditions at power-up. Refer to

Figure 35 shows the Watchdog timer in Watchdog mode. It consists of a programmable

13-bit prescaler, and an 8-bit down counter. The down counter is clocked (decremented) by a tap taken from the prescaler. The clock source for the prescaler is either PCLK or the Watchdog oscillator selected by the WDCLK bit in the WDCON register. (Note that switching of the clock sources will not take effect immediately - see

The Watchdog asserts the Watchdog reset when the Watchdog count underflows and the Watchdog reset is enabled. When the Watchdog reset is enabled, writing to WDL or WDCON must be followed by a feed sequence for the new values to take effect.

If a Watchdog reset occurs, the internal reset is active for at least one Watchdog clock cycle (PCLK or the Watchdog oscillator clock). If CCLK is still running, code execution will begin immediately after the reset cycle. If the processor was in Power-down mode, the Watchdog reset will start the oscillator and code execution will resume after the oscillator is stable.

UM10108

P89LPC924/925 User manual

Ta bl e 74 for details.

Section 14.3).

Table 74: Watchdog timer configuration.

WDTE (UCFG1.7) WDSE (UCFG1.4) FUNCTION

0 x The Watchdog reset is disabled. The timer can be used as an internal timer and

can be used to generate an interrupt. WDSE has no effect.

1 0 The Watchdog reset is enabled. The user can set WDCLK to choose the clock

source.

1 1 The watchdog reset is enabled, along with additional safety features:

1. WDCLK is forced to 1 (using watchdog oscillator)

2. WDCON and WDL register can only be written once

3. WDRUN is forced to 1 and cannot be cleared by software.

Watchdog

oscillator

PCLK

WDCLK after a Watchdog feed

sequence

PRE2

PRE1

PRE0

DECODE

000 001 010 011 100 101 110 111

128

256

512÷1024÷2048÷4096

TO WATCHDOG DOWN COUNTER (after one prescaler count delay)

002aaa938

Fig 33. Watchdog prescaler.

User manual Rev. 02 — 2 March 2005 75 of 105

Philips Semiconductors

14.2 Feed sequence

The Watchdog timer control register and the 8-bit down counter (See Figure 34) are not directly loaded by the user. The user writes to the WDCON and the WDL SFRs. At the end of a feed sequence, the values in the WDCON and WDL SFRs are loaded to the control register and the 8-bit down counter. Before the feed sequence, any new values written to these two SFRs will not take effect. To avoid a Watchdog reset, the Watchdog timer needs to be fed (via a special sequence of software action called the feed sequence) prior to reaching an underflow.

To feed the Watchdog, two write instructions must be sequentially executed successfully. Between the two write instructions, SFR reads are allowed, but writes are not allowed. The instructions should move A5H to the WFEED1 register and then 5AH to the WFEED2 register. An incorrect feed sequence will cause an immediate Watchdog reset. The program sequence to feed the Watchdog timer is as follows:

CLR EA ;disable interrupt MOV WFEED1,#0A5h ;do watchdog feed part 1 MOV WFEED2,#05Ah ;do watchdog feed part 2 SETB EA ;enable interrupt

UM10108

P89LPC924/925 User manual

This sequence assumes that the P89LPC924/925 interrupt system is enabled and there is a possibility of an interrupt request occurring during the feed sequence. If an interrupt was allowed to be serviced and the service routine contained any SFR writes, it would trigger a Watchdog reset. If it is known that no interrupt could occur during the feed sequence, the instructions to disable and re-enable interrupts may be removed.

In Watchdog mode (WDTE = 1), writing the WDCON register must be IMMEDIATELY followed by a feed sequence to load the WDL to the 8-bit down counter, and the WDCON to the shadow register. If writing to the WDCON register is not immediately followed by the feed sequence, a Watchdog reset will occur.

For example: setting WDRUN = 1:

MOV ACC,WDCON ;get WDCON SETB ACC.2 ;set WD_RUN = 1 MOV WDL,#0FFh ;New count to be loaded to 8-bit down counter CLR EA ;disable interrupt MOV WDCON,ACC ;write back to WDCON (after the watchdog is enabled, a feed must occur ; immediately) MOV WFEED1,#0A5h ;do watchdog feed part 1 MOV WFEED2,#05Ah ;do watchdog feed part 2 SETB EA ;enable interrupt

In timer mode (WDTE = 0), WDCON is loaded to the control register every CCLK cycle (no feed sequence is required to load the control register), but a feed sequence is required to load from the WDL SFR to the 8-bit down counter before a time-out occurs.

The number of Watchdog clocks before timing out is calculated by the following equations:

tclks 2

where:

User manual Rev. 02 — 2 March 2005 76 of 105

5 PRE+()

()WDL 1+()1+=

(1)

Philips Semiconductors

PRE is the value of prescaler (PRE2 to PRE0) which can be the range 0 to 7, and;

WDL is the value of Watchdog load register which can be the range of 0 to 255.

The minimum number of tclks is:

UM10108

P89LPC924/925 User manual

tclks 2

The maximum number of tclks is:

tclks 2

Ta bl e 77 shows sample P89LPC924/925 timeout values.

Table 75: Watchdog Timer Control register (WDCON - address A7h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol PRE2 PRE1 PRE0 - - WDRUN WDTOF WDCLK

Reset 1 1 1 x x 1 1/0 1

Table 76: Watchdog Timer Control register (WDCON - address A7h) bit description

Bit Symbol Description

0 WDCLK Watchdog input clock select. When set, the Watchdog oscillator is selected. When cleared, PCLK is

selected. (If the CPU is powered down, the Watchdog is disabled if WDCLK = 0, see Section 14.5). (Note: If both WDTE and WDSE are set to 1, this bit is forced to 1.) Refer to Section 14.3 for details.

1 WDTOF Watchdog Timer Time-Out Flag. This bit is set when the 8-bit down counter underflows. In Watchdog mode,

a feed sequence will clear this bit. It can also be cleared by writing logic 0 to this bit in software.

2 WDRUN Watchdog Run Control. The Watchdog timer is started when WDRUN = 1 and stopped when WDRUN = 0.

This bit is forced to logic 1 (Watchdog running) and cannot be cleared to zero if both WDTE and WDSE are set to 1.

3:4 - reserved

5 PRE0

Clock Prescaler Tap Select. Refer to Ta bl e 77 for details.6 PRE1

7 PRE2

50+()

()01+()133=+=

57+()

()255 1+()1 1048577=+=

(2)

(3)

Table 77: Watchdog timeout vales.

PRE2 to PRE0 WDL (in decimal) Timeout Period

(in Watchdog clock cycles)

000 0 33 82.5 µs 5.50 µs

255 8,193 20.5 ms 1.37 ms

001 0 65 162.5 µs 10.8 µs

255 16,385 41.0 ms 2.73 ms

010 0 129 322.5 µs 21.5 µs

255 32,769 81.9 ms 5.46 ms

011 0 257 642.5 µs 42.8 µs

255 65,537 163.8 ms 10.9 ms

User manual Rev. 02 — 2 March 2005 77 of 105

Watchdog Clock Source

400 KHz Watchdog Oscillator Clock (Nominal)

12 MHz CCLK (6 MHz CCLK/2 Watchdog Clock)

Philips Semiconductors

P89LPC924/925 User manual

Table 77: Watchdog timeout vales.

