Philips MCD122 93 User Manual

Register your product and get support at

www.philips.com/welcome

MCD122

EN User manual

=+&1 Ⴌ߀൱Ҭ 

5 Play 17

Contents

1 Important 5

Safety 5

Hearing safety 6

Notice 7

2 Your DVD Micro Theater 8

Introduction 8
What’s in the box 8
Overview of the main unit 9
Overview of the remote control 10

3 Connect 12

Place the unit 12
Connect speakers 12
Connect FM antenna 12
Connect TV 13

Connect video cables 13
Option 1: Connect through
component video 13
Option 2: Connect through S-Video 13
Option 3: Connect through
composite video 14
Connect audio cables 14

Connect power 14

4 Get started 15

Prepare the remote control 15
Set clock 15
Turn on 15

Switch to standby mode 15
Find the correct viewing channel 15
Select the correct TV system 16
Change system menu language 16
Turn on Progressive Scan 16

Play a disc 17

Use the disc menu 17
Select an audio language 17

Select a subtitle language 17
Play from USB 18
Play DivX video 18
Play MP3/WMA/picture fi les 18
Play control 18

Select repeat/shuffl e play options 18

Repeat A-B (DVD/VCD/CD/MP3/

WMA) 19

Search forward/backward 19

Search by time or chapter/track

number 19

Resume video play from last

stopped point 19
Play options 19

Display play information 19

Zoom in/out image 19

Slow-motion play 19

Change the audio channel 20

Select a camera angle 20
Picture view options 20

Preview pictures 20

Rotate picture 20

6 Adjust settings 21

General setup 21
Audio setup 21
Video setup 21
Preferences 22

7 Tune to FM radio stations 23

Program radio stations automatically 23
Program radio stations manually 23
Tune to a preset radio station 23

English

EN

3

8 Adjust volume level and sound effect

24
Adjust volume level 24
Select a sound effect 24

Select a preset sound effect 24
Enhance bass 24

Select automatic loudness control 24
Mute sound 24
Listen through headphone 24

9 Other features 25

Activate demonstration mode 25
Adjust brightness of display panel 25
Set the alarm timer 25
Set the sleep timer 25
Connect other devices 25

Listen to an audio player 25

Record to a digital recorder 26

10 Product information 27

Specifi cations 27

Amplifi er 27

Disc 27

Tuner (FM) 27

Speakers 27

General information 27
Supported disc formats 28
USB playability information 28

11 Troubleshooting 29

4

EN

1 Important

g Do not block any ventilation openings.

Install in accordance with the
manufacturer’s instructions.

Safety

Know these safety symbols

This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an electrical
shock. For the safety of everyone in your
household, please do not remove product
covering.
The ‘exclamation point’ calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.
WARNING: To reduce the risk of fi re or electric
shock, this apparatus should not be exposed to
rain or moisture and objects fi lled with liquids,
such as vases, should not be placed on this
apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.

a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.

h Do not install near any heat sources such

as radiators, heat registers, stoves, or
other apparatus (including amplifi ers) that
produce heat.

i For countries with a polarized mains,

do not defeat the safety purpose of
the polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and a third grounding
prong. The wide blade or the third prong
is provided for your safety. If the provided
plug does not fi t into your outlet, consult
an electrician for replacement of the
obsolete outlet.
Caution: To prevent electric shock, match
the wide blade of the plug to the wide
slot, fully insert.

j Protect the power cord from being

walked on or pinched, particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.

k Only use attachments/accessories

specifi ed by the manufacturer.

l Use only with the cart, stand, tripod,

bracket, or table specifi ed by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.

English

e Do not use this apparatus near water.
f Clean only with dry cloth.

EN

5

m Unplug this apparatus during lightning

storms or when unused for long periods
of time.

n Refer all servicing to qualifi ed service

personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.

o Battery usage CAUTION – To prevent

battery leakage which may result in bodily
injury, property damage, or damage to the
apparatus:

Install all batteries correctly, + and - as •
marked on the apparatus.
Do not mix batteries (old and new or •
carbon and alkaline, etc.).
Remove batteries when the unit is not •
used for a long time.

p The batteries shall not be exposed to

excessive heat such as sunshine, fi re or
the like.

q Apparatus shall not be exposed to

dripping or splashing.

r Do not place any sources of danger on

the apparatus (e.g. liquid fi lled objects,
lighted candles).

s This product may contain lead and

mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org.

Caution

Use of controls or adjustments or performance of •
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.

Warning

Where the MAINS plug or an appliance coupler is used •
as the disconnect device, the disconnect device shall
remain readily operable.

Warning

Never remove the casing of this unit. •
Never lubricate any part of this unit.•
Place this unit on a fl at, hard and stable surface.•
Never place this unit on other electrical equipment.•
Only use this unit indoors. Keep this unit away from •
water, moisture and liquid-fi lled objects.

•

Keep this unit away from direct sunlight, naked fl ames
or heat.

