Philips MCM760 05 User Manual
Micro Hi-Fi System
User manual
Manuel d'utilisation
Manual del usuario
Benutzerhandbuch
Gebruikershandleiding
Manuale per l'utente
Användarhandböckerna
Brugermanual
MCM760
Important notes for users in the
U.K.
Mains plug
This apparatus is fitted with an approved 13
Amp plug. To change a fuse in this type of plug
proceed as follows:
1 Remove fuse cover and fuse.
2 Fix new fuse which should be a BS1362 3 Amp,
A.S.T.A. or BSI approved type.
3 Refit the fuse cover.
If the fitted plug is not suitable for your socket
outlets, it should be cut off and an appropriate
plug fitted in its place.
If the mains plug contains a fuse, this should have
a value of 3 Amp. If a plug without a fuse is used,
the fuse at the distribution board should not be
greater than 3 Amp.
Note: The severed plug must be disposed of to
avoid a possible shock hazard should it be inserted
into a 13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured with
the following code: blue = neutral (N),
brown = live (L).
¶ As these colour s may not correspond with the
colour markings identifying the terminals in your
plug, proceed as follows:
– Connect the blue wire to the terminal
marked N or coloured black.
– Connect the brown wire to the terminal
marked L or coloured red.
– Do not connect either wire to the earth
terminal in the plug, marked E (or e) or coloured
green (or green and yellow).
Before replacing the plug cover, make certain
that the cord grip is clamped over the sheath of
the lead - not simply over the two wires.
Italia
DICHIARAZIONE DI CONFORMITA’
Si dichiara che l’apparecchio MCM760 Philips
risponde alle prescrizioni dell’ar t. 2 comma 1
del D.M. 28 Agosto 1995 n. 548.
Fatto a Eindhoven
Philips Consumer Electronics
Philips, Glaslaan 2
5616 JB Eindhoven, The Netherlands
Norge
Typeskilt finnes på apparatens underside.
Observer: Nettbryteren er sekundert
innkoplet. Den innebygde netdelen er
derfor ikke frakoplet nettet så lenge
apparatet er tilsluttet nettkontakten.
For å redusere faren for brann eller elektrisk
støt, skal apparatet ikke utsettes for regn eller
fuktighet.
Copyright in the U.K.
Recording and playback of material may require
consent. See Copyright Act 1956 and The
Performer’s Protection Acts 1958 to 1972.
2
1
STANDBY-ON
ECO POWER
WMA-MP3-CD/CD-R/CD-RW COMPATIBLE
TAPE RECORDUSB RECORD OPEN/CLOSERD S/NEWS
2
3
4
5
%
$
#
@
iR
USB DIRECT
ALBUM STOP/DEMO
6
PLAY/PAUSEPRESET
VOLUME
BASS
TREBLE
7
8
9
OPEN CLOSE
0
!
3
/ /
(for tuner installation)
DK
Advarsel: Usynlig laserstråling ved åbning
når sikkerhedsafbrydere er ude af funktion.
Undgå utsættelse for stråling.
Bemærk: Netafbryderen er sekundært
indkoblet og ofbryder ikke strømmen fra
nettet. Den indbyggede netdel er derfor
tilsluttet til lysnettet så længe netstikket
sidder i stikkontakten.
S
Klass 1 laseraparat
Varning! Om apparaten används på annat
sätt än i denna bruksanvisning specificerats,
kan användaren utsättas för osynlig
laserstrålning, som överskrider gränsen för
laserklass 1.
Observera! Stömbrytaren är sekundärt
kopplad och bryter inte strömmen från
nätet. Den inbyggda nätdelen är därför
ansluten till elnätet så länge stickproppen
sitter i vägguttaget.
4
SF
Luokan 1 laserlaite
Va roitus! Laitteen käyttäminen
muulla kuin tässä käyttöohjeessa
mainitulla tavalla saattaa altistaa
käyttäjän turvallisuusluokan 1 ylittävälle
näkymättömälle lasersäteilylle.
Oikeus muutoksiin varataan. Laite
ei saa olla alttiina tippu-ja roiskevedelle.
Huom. Toiminnanvalitsin on kytketty
toisiopuolelle, eikä se kytke laitetta irti
sähköverkosta. Sisäänrakennettu verkkoosa on kytkettynä sähköverkkoon aina
silloin, kun pistoke on pistorasiassa.