PRE2 to PRE0 WDL (in decimal) Timeout Period

(in Watchdog clock cycles)

100 0 513 1.28 ms 85.5 µs

255 131,073 327.7 ms 21.8 ms

101 0 1,025 2.56 ms 170.8 µs

255 262,145 655.4 ms 43.7 ms

110 0 2,049 5.12 ms 341.5 µs

255 524,289 1.31 s 87.4 ms

111 0 4097 10.2 ms 682.8 ms

255 1,048,577 2.62 s 174.8 ms

Watchdog Clock Source

400 KHz Watchdog Oscillator Clock (Nominal)

UM10108

12 MHz CCLK (6 MHz CCLK/2 Watchdog Clock)

14.3 Watchdog clock source

The Watchdog timer system has an on-chip 400 KHz oscillator. The Watchdog timer can be clocked from either the Watchdog oscillator or from PCLK (refer to configuring the WDCLK bit in the Watchdog Control Register WDCON. When the Watchdog feature is enabled, the timer must be fed regularly by software in order to prevent it from resetting the CPU.

Figure 33) by

After changing WDCLK (WDCON.0), switching of the clock source will not immediately take effect. As shown in sequence. In addition, due to clock synchronization logic, it can take two old clock cycles before the old clock source is deselected, and then an additional two new clock cycles before the new clock source is selected.

Since the prescaler starts counting immediately after a feed, switching clocks can cause some inaccuracy in the prescaler count. The inaccuracy could be as much as two old clock source counts plus two new clock cycles.

Note: When switching clocks, it is important that the old clock source is left enabled for two clock cycles after the feed completes. Otherwise, the Watchdog may become disabled when the old clock source is disabled. For example, suppose PCLK (WCLK current clock source. After WCLK is set to logic PCLK cycles (4 CCLKs) after the feed completes before going into Power-down mode. Otherwise, the Watchdog could become disabled when CCLK turns off. The Watchdog oscillator will never become selected as the clock source unless CCLK is turned on again first.

Figure 35, the selection is loaded after a Watchdog feed

= 0) is the

1, the program should wait at least two

User manual Rev. 02 — 2 March 2005 78 of 105

Philips Semiconductors

MOV WFEED1, #0A5H MOV WFEED2, #05AH

UM10108

P89LPC924/925 User manual

WDL (C1H)

Watchdog

oscillator

PCLK

WDCON (A7H)

PRESCALER

CONTROL REGISTER

PRE2 PRE1 PRE0 – – WDRUN WDTOF WDCLK

Fig 34. Watchdog timer in Watchdog Mode (WDTE = 1).

MOV WFEED1, #0A5H MOV WFEED2, #05AH

Watchdog

oscillator

PCLK

PRESCALER

8-BIT DOWN

COUNTER

WDL (C1H)

8-BIT DOWN

COUNTER

RESET see note (1)

SHADOW REGISTER FOR WDCON

002aaa423

Interrupt

SHADOW REGISTER FOR WDCON

002aaa939

WDCON (A7H)

CONTROL REGISTER

PRE2 PRE1 PRE0 – – WDRUN WDTOF WDCLK

Fig 35. Watchdog timer in Timer Mode (WDTE = 0).

14.4 Watchdog timer in Timer mode

Figure 35 shows the Watchdog timer in Timer Mode. In this mode, any changes to

WDCON are written to the shadow register after one Watchdog clock cycle. A Watchdog underflow will set the WDTOF bit. If IEN0.6 is set, the Watchdog underflow is enabled to cause an interrupt. WDTOF is cleared by writing a logic underflow occurs, the contents of WDL is reloaded into the down counter and the Watchdog timer immediately begins to count down again.

A feed is necessary to cause WDL to be loaded into the down counter before an underflow occurs. Incorrect feeds are ignored in this mode.

User manual Rev. 02 — 2 March 2005 79 of 105

0 to this bit in software. When an

Philips Semiconductors

14.5 Power-down operation

The WDT oscillator will continue to run in power-down, consuming approximately 50 µA, as long as the WDT oscillator is selected as the clock source for the WDT. Selecting PCLK as the WDT source will result in the WDT oscillator going into power-down with the rest of the device (see therefore the Watchdog is effectively disabled.

14.6 Periodic wake-up from power-down without an external oscillator

Without using an external oscillator source, the power consumption required in order to have a periodic wake-up is determined by the power consumption of the internal oscillator source used to produce the wake-up. The Real-time clock running from the internal RC oscillator can be used. The power consumption of this oscillator is approximately 300 Instead, if the WDT is used to generate interrupts the current is reduced to approximately 50

µA. Whenever the WDT underflows, the device will wake up.

15. Additional features

UM10108

P89LPC924/925 User manual

Section 14.3). Power-down mode will also prevent PCLK from running and

µA.

The AUXR1 register contains several special purpose control bits that relate to several chip features. AUXR1 is described in

Table 78: AUXR1 register (address A2h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol CLKLP EBRR ENT1 ENT0 SRST 0 - DPS

Reset 0 0 0 0 0 0 x 0

Table 79: AUXR1 register (address A2h) bit description

Bit Symbol Description

0 DPS Data Pointer Select. Chooses one of two Data Pointers.

1 - Not used. Allowable to set to a logic 1.

2 0 This bit contains a hard-wired 0. Allows toggling of the DPS bit by incrementing AUXR1, without interfering

with other bits in the register.

3 SRST Software Reset. When set by software, resets the P89LPC924/925 as if a hardware reset occurred.

4 ENT0 When set the P1.2 pin is toggled whenever Timer 0 overflows. The output frequency is therefore one half of

the Timer 0 overflow rate. Refer to the Timer/Counters section for details.

5 ENT1 When set, the P0.7 pin is toggled whenever Timer 1 overflows. The output frequency is therefore one half of

the Timer 1 overflow rate. Refer to the Timer/Counters section for details.

6 EBRR UART Break Detect Reset Enable. If logic 1, UART Break Detect will cause a chip reset and force the device

into ISP mode.

7 CLKLP Clock Low Power Select. When set, reduces power consumption in the clock circuits. Can be used when the

clock frequency is 8

MHz or less. After reset this bit is cleared to support up to 12 MHz operation.

Ta bl e 79.

15.1 Software reset

The SRST bit in AUXR1 gives software the opportunity to reset the processor completely, as if an external reset or Watchdog reset had occurred. If a value is written to AUXR1 that contains a logic 1 at bit position 3, all SFRs will be initialized and execution will resume at program address 0000. Care should be taken when writing to AUXR1 to avoid accidental software resets.

User manual Rev. 02 — 2 March 2005 80 of 105

Philips Semiconductors

15.2 Dual Data Pointers

The dual Data Pointers (DPTR) adds to the ways in which the processor can specify the address used with certain instructions. The DPS bit in the AUXR1 register selects one of the two Data Pointers. The DPTR that is not currently selected is not accessible to software unless the DPS bit is toggled.

