Philips L01H.1E AA Service Manual

Colour television Chassis

L01H.1E

AA 02.01

 Service Information L01H.1E AA 02.01

Introduction

In this Service Information, all the new schematics and PCB layouts are given for the L01H.1E AA update to the “2002” PCB layout. The change will be introduced from week 236 onwards in production.

 Service Information L01H.1E AA 02.01

Einführung

In dieser Serviceinformation finden Sie alle neuen Schaltbilder und Platinenlayouts für das Chassis L01H.1EAA mit dem sogenannten “2002” Platinenlayout. Diese Änderungen sind ab Kalenderwoche 236 in die Produktion eingeflossen.

Inhalt

• Ersatzteilliste

• Elektrische Schaltbilder und Platinenlayouts

 Information Service L01H.1E AA 02.01

Introduction

Dans cette Information Service, vous trouverez les nouveaux schémas et implantations du L01H.1E AA adapté en "2002". Cette modification sera introduite en production à partir de la semaine 236.

Copyright 2002 Philips Consumer Electronics B.V. Eindhoven, The Netherlands. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.

Published by RB 0269 Service PaCE Printed in the Netherlands Subject to modification 3122 785 40690

EN 2 L01H.1E AA 02.01

Spare Parts List

Mono Carrier [A] and CRT Panel [B]

Various

0127 4822 265 11253 Fuse holder 0129 3139 120 10151 NTC holder 0136 4822 492 70788 IC fix 0137 4822 492 70289 IC fix 0138 4822 492 70788 IC fix 0139 3122 121 24785 Spring for bracket 0140 4822 492 70289 IC fix 0141 4822 492 70788 IC fix 0150 3139 131 00761 Cable 2p 560mm 0151 3104 311 02821 Cable 2p 560mm 0152 3104 301 09421 Cable 6p 400mm 0152 3104 311 04431 Cable 6p 480mm 0153 3104 311 04381 Cable 5p 560mm 0159 3104 311 02931 Cable 3p 400mm 0180 3104 311 03312 Cable 6p 680mm 0180 3139 131 01801 Cable 6p 680mm 0186 3104 311 02971 Cable 5p 560mm 0211 4822 265 20723 2p 0211 2422 025 16374 2p male 0212 4822 267 10774 2p male (red) 0214 4822 267 10734 5p 0219 2422 025 15849 6p male 0220 4822 265 30735 5p 0221 4822 267 10966 2p 0222 2422 025 10646 2p male 0224 4822 267 10982 2p 0231 2422 128 02972 Power switch 0235 4822 267 10771 42p female 0235 2422 025 16745 Scart 42p female 0239 2422 025 16382 3p male 0242 3139 131 00941 Cable 3p 560mm 0243 2422 025 04854 6p female 0244 4822 265 30735 5p 0245 2422 025 04854 6p female 0246 4822 267 10734 5p 0254 2422 500 80053 CRT 9p female 0254 2422 500 80076 CRT 9p female 0265 4822 267 10748 3p 0267 2422 025 16382 3p male 0268 4822 267 10735 3p 0278 4822 267 10735 3p 0278 2422 025 16382 3p male 0291 4822 267 10565 4p 1000 3139 147 17401 Tuner UR1316R/A I -3 1002 4822 242 81436 OFWK3953M 1004 2422 549 44341 Saw filter 38.9MHz

1200 4822 242 81712 TPWA04B 1400 2422 132 07543 Relay 5A 12V LKS1AF-H10 1500 2422 086 10914 Fuse 4A 250V 1515 2422 132 07467 Relay 1p 12V 5A LKS1AF 1660 2422 543 01203 Crystal 12.00MHz 1831 4822 242 10769 18.432MHz



2001 5322 122 32658 22pF 5% 50V 2002 5322 122 32658 22pF 5% 50V 2003 4822 122 33177 10nF 20% 50V 2004 4822 126 13751 47nF 10% 63V 2005 4822 124 40248 10µF 20% 63V 2006 4822 124 80791 470µF 20% 16V 2007 4822 126 14585 100nF 10% 50V 2008 4822 124 40207 100µF 20% 25V 2009 5322 122 32654 22nF 10% 63V 2010 5322 126 10511 1nF 5% 50V 2101 9965 000 10115 390pF 50V 10% 2102 9965 000 10115 390pF 50V 10% 2103 2020 552 96305 4.7µF 20-80% 10V 2104 9965 000 10115 390pF 50V 10% 2105 9965 000 10115 390pF 50V 10% 2106 2020 552 96305 4.7µF 20-80% 10V 2107 9965 000 10115 390pF 50V 10% 2108 9965 000 10115 390pF 50V 10% 2109 2020 552 96305 4.7µF 20-80% 10V 2110 9965 000 10115 390pF 50V 10% 2111 9965 000 10115 390pF 50V 10% 2112 2020 552 96305 4.7µF 20-80% 10V 2113 5322 122 32658 22pF 5% 50V 2114 5322 122 32658 22pF 5% 50V 2115 5322 122 32658 22pF 5% 50V 2116 5322 122 32658 22pF 5% 50V 2117 5322 122 32658 22pF 5% 50V 2118 5322 122 32658 22pF 5% 50V

OFWK9656M

2120 5322 122 32658 22pF 5% 50V 2131 9965 000 10115 390pF 50V 10% 2132 9965 000 10115 390pF 50V 10% 2133 2020 552 96305 4.7µF 20-80% 10V 2134 9965 000 10115 390pF 50V 10% 2135 9965 000 10115 390pF 50V 10% 2136 2020 552 96305 4.7µF 20-80% 10V 2137 9965 000 10115 390pF 50V 10% 2138 9965 000 10115 390pF 50V 10% 2139 2020 552 96305 4.7µF 20-80% 10V 2140 9965 000 10115 390pF 50V 10% 2141 9965 000 10115 390pF 50V 10% 2142 2020 552 96305 4.7µF 20-80% 10V 2143 5322 122 31863 330pF 5% 63V 2144 5322 122 31863 330pF 5% 63V 2145 5322 122 32658 22pF 5% 50V 2147 5322 122 32658 22pF 5% 50V 2151 5322 122 31863 330pF 5% 63V 2152 2020 552 96305 4.7µF 20-80% 10V 2153 5322 122 31863 330pF 5% 63V 2154 2020 552 96305 4.7µF 20-80% 10V 2161 4822 124 12392 47µF 20% 16V 2171 4822 126 13682 100pF 5% 1kV 2172 4822 126 12263 220pF 10% 1kV 2174 4822 122 31177 470pF 10% 500V 2175 2020 021 91577 470µF 20% 16V 2184 2020 552 96305 4.7µF 20-80% 10V 2201 4822 126 14585 100nF 10% 50V 2202 4822 126 14585 100nF 10% 50V 2203 4822 126 14585 100nF 10% 50V 2204 4822 126 14585 100nF 10% 50V 2205 4822 126 14076 220nF 25V 2206 4822 126 13693 56pF 1% 63V 2207 5322 126 10184 820pF 5% 50V 3 2208 4822 126 14585 100nF 10% 50V 2209 4822 124 40248 10µF 20% 63V 2210 4822 126 14043 1µF 20-80% 16V 2211 4822 126 13482 470nF 80/20% 16V 2213 5322 122 32654 22nF 10% 63V 2214 5322 122 32654 22nF 10% 63V 2215 5322 122 32654 22nF 10% 63V 2216 4822 124 81144 1000µF 16V 2216 2020 012 93728 2200µF 20% 10V 2217 5322 122 32654 22nF 10% 63V 2219 4822 126 14076 220nF 25V 2220 4822 121 51252 470nF 5% 63V 2221 5322 122 32654 22nF 10% 63V 2230 4822 124 40769 4.7µF 20% 100V 2234 4822 126 14585 100nF 10% 50V 2238 5322 126 10511 1nF 5% 50V 2239 5322 126 10511 1nF 5% 50V 2240 5322 126 10511 1nF 5% 50V 2241 4822 126 13344 1.5nF 5% 63V 2242 4822 126 14043 1µF 20-80% 16V 2243 4822 122 33177 10nF 20% 50V 2244 5322 121 42386 100nF 5% 63V 2245 4822 126 14076 220nF 25V 2245 4822 126 14107 330nF 20-80% 25V 2247 4822 124 81144 1000µF 16V 2247 2020 012 93728 2200µF 20% 10V 2248 5322 122 32654 22nF 10% 63V 2249 5322 122 32654 22nF 10% 63V 2250 4822 124 22652 2.2µF 20% 50V 2252 5322 126 10511 1nF 5% 50V 2253 5322 126 10511 1nF 5% 50V 2254 4822 051 20008 Jumper 2330 4822 121 51473 470nF 20% 63V 2340 4822 124 11565 10µF 20% 250V 2341 4822 126 13599 3.3nF 10% 500V 2342 5322 116 80853 560pF 5% 63V 2343 4822 126 13451 2.2nF 10% 2kV 2343 4822 126 12278 3300pF10% 2kV 2344 4822 051 20008 Jumper 2345 4822 122 31175 1nF 10% 500V 2346 4822 126 13435 1.2nF 10% 2kV 2346 4822 126 14237 470pF 10% 2kV 2360 4822 124 40764 22µF 100V 2361 4822 124 40207 100µF 20% 25V 2365 4822 121 40516 22nF 10% 250V 2366 4822 121 40334 100nF 10% 100V 2367 5322 122 33861 120pF10% 50V 2367 5322 122 33538 150pF 2% 63V 2367 4822 126 10326 180pF 5% 63V 2368 5322 122 32654 22nF 10% 63V 2373 4822 126 13693 56pF 1% 63V 2375 5322 122 31863 330pF 5% 63V 2376 4822 126 14585 100nF 10% 50V 2377 4822 126 14585 100nF 10% 50V 2401 4822 124 12438 2.2µF 20% 100V

2401 5322 124 41379 2.2µF 20% 50V 2402 4822 122 31177 470pF 10% 500V 2404 4822 124 41751 47µF 20% 50V 2405 4822 124 40196 220µF 20% 16V 2405 4822 124 80875 220µF 20% 25V 2420 4822 126 14043 1µF 20-80% 16V 2421 5322 122 32268 470pF 5% 63V 2441 4822 124 21913 1µF 20% 63V 2443 4822 126 13751 47nF 10% 63V 2444 4822 124 21913 1µF 20% 63V 2450 4822 124 11575 47µF 20% 160V 2451 4822 121 51305 15nF 10% 50V 2451 4822 121 41856 22nF 5% 250V 2452 4822 126 10326 180pF 5% 63V 2454 2222 479 90133 68nF 5% 250V 2455 4822 124 40433 47µF 20% 25V 2457 4822 121 42365 330nF 5% 250V 2457 4822 121 10781 470nF 5% 250V 2458 4822 124 12438 2.2µF 20% 100V 2459 4822 126 13185 680pF10% 500V 2460 5322 122 32531 100pF 5% 50V 2463 4822 126 14237 470pF 10% 2kV 2463 4822 126 14138 680pF 10% 2kV 2464 4822 121 10739 2.2µF 5% 160V 2465 4822 121 70618 12nF 5% 1600V 2465 4822 121 70637 8.2nF 5% 1600V 2466 4822 121 40483 10nF 10% 400V 2466 2222 347 90219 15nF 10% 400V 2467 2222 375 90424 9.1nF 5% 1kV 2468 5322 121 42532 18nF 10% 400V 2468 2222 375 90424 9.1nF 5% 1kV 2469 4822 126 14096 560nF 5% 250V 2471 5322 121 42386 100nF 5% 63V 2472 4822 121 41854 150nF 5% 63V 2473 5322 121 42386 100nF 5% 63V 2474 4822 122 33127 2.2nF 10% 63V 2475 4822 122 33127 2.2nF 10% 63V 2476 5322 126 10223 4.7nF 10% 63V 2480 5322 121 10472 47µF 2481 4822 122 31177 470pF 10% 500V 2482 4822 121 51408 33nF 10% 250V 2482 4822 121 40482 68nF 10% 250V 2485 4822 124 12265 4.7µF 20% 250V 2486 2020 021 91577 470µF 20% 16V 2487 4822 124 80604 47µF 20% 50V 2488 4822 124 81145 16V 20% 1000µF 2489 2020 021 91577 470µF 20% 16V 2490 4822 124 12438 2.2µF 20% 100V 2491 4822 122 31175 1nF 10% 500V 2493 2222 347 90219 15nF 10% 400V 2500 4822 126 13589 470nF 275V 2501 4822 126 14153 2.2nF 10% 1kV 2502 4822 126 14153 2.2nF 10% 1kV 2503 4822 124 12415 220µF 20% 400V 2505 4822 126 14153 2.2nF 10% 1kV 2505 4822 126 13599 3.3nF 10% 500V 2506 4822 121 10798 33nF 5% 400V 2507 5322 122 34099 470pF 10% 63V 2508 4822 122 50116 470pF 10% 1kV 2509 4822 121 10711 100nF 20% 275V 2515 4822 126 14049 1.5nF 20% 250V 2516 4822 126 14208 220pF 20% 250V 2516 4822 126 13867 330P 20% 250V 2520 4822 126 14585 100nF 10% 50V 2520 4822 122 33177 10nF 20% 50V 2521 4822 124 81151 22µF 50V 2522 4822 126 14585 100nF 10% 50V 2523 4822 126 13862 1.5nF 10% 2kV 2525 5322 122 34099 470pF 10% 63V 2526 4822 126 13482 470nF 80/20% 16V 2527 4822 122 33127 2.2nF 10% 63V 2528 5322 122 31647 1nF 10% 63V 2540 4822 122 33177 10nF 20% 50V 2541 4822 122 33177 10nF 20% 50V 2560 4822 126 14152 680pF 10% 1kV 2561 2020 021 91496 100µF 20% 160V 2562 5322 122 32331 1nF 10% 100V 2563 5322 121 42386 100nF 5% 63V 2564 4822 124 12417 2200µF 20% 25V 2564 2020 021 91374

2567 4822 124 40433 47µF 20% 25V 2568 4822 124 21913 1µF 20% 63V 2580 4822 124 81286 47µF 20% 16V 2581 4822 124 81151 22µF 50V 2601 4822 126 14076 220nF 25V 2602 5322 122 32531 100pF 5% 50V 2604 4822 124 40248 10µF 20% 63V

ELECTROLYTICPM25V.S22 0

Spare Parts List

EN 3L01H.1E AA 02.01

2606 5322 122 31647 1nF 10% 63V 2607 2238 861 18339 33P 1% 50V 2608 4822 126 14043 1µF 20-80% 16V 2609 2238 861 18339 33P 1% 50V 2611 4822 126 14043 1µF 20-80% 16V 2612 4822 126 13694 68pF 1% 63V 2613 4822 126 13694 68pF 1% 63V 2615 5322 122 31647 1nF 10% 63V 2618 4822 126 14043 1µF 20-80% 16V 2619 4822 126 14043 1µF 20-80% 16V 2691 4822 124 40248 10µF 20% 63V 2801 4822 124 40207 100µF 20% 25V 2801 4822 124 81151 22µF 50V 2802 4822 126 14076 220nF 25V 2802 2020 552 96305 4.7µF 20-80% 10V 2803 2020 552 96305 4.7µF 20-80% 10V 2804 2020 552 96305 4.7µF 20-80% 10V 2805 2020 552 96305 4.7µF 20-80% 10V 2811 2020 552 96305 4.7µF 20-80% 10V 2823 4822 124 40207 100µF 20% 25V 2824 2020 552 96305 4.7µF 20-80% 10V 2831 5322 122 32447 1pF 5% 63V 2832 5322 122 32447 1pF 5% 63V 2833 4822 126 13692 47pF 1% 63V 2834 5322 122 32268 470pF 5% 63V 2835 4822 122 33575 220pF 5% 63V 2836 4822 126 13344 1.5nF 5% 63V 2837 4822 124 40769 4.7µF 20% 100V 2840 4822 126 14585 100nF 10% 50V 2841 4822 124 40248 10µF 20% 63V 2842 4822 126 14585 100nF 10% 50V 2843 4822 124 40248 10µF 20% 63V 2844 4822 124 40248 10µF 20% 63V 2845 4822 126 14585 100nF 10% 50V 2846 4822 124 40207 100µF 20% 25V 2849 5322 126 10511 1nF 5% 50V 2850 5322 126 10511 1nF 5% 50V 2851 2020 552 96305 4.7µF 20-80% 10V 2851 4822 051 20008 Jumper 2852 5322 126 10511 1nF 5% 50V 2853 2020 552 96305 4.7µF 20-80% 10V 2853 4822 051 20008 Jumper 2854 5322 126 10511 1nF 5% 50V 2855 4822 122 30045 27pF 2% 100V 2856 4822 126 13486 15pF 2% 63V 2857 5322 122 33538 150pF 2% 63V 2858 5322 126 10511 1nF 5% 50V 2859 5322 126 10511 1nF 5% 50V 2860 4822 126 13693 56pF 1% 63V 2862 2020 552 96305 4.7µF 20-80% 10V 2887 4822 122 33177 10nF 20% 50V 2894 4822 122 33575 220pF 5% 63V 2895 5322 116 80853 560pF 5% 63V 2897 4822 122 33172 390pF 5% 50V 2898 4822 122 33177 10nF 20% 50V 2902 4822 124 81144 1000µF 16V 2902 4822 124 80061 1000µF 20% 25V 2903 4822 124 21913 1µF 20% 63V 2904 4822 126 13482 470nF 80/20% 16V 2905 5322 122 31647 1nF 10% 63V 2905 5322 116 80853 560pF 5% 63V 2906 4822 126 13482 470nF 80/20% 16V 2907 5322 122 31647 1nF 10% 63V 2907 5322 116 80853 560pF 5% 63V 2908 4822 124 40248 10µF 20% 63V 2910 5322 122 31647 1nF 10% 63V 2910 4822 122 33891 3.3nF 10% 63V 2911 5322 122 31647 1nF 10% 63V 2911 4822 122 33891 3.3nF 10% 63V 2950 5322 122 31863 330pF 5% 63V



3000 4822 116 52175 100Ω 5% 0.5W 3001 4822 116 52175 100Ω 5% 0.5W 3002 4822 117 10833 10kΩ 1% 0.1W 3002 4822 051 20008 Jumper 3003 4822 117 11139 1.5kΩ 1% 0.1W 3005 4822 116 52175 100Ω 5% 0.5W 3006 4822 117 11449 2.2kΩ 5% 0.1W 3007 4822 117 11507 6.8kΩ 1% 0.1W 3008 4822 117 11449 2.2kΩ 5% 0.1W 3010 4822 117 13577 330Ω 1% 1.25W 3101 4822 116 83868 150Ω 5% 0.5W 3102 3198 021 52240 220kΩ 5% 3103 4822 116 83868 150Ω 5% 0.5W 3104 4822 117 10834 47kΩ 1% 0.1W 3105 4822 116 83868 150Ω 5% 0.5W 3106 3198 021 52240 220kΩ 5% 3107 4822 116 83868 150Ω 5% 0.5W 3108 4822 117 10834 47kΩ 1% 0.1W 3109 4822 116 52201 75Ω 5% 0.5W 3110 4822 116 52175 100Ω 5% 0.5W

3111 4822 116 52264 27kΩ 5% 0.5W 3112 4822 117 11507 6.8kΩ 1% 0.1W 3113 4822 116 52201 75Ω 5% 0.5W 3114 4822 116 52175 100Ω 5% 0.5W 3115 4822 116 52201 75Ω 5% 0.5W 3116 4822 116 52175 100Ω 5% 0.5W 3117 4822 116 52201 75Ω 5% 0.5W 3118 4822 116 52175 100Ω 5% 0.5W 3119 4822 116 52199 68Ω 5% 0.5W 3120 4822 051 10102 1kΩ 2% 0.25W 3131 4822 116 83868 150Ω 5% 0.5W 3132 3198 021 52240 220kΩ 5% 3133 4822 116 83868 150Ω 5% 0.5W 3134 4822 117 10834 47kΩ 1% 0.1W 3135 4822 116 83868 150Ω 5% 0.5W 3136 3198 021 52240 220kΩ 5% 3137 4822 116 83868 150Ω 5% 0.5W 3138 4822 117 10834 47kΩ 1% 0.1W 3139 4822 116 52264 27kΩ 5% 0.5W 3140 4822 117 11507 6.8kΩ 1% 0.1W 3141 4822 116 52201 75Ω 5% 0.5W 3142 4822 116 52175 100Ω 5% 0.5W 3143 4822 116 52199 68Ω 5% 0.5W 3144 4822 051 10102 1kΩ 2% 0.25W 3151 4822 116 83868 150Ω 5% 0.5W 3152 3198 021 52240 220kΩ 5% 3153 4822 116 83868 150Ω 5% 0.5W 3154 3198 021 52240 220kΩ 5% 3155 4822 116 52195 47Ω 5% 0.5W 3171 4822 050 11204 120kΩ 1% 0.4W 3172 4822 116 83961 6.8kΩ 5% 3173 4822 116 52297 68kΩ 5% 0.5W 3174 4822 116 52297 68kΩ 5% 0.5W 3176 4822 052 11108 1Ω 5% 0.5W 3200 4822 116 83881 390Ω 5% 0.5W 3201 4822 116 52175 100Ω 5% 0.5W 3202 4822 116 52175 100Ω 5% 0.5W 3203 4822 116 52175 100Ω 5% 0.5W 3204 4822 116 52257 22kΩ 5% 0.5W 3206 4822 051 20124 120kΩ 5% 0.1W 3206 4822 051 20154 150kΩ 5% 0.1W 3206 3198 021 52240 220kΩ 5% 3207 4822 050 11002 1kΩ 1% 0.4W 3208 4822 117 11503 220Ω 1% 0.1W 3209 4822 117 12521 68Ω 1% 0.1W 3212 4822 051 20471 470Ω 5% 0.1W 3213 4822 051 20561 560Ω 5% 0.1W 3214 4822 116 52175 100Ω 5% 0.5W 3217 4822 051 20334 330kΩ 5% 0.1W 3218 4822 117 11149 82kΩ 1% 0.1W 3219 4822 117 11449 2kΩ2 5% 0.1W 3223 4822 117 11373 100Ω 1% 3226 4822 051 20561 560Ω 5% 0.1W 3229 4822 117 11454 820Ω 1% 0.1W 3230 4822 117 11504 270Ω 1% 0.1W 3231 4822 051 20561 560Ω 5% 0.1W 3233 4822 117 11454 820Ω 1% 0.1W 3235 4822 116 52175 100Ω 5% 0.5W 3236 4822 051 20154 150kΩ 5% 0.1W 3237 4822 051 20122 1kΩ20 5% 0.1W 3238 4822 051 20561 560Ω 5% 0.1W 3239 4822 117 11504 270Ω 1% 0.1W 3240 4822 117 10837 100kΩ 1% 0.1W 3241 4822 051 20223 22kΩ 5% 0.1W 3242 4822 117 11383 12kΩ 1% 0.1W 3244 4822 116 52231 820Ω 5% 0.5W 3245 4822 117 12708 39kΩ 1% 0.1W 3245 4822 051 20393 39kΩ 5% 0.1W 3246 4822 117 10833 10kΩ 1% 0.1W 3247 2120 108 92641 180kΩ 1% 3247 4822 051 20564 560kΩ 5% 0.1W 3248 4822 051 20333 33kΩ 5% 0.1W 3249 4822 116 52231 820Ω 5% 0.5W 3250 4822 050 11002 1kΩ 1% 0.4W 3250 4822 116 52303 8.2kΩ 5% 0.5W 3251 4822 116 52175 100Ω 5% 0.5W 3256 4822 051 10102 1kΩ 2% 0.25W 3257 4822 051 20106 10M Ω 5% 0.1W 3257 4822 051 20105 1M Ω 5% 0.1W 3258 4822 117 10837 100kΩ 1% 0.1W 3258 2120 108 92641 180kΩ 1% 3258 4822 051 20274 270kΩ 5% 0.1W 3259 4822 051 20475 4.7M Ω 5% 0.1W 3259 4822 051 20474 470kΩ 5% 0.1W 3270 4822 051 20008 Jumper 3331 4822 116 52175 100Ω 5% 0.5W 3332 3198 013 01020 1kΩ 20% 0.5W 3333 4822 116 52175 100Ω 5% 0.5W 3334 3198 013 01020 1kΩ 20% 0.5W 3335 4822 116 52175 100Ω 5% 0.5W 3336 3198 013 01020 1kΩ 20% 0.5W 3340 4822 052 11109 10Ω 5% 0.5W 3341 4822 052 10108 1Ω 5% 0.33W 3342 4822 052 10108 1Ω 5% 0.33W