Index
English ------------------------------------------------ 6
Français -------------------------------------------- 34
Español --------------------------------------------- 62
Deutsch --------------------------------------------- 90
Nederlands -------------------------------------- 118
Italiano -------------------------------------------- 146
Svenska ------------------------------------------- 174
English
Français
Español
Deutsch
NederlandsItaliano
SvenskaDansk
Dansk --------------------------------------------- 202
5
Contents
English
General Information
Supplied accessories ............................................ 7
Environmental information ................................ 7
Safety information ................................................ 7
Controls
Controls on the set ............................................. 8
Remote control .............................................. 9-10
Installation
Rear connections ......................................... 11-12
Speaker connections
Antenna connections
Connecting an additional appliance ............... 12-13
Connecting a USB device or memory card
Connecting a non-USB device
Using AC power .................................................. 13
Preparations
Using the remote control .......................................... 14
Setting the clock ................................................. 14
Basic Functions
Switching on/off the set .................................... 15
Displaying the clock ....................................................... 15
Display adjustment ............................................. 15
Volume control ................................................... 16
Volume adjustment
MUTE
Sound control ..................................................... 16
Incredible surround
Bass/Treble
CD
Discs for playback .............................................. 17
Playing discs ................................................... 17-18
Selecting and searching ..................................... 18
Selecting a different track
Finding a passage within a track during playback
Programming tracks ........................................... 19
Erasing the program
Different play modes: REPEAT, SHUFFLE ...... 20
Display track information
(MP3/WMA only) ............................................... 20
Tuner
Tuning to radio stations .................................... 21
Programming radio stations ....................... 21-22
Plug & Play
Autostore: Automatic programming
Manual programming
To listen to a preset station
Deleting a preset radio station
RDS (Radio Data System) .......................... 22-23
Switching through RDS information
Clock setting via RDS
NEWS ................................................................... 23
Activating the NEWS function
Deactivating NEWS function
USB
Using a USB mass storage device ................... 24
Playing a USB mass storage device ................. 25
Recording to a USB mass storage device
.......................................................................... 25-26
TAPE
Playing a tape ....................................................... 27
Recording to a tape ..................................... 27-28
AUX
AUX (Listening to an external source) ......... 29
Timer
Setting the timer ........................................... 29-30
Activating and deactivating TIMER ................. 30
Temporarily deactivating TIMER ..................... 30
SLEEP
................................................................................ 30
Demonstration mode
................................................................................ 30
Specifications ........................................... 31
Maintenance .............................................. 31
Troubleshooting .............................. 32-33
6
General Information
Supplied accessories
–2 speaker boxes including 2 speaker cables
– remote control and two AA batteries
– MW loop antenna
– FM wire antenna
–AC power cord
Environmental Information
All unnecessary packaging has been omitted. We
have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags,
protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialized company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Disposal of your old product
Your product is designed and
manufactured with high quality materials
and components, which can be recycled
and reused.
When this crossed-out
wheeled bin symbol is
attached to a product it
means the product is
covered by the
European Directive
2002/96/EC
Safety Information
● Place the system on a flat, hard and stable
surface.
● Place the system in a location with adequate
ventilation to prevent internal heat build-up in
your system. Allow at least 10 cm (4 inches)
clearance from the rear and the top of the unit
and 5 cm (2 inches) from each side.
● The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloths, cur tains, etc.
● Do not expose the system, batteries or discs to
excessive moisture, rain, sand or heat sources
caused by heating equipment or direct sunlight.
● No naked flame sources, such as lighted candles,
should be placed on the apparatus.
● No objects filled with liquids, such as vases, shall
be placed on the apparatus.
● If the system is brought directly from a cold to a
warm location, or is placed in a very damp room,
moisture may condense on the lens of the disc
unit inside the system. Should this occur, the CD
player would not operate normally. Leave the
power on for about one hour with no disc in the
system until normal playback is possible.
● The mechanical parts of the set contain self-
lubricating bearings and must not be oiled or
lubricated.
● When the system is switched to Standby
mode, it is still consuming some power.
To disconnect the system from the
power supply completely, remove the AC
power plug from the wall socket.
Apparatus shall not be exposed to dripping
or splashing
English
Please inform yourself about the local
separate collection system for electrical
and electronic products.
Please act according to your local rules
and do not dispose of your old products
with your normal household waste. The
correct disposal of your old product will
help prevent potential negative
consequences for the environment and
human health.
7
Controls
English
Controls on the set (illustrations
on page 3)
1 STANDBY-ON/ECO POWER
– press briefly to switch the set on or to ECO
POWER (power-saving mode);
– press and hold to switch the set to standby
mode
– Red indicator: lights up red when the set is
switched to ECO POWER mode
2 OPEN/CLOSEç
– opens/closes the CD door
3 RDS/NEWS
– Tuner: selects RDS (Radio Data System)
information
– CD/USB/TAPE/AUX: activates/deactivates
news
4 TAPE RECORD
– starts recording to a tape
5 USB RECORD
– starts recording to a USB mass storage device
6 Source buttons
CD
– selects CD source
– In standby or Eco Power mode: switches the
set on and selects CD source
TUNER
– selects TUNER source and toggles between the
wavebands: FM and MW
– In standby or Eco Power mode: switches the
set on and selects TUNER source
USB
– selects USB source
– In standby or Eco Power mode: switches the
set on and selects USB source
TAPE/AUX
– selects TAPE source or the audio input from an
additional connected appliance
– In standby or Eco Power mode: switches the
set on and selects TAPE source or the audio
input from an additional connected appliance
7 TREBLE
– selects a desired TREBLE (high tone) level
8 BASS
– selects a desired BASS (low tone)
nn
9
n
nn
– 3.5 mm headphone socket
Helpful hints:
– Adjust the volume to a moderate level
before you plug in the headphones.