Specific instructions affected by the Data Pointer selection are:

INC DPTR — Increments the Data Pointer by 1.

JMP @A+DPTR — Jump indirect relative to DPTR value.

MOV DPTR, #data16 — Load the Data Pointer with a 16-bit constant.

MOVC A, @A+DPTR — Move code byte relative to DPTR to the accumulator.

MOVX A, @DPTR — Move data byte the accumulator to data memory relative to DPTR.

MOVX@DPTR, A — Move data byte from data memory relative to DPTR to the

accumulator.

Also, any instruction that reads or manipulates the DPH and DPL registers (the upper and lower bytes of the current DPTR) will be affected by the setting of DPS. The MOVX instructions have limited application for the an external data bus. However, they may be used to access Flash configuration information (see Flash Configuration section) or auxiliary data (XDATA) memory.

UM10108

P89LPC924/925 User manual

P89LPC924/925 since the part does not have

Bit 2 of AUXR1 is permanently wired as a logic 0. This is so that the DPS bit may be toggled (thereby switching Data Pointers) simply by incrementing the AUXR1 register, without the possibility of inadvertently altering other bits in the register.

16. Flash memory

The P89LPC924/925 Flash memory provides in-circuit electrical erasure and programming. The Flash can be read and written as bytes. The Sector and Page Erase functions can erase any Flash sector (1 will erase the entire program memory. Five Flash programming methods are available. On-chip erase and write timing generation contribute to a user-friendly programming interface. The erase and program cycles. The cell is designed to optimize the erase and programming mechanisms. The Program/Erase algorithms.

16.1 Features

• Parallel programming with industry-standard commercial programmers.

• In-Circuit serial Programming (ICP) with industry-standard commercial programmers.

• IAP-Lite allows individual and multiple bytes of code memory to be used for data

• Internal fixed boot ROM, containing low-level In-Application Programming (IAP)

• Default serial loader providing In-System Programming (ISP) via the serial port,

kB) or page (64 bytes). The Chip Erase operation

P89LPC924/925 Flash reliably stores memory contents even after 100,000

P89LPC924/925 uses VDD as the supply voltage to perform the

storage and programmed under control of the end application.

routines that can be called from the end application (in addition to IAP-Lite).

located in upper end of user program memory.

User manual Rev. 02 — 2 March 2005 81 of 105

Philips Semiconductors

• Boot vector allows user provided Flash loader code to reside anywhere in the Flash

memory space, providing flexibility to the user.

• Programming and erase over the full operating voltage range.

• Read/Programming/Erase using ISP/IAP/IAP-Lite.

• Any flash program operation in 2 ms (4 ms for erase/program).

• Programmable security for the code in the Flash for each sector.

• > 100,000 typical erase/program cycles for each byte.

• 10-year minimum data retention.

16.2 Flash programming and erase

The P89LPC924/925 program memory consists 1 kB sectors. Each sector can be further divided into 64-byte pages. In addition to sector erase and page erase, a 64-byte page register is included which allows from 1 to 64 bytes of a given page to be programmed at the same time, substantially reducing overall programming time. Five methods of programming this device are available.

• Parallel programming with industry-standard commercial programmers.

• In-Circuit serial Programming (ICP) with industry-standard commercial programmers.

• IAP-Lite allows individual and multiple bytes of code memory to be used for data

storage and programmed under control of the end application.

• Internal fixed boot ROM, containing low-level In-Application Programming (IAP)

routines that can be called from the end application (in addition to IAP-Lite).

• A factory-provided default serial loader, located in upper end of user program

memory, providing In-System Programming (ISP) via the serial port.

UM10108

P89LPC924/925 User manual

16.3 Using Flash as data storage: IAP-Lite

The Flash code memory array of this device supports IAP-Lite in addition to standard IAP functions. Any byte in a non-secured sector of the code memory array may be read using the MOVC instruction and thus is suitable for use as non-volatile data storage. IAP-Lite provides an erase-program function that makes it easy for one or more bytes within a page to be erased and programmed in a single operation without the need to erase or program any other bytes in the page. IAP-Lite is performed in the application under the control of the microcontroller’s firmware using four SFRs and an internal 64-byte ‘page register’ to facilitate erasing and programing within unsecured sectors. These SFRs are:

• FMCON (Flash Control Register). When read, this is the status register. When written,

this is a command register. Note that the status bits are cleared to logic command is written.

0s when the

• FMDATA (Flash Data Register). Accepts data to be loaded into the page register.

• FMADRL, FMADRH (Flash memory address LOW, Flash memory address HIGH).

Used to specify the byte address within the page register or specify the page within user code memory.

The page register consists of 64 bytes and an update flag for each byte. When a LOAD command is issued to FMCON the page register contents and all of the update flags will be cleared. When FMDATA is written, the value written to FMDATA will be stored in the page register at the location specified by the lower 6 bits of FMADRL. In addition, the

User manual Rev. 02 — 2 March 2005 82 of 105

Philips Semiconductors

update flag for that location will be set. FMADRL will auto-increment to the next location. Auto-increment after writing to the last byte in the page register will ‘wrap -around’ to the first byte in the page register, but will not affect FMADRL[7:6]. Bytes loaded into the page register do not have to be continuous. Any byte location can be loaded into the page register by changing the contents of FMADRL prior to writing to FMDATA. However, each location in the page register can only be written once following each LOAD command. Attempts to write to a page register location more than once should be avoided.

FMADRH and FMADRL[7:6] are used to select a page of code memory for the erase-program function. When the erase-program command is written to FMCON, the locations within the code memory page that correspond to updated locations in the page register, will have their contents erased and programmed with the contents of their corresponding locations in the page register. Only the bytes that were loaded into the page register will be erased and programmed in the user code array. Other bytes within the user code memory will not be affected.

Writing the erase-program command (68H) to FMCON will start the erase-program process and place the CPU in a program-idle state. The CPU will remain in this idle state until the erase-program cycle is either completed or terminated by an interrupt. When the program-idle state is exited FMCON will contain status information for the cycle.

UM10108

P89LPC924/925 User manual

If an interrupt occurs during an erase/programming cycle, the erase/programming cycle will be aborted and the OI flag (Operation Interrupted) in FMCON will be set. If the application permits interrupts during erasing-programming the user code should check the OI flag (FMCON.0) after each erase-programming operation to see if the operation was aborted. If the operation was aborted, the user’s code will need to repeat the process starting with loading the page register.

The erase-program cycle takes 4 ms (2 ms for erase, 2 ms for programming) to complete, regardless of the number of bytes that were loaded into the page register.

Erasing-programming of a single byte (or multiple bytes) in code memory is accomplished using the following steps:

• Write the LOAD command (00H) to FMCON. The LOAD command will clear all

locations in the page register and their corresponding update flags.

• Write the address within the page register to FMADRL. Since the loading the page

register uses FMADRL[5:0], and since the erase-program command uses FMADRH and FMADRL[7:6], the user can write the byte location within the page register (FMADRL[5:0]) and the code memory page address (FMADRH and FMADRL[7:6]) at this time.