3343 3198 013 01520 1.5kΩ 20% 0.5W 3344 4822 116 52186 22Ω 5% 0.5W 3344 4822 116 52191 33Ω 5% 0.5W 3345 4822 117 13016 1mA/50V max 115V 3346 4822 116 52186 22Ω 5% 0.5W 3346 4822 116 52191 33Ω 5% 0.5W 3347 4822 051 10102 1kΩ 2% 0.25W 3348 4822 051 10102 1kΩ 2% 0.25W 3350 4822 051 10102 1kΩ 2% 0.25W 3351 4822 051 10102 1kΩ 2% 0.25W 3353 4822 051 10102 1kΩ 2% 0.25W 3354 4822 051 10102 1kΩ 2% 0.25W 3360 4822 117 13424 8.2kΩ 5% 5W 3362 4822 052 10109 10Ω 5% 0.33W 3363 4822 116 52231 820Ω 5% 0.5W 3364 4822 116 80176 1Ω 5% 0.5W 3364 4822 116 81039 1.8Ω 5% 0.5W 3368 4822 117 12955 2.7kΩ 1% 0.1W 3369 4822 117 10833 10kΩ 1% 0.1W 3370 4822 117 11503 220Ω 1% 0.1W 3371 4822 051 20472 4.7kΩ 5% 0.1W 3373 4822 117 11503 220Ω 1% 0.1W 3374 4822 116 52291 56kΩ 5% 0.5W 3375 4822 116 83868 150Ω 5% 0.5W 3375 4822 116 83872 220Ω 5% 0.5W 3376 4822 051 20008 Jumper 3377 4822 050 24708 4.7Ω 1% 0.6W 3378 4822 117 11148 56kΩ 1% 0.1W 3379 4822 051 20472 4.7kΩ 5% 0.1W 3382 4822 117 11139 1.5kΩ 1% 0.1W 3383 4822 051 20471 470Ω 5% 0.1W 3384 4822 117 11454 820Ω 1% 0.1W 3385 4822 116 80176 1Ω 5% 0.5W 3385 4822 116 81039 1.8Ω 5% 0.5W 3386 4822 051 20472 4.7kΩ 5% 0.1W 3387 4822 051 20471 470Ω 5% 0.1W 3390 4822 051 20109 10Ω 5% 0.1W 3391 4822 051 20109 10Ω 5% 0.1W 3392 4822 117 11373 100Ω 1% 3392 4822 117 11503 220Ω 1% 0.1W 3393 4822 051 20472 4.7kΩ 5% 0.1W 3400 4822 116 52219 330Ω 5% 0.5W 3401 4822 116 83874 220kΩ 5% 0.5W 3401 4822 116 52257 22kΩ 5% 0.5W 3401 4822 050 23303 33kΩ 1% 0.6W 3403 4822 116 52234 100kΩ 5% 0.5W 3403 4822 116 52297 68kΩ 5% 0.5W 3403 4822 116 52304 82kΩ 5% 0.5W 3404 4822 050 11002 1kΩ 1% 0.4W 3405 4822 050 24708 4.7Ω 1% 0.6W 3406 4822 050 24708 4.7Ω 1% 0.6W 3407 4822 050 24708 4.7Ω 1% 0.6W 3408 4822 116 52175 100Ω 5% 0.5W 3408 4822 050 21003 10kΩ 1% 0.6W 3410 4822 050 21003 10kΩ 1% 0.6W 3411 4822 052 10478 4.7Ω 5% 0.33W 3441 4822 117 11373 100Ω 1% 3442 4822 051 20008 Jumper 3443 4822 051 20105 1M Ω 5% 0.1W 3445 4822 116 52244 15kΩ 5% 0.5W 3446 4822 116 52289 5.6kΩ 5% 0.5W 3447 4822 116 52213 180Ω 5% 0.5W 3448 4822 116 52231 820Ω 5% 0.5W 3449 4822 116 52199 68Ω 5% 0.5W 3450 4822 116 52191 33Ω 5% 0.5W 3451 4822 052 10109 10Ω 5% 0.33W 3452 4822 050 24703 47kΩ 1% 0.6W 3453 4822 050 11002 1kΩ 1% 0.4W 3454 4822 050 21503 15kΩ 1% 0.6W 3455 4822 053 11688 6.8Ω 5% 2W 3456 4822 051 20008 Jumper 3457 4822 051 20008 Jumper 3458 4822 050 11002 1kΩ 1% 0.4W 3459 4822 053 11153 15kΩ 5% 2W 3460 4822 116 52276 3.9kΩ 5% 0.5W 3463 4822 116 52191 33Ω 5% 0.5W 3465 2312 915 12203 22kΩ 1% 3465 4822 050 22703 27kΩ 1% 0.6W 3465 4822 050 25603 56kΩ 1% 0.6W 3468 4822 116 52213 180Ω 5% 0.5W 3469 4822 116 52269 3.3kΩ 5% 0.5W 3470 2120 108 92641 180kΩ 1% 3470 4822 051 20274 270kΩ 5% 0.1W 3470 4822 051 20334 330kΩ 5% 0.1W 3470 4822 051 20474 470kΩ 5% 0.1W 3471 4822 050 22202 2.2kΩ 1% 0.6W 3471 4822 050 23308 3.3Ω 1% 0.6W 3471 4822 050 23908 3.9Ω 1% 0.6W 3471 4822 050 25608 5.6Ω 1% 0.6W 3472 4822 050 23308 3.3Ω 1% 0.6W 3472 4822 050 25608 5.6Ω 1% 0.6W 3473 4822 050 23308 3.3Ω 1% 0.6W 3473 4822 050 23908 3.9Ω 1% 0.6W 3473 4822 050 25608 5.6Ω 1% 0.6W

EN 4 L01H.1E AA 02.01

Spare Parts List

3474 4822 050 22202 2.2kΩ 1% 0.6W 3475 4822 050 22202 2.2kΩ 1% 0.6W 3477 4822 116 83868 150Ω 5% 0.5W 3478 4822 116 83868 150Ω 5% 0.5W 3479 4822 117 12955 2.7kΩ 1% 0.1W 3480 4822 116 80676 1.5Ω 5% 0.5W 3481 4822 050 21503 15kΩ 1% 0.6W 3481 2312 915 12203 22kΩ 1% 3481 4822 050 22703 27kΩ 1% 0.6W 3482 4822 050 23902 3.9kΩ 1% 0.6W 3482 4822 050 23901 390Ω 1% 0.6W 3482 2312 915 15602 5kΩ6 1% 3484 4822 116 52276 3.9kΩ 5% 0.5W 3486 4822 053 12229 22Ω 5% 3W 3486 4822 053 12339 33Ω 5% 3W 3488 4822 052 11478 4.7Ω 5% 0.5W 3489 4822 116 52276 3.9kΩ 5% 0.5W 3490 4822 116 52303 8.2kΩ 5% 0.5W 3491 4822 117 10833 10kΩ 1% 0.1W 3491 4822 051 20332 3.3kΩ 5% 0.1W 3492 4822 051 10102 1kΩ 2% 0.25W 3492 4822 117 13577 330Ω 1% 1.25W 3493 4822 052 10688 6.8Ω 5% 0.33W 3494 4822 052 11478 4.7Ω 5% 0.5W 3495 4822 051 20223 22kΩ 5% 0.1W 3496 4822 117 10837 100kΩ 1% 0.1W 3497 4822 117 10837 100kΩ 1% 0.1W 3498 4822 117 11383 12kΩ 1% 0.1W 3500 4822 053 21335 3.3M Ω 5% 0.5W 3501 4822 053 21335 3.3M Ω 5% 0.5W 3504 4822 116 10105 PTC 9Ω 220V 3506 4822 053 21155 1.5Ω 5% 0.5W 3507 4822 252 11215 Spark gap 3508 4822 116 83872 220Ω 5% 0.5W 3509 3198 013 04710 470Ω 20% 0.5W 3510 4822 117 12765 4.7Ω 20% 3W 3519 4822 116 83876 270Ω 5% 0.5W 3520 4822 051 20122 1.2kΩ 5% 0.1W 3521 4822 116 52186 22Ω 5% 0.5W 3521 4822 050 24708 4.7Ω 1% 0.6W 3522 2322 734 63004 300kΩ 1% 3522 4822 051 20334 330kΩ 5% 0.1W 3522 4822 051 20394 390kΩ 5% 0.1W 3523 4822 052 10479 47Ω 5% 0.33W 3524 4822 117 11148 56kΩ 1% 0.1W 3525 4822 051 10102 1kΩ 2% 0.25W 3526 3198 012 11570 0.15Ω 5% 1W 3526 4822 117 11744 0.22Ω 5% 1W 3527 4822 117 11744 0.22Ω 5% 1W 3528 4822 051 20109 10Ω 5% 0.1W 3528 4822 051 20008 Jumper 3529 4822 117 10834 47kΩ 1% 0.1W 3530 4822 117 10833 10kΩ 1% 0.1W 3531 4822 051 20472 4.7kΩ 5% 0.1W 3532 4822 052 10222 2.2kΩ 5% 0.33W 3541 4822 051 20471 470Ω 5% 0.1W 3542 4822 117 11139 1.5kΩ 1% 0.1W 3543 4822 050 28203 82kΩ 1% 0.6W 3544 2120 108 92624 4.7kΩ1% 3545 4822 051 20274 270kΩ 5% 0.1W 3545 4822 051 20393 39kΩ 5% 0.1W 3548 4822 116 83933 15kΩ 1% 0.1W 3552 4822 051 20472 4.7kΩ 5% 0.1W 3557 4822 051 10102 1kΩ 2% 0.25W 3557 4822 117 11139 1.5kΩ 1% 0.1W 3561 4822 116 52213 180Ω 5% 0.5W 3561 4822 116 83872 220Ω 5% 0.5W 3562 4822 117 11383 12kΩ 1% 0.1W 3562 4822 116 83933 15kΩ 1% 0.1W 3562 4822 051 20822 8.2kΩ 5% 0.1W 3563 4822 051 20472 4.7kΩ 5% 0.1W 3563 4822 051 20822 8.2kΩ 5% 0.1W 3564 2120 106 90565 0.1Ω 5% 3565 4822 053 10221 220Ω 5% 1W 3565 4822 053 10331 330Ω 5% 1W 3566 4822 117 11449 2kΩ2 5% 0.1W 3569 4822 051 20562 5.6kΩ 5% 0.1W 3580 4822 117 10834 47kΩ 1% 0.1W 3594 4822 117 13577 330Ω 1% 1.25W 3595 3198 021 52240 220kΩ 5% 3596 3198 021 52240 220kΩ 5% 3603 4822 116 52175 100Ω 5% 0.5W 3604 4822 116 52175 100Ω 5% 0.5W 3605 4822 051 20472 4.7kΩ 5% 0.1W 3606 4822 116 52256 2kΩ2 5% 0.5W 3607 4822 116 52256 2kΩ2 5% 0.5W 3608 4822 116 52175 100Ω 5% 0.5W 3609 4822 050 21003 10kΩ 1% 0.6W 3610 4822 116 52303 8.2kΩ 5% 0.5W 3611 4822 117 11373 100Ω 1% 3612 4822 116 52303 8.2kΩ 5% 0.5W 3614 4822 116 52283 4.7kΩ 5% 0.5W 3615 4822 050 21003 10kΩ 1% 0.6W 3617 4822 116 52283 4.7kΩ 5% 0.5W

3618 4822 050 21003 10kΩ 1% 0.6W 3618 4822 116 83961 6.8kΩ 5% 3619 4822 116 52303 8.2kΩ 5% 0.5W 3622 4822 117 11373 100Ω 1% 3623 4822 051 20472 4.7kΩ 5% 0.1W 3624 4822 116 52175 100Ω 5% 0.5W 3625 4822 116 52175 100Ω 5% 0.5W 3626 4822 051 20472 4.7kΩ 5% 0.1W 3627 4822 051 20472 4.7kΩ 5% 0.1W 3628 4822 117 10833 10kΩ 1% 0.1W 3630 4822 117 11449 2kΩ2 5% 0.1W 3632 4822 051 20008 Jumper 3634 4822 116 52175 100Ω 5% 0.5W 3635 4822 116 52175 100Ω 5% 0.5W 3636 4822 117 11373 100Ω 1% 3638 4822 117 11927 75Ω 1% 0.1W 3640 4822 116 52175 100Ω 5% 0.5W 3691 4822 117 13577 330Ω 1% 1.25W 3692 4822 051 10102 1kΩ 2% 0.25W 3693 4822 117 11503 220Ω 1% 0.1W 3694 4822 051 20472 4.7kΩ 5% 0.1W 3801 4822 116 83872 220Ω 5% 0.5W 3802 4822 050 11002 1kΩ 1% 0.4W 3802 4822 116 83872 220Ω 5% 0.5W 3803 4822 117 10837 100kΩ 1% 0.1W 3803 4822 051 20124 120kΩ 5% 0.1W 3804 3198 021 52240 220kΩ 5% 3804 4822 117 11149 82kΩ 1% 0.1W 3805 4822 051 10102 1kΩ 2% 0.25W 3806 4822 117 10837 100kΩ 1% 0.1W 3806 4822 051 20124 120kΩ 5% 0.1W 3807 3198 021 52240 220kΩ 5% 3807 4822 117 11149 82kΩ 1% 0.1W 3808 4822 050 11002 1kΩ 1% 0.4W 3809 4822 117 11927 75Ω 1% 0.1W 3810 4822 117 11927 75Ω 1% 0.1W 3811 4822 051 20471 470Ω 5% 0.1W 3812 4822 051 20564 560kΩ 5% 0.1W 3813 4822 117 10837 100kΩ 1% 0.1W 3814 4822 117 10837 100kΩ 1% 0.1W 3815 4822 117 11503 220Ω 1% 0.1W 3831 4822 117 10834 47kΩ 1% 0.1W 3832 4822 116 52175 100Ω 5% 0.5W 3833 4822 116 52175 100Ω 5% 0.5W 3837 4822 117 11373 100Ω 1% 3839 4822 117 11373 100Ω 1% 3840 4822 051 20472 4.7kΩ 5% 0.1W 3841 4822 051 20822 8.2kΩ 5% 0.1W 3842 4822 051 10102 1kΩ 2% 0.25W 3844 4822 117 11373 100Ω 1% 3845 4822 117 11373 100Ω 1% 3849 4822 051 20471 470Ω 5% 0.1W 3861 4822 117 10833 10kΩ 1% 0.1W 3901 4822 051 10102 1kΩ 2% 0.25W 3901 4822 117 11507 6.8kΩ 1% 0.1W 3902 4822 051 20332 3.3kΩ 5% 0.1W 3903 4822 051 20332 3.3kΩ 5% 0.1W 3903 4822 117 11149 82kΩ 1% 0.1W 3904 4822 117 10833 10kΩ 1% 0.1W 3905 4822 051 20332 3.3kΩ 5% 0.1W 3905 4822 117 11149 82kΩ 1% 0.1W 3906 4822 117 10833 10kΩ 1% 0.1W 3907 4822 117 11507 6.8kΩ 1% 0.1W 3909 4822 051 20273 27kΩ 5% 0.1W 3910 4822 051 20273 27kΩ 5% 0.1W 3912 4822 116 52231 820Ω 5% 0.5W 4xxx 4822 051 10008 0Ω 5% 0.25W (1206) 4xxx 4822 051 20008 0Ω 5% 0.25W (0805)



5001 4822 157 51216 5.6µH 5002 2422 535 94639 10µH 20% 5003 4822 157 11866 1.8µH 10% 5180 4822 157 71401 27µH 5201 4822 157 11868 2.7µH 5% 5204 4822 157 11411 100mH z 5205 4822 157 11411 100mH z 5206 4822 157 11411 100mH z 5242 4822 157 11706 10µH 5% 5342 4822 157 50961 22µH 5342 4822 156 21125 3.9µH 10% 5343 2722 122 00333 Delay line 160ns SDL-4893 5344 2722 122 00333 Delay line 160ns SDL-4893 5345 2722 122 00333 Delay line 160ns SDL-4893 5360 4822 157 51216 5.6µH 5400 2422 535 91027 Choke coil 11.7mHz 8.4Ω

5401 4822 157 11885 1000µH 5% 5445 2422 531 02464 LOT 1342.0033C 5445 3128 138 21411 Transformer LOT PSLOT

C906-0

29”RF

5445 3128 138 21921 Transformer LOT PSLOT

5451 4822 157 11737 22µH 10% 5451 4822 157 11869 33µH 10% 5452 4822 157 11411 100mHz 5457 2422 535 91028 Linearity coil 25µH C907-01 5457 4822 157 11076 Linearity coil 25µH C907-01 5457 4822 157 11671 Linearity drum coil 5461 2422 536 00181 Transformer driver

5461 2422 531 02465 Transformer sig driver

5463 2422 536 00048 Bridge coil C957-02 5463 4822 157 11711 Choke coil 5464 2422 531 02419 Bridge coil C946-01 5471 3198 018 73380 3.3µH 20% 5471 2422 535 94638 6.8µH 20% 5472 4822 157 51157 3.3µH 5480 4822 157 50961 22µH 5480 4822 156 20915 33µH 5480 5322 157 51687 39µH 5500 4822 157 10476 DMF-2820H 5501 4822 157 11523 DMF-2405 5502 2422 549 45296 Mains harmonic filter 38mH 5502 2422 549 44694 Mains harmonic filter 65mH 5520 3128 138 39721 Transformer CT425V 5520 2422 531 02544 Transformer POW LAYER

5520 2422 531 02539 Transformer SS42030-03 5521 4822 526 10704 Bead 100mHz 5560 4822 526 10704 Bead 100mHz 5561 4822 157 52392 27µH 5562 4822 526 10704 Bead 100mHz 5564 4822 526 10704 Bead 100mHz 5602 4822 157 11867 5.6µH 5% 5603 4822 157 11867 5.6µH 5% 5604 4822 157 11867 5.6µH 5% 5672 4822 157 71401 27µH 5678 4822 157 71401 27µH 5831 4822 157 11139 6.8µH 5% 5832 4822 157 11139 6.8µH 5% 5833 4822 157 11139 6.8µH 5% 5835 3198 018 31290 12µH 10%

OV2076

SRW0913DR-T

SC10015

PSS42-11



6001 4822 130 34142 BZX79-B33 6002 4822 130 11397 BAS316 6004 4822 130 11525 1SS356 6101 4822 130 10837 UDZS8.2B 6103 4822 130 10837 UDZS8.2B 6104 4822 130 10837 UDZS8.2B 6105 4822 130 10837 UDZS8.2B 6106 4822 130 11416 PDZ6.8B 6171 4822 130 42488 BYD33D 6201 4822 130 11397 BAS316 6202 4822 130 11397 BAS316 6206 4822 130 11416 PDZ6.8B 6207 9322 179 26673 ZTE2 6331 4822 130 30842 BAV21 6333 4822 130 30842 BAV21 6335 4822 130 30842 BAV21 6360 4822 130 30621 1N4148 6361 4822 130 11397 BAS316 6362 4822 130 11397 BAS316 6364 4822 130 11397 BAS316 6365 4822 130 11397 BAS316 6400 4822 050 21002 1K 1% 0,6W 6401 4822 130 34383 BZX79-B47 6401 4822 130 30864 BZX79-B68 6445 4822 130 11551 UDZS10B 6447 4822 130 30621 1N4148 6448 4822 130 34167 BZX79-B6V2 6449 5322 130 34337 BAV99 6452 4822 130 11397 BAS316 6453 3198 020 55680 BZX384-C5V6 6460 9340 559 50112 BY228/24 6460 4822 130 80298 DG3-7005L 6461 4822 130 80572 RGP30J 6462 4822 130 34197 BZX79-B12 6463 9340 548 61115 PDZ12B 6465 4822 130 30842 BAV21 6466 4822 130 30842 BAV21 6468 4822 130 11397 BAS316 6469 4822 130 42606 BYD33J 6470 5322 130 34337 BAV99 6476 4822 130 34281 BZX79-B15 6481 4822 130 34173 BZX79-B5V6 6482 4822 130 30862 BZX79-B9V1 6483 4822 130 34142 BZX79-B33 6485 4822 130 42606 BYD33J 6486 9322 164 42682 EGP20DL-5100 6487 4822 130 42488 BYD33D

Spare Parts List

EN 5L01H.1E AA 02.01

6488 9322 164 42682 EGP20DL-5100 6490 4822 130 42606 BYD33J 6500 9322 132 55667 Bridge coil GBU4JL-7002 6520 4822 130 42488 BYD33D 6522 4822 130 11152 UDZ18B 6523 4822 130 30621 1N4148 6524 4822 130 31083 BYW55 6525 4822 130 31083 BYW55 6526 9340 548 67115 PDZ22B 6540 4822 130 34167 BZX79-B6V2 6541 4822 130 11551 UDZS10B 6560 3139 120 52021 BYV29X-500 6561 4822 130 32715 SB340 6563 4822 130 11397 BAS316 6565 5322 130 34331 BAV70 6566 4822 130 30621 1N4148 6567 4822 130 11148 UDZ4.7B 6567 4822 130 10837 UDZS8.2B 6569 4822 130 11397 BAS316 6570 9322 163 91685 BZX384-C6V2 6570 4822 130 10837 UDZS8.2B 6580 4822 130 11397 BAS316 6582 9322 175 70667 STPS10L60D 6691 9322 050 99682 LTL-10224WHCR 6692 9322 127 54667 TSOP1836UH1 6801 9340 548 52115 PDZ5.1B 6805 4822 130 10838 UDZ3.3B 6806 4822 130 10837 UDZS8.2B 6808 9322 179 26673 ZTE2 6831 4822 130 30621 1N4148 6901 4822 051 20008 Jumper