– Connecting headphones will switch off the
speakers.
0 OPEN/CLOSEç
– opens/ closes the tape deck door
! Ta pe deck
@ VOLUME
– adjusts the volume level
# PRESET í/ ë
– CD/USB: skips CD tracks backwards/forwards
– TUNER: selects a preset radio station.
– TAPE: selects other side of the tape
ALBUM àá
– CD/USB: selects albums (for MP3/WMA only)
– CD: searches backward / forward
– TUNER: tunes to radio stations
– TAPE: rewind or fast forward
– CLOCK: sets the hours or minutes
PLAY/ PAUSEÉÅ
– CD/USB: star ts or pauses playback
– TAPE: starts playback
– CLOCK: toggles between hour and minutes
setting
– TUNER: enters Plug & Play mode and/or star ts
preset radio station installation
STOP/DEMO Ç
– CD/USB: stops playback or recording; erase a
program
– TUNER: press and hold to erase a preset radio
station
– TAPE: stops playback or recording
– In standby or Eco Power mode: press and
hold to turn on /off the demonstration mode
$
– jack for the external USB mass storage device
% IR
– sensor for the infrared remote control
Helpful hints: Always point the remote control
towards this sensor.
8
Controls
Remote control
STANDBY
CD TUNER
TAPE AUX
(
*
&
^
%
$
#
@
REPEAT PROGRAM
TAPE REC
INC. SURR
TAPE A/BDISPLAY/CLOCK
VOL
PRESET
ALBUM
USB REC USB DEL SNOOZE
DIM
SLEEP/TIMER TIMER ON/OFF
BASS TREBLE
MUTEUSB
SHUFFLE
Notes for remote control:
– First select the source you wish to
control by pressing one of the source select
keys on the remote control (for example
CD, TUNER).
– Then select the desired function (for
example ÉÅ, í, ë).
BB
1
B
BB
– press briefly to switch the set to ECO POWER
(power-saving mode);
– press and hold to switch the set to standby
mode
1
2
(
3
4
5
6
7
8
9
0
!
2 Source buttons
CD
– selects CD source
– In standby or Eco Power mode: switches the
set on and selects CD source
TUNER
– selects TUNER source and toggles between the
wavebands: FM and MW
– In standby or Eco Power mode: switches the
set on and selects TUNER source
TAPE
– selects TAPE source
– In standby or Eco Power mode: switches the
set on and selects TAPE source
AUX
– selects the audio input from an additional
connected appliance
– In standby or Eco Power mode: switches the
set on and selects the audio input from an
additional connected appliance
3 PROGRAM
– CD/USB: programs tracks
– Tuner: programs preset radio stations
4 DISPLAY/CLOCK
– Clock: - displays the set time
- enters the clock
setting mode (press and hold for more
than 2 seconds)
– TUNER/Audio CD: switches between clock
display and playback
display
– MP3/WMA files: displays disc information
during playback
5 VOLUME
– adjusts the volume level
6 PRESETí/ë
– CD/USB: skips CD tracks backwards/forwards
– TUNER: selects a preset radio station.
– TAPE: selects other side of the tape
Ç
– CD/USB: stops playback or recording; erase a
program
– TUNER: press and hold to erase a preset radio
station
– TAPE: stops playback or recording
ÉÅ
– CD/USB: star ts or pauses playback
– TAPE: starts playback
– CLOCK: toggles between hour and minutes
setting
ALBUM à / á
– CD/USB: selects albums (for MP3/WMA only)
– CD: searches backward / forward
– TUNER: tunes to radio stations
– TAPE: rewind or fast forward
– CLOCK: sets the hours or minutes
English
9
Controls
English
7 SNOOZE
–Temporarily deactivate the timer
8 TIMER ON/OFF
– turns the timer on/off
9 SLEEP/TIMER
– set the sleep timer
– displays the timer setting
– enters the timer setting mode (press and hold
for more than 2 seconds)
0 TREBLE (+-)
– Selects a desired TREBLE (high tone) level
! MUTE
– switches the sound off temporarily
@ USB
– selects USB source
– In standby or Eco Power mode: switches the
set on and selects USB source
# BASS (+-)
– Selects a desired BASS (low tone) level
$ INC. SURR.
–Turns on/ off the incredible surround sound
effect
% DIM
– Selects different levels of brightness for display
panel
^ TAPE REC
– starts recording to a tape
& USB REC
– starts recording to a USB mass storage device
USB DEL
– delete files from a USB mass storage device
* TAPE A/B
– selects the desired tape playback modes : one
side, both sides or auto replay
( REPEAT
– selects continuous playback
SHUFFLE
– selects random playback
The making of unauthorized copies of
copy-protected material, including
computer programs, files, broadcasts and
sound recordings, may be an infringement
of copyrights and constitute a criminal
offence. This equipment should not be used
for such purposes.
10
Loading...