• Write the data to be programmed to FMDATA. This will increment FMADRL pointing to

the next byte in the page register.

• Write the address of the next byte to be programmed to FMADRL, if desired. (Not

needed for contiguous bytes since FMADRL is auto-incremented). All bytes to be programmed must be within the same page.

• Write the data for the next byte to be programmed to FMDATA.

• Repeat writing of FMADRL and/or FMDATA until all desired bytes have been loaded

into the page register.

• Write the page address in user code memory to FMADRH and FMADRL[7:6], if not

previously included when writing the page register address to FMADRL[5:0].

User manual Rev. 02 — 2 March 2005 83 of 105

Philips Semiconductors

P89LPC924/925 User manual

UM10108

• Write the erase-program command (68H) to FMCON, starting the erase-program

cycle.

• Read FMCON to check status. If aborted, repeat starting with the LOAD command.

Table 80: Flash Memory Control register (FMCON - address E4h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol (R) - - - - HVA HVE SV OI

Symbol (W) FMCMD.7 FMCMD.6 FMCMD.5 FMCMD.4 FMCMD.3 FMCMD.2 FMCMD.1 FMCMD.0

Reset 0 0 0 0 0 0 0 0

Table 81: Flash Memory Control register (FMCON - address E4h) bit description

Bit Symbol Access Description

0 OI R Operation interrupted. Set when cycle aborted due to an interrupt or reset.

FMCMD.0 W Command byte bit 0.

1 SV R Security violation. Set when an attempt is made to program, erase, or CRC a secured sector or

page.

FMCMD.1 W Command byte bit 1

2 HVE R High voltage error. Set when an error occurs in the high voltage generator.

FMCMD.2 W Command byte bit 2.

3 HVA R High voltage abort. Set if either an interrupt or a brown-out is detected during a program or

erase cycle. Also set if the brown-out detector is disabled at the start of a program or erase cycle.

FMCMD.3 W Command byte bit 3.

4:7 - R reserved

4:7 FMCMD.4 W Command byte bit 4.

4:7 FMCMD.5 W Command byte bit 5.

4:7 FMCMD.6 W Command byte bit 6.

4:7 FMCMD.7 W Command byte bit 7.

An assembly language routine to load the page register and perform an erase/program operation is shown below.

;************************************************** ;* pgm user code * ;************************************************** ;* * ;* Inputs: * ;*R3 = number of bytes to program (byte) * ;*R4 = page address MSB(byte) * ;*R5 = page address LSB(byte) * ;*R7 = pointer to data buffer in RAM(byte) * ;* Outputs: * ;*R7 = status (byte) * ;* C = clear on no error, set on error * ;**************************************************

LOAD EQU 00H EP EQU 68H

User manual Rev. 02 — 2 March 2005 84 of 105

Philips Semiconductors

PGM_USER: MOV FMCON,#LOAD ;load command, clears page register MOV FMADRH,R4 ;get high address MOV FMADRL,R5 ;get low address MOV A,R7 ; MOV R0,A ;get pointer into R0 LOAD_PAGE: MOV FMDAT,@R0 ;write data to page register INC R0 ;point to next byte DJNZ R3,LOAD_PAGE ;do until count is zero MOV FMCON,#EP ;else erase and program the page

MOV R7,FMCON ;copy status for return MOV A,R7 ;read status ANL A,#0FH ;save only four lower bits JNZ BAD ; CLR C ;clear error flag if good RET ;and return BAD: SETB C ;set error flag RET ;and return

UM10108

P89LPC924/925 User manual

A C-language routine to load the page register and perform an erase/program operation is shown below.

#include <REG931.H> unsigned char idata dbytes[64]; // data buffer unsigned char Fm_stat; // status result bit PGM_USER (unsigned char, unsigned char); bit prog_fail;

void main () { prog_fail=PGM_USER(0x1F,0xC0); }

bit PGM_USER (unsigned char page_hi, unsigned char page_lo) {

#define LOAD 0x00 // clear page register, enable loading #define EP 0x68// erase and program page unsigned char i; // loop count

FMCON = LOAD; //load command, clears page reg FMADRH = page_hi; // FMADRL = page_lo; //write my page address to addr regs

for (i=0;i<64;i=i+1)

{ FMDATA = dbytes[i]; }

User manual Rev. 02 — 2 March 2005 85 of 105

Philips Semiconductors

FMCON = EP; //erase and prog page command Fm_stat = FMCON; //read the result status if ((Fm_stat & 0x0F)!=0) prog_fail=1; else prog_fail=0; return(prog_fail); }

16.4 In-circuit programming (ICP)

In-Circuit Programming is a method intended to allow commercial programmers to program and erase these devices without removing the microcontroller from the system. The In-Circuit Programming facility consists of a series of internal hardware resources to facilitate remote programming of the Philips has made in-circuit programming in an embedded application possible with a minimum of additional expense in components and circuit board area. The ICP function uses five pins (V available to interface your application to an external programmer in order to use this feature.

16.5 ISP and IAP capabilities of the P89LPC924/925

UM10108

P89LPC924/925 User manual

P89LPC924/925 through a two-wire serial interface.

, VSS, P0.5, P0.4, and RST). Only a small connector needs to be

An In-Application Programming (IAP) interface is provided to allow the end user’s application to erase and reprogram the user code memory. In addition, erasing and reprogramming of user-programmable bytes including UCFG1, the Boot Status Bit, and the Boot Vector is supported. As shipped from the factory, the upper 512 code space contains a serial In-System Programming (ISP) loader allowing for the device to be programmed in circuit through the serial port. This ISP boot loader will, in turn, call low-level routines through the same common entry point that can be used by the end-user application.

16.6 Boot ROM

When the microcontroller contains a a 256 byte Boot ROM that is separate from the user’s Flash program memory. This Boot ROM contains routines which handle all of the low level details needed to erase and program the user Flash memory. A user program simply calls a common entry point in the Boot ROM with appropriate parameters to accomplish the desired operation. Boot ROM operations include operations such as erase sector, erase page, program page, CRC, program security bit, etc. The Boot ROM occupies the program memory space at the top of the address space from FF00 to FFFF hex, thereby not conflicting with the user program memory space. This function is in addition to the IAP-Lite feature.

16.7 Power on reset code execution

The P89LPC924/925 contains two special Flash elements: the BOOT VECTOR and the Boot Status Bit. Following reset, the Status Bit. If the Boot Status Bit is set to zero, power-up execution starts at location 0000H, which is the normal start address of the user’s application code. When the Boot Status Bit is set to a va one, the contents of the Boot Vector is used as the HIGH byte of the execution address and the LOW byte is set to 00H.

P89LPC924/925 examines the contents of the Boot

bytes of user

The factory default settings for these devices are show in Tab le 82, below. The factory pre-programmed boot loader can be erased by the user. Users who wish to use this

loader should take cautions to avoid erasing the last 1

User manual Rev. 02 — 2 March 2005 86 of 105

kB sector on the device.