7000 9352 628 51112 TDA8941P/N1 7001 4822 130 63732 MMUN2212 7101 5322 130 60159 BC846B 7131 5322 130 60159 BC846B 7200 9352 707 67557 TDA9565H/N1/5/0648 7200 9352 712 22557 TDA9565H/N1/5/0739 7201 5322 130 60159 BC846B 7204 4822 130 60373 BC856B 7206 5322 130 42755 BC847C 7209 5322 130 42718 BFS20 7210 5322 130 42718 BFS20 7330 9352 561 40112 TDA6108 7331 5322 130 60159 BC846B 7332 5322 130 60159 BC846B 7333 5322 130 60159 BC846B 7360 4822 130 40959 BC547B 7362 9322 166 55682 2SA1358 7363 4822 130 40959 BC547B 7365 9322 166 56682 2SC3421 7366 4822 130 41646 BF423 7367 4822 130 44568 BC557B 7400 9322 157 37687 STP3NC60FP 7441 4822 130 60373 BC856B 7443 4822 130 44568 BC557B 7444 4822 130 40959 BC547B 7450 3198 010 44010 PDTA114ET 7460 9340 550 92127 BU4508DX 7461 4822 130 40981 BC337-25 7462 9340 547 00215 PDTC143ZT 7463 4822 130 41246 BC327-25 7471 9352 701 64112 TDA8359J/N2 7480 4822 130 40823 BD139 7482 4822 130 40823 BD139 7515 9322 175 72667 TCET1104(G) 7520 9352 673 56112 TEA1507P/N1 7521 9322 160 63687 STP7NC80ZFP 7522 5322 130 60159 BC846B 7540 4822 130 40959 BC547B 7541 4822 130 11155 PDTC114ET 7542 4822 130 60373 BC856B 7560 4822 209 16978 LF33CV 7561 9340 547 00215 PDTC143ZT 7580 4822 130 60373 BC856B 7602 9322 147 25682 M24C16-WBN6 7606 9340 547 00215 PDTC143ZT 7801 5322 209 11102 HEF4052BT 7802 5322 209 14481 HEF4053BT 7803 5322 130 60159 BC846B 7803 4822 130 61129 BCV27 7804 5322 130 60159 BC846B 7804 4822 130 61129 BCV27 7805 5322 130 60159 BC846B 7806 5322 130 60159 BC846B 7807 5322 130 60159 BC846B 7831 9322 182 56682 MSP3411G-PO-B11 7831 9322 183 57682 MSP3415G-PO-B11 7834 5322 130 60159 BC846B 7835 5322 130 60159 BC846B 7901 9322 158 65667 AN7522N

7901 9322 166 29682 AN7580 7903 5322 130 60159 BC846B 9611 4822 157 52392 27µH

Side AV Panel [C + E1]

Various

0232 4822 267 31014 Headphone socket 0250 4822 265 11606 3p 0251 4822 267 10735 3p 0251 2422 025 15849 6p male 0253 2422 025 16382 3p male 0254 4822 267 10734 5p 0255 4822 267 10565 4p



2171 5322 122 32311 470pF 10% 100V 2172 5322 122 32311 470pF 10% 100V 2173 5322 122 32311 470pF 10% 100V 2174 5322 122 32311 470pF 10% 100V 2176 5322 122 32311 470pF 10% 100V 2177 4822 124 40248 10µF 20% 63V 2178 5322 122 32311 470pF 10% 100V 2179 4822 124 40248 10µF 20% 63V



3150 4822 116 83884 47kΩ 5% 0.5W 3151 4822 116 83868 150Ω 5% 0.5W 3152 4822 116 83884 47kΩ 5% 0.5W 3153 4822 116 83868 150Ω 5% 0.5W 3155 4822 116 52201 75Ω 5% 0.5W 3156 4822 116 52206 120Ω 5% 0.5W 3156 4822 116 83876 270Ω 5% 0.5W 3157 4822 116 52206 120Ω 5% 0.5W 3157 4822 116 83876 270Ω 5% 0.5W



6161 4822 130 34278 BZX79-B6V8

Front Interface [Q1]

Various

0157 3104 311 02471 Cable 5p 680m 0177 3104 311 03011 Cable 2p 340mm 0211 2422 025 16268 2p male 0212 2422 025 16268 2p male 0214 2422 025 06353 5p male 0231 2422 128 02972 Power switch



2691 4822 124 40248 10µF 20% 63V 2692 4822 126 13751 47nF 10% 63V 2693 4822 126 13751 47nF 10% 63V 2694 4822 126 13751 47nF 10% 63V 2695 4822 126 13751 47nF 10% 63V 2698 5322 121 42386 100nF 5% 63V



3500 4822 053 21335 3.3M Ω 5% 0.5W 3501 4822 053 21335 3.3M Ω 5% 0.5W 3691 4822 116 52219 330Ω 5% 0.5W 3693 4822 116 83872 220Ω 5% 0.5W



6691 9322 050 99682 LTL-10224WHCR 6692 9322 127 54667 TSOP1836UH1

Top control [T, T1]

Various

0158 3139 131 01771 Cable 3p 1000mm 0158 3139 131 01711 Cable 3p 1340mm 0215 4822 267 10748 3p 0215 2422 025 16601 3p male 1091 4822 276 13775 Switch 1092 4822 276 13775 Switch 1093 4822 276 13775 Switch

1094 4822 276 13775 Switch



3091 4822 051 20561 560Ω 5% 0.1W 3092 4822 051 20391 390Ω 5% 0.1W 3093 4822 051 20561 560Ω 5% 0.1W 3094 4822 051 20391 390Ω 5% 0.1W 3095 4822 051 20332 3.3kΩ 5% 0.1W 3096 4822 117 11139 1.5kΩ 1% 0.1W



6091 4822 130 11528 1PS76SB10 6091 4822 130 31983 BAT85

EN 6 L01H.1E AA 02.01

Personal Notes:

Schematics and PWB’s

Mono Carrier: Power supply

Schematics and PWB’s

7L01H.1E AA 02.01

A

B

C

D

E

F

G

1234567891011

POWER SUPPLY

0212

1

2

DEGAUSSING COIL

MAINS

150 - 276 V SINGLE RANGE

90 - 276 V FULL RANGE

2

1

0211

OR

TO 0283

OF

OR

P3

9500

0231

SDW

56

24

13

MAINS SWITCH

3500

3501

3528

*

22u

2521

6520

3521

9501

3M3

2526

2528

BYD33D

*

0211 C1 0212 A1 0213 B5 0231 C1

VlotAux+13V

2581

For AV Video

1515 G5PA

9505 3504

+t

ZPB

9504

3510

B57237

1500

*

T4E.250V

9502

for ITV only

2500

9508

*

14

5501

*

470n

23

DMF-2405

9509

*

3508

*

7520

TEA1507

16V8

(13V8)

1

Vcc

0V

2

Gnd

*

6522

1n

1V3

2520

3

100n

Ctrl

3520

CONTROL

DETECTOR

1K2

INPUT

CIRCUIT

BURST

MANAGEMENT

FREQUENCY

CONTROL

SUPPLY

VOLTAGE

CONTRLLED

OSCILLATOR

OVER

TEMPERATURE

PROTECTIOM

POWER-ON

RESET

9506

*

2

5500

3

*

14

DMF-2820

9507

*

3507

*

DSP

LOGIC

CONTROL

CIRCUIT

MAXIMUM

ON-TIME

PROTECTION

3506

VALLEY

*

1M5

2509

47K

3529

START-UP

CURRENT SOURCE

START-UP

CURRENT SOURCE

CURRENT SENSING

OUTPUT DRIVER

OVER

POWER

PROTECTION

FOR MAINS 120V AC 170V (177V)

"$"

*

5502

t

0213

USA

ONLY

FOR ITV ONLY

3531

6523

1N4148

Drain

HVS

Demag

Sense

Driver

45

2506

*

7522

BC847B

0V

4K7

"$"

8

7

4

5

6

-V NORMAL OPERATION

(-V) STANDBY OPERATION

1

2

3

6

7

8

9503

*

3509

*

2

V

1

3503

2V8

0V

2V

*

3522

220V AC 309V (317V)

*

P2

3523

2525

3511

*

470p

3532

2K2

3525

1K

V

*

3V

10K

3530

2502

2501

6526

4

2n2

G

2

2n2

6500

*

3

7521

*

D

S

"$"

BZX284-C22

2522

100n

3524

56K

1

0V4

3519

270R

2503

2523

3526

*

P1

"$"

RES

2505

2504

2508

5521

1n5

6524

Jumper

2n2

*

3527

2527

TCET1104G

P1 = "$" P2

2V / div DC

5us / div

P3 = 16V8 (13V8)

P4 = 3V3

P5 = 12V

P6 = 140V

2n2

470p

2507

6525

EAR

470p

7515

14

23

2515

1n5

2516

*

5520

*

2

3

4

5

8

9

1N5062

17V 3

4 1V7

(12V)

6570

10V

(7V7)

1

2 9V

(6V7)

*

3569

18

17

16

15

14

13

12

11

10

PDTC114ET

12V4

MainSupplyGnd

5562

7541

5K6

7542 BC857B

1V8

3566

2K2

2568

1u

0V

5560

3541

470R

9V

0V

7580

BC857B

11V8

3561

220R

2541

1n

3552

10K

BAS216

6580

6582

STPS10L60D

2562

1n

6561

SB340

6562

EGP20DL

6563

BAS316

6560

BYV29X-500

6568

BYW76

6541

PDZ-10B

0V

6569

3580

BAS316

2580

2560

680p

3542

6V8

6540

22u

3565

330R

47K

47u

2m2

2564

3567

2K2

BC857B

3562

12K

5564

3594

470R

3548

1K5

15K

8V8

7540

BC547B

BZX79-B6V2

2561

6V8

3558

330R

3557

3590

150R

9510

2590

2u2

3560

11V8

7562

1K

2563

100n 6567

2540

3545

9511 3564

0R1

47R

2566

470u

-3V2

*

100u

10n

39K

4500

3543

3544

7560

LE33CZ

1

12V

IN

GND

2

12V

11V5

3570

-3V2

PDTC143ZT

3596

3595

220K

1540

82K

4K7

6566

1N4148

0V

3568

3563

8K2

7561

220K

3

3V3

OUT

7564 BC857B

*

15K

5561

27u

RES

3550

2567

3V2

0V

For ITV only

2569

RES

+3.9V

47u

P5

12V

6564

BAS216

0251

1

2

3

4

0282

6565

BAV70

+3.3V

P4

MainAux

TO

AudioSupplyGnd

EW_protection

+3.3V

POWER_DOWN

P6

140V MainSupply

FOR ITV ONLY

TO 0251

Vcontrol

TO 0283

OF

TO

MainSupplyGnd

Stdby_con

OF

A7-11 A2-11

A7-5

A

B

OF

C

D

E

F

OF

G

HOT GROUND

COLD GROUND

CL 26532063_001.eps

140602

0251 E11 0282 F11 1500 B2 1515 A8 1540 E10 2500 C3 2501 C6 2502 B6 2503 C7 2504 C7 2505 C7 2506 B5 2507 D7 2508 C7 2509 C4 2515 B8 2516 B8 2520 F2 2521 E1 2522 D6 2523 D7 2525 E5 2526 D2 2527 E7 2528 E2 2540 E9 2541 F9 2560 D9 2561 D9 2562 B9 2563 D10 2564 C9 2566 C10 2567 B10 2568 G8 2569 G10 2580 B9 2581 A9 2590 B9 3500 C2 3501 D2 3503 B5 3504 A3 3506 C4 3507 C4 3508 C3 3509 B5 3510 B5 3511 B6 3519 E7 3520 F2 3521 F2 3522 E5 3523 E5 3524 E6 3525 D6 3526 E7 3527 E7 3528 D2 3529 D4 3530 D6 3531 D5 3532 C6 3541 E8 3542 E9 3543 E10 3544 F10 3545 F9 3548 E9 3550 F10 3552 F9 3557 A9 3558 A9 3560 C9 3561 C8 3562 D9 3563 D10 3564 B10 3565 A9 3566 G8 3567 C9 3568 C10 3569 F8 3570 C10 3580 A9 3590 A9

3594 E9 3595 E10 3596 E10 4500 C10 5500 C4 5501 C3 5502 A5 5520 C7 5521 D7 5560 D8 5561 E10 5562 C8 5564 D9 6500 B6 6520 E2 6522 D2 6523 D5 6524 D7 6525 E7 6526 D6 6540 F9 6541 E9 6560 D9 6561 B9 6562 C9 6563 D9 6564 C11 6565 A11 6566 F10 6567 D10 6568 E9 6569 G9 6570 G8 6580 A9 6582 B9 7515 E7 7520 D3 7521 C6 7522 C5 7540 F9 7541 F8 7542 F8 7560 A10 7561 D10 7562 C9 7564 C10 7580 A8 9500 B2 9501 C2 9502 C2 9503 B5 9504 B5 9505 A3 9506 B4 9507 C4 9508 B3 9509 C3 9510 B9 9511 B10

12345678

91011

Schematics and PWB’s

Mono Carrier: Power supply Diversity Tables

8L01H.1E AA 02.01

1

DIVERSITY TABLE FOR

REGION NA

MAINS RANGE

A

B

C

D

AUDIO OUTPUT

SET 21RF21RB

2503 2505 1KV 2N2 2506 2509 2515 2516 2520 2526 2561 3503 3504 3509 3510 3511

3522 3523 3526 3627 3528 3545 3552 3557 3561 3562 3563 3565 3594 3595 3596 4500 4608 4609 5500 5501 5502 5520 6500 6522 6524 6526 6541 6560 6566 6567 6568 6570 6582 7521

25V-36V

200V 470U

1KV 2N2

250V 1N5

16V 100N

160V 100U

PTC 120V 3R

NTC B57237

RST FUSE 100R

SMD JUMPER

FL MAINS 5MH

SS39009-04

GBU4JL-7002 GBU4JL-7002

BZX394-C22 BZX384-C22 BZX384-C10

BYV29X-500(PHSE) -

BZX384-C6V8 BZX384-C6V8

STP8NC50FP 2SK2750

234

POWER SUPPLY

LR

2X5W

220V 220U

-

4R7

330K

0R1

0R33

270K

4K7

1K

12K

5K6 330R 330R 220K 220K

-

--

- BZX394-C20

1N5062

1N4148

--

-

--

1KV 2N2

-

250V 1N5

-

50V 10N 16V 470N 160V 47U

-

PTC 120V 3R

-

4R73521

330K

RST FUSE 100R

OR15

-

10R

270K

10K

1K

100R100R

12K

8K2 330R 220R 220K 220K

-

FIL MAINS 22MH

SS35107-01

1N5062

BZX384-C9V1 BZX384-C9V1

1N4148

BYW76-RAS 15/10

RST FUSE 47R

FIL MAINS 10MH

BZX384-C4V7

BYW76-RAS 15/10

BZX384-C6V2

STP6NC80ZFP

LA FR

2X5W

400V 220U

-

250V 1N5

-

50V 10N 16V 470N 160V 47U

-

PTC 220V 9R

-

NTC B57237

-

4R7

330K

0R15

-

10R

270K

10K

1K

100R

12K

8K2 330R 220R 220K 220K

-

SS35107-01

GBU4JL-7002

BZX384-C20

1N5062

BZX384-C22

-

1N4148

-

ITEM

2566 3560 3564 3567 3568 6561 6562 7562 7564

ITEM

2566 3560 3564 3567 3568 6561 6562 7562 7564

ITEM

3500 0239 9500 9501

ITEM

2581 2132

SNDAMP-

1x1W-MN-

GL

470uF/6V3

47R 0R1 3K3 8K2

---

DIO EGP20

BC857B BC857B

SNDAMP2x3W-LA

470uF/6V3

47R 0R1 1K8 8K2

---

DIO EGP20

BC857B BC857B

KEYBOARDIR+LED-GL

3M3 3M3

---

SINGLE SCART INDVD

---

SNDAMP2x1W-ST-

EU/AP

470uF/6V3

47R 0R1

1K8

8K2

DIO SBE340

--BC857B BC857B

SNDAMP2x1W-NA

470uF/6V3

47R 0R1 3K3 8K2

---

DIO EGP20

BC857B BC857B

R+LEDEU/LA/AP

3M3 3M3

---

DUAL SCART IN

22uF 390pF

SNDAMP-

1x3WNA/LA

470uF/6V3

47R 0R1 3K3 8K2

---

DIO EGP20

BC857B BC857B

SNDAMP2x3W-ST-

NA

470uF/6V3

47R 0R1 1K8 8K2

---

DIO EGP20

BC857B BC857B

TC.PNL+FI. PNL-INTERF

EU/NA/AP

---

--YES YES

5

SNDAMP-

2x10W-ST-

AP/EU

---

SNDAMP-

2x5W-ST-

AP

470uF/6V3

47R 0R1 1K8 8K2

DIO SBE340

--BC857B BC857B

L2K2.FRNT.

55K-NA

3M3 3M3 YES YES

SNDAMP-

2x3W-ST-

NA

470uF/6V3

47R 0R1

1K8

8K2

---

DIO EGP20

BC857B BC857B

SNDAMP-

2x3W-ST-

NDBX-NA/LA

470uF/6V3

47R 0R1 1K8 8K2

---

DIO EGP20

BC857B BC857B

L2K2.FRNT. L2K2.FRNT.

55K-LA

3M3 3M3

---

SNDAMP-

2x5W-ST-

EU/AP

470uF/6V3

47R 0R1 1K8 8K2

DIO SBE340

---

BC857B BC857B

SNDAMP-2x5WST+WOOFER-

IND

---

DIO SBE340

---

NON-55K-

NA

3M3 3M3 YES YES

67

SNDAMP-

2x5W-ST-

IND-MKII

---

DIO SBE340

---

DIO EGP20

L2K2.FRNT

NON-55K-LA

3M3 3M3

SNDAMP2x5W-ST-

470uF/6V3

DIO SDE340

BC857B BC857B

SNDAMP1x4W-MN-

AP

---

0R1

---

IR+LED.55K

---

LA

47R

0R1 1K8 8K2

---

SNDAMP2x5W-VD-

ST-EU

DIO SB340

NA

3M3 3M3 YES YES

SNDAMP2x1W-NA

470uF/6V3

47R

0R1 3K3 8K2

DIO EGP20

BC857B BC857B

---

0R1

---

SNDAMP2x10W-VD-

ST-EU

SNDAMP-

2x5W-LA

470uF/6V3

47R

0R1 1K8 8K2

DIO SBE340

--BC857B BC857B

---

CL 26532063_002.eps

210502

A

B

C

D

1234567

Mono Carrier: Line Deflection

Schematics and PWB’s

9L01H.1E AA 02.01

A

B

C

D

E

F

G

1234567891011

LINE DEFLECTION

EHTinfo

A2-16

VideoSupply

VlotAux+13V

MainSupplyGnd

Filament

A2-69

Bass_panorama

A7-7

VlotAux+13V

L1

Hdrive

A6-21

EWdrive|EWD_dyn

A2-22

6467

BAS216

6468

BAS216

2460

*

2461

*

6463

UDZS-10B

1V5

7462 PDTC143ZT

9420

5450

1K

3492

5V2

2452

4430

3499

0V

*

7461 BC337-25

5V2

6462

3468

1

2

3

4

5

180p

3491

*

5V2

7463 BC327-25

*

0220

0319

9423

11V6

TO 0244 OF CRT

PANEL

MainAux

22u

5453

*

3493

6490

BYD33M

2405

2455

5V5

47u

5V2

2415

*

0V

*

6400

*

9424

6402

*

9426

6403

ONLY FOR SETS WITH E/W CORRECTION

3489

*

6469

BYD33M

PANORAMA

L2

36

1

220u

5461

*

3400

*

3401

3402

*

3404

*

2420

2423

2422

2421

7460 BU4508DX

2402

*

3403

*

0V

MainSupply

*

0V

+13V

2400

*

G

7400

*

3463

33R

137V

0V

D

S

6452

7444

*

13V3

0V

100MHZ

126V

0V

2463

L4

*

3405

VlotAux+13V

1400

G5PA

*

5452

6460

*

6461

3406

14

23

*

2465

*

2462

RGP30J

*

5401

5400

CU15

*

3411

*

2401

*

3407

2450

2466

6401

3410

10K

0322

*

2454

2467

47u

L3

*

3408

2404

*

9453

*

3487

*

2453

2470

4R7

*

HORIZONTAL DEFLECTION COIL

*

2468

*

2493

*

2451

*

6466

6465

9461

*

0288

L1

1V / div DC

20us / div

BAV21

9462

*

9451

RES

5451

27u

0221

VH

2459

2490

2458

3459

*

2484

*

9463

TO DAF

CCT.

