Page 1
Philips
Mini Hi-Fi System
MP3
FWM570
MP3 Playback with MAX Sound
For those who value technology that enhances experiences, FWM570 has it all. Immerse
yourself in the power of Max Sound and fully appreciate your favorite MP3 music in
dynamic and rich sound.
Powerful sound you can hear and feel
• Class 'D' digital amplifier for quality sound performance
• 3-way Speaker System with MAX bass port
• 2 x 110W RMS/2 x 220W music power/3000W PMPO
Longer listening, greater enjoyment
• 30 hours of MP3-CD music playback
• 3-disc changer for convenient multi-disc playback
• Dual Logic Tape Deck with auto replay
Ready for gaming
• Gameport connection to your game console
• Game Sound modes for different types of games
• MIX-IT for mixing the game sound with your favorite music
Page 2
Mini Hi-Fi System
MP3
FWM570/33
Specifications
Sound
• Output Power: 3000W PMPO
• Sound Enhancement: Class "D" Digital Amplifier,
Loudspeakers
• Main Speaker: 3 way, Bass Reflex Speaker System,
Audio Playback
• Playback Media: CD, CD-R, CD-RW, MP3-CD
• Loader Type: 3 CD Carousel
• Number of Discs: 3
• Disc Playback Modes: Change 2 disc
• Cassette Deck Technology: Logic
•Number of decks: 2
• Cassette Playback Modes: Full Auto Stop,
Audio Recording
• Recording Media: Tape
• Tape Recording Enhancement: CD Synchro Start
Tuner/Reception/Transmission
• Auto digital tuning
• Tuner Bands: FM Stereo, MW
• Tuner Enhancements: Auto Store, Easy Set (Plug &
und, Digital Sound Control, Dynamic Bass
MAX So
Boost, Virtual Ambience Control, Game Sound,
MIX-IT
6.5" woofer, 2" tweeter, Piezo, Speaker grilles
detachable
1, Fast Forward/Backward, Next/Previous Track
Search, Repeat/one/all/program, Repeat/one/disk/
program, 99-Track Programmable
everse, Electronic Speed Control
Autor
ecording, Automatic Recording Level
R
s while playing
Play)
• Station presets: 40
Connectivity
• Aux in: Line in, Gameport
• Headphone: 3.5 mm
• Other connections: Composite video (CVBS) out,
tenna, MW Antenna
FM An
Convenience
•Alarms: CD Alarm, Radio Alarm, Sleep timer,
Wake to favourite track
• Clock: On main display
• Display Type: FTD
• Eco Power Standby: 1 watt
• Indications: DIM mode, album name, album
mber, artis name, Cd functions, date, file name,
nu
time, track
Accessories
• Remote control: 32-key with 2xAA Batteries
• Included accessories: AC Power Cord, FM/MW
a
Antenn
Dimensions
• Set dimensions (W x H x D): 265 x 322 x 384 mm
• Main speaker dimensions (W x H x D):
2 x 310 x 245 mm
24
• Packaging dimensions (W x H x D):
0 x 412 x 624 mm
51
• Weight incl. Packaging: 20.5 kg
Power
• Power supply: 110-240V, 50/60 Hz
• Standby power consumption: < 1 W
•
Highlights
Class 'D' Amplifier
Class ‘D’ Digital Amplifier takes an analog signal,
converts it into a digital signal and then amplifies the
signal digitally. The signal then enters a demodulation
filter to give the final output. The amplified digital
output delivers all the advantages of digital audio,
including improved sound quality. In addition, Class
‘D’ Digital Amplifier has greater than 90% efficiency
compared to traditional AB amplifiers. This high
efficiency translates into a powerful amplifier with a
small footprint.
3-way spk sys with MAX port
3-way Speaker System with MAX bass port
2x110W RMS/2x220W music power
2 x 110W RMS/2 x 220W music power/3000W
PMPO
30 hours of MP3-CD music
MP3 stands for "MPEG 1 Audio layer-3".MP3 is a
revolutionary compression technology by which
large digital music files can be made up to 10 times
smaller without radically degrading their audio
quality. MP3 has become the standard audio
compression format used on the world wide web,
allowing quick and easy audio file transfer.
3-disc changer
With a three-disc changer for music playback, you
can choose between three different CDs inside the
device at any one time. This convenient feature
allows you to savor a variety of music while saving
you precious time from changing CDs frequently.
Dual Logic Tape Deck
Dual Logic Tape Deck with auto replay
Issue date 2014-02-10
Version: 5.0.6
12 NC: 9073 100 11733
EAN: 87 10895 79551 7
Gameport connection
Gameport connection to your game console
Game Sound modes
Game Sound modes for different types of games
MIX-IT for mixing game sound
MIX-IT for mixing the game sound with your favorite
music
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