Philips Semiconductors

P89LPC924/925 User manual

Instead, the page erase function can be used to erase the eight 64-byte pages located in this sector. A custom boot loader can be written with the Boot Vector set to

the custom boot loader, if desired.

Table 82: Boot loader address and default Boot vector

Product Flash size End

address

P89LPC924 4K × 8 0FFFh 15h DDh 1Bh 1K × 8 64 × 8 0E00h-0FFFh 0Fh

P89LPC925 8K × 8 1FFFh 15h DDh 1Ch 1K × 8 64 × 8 1E00h-1FFFh 1Fh

Signature bytes Sector

Mfg. id Id 1 Id 2

size

Page size

Pre-programmed serial loader

UM10108

Default Boot vector

16.8 Hardware activation of Boot Loader

The boot loader can also be executed by forcing the device into ISP mode during a power-on sequence (see the reset pin initially held LOW and holding the pin LOW for a fixed time after VDD rises to its normal operating value. This is followed by three, and only three, properly timed LOW-going pulses. Fewer or more than three pulses will result in the device not entering ISP mode. Timing specifications may be found in the data sheet for this device.

Figure 36). This is accomplished by powering up the device with

This has the same effect as having a non-zero status bit. This allows an application to be built that will normally execute the user code but can be manually forced into ISP operation. If the factory default setting for the Boot Vector is changed, it will no longer point to the factory pre-programmed ISP boot loader code. If this happens, the only way it is possible to change the contents of the Boot Vector is through the parallel or ICP programming method, provided that the end user application does not contain a customized loader that provides for erasing and reprogramming of the Boot Vector and Boot Status Bit. After programming the Flash, the status byte should be programmed to zero in order to allow execution of the user’s application code beginning at address 0000H.

RST

Fig 36. Forcing ISP mode.

16.9 In-system programming (ISP)

In-System Programming is performed without removing the microcontroller from the system. The In-System Programming facility consists of a series of internal hardware resources coupled with internal firmware to facilitate remote programming of the P89LPC924/925 through the serial port. This firmware is provided by Philips and embedded within each facility has made in-circuit programming in an embedded application possible with a minimum of additional expense in components and circuit board area. The ISP function uses five pins (V available to interface your application to an external circuit in order to use this feature.

P89LPC924/925 device. The Philips In-System Programming

, VSS, TXD, RXD, and RST). Only a small connector needs to be

002aaa912

User manual Rev. 02 — 2 March 2005 87 of 105

Philips Semiconductors

16.10 Using the In-system programming (ISP)

The ISP feature allows for a wide range of baud rates to be used in your application, independent of the oscillator frequency. It is also adaptable to a wide range of oscillator frequencies. This is accomplished by measuring the bit-time of a single bit in a received character. This information is then used to program the baud rate in terms of timer counts based on the oscillator frequency. The ISP feature requires that an initial character (an uppercase U) be sent to the provides auto-echo of received characters. Once baud rate initialization has been performed, the ISP firmware will only accept Intel Hex-type records. Intel Hex records consist of ASCII characters used to represent hexadecimal values and are summarized below:

:NNAAAARRDD..DDCC<crlf>

In the Intel Hex record, the ‘NN’ represents the number of data bytes in the record. The P89LPC924/925 will accept up to 64 (40H) data bytes. The ‘AAAA’ string represents the address of the first byte in the record. If there are zero bytes in the record, this field is often set to 0000. The ‘RR’ string indicates the record type. A record type of ‘00’ is a data record. A record type of ‘01’ indicates the end-of-file mark. In this application, additional record types will be added to indicate either commands or data for the ISP facility. The maximum number of data bytes in a record is limited to 64 (decimal). ISP commands are summarized in in the record is stored internally and a checksum calculation is performed. The operation indicated by the record type is not performed until the entire record has been received. Should an error occur in the checksum, the port indicating a checksum error. If the checksum calculation is found to match the checksum in the record, then the command will be executed. In most cases, successful reception of the record will be indicated by transmitting a ‘.’ character out the serial port.

UM10108

P89LPC924/925 User manual

P89LPC924/925 to establish the baud rate. The ISP firmware

Ta bl e 83. As a record is received by the P89LPC924/925, the information

P89LPC924/925 will send an ‘X’ out the serial

User manual Rev. 02 — 2 March 2005 88 of 105

Philips Semiconductors

Table 83: In-system Programming (ISP) hex record formats

Record type Command/data function

00 Program User Code Memory Page

01 Read Version Id

02 Miscellaneous Write Functions

:nnaaaa00dd..ddcc

Where:

nn = number of bytes to program

aaaa = page address

dd..dd = data bytes

cc = checksum

Example:

:100000000102030405006070809cc

:00xxxx01cc

Where:

xxxx = required field but value is a ‘don’t care’

cc = checksum

Example:

:00000001cc

:02xxxx02ssddcc

Where:

xxxx = required field but value is a ‘don’t care’

ss= subfunction code

dd = data

cc = checksum

Subfunction codes:

00 = UCFG1

01 = reserved

02 = Boot Vector

03 = Status Byte

04 = reserved

05 = reserved

06 = reserved

07 = reserved

08 = Security Byte 0

09 = Security Byte 1

0A = Security Byte 2

0B = Security Byte 3

0C = Security Byte 4

0D = Security Byte 5

0E = Security Byte 6

0F = Security Byte 7

0A = Clear Configuration Protection

Example:

:020000020347cc

UM10108

P89LPC924/925 User manual

User manual Rev. 02 — 2 March 2005 89 of 105

Philips Semiconductors

Table 83: In-system Programming (ISP) hex record formats

Record type Command/data function

03 Miscellaneous Read Functions

:01xxxx03sscc

Where

xxxx = required field but value is a ‘don’t care’

ss = subfunction code

cc = checksum

Subfunction codes:

00 = UCFG1

01 = reserved

02 = Boot Vector

03 = Status Byte

04 = reserved

05 = reserved

06 = reserved

07 = reserved

08 = Security Byte 0

09 = Security Byte 1

0A = Security Byte 2

0B = Security Byte 3

0C = Security Byte 4

0D = Security Byte 5

0E = Security Byte 6

0F = Security Byte 7

10 = Manufacturer Id

11 = Device Id

12 = Derivative Id

UM10108

P89LPC924/925 User manual

Example:

:0100000312cc

04 Erase Sector/Page

:03xxxx04ssaaaacc

Where:

xxxx = required field but value is a ‘don’t care’

aaaa = sector/page address

ss = 01 erase sector

= 00 erase page

cc = checksum

Example:

:03000004010000F8

User manual Rev. 02 — 2 March 2005 90 of 105

Philips Semiconductors

Table 83: In-system Programming (ISP) hex record formats

Record type Command/data function

05 Read Sector CRC

06 Read Global CRC

07 Direct Load of Baud Rate

:01xxxx05aacc

Where:

xxxx = required field but value is a ‘don’t care’

aa = sector address HIGH byte

cc = checksum

Example:

:0100000504F6cc

:00xxxx06cc

Where:

xxxx = required field but value is a ‘don’t care’

cc = checksum

Example:

:00000006FA

:02xxxx07HHLLcc

Where:

xxxx = required field but value is a ‘don’t care’

HH = HIGH byte of timer

LL = LOW byte of timer

cc = checksum

UM10108

P89LPC924/925 User manual

Example:

:02000007FFFFcc

08 Reset MCU

:00xxxx08cc

Where:

xxxx = required field but value is a ‘don’t care’

cc = checksum

Example:

:00000008F8

16.11 In-application programming (IAP)

Several In-Application Programming (IAP) calls are available for use by an application program to permit selective erasing and programming of Flash sectors, pages, security bits, configuration bytes, and device id. All calls are made through a common interface, PGM_MTP. The programming functions are selected by setting up the microcontroller’s registers before making a call to PGM_MTP at FF03H. The IAP calls are shown in

Ta bl e 85.