PANEL

3485

RES

3486

*

680p

5457

*

1K

3458

*

15K

*

2456

9460

*

2469

43

5465

5464 34

*

9464

2464

L2

1V / div DC

20us / div

1

4

*

3

1

L.LIN

*

2457

5463

CU15

CU20d

21

12

*

3430

*

3431

5445

CI-15

1410

For Picture Width Control

L4

5V / div DC

5ms / div

10

6

5

11

7

12

8

9

1402

1

2

3

EHT

TO PICTURE TUBE

FOCUS

VG2

2481

470p 6486

EGP20DL

6447

3451

L5 = +200V L6 = +50V L7 = +50V L8 = +13V L9 = +5V L10 = +8V L11 = +13V

1N4148

*

3445

L12

2V / div DC

20us / div

0289

6485

BYD33J

3481

*

6487

BYD33D

6489

BYD33D

6488

EGP20DL

2491

*

5480

*

VlotAux+5VA

15K

3446

2444

9422 3464

4R7

0321

6445

5K6

1u

TO 0290

2448

3490

8K2

L8

2480

VlotAux+13V

BZX284-C10

3452

*

OF

*

3494

4R7

3482

3488

4R7

2441

*

47u

7480

BD135

1u

3484

2487

2486

9V

3442

1K

3454

13V3

5V6

BAV99 6449

6483

3K9

47u

470u

BC857B

*

BC557B

3469

3K3

5V

BZX79-C33

1m

2488

BZX79

8V

8V9

3447

*

7441

5V

13V3

7450

PDTA114ET

2V

6V3

7443

0V5

0V

9V

6R8

3455

6481

C5V6

0R

3456

3453

6448

BZX79-B6V2

*

3465

RES

3483

4u7

2485

L7

5V

7482

BD135

5V7

3450

100R

3449

100R

3448

*

6482

BZX79-C9V1

3441

100R

3443

6453

BZX384-C6V8

VlotAux+13V

1K

1M

47n2443

2482

2492

3460

3K9

1.9V

*

3n3

2489

3457

0R

L5

L6

L9

470u

L10

L11

POWER_DOWN

EHTinfo

A2-16 A5-16 A6-16

Hflybk

A6-18

200V

VideoSupply

VT_Supply

VlotAux+50V

VlotAux+13V

+13V

VlotAux+5VA

+8VB

VlotAux+13V

Filament

A2-69

Vguard

A3-65

BLK-IN

A5-36

A1-11

EHTo

A6-23

Vcontrol

EW_protection

A7-9

CL 26532063_003.eps

130602

A

B

C

D

E

F

G

0220 A2 0221 B6 0288 F6 0289 A9 0319 B2 0321 D8 0322 G5 1400 B4 1402 E7 1410 F7 2400 F4 2401 F4 2402 F3 2404 G5 2405 D3 2415 E3 2420 B4 2421 B4 2422 B4 2423 B4 2441 F9 2443 F10 2444 G8 2448 A9 2450 A5 2451 A6 2452 B2 2453 B5 2454 B5 2455 D3 2456 D6 2457 D6 2458 C6 2459 B6 2460 D2 2461 E2 2462 E4 2463 D4 2464 E6 2465 D4 2466 E5 2467 E5 2468 E5 2469 D6 2470 E5 2480 D9 2481 D8 2482 A10 2484 D6 2485 B10 2486 D9 2487 D9 2488 D9 2489 D10 2490 C6 2491 E8 2492 B10 2493 E5 3400 E3 3401 F3 3402 F3 3403 G3 3404 G3 3405 G4 3406 G4 3407 G4 3408 G5 3410 G5 3411 F4 3430 E7 3431 F7 3441 E10 3442 F9 3443 F10 3445 F8 3446 F8 3447 E9 3448 E10 3449 D10 3450 D10 3451 F8 3452 F9 3453 F10 3454 G9 3455 D10 3456 F10 3457 F10 3458 C6 3459 D6 3460 C10 3463 D4

3464 D9 3465 A10 3468 E2 3469 B9 3481 C8 3482 C9 3483 B10 3484 C9 3485 A6 3486 A6 3487 A5 3488 C9 3489 C3 3490 B9 3491 D2 3492 D2 3493 C3 3494 B9 3499 D2 4430 C2 5400 E4 5401 E5 5445 B7 5450 B2 5451 A6 5452 D4 5453 C3 5457 B6 5461 D3 5463 E7 5464 E6 5465 E6 5480 E8 6400 F3 6401 F5 6402 F3 6403 F3 6445 F8 6447 E8 6448 G10 6449 B9 6452 B4 6453 F10 6460 D4 6461 E4 6462 E2 6463 E2 6465 D6 6466 C6 6467 C2 6468 C2 6469 C3 6481 D10 6482 E10 6483 C9 6485 B8 6486 D8 6487 C8 6488 D8 6489 D8 6490 D2 7400 G4 7441 E9 7443 G9 7444 C4 7450 F10 7460 D3 7461 D2 7462 F1 7463 E2 7480 E9 7482 D10 9420 B2 9422 D9 9423 D2 9424 F3 9426 F3 9451 A6 9453 A5 9460 D6 9461 E5 9462 E6 9463 E6 9464 E6

12345678

91011

Schematics and PWB’s

Mono Carrier: Line Deflection Diversity Tables

10L01H.1E AA 02.01

12345678

DIVERSITY TABLE FOR

REGION LATAM NAFTA

A

B

C

D

E

F

TUBE PHILIPS

EW/NON EW

TYPE OF TUBE

ITEM

2401

2404 2405 220U-16V 2451 2457 270N

2463 390P 680P 390P 2464 2465 9N1 9N1 2466 2467 15N 2468 2482 33N 3400 3401 3403 - 3404 - - 3405 3406 3408 3410 3411 3447 3448 3451 3452 3454 3456 3457 3468 3481 3482 3484 3486 3491 3492 3493 3499 4401 4402 4430 5401 5445 5451 5453 5457 5461 5463 5480 6400 6401 6453 6460 6462 6463 6467 6469 7400 7450 7606 9414 9424 9426 9451 9463 9646 9655 9656 9685 9921

NOEW

21RF

-2402

--

33N 33N 33N

-- -

-

180R 820R

10R 47K

15K SM JUMPER SM JUMPER SM JUMPER SM JUMPER SM JUMPER SM JUMPER

18K 18K 18K 12K 8K2

16 29 24

-

SM 10K SM 10K

SM 820R SM 1K

6R8

-

-- -

--

-- -

2519

-

22U

00425

SC10015-00 B

-

LAL04A 18U

-

BZX384-C5V6

BY228/24

-

BZX384-C9V1

-

PDTA114ET

-

YES

-

LINE DEFLECTION

SMGK

NO EW

21RF

--

-

220U-16V

270N

--2462

68N

--

-

180R 820R

10R 47K 15K

--

6R8

-

2519

-

22U

00425

SC10015-00 B

--

LAL04A 22U LAL04A 18U

-

BZX384-C5V6 BZX384-C5V6

BY228/24 BY228/24

-

BZX384-C8V2

--

-

--

PDTA114ET PDTA114ET

--

-

--

-

YES YES

--

-

--

SMGK

NO EW

21RF

-

220u-16v

-

270N

-

9N1

-

15N68N

33N

---

-

180R 820R

10R 5K1

2K

12K

24

SM 820R

6R8

-

2519

-

22U

00425

SC10015-00 B

-

BZX384-C9V1

-

SMGK

EW

27RF (PIP)

2U2

470P

47U

220U-25V

22N

360N

-

820P

2U2 12N

15N 15N

180N 330R 220K

82K

1K 4R7 4R7

100R

10K 4R7 56R

470R

3R9 5K1

2K

SM JUMPER SM JUMPER

100R

12K 10K

34 22R

SM 10K

SM 1K

6R8

SM JUMPER SM JUMPER

-

1000U

21421

22U 22U

53201

SC10015-00 B

CHOKE

LAL04A 33U

1K

BZX79-C47

BZX384-C6V8

BY228/24

BZX79-C9V1

BZX384-C10V

-

STP3NC60FP

PDTA114ET

PDTC143ZT

YES YES YES

-

YES YES YES YES YES YES

LATAM

REGION

TUBE

ITEM 5464

5480 6171 6401 6452 6460 6462 6463 6464 6467 6469 6490 7444 9423 9451 9460 9462 9463 9464 9635 9636 9921

PHCO

28WR 32WR

C946-01

LAL04 39U

BYD 33D

BZX79-C68

BAS 316 DG3-7005L BZX78-C12

---

--BYD 33J BYD 33J BC547B

---

--JUMPER

--JUMPER JUMPER JUMPER JUMPER

C946-01

LAL04 39U

BZX79-C68

BAS 316 DG3-7005L BZX78-C12

BYD 33J BYD 33J BC547B

JUMPER

---

21RF

---

LAL04 22U

---

BZX79-C47

---

BY228/24

---

BZX384-C12

---

JUMPER

---

JUMPER

---

JUMPER

---

JUMPER

LG.PH

29RF

---

SPT0508 18U

---

BZX79-C47

---

BY228/24

---

BZX384-C10

---

JUMPER

---

JUMPER

---

JUMPER

---

JUMPER

EU

24WR

C946-01

LAL04 18U

BYD 33D

BZX79-C68

BAS 316

BY228/24

BZX78-C12

---

--BYD 33D BYD 33D BC547B

---

--JUMPER

--JUMPER JUMPER JUMPER JUMPER

L2K2

29RF

---

LAL04 22U

---

BZX79-C47

--BY228/24 BZX79-C10

---

--BAS 316 BYD 33J

---

JUMPER

---

JUMPER

---

JUMPER

---

JUMPER

SMGK

29RF-2x10W

LAL04 33U

BZX79-C47

BY228/24

BZX384-C12

BYD 33J BYD 33J

JUMPER

---

21RF-2x10W

---

LAL04 27U

---

BZX79-C47

---

BY228/24

---

BZX384-C12

---

--BYD 33J BYD 33J

---

JUMPER JUMPER

---

JUMPER

---

AP AP/CH

SMGK LG.PH

21RF-2x5W

---

LAL04 27U

---

BZX79-C47

---

BY228/24

---

BZX384-C10

---

JUMPER JUMPER JUMPER

---

JUMPER

---

29RF

LAL04 18U

BZX79-C47

BY228/24

BZX384-C10

BAS 316

BYD 33J BYD 33J

JUMPER JUMPER

JUMPER

---

21RF-2x10W

BZX79-C47

BZX384-C12

---

LAL04 27U

---

BY228/24

---

--BYD 33J BYD 33J

---

JUMPER JUMPER

---

JUMPER

---

910

SMGKLG.PHLGPD

21RF-2x5W

---

LAL04 27U

---

BZX79-C47

---

BY228/24

---

BZX384-C8V2

---

--JUMPER JUMPER JUMPER

--JUMPER

---

IN

---

LAL04 27U

---

BZX79-C47

---

BY228/24

---

BZX384-C10

BAS 316

---

JUMPER JUMPER JUMPER

---

JUMPER

---

CH

LG.PH

29FL-2x10W29RF-2x5W

---

LAL04 27U

---

BZX79-C47

---

BY228/24

---

BZX384-C12

BAS 316

--BYD 33J BYD 33J

---

JUMPER JUMPER

---

JUMPER

---

A

B

C

D

E

F

CL 26532063_005.eps

210502

12

3456

7

8910

Schematics and PWB’s

Mono Carrier: Line Deflection Diversity Tables

11L01H.1E AA 02.01

12345

DIVERSITY TABLE FOR

A

LATAM L2K2

REGION

TUBE

B

C

D

E

F

ITEM

2174 2175 2209 2216 2243 2245 2247 2401 2405 2420 2421 2451 2454 2457 2458 2463 2464 2465 2466 2467 2468 2469 2482 2490 2493 3176 3206 3247 3250 3257 3258 3259 3400 3401 3403 3405 3406 3407 3408 3447 3465 3468 3481 3482 3486 3489 3491 3492 3499 3617 3619 3640 4402 4430 5180 5400 5401 5445 5451 5453 5457 5461 5463

28WR 32WR 21RF 29RF 24WR

12V 5A LKS1A-H101400

500V 470P 16V 470U 50V 10U

10V 2200U

50V 10N

25V 330N 10V 2200U 100V 2U2

25V 220U

16V 1U

50V 470P

50V 22N

250V 68N

250V 470N

---

2KV 680P

---

1K6V 12N

--1KV 9N1 1KV 9N1

250V 560N 250V 33N

100V 2U2

---

NFR25H 1R

120K 560K

1K

10M 100K 470K 330R

33K

100K

4R7 4R7 4R7

10K

180R

56K

180R

22K

390R

3W 22R

3K9 3K3

330R

--4K7 8K2

100R

SMD JUMPER

---

27U

BF40 C906-01

---

PSLOT 0V2076

22U

---

LNCOR DRUM

SRW0913DR-T02

---

12V 5A LKS1A-H10

---

--50V 10U 10V 2200U

50V 10N 25V 330N 10V 2200U 100V 2U2 25V 220U

16V 1U

50V 470P

50V 22N

250V 68N

250V 470N

---

2KV 680P

--1K6V 12N

---

1KV 9N1 1KV 9N1

250V 560N

250V 33N 100V 2U2

---

--120K 560K

1K 10M 100K 470K 330R

33K

100K

4R7 4R7 4R7

10K

180R

56K 180R

22K

390R

3W 22R

3K9

3K3

330R

--4K7 8K2

100R

SMD JUMPER

---

27U

BF40 C906-01

---

PSLOT 0V2076

22U

---

25UH

SRW0913DR-T02

---

LINE DEFLECTION

EU

LG.PHPHCO

---

50V 10U

16V 1000U

50V 10N

25V 330N 16V 2200U 50V 2U2 16V 220U

---

50V 15N

---

250V 330N

100V 2U2

2KV 470P 160V 2U2 1K6V 8N2 400V 15N

---

250V 33N

---

400V 15N

--220K 180K

8K2

1M 180K 4M7 330R

22K

68K

4R7 4R7

--100R 180R

22K 180R

27K 3K9

3W 33R

--10K 1K

---

SMD JUMPER

---

1000U

1342 0033C

33U

JUMPER LINCOR DRUM SRW0913DR-T01

C957-02

---

50V 4U7 16V 1000U

50V 10N

25V 220N 16V 1000U 50V 2U2

25V 220U

---

50V 22N

---

250V 330N

100V 2U2

2KV 680P 160V 2U2 1K6V 12N 400V 10N

---

400V 18N

---

250V 68N

---

--33K 680K

8K2 10M 270K 470K

330R

220K

82K 4R7 4R7

---

100R

180R

27K

---

15K

6K8

3W 22R

--10K 1K

---

SMD JUMPER

---

1000U

PSLOT 29"RF

22U

JUMPER

LINCOR DRUM

SRW0913DR-T06

CU15

12V 5A LKS1A-H10

---

50V 10U

10V 2200U

50V 10N 25V 220N 10V 2200U 100V 2U2 25V 220U

16V 1U 50V 470P 50V 22N

250V 68N

---

2KV 1N2

---

1K6V 12N

--1KV 9N1 1KV 9N1

250V 560N

250V 68N

100V 2U2

---

220K 680K

1K

10M

100K

470K

---

100K

10R 10R

---

10K

180R

27K

180R

10K 24K

3W 22R

3K9 3K3

330R

--4K7 8K2

100R

SMD JUMPER

---

8R40 C906-01

---

USLOT +S

22U

---

LINCOR DRUM SRW0913DR-T02

---

29RF

---

50V 10U

50V 1000U

50V 10N 25V 220N

16V 1000U

50V 2U2

25V 220U

---

50V 22N

--250V 330N 100V 2U2

2KV 680P 160V 2U2 1K6V 12N

400V 10N

---

400V 18N

---

250V 68N

---

150K

560K 8K2

10M 270K 470K 330R 220K

82K

4R7

--100R 180R

27K

100R

15K 5K6

3W 22R

---

--1K

10K

---

SMD JUMPER SMD JUMPER

---

1000U

USLOT 29"RF

22U

--LINCOR DRUM SRW0913DR-T02

CU15

SMGK

29RF-2x10W

---

50V 10U

16V 1000U

50V 10N 25V 220N 16V 1000U 50V 2U2

25V 220U

50V 22N

250V 330N 100V 2U2

2KV 680P 160V 2U2 1K6V 12N

400V 10N 400V 18N

250V 68N

150K

560K

8K2

10M 270K 470K 330R 220K

82K 4R7 4R7

100R

180R

27K

15K 5K6

3W 22R

SMD JUMPER

1000U

PSLOT 29"RF

LINCOR DRUM

SRW0913DR-T02

CU15

---

--10K 1K

---

22U

---

LGPD

21RF-2x10W

---

50V 22U

16V 1000U

50V 6N8 25V 330N

16V 1000U

50V 2U2 16V 220U

---

--250V 270N 100V 2U2

2KV 470P

160V 2U2

1K6V 8N2

---

400V 22N 400V 22N

---

250V 33N

---

--100K 270K

8K2

10M 390K 470K 330R

22K

100K

4R7 4R7

---

100R

56R 27K

---

15K 12K

---

--10K 1K

---

1000U

JF0501-2135

---

82UH

SC10009-03

C957-02

678

AP AP/CH

SMGKLG.PH

21RF-2x5W

---

50V 22U

16V 1000U

50V 6N8 25V 330N

16V 1000U

50V 2U2 16V 220U

---

--250V 270N 100V 2U2

2KV 470P

160V 2U2

1K6V 8N2

--400V 22N

400V 22N

---

250V 33N

---

--100K 270K

8K2

10M

390K

470K 330R

22K

100K

4R7

---

100R

56R

27K

---

15K 12K

---

--10K 1K

---

1000U

JF0501-2135

---

82UH

SC100015-00

C957-02

29RF

---

50V 4U7

16V 1000U

50V 2N2

25V 220N 16V 1000U 50V 2U2

25V 220U

---

250V 360N 100V 2U2

2KV 2N2 160V 2U2 1K6V 15N

--400V 22N 400V 15N

---

250V 120N

---

33K

680K

8K2

10M 100K 470K 330R

68K

100K

4R7 4R7

---

100R

56R 27K

---

15K

8K2

---

10K

1K

---

1000U

JF0501-2136

---

LNCOR DRUM

SC100015-00

CU15

21RF-2x10W

---

50V 10U

16V 1000U

50V 6N8 25V 220N

16V 1000U

50V 2U2 16V 220U

---

--250V 270N 100V 2U2

2KV 390P 160V 2U2 1K6V 9N1

--400V 22N 400V 22N

--250V 33N

---

82K 270K 8K2 10M 100K 470K 330R 33K 100K 4R7 4R7

--100R 180R

68K

---

22K 3K9

---

10K 1K

---

1000U

JF0501-2135

---

82UH

SC10009-03

C957-02

SMGK

21RF-2x5W

---

--50V 10U 16V 1000U

50V 6N8

25V 220N 16V 1000U 50V 2U2

16V 220U

---

250V 270N

100V 2U2

2KV 290P

160V 2U2

1K6V 9N1

--400V 22N 400V 22N

--250V 33N

---

82K

270K

8K2

10M 180K 470K 330R

22K

100K

4R7 4R7

100R

180R

68K

22K 3K9

10K 1K

---

1000U

JF0501-2135

---

LAL04 22U

82UH

SC100015-00

C957-02

IN

LG.PH

29RF-2x5W

---

50V 10U 10V 1000U 50V 2N2 25V 100N 16V 1000U 50V 2U2 25V 220U

---

--250V 330N 100V 2U2

2KV 2N2 160V 2U2 1K6V 15N

--400V 22N 400V 15N

--250V 120N

---

68K 680K 8K2 10M 180K 470K 330R

33K

100K

4R7

---

4R7

---

100R

56R 27K

---

15K

8K2

---

10K

1K

---

1000U

JF0601-2136

---

LAL04 22U

LINCOR DRUM

SC10013-00

CU15

9

29FL-2x10W

10V 2200U

50V 2N2

25V 100N 10V 2200U 50V 2U2

25V 220U

160V 2U2

1K6V 15N

400V 22N 400V 15N

250V 120N

LINCOR DRUM

SC10015-00

CH

LG.PH

---

50V 10U

---

250V 330N 100V 2U2 2KV 2N2

---

68K 680K

6K2

10M 180K 470K

330K

33K

100K

4R7 4R7

---

100R

56R

27K

--15K 8K2

---

10K

1K

---

1000U

JF0501-2136

---

A

B

C

D

E

F

123456

CL 26532063_007.eps

210502

789

Mono Carrier: Frame Deflection

Schematics and PWB’s

12L01H.1E AA 02.01

A

B

C

D

12345678910

FRAME DEFLECTION

Vdrive+

A6-19

Vdrive-

A6-20

0222 C8 2471 B5 2472 C6 2473 B7

MODEL

REGION

TUBE

SET

2472 63V 150N 3470 470K 3471 2R2 3472 3R3 3473 3480 1R5 4470 --5471 6U8

+13V

2471

100n

7471

TDA8359J

12K

3498

F1

1V

2n2

2K2

3474

2474

F2

1V

2K2

2n2

3475

2475

INPUT/FEEDBACK

VI+1

VI-2

R

1:1

25uA

0V

8 VOG

GUARD

R

13V

3 VP

A

B

GND

0V

5

48V

6 VFLB

VOA

VM 9

VOB 4

7

7V

6V

5472 3MUH3 9472 ---

VlotAux+50V

*

3470

4470

9472

6476

BZX79-C12

47n

2472

4R7

3480

3479

2K7

3471

5472

3495

22K

*

2473

100n

3496

3477

3478

*

3472

PHCO LG.PH

28WR

3R9

150R

2476

2n7

100K

5471

9471

3473

*

32WR 29RF

63V 150N

270K

3R9 3R3 3R9 1R5

---

6U8

3MUH3

---

5V

-0V3

100K

F3

F4

6470

BAV99

VlotAux+5VA

3497

EU

5V

1

2

L2K2

63V 150N

330K

3R3 3R3 3R3 1R5

---

3U3

6MUH8

---

0222

VERTICAL DEFLECTION COIL

24WR

63V 150N

470K

2R2 3R3 3R9 1R5

---

3U3

3MUH3

---

Vguard

COIL

AP

LG.PH

21RF

100V 10N

270K

3R9 4R7 6R8

---

SMD_JUMPER

6U8

3MUH3

JUMPER

A2-65

GL

SMGK(SF)

21RF

100V 10N

470K

3R9 3R9

---

SMD_JUMPER

6U8

6MUH8

JUMPER

CH/IN

LG.PH

29RF

63V 150N

470K

3R9 3R9

---

1R5

---

3U3

3MUH3

---

A

B

C

D

2474 C3 2475 D3 2476 C7 3470 B6 3471 D7 3472 D7 3473 D7 3474 C4 3475 D4 3477 C7 3478 D7 3479 D7 3480 D6 3495 C7 3496 C7 3497 C7 3498 B4 4470 B7 5471 C7 5472 B7 6470 B8 6476 C6 7471 B4 9471 C7 9472 C7

E

F

REGION NAFTA/LATAM

TUBE

TYPE OF TUBE

ITEM

2472 10N 3470 SM 270K SM270K 3471 3472 6R8 6R8 3473 3R9 6R8 3480 4470 5471 3U3 6U8 9472 YES

PHILIPS

21RF

6R8 3R9

SM JUMPER

NAFTA/LATAM NAFTA/LATAM

1234567

NAFTA/LATAM

LG PHILIPS SMGK

21RF 27V/29"

150N

-

1R5

-

PHILIPS

150N

SM 330K

3R3 3R3 3R3 1R5

-

3U3

-

27RF

150N

SM 470K

3R9 3R9 2R2 1R5

6U8

-

E

F1

F2

F3

F4

F

500mV / div DC

5ms / div

-

500mV / div DC

5ms / div

10V / div DC

5ms / div

5V / div DC

5ms / div

CL 26532063_004.eps

130602

8910

Mono Carrier: Tuner IF

Schematics and PWB’s

13L01H.1E AA 02.01

A

B

C

D

123456789

TUNER IF

(EUROPE)

FOR ITV ONLY

0285

TO 0282

OF

A7-13

A7-14

A5-24

FOR EMC ONLY

0283

SCL

SDA

FM

3000

100R

3001

100R

3010

*

1000

12

13

14

15

TUNER

MT

AS SCL SDA

345678

4.3V

I2

2001

22p

2002

3011

I1

22p

*

FM-ANT

+5V ADC

4.9V

FM-RADIO ANTENNA

0265

1

2010

1

AGC

2

+5V

9

34V5

VT

10

FM

11

IF

0265 A4 0283 B2 0285 B2 1000 A3 1002 D7 1003 E7 1004 F7 2001 C3 2002 C4 2003 D5 2004 B5 2005 A5 2006 B6 2007 B6 2008 C5 2009 C8 2010 A4 3000 C3 3001 C3 3002 C6 3003 B7 3004 C7 3005 C8 3006 D5 3007 D5 3008 D5 3009 D6 3010 D3 3011 D4 3012 A7 4001 D5 4002 E7 4003 E6 4004 E7 4005 D6 4006 D5 4007 B7 4011 F7 4012 F7 5001 A6 5002 C5 5003 F8 6001 A5 6002 B6 6003 C6 6004 D5 6005 D6 7001 E5 7002 E6 9001 D6

RES

4005

VlotAux+5V

6002

BAS216

6003

RES

3002

10K

RES

6005

5001

2006

5u6

3009

FOR ITV ONLY

2007

470u

RES

9001

3012

100n

33R

4007

3003

1K5

FOR ITV ONLY

3004

1

2

3005

100R

RES

1002 K3953M

A

B

RF_AGC

22n

2009

4

5

3

VIF_1

VIF_2

A5-25

A5-27

A5-26

C

D

VT_Supply

2

3

1n

I4

2004

I3

5002

4001

2003

*

2K2

3006

2005

47n

390n

RES

4006

3007

6004

10u

2008

6K8

ISS356

6001

+8V

3008

BZX79-C33

100u

2K2

E

F

Diversity Table

ITEM

Non-FM Radio

1000 3010 3011

UV1317

1003

RES

10

SWI

4002

4012

1

IN

2

ING

1004 K9656M

1

2

RES

GND

3

4003

SEL-IF-LL_M-TRAP

A7-3

FM Radio

Stereo Mono

---

UR1316R UR1316R

330R

---

JMP

330R

I1

2V / div DC

200us / div

I2

2V / div DC 200us / div

I3

500mV / div DC

10us / div

I4

20mV / div DC

10us / div

5V

0V

7001

PDTC124ET

0V

7002 RES

4004 RES

4011

1234567

4

O1

E

5

O2

8

4

1n8

5003

5

3

SIF_1

SIF_2

CL 26532063_008.eps

A5-28

A5-29

130602

F

89

Mono Carrier: Video IF + Sound IF

1234567891011

VIDEO IF + SOUND IF

A

B

C

D

E

F

G

A14-32

LFRONT-IN

A12-31

A14-30

SY_CVBS-IN

A10-37

CVBS1-IN

A14-38

A2-36

A14-35

A14-33

A14-34

A14-39

AudioSupplyGnd

A1-XX

MainAux_FB

A8-XX

AudioSupplyGnd_FB

A8-XX

A2-16

L1-IN

C-IN

BLK-IN

R_V-IN

G_Y-IN

B_U-IN

FBL-1

MainAux

EHTinfo

3638 3637

4213

4212

FOR ITV ONLY

0249

2221

22n

FOR ITV ONLY

0248

2202

100n

FOR ITV ONLY

RES

75R

V3

V1

V2

5204 100MHZ

9653

5205 100MHZ

9673

0276

2201 100n

2203

3235

100R

2213

22n

RES

4207

2214

22n

RES

4205

2215

22n

RES

4206

RES

100n

2233

3V7

1V5

3V3

3V8

28

29

45

44

42

40

0V

41

0V

43

RES

Schematics and PWB’s

(EUROPE)

1204

7200-C

TDA95XX

I/O SWITCHING

VIDEO

3219

FILTERS VIDEO IDENT

2210

470n

2K2

PAL/SECAM/NTSC DECODER

3224 3225

RES

2209

6201

BAS316

6206

V4

2205

220n

8

47

2V3

2V9

LUMA DELAY PEAKING

BASE-BAND DELAY LINE

3V3

4u7

BC857B

0V

BZX384-C6V8

1V2

7204

ITEM

5206

5272 5672

10

5V

Y U V

RES

6202

BAS316

3218

82K

SINGLE SCART IN DVD

JUMPER

SPT0508

---

3220

RES

220n

2219

OSD

OSD/TEXT INSERT

BLUE STRETCH

WHITE-P. ADJ.

