Philips MCM770 12 User Manual

Register your product and get support at

MCM770

EN User manual 3

DE Benutzerhandbuch 25

ES Manual del usuario 48

FR Mode d’emploi 72

DA Brugervejledning 97

IT Manuale utente 120

NL Gebruiksaanwijzing 145

SV Användarhandbok 169

Contents

1 Important 4

Safety 4
Notice 6

2 Your Micro Hi-Fi System 8

Introduction 8
What’s in the box 8
Overview of the main unit 9
Overview of the remote control 10

7 Tune to FM radio stations 19

Program radio stations automatically 19
Program radio stations manually 19
Tune to a preset radio station 19
Show RDS information 19
Set RDS clock 20

8 Use more of your audio system 21

Set the alarm timer 21
Set the sleep timer 21
Connect other devices 21

Listen through other devices 21
Listen to other devices 21

English

3 Get started 12

Connect speakers 12
Connect FM antenna 12
Connect power 12
Prepare the remote control 13
Set clock 13
Turn on 13

Switch to standby mode 13

4 Play disc/USB 15

Play from disc 15
Play from USB 15

5 Control play 16

Skip to a track 16
Pause/resume play 16
Search within a track 16
Display play information 16
Repeat play 16
Random play 16
Program tracks 16
Scan all tracks 17

6 Adjust volume level and sound effect

18

Adjust volume level 18
Select a preset sound effect 18
Enhance bass 18
Select automatic loudness control 18
Mute sound 18

9 Product information 22

Specifi cations 22

Amplifi er 22
Disc 22
Tuner (FM) 22
Speakers 22

General information 22
USB playability information 22
Supported MP3 disc formats 23
RDS program types 23

10 Troubleshooting 24

EN

3

1 Important

Safety

Know these safety symbols

This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an electrical
shock. For the safety of everyone in your
household, please do not remove product
covering.
The ‘exclamation point’ calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.
WARNING: To reduce the risk of fi re or electric
shock, this apparatus should not be exposed to
rain or moisture and objects fi lled with liquids,
such as vases, should not be placed on this
apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.

a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.

g Do not block any ventilation openings.

Install in accordance with the
manufacturer’s instructions.

h Do not install near any heat sources such

as radiators, heat registers, stoves, or
other apparatus (including amplifi ers) that
produce heat.

i For countries with a polarized mains,

do not defeat the safety purpose of
the polarized or grounding-type plug.
A polarized plug has two blades with
one wider than the other. A grounding
type plug has two blades and a third
grounding prong. The wide blade or the
third prong are provided for your safety.
If the provided plug does not fi t into
your outlet, consult an electrician for
replacement of the obsolete outlet.
Caution: To prevent electric shock, match
the wide blade of the plug to the wide
slot, fully insert.

j Protect the power cord from being

walked on or pinched, particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.

k Only use attachments/accessories

specifi ed by the manufacturer.

l Use only with the cart, stand, tripod,

bracket, or table specifi ed by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.

4

EN

m Unplug this apparatus during lightning

storms or when unused for long periods
of time.

n Refer all servicing to qualifi ed service

personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.

o Battery usage CAUTION – To prevent

battery leakage which may result in bodily
injury, property damage, or damage to the
unit:

•

Install all batteries correctly, + and - as
marked on the unit.

•

Do not mix batteries (old and new or
carbon and alkaline, etc.).

•

Remove batteries when the unit is not
used for a long time.

p Apparatus shall not be exposed to

dripping or splashing.

q Do not place any sources of danger on

the apparatus (e.g. liquid fi lled objects,
lighted candles).

r This product may contain lead and

mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org.

How to connect a plug
The wires in the mains lead are coloured with
the following code: blue = neutral (N), brown
= live (L).
As these colours may not correspond with the
colour markings identifying the terminals in your
plug, proceed as follows:

•

Connect the blue wire to the terminal
marked N or coloured black.

•

Connect the brown wire to the terminal
marked L or coloured red.
Do not connect either wire to the earth

•
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make
certain that the cord grip is clamped over
the sheath of the lead - not simply over
the two wires.