User manual Rev. 02 — 2 March 2005 91 of 105

Philips Semiconductors

16.12 IAP authorization key

IAP functions which write or erase code memory require an authorization key be set by the calling routine prior to performing the IAP function call. This authorization key is set by writing 96H to RAM location FFH. For example:

MOV R0,#0FFH

MOV @R0,#96H

CALL PGM_MTP

After the function call is processed by the IAP routine, the authorization key will be cleared. Thus it is necessary for the authorization key to be set prior to EACH call to PGM_MTP that requires a key. If an IAP routine that requires an authorization key is called without a valid authorization key present, the MCU will perform a reset.

16.13 Flash write enable

This device has hardware write enable protection. This protection applies to both ISP and IAP modes and applies to both the user code memory space and the user configuration bytes (UCFG1, BOOTVEC, and BOOTSTAT). This protection does not apply to ICP or parallel programmer modes. If the Activate Write Enable (AWE) bit in BOOTSTAT.7 is a logic

0, an internal Write Enable (WE) flag is forced set and writes to the flash memory and configuration bytes are enabled. If the Active Write Enable (AWE) bit is a logic 1 then the state of the internal WE flag can be controlled by the user.

UM10108

P89LPC924/925 User manual

The WE flag is SET by writing the Set Write Enable (08H) command to FMCON followed by a key value (96H) to FMDATA:

MOV FMCON,#08H

MOV FMDATA,#96H

The WE flag is CLEARED by writing the Clear Write Enable (0BH) command to FMCON followed by a key value (96H) to FMDATA, or by a reset:

MOV FMCON,#0BH

MOV FMDATA,#96H

The ISP function in this device sets the WE flag prior to calling the IAP routines. The IAP function in this device executes a Clear Write Enable command following any write operation. If the Write Enable function is active, user code which calls IAP routines will need to set the Write Enable flag prior to each IAP write function call.

16.14 Configuration byte protection

In addition to the hardware write enable protection, described above, the ‘configuration bytes’ may be separately write protected. These configuration bytes include UCFG1, BOOTVEC, and BOOTSTAT. This protection applies to both ISP and IAP modes and does not apply to ICP or parallel programmer modes.

User manual Rev. 02 — 2 March 2005 92 of 105

Philips Semiconductors

If the Configuration Write Protect Writ (CWP) bit in BOOTSTAT.6 is a logic 1 writes to the configuration bytes are disabled. If the Configuration Write Protect Writ (CWP) bit in BOOTSTAT.6 is a logic by programming the BOOTSTAT register. This bit is cleared by using the Clear Configuration Protection function in IAP or ISP.

The Clear Configuration Protection command can be disabled in ISP or IAP mode by programming to a logic BOOTSTAT.7. When DCCP is set, the CCP command may still be used in ICP or parallel programming modes. This bit is cleared by writing the Clear Configuration Protection command in either ICP or parallel programming modes.

16.15 IAP error status

It is not possible to use the Flash memory as the source of program instructions while programming or erasing this same Flash memory. During an IAP erase, program, or CRC the CPU enters a program-idle state. The CPU will remain in this program-idle state until the erase, program, or CRC cycle is completed. These cycles are self timed. When the cycle is completed, code execution resumes. If an interrupt occurs during an erase, programming or CRC cycle, the erase, programming, or CRC cycle will be aborted so that the Flash memory can be used as the source of instructions to service the interrupt. An IAP error condition will be flagged by setting the carry flag and status information returned. The status information returned is shown in interrupts during erasing, programming, or CRC cycles, the user code should check the carry flag after each erase, programming, or CRC operation to see if an error occurred. If the operation was aborted, the user’s code will need to repeat the operation.

UM10108

P89LPC924/925 User manual

0 writes to the configuration bytes are enabled. The CWP bit is set

1 the Disable Clear Configuration Protection (DCCP) bit in

Ta bl e 84. If the application permits

Table 84: IAP error status

Bit Flag Description

0 OI Operation Interrupted. Indicates that an operation was aborted due to an interrupt

occurring during a program or erase cycle.

1 SV Security Violation. Set if program or erase operation fails due to security settings.

Cycle is aborted. Memory contents are unchanged. CRC output is invalid.

2 HVE High Voltage Error. Set if error detected in high voltage generation circuits. Cycle is

aborted. Memory contents may be corrupted.

3 VE Verify error. Set during IAP programming of user code if the contents of the

programmed address does not agree with the intended programmed value. IAP uses the MOVC instruction to perform this verify. Attempts to program user code that is MOVC protected can be programmed but will generate this error after the programming cycle has been completed.

4:7 - unused; reads as a logic 0

User manual Rev. 02 — 2 March 2005 93 of 105

Philips Semiconductors

Table 85: IAP function calls

IAP function IAP call parameters

Program User Code Page (requires ‘key’)

Read Version Id Input parameters:

Misc. Write (requires ‘key’) Input parameters:

Input parameters:

ACC = 00h

R3 = number of bytes to program

R4 = page address (MSB)

R5 = page address (LSB)

R7 = pointer to data buffer in RAM

F1= 0h = use IDATA

Return parameter(s):

R7 = status

Carry = set on error, clear on no error

ACC = 01h

Return parameter(s):

R7 = IAP code version id

ACC = 02h

R5 = data to write

R7 = register address

00 = UCFG1

01 = reserved

02 = Boot Vector

03 = Status Byte

04 = reserved

05 = reserved

06 = reserved

07 = reserved

08 = Security Byte 0

09 = Security Byte 1

0A = Security Byte 2

0B = Security Byte 3

0C = Security Byte 4

0D = Security Byte 5

0E = Security Byte 6

0F = Security Byte 7

0A = Clear Configuration Protection

Return parameter(s):

R7 = status

Carry = set on error, clear on no error

UM10108

P89LPC924/925 User manual

User manual Rev. 02 — 2 March 2005 94 of 105

Philips Semiconductors

Table 85: IAP function calls

IAP function IAP call parameters

Misc. Read Input parameters:

Erase Sector/Page (requires ‘key’) Input parameters:

P89LPC924/925 User manual

ACC = 03h

R7 = register address

00 = UCFG1

01 = reserved

02 = Boot Vector

03 = Status Byte

04 = reserved

05 = reserved

06 = reserved

07 = reserved

08 = Security Byte 0

09 = Security Byte 1

0A = Security Byte 2

0B = Security Byte 3

0C = Security Byte 4

0D = Security Byte 5

0E = Security Byte 6

0F = Security Byte 7

Return parameter(s):

R7 = register data if no error, else error status

Carry = set on error, clear on no error

ACC = 04h

R7 = 00H (erase page) or 01H (erase sector)

R4 = sector/page address (MSB)

R5 = sector/page address (LSB)

Return parameter(s):

R7 = status

Carry = set on error, clear on no error

UM10108

User manual Rev. 02 — 2 March 2005 95 of 105

Philips Semiconductors

Table 85: IAP function calls

IAP function IAP call parameters

Read Sector CRC Input parameters:

Read Global CRC Input parameters:

Read User Code Input parameters:

ACC = 05h

R7 = sector address

Return parameter(s):

R4 = CRC bits 31:24

R5 = CRC bits 23:16

R6 = CRC bits 15:8

R7 = CRC bits 7:0 (if no error)

R7 = error status (if error)

Carry = set on error, clear on no error

ACC = 06h

Return parameter(s):

R4 = CRC bits 31:24

R5 = CRC bits 23:16

R6 = CRC bits 15:8

R7 = CRC bits 7:0 (if no error)

R7 = error status (if error)

Carry = set on error, clear on no error

ACC = 07h

R4 = address (MSB)

R5 = address (LSB)

Return parameter(s):

R7 = data

UM10108

P89LPC924/925 User manual

16.16 User configuration bytes

A number of user-configurable features of the P89LPC924/925 must be defined at power-up and therefore cannot be set by the program after start of execution. These features are configured through the use of an Flash byte UCFG1 shown in

Table 86: Flash User Configuration Byte (UCFG1) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol WDTE RPE BOE WDSE - FOSC2 FOSC1 FOSC0

Unprogrammed value

Table 87: Flash User Configuration Byte (UCFG1) bit description

Bit Symbol Description

0 FOSC0 CPU oscillator type select. See Section 2 “Clocks” on page 14 for additional information. Combinations other

1 FOSC1

2 FOSC2

3 - reserved

User manual Rev. 02 — 2 March 2005 96 of 105

than those shown in Ta bl e 88 are reserved for future use should not be used.

0 1 1 0 0 0 1 1

Ta bl e 87.

Philips Semiconductors

P89LPC924/925 User manual

Table 87: Flash User Configuration Byte (UCFG1) bit description

Bit Symbol Description

4 WDSE Watchdog Safety Enable bit. Refer to Ta bl e 88 for details.

5 BOE Brownout Detect Enable (see Section 6.1 “Brownout detection” on page 31).

6 RPE Reset pin enable. When set = 1, enables the reset function of pin P1.5. When cleared, P1.5 may be used as

an input pin. NOTE: During a power-up sequence, the RPE selection is overridden and this pin will always functions as a reset input. After power-up the pin will function as defined by the RPE bit. Only a power-up reset will temporarily override the selection defined by RPE bit. Other sources of reset will not override the RPE bit.

7 WDTE Watchdog timer reset enable. When set = 1, enables the Watchdog timer reset. When cleared = 0, disables

the Watchdog timer reset. The timer may still be used to generate an interrupt. Refer to

Table 88: Oscillator type selection

FOSC[2 :0]

111 External clock input on XTAL1.

100 Watchdog Oscillator, 400 kHz (+20/−30 % tolerance).

011 Internal RC oscillator, 7.373 MHz ± 2.5 %.

010 Low frequency crystal, 20 kHz to 100 kHz.

001 Medium frequency crystal or resonator, 100 kHz to 4 MHz.

000 High frequency crystal or resonator, 4 MHz to 12 MHz.

Oscillator configuration

UM10108

Ta bl e 88 for details.

16.17 User security bytes

This device has three security bits associated with each of its eight sectors, as shown in

Ta bl e 89

Table 89: Sector Security Bytes (SECx) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol - - - - - EDISx SPEDISx MOVCDISx

Unprogrammed value

Table 90: Sector Security Bytes (SECx) bit description

Bit Symbol Description

0 MOVCDISx MOVC Disable. Disables the MOVC command for sector x. Any MOVC that attempts to read a byte in a

1 SPEDISx Sector Program Erase Disable x. Disables program or erase of all or part of sector x. This bit and sector

2 EDISx Erase Disable ISP. Disables the ability to perform an erase of sector ‘x’ in ISP or IAP mode. When

3:7 - reserved

0 0 0 0 0 0 0 0

MOVC protected sector will return invalid data. This bit can only be erased when sector x is erased.

x are erased by either a sector erase command (ISP, IAP, commercial programmer) or a 'global' erase command (commercial programmer).

programmed, this bit and sector x can only be erased by a 'global' erase command using a commercial programmer. This bit and sector x CANNOT be erased in ISP or IAP modes.

User manual Rev. 02 — 2 March 2005 97 of 105

Philips Semiconductors

P89LPC924/925 User manual

Table 91: Effects of Security Bits

EDISx SPEDISx MOVCDISxEffects on Programming

0 0 0 None.

0 0 1 Security violation flag set for sector CRC calculation for the

specific sector. Security violation flag set for global CRC calculation if any MOVCDISx bit is set. Cycle aborted. Memory contents unchanged. CRC invalid. Program/erase commands will not result in a security violation.

0 1 x Security violation flag set for program commands or an erase

page command. Cycle aborted. Memory contents unchanged. Sector erase and global erase are allowed.

1 x x Security violation flag set for program commands or an erase

page command. Cycle aborted. Memory contents unchanged. Global erase is allowed.

UM10108

16.18 Boot Vector register

Table 92: Boot Vector (BOOTVEC) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol - - - BOOTV4 BOOTV3 BOOTV2 BOOTV1 BOOTV0

Factory default value

0 0 0 1 1 1 1 1

Table 93: Boot Vector (BOOTVEC) bit description

Bit Symbol Description

0:4 BOOTV.0:4 Boot vector. If the Boot Vector is selected as the reset address, the P89LPC924/925 will start execution

at an address comprised of 00h in the lower eight bits and this BOOTVEC as the upper eight bits after a reset.

5:7 - reserved

16.19 Boot status register

Table 94: Boot Status (BOOTSTAT) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol - - - - - - -- BSB0

Factory default value

Table 95: Boot Status (BOOTSTAT) bit description

Bit Symbol Description

0:4 BOOTV.0:4 Boot Status Bit. If programmed to logic 1, the P89LPC924/925 will always start execution at an address

5:7 - reserved

0 0 0 0 0 0 0 1

comprised of 00H in the lower eight bits and BOOTVEC as the upper bits after a reset. (See

“Reset vector” on page 36).