RGB/YUV INSERT BLACK STRETCH WHITE STRETCH

53

2V5

+8V

33K

3206

2220 470n

3217

330K

DUAL SCART IN

DVD

F.BEAD

1000MHz80R

---

SPT0508

5051 52

0V

3223

3226

100R

470n

5672

2260

2V5 56

57

58

54

55

3V5 46

2V5

5V6

560R

27u

9672

ITEM

2234 2238 2239 2240 3233 3236 3237 3238 3239 3240 7209 7210

3201

100R

3202

100R

3203

100R

2204

100n

V9

3204

10K

5206

100MHz

9206

RES

+8VB

FM RADIO

V5

V6

V7

VlotAux+5V

100uF

1nF 1nF

1nF 820R 150K 1K2 560R 270R

100K BFS20 BFS20

A4-24

FM

V5

14L01H.1E AA 02.01

NON-FM RADIO

---

0243

1

2

3

4

5

6

0297

V8

2206

6207

2238

1n

1V / div DC

10us / div

TO 0245

CRT

PANEL

SGP

ZTE2

(EUROPE)

2234

OF

TO 0296

(EUROPE)

3213

3212

TO 0295

OF

100n

OF

560R470R

3240

1V4

2239

V6

1V / div DC

10us / div

0294

220K

1n

9200

*

I1O

3233

2V9

7209 BFS20

0V7

3238

5201

2u7

G

1I3

G

2K2

1K

+8V

3228

RES

2

O

2

2240

1n

2236

1n

390K

2V6

7206 BC847B

2225

22n

3229

1K

3

1200

04B

1201 RES

3236

V7

1V / div DC

10us / div

0V8

100K

3231

4V

2V

3230

680R

270R

4204

RES 2211

470n

2207

820P

3209

100R

3237

3239

4210

*

4211

*

for M’nas only

2K2

5V

7210 BFS20

0V

330K

V8

4203

3n3

2226

+8V

JMP

3270

8V1

2V5

3208

220R

2222

22n

MainSupplyGnd

1n

2237

2V / div DC

5ms / div

3200

390R

2208

7201

BC847B

3V1

1203

100n

V10

1K

3207

3

I1O

G

2

4219

V9

500mV / div DC

10us / div

7200-A

TDA95XX

38

3V2

2V9

2V6

3V5

49

33

48

3261

330R

SOUND

AMPL. + AVL

5V

2235

2223

VIDEO

AMPL

27

1n

10p

AudioSupplyGnd_FB

V10

200mV / div DC

20us / div

4218

9618

VIDEO

PLL DEMOD.

QSS MIXER AM DEMODULTOR

AUDIO SWITCH

4209

3214

100R

35

2V5

RES

*

4214

3234

5202

10u

9207 RES

VISION IF

AGC/AFC

QSS SOUND

IF

AGC

SOUND PLL

DEEMPHASIS

680R

1205

7V8

0243 B6 0248 C2 0249 B2 0266 E11 0276 C2 0294 E7 0297 C6 1200 E7

A

B

C

D

E

G

F

1201 E7 1203 F8 1204 B3 1205 A10 2201 D2 2202 C2 2203 D2 2204 D5 2205 B3 2206 D6 2207 D8 2208 B8 2209 F3 2210 G3 2211 D8 2213 E2 2214 E2 2215 F2 2216 B10 2217 B11 2219 B4 2220 F4 2221 B2 2222 F8 2223 F9 2225 C7 2226 C8 2227 D11 2228 D10 2229 C11 2230 C11 2233 E2 2234 F6 2235 E9 2236 F7 2237 G8 2238 F6 2239 G6 2240 F7 2260 F5 3200 B8 3201 B5 3202 C5 3203 C5 3204 E5 3206 F4 3207 C8 3208 E8 3209 E8 3212 E6 3213 D6 3214 A10 3217 G4 3218 G4 3219 G2 3220 B4 3223 E4 3224 F3 3225 F4 3226 E5 3228 A7 3229 C7 3230 B7 3231 A7 3232 C11 3233 F7 3234 E10 3235 E2 3236 F7 3237 F8 3238 G7 3239 G8 3240 F6 3261 F9 3270 D8 3637 C1 3638 D1 4203 B8 4204 C8 4205 F2 4206 F2

V_OUT

A14-40

V1-OUT

A14-41

+8VA

QSS_AM_DEM_OUT

A5-42 A9-42 A10-42

1m

22n

2217

2216

39

0V

25

18

19

22

23

24

36

32

26

1V9

1V5

1V9

2V5

0V

1V7

2228

820p

FOR ITV ONLY

VIF_1

VIF_2

RF_AGC

SIF_1

SIF_2

4u7

2229

2230

2K2

3232

4n7

2227

MONO|AM_MONO_SOUND

QSS_AM_DEM_OUT

4u7

A4-27

A4-26

A4-25

A4-28

A4-29

A8-43 A9-43

A5-42

0266

FMR

A7-44 A9-44

CL 26532063_009.eps

140602

4207 E2 4209 E9 4210 B8 4211 B8 4212 B2 4213 A2 4214 D10 4218 F9 4219 F9 5201 D7 5202 A10 5204 F2 5205 G2 5206 E5 5672 F5 6201 F3 6202 F4 6206 G3 6207 E6 7200-A B9 7200-C C3 7201 D8 7204 F4 7206 B7 7209 F7 7210 F8 9200 D7 9206 E5 9207 A10 9618 A10 9653 F2 9672 F5 9673 G2

123456789

1011

Mono Carrier: Synchronisation

123456789

SYNCHRONISATION

A

B

C

D

Schematics and PWB’s

(EUROPE)

A2-16 A6-16

SANDCASTLE

A7-17

Hflybk

A2-18

EHTinfo

3259

470K

2255

15p

3258

3242

100K

12K

2250

2254

*

2u2

2249

15L01H.1E AA 02.01

3257

S1

22n

7200-D TDA95XX

10M

VIDEO IDENT

H/V SYNC SEP.

H-OSC. + PLL

12

3V9

2243

H

V

10n

14

31

0V9

4V

H-DRIVE

2nd LOOP

H-SHIFT

V-DRIVE

+

GEOMETRY

20

21

3V8

3V9

11

2V9

34

2V1

3254

1M

TELETEXT/ODS

DISPLAY

EW

GEOMATRY

7V9

0295 D7 2241 E5 2242 E5 2243 B5 2244 E6 2245 E6 2246 D8 2247 B7 2248 B7 2249 B5 2250 B4 2252 C8

A

5241

2247

1000u

2248

RES

9241

22n

+8V

B

S2

**

*

5242

10u

3244

820R

2252

1n

3249

820R

2253

1n

3250

100R

2246

4u7

3251

9

30

1V2

17

1V3

16

1V2

15

0V

13

0295

S3

S4

S5

100R

TO 0294

OF

3256

1K

+3.3V

Hdrive

Vdrive+

Vdrive-

EWdrive|EWD_dyn

A2-21

A3-19

A3-20

A2-22

C

D

2253 C8 2254 B5 2255 B4 3241 D5 3242 B4 3244 C8 3245 E6 3246 E6 3247 E8 3248 D8 3249 C8 3250 D8 3251 C8 3254 B6 3256 B8 3257 B5 3258 B4 3259 B4 5241 A8 5242 C8 7200-D C5 9241 B8

E

123

2242

3241

22K

39K3245

1u

S1

2V / div DC

20us / div

2241

1n5

2244

100n

S2

500mV / div DC

20us / div

10K

3246

2245

S3

500mV / div DC

5ms / div

220n

S4

500mV / div DC

5ms / div

S5

1V / div DC

5ms / div

*

3248

33K

3247

560K

+8VA

EHTinfo

EHTo

A6-16

A2-23

CL 26532063_010.eps

130602

E

456789

Mono Carrier: Control

123456789

CONTROL

A

VlotAux+5VA

VlotAux+5V

B

C

D

E

F

G

STATUS2

A14-2

ITV_MSG

A14-75

SEL-IF-LL_M-TRAP

A4-3 A5-3

A12-4

Stdby_con

A1-5

SEL-MAIN-FRNT-RR

A10-12

Bass_panorama

A2-7

Volume|Mute

A8-15

Treble_Buzzer_Hosp-app

A8-6

A7-14

A7-13

SANDCASTLE

A6-17

(EUROPE)

FOR ITV ONLY

0279

FOR ITV ONLY

0250

FOR ITV ONLY

0287

LED

+3.3V

FOR ITV ONLY

+3.3V

SDA

SCL

+8V

9647

0318

4604

4618

5678

Schematics and PWB’s

TO

0240

OF

27u

9678

3635

100R

3636

100R

3605

4K7

FOR ITV ONLY

0261

*

3617

*

4K7

3618

10K

2604

RES

SDM

9641

9631

3615

*

10K

3614

*

4K7

FOR ITV ONLY

0217

1

2

3

4

5

6

TO

0217

OF

FOR ITV ONLY

0240

1

2

3

4

5

6

7

3601

RES

3612

8K2

3619

*

3609

1K

3623

4K7

ITEM

3609 1K 3638

ITEM

2604 10uF

POR

DATA-OUT

DATA-IN

CLOCK

GND

TREBLE-BUZZ

Bass_panorama

8K2

3610

*

SINGLE SCART IN-

DVD

SNDAMP-

2x10W-ST-

8K2

---

EU

FOR ITV ONLY

0273

C4

DUAL SCART IN

10K

75R

SNDAMP2x5W-ST-

EU/AP

--- ---

2616

7200-B

TDA95XX

C5

3V7

0V

3V2

3V3

5V

0V

71

72

3

5

6

70

78

79

73

74

75

76

77

47n

3V3

SCL

SDA

TRANSCEIVER

VST PWM-DAC

R

G

B

TELETEXT

BL

COR

0V

7

0V

SNDAMP-

2x5w-VD-ST

EU

61

66

3V2

IIC-BUS

I/O

PORTS

ROM/RAM

OSD

DISPLAY

4

16L01H.1E AA 02.01

2618

59

3V2

H

V

SNDAMP2x10W-VD-

ST-EU

10uF

2608

1u

2611

ENHANCED

TELETEXT

ACQUISITION

1/10 PAGES

MEMORY

5602

1u

5603

5604

1u

80C51

CPU

5u6

+3.3V

CVBS

SYNC

C1

1V / div DC

500us / div

0217 F2 0240 A3 0250 A1 0261 D2 0273 B4 0274 A8 0279 A1 0287 B2 0318 E2 1660 E7 2601 A6 2602 D8 2604 D2 2606 E8 2607 D7 2608 A5 2609 E7 2611 B5 2612 B8 2613 B8 2615 A6 2616 A4 2618 B5 2619 D8 3601 B3 3603 A8 3604 A8 3605 C2 3606 B7 3607 B7 3608 D8 3609 D3 3610 C3 3611 A8 3612 C3 3614 F2 3615 E2 3617 D2 3618 D2 3619 C3 3622 D7 3623 D3 3624 B7 3625 B7 3626 C7 3627 C9 3628 D7 3629 C8 3630 D8 3632 D9 3633 D9 3634 C7 3635 B2 3636 B2 4601 A7 4602 A7 4603 B7 4604 G2 4618 G2 5602 A6 5603 A6 5604 A6 5678 A2 7200-B B4 7602 A7 7606 E8 9631 E2 9641 E2 9647 B2 9678 A2

2601

2615

220n

1n

4601

RES

*

4602

RES

4603

RES

3606

3V3 3V3

0V 0V 0V

2K2

8

7 4 3 2

3607

#

7602

EEPROM

2K2

3624

100R

3V7

6

3V7

5

M24C08

1

100R3625

3611

100R

0V

3604

3603

100R

2612

100R

68p

FOR ITV ONLY

0274

2613

3629

1

68p

+3.3V

+3.9V

SDA

SCL

+3.3V

A4-14 A7-14 A8-14 A9-14

A4-13 A7-13 A8-13 A9-13

A

B

RES

STATUS1

A14-1

+3.3V

POWER_DOWN

A1-11

IR

A12-10

+3.9V

+3.3V

KEYBOARD_protn

A12-8 A9-8

EW_protection

A2-9

C

D

E

1660

3634

100R

3626

4K7

3622

100R

12MHZ

3628

10K

2607

33p

2609

33p

2619

2606

1u

1n

2602

3630

2K2

3V3

0V

3608

100R

100p

7606

*

PDTC143ZT

0V3

3627

3633

RES

3632

0R

4K7

1

0V

2

3V3

67

0V

68

69

3V2

80

3V3

C3

0V

60

0V

62

63

1V5

0V

64

65

0V

C1

C2

F

C2

1V / div DC

500us / div

C4

2V / div DC

200us / div

C5

2V / div DC

200us / div

CL 26532063_011.eps

060602

G

123456789

Mono Carrier: Audio Amplifier

12345678910

AUDIO_AMPLIFIER

A

MainAux_FB

VlotAux+5V

B

Main_OutL

A8-45 A9-45 A11-45

4905

C

D

E

MONO|AM_MONO_SOUND

A5-43

Main_OutR

A9-46 A11-46

A15-74

Treble_Buzzer_Hosp-app

A7-6

Volume|Mute

A7-15

ITEM 3172

Tilt

PIP Interface

68K

*

Schematics and PWB’s

4901

FOR ITV

0271

ONLY

1

2

3

4

4903

Tilt Rotation 29RF-CH/32WS-EU

3172

68K

9905

7903

*

BC847B

6K8

FOR ITV ONLY

3921

330K

3912

*

2K2

*

6903

VlotAux+5V

3911

4R7

9903

*

3908

2R2

9904 2911

*

4902

3903

*

2910

*

4904

3905

*

3922

330K

3923

330K

3904

3906

*

RES

4921

*

FOR ITV ONLY

0275

3901

*

2904

470n

2906

*

3907

17L01H.1E AA 02.01

0246 B10 0267 G2 0271 C2 0275 B4 0280 D10 0281 C10 2901 B7 2902 B7 2903 B5 2904 B4 2905 C5

A

AmpOutR+

A12-70

AmpOutL+

A12-71

AmpOutR_Pos

6901

2901

*

RES

2902

*

1n

10u

2903

3909

3910

1u

10K10K

7901

*

1V4

CH1-IN6

1V4

CH2-IN8

0V3

VOL9

GNDCH13GNDCH2

AudioSupplyGnd_FB

7902

*

AN7523N

6 CH1-IN

9 VOL

GNDINP NC

GNDINP 7

STB1VCC

7

4906

*

3902

2905

*

2907

*

2908

AudioSupplyGnd_FB

5

1

11V8

3V7

STB

VCC

11

AudioSupplyGnd_FB

5

GNDCH1

8

AudioSupplyGnd_FB

CH1+

CH2+

CH1+

3

CH1-

CH2-

CH1-

A1

2

5V2

A2

5V2

4

A3

5V2

10

A4

5V2

12

2

4

9901

*

9902

*

AmpOutL_Neg

AmpOutL_Pos

AmpOutR_Pos

AmpOutR_Neg

RES

2947

2948

AudioSupplyGnd_FB

2949

RES

2950

RES

5

4

3

2

1

4

3

2

1

4

3

2

1

0246

0281

0280

TO 0254

TO VOICE CONTROL

A12-72

AmpOutL_Pos

A12-73

B

OF

C

D

E

2906 C4 2907 D5 2908 E5 2910 C3 2911 B3 2947 C8 2948 C9 2949 C9 2950 C9 3172 D2 3901 B4 3902 B5 3903 B3 3904 C4 3905 C3 3906 D4 3907 E4 3908 B3 3909 C5 3910 D5 3911 A3 3912 E3 3921 D3 3922 D3 3923 D3 4901 B3 4902 B3 4903 C3 4904 C3 4905 C2 4906 E6 4921 B4 6901 B5 6903 A3 7901 B6 7902 D6 7903 E2 9901 C8 9902 C8 9903 A3 9904 B3 9905 D2

F

G

AudioSupplyGnd_FB

COMMON

*

3901 1K 3902 3912 7901-AN7522N 7903 9905

FOR COMPAIR ONLY

SDA

A7-14

SCL

A7-13

1

0267

1

2

3

A1

1V / div DC 500us / div

A2

1V / div DC 500us / div

2345678910

2BY10W

A3

1V / div DC 500us / div

6K8

AN7580

3K3 Yes No

Yes No Yes No

A4

1V / div DC 500us / div

CL 26532063_012.eps

130602

F

G

Schematics and PWB’s

Mono Carrier: Audio Amplifier Diversity Tables

18L01H.1E AA 02.01

1234

Diversity Table For

ITEM Mono Sets 2x10W-AP Others

Or 2x1W-NA

2902 220uF/50V

ITEM With Stereo W/O Stereo

4905 --- JUMPER

A

ITEM

2x10W Non 2x10W

1000uF/25V 1000uF/16V

Using 2K2Using 2K2

Chassis-Chassis-

JUMPER---9905

B

GL

470nF

1nF

---

330nF

1K 3K3 18K 8K2

---

8K2

---

--JMP JMP

---

SNDAMP2x1W-ST-

EU/AP 470nF

1nF

470nF

1nF 3n3 3n3

330pF

1K 3K3 3K3 10K 3K3 10K 6K8

---

AN7522

---

--JMP JMP JMP

---

C

D

ITEM

2904 2905 2906 2907 2910 2911 2950 3901 3902 3903 3904 3905 3906 3907 3909 3910 3912 6903 7901 7902 7903 9903 9914 9916 9923

SNDAMP-

1x1W-MN-

1N5062

AN7523

SNDAMP-

1x3WNA/LA

470nF

1nF

---

330pF

1K 3K3 18K 10K

---

8K2

---

AN7523

--JMP JMP JMP

---

Audio Amplifier

SNDAMP-

ITEM

2x10W-ST-

1000uF/25V

2902 2905 2907 2910 2911 2950 3901 3902 3903 3904 3905 3906 3907 3909 3910 3912 4905

AN7580

7901 7902

BC857B

7903 9905 9923

SNDAMP-

2x10W-ST-

AP

470nF

1nF

470nF

1nF 1nF 1nF

---

6K8

---

22K

---

22K

--8K2 27K 27K 2K2

---

AN7580

---

BC847B

JMP JMP JMP JMP

SNDAMP-

2x3W-ST-

NA

470nF

1nF

470nF

1nF 3n3 3n3

330pF

1K 3K3 3K3 10K 3K3 10K 8K2

---

AN7522

---

--JMP JMP JMP

---

EU

1nF 1nF 1nF 1nF

---

6K8

---

82K

---

8K2

---

--27K 27K 820R

---

--JMP

SNDAMP-

2x5W-ST-

EU/AP

470nF

1nF

470nF

1nF 3n3 3n3

330pF

1K 3K3 3K3 10K 3K3 10K 6K8

---

AN7522

---

--JMP JMP JMP

---

SNDAMP2x5W-ST-

EU/AP

1000uF/16V

1nF 1nF 3K3 3n3 330pF

1K 3K3 3K3 10K 3K3 10K 6K8

---

AN7522N

---

JMP

---

SNDAMP-

2x5W-ST-

IND-MKII

470nF

1nF

470nF

1nF 3n3 3n3

330pF

1K 3K3 3K3 10K 3K3 10K 6K8

---

AN7522 PH

---

--JMP JMP JMP

---

SNDAMP-

2x5w-VD-ST

EU

1000uF/16V

560pF 560pF

---

1K 3K3 12K 10K 12K 10K 6K8

---

AN7522N

---

JMP

---

SNDAMP2x5W-ST-

LA

470nF

1nF

470nF

1nF 3n3 3n3

330pF

1K 3K3 3K3 10K 3K3 10K 8K2

---

AN7522

---

--JMP JMP JMP

---

SNDAMP-

2x10W-VD-

ST-EU

1000uF/25V

560pF 560pF

---

6K8

---

82K

---

82K

---

--27K 27K

820R

---

AN7580

---

BC857B

---

JMP

SNDAMP-

2x1W-NA

470nF

1nF

470nF

1nF 3n3 3n3

330pF

1K 3K3 3K3 10K 3K3 10K 8K2

---

--1N5062 AN7522

---

JMP JMP

---

SNDAMP-

2x5W-LA

470nF

1nF

470nF

1nF 3n3 3n3

330pF

1K 3K3 3K3 10K 3K3 10K 8K2

---

AN7522

---

--JMP JMP JMP

---

Personal Notes:

