Quick start guide
MCB700
What’s in the Box?
You should find these items upon opening the box.
DAB/FM antenna
Quick Start Guide
1
Quick Start Guide Control cableUser Manual
Remote Control
2
User Manual
Pull out the plastic
protective sheet
before use.
1
Connect the speaker cables.
3
Connect the control cable.
2
Connect the DAB/FM antenna.
Speaker
(right)
1
4
AC power cord
DAB/FM
antenna
2
4
Connect the power cord of the system.
Speaker
(left)
3
1
Tip
See the User Manual for how to
connect other equipment to this
system.
1
In standby mode, press and hold CLOCK on the remote.
2
When the hour digits flash, turn VOLUME-/+ on the system or press VOL+/- on the
remote to set the hours.
3
Press CLOCK again and the minute digits flash. Then turn VOLUME-/+ on the system or
press VOL+/- on the remote to set the minutes.
4
Press CLOCK again to confirm the time setting.
Playing a disc
1
Press SOURCE on the top of the system to select DISC or press
DISC on the remote.
2
Press OPEN•CLOSE to open the CD compartment.
3
Insert a disc with the pr inted side facing up. Press OPEN•CLOSE
again to close the compartment.
4
Playback will start automatically. If not press ENTER/ÉÅ.
5
To stop playback, press CANCEL/9 .
Tip
See the User Manual for detailed playback operations.
Tuning to DAB stations
1
Press SOURCE on the top of the system to select DAB (or press DAB on the remote) to star t
automatic search for available DAB stations.
2
Press and hold INTRO/SCAN to scan all band III frequencies.
3
At the completion of full scan, press the control knob on the front panel of the system to the left
or right (corresonding to
DAB channels backward/forward.
S/T) or press 5 /6 on the remote to select your desired
4
Press ENTER/ÉÅ to confirm and tune to your selected channel.
Tips
– If the reception is poor, hang up one end of the T-shape DAB/FM antenna
and keep the other end at horizontal angle to it.
– See the User Manuals for detailed instructions on DAB operations.
PDCC-JS/JW-0622