Section 7.1

User manual Rev. 02 — 2 March 2005 98 of 105

Philips Semiconductors

17. Instruction set

Table 96: Instruction set summary

Mnemonic Description Bytes Cycles Hex

ADD A,Rn Add register to A 1 1 28 to 2F

ADD A,dir Add direct byte to A 2 1 25

ADD A,@Ri Add indirect memory to A 1 1 26 to 27

ADD A,#data Add immediate to A 2 1 24

ADDC A,Rn Add register to A with carry 1 1 38 to 3F

ADDC A,dir Add direct byte to A with carry 2 1 35

ADDC A,@Ri Add indirect memory to A with

ADDC A,#data Add immediate to A with carry 2 1 34

SUBB A,Rn Subtract register from A with

SUBB A,dir Subtract direct byte from A with

SUBB A,@Ri Subtract indirect memory from A

SUBB A,#data Subtract immediate from A with

INC A Increment A 1 1 04

INC Rn Increment register 1 1 08 to 0F

INC dir Increment direct byte 2 1 05

INC @Ri Increment indirect memory 1 1 06 to 07

DEC A Decrement A 1 1 14

DEC Rn Decrement register 1 1 18 to 1F

DEC dir Decrement direct byte 2 1 15

DEC @Ri Decrement indirect memory 1 1 16 to 17

INC DPTR Increment data pointer 1 2 A3

MUL AB Multiply A by B 1 4 A4

DIV AB Divide A by B 1 4 84

DA A Decimal Adjust A 1 1 D4

ANL A,Rn AND register to A 1 1 58 to 5F

ANL A,dir AND direct byte to A 2 1 55

ANL A,@Ri AND indirect memory to A 1 1 56 to 57

ANL A,#data AND immediate to A 2 1 54

ANL dir,A AND A to direct byte 2 1 52

ANL dir,#data AND immediate to direct byte 3 2 53

ORL A,Rn OR register to A 1 1 48 to 4F

ORL A,dir OR direct byte to A 2 1 45

ARITHMETIC

carry

borrow

with borrow

borrow

LOGICAL

UM10108

P89LPC924/925 User manual

code

1 1 36 to 37

1 1 98 to 9F

2 1 95

1 1 96 to 97

2 1 94

User manual Rev. 02 — 2 March 2005 99 of 105

Philips Semiconductors

Table 96: Instruction set summary

Mnemonic Description Bytes Cycles Hex

ORL A,@Ri OR indirect memory to A 1 1 46 to 47

ORL A,#data OR immediate to A 2 1 44

ORL dir,A OR A to direct byte 2 1 42

ORL dir,#data OR immediate to direct byte 3 2 43

XRL A,Rn Exclusive-OR register to A 1 1 68 to 6F

XRL A,dir Exclusive-OR direct byte to A 2 1 65

XRL A, @Ri Exclusive-OR indirect memory to A1 1 66 to 67

XRL A,#data Exclusive-OR immediate to A 2 1 64

XRL dir,A Exclusive-OR A to direct byte 2 1 62

XRL dir,#data Exclusive-OR immediate to direct

CLR A Clear A 1 1 E4

CPL A Complement A 1 1 F4

SWAP A Swap Nibbles of A 1 1 C4

RL A Rotate A left 1 1 23

RLC A Rotate A left through carry 1 1 33

Rotate A right RR A 1 1 03

RRC A Rotate A right through carry 1 1 13

MOV A,Rn Move register to A 1 1 E8 to EF

MOV A,dir Move direct byte to A 2 1 E5

Move indirect memory to A MOV A,@Ri 1 1 E6 to E7

MOV A,#data Move immediate to A 2 1 74

MOV Rn,A Move A to register 1 1 F8 to FF

MOV Rn,dir Move direct byte to register 2 2 A8 to AF

MOV Rn,#data Move immediate to register 2 1 78 to 7F

MOV dir,A Move A to direct byte 2 1 F5

MOV dir,Rn Move register to direct byte 2 2 88 to 8F

MOV dir,dir Move direct byte to direct byte 3 2 85

MOV dir,@Ri Move indirect memory to direct

MOV dir,#data Move immediate to direct byte 3 2 75

MOV @Ri,A Move A to indirect memory 1 1 F6 to F7

MOV @Ri,dir Move direct byte to indirect

MOV @Ri,#data Move immediate to indirect

MOV DPTR,#data Move immediate to data pointer 3 2 90

MOVC A,@A+DPTR Move code byte relative DPTR to A1 2 93

UM10108

P89LPC924/925 User manual

code

3 2 63

byte

DATA TRANSFER

2 2 86 to 87

byte

2 2 A6 to A7

memory

2 1 76 to 77

memory

MOVC A,@A+PC Move code byte relative PC to A 1 2 94

User manual Rev. 02 — 2 March 2005 100 of 105

Philips P89LPC924, P89LPC925 Technical data

Specifications and Main Features

Frequently Asked Questions

User Manual

1. Introduction

1.1 Pin Configuration

1.2 Special function registers

1.3 Memory organization

2. Clocks

2.1 Enhanced CPU

2.2 Clock definitions

2.3 Clock output

2.4 On-chip RC oscillator option

2.5 Watchdog oscillator option

2.6 External clock input option

2.7 Oscillator Clock (OSCCLK) wake-up delay

2.8 CPU Clock (CCLK) modification: DIVM register

2.9 Low power select

3. A/D converter

3.1 Features

3.2 A/D operating modes

3.3 Trigger modes

3.4 DAC output to a port pin with high-impedance

3.5 Clock divider

3.6 I/O pins used with A/D converter functions

3.7 Power-down and idle mode

4. Interrupts

4.1 Interrupt priority structure

4.2 External Interrupt pin glitch suppression

5. I/O ports

5.1 Port configurations

5.2 Quasi-bidirectional output configuration

5.3 Open drain output configuration

5.4 Input-only configuration

5.5 Push-pull output configuration

5.6 Port 0 analog functions

5.7 Additional port features

6. Power monitoring functions

6.1 Brownout detection

6.2 Power-on detection

6.3 Power reduction modes

7. Reset

7.1 Reset vector

8. Timers 0 and 1

8.1 Mode 0

8.2 Mode 1

8.3 Mode 2

8.4 Mode 3

8.5 Mode 6

8.6 Timer overflow toggle output

9. Real-time clock system timer

9.1 Real-time clock source

9.2 Changing RTCS1-0

9.3 Real-time clock interrupt/wake-up

9.4 Reset sources affecting the Real-time clock

10. UART

10.1 Mode 0

10.2 Mode 1

10.3 Mode 2

10.4 Mode 3

10.5 SFR space

10.6 Baud Rate generator and selection

10.7 Updating the BRGR1 and BRGR0 SFRs

10.8 Framing error

10.9 Break detect

10.10 More about UART Mode 0

10.11 More about UART Mode 1

10.12 More about UART Modes 2 and 3

10.13 Framing error and RI in Modes 2 and 3 with SM2 = 1

10.14 Break detect

10.15 Double buffering

10.16 Double buffering in different modes

10.17 Transmit interrupts with double buffering enabled (Modes 1,2, and 3)

10.18 The 9th bit (bit 8) in double buffering (Modes 1, 2, and 3)

10.19 Multiprocessor communications

10.20 Automatic address recognition

11. I2C interface

11.1 I2C Data register

11.2 I2C Slave Address register

11.3 I2C Control register