A

B

C

D

E

F

ITEM

2904 2905 2906 2907 2910 2911 2950 3901 3902 3903 3904 3905 3906 3907 3909 3910 3912 6903 7901 7902 7903 9903 9914 9916 9923

SNDAMP-

2x3W-LA

470nF

1nF

470nF

1nF

3n3 3n3

330pF

1K 3K3 3K3 10K 3K3 10K 8K2

---

AN7522

---

--JMP JMP JMP

---

SNDAMP2x1W-NA

470nF

1nF

470nF

1nF 3n3 3n3

330pF

1K 3K3 3K3 10K 3K3 10K 8K2

---

--1N5062 AN7522

---

JMP JMP

---

SNDAMP2x3W-ST-

NA

470nF

1nF

470nF

1nF 3n3 3n3

330pF

1K 3K3 3K3 10K 3K3 10K 8K2

---

AN7522

---

--JMP JMP JMP

---

SNDAMP2x5W-ST-

AP

470nF

1nF

470nF

1nF

3n3 3n3

330pF

1K 3K3 3K3 10K 3K3 10K 6K8

---

AN7522

---

--JMP JMP JMP

---

SNDAMP-

2x3W-ST-

NDBX-NA/LA

27nF

1n2

27nF

1n2 10nF 10nF

330pF

1K 3K3 3K3 10K 3K3 10K 8K2

---

AN7522

---

--JMP JMP JMP

---

SNDAMP-2x5WST+WOOFER-

IND

47nF

1nF

47nF

1nF 10nF 10nF

330pF

1K 3K3 8K2 10K 8K2 10K 6K8

---

AN7522 PH

---

--JMP JMP JMP

---

SNDAMP-

1x4W-MN-

AP

470pF

1nF

---

330pF

1K 3K3 18K 10K

---

8K2

---

AN7523 PH

---

JMP

---

CL 26532063_013.eps

1234

E

F

210502

Schematics and PWB’s

Mono Carrier: NICAM + 2CS + BTSC (Stereo / SAP) Decoder

12345678910

NICAM + 2CS + BTSC (STEREO/SAP) DECODER

]

A

B

C

D

E

F

MONO|AM_MONO_SOUND

QSS_AM_DEM_OUT

A9-43

A10-47

A10-48

A5-42

A5-44

+5VA

VlotAux+5V

SC1_LIN

SC1_RIN

+5VA

FMR

A11

2855

27p

4834

3834

RES

5835

2857

12u

150p

3843

2859

*

RES

2860

3835

A11a

2856

56p

RES

15p

5831

2844

2847

RES

2896

RES

6u8

1N4148

10u

3840

3V

*

3841

2834

6831

3831

47K

2897

390p

2845

2848

*

7835

4835

*

4836

470p

100n

RES

2835

5V

2V5

3849

220p

5V

2V5

*

2836

2837

2833

2858

*

1n5

4u7

47p

*

0V

7834

2V6

1V5

3V8

43

47

48

44

41

42

39

40

A5

(EUROPE)

10u

2841

0V

6V2

DVSS

TESTEN

CAPL_M

VREFTOP

SOUND IF

ANA_IN1+

ANA_IN1-

MONO

MONO-IN

SC1-IN-L

SCART 1

SC1-IN-R

SC2-IN-L

SCART 2

SC2-IN-R

12

TO 1810

OF

(EUROPE)

DEMODULATOR

& NICAM

DECODER

18 19

3842

*

1617

0V

DVS UP

3V8

AGNDC

1812

19L01H.1E AA 02.01

2898

10n

2840

100n

45 46

0V

5V

0V

AVS S

AVS UP

AHVS S

FM1/AM FM2 NICAM A NICAM B

IDENT

21 22

2870

1u

SCART-L

SCART

3844

A/D

A/D SCART-R

29

3334 3536

0V

7V8

VREF1

AHVS UP

LOUDSPEAKER L

LOUDSPEAKER R

DSP

Switching Facilities

NC

27

3845

100R

28

23

0V

VREF2

SCART-L

SCART-R

100R

5V

2871

1u

20

RESETQ

32

5V

STANDBYQ

2843

10u

2842

100n 2895

560p 2894

220p

550 51 52678

0V

3V7

I2C_CL

I2C_DA

ADR_SEL

D/A

37 38

1813

(EUROPE)

2V4

AUDIO PLL

DACM-L

LOUDSPEAKER

DACM-R

SC1-OUT-R

49

TO 1811

OF

7831

MSP34X5G

2V4

TP

SC1-OUT-L

SCART

1

0239 F10 1812 F5 1813 F7 1831 B8 2831 C8 2832 C8 2833 C4 2834 A3 2835 A3 2836 A4 2837 B3

A

A6

3832

100R

A7

5832

2838

RES

3833

100R

2839

RES

6u8

1831

18M432 HC-49/U

2832

1p

2831

1p

RES

2887

A10

1V8

25

1V8

24

2

3

0V

4

0V

9

10

11

13

14

15

26

3V

31

3V

30

A8

A8a

2861

10n

3837

100R

2852

4861 3861

10K

1n

A9

3839

100R

2854

1n

TO

0215

OF

2849

1n

2850

1n

4832

RES

2851

4u7

2853

4u7

4u72862

0239

1

2

3

SCL

A7-13

SDA

A7-14

+8V

Main_OutL

A8-45

Main_OutR

A8-46

SC2_CTRL

A10-50

MONO|AM_MONO_SOUND

A5-43

SC1_LOUT

KEYBOARD_protn

A9-43

A10-51

SC1_ROUT

A10-49

A7-8

B

C

D

E

F

2838 A10 2839 B10 2840 B6 2841 B4 2842 A6 2843 A6 2844 C3 2845 C3 2846 G1 2847 D3 2848 D3 2849 C10 2850 C10 2851 D10 2852 E8 2853 E10 2854 E8 2855 E2 2856 E2 2857 F2 2858 E4 2859 F2 2860 F2 2861 D8 2862 D10 2870 F5 2871 F6 2887 C9 2894 A6 2895 A6 2896 F3 2897 C3 2898 A6 3831 B3 3832 A10 3833 B10 3834 D2 3835 D2 3837 D8 3839 E8 3840 E3 3841 F3 3842 F5 3843 F2 3844 F6 3845 F6 3849 F3 3861 D9 4832 D10 4834 F1 4835 F3 4836 F3 4861 D9 5831 A3 5832 B8 5833 G2 5835 E2 6831 B3 7831 C7 7834 E4 7835 E3

G

VlotAux+5V

2846

5833

6u8

100u

+5VA

ITEM

SNDSYSNI/GS/RD/

VD-EU

SNDSYS NI/GS/RD/

CL-EU

7831 MSP3411G MSP3415

ITEM

2581 2853

WITH MON.

OUT

JUMPER JUMPER

SNDSYS NI/GS/RL-

EU

WITHOUT MON. OUT

4u7 4u7

SNDSYS NI/GS/RD/ FM/AM-EU

MSP3415B8MSP3415

FM

ITEM

2862 3836 3837 3838

3839 3844 3845 3861 7832 7833

WITH MON.

OUT

--1K

100R

1K

100R

---

BC847B BC847B

1234

WITHOUT MON. OUT

4u7

---

--100R 100R

10K

---

A8

1V / div DC 500us / div

A8a

1V / div DC

500us / div

A9

500mV / div DC

500us / div

A10

500mV / div DC

500us / div

A11

1V / div DC

200us / div

A11a

500mV / div DC

2us / div

CL 26532063_014.eps

5678910

G

140602

Schematics and PWB’s

Mono Carrier: Audio / Video Source Switching

123456789

AUDIO/VIDEO SOURCE SWITCHING

6808

*

A

B

C

D

E

F

G

+8V

From Micronas

A9-50

A7-12

A12-31

A13-32 A14-32

A13-52 A14-52

A12-53

A13-54 A14-54

A13-55 A14-55

A9-51

A9-49

A14-56

A14-57

Mono Scart1 out

(RF Mode always)

QSS_AM_DEM_OUT

A5-42

SC2_CTRL

SEL-MAIN-FRNT-RR

From MicroP

From Front/Rear I/O

LFRONT-IN

RFRONT-IN

From Micronas

SC1_LOUT

SC1_ROUT

Stereo Scart1 Out (RF Mode always)

L1-OUT

R1-OUT

L1-IN

L2-IN

R1-IN

R2-IN

*

4806

3801

* *

4805

9801

2824

4809

*

2803

*

3802

*

4u7

+6V8

2V4

1V8

2V4

1V7

+6V8

16

5V8

VDD

7801

*

LL

0V

1

0V

5

LH

HL

2

4

HH

0V

12

LL

LH

0V

14

15

HL

HH

11

VSS

8

*

3V8

12

Y0

1V6

Y1

13

Vss

8

*

Y0

2

3V8

1V6

Y1

1

Vss

8

VEE

7802-A

Vee

7

7802-B

Vee

7

VlotAux+13V

9

8V

LOGIC

7

5V8

Vdd

E

6

Vdd

E

6

5V8

20L01H.1E AA 02.01

0296 B4 0298 C5 0299 C5 0300 C5

(EUROPE)

3805

3808

6805

3812

3813

1815 0301

0299

1K

Only Europe (Scart2 Out)

*

+8V2

L2-OUT

R2-OUT

3814

*

7805

*

2813

RESERVE

*

2814

A14-62

A14-63

7806

7807

*

1814

0300

0298

3815

+8V2

*

6806

2801

10

0V

LSBMSB

H

L

H

L

6

16

5V

S

11

1V6

Z

14

16

5V

S

10

1V6

Z

15

TO 0297

22u

OF

0296

(EUROPE)

RESERVE

+6V8

2V4

3

+6V8

2V4

13

+6V8

*

2802

3803

3804

3806

3807

2V5

*

2V3

*

7803

*

6V

*

1V8

*

7804

*

6V

1V8

2815

2804

2805

6801

6807

*

6802

*

6803

3811

*

2811

*

6804

*

2816

**

2817

TO 1812

OF

(EUROPE)

*

2818

*

1810

2819

*

To Micronas/BTSC/UOC

*

TO 1813

1811

OF

(EUROPE)

*

Only With CL Out

*

2821

2820

SC1_RIN

SC1_LIN

L-OUT

R-OUT

Monitor Out/AV Out

WITH MON.

ITEM

OUT

YES

0298

YES

0299

YES

1810

YES

1811 2823

SINGLE

ITEM

SCART INDVD

2824 4815 4820 4837 9835 ---

SC1-DVD

ITEM

*

2822

*

2823

A9-48

A9-47

A13-60 A14-60

3801 3802 3803 3804 3806 3807 6808

220K ZTE2

---

220R 82K

220K 82K

WITHOUT MON.OUT

---

---100uF/25V

DUAL SCART IN

4u7 JMP JMP JMP JMP

SC2-MON OUT-S/CNST-EU

--220R 120K 220K 120K

220K ZTE2

SC2-S/CN-

ST-EU

220R

1K

100K

82K 1K

82K

---

SC2-S/CN-

VD-ST-EU

--220R 82K 220K 220R

220K ZTE2

A

B

C

D

A13-61 A14-61

E

F

G

0301 C5 1810 C6 1811 E6 1814 C5 1815 C5 2801 B3 2802 F4 2803 D2 2804 D6 2805 E6 2811 A6 2813 B5 2814 B5 2815 B6 2816 B6 2817 B6 2818 B6 2819 B6 2820 B7 2821 B7 2822 B7 2823 C7 2824 B2 3801 A1 3802 A2 3803 C4 3804 D4 3805 D4 3806 D4 3807 E4 3808 E4 3809 H1 3810 H2 3811 A6 3812 B4 3813 B4 3814 A5 3815 A4 4805 E1 4806 F1 4807 H2 4808 H3 4809 C2 6801 A6 6802 A6 6803 B6 6804 B6 6805 A4 6806 A4 6807 A6 6808 A1 7801 C3 7802-A F3 7802-B G3 7802-C G3 7803 C4 7804 D4 7805 B5 7806 B5 7807 B5 9801 F1

H

CVBSFRONT-IN

A12-58

A13-59 A14-59

Vee

7

16

5V8

5V

Vdd

S

9

0V

Z

4

E

6

SY_CVBS-IN

A5-37

CL 26532063_015.eps

Y_CVBS-IN

3809

SET WITH

FRONT/SIDE AV

75R

3810

75R

RES

4807

0V

RES

4808

7802-C

*

Y0

5

Y1

3

Vss

8

123456789

H

210502

Schematics and PWB’s

Mono Carrier: Front I/O + Front Control + Headphone

12345678910

FRONT IO + FRONT CONTROL + HEADPHONE

FRONT CINCH

A

B

C

D

E

F

MONO SET

0277-A

0277-B

HEADPHONE

AmpOutL+

A8-71

AmpOutR+

A8-70

3182

0218-C

0218-B

0218-A

*

9982

2

1181

3

1

5

1182

6

4

8

1183

9

7

2981

10u

2983

10u

V

L

R

0R

RES

3181

3183

*

2185

3185

*

2186

3981

*

120R

AudioSupplyGnd_FB

3982

*

120R

2982

2984

2181

3184

3186

470p

21L01H.1E AA 02.01

0214 E9 0215 C4 0218-A C2

(EUROPE)

SET WITH SIDE/FRONT AV.

9181

22p

6181

BZX384-C6V8

2184

*

2182

*

2183

FOR ITV ONLY

0292

AudioSupplyGnd_FB

FOR ITV ONLY

*

0215

1

2

3

0219

6

5

4

3

2

1

0232

1 6

5

4

2

3

7

8

9

0270

FOR ITV ONLY

TO 0251 OF

OR

TO 0251 & 0253 OF

CVBSFRONT-IN

A10-58

LFRONT-IN

A5-31 A10-31

RFRONT-IN

A10-53

AmpOutL_Pos

A8-73

FRONT CONTROL

KEYBOARD_protn

A7-8 A12-8

A7-4

+3.3V

A7-10

KEYBOARD_protn

A12-8

LED

IR

2K7

3689

FOR ITV ONLY

0293

0286

9184

3685

*

3695

100R

4692

4693

TS USA

1606

POWER

*

2693

3683

*

4691

RES

*

2694

6691

3692

RES

3684

*

1603 channel+

LTL-10224WHCR

1K

RES

2692

C6

RES

2696

2695

1602 channel-

+3.3VA

3694

+3.3VA

TO 0214 OF

4K7

3681

*

FOR ITV ONLY

*

3

1

2

0214

*

1

2

3

4

5

1601 volume+

*

3686

3691

330R

4695

6692 TSOP1836

VS

OUT

GND

*

BAT85

3682

*

6681

75R

3687

68R

3688

1600 volume-

3693

220R

*

10u

2691

*

0259

1

2

3

TO 0259 OF

4

5

FOR ITV

&

VOICE CONTROL

4696

A

B

C

D

E

F

0218-B B2 0218-C B2 0219 C4 0232 E5 0259 E10 0270 A5 0277-A B1 0277-B B1 0286 F7 0292 E4 0293 E7 1181 A2 1182 B2 1183 C2 1600 C10 1601 A9 1602 A9 1603 A8 1606 B8 2181 A3 2182 B3 2183 C3 2184 B4 2185 B3 2186 C3 2691 D10 2692 D8 2693 F8 2694 F8 2695 F8 2696 F8 2981 E2 2982 F3 2983 F2 2984 F3 3181 A3 3182 A3 3183 B3 3184 B3 3185 B3 3186 C3 3681 A9 3682 A10 3683 A8 3684 A8 3685 A7 3686 B9 3687 B10 3688 B10 3689 A7 3691 C9 3692 D8 3693 D10 3694 D9 3695 C7 3981 E3 3982 F3 4691 E8 4692 D7 4693 D7 4694 G3 4695 C9 4696 B10 6181 A4 6681 B10 6691 D8 6692 D9 9181 A5 9184 A7 9982 F2

G

AudioSupplyGnd_FB

AmpOutR_Pos

A8-72

For Engg Purpose Only

4694

CL 26532063_016.eps

060602

12345678910

G

Schematics and PWB’s

22L01H.1E AA 02.01

Mono Carrier: Front Control Diversity Tables

123

Diversity Table For

For Front Control

ITEM

0231

A

B

C

D

0239

1600

1601

1602

1603

1606

3681

3682

3684

3685

3686

3687

3688

3689

4696

6681

9184 9500

9501

* 1% TOLERENCE RESISTER

ITEM

0214 0239

1600

1601 1602 1603 1606

2691

3681

3682

3683

3684

E

3685

3686

3687

3688

3689

3691

3693

4696

6681 BAT85

6691

6692

9184

F

---

YES

*180

*270

*390

---

JMP

*75

*68

*2K7

---

IR+LED-GL EU/LA/AP

---

YES YES YES YES

--10uF 390R

3K3 390R 560R 560R

1K5

---

--330R 220R YES

YES YES

---

IR+LED-KEYBOARD-

55K LA55K NA

YES

---

YES

---

*180

*270

*390

---

JMP

*75

*68

*2K7

---

YES

---

10uF

330R 220R

---

YES

---

YES

---

NON

55K NA

---

YES

390

3K

560

1K5

---

JMP

BAT85

--YES

YES

TC.PNL+FI.

PNL-INTERF

EU/NA/AP

YES YES

---

Front Control

NON

55K LA

YES

---

YES

---

YES

390

3K

560

1K5

---

JMP

BAT85

---

L2K2.FRNT

55K-NA

JUMPER

---

--YES YES

YES

YES YES

10uF

180R 270R 390R

390R

---

75R

68R 2K7

330R 220R

---

--YES YES YES

IR + LED

NA

---

YES

---

YES

---

YES

*1K5

---

YES

L2K2.FRNT

55K-LA

---

--YES YES

YES

--10uF 180R 270R 390R 390R

---

JUMPER

75R 68R 2K7

330R 220R

---

--YES YES YES

IR + LED

LA

YES

---

JMP

---

L2K2.FRNT

NON-55K-

NA

---

--YES YES

YES YES YES 10uF 390R 3K3

390R 560R 560R 1K5

---

330R 220R

YES

BAT85

YES YES

---

KEYBOARD+

IR + LED

LA

YES

---

YES

---

390

3K3

560

1K5

---

JMP

BAT85

---

L2K2.FRNT NON-55K-LA

---

--YES YES

YES YES

---

10uF

390R 3K3 390R

560R 560R

1K5

---

330R

220R YES BAT85

YES YES

---

4

ITEM

SCART IN- SCART IN

DVD

NA

---

YES

---

YES 10uF

---

1K5

---

330R 220R

---

--YES YES

---

1K

---

3609 3538

IR+LED.55K

Mono Carrier: Rear I/O SCART Diversity Table

123

DIVERSITY TABLE FOR REAR I/O SCART

DUALSINGLE

10K

75R

A

B

C

A

B

C

SINGLE SCART IN-

ITEM

DVD

2131 2132 2133 2134 2135 390pF 2136 4u7 2137 390pF 2138 390pF 2139 4U7 2140 390pF 2141 390pF 2142 4u7 2143 2144 2145 2147 3121 3131 3132 3133 3134 3135 3136 3138 3139 3140 3141 3142 3143 3144 3146 4105

---

75R

---

JMP

DUAL SCART IN

390pF 390pF

4u7

390pF

330pF 330pF

22pF 22pF

---

150R 220K

150R

47K

150R

220K

47K 27K

6K8 75R

100R 68R

1K

JMP

---

ITEM

2131 2152

2153 2154 3151 3152 3153 3154 7131

WITH MON. OUT

330pF

4u7

330pF

4u7

150R

220K

150R

220K

BC847B

WITHOUT MON.OUT

---

CL 26532063_019.eps

210502

A

B

C

D

123

E

F

ITEM

2x10W-ST- 2x5W-ST-

EU

2604

10uF

SNDAMP-SNDAMP-

EU/AP

1

---

SNDAMP-

2x5W-VD-ST-

EU

---

SNDAMP-

2x10W-VDST-EU

10uF

CL 26532063_017.eps

234

210502

Mono Carrier: Rear I/O SCART

1234567891011

REAR I/O SCART

SCART 1

Video_in

0235-A

+8V

1A

2A

3A

4A

5A

6A

7A

8A

9A

10A

11A

12A

13A

14A

15A

16A

17A

18A

19A

20A

21A

1107

1109

A

B

C

D

E

F

G

Audio-R_out

Audio-R_in

Audio-L_out

Audio-L_in

RGB-B_in

Function_Sw

RGB-G_in

RGB-R_in

RGB-BL_in

Terr_CVBS_out

Schematics and PWB’s

+8V

RES

2101

1101

4101

*

RES

2104

1102

RES

2107

1103

4102

*

RES

2110

1104

6106

2161

6101

BZX384-C8V2

6102

RES

6103

BZX384-C8V2

6104

BZX384-C8V2

6105

BZX384-C8V2

3119

68R

2119

RES

BZX384-C6V8

47u

3121

RES

1105

1106

1108

1110

1111

1112

1113

3155

47R

3101

150R

3103

150R

3105

150R

3107

150R

3111

27K

2118

3122

0R

22p

2102

2105

2108

2111

3109

3112

3113

3115

3117

3120

2120

330p

75R

6K8

75R

1K

22p

3102

3104

3106

3108

2V9

2

3

7V6

3110

100R

3114

100R

3116

100R

3118

100R

7101 BC847B

TO 0227 0F

FOR ITV ONLY

0236

1

220K

47K

220K

47K

2113

2114

2115

2116

2117

3V5

1

7

FOR ITV ONLY

TO 0262

OF

2

23L01H.1E AA 02.01

TO 0227 0F

2V9

7V6

+8V

75R

3141

2

3

3144

2147

* *

1K

22p

4151

2152

100n

4152

2154

100n

FOR ITV ONLY

0227

2

3

4103

*

2103

*

100n 150R

2106

100n

4104

*

2109

*

100n

2112

100n

22p

330p

22p

4

5

6

TO 0242 OF

0262

89

1

2

3

67

R1-IN

B_U-IN

STATUS1

G_Y-IN

R_V-IN

FBL-1

V1-OUT

CVBS1-IN

1

2

3

FOR ITV ONLY

R1-OUT

L1-OUT

L1-IN

4105

RES

0242

ITV_MSG

A10-57

A10-54

A10-56

A5-32 A10-32

A5-34

A7-1

A5-33

A5-35

A5-39

A5-41

A5-38

A7-75

A10-63

A10-55

A10-62

A10-52

A7-2

A5-30

A5-40

A10-59

A10-61

A10-60

R2-OUT

R2-IN

L2-OUT

L2-IN

STATUS2

C-IN

V_OUT

Y_CVBS-IN

R-OUT

L-OUT

1

4106

0229

FOR ITV ONLY

3

2133

100n

2136

100n

2139

100n

2142

100n

2144

3V5

7131 BC847B

3

100R

330p

1

2

TO 0242

OF

3142

1

3132

3134

3136

3138

3140

6131

RES

2145

3146

0R

220K

47K

220K

47K

6K8

22p

2132

2135

2138

2141

2143

3145

3152

3154

330p

RES

220K

3131

3133

150R

3135

150R

3137

150R

3139

27K

2146

2151

2153

3143

68R

RES

330p

2131

2134

2137

2140

6132

3151

150R

3153

150R

RES

1131

1132

1133

1134

1136

1139

1141

1142

1151

1152

2155

2156

RES

1135

SCART 2

0235-B

1B

2B

3B

4B

5B

6B

7B

8B

9B

10B

11B

12B

1138

1140

13B

14B

15B

16B

17B

18B

19B

20B

21B

1137

MONITOR OUTPUT

1

4

0224-A

2

5

0224-B

Audio-R_out Audio-R_in Audio-L_out

Audio-L_in

Function_Sw

YC-C_in

CVBS_out Video/YC-Y_in

Audio-RIGHT

Audio-LEFT

CL 26532063_018.eps

210502

A

B

C

D

E

F

G

0224-A F11 0224-B F11 0227 A7 0229 E7 0235-A A1 0235-B A11 0236 A5 0242 F6 0262 G5 1101 A3 1102 B3 1103 B3 1104 C3 1105 C3 1106 D3 1107 C2 1108 D3 1109 C2 1110 E3 1111 E3 1112 F3 1113 F3 1131 A9 1132 B9 1133 B9 1134 C9 1135 B10 1136 C9 1137 C10 1138 C10 1139 D9 1140 C10 1141 D9 1142 E9 1151 F9 1152 F9 2101 A3 2102 A4 2103 A5 2104 B3 2105 B4 2106 B5 2107 B3 2108 B4 2109 B5 2110 C3 2111 C4 2112 C5 2113 C5 2114 D5 2115 D5 2116 E5 2117 E5 2118 F4 2119 F3 2120 F4 2131 A9 2132 A8 2133 A7 2134 B9 2135 B8 2136 B7 2137 B9 2138 B8 2139 B7 2140 C9 2141 C8 2142 C7 2143 C8 2144 D7 2145 D8 2146 E9 2147 E8 2151 F9 2152 F8 2153 F9 2154 F8 2155 F10 2156 F10 2161 G3 3101 A4 3102 A4 3103 B4 3104 B4 3105 B4 3106 B4 3107 C4 3108 C4 3109 C4 3110 C5 3111 D4 3112 D4