Mains plug
This apparatus is fi tted with an approved 13
Amp plug. To change a fuse in this type of plug
proceed as follows:

a Remove fuse cover and fuse.
b Fix new fuse which should be a BS13625

Amp, A.S.T.A. or BSI approved type.

c Refi t the fuse cover.

If the fi tted plug is not suitable for your socket
outlets, it should be cut off and an appropriate
plug fi tted in its place.
If the mains plug contains a fuse, this should
have a value of 5 Amp. If a plug without a fuse
is used, the fuse at the distribution board should
not be greater than 5 Amp.
The severed plug must be disposed off to avoid
a possible shock hazard should it be inserted
into a 13 Amp socket elsewhere.

Warning

Never remove the casing of this audio system.

•

•

Never lubricate any part of this audio system.

•

Place this audio system on a fl at, hard and stable
surface.

•

Never place this audio system on other electrical
equipment.

•

Only use this audio system indoors. Keep this audio
system away from water, moisture and liquid-fi lled
objects.

•

Keep this audio system away from direct sunlight, naked
fl ames or heat.

•

Never look into the laser beam inside the audio system.

English

EN

5

Norge
Typeskilt fi nnes på apparatens bakside.
Observer: Nettbryteren er sekundert innkoplet.
Den innebygde netdelen er derfor ikke
fraktoplet nettet så lenge apparatet er tilsluttet
nettkontakten.
For å redusere faren for brann eller elektrisk
støt, skal apparatet, ikke utsettes for regn eller
fuktighet.

Notice

Any changes or modifi cations made to this
device that are not expressly approved by
Philips Consumer Electronics may void the
user’s authority to operate the equipment.

This product complies with the radio
interference requirements of the European
Community.
This product complies with the requirements of
the following directives and guidelines: 73/23/
EEC + 89/336/EEC + 93/68/EEC

Information for Users on Collection and
Disposal of Old Equipment and used Batteries
These symbols on the products, packaging, and/
or accompanying documents mean that used
electrical and electronic products and batteries
should not be mixed with general household
waste. For proper treatment, recovery and
recycling of old products and used batteries,
please take them to applicable collection points,

in accordance with your national legislation and
the Directives 2002/96/EC and 2006/66/EC.
By disposing of these products and batteries
correctly, you will help to save valuable
resources and prevent any potential negative
effects on human health and the environment
which could otherwise arise from inappropriate
waste handling.
For more information about collection and
recycling of old products and batteries, please
contact your local municipality, your waste
disposal service or the point of sale where you
purchased the items.
[Information on Disposal in other Countries
outside the European Union]
These symbols are only valid in the European
Union. If you wish to discard these items, please
contact your local authorities or dealer and ask
for the correct method of disposal.
Note for the battery symbol:

This symbol might be used in combination with
a chemical symbol. In this case it complies with
the requirement set by the Directive for the
chemical involved.
Environmental information
All redundant packing material has been
omitted. We have done our utmost to make the
packaging easily separable into mono materials.
Please observe the local regulations regarding
the disposal of packing materials.
Recording and playback of material may require
consent. See Copyright Act 1956 and The
Performer’s Protection Acts 1958 to 1972.

6

EN

Windows Media and the Windows logo
are trademarks, or registered trademarks of
Microsoft Corporation in the United States
and/or other countries.

English

EN

7

2 Your Micro Hi-

Fi System

Congratulations on your purchase, and
welcome to Philips! To fully benefi t from the
support that Philips offers, register your product
at www.Philips.com/welcome.

Introduction

With this audio system, you can enjoy music
from audio discs and USB devices directly or
listen to FM radio stations.
The audio system offers you multiple sound
effect settings that enrich sound with Digital
Sound Control (DSC), Dynamic Bass Boost
(DBB) and bass/treble enhancement (loudness).
The audio system supports the following media
formats:

What’s in the box

Check and identify the contents of your
package:

•

Main unit

•

Loudspeaker boxes x 2

•

Speaker cables x 2

•

AC adaptor

•

Remote control with battery
FM wire antenna

•