•

Never look into the laser beam inside the unit.

Hearing safety

Listen at a moderate volume.

Using headphones at a high volume can •
impair your hearing. This product can
produce sounds in decibel ranges that may
cause hearing loss for a normal person,
even for exposure less than a minute. The
higher decibel ranges are offered for those
that may have already experienced some
hearing loss.
Sound can be deceiving. Over time your •
hearing ‘comfort level’ adapts to higher
volumes of sound. So after prolonged
listening, what sounds ‘normal’ can actually
be loud and harmful to your hearing. To
guard against this, set your volume to a safe
level before your hearing adapts and leave
it there.

To establish a safe volume level:

Set your volume control at a low setting. •
Slowly increase the sound until you can •
hear it comfortably and clearly, without
distortion.

Listen for reasonable periods of time:

Prolonged exposure to sound, even at •
normally ‘safe’ levels, can also cause hearing
loss.

6

EN

Be sure to use your equipment reasonably •
and take appropriate breaks.

Be sure to observe the following guidelines
when using your headphones.

Listen at reasonable volumes for •
reasonable periods of time.
Be careful not to adjust the volume as your •
hearing adapts.
Do not turn up the volume so high that •
you can’t hear what’s around you.
You should use caution or temporarily •
discontinue use in potentially hazardous
situations. Do not use headphones while
operating a motorized vehicle, cycling,
skateboarding, etc.; it may create a traffi c
hazard and is illegal in many areas.

Notice

This equipment should not be used for such
purposes.

English

‘DVD Video’ is a trademark of DVD Format/
Logo Licensing Corporation.

Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.

This apparatus includes this label:

Any changes or modifi cations made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.

Environmental information

All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.

Note

The type plate is located on the bottom of the •
apparatus.

The making of unauthorized copies of copy­protected material, including computer
programs, fi les, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.

EN

7

2 Your DVD

Micro Theater

Congratulations on your purchase, and
welcome to Philips! To fully benefi t from the
support that Philips offers, register your product
at www.Philips.com/welcome.

Introduction

With this unit, you can:

watch video from DVD/VCD/SVCD or •
USB devices
enjoy audio from discs or USB devices•
view pictures from discs or USB devices•
Listen to FM radio•

You can enrich sound output with these
sound effects:

Digital Sound Control (DSC)•
Dynamic Bass Boost (DBB)•
Bass/treble enhancement•

The unit supports these media/disc formats:

DVD region code Countries

China

What’s in the box

Check and identify the contents of your
package:

Main unit•
2 speakers•
Remote control with battery•
Composite video cable (yellow)•
Power cord•
FM wire antenna•
User manual•
Quick start guide•

Recordable

ReWritable

You can play DVD discs with the following
region codes:

8

EN

Overview of the main unit

a b c d fe g kh ij

English

a

Turn on the apparatus; switch to •
standby mode.

b VOLUME

Adjust volume.•
Adjust time. •

c SOURCE

Select a source.•

d Display panel

Display current status.•

e

Open or close the disc compartment.•

f Remote control sensor
g

/

Skip to the previous/next track.•
Skip to the previous/next title or •
chapter.
Select a preset radio station.•

/

lmno

h DBB

Turn on or off dynamic bass •
enhancement.

i

Start or pause play.•

j

Stop play.•
In demo mode, activate or deactivate •
demonstration.

k MODE

Select repeat play modes.•
Select shuffl e play modes.•

l MP3-LINK

Jack for an external audio device.•

m

Headphone socket.•

n USB DIRECT

USB socket.•

o Disc compartment

EN

9

Overview of the remote
control

a

b

c DISPLAY/RDS (RDS function unavailable

for this version)

Display play information on a •
connected TV.

d DISC MENU

For video discs: access or exit the disc •
menu.
For video discs with playback •
control(PBC): turn on/off PBC.

x

w
v

u

t
s

r

q

p

o

c

d
e

f

g

h

i

j

k

l

m
n

e AUDIO

For VCD, select stereo, mono-left or •
mono-right channel.
For DVD/DivX video, select an audio •
language.

f

/

Search within a track.•
Tune to a radio station.•
For menus, navigate left/right.•
Move an enlarged image left/right.•
Rotate or invert pictures.•

g

SLOW / ZOOM

For menus, navigate up/down.•
Rotate or invert pictures.•
(•

SLOW) For video: select a slow
play mode.
(•

ZOOM) For video: zoom in/out.

h LOUD/DBB

Turn on or off automatic loudness •
adjustment.
Turn on or off dynamic bass •
enhancement.

i VOL +/-

Adjust volume.•
Adjust time. •

a

Turn on the apparatus; switch to •
standby mode.

b Source selection keys

Select a source.•

10

EN

j MUTE

Mute or restore volume.•

k CLOCK

Set the clock.•

l SLEEP/TIMER

Set the sleep timer.•
Set the alarm timer.•