3113 D4 3114 D5 3115 E4 3116 E5 3117 E4 3118 E5 3119 F3 3120 F4 3121 F4 3122 F4 3131 A9 3132 A8 3133 B9 3134 B8 3135 B9 3136 B8 3137 C9 3138 C8 3139 C9 3140 C8 3141 D8 3142 D7 3143 D9 3144 D8 3145 E8 3146 E8 3151 E9 3152 F8 3153 F9 3154 F8 3155 G3 4101 A3 4102 B3 4103 A5 4104 B5 4105 F6 4106 A7 4151 E8 4152 F8 6101 C3 6102 D3 6103 D3 6104 E3 6105 E3 6106 F3 6131 D8 6132 E9 7101 E5 7131 D7

12345678

91011

Mono Carrier: Tilt and Rotation

Schematics and PWB’s

24L01H.1E AA 02.01

A

B

12345678

TILT & ROTATION

VlotAux+13V

3171

120K

7000 TDA8941P

VlotAux+13V

12V6

1

VCC

A

B

0268 C8 0290 F5 0291 F8 2171 C4 2172 C5 2174 F7 2175 F7 3171 C4 3173 C4 3174 C5 3176 F6 5180 F6 6171 F7 7000 B6 9180 F6

C

D

E

F

A8-74

OUT-

OUT+

7

6V3

2

6V1

3174

68K

2172

220p

6V3

6V2

5

3

4

6

IN-

IN+

MODE

SVR

STANDBY/

MUTE LOGIC

20K

Vcc

GND

8

SHORT CIRCUIT

AND

TEMPERATURE

PROTECTION

2171

3173

68K

100p

Tilt

3

2

1

0268

TO

ROTATION

COIL

C

D

E

VlotAux+13V

0291

1

TO 0289

OF

0290

9180

5180

27u

3176

1R

2174

470p 6171

BYD33D

2175

2

3

4

470u

TO 1015

OF

GPM CCT.

PANEL

F

CL 26532063_021.eps

210502

12345678

Layout Mono Carrier (Top Side)

Schematics and PWB’s

25L01H.1E AA 02.01

CL 26532063_023.eps

060602

Schematics and PWB’s

26L01H.1E AA 02.01

Layout Mono Carrier (Mapping Top Side)

0211 A2 0212 B3 0213 A3 0214 B1 0215 B1 0217 E5 0218 B1 0219 B1 0220 C6 0221 B6 0222 C8 0224 E8 0227 C7 0229 D7 0231 A2 0232 B1 0235 D8 0236 C7 0239 C3 0240 D6 0242 D7 0243 D5 0246 E4 0248 E5 0249 D6 0250 C7 0251 B3 0259 B1 0261 D5 0262 D7 0265 E8 0266 E6 0267 E4 0268 E3 0270 B1 0271 E4 0273 D7 0274 C6 0275 D4 0276 D5 0277 B1 0279 D6 0280 E4 0281 E4 0282 B5 0283 E7 0285 E7 0286 C2 0287 D7 0288 B8 0289 B6 0290 E3 0291 D3 0292 B1 0293 C2 0294 E5 0295 E6 0296 D4 0297 D5 0298 C4 0299 C4 0300 D2 0301 D2 0318 D6 0319 C6 0321 C7 0322 C6 1000 E8 1002 E6 1003 E6 1004 E6 1200 E5 1201 E5 1203 E7 1204 D6 1205 D7 1400 C6 1402 B7 1410 A6 1500 A2 1515 B3 1530 B5 1531 B5 1532 B4 1533 B4 1534 B4 1535 B4 1540 B3 1600 C1 1601 C1 1602 D1 1603 D1 1606 A1 1660 D6 1810 C5 1811 C5 1812 C4

1813 C3 1814 D2 1815 D2 1831 C3 2005 E7 2006 E7 2008 E8 2161 D7 2171 E3 2172 E3 2174 D3 2175 E3 2209 D5 2216 E5 2220 D5 2229 E6 2230 E5 2235 E6 2244 E6 2246 E6 2247 E6 2250 E6 2400 A5 2401 A6 2402 A5 2404 C6 2405 C5 2441 B7 2444 B6 2448 B6 2450 B5 2451 B6 2453 B6 2454 B6 2455 B5 2456 B6 2457 B6 2458 B6 2459 B6 2462 A6 2463 A7 2464 B5 2465 A6 2466 A6 2467 A6 2468 A6 2469 B6 2470 A6 2471 B8 2472 C8 2473 B8 2480 B8 2481 B7 2482 A8 2484 B6 2485 C6 2486 A8 2487 A8 2488 C7 2489 C7 2490 B5 2491 B7 2492 C6 2493 A6 2500 A2 2501 A3 2502 A4 2503 A4 2504 A5 2505 A5 2506 B3 2508 B5 2509 B2 2515 B5 2516 B4 2521 B3 2523 A4 2560 C5 2561 C5 2562 B4 2563 B4 2564 B4 2566 C3 2567 C3 2568 C3 2580 C2 2581 C3 2604 D6 2691 A1 2801 D4 2823 D2 2837 D4 2841 C3 2843 C4 2844 C3 2846 C3 2855 C3

2902 D4 2903 E4 2908 E4 2981 B1 2983 B1 3000 E8 3001 E8 3005 E6 3012 E7 3101 C8 3103 C8 3105 C7 3107 C8 3109 D8 3110 D8 3111 D8 3113 D8 3114 D8 3115 D8 3116 D8 3117 D8 3118 D8 3119 D8 3121 D8 3122 D8 3131 C7 3133 C7 3135 C7 3137 C7 3139 D8 3141 D8 3142 D8 3143 D8 3145 D8 3146 D8 3151 E8 3153 D8 3155 D8 3171 E4 3172 E4 3173 E4 3174 E3 3176 E3 3181 B1 3182 B1 3183 C1 3185 C1 3200 E6 3201 D5 3202 D5 3203 D5 3204 D5 3207 E5 3214 D7 3220 D5 3228 E6 3235 D5 3244 E7 3249 E7 3250 E7 3251 E6 3400 A8 3401 A7 3402 A5 3403 A5 3404 A5 3405 A6 3406 A6 3407 A6 3408 A5 3410 A5 3411 A6 3430 A5 3431 A5 3445 C6 3446 C6 3447 C7 3448 C7 3449 C7 3450 C7 3451 B6 3452 C6 3453 C7 3454 C6 3455 C7 3458 B6 3459 B6 3460 B8 3463 A6 3464 B7 3465 A8 3468 B5 3469 C6 3471 C8 3472 C8 3473 C8 3474 B8

3475 B8 3477 C8 3478 C8 3480 B8 3481 A7 3482 A7 3483 C6 3484 A8 3485 B6 3486 B6 3487 B5 3488 A8 3489 C6 3490 C6 3493 C5 3494 B6 3500 A2 3501 B2 3503 A4 3504 B3 3506 B3 3507 B2 3508 A2 3509 B3 3510 B3 3511 A3 3519 B4 3521 B4 3523 A4 3526 A4 3527 A4 3532 A3 3543 B3 3550 C3 3558 C4 3560 C4 3561 B4 3564 C4 3565 C4 3590 C3 3601 D7 3603 D6 3604 D6 3606 D6 3607 D6 3608 D6 3609 D6 3610 D6 3612 E7 3614 D6 3615 D6 3617 D6 3618 D6 3619 D6 3624 D6 3625 D6 3634 D7 3635 D7 3801 D4 3802 D4 3808 C4 3832 D3 3833 D3 3834 C3 3908 D5 3911 D5 3912 E4 3981 B1 3982 B1 5001 E7 5002 E7 5180 E3 5201 E5 5202 E5 5204 C5 5205 C5 5206 C5 5241 E7 5242 E7 5400 A6 5401 A6 5445 B7 5451 B6 5452 A6 5453 C4 5457 B6 5461 B5 5463 A5 5464 A5 5465 A5 5471 C8 5472 B8 5480 C6 5500 B2 5501 B2 5502 A3 5520 B4

5521 B4 5560 B5 5561 B5 5562 B4 5564 C4 5602 D6 5603 D6 5604 D6 5672 C6 5678 C7 5831 D3 5832 C4 5833 C3 6001 E7 6171 D3 6207 E5 6400 A7 6401 A5 6402 A7 6403 A8 6447 B6 6448 C7 6460 A6 6461 A6 6462 B5 6465 B6 6466 B6 6469 C4 6476 C8 6481 C7 6482 C7 6483 A8 6485 B7 6486 C7 6487 A8 6488 B7 6489 B7 6490 C5 6500 A4 6520 B4 6523 B4 6524 A4 6525 A4 6540 C3 6560 C5 6561 C4 6562 C4 6566 B3 6568 B4 6582 C4 6681 D1 6691 A1 6692 B1 6808 D4 6831 D3 6903 D5 7000 E3 7400 A6 7443 C7 7444 B5 7460 A6 7461 C5 7463 C5 7471 C8 7480 C7 7482 C7 7515 B3 7520 B4 7521 A4 7540 B3 7560 C3 7602 D6 7831 D3 7901 E4 7902 E4 9001 E7 9171 D7 9172 D7 9173 D7 9174 D7 9175 D7 9176 D7 9177 D7 9178 D7 9179 D7 9180 E3 9181 C1 9182 C1 9183 C1 9184 C1 9191 B1 9192 B1 9193 B1 9200 E5 9201 E5 9202 D5 9203 D5

9206 C5 9207 E5 9241 E7 9406 A6 9407 A6 9408 B7 9409 C5 9410 C6 9411 B6 9412 C6 9413 C6 9414 C6 9415 C7 9416 C8 9417 C7 9418 C7 9419 B8 9420 C6 9421 A8 9422 B7 9423 C5 9424 A7 9425 B8 9426 A8 9427 B7 9451 B6 9453 B5 9460 B6 9461 A6 9462 A6 9463 A6 9464 B5 9471 C8 9472 B8 9500 A2 9501 A2 9502 A2 9503 A3 9504 B3 9506 B2 9507 B2 9508 B2 9509 B2 9510 C3 9511 C4 9512 C4 9513 C4 9514 B5 9515 C5 9516 C4 9518 B3 9520 B3 9521 A5 9522 C4 9524 C4 9525 B4 9526 B5 9528 B4 9529 B4 9611 C5 9612 C5 9613 D5 9614 E5 9615 D7 9616 D7 9617 D5 9618 D7 9619 D5 9620 D7 9622 C6 9623 D7 9624 D5 9625 E7 9626 D5 9627 D5 9628 E7 9629 D6 9630 C5 9631 D6 9632 E5 9633 D5 9634 D5 9635 D6 9636 C6 9637 E6 9638 D6 9639 E5 9640 D7 9641 D6 9642 D6 9643 D5 9644 E5 9645 E5 9647 D7 9648 E7 9650 E7 9653 C5

9654 C5 9655 C6 9656 C7 9657 D6 9658 C6 9659 C6 9660 C6 9661 D7 9662 D7 9663 D7 9664 C6 9665 C6 9666 C6 9668 C6 9669 C6 9670 C5 9672 C6 9673 C5 9674 C5 9675 C7 9676 C7 9678 C7 9679 C7 9680 D5 9683 D5 9685 D6 9686 D6 9687 D5 9688 D5 9689 D7 9690 D5 9691 E7 9692 C5 9693 C5 9695 E7 9696 E8 9697 D7 9698 D7 9699 C1 9801 D4 9811 C4 9812 D4 9814 D4 9815 D4 9816 C3 9817 C4 9818 C4 9820 C3 9821 D4 9822 D4 9824 C4 9825 C4 9826 C4 9827 D4 9828 D4 9829 D4 9830 C4 9832 C3 9833 D3 9834 C2 9835 C2 9901 D4 9902 E4 9903 D5 9904 D4 9905 E5 9911 D4 9912 D4 9913 E4 9914 E4 9915 E4 9916 E4 9918 D4 9919 D4 9920 E4 9921 E4 9922 E4 9923 D4 9982 B1 9991 B1 9993 E8 9994 E5 9995 D5 9996 E7 9997 E8 9998 E5 9999 E5

CL 26532063_23m.eps

060602

Layout Mono Carrier (Mapping Bottom Side)

2001 A8 2002 A8 2003 A7 2004 A7 2007 A7 2009 A6 2010 A8 2101 C8 2102 C7 2103 C7 2104 C8 2105 C8 2106 C7 2107 C8 2108 C7 2109 C7 2110 C8 2111 C8 2112 C7 2113 B8 2114 B7 2115 B8 2116 B7 2117 B8 2118 B8 2119 B8 2120 B8 2131 C8 2132 C7 2133 C7 2134 C8 2135 C7 2136 C7 2137 C8 2138 C7 2139 C7 2140 C8 2141 B7 2142 B7 2143 B7 2144 B7 2145 B8 2146 B8 2147 B7 2151 A7 2152 A8 2153 B8 2154 B7 2155 A8 2156 A8 2181 D1 2182 D1 2183 C1 2184 C2 2185 D1 2186 C1 2201 A5 2202 B5 2203 A5 2204 B6 2205 A6 2206 A5 2207 A5 2208 A5 2210 B5 2211 A5 2213 B5 2214 B5 2215 B5 2217 A5 2219 A6 2221 B5 2222 A7 2223 A7 2225 A6 2226 A6 2227 A6 2228 A6 2233 B6 2234 A7 2236 A7 2237 A7 2238 A7 2239 A7 2240 A7 2241 A6 2242 A6 2243 A6 2245 A5 2248 A7 2249 A6 2252 A7 2253 A7 2254 A7 2255 A5 2260 B5 2415 D5 2420 C5 2421 C6 2422 C6 2423 C5 2443 C6 2452 C8 2460 C5 2461 C6 2474 D8

2475 D8 2476 C7 2507 D4 2520 D4 2522 E4 2525 D4 2526 D3 2527 E4 2528 D4 2540 C3 2541 D3 2569 C5 2590 C3 2601 B6 2602 B6 2606 B7 2607 B6 2608 B6 2609 B6 2611 B6 2612 B7 2613 B6 2615 B6 2616 B6 2618 B6 2619 B6 2692 E1 2693 D2 2694 E1 2695 E1 2696 D1 2802 C4 2803 C3 2804 B4 2805 B4 2811 C2 2813 B2 2814 B2 2815 B2 2816 C2 2817 C2 2818 C2 2819 C2 2820 C2 2821 B2 2822 B2 2824 B5 2831 B3 2832 B3 2833 B3 2834 B3 2835 B3 2836 B3 2838 B3 2839 B3 2840 B3 2842 B3 2845 B3 2847 C3 2848 B3 2849 B4 2850 B4 2851 B4 2852 C4 2853 B4 2854 C4 2856 C3 2857 C3 2858 C3 2859 C3 2860 C3 2861 B3 2862 B3 2870 C4 2871 C3 2887 B4 2894 B3 2895 B3 2896 C3 2897 B3 2898 B3 2901 B4 2904 A4 2905 A4 2906 A4 2907 A4 2910 A4 2911 A4 2947 A4 2948 A4 2949 A4 2950 A4 2982 D1 2984 D1 3002 A8 3003 A8 3004 A8 3006 A7 3007 A7 3008 A7 3009 A6 3010 A7 3011 A7 3102 C7 3104 C8 3106 C7

3108 C8 3112 B7 3120 B8 3132 C7 3134 C7 3136 C7 3138 C7 3140 B7 3144 B8 3152 A8 3154 B8 3184 C1 3186 C1 3206 B5 3208 A5 3209 A5 3212 A5 3213 A5 3217 B5 3218 B5 3219 B5 3223 B5 3224 B5 3225 B5 3226 B5 3229 A5 3230 A6 3231 A5 3232 A6 3233 A8 3234 A6 3236 A8 3237 A7 3238 A7 3239 A7 3240 A8 3241 A6 3242 B5 3245 A6 3246 A5 3247 C6 3248 A5 3254 A6 3256 C6 3257 A6 3258 A7 3259 B6 3261 A7 3270 A5 3441 D7 3442 D7 3443 C6 3456 C7 3457 C6 3470 C8 3479 C8 3491 C5 3492 C5 3495 C8 3496 C8 3497 C7 3498 C8 3499 C5 3520 D4 3522 D4 3524 E4 3525 E4 3528 D3 3529 D4 3530 E4 3531 D4 3541 D3 3542 D3 3544 D3 3545 D3 3548 C3 3552 D3 3557 C4 3562 D4 3563 C4 3566 C3 3567 D3 3568 D3 3569 D3 3570 D4 3580 C2 3594 D3 3595 D5 3596 D5 3605 C6 3611 B6 3622 B7 3623 B6 3626 B6 3627 B6 3628 B6 3629 B6 3630 B6 3632 B6 3633 B6 3636 A7 3637 B5 3638 A5 3681 B1 3682 C1 3683 C1

3684 B1 3685 C2 3686 B1 3687 C1 3688 C1 3689 C2 3691 E1 3692 E1 3693 E1 3694 E1 3695 C2 3803 B4 3804 C4 3805 B4 3806 C4 3807 C4 3809 B4 3810 B4 3811 C2 3812 C2 3813 C2 3814 B2 3815 C2 3831 B3 3835 C3 3837 C4 3839 C4 3840 C3 3841 C3 3842 C3 3843 C3 3844 C4 3845 C4 3849 C3 3861 B3 3901 B4 3902 A4 3903 A4 3904 A4 3905 A4 3906 A4 3907 A4 3909 A4 3910 A4 3921 A4 3922 A4 3923 A4 4001 A7 4002 A6 4003 A7 4004 A6 4005 A7 4006 A7 4007 A7 4011 A6 4012 A6 4101 C8 4102 C8 4103 C7 4104 C7 4105 B7 4106 C7 4151 A8 4152 B7 4171 B8 4203 A6 4204 A5 4205 B5 4206 B5 4207 B5 4209 A5 4210 A5 4211 A5 4212 A6 4213 A6 4214 C5 4218 A6 4219 B5 4401 C7 4402 E8 4430 C5 4470 D8 4500 C4 4601 B6 4602 B6 4603 B6 4604 A5 4608 A8 4609 A8 4613 B5 4614 A5 4615 B6 4616 B6 4617 A6 4618 A5 4619 A6 4622 A7 4623 A7 4691 D1 4692 C2 4693 C2 4694 B1 4695 E1 4696 C1 4805 B4 4806 B4

4807 B4 4808 B4 4809 C4 4811 B4 4812 B4 4813 B4 4814 C4 4815 B4 4820 C2 4832 C3 4834 C3 4835 C3 4836 C3 4837 B2 4861 B3 4901 A4 4902 A4 4903 A4 4904 A4 4905 B4 4906 A4 4921 B4 4982 D1 4991 A7 5003 A6 5450 C8 5835 C3 6002 A8 6003 A8 6004 A7 6005 A7 6101 B8 6102 B8 6103 B8 6104 B8 6105 B8 6106 B8 6131 B8 6132 B8 6181 C1 6201 B5 6202 B5 6206 B5 6445 D7 6449 C7 6452 C6 6453 C6 6463 C6 6467 C5 6468 C5 6470 D7 6522 D3 6526 E4 6541 D3 6563 D4 6564 D4 6565 C4 6567 D4 6569 C3 6570 C3 6580 C3 6801 C2 6802 C2 6803 C2 6804 C2 6805 C2 6806 C2 6807 C2 6901 A4 7001 A7 7002 A6 7101 B7 7131 B7 7200 A6 7201 A5 7204 B5 7206 A5 7209 A8 7210 A7 7441 D7 7450 C6 7462 C5 7522 D4 7541 D3 7542 C3 7561 C4 7562 C4 7564 C3 7580 C3 7606 B7 7801 C4 7802 B4 7803 C4 7804 B4 7805 B2 7806 B2 7807 C2 7834 C3 7835 C3 7903 A5

CL 26532063_22m.eps

060602

Schematics and PWB’s

Layout Mono Carrier (Overview Bottom Side)

Part 1

CL 26532063_22a.eps

27L01H.1E AA 02.01

Part 3

CL 26532063_22c.eps

Part 2

CL 26532063_22b.eps

Part 4

CL 26532063_22d.eps

CL 26532063_022.eps

060602

Schematics and PWB’s

Layout Mono Carrier (Part 1 Bottom Side)

28L01H.1E AA 02.01

CL 26532063_22a.eps

060602

Schematics and PWB’s

Layout Mono Carrier (Part 2 Bottom Side)

29L01H.1E AA 02.01

CL 26532063_22b.eps

060602

Schematics and PWB’s

Layout Mono Carrier (Part 3 Bottom Side)

30L01H.1E AA 02.01

CL 26532063_22c.eps

060602

Schematics and PWB’s

Layout Mono Carrier (Part 4 Bottom Side)

31L01H.1E AA 02.01

CL 26532063_22d.eps

060602

CRT Panel

A

B

B2-67

B2-68

C

TO

0243

OF

B2-69

D

0220

TO

OF

E

Schematics and PWB’s

32L01H.1E AA 02.01

12345678

CRT PANEL

+13Va

7331

*

3356 3347

0245

R

G

B

3357

*

R

1

2

G

3

B

4

5

6

GNDSS

0244

*

3348

*

7332

*

3350

*

3351

1

2

3

4

5

+13Va

*

7333

*

3358

*

3354

BC_INFO

FROM RGB PROCESSING

EHT_INFO

GNDLS

FF

(EUROPE)

9341

*

5346

RES

5343

*

RES

3349

9342

*

5347

RES

5344

*

RES

3352

9343

*

5348

RES

3353

5345

*

**

3355

+200V

+13V

FROM LINE DEFLECTION

3340

10R

2340

V12

V13

10u

2V5

RES

V11

7330

*

1 IN1

2 IN2

3 IN3

2344

+200VA

3k77

3k75

3k77

3k75

3k77

3k75

Vref

2.5V

*

Vdd

Vref

PROTECTION

GND 4

6332

*

V11

1V / div DC

+200VA

2330

6

188k7

Vdd

A1

188k7

Vdd

A2

188k7

Vdd

A3

THERMAL

10us / div

100n

BC1

BC2

BC3

V12

1V / div DC

10us / div

V13

1V / div DC

10us / div

V14

50V / div DC

10us / div

V15

50V / div DC

10us / div

V16

50V / div DC

10us / div

0165

AQUADAG

WIRE

CRT Sockets

0255

0256-A

1

5

6

7

8

9

10

11

12

3343

1

4

5

6

G

7

8

R

9

10

11

B

12

1K5

BAV21

6331

6335

BAV21

3334

1K

3336

1K

3332

1K

V15

V14

V16

5342

*

6333

3333

9OUT1

100R

140V

3335

8OUT2

140V

100R

3331

7OUT3

140V

100R

5BCI

6V

7V

2342

3341

*

3342

1n

G3

G1

CG

G2

CR

H1

H2

CB

GND

2345

1n

3345

3344

22R

3346

22R

0254-A

1

G3

5

G1

6

CG

7

G2

8

CR

9

H1

10

H2

11

CB

12

GND

T0 CRT SOCKET

V

Blue

Green

Red

*

2341

3n3

2346

680p

2343

3n3

91011

7

FOCUS

1

NOT USED

EHT

5

T0 CRT SOCKET

VG2

A

B

C

D

E

VG2 E9 0165 A7 0244 D1 0245 C1 0254-A A7 0255 A6 0256-A A6 2330 A3 2340 F2 2341 F4 2342 C4 2343 F5 2344 D3 2345 C6 2346 F5 3331 C4 3332 C5 3333 B4 3334 B5 3335 B4 3336 B5 3340 E2 3341 E4 3342 E4 3343 E5 3344 D6 3345 C6 3346 E6 3347 A2 3348 A1 3349 A2 3350 B2 3351 B1 3352 B2 3353 C2 3354 C2 3355 C2 3356 A1 3357 B1 3358 C1 5342 C5 5343 A2 5344 B2 5345 C2 5346 A2 5347 B2 5348 C2 6331 B4 6332 D3 6333 A4 6335 A4 7330 B3 7331 A1 7332 B1 7333 C1 9341 A2 9342 B2 9343 C2

Diversity Table

F

ITEM

21/25RF 29SF 28BLD/BLS/32WS(O)

100n

2344 3347

JMP

3348

---

3350

JMP

---

3351 3353

JMP

3354

--- ---

JMP

3356

JMP

3357

JMP

3358

---

5343

G

---

5344

---

5345 6332

TDA6107

7330 7331 7332 7333 --9341 9342 9343

---

--JMP JMP JMP

TDA6107

12345678

JMP

---

JMP

---

JMP

JMP JMP JMP

---

BAS316

---

JMP JMP

100n JMP

---

JMP

--JMP JMP JMP

---

BAS316

TDA6107

---

JMP JMP JMP

REGION TUBE (EUROPE)

29RF(I) 28/32WS(I) 32W(TH)(O)

JMP

1K 1K 1K 1K 1K 1K 1K

SDL-4893 SDL-4893 SDL-4893

BC847B BC847B BC847B

JMP100n

1K 1K 1K 1K

---

---BAS316

---

1K

---

--SDL-4893 SDL-4893 SDL-4893---

---

TDA6108

BC847B BC847B BC847B

---JMP

--- JMP

---

100n JMP

--- 3341

JMPJMP

---

JMP

--JMP JMP JMP

---

------

---

BAS316

TDA6107

---

--JMP JMP JMP

28/32WS(TH)(I)

JMP

1K

1K 1K 1K 1K

---

------

--SDL-4893 SDL-4893 SDL-4893

---

TDA6108TDA6108

BC847B BC847B BC847B

---

NO SVM SETS

100n JMP1K

---

JMP

---

JMP

--JMP JMP JMP

---

BAS316

TDA6107

---

--JMP

JMP

Diversity Table

EU PH

ITEM

NO EW

21FSQ

1R

3342

1R

22u

5342

EU

EU EU

PH

EW

28" BLD

28"BLS

1R

15u

22u

EU PH EW

25BLD

1R 1R 15u

EU PH

EW

25BLS

1R 1R

22u

PH

EW

29SF

1R 1R

18u

REGION TUBE

EU PH

EW

24" WS BLD

1R 1R

22u

EU

SGMK

EW

29" RF

1R 1R 3u9

EU PH

EW

32" WS BLS

1R8 1R8 18u

EU PH EW

28" WS BLD

1R5 1R5

22u

EU

SGMK

EW

25" RF

1R 1R

3u9

EU

MATJ

EW

21" RF

1K5

---

100MHZ 50R

FROM LOT, MAIN CHASSIS

--22R 22R

L2K2 EU

28WR

2KV 2N2

---

33R

LAL04 22U

32WR

---

2KV 470P

33R 33R

LAL04 22U

CL 26532063_020.eps

32WR

---

33R 33R

LAL04 22U

060602

EU

THCF

EW

32WS

1R5 1R5 JMP

EU

THCF

EW

28WS

1R5 1R5 JMP

MODEL

REGION

TUBE

SET

2343 2346 3344 3346 5342

29RF

--

2KV 1N2

22R 22R

LAL04 3U9

21RF

2KV 3N3

LAL04 22U

91011

F

G

SCAVEM Panel

Diversity Table B2

Item Description

2365 22N 250V XXXXXXXX

2366 100N 100V XXXXXXXX

2367 47P 50V X X X

2367 56P 50V X X

2367 150P 50V X

2367 180P 50V X X

2368 22N 50v XXXXXXXX

2372 5P6 50V XXXXX

2373 56P 50V X X

2375 100P 50V XXXXX

2375 330P 50V X X

2376 100N 25V X X X

2377 100N 25V X X X

3360 8K2 5W XXXXXXXX

3361 680R

3362 Fuse 10R XXXXXXXX

3363 820R XXXXXXXX

3364 1R8 X X X

3364 3R3 XXXXX

3368 2K7 XXXXXXXX

3369 10K XXXXXXXX

3370 220R X X X

3370 330R XXXXX

3371 10K XXXXX

3371 4K7 X X X

3373 220R X X X

3374 56K XXXXXXXX

3375 150R X X

3375 220R X

3375 470R XXXXX

3376 Jumper XXXXXXXX

3377 10R X

3377 4R7 X X

3378 56K XXXXXXXX

3379 10K XXXXX

3379 4K7 X X X

3382 1K5 XXXXXXXX

3383 470R XXXXXXXX

3384 820R XXXXXXXX

3385 1R8 X X X

3385 3R3 XXXXX

3386 10K XXXXX

3386 4K7 X X X

3387 470R XXXXXXXX

3388 220R XXXXX

3389 220R XXXXX

3390 10R X X

3390 33R XXXXXX

3391 10R X X

3391 33R XXXXXX

3392 220R X X X

3393 4K7 X X X

5360 5.6uH 10% XXXXXXXX

5361 COIL

5362 COIL

6360 1N4148 X X X

6361 BAS316 X X X

6362 BAS316 X X X

6364 BAS316 X X X

6365 BAS316 X X X

7360 BC547B XXXXXXXX

7362 2SA1358 XXXXXXXX

7363 BC547B XXXXXXXX

7365 2SC3421 XXXXXXXX

7366 BF423 X X X

7367 BC557B XXXXXXXX

9361 Wire

9363 Wire XXXXXXXX

9364 Wire XXXXXXXX

9365 Wire XXXXX 9366 Wire XXXXX

21" Real flat

25" Real flat

29" Super flat

28" Blackline, FM radio

32" Wide screen, No FM radio

29" Real flat

28" Wide screen, FM radio

32" Wide screen, FM radio

21" Blackline

24" Wide screen

25" Blackline

Schematics and PWB’s

12345678910

B2

SCAVEM PANEL

28" Blackline, No FM radio

28" Wide screen, No FM radio

B1-67

B1-68

B1-69

+200V

+13Va

+13V

R

G

B

12345678910

33L01H.1E AA 02.01

0278 D10 2360 A8 2361 B3 2365 D8 2366 D7 2367 D4 2368 D7 2372 C4 2373 E3 2374 E5 2375 D9

3360

8K2

22u

100n

0V6

92V4

3363

3374

3378

3384

2360

820R

7362 BD140

56K

820R

0V

3364

3385

3R33R3

93V7

5361

**

48V8

7365 BD139

9363

0278

3

TO SCAVEM COIL

2

3375

2375

150p

5362

*

9364

*

470R

1

CL 16532020_089.eps

050601

3361

*

680R

5360

*

5u6

9361

*

3371

2K2

3379

2K2

3386

2K2

3362

10R

2361

100u

2373

100n

2377

6364

6361

BAS216

7V3

1V1

3383

6365

9365

6360

1N4148

7363

BC548B

220R

BAS216

3368

BAS216

1V8

1K2

3370

330R

3373

3376

2374

10K

3369

14V

7V9

7V6

7360 BC548B

1K5

3377

10R

7V6

7366 BF423

9366

220R3388

0R

1n

3382

220R3389

3392

2376

3390

33R

3391

33R

220R

100n

2368

4n7

2365

4n7

2366

4K7

3393

6362

5p6

2372

3387

470R

2367

150p

7367 BC557B

1n

2376 E7 2377 B5

A

3360 A7 3361 A2 3362 B3 3363 B8 3364 B8 3368 B5 3369 B6 3370 C5 3371 C3 3373 D5 3374 D8

B

3375 D9 3376 D5 3377 D6 3378 D8 3379 D3 3382 E6 3383 E5 3384 E8 3385 E8 3386 D3 3387 D4 3388 E6

C

3389 E7 3390 D7 3391 D7 3392 E7 3393 B4 5360 B2 5361 D8 5362 D9 6360 C5 6361 B5 6362 C5 6364 B5

D

6365 C5 7360 C6 7362 C8 7363 D5 7365 D8 7366 E6 7367 D4 9361 B2 9363 D8 9364 D9 9365 C5

E

9366 D6

Schematics and PWB’s

34L01H.1E AA 02.01

Layout CRT and SCAVEM Panel (Top Side)

5346 A1

5347 A1

5348 A1

5360 A2

5361 A2

5362 A2

6331 A1

6333 A1

6335 A1

6360 A1

7330 A1

7360 A1

7362 A2

7363 A1

7365 A2

7366 A2

7367 A1

9311 A1

9312 A1

9341 A1

9342 A1

9343 A1

9361 A2

9363 A2

9364 A2

9365 A1

9366 A2

VG2 A1

0165 A2

0244 A2

0245 A1

0254 A2

0255 A2

0256 A2

0278 A2

2330 A1

2340 A1

2341 A2

2343 A2

2345 A2

2346 A2

2360 A2

2361 A1

2365 A2

2366 A2

3331 A1

3332 A2

3333 A1

3334 A2

3335 A1

3336 A2

3340 A2

3341 A2

3342 A2

3343 A1

Layout CRT and SCAVEM (Bottom Side)

2342 A2

2344 A2

2367 A2

2368 A1

2372 A2

2373 A2

2374 A2

2375 A1

2376 A1

2377 A2

3347 A2

3348 A2

3349 A2

3350 A2

3351 A2

3352 A2

3353 A2

3354 A2

3355 A2

3356 A2

3357 A2

3358 A2

3368 A2

3369 A2

3370 A2

3371 A2

3373 A1

3376 A2

3378 A1

3379 A2

3382 A2

3383 A2

3384 A1

3386 A2

3387 A2

3390 A1

3391 A1

3392 A1

3393 A2

4311 A2

6332 A2

6361 A2

6362 A2

6364 A2

6365 A2

7331 A2

7332 A2

7333 A2

3344 A2

3345 A2

3346 A2

3360 A2

3361 A2

3362 A1

3363 A2

3364 A2

3374 A2

3375 A2

3377 A2

3385 A2

3388 A2

3389 A2

5342 A2

5343 A1

5344 A1

5345 A1

140501

050601

CL 16532051_014.eps

CL 16532053_013.eps

Schematics and PWB’s

35L01H.1E AA 02.01

Side AV + HP Panel

123456

C

SIDE AV + HP PANEL

0277-A

0277-B

VIDEO IN

0250-C

RIGHT

0250-A

LEFT

0250-B

Layout Side AV + HP Panel (Top Side)

0232 E5 0250-A C2 0250-B D2 0250-C B2 0251 A5 0254 E2 0255 E5 0277-A B1 0277-B D1 2171 D4 2172 C4

A

2

3

1

8

9

7

5

6

4

9152

RES

SG02

SG04

SG03

6161

2173

2174

RES

3155

BZX79-C6V8

9153 RES 3153

8K2

31523150

3151

8K2

75R

10K

2172

2171

330p

0251

6

5

4

3

2

1

TO 0219 OF

B

C

D

2173 C4 2174 D4 2176 F3 2177 F3 2178 E3 2179 E3 3150 D4 3151 D4 3152 C4 3153 B4 3155 B4 3156 E3 3157 F3 6161 B4 9152 C3 9153 B4 SG02 B3 SG03 D3 SG04 C3 SG06 F4 SG07 E4

HEADPHONE

TO 0246 OF

GND

0254

L-

5

L+

4

3

R+

2

R-

1

2179

100u

2177

100u

3156

330R

3157

330R

2178

2176

330p330p

SG07

SG06

1

0232 6

5

4

2

3

7

8

9

0255

L+

4

L-

R-

R+

To Speakers

CL 16532020_057.eps

050601

3

2

1

123456

E

F

CL16532010_014.eps

210301

Schematics and PWB’s

36L01H.1E AA 02.01

Side AV Panel + Headphone

12345

SIDE AV PANEL & HEADPHONE

A

0252

1

2

3

4

AP/INDIA/LATAM

120R

B

C

*

3156

3157

EUROPE

330R

N.C

VIDEO IN

0250-C

RIGHT

0250-A

LEFT

0250-B

Layout Side AV Panel + Headphone (Top Side)

0232 D4 0250-A B2 0250-B C2 0250-C A2 0251 B5 0252 B2 0253 A5 0254 D2

A

B

C

0255 D5 0261 C5 2171 C4 2172 B4 2173 B3 2174 C3 2176 E3 2177 E2 2178 E3 2179 D2 3150 C3 3151 C3 3152 B3 3153 B3 3155 A3 3156 D3 3157 E3 6161 A3 9153 B3 9155 B4 SG02 A3 SG03 C3 SG04 B3 SG06 E3 SG07 E3

0253

2

3

1

SG02SG04

6161

3155

BZX79-C6V8

75R

3

2

1

To 0219

of

A12

9153 RES 3153

8

9

7

5

6

4

SG03

2173

2174

8K2

330p

3151

8K2

330p

31523150

10K

2172

2171

330p

9155

(FOR ESD)

1

2

3

1

2

3

4

5

6

0251

0261

N.C

D

HEADPHONE

0254

L-

To 0246

of

GND

5

L+

4

3

R+

2

R-

1

E

2179

100u

2177

100u

*

3156

330R

3157

330R

2178

2176

330p330p

SG07

SG06

1

0232

6

5

4

2

3

7

8

9

0255

4

3

2

1

To Speakers

L+

L-

R-

R+

To

Speakers

D

E

CL 16532004_016.eps

CL 16532020_056.eps

120401

210301

12345

Schematics and PWB’s

37L01H.1E AA 02.01

Front Interface Panel

12345

A

B

C

FRONT INTERFACE PANEL

LATAM 100V - 250V NAFTA 110V EUROPE 220V - 240V

AC MAINS

INPUT

110V/220V

TO ITV/

MULTIMEDIA

0211

0218

I012 I013

1

I001

2

3M3

3500

*

I002

3M3

3501

*

I003

I004

1

2

9001

*

24

13

9002

*

56

0231 SDDF T4.0AE

TO 0211 OF

POWER SUPPLY

0212

1

I014

2

+3.3V

3694

RES

TSOP1836

3

VS

1

OUT

2

GND

Layout Front Interface Panel (Top Side)

0211 B3 0212 B5 0214 D3 0218 D3 0231 B4 1606 E4 2691 E5

A

B

C

6692

*

2698 E5 3500 C3 3501 C3 3685 E4 3691 E4 3693 D5 3694 C5 6691 E4 6692 C6 9001 B4 9002 C4 9695 E4 I001 B3 I002 C4 I003 C4 I004 D4 I005 D3 I006 D3 I007 E4 I008 E3 I009 D5 I010 E3 I011 E4 I012 B4 I013 B5 I014 B5

D

E

F

G

ITEM

0231 9001 9002

ITEM

0231 1606 2691 2698 3500 3501 3685 3691 3693 6691 6692 9901 9002

KEYBOARD

IR+LED-GL

2P 8/128A SDKV

-

FRNT INTERF. -

SLIM

EU / LA

YES

--YES YES YES YES

---

TO 0214

OF

FRONT

CONTROL

KEYBOARD

IR+LED-NA

YES YES

FRNT INTERF. -

SLIM

NA

--YES YES YES YES YES YES YES YES YES YES YES YEs

0214

I005

1

I006

2

3

I008

4

5

IR+LED-NA

YES YES

FRNT INTERF. -

SLIM

EU NON ULL01L

YES

---

6691

*

I007

3685

I010

*

560R

IR+LED

EU/AP

2P 8/128A SDKV

-

+3.3V

3691

330R

*

L01 USA ONLY

1606

I011

*

POWER

FRNT.INTERF

AP

YES YES

9695

-

FOR ITV ONLY

3693

*

I009

220R

2691

TOP CTL + FR.PL

INTERF - EU/NA

YES YES

10u

**

2698

100n

D

E

F

G

CL 16532020_103.eps

240801

H

12

H

CL 16532101_018.eps

230801

345

Schematics and PWB’s

38L01H.1E AA 02.01

Top Control Panel (RF)

12 3

TOP CONTROL PANEL (RF)

A

0215

1

TO 0239

OF

B

2

3

2010

3091

560R

10n

3092

390R 560R

3093

C+

1091

3094

270R

C-

1092 1093

V+

3096

1K5

3095

3K3

6091

BAT85

V-

1094

A

B

0215 A1 1091 B2 1092 B3 1093 B3 1094 C3 2010 B1 3091 A1 3092 A2 3093 A2 3094 A3 3095 A3 3096 C3 6091 B3

Layout Top Control Panel (RF) (Top Side)

1091 A1 1092 B1 1093 A2 1094 A1 6091 A1

C

PLUG&PLAY MENU

CL 16532020_053.eps

200301

12 3

CL 16532020_059.eps

030401

Schematics and PWB’s

39L01H.1E AA 02.01

Top Control Panel (FSQ)

12 3

TOP CONTROL PANEL (FSQ)

A

TO 0239

B

OF

0215

1

2

3

2010

560R

10n

3092

390R 560R

30933091

C+ C- V+

1091

3094

270R

1092 1093

1K5

3096

3095

3K3

BAT85

6091

V-

1094

A

B

0215 A1 1091 B2 1092 B3 1093 B3 1094 C3 2010 B1 3091 A1 3092 A2 3093 A2 3094 A3 3095 A3 3096 C3 6091 B3

Layout Top Control Panel (FSQ) (Top Side)

CL 16532020_100.eps

050601

0215 A2 1091 A2 1092 A1 1093 A2 1094 A1 6091 A2

C

PLUG&PLAY

MENU

CL 16532020_054.eps

200301

12 3

Philips L01H.1E AA Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

 Service Information L01H.1E AA 02.01

Introduction

Contents

 Service Information L01H.1E AA 02.01

Einführung

Inhalt

 Information Service L01H.1E AA 02.01

Introduction

Contents

Spare Parts List

Mono Carrier [A] and CRT Panel [B]

Side AV Panel [C + E1]

Front Interface [Q1]

Top control [T, T1]

Schematics and PWB’s

Mono Carrier: Power supply

Mono Carrier: Power supply Diversity Tables

Mono Carrier: Line Deflection

Mono Carrier: Line Deflection Diversity Tables

Mono Carrier: Line Deflection Diversity Tables

Mono Carrier: Frame Deflection

Mono Carrier: Tuner IF

Mono Carrier: Video IF + Sound IF

Mono Carrier: Synchronisation

Mono Carrier: Control

Mono Carrier: Audio Amplifier

Mono Carrier: Audio Amplifier Diversity Tables

Mono Carrier: NICAM + 2CS + BTSC (Stereo / SAP) Decoder

Mono Carrier: Audio / Video Source Switching

Mono Carrier: Front I/O + Front Control + Headphone

Mono Carrier: Front Control Diversity Tables

Mono Carrier: Rear I/O SCART Diversity Table

Mono Carrier: Rear I/O SCART

Mono Carrier: Tilt and Rotation

Layout Mono Carrier (Top Side)

Layout Mono Carrier (Mapping Top Side)

Layout Mono Carrier (Mapping Bottom Side)

Layout Mono Carrier (Overview Bottom Side)

Layout Mono Carrier (Part 1 Bottom Side)

Layout Mono Carrier (Part 2 Bottom Side)

Layout Mono Carrier (Part 3 Bottom Side)

Layout Mono Carrier (Part 4 Bottom Side)

CRT Panel

SCAVEM Panel

Layout CRT and SCAVEM Panel (Top Side)

Layout CRT and SCAVEM (Bottom Side)

Side AV + HP Panel

Layout Side AV + HP Panel (Top Side)

Side AV Panel + Headphone

Layout Side AV Panel + Headphone (Top Side)

Front Interface Panel

Layout Front Interface Panel (Top Side)

Top Control Panel (RF)

Layout Top Control Panel (RF) (Top Side)

Top Control Panel (FSQ)

Layout Top Control Panel (FSQ) (Top Side)
